Savaria Track Bridge User manual

To Be Retained by Owner After Installation by Authorized Savaria Dealer
Part No. 001-ENRev.00-m-20
Savaria
5SBDL#SJEHF.Y
5SBDL#SJEHF#BSJBUSJD.Y
OWNER’S
MANUAL

2
Track Bridge /Track Bridge Bariatric Owner’s Manual Part No. 001300-EN, 10-m10-2023
IMPORTANT
Be sure to read this entire manual before using the Savaria Track Bridge. The
information in this manual is important for the safety of the person being
transferred and the operator, and for the proper use and maintenance of the
device. Transfer always presents a potential risk and this manual provides
important safety information that must be read and understood to help
prevent injuries.
Unauthorized modifications to the device may affect its safety. Savaria Concord
Lifts, Inc. will NOT be held responsible for any accidents, incidents or
performance deficiencies that occur due to any unauthorized modification to
the device. To avoid potential injury due to the use of inadequate parts, always
use only Savaria replacement parts.
Regularly scheduled maintenance must be performed on your device by an
Authorized Savaria Dealer to ensure safety and proper operation of the device.
Refer to the Maintenance section in this manual
If a serious incident occurs in relation to the device should be
reported to the manufacturer or distributor of the device. In
the European community, the incident shall be reported as
well to the competent authority of the Member State in which
the user and/or patient is established.
Legal Manufacturer:
Savaria Concord Lifts, Inc.
2 Walker Drive
Brampton, Ontario L6T 5E1
Canada
European Representative:
Advena Ltd.
Tower Business Centre,
2nd Flr., Tower Street, Swatar,
BKR 4013 Malta
UK Responsible Person/Northern Ireland Authorised Representative:
Advena Ltd, Pure Offices, Plato Close,
Warwick. CV34 6WE UK
NOTE

3
Part No. 001300-EN, 10-m10-2023 Track Bridge /Track Bridge Bariatric Owner’s Manual
Australian Sponsor:
KD&A PTY LTD
286 Flinders St, Adelaide
South Australia, 5000
Copyright  2023
Savaria Concord Lifts, Inc.
All rights reserved.

4
Track Bridge /Track Bridge Bariatric Owner’s Manual Part No. 001300-EN, 10-m10-2023
STANDARD NOTATIONS
The following notations may be used throughout this manual to emphasize
important safety information, mechanical concerns, and other important
information. Please review and follow all of these messages.
Danger messages indicate an imminently hazardous
situation, which, if not avoided, results in death or serious
injury. All danger messages feature a standard ISO safety
alert symbol followed by the signal word DANGER in
capitalized black lettering on a red background.
Warning messages indicate a potentially hazardous
situation, which, if not avoided, could result in death or
serious injury. All warning messages feature a standard
ISO safety alert symbol followed by the signal word
WARNING in capitalized black lettering on a dark yellow
background.
Caution messages indicate a potentially hazardous
situation, which, if not avoided, could result in minor
injuries. All caution messages feature a standard ISO
safety alert symbol followed by the signal word CAUTION
in capitalized black lettering on a yellow background.
Note messages provide information, such as reminders,
general information about a previous statement, or
additional guidelines that do not fit into the flow of the
preceding text. All note messages include the signal
word NOTE in capitalized white lettering on a blue
background.
DANGER
WARNING
CAUTION
NOTE

5
Part No. 001300-EN, 10-m10-2023 Track Bridge /Track Bridge Bariatric Owner’s Manual
CONTENTS
1. OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Product Life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Using This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2. SAFETY INSTRUCIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
To Ensure Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Battery and Charger Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Fire and Explosion Prevention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Electric Shock Prevention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3. DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Exterior View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Device Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Charger (M920001). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4. SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5. USING THE DEVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Before Transfer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Using the Track Bridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Manual Operation (electrical). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Manual Operation (mechanical) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6. MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Environmental Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Operator Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Dealer Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Inspection and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
8. ELECTROMAGNETIC COMPATIBILITY. . . . . . . . . . . . . . . . . . . . . . . 32
Electromagnetic Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Electromagnetic Immunity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

6
Track Bridge /Track Bridge Bariatric Owner’s Manual Part No. 001300-EN, 10-m10-2023
1. OVERVIEW
This document is meant for both the Track Bridge (M92940x) and
Track Bridge Bariatric (M92942x). Unless specified, the manual
will only be referring to the track bridge.
Intended Use
The Track Bridge is designed for use by caregivers and health care professionals
to connect a mobile X-Y rail to a fixed rail together, thus allowing the ceiling lift
to move freely between both track routes in a homecare, assisted-living or
hospital environment. Transfer must be performed by a qualified operator as
described in this manual. Do NOT use the device for any other purpose.
Product Life
The device is designed for a useful life of 10 years after which time it must be
replaced. To ensure this life span, you must perform the preventive
maintenance as specified in the Maintenance section in this manual.
Savaria Concord Lifts, Inc. cannot ensure complete safety
for a device that has exceeded its useful life. Wear may
cause failure of a part and lead to a patient fall.
The expected life for other parts such as slings, batteries, fuses, straps, and
cords is dependent upon the proper care and use of the individual items. The
items must be maintained as described in their accompanying documentation
and in the Maintenance section in this manual.
NOTE
WARNING

7
Part No. 001300-EN, 10-m10-2023 Track Bridge /Track Bridge Bariatric Owner’s Manual
Using This Manual
To ensure safe operation of the device, read this entire manual carefully,
especially the Safety Instructions, before installing, using or maintaining the
device. Failure to comply with all WARNINGS in this manual may result in
injury. If there is anything you don't understand, contact your Authorized
Savaria Dealer for further details.
Keep this manual with the device and ensure all operators are fully trained in
the use of the device as described in this manual.

8
Track Bridge /Track Bridge Bariatric Owner’s Manual Part No. 001300-EN, 10-m10-2023
2. SAFETY INSTRUCTIONS
Keep these Safety Instructions with the device at all times. Read this entire
manual before installing, using or maintaining the device.
Do NOT use the device for any purpose other than to
transfer a person. To ensure safety of the person being
transferred and the operator, follow all Safety
Instructions.
To Ensure Safety
• The Track Bridge has a safe working load of 272 kg (600 lb). The Track
Bridge Bariatric has a safe working load of 544kg (1200 lb). If the
maximum load differs between the track bridge, the ceiling lift or a
ceiling lift accessory, then the lowest maximum load shall always be
used. Refer to the nameplate tags for the Maximum Load allowed.
• Ensure the track bridge is installed only with a Savaria ceiling track
system and used only with Savaria ceiling lifts.
• The track bridge and track system must be installed by a trained and
Authorized Savaria Dealer.
• Operators must be fully trained before using the ceiling lift and the
track bridge.
• Take care to avoid impact during transfer.
• Keep all components of the device clean and dry.
• Perform the “Before each use” checks and actions specified in the
Operator Maintenance Schedule before using the device.
• Ensure all checks and actions are performed at the frequency indicated
in the Maintenance section in this manual.
WARNING

9
Part No. 001300-EN, 10-m10-2023 Track Bridge /Track Bridge Bariatric Owner’s Manual
Battery and Charger Safety
Contact your Authorized Savaria Dealer if you are unsure
of any of the safety instructions provided below.
• Do NOT expose the battery or charger to water or any other liquid.
• To avoid injury, do NOT alter the battery in any way. Stop using the
battery if any damage is noted.
• Do NOT charge the battery in an unventilated area and do not cover
the charger.
• If the battery case cracks and the contents of the battery contact your
skin or clothing, rinse immediately with plenty of water.
• If the contents of the battery contact your eyes, rinse immediately with
plenty of water and seek medical attention.
• Inhalation of the contents of the battery can cause respiratory
irritation. Provide fresh air and seek medical attention.
• For recycling or disposal of batteries, follow the rules according to the
WEEE directive (Waste of Electronic and Electrical Equipment) as well
as all local laws and regulations. If you do not follow these rules, the
battery may explode, leak and cause personal injury.
Fire and Explosion Prevention
• Use only lithium ion batteries that are designed for use with the device.
• Use only the charger that is supplied with the device.
• Do NOT store batteries in an area with a temperature higher than 70
degrees C (158 degrees F).
• Do NOT store the battery in direct sunlight or near any heat source.
• Do NOT expose the battery or charger to flames.
• Do NOT use the charger in the presence of any flammable anaesthetic
gases.
• Do NOT short circuit the battery terminals.
• Do NOT incinerate the battery.
• Do NOT puncture the battery or try to open/dismantle the battery
WARNING

10
Track Bridge /Track Bridge Bariatric Owner’s Manual Part No. 001300-EN, 10-m10-2023
Electric Shock Prevention
• Do NOT touch or use the device if you notice any exposed or damaged
wires.
• Do NOT expose electrical parts of the device to water or moisture.
• Do NOT attempt to use the charger in an area that has a different
voltage and frequency requirement other than that specified on the
nameplate.
• Do NOT attempt any repairs to the device, battery or charger. Always
contact your Authorized Savaria Dealer for service.

11
Part No. 001300-EN, 10-m10-2023 Track Bridge /Track Bridge Bariatric Owner’s Manual
3. DESCRIPTION
Exterior View
The image below shows the track bridge uninstalled, viewed from below.
Figure 1
Note that the track bridge will only work with devices equipped with a
magnetic block as shown in the following figure. For magnetic block
installation, refer to the Track Installation section in the Track Installation Guide
(001076).
On/Off Switch

12
Track Bridge /Track Bridge Bariatric Owner’s Manual Part No. 001300-EN, 10-m10-2023
Figure 2
Magnetic block installed on
portable trolley when used with
Magnetic block installed on
fixed ceiling lift.
Magnetic block installed on
bariatric ceiling lift.
Magnetic block kit provided
with the track bridge and the
track bridge bariatric.
portable ceiling lift.

13
Part No. 001300-EN, 10-m10-2023 Track Bridge /Track Bridge Bariatric Owner’s Manual
Device Controls
Symbols Lights Indicator Meaning
Charge Light- OFF Device not connected to the charger (battery
powered unit only), power failure, device in
use.
Charge Light- Amber
(Solid)
Device is connected to charging system.
Power Light- OFF Device is OFF.
Power Light - Green
(Solid)
Device is powered ON and ready.
Power Light - Green
(Flashing)
Device battery is low. Still can be used, but
will require charging
Note: An audible beep is emitted
approximately every minute in addition to the
flashing indicator.
Power Light - Red
(Flashing)
Device battery is low. Not sufficient power
available to complete one full cycle. Requires
charging.
Power Light - Red (3
flashes sequence)
Battery overheat
Power Light - Red
(Solid)
Device malfunction (incomplete lock/unlock
action, jammed, time-out, etc.).
Maintenance Light -
OFF
Device is ready for use.
Maintenance Light -
Amber (Solid)
Inspection required. Call Authorized Savaria
Dealer.

14
Track Bridge /Track Bridge Bariatric Owner’s Manual Part No. 001300-EN, 10-m10-2023
Charger (M920001)
The device is supplied with a battery charger. Please note the charger may
slightly look different from the image below.
The track bridge is connected to the constant charging system (CCR system) in
the track. The battery charger is external to the track system and it is intended
to stay connected to the CCR at all times. The track bridge manages the battery
charging automatically as needed.
Figure 3
LED Description
1. Green LED (solid): Charger is powered, device is fully charged
or disconnected
2. Yellow, orange or red LED (depending on the charger version):
Device is charging
3. Green LED (blinking/fading): erroneous plugging sequence
(most likely to occur with M920001-X charger):
a. When this happens, user has to make sure that the charger
is powered (plugged to the wall) prior to connect it to the
device.

15
Part No. 001300-EN, 10-m10-2023 Track Bridge /Track Bridge Bariatric Owner’s Manual
Symbols
The following chart illustrates the symbols that may be used on the nameplate,
the packaging and the device.
Symbols on nameplate
Indicates the medical device manufacturer. This
symbol is accompanied by the address of the
manufacturer and the date of manufacture.
YYYY: Represents the year
MM: Represents the month
DD: Represents the day
Indicates the authorized representative in the
European Community.
This symbol is accompanied by the address of the
authorized representative.
Indicates the UK Responsible Person.
This symbol is accompanied by the address of the
UK Responsible Person.
Indicates the Australian Sponsor.
This symbol is accompanied by the address of the
Australian Sponsor.
Indicates the manufacturer's catalogue number
Indicates the manufacturer's serial number
Indicates a medical device that needs to be
protected from moisture
Indicates the product complies with the medical
device directive

16
Track Bridge /Track Bridge Bariatric Owner’s Manual Part No. 001300-EN, 10-m10-2023
Indicates the product was certified by third-party
“QPS”
Indicates the product complies with the directive
(RoHS)
Indicates separate collection for waste of electrical
and electronic equipment as per WEEE directive
Caution
Follow instructions for use
Consult instructions for use
Type BF protection against electrical shocks
MAX.LOAD:
Refers to the greatest permissible load that can be
applied to the product.
IPX1X2
Ingress Protection:
X1: Protection level against ingress of solid particles
X2: Protection level against ingress of liquids

17
Part No. 001300-EN, 10-m10-2023 Track Bridge /Track Bridge Bariatric Owner’s Manual
Unique Device Identifier (UDI) carrier according to
GS1.
Indicates the product is a medical device according
to EU Medical Device Regulation 2017/745
Symbols on box label
Indicates the temperature limits to which the
medical device can be safely exposed
Indicates the range of humidity to which the
medical device can be safely exposed
Indicates the range of atmospheric pressure to
which the medical device can be safely exposed

18
Track Bridge /Track Bridge Bariatric Owner’s Manual Part No. 001300-EN, 10-m10-2023
Symbols on device
Charge Light. Indicates that the device is on charge
or charged
Power Light. Indicates the power status
Maintenance Light. Indicates that maintenance is
recommended on the device
Lock button. Its hold locks the track bridge sections
together. To prevent sequence errors should be held
until the end of the action.
Unlock button. Its hold unlocks the track bridge
sections. To prevent sequence errors should be held
until the end of the action.
Clockwise rotation will lock track bridge sections
together
Counter-clockwise rotation will unlock track
bridge sections
Indicates the " Stop " button on the product

19
Part No. 001300-EN, 10-m10-2023 Track Bridge /Track Bridge Bariatric Owner’s Manual
4. SPECIFICATIONS
This equipment is not suitable in the presence of flammable anesthetic
mixtures with air or oxygen, or with nitrous oxide.
Product
Product Weight 9.8 kg (21.6 lb)
Product Life 10 years
Safe Working Load (SWL) -
Track Bridge
272 kg (600 lb)
Safe Working Load (SWL) -
Track Bridge Bariatric
544 kg (1200 lb)
Ingress Protection Rating IP20
Noise Level Maximum 54 dBA
Duty Cycle Max 10%, 1 min continuous use
Medical Equipment Class Class 1
Protection Class Type BF
Power Source
Battery Battery type: Lithium Ion, 25.2V, 2500mAh
(replaceable)
Charger
Input 100-240 VAC, 50-60Hz
Output 29.4 VDC, max 1A
Environmental Conditions: Operation
Temperature 5 °C to 40 °C (41 °F to 104 °F)
Battery Charging
Temperature
10 °C to 40 °C (50 °F to 104 °F)
Humidity 15 to 93%, non-condensing
Atmospheric Pressure 700 hPA to 1060 hPA
WARNING

20
Track Bridge /Track Bridge Bariatric Owner’s Manual Part No. 001300-EN, 10-m10-2023
Environmental Conditions: Transport/Storage
Temperature -25 °C to 70 °C (-13 °F to 158 °F)
Humidity 0 to 93%, non-condensing
Atmospheric Pressure 500 hPa to 1060 hPA
Controls
Control Ceiling lift presence detected by magnetic
sensor
Operating Force < 5 N
On/Off Switch Allows to bring the device into operation and
to safely terminate the operation.
Compliance
IEC 60601-1:2005 + corr1:2006 + corr2:2007 + A1:2012 (Medical Electrical
Equipment)
IEC 60601-1-11:2015 (Homecare)
ISO 10535:2021
CAN/CSA Z10535.1:15 (Patient Lift)
CE Marking per MDR (EU) 2017/745 (Medical Device)
2006/42/EC (Machinery Directive)
2015/863/EU (ROHS - 100% of components)
2012/19/EU (WEEE)
