SCHUBERTH SC2 User manual

SC2
MOTORCYCLE BLUETOOTH®
COMMUNICATION SYSTEM
WITH MESH INTERCOM™
USER’S GUIDE
ENGLISH
Version 1.0.1

TABLE OF CONTENTS
1. ABOUT THE SC2 6
1.1 Product Details 6
1.1.1 SC2 6
1.1.2 SC2 Remote Control 6
1.2 Package Contents 7
1.3 Optional Accessories 7
2. INSTALLING THE HEADSET ON YOUR HELMET 8
2.1 Installing the SC2 Remote Control 8
2.2 Installing the SC2 8
2.3 Removing the SC2 10
2.4 Installing the Microphone 11
3. GETTING STARTED 12
3.1 Legend 12
3.2 Downloadable Software 12
3.2.1 SCHUBERTH SC2 App 12
3.2.2 SCHUBERTH Device Manager 12
3.3 Powering On and O 13
3.3.1 SC2 Powering On and O 13
3.3.2 SC2 Remote Control Powering On and O 13
3.4 Charging the SC2 14
3.5 Replacing the Battery 14
3.6 Checking the Battery Level 15
3.7 Volume Adjustment 15
4. PAIRING THE HEADSET WITH OTHER
BLUETOOTH DEVICES 16
4.1 Phone Pairing 16
4.2 Second Mobile Phone Pairing - Second Mobile
Phone, GPS, and SR10 17

TABLE OF CONTENTS CONTINUED
4.3 Advanced Selective Pairing: Hands-Free or
A2DP Stereo 18
4.3.1 Phone Selective Pairing - Hands-Free Prole 18
4.3.2 Media Selective Pairing - A2DP Prole 18
4.4 GPS Pairing 19
5. MOBILE PHONE USAGE 20
5.1 Making and Answering Calls 20
5.2 Siri and Google Assistant 20
5.3 Speed Dialing 21
5.3.1 Assigning Speed Dial Presets 21
5.3.2 Using Speed Dial Presets 21
6. STEREO MUSIC 22
6.1 Bluetooth Stereo Music 22
6.2 Music Sharing 22
6.2.1 Bluetooth Intercom Music Sharing 23
6.2.2 Mesh Intercom Music Sharing 23
7. MESH INTERCOM 24
7.1 What is Mesh Intercom? 24
7.1.1 Open Mesh 25
7.1.2 Group Mesh 26
7.2 Starting Mesh Intercom 26
7.3 Using the Mesh in Open Mesh 27
7.3.1 Channel Setting (Default: Channel 1) 27
7.4 Using Mesh in Group Mesh 28
7.4.1 Creating a Group Mesh 28
7.4.2 Joining an Existing Group Mesh 29
7.5 Enable/Disable Mic (Default: Enable) 30
7.6 Toggling Open Mesh/Group Mesh 30
7.7 Reset Mesh 30

TABLE OF CONTENTS CONTINUED
8. BLUETOOTH INTERCOM 31
8.1 Intercom Pairing 31
8.1.1 Using the Smart Intercom Pairing (SIP) 31
8.1.2 Using the Button 32
8.2 Last-Come, First-Served 32
8.3 Two-Way Intercom 33
8.4 Multi-Way Intercom 34
8.4.1 Starting a Three-Way Intercom Conference 34
8.4.2 Starting a Four-Way Intercom Conference 35
8.4.3 Ending Multi-Way Intercom 35
8.5 Three-Way Conference Phone Call with
Intercom Users 36
8.6 Group Intercom 37
8.7 Mesh Intercom Conference with Bluetooth
Intercom Participant 37
8.8 Universal Intercom 39
8.9 Mesh Intercom Conference with Two-way
Universal Intercom Participant 40
9. USING THE FM RADIO 41
9.1 FM Radio On/O 41
9.2 Seek and Save Radio Stations 41
9.3 Scan and Save Radio Stations 42
9.4 Navigating Preset Stations 43
9.5 Temporary Station Preset 43
9.6 Region Selection 43
10. VOICE COMMAND 44
11. FUNCTION PRIORITY 46
11.1 Function Priority 46

TABLE OF CONTENTS CONTINUED
12. CONFIGURATION SETTING 47
12.1 Headset Conguration Setting 47
12.1.1 Delete All Pairings 47
12.2 Software Conguration Setting 48
12.2.1 Speed Dial 48
12.2.2 Headset Language 48
12.2.3 Audio Equalizer (Default: O) 48
12.2.4 VOX Phone (Default: Enable) 48
12.2.5 VOX Intercom (Default: Disable) 48
12.2.6 VOX Sensitivity (Default: 3) 49
12.2.7 Bluetooth Intercom Audio Multitasking
(Default: Disabled) 49
12.2.8 Intercom-Audio Overlay Sensitivity (Default: 3) 49
12.2.9 Audio Overlay Volume Management
(Default: Disable) 49
12.2.10 HD Intercom (Default: Enable) 50
12.2.11 HD Voice (Default: Enable) 50
12.2.12 Smart Volume Control (Default: Disable) 50
12.2.13 Sidetone (Default: Disable) 50
12.2.14 Voice Prompt (Default: Enable) 51
12.2.15 RDS AF Setting (Default: Disable) 51
12.2.16 FM Station Guide (Default: Enable) 51
12.2.17 Advanced Noise Control™ (Default: Enable) 51
13. TROUBLESHOOTING 52
13.1 SC2 Factory Reset 52
13.2 SC2 Remote Control Factory Reset 52
13.3 Remote Control Pairing 52
13.4 SC2 Fault Reset 53

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 6
1. ABOUT THE SC2
1.1 Product Details
1.1.1 SC2
DC Power Charging &
Firmware Upgrade Port
Multi-function Button
Status LED
1.1.2 SC2 Remote Control
(+) Button
(-) Button
Center Button
Mesh Intercom Button
Battery Slot
Battery Release Hole

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 7
1 ABOUT THE SC2
1.2 Package Contents
SC2 SC2 Remote Control SC2 HD Boom
Microphone
USB-C Power &
Data Cable Coin Battery Foam cover for SC2 HD Boom Microphone (2)
1.3 Optional Accessories
Contact SCHUBERTH or your authorized dealer for accessories.
Part Number Spare Part
9049100370
SC2 HD Boom Microphone with foam cover
9049100372
Foam cover for SC2 HD Boom Microphone
9049100374
Remote Control for SC2
9049100375
USB-C Power & Data Cable

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 8
2. INSTALLING THE HEADSET ON
YOUR HELMET
2.1 Installing the SC2 Remote Control
1. Remove the cover for the SC2 Remote Control from your helmet.
Cover for the SC2 Remote Control
2. Slide and insert the SC2 Remote Control onto your helmet.
2.2 Installing the SC2
1. Remove the SC2 cover from the helmet by lifting it up with the SC2
Remote Control cover.

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 9
2 INSTALLING THE HEADSET ON YOUR HELMET
2. Pull out the antenna cable retainer from its original position, and pull out the
antenna cables from the upper gap in the space. Then, connect the SC2’s
antenna cables and the helmet’s antenna cables correctly.
Click
Antenna
cable
retainer
3. Put the antenna cable retainer back into its original position, and put the
connected cables into the upper gap in the space.
Note: Make sure that the antenna cable retainer and the connected cables
are positioned correctly before installing the SC2. If not, the cables may be
damaged or interference may occur.

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 10
2 INSTALLING THE HEADSET ON YOUR HELMET
4. Install the SC2 into the helmet.
Click
2.3 Removing the SC2
1. Remove the installed SC2 from the helmet by lifting it up with the SC2
Remote Control cover.
2. Pull the antenna cable retainer out from its original position, and pull out the
connected cables from the upper gap in the space. Then, disconnect the
cables correctly.
Note: When you need to un-plug the connectors, please wiggle and pull
them. It will help the connector connection be released more easily.

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 11
2 INSTALLING THE HEADSET ON YOUR HELMET
3. Put the antenna cable retainer back into its original position, and put the
helmet’s cables into the upper gap in the space.
2.4 Installing the Microphone
1. Remove the microphone rubber cap as shown in the illustration to install
the microphone.
2. Install the microphone.

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 12
3. GETTING STARTED
3.1 Legend
= /
Function =Button(s) to tap the specified amount of number of times or
press and hold for the specified amount of time.
“Hello” Audible prompt
3.2 Downloadable Software
3.2.1 SCHUBERTH SC2 App
SCHUBERTH SC2 APP
By simply pairing your phone with your headset, you can use the
SCHUBERTH SC2 App for quicker and easier set up and management.
• App functions: Mesh Intercom, Bluetooth Intercom, Music, Device settings,
Language settings
• Download
_
Android: Google Play Store > SCHUBERTH SC2
_
iOS: App Store > SCHUBERTH SC2
3.2.2 SCHUBERTH Device Manager
The SCHUBERTH Device Manager allows you to upgrade the firmware and
configure its settings directly from your PC or Apple computer.
Download the SCHUBERTH Device Manager from oem.sena.com/schuberth/.
Click Here to Visit oem.sena.com/schuberth/

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 13
3 GETTING STARTED
3.3 Powering On and O
3.3.1 SC2 Powering On and O
To switch on the SC2, hold the Multi-function Button for 2 seconds.
To switch off the SC2, hold the Multi-function Button for 2 seconds until
you hear the double beep.
Powering On/Off
=
“Hello” or “Good bye”
3.3.2 SC2 Remote Control Powering On and O
• To begin using the SC2 Remote Control, remove the plastic strip from the
battery slot.
Plastic Strip
• Tap the Center Button.
Powering On
=
• Press and hold the (+) Button and the Center Button for 3 seconds.
Powering Off
=
Note: The SC2 and the SC2 Remote Control come paired together.
They will automatically connect to each other when the SC2 and the SC2
Remote Control are powered on.

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 14
3 GETTING STARTED
3.4 Charging the SC2
Charging the Headset
The headset will be fully
charged in about 2.5 hours.
(The charging time may vary
depending on the charging
method.)
Note:
• Please make sure to take off your SC2-installed helmet while charging.
The headset automatically turns off during charging.
• Any 3rd party USB charger can be used with the headset if the charger is
approved by either the FCC, CE, or IC.
• The SC2 is compatible with 5 V/1 A input USB-charged devices only.
3.5 Replacing the Battery
To replace the discharged battery of the SC2 Remote Control, follow the
steps below:
1. Prepare a CR2016 Lithium 3 V coin battery for the SC2 Remote Control.
2. Open the battery slot’s cover.
3. Insert a paper clip into the Battery Release Hole. Then, change the
discharged battery with the new battery.

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 15
3 GETTING STARTED
4. Insert the new battery into the battery slot.
CR 2016
5. Close the battery slot’s cover. When closing the cover, insert the cover’s
two battery guides first.
3.6 Checking the Battery Level
When switching on, the LED flashes red to indicate the charge level.
SC2
=
=
=
=
SC2 Remote Control
=
=
=
=
Note: When the SC2’s battery is low while in use, you will hear a voice
prompt saying “Low battery”.
3.7 Volume Adjustment
You can raise or lower the volume by tapping the (+) Button or the
(-) Button. Volume is set and maintained independently at different levels for
each audio source (i.e., phone, intercom), even when the headset is rebooted.
Volume Up
=
Volume Down
=

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 16
4. PAIRING THE HEADSET WITH
OTHER BLUETOOTH DEVICES
When using the headset with other Bluetooth devices for the first time, they
will need to be “paired”. This enables them to recognize and communicate with
one another whenever they are within range.
The headset can pair with multiple Bluetooth devices such as a mobile phone,
GPS, MP3 player, or Sena SR10 Two-Way Radio Adapter via Mobile Phone
Pairing, Second Mobile Phone Pairing, and GPS Pairing. The headset can
also be paired with up to three other SCHUBERTH headsets.
Pairs with up to Three SCHUBERTH Headsets
Also Pairs with:
Mobile
Phone
MP3
Player
GPS
Devices
Sena
SR10
4.1 Phone Pairing
Phone Pairing
1. Press and hold the Center Button for 10 seconds.
=
“ Conguration menu ”
2. Tap the (+) Button.
=
Blinking alternatively
“Phone pairing”

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 17
4 PAIRING THE HEADSET WITH OTHER BLUETOOTH DEVICES
3. With your mobile phone in Bluetooth-pairing mode, select SC2 in the list of
devices detected.
If your mobile phone asks for a PIN, enter 0000.
Device B
Pi
Bluetooth
SC2
PIN =
4.2 Second Mobile Phone Pairing - Second Mobile
Phone, GPS, and SR10
1. Press and hold the Center Button for 10 seconds.
=
“ Conguration menu ”
2. Double tap the (+) Button.
=
Blinking
“Second mobile phone
pairing”
3. With your mobile phone in Bluetooth-pairing mode, select SC2 in the list of
devices detected.
If your device asks for a PIN, enter 0000.
Device B
Pi
Bluetooth
SC2
PIN =

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 18
4 PAIRING THE HEADSET WITH OTHER BLUETOOTH DEVICES
4.3 Advanced Selective Pairing: Hands-Free or
A2DP Stereo
Phone Pairing allows the headset to establish two Bluetooth profiles: Hands-
Free or A2DP Stereo. Advanced Selective Pairing allows the headset to
separate the profiles to enable connection with two devices.
4.3.1 Phone Selective Pairing - Hands-Free Prole
1. Press and hold the Center Button for 10 seconds.
=
“ Conguration menu ”
2. Tap the (+) Button three times.
=
Blinking
“Phone selective pairing”
3. Select SC2 in the list of Bluetooth devices detected.
If your mobile phone asks for a PIN, enter 0000.
Device B
Pi
Bluetooth
SC2
PIN =
4.3.2 Media Selective Pairing - A2DP Prole
1. Press and hold the Center Button for 10 seconds.
=
“ Conguration menu ”
2. Tap the (+) Button four times.
=4x
Blinking
“Media selective pairing”

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 19
4 PAIRING THE HEADSET WITH OTHER BLUETOOTH DEVICES
3. Select SC2 in the list of Bluetooth devices detected.
If your mobile phone asks for a PIN, enter 0000.
Device B
Pi
Bluetooth
SC2
PIN =
4.4 GPS Pairing
1. Press and hold the Center Button for 10 seconds.
=
“ Conguration menu ”
2. Tap the (+) Button five times.
=5x
Blinking
“GPS pairing”
3. Select SC2 in the list of Bluetooth devices detected.
If your device asks for a PIN, enter 0000.
Device B
Pi
Bluetooth
SC2
PIN =
Note: If you pair your GPS device via GPS Pairing, its instruction will
not interrupt your Mesh Intercom conversations, but overlay with them.
Bluetooth intercom conversations will be interrupted by GPS instructions.

SC2 Motorcycle Bluetooth®Communication System with Mesh Intercom™ | 20
5. MOBILE PHONE USAGE
5.1 Making and Answering Calls
Answer a Call End a Call
= =
Reject a Call
=
Note: If you have a GPS device connected, you will not hear its voice
navigations during a phone call.
5.2 Siri and Google Assistant
The headset supports the Siri and Google Assistant access directly. You can
activate the Siri or Google Assistant using the voice through the headset’s
microphone, a wake word will be used. This is a word or a group of words such
as “Hey Siri” or “Hey Google”.
Activate the Siri or Google Assistant installed on Your Smartphone
=
“Hey Google” or “Hey Siri”
or “[Beep, Beep]”
