OWNER’S MANUAL
(To Be Retained by Owner After Installation
by Authorized Savaria Dealer)
Part No. 000738
13-m07-2010
Step-Saver
Stairlift

2
Step-Saver Owner’s Manual Part No. 000738, 13-m07-2010
IMPORTANT
Ensure that only an authorized Savaria Dealer installs and services the Savaria™
Step-Saver Stairlift. Under no circumstances is anyone other than a dealer with
Savaria training and authorization to install, adjust, service or modify any
mechanical or electrical device on this equipment. Failure to follow this
warning can result in safety system compromises or defeat; this can result in
serious injury or death. Savaria accepts no liability for property damage,
warranty claims or personal injury, including death, in this circumstance.
Passenger safety is the result of countless details in the equipment’s design,
manufacture, and installation. After installation, reliable operation and
continual safe operation requires regular service and inspection at least twice
per year, or more frequently where usage, environment, or local jurisdiction
requires. As the Owner, you are responsible for ensuring that regular service
and inspections occur in a timely manner.
Refer to this manual for specifications, operating instructions and maintenance
of theSavaria™ Step-Saver Stairlift.
Upon completion of installation, the dealer must provide you with the
following information and ensure it is recorded in this manual. In addition,
either the dealer or you must keep any service and/or maintenance records in
the Maintenance Record section of this manual.
WARRANTY
Ensure your Savaria Dealer provides you with a copy of the manufacturer’s
limited parts warranty and documentation relating to any Dealer labour
warranty.
-------------------------------------------------------------------------------------------------
FOR OWNER’S RECORDS
Customer Name: _________________________________________
Installing Dealer: _________________________________________
Dealer’s Telephone Number: _______________________________
Date Installed: ___________________________________________
Serial/Job Number: _______________________________________

3
Part No. 000738, 13-m07-2010 Step-Saver Owner’s Manual
Table of Contents
TO ENSURE SAFE OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
1. DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2. SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3. FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Seating Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Safety Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Safety Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Footrest and Carriage Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4. OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Safeguards Before Operating the Stairlift . . . . . . . . . . . . . . . . . . . . . . . . . .8
Operating the Stairlift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
5. TROUBLESHOOTING AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Operator Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Stairlift Will Not Operate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Stairlift Emits Beeping Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Maintenance Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

4
Step-Saver Owner’s Manual Part No. 000738, 13-m07-2010
TO ENSURE SAFE OPERATION
To ensure safe operation of this equipment, pay careful attention to the
important notes below.
• Read this manual carefully before using the Savaria™ Step-Saver
Stairlift.
• To prevent accidents, adhere strictly to the instructions and keep clear
of moving parts at all times.
• Follow instructions on all equipment labels at all times. Replace any
damaged labels immediately.
• Ensure that only qualified personnel perform maintenance.

5
Part No. 000738, 13-m07-2010 Step-Saver Owner’s Manual
1. DESCRIPTION
Figure 1 shows the exterior components of the Step-Saver Stairlift.
Figure 1
Backrest
Flip-up
Folding seat
UP/DOWN
rocker switch
Seat belt
Folding
Carriage
footrest
armrests
Seat swivel
handle

6
Step-Saver Owner’s Manual Part No. 000738, 13-m07-2010
2. SPECIFICATIONS
Step-Saver Specifications
Applications Residential, indoor, straight-run stairway
Load capacity 300 lb (136 kg)
Maximum travel 32 ft (9.75 m)
Travel speed 20 ft/min (0.10 m/s)
Angle of incline 25° to 50°
Drive system Rack and pinion
Operator controls Constant pressure buttons (UP/DOWN rocker switch
on chair and remote control call/send units)
Motor 1/2 HP, 24 VDC
Fold-up width 15 1/2” (394 mm)
Rail
Aluminum extruded
For stairs with a door or hall at the bottom, optional
flip-up rail is available (constant charge system not
available with this option)
Charging
Charges on standard household power (110 VAC)
Constant charge system along the rail ensures the
stairlift is always charged
Emergency operation Battery-powered operation allows use even through
a power failure

7
Part No. 000738, 13-m07-2010 Step-Saver Owner’s Manual
3. FEATURES
Seating Features
The seat assembly is designed to swivel and lock in five positions. Lift up and
hold the swivel handle to swivel the seat to a convenient position for transfer
into or out of the seat. For your safety, do not swivel the seat until the unit has
stopped.
You can flip the armrests up and backwards to allow easier transfer into or out
of the seat. To raise the armrest, grasp the end of the armrest and flip it
backwards. Be sure to lower the armrest back to its original position whenever
you are seated in the chair.
When the stairlift is not in use, you can fold up the seat, footrest and armrests
to allow for more space on the stairway.
Always use the seat belt to ensure that you are safely secured in the chair during
travel.
Safety Features
Safety Switches
There are upper and lower limit switches on the Step-Saver to stop the stairlift
when it reaches the top or bottom of the stairway.
There is also a safety switch for the swivel seat that will prevent the unit from
running if the seat is not locked in the normal riding position.
Footrest and Carriage Sensors
There are edge sensors on the sides of the footrest and an underpan sensor on
the bottom of the footrest. There are also edge sensors on the sides of the
carriage. These sensors will stop the unit if an obstruction is encountered on
the stairway.
If you encounter an obstruction, press the opposite side of the UP/DOWN
rocker switch to run the stairlift in the opposite direction. Remove the obstacle
from the pathway and then proceed in the original direction of travel.

8
Step-Saver Owner’s Manual Part No. 000738, 13-m07-2010
4. OPERATION
Safeguards Before Operating the Stairlift
1Ensure the stairway is clear of any obstructions.
2Fasten your seat belt before operating the stairlift.
3Check that the seat is locked in the riding position for up/down travel.
Operating the Stairlift
1If the stairlift is not at the required end of the stairway, use one of the remote
control CALL/SEND units to call or send the stairlift to the appropriate end
of the rail. Be sure to point the remote at the lift.
2If necessary, fold down the seat, armrests, and footrest.
3Position yourself in the seat and fasten the seat belt.
4Lift up and hold the seat swivel handle, and then rotate the seat so that you
are parallel to the rail (with your back against the stairway wall).
5Release the seat swivel handle to secure the seat in the riding position.
6Position both feet securely on the footrest and place your arms on the
armrest cushions.
7Press and hold one end of the UP/DOWN rocker switch (located on the front
end of the right arm) to move the stairlift in the desired direction.
8The stairlift will stop automatically at the upper or lower end of the rail, or
when the rocker switch is released.
9Once the stairlift has come to a complete stop, swivel the seat as required,
unfasten the seat belt, and get out of the chair.
10 To allow for more room on the stairway, you can fold up the seat, armrests,
and footrest when the stairlift is not in use.
NOTE
Do not unplug the unit from the wall or the batteries will not
charge.

9
Part No. 000738, 13-m07-2010 Step-Saver Owner’s Manual
5. TROUBLESHOOTING AND MAINTENANCE
Operator Troubleshooting
Stairlift Will Not Operate
If your stairlift will not operate, check the basic items listed below first.
1Check that the stairlift is plugged in to the wall outlet.
2Check the swivel seat. Is the seat locked in the riding position?
3Check around the footrest and carriage. Is there an obstruction on the
stairway?
4Check the residence main circuit breaker (or fuse) panel. Has a breaker
tripped or a fuse blown?
5Make a visual check. Do you notice anything about your stairlift that is
different or out of place?
If the stairlift does not operate after checking the above items, contact your
Authorized Savaria Dealer to perform all required services, repairs and
maintenance.

10
Step-Saver Owner’s Manual Part No. 000738, 13-m07-2010
Maintenance Schedule
NOTE
Verification by owner Frequency
Verify that the swivel seat switch is working.
To do this, ensure the unit will not travel until the swivel seat
is locked in the riding position.
Every 3 months
Verify that the footrest and carriage sensors are working.
To do this, ensure the unit stops when it contacts an
obstacle.
Every 3 months
Lubricate the rack using white lithium grease Every 3 months
Verification by technician Frequency
Verify that the upper and lower limit switches are working.
To do this, ensure the unit stops at the required position at
the top and bottom of the stairway.
Every 6 months
Visually inspect the rack and gear. Every 6 months
Lubricate the rollers using white lithium grease. As required
The owner can perform the 3-month checks, but the 6-month checks
must be performed by a Qualified Technician. Contact your Authorized
Dealer. Note also that the maintenance is not covered by warranty.
Maintenance Schedule

11
Part No. 000738, 13-m07-2010 Step-Saver Owner’s Manual
Maintenance Record
Date Time Reason for Call Comments Dealer
