Schulte V1280 User manual

©2016 Alamo Group Inc.
Published 07/16 SN: CS0110461703-CS0110530905 inclusive Part No. CS01-010C
OPERATOR’S MANUAL
This Operator's Manual is an
integral part of the safe operation
of this machine and must be
maintained with the unit at all
times. READ, UNDERSTAND, and
FOLLOW the Safety and
Operation Instructions contained
in this manual before operating
the equipment. C01-Cover_S
Important Operating
and Safety Instructions
are found in the Mower
Safety Video that can
be instantly accessed
on the internet at:
www.algqr.com/save
$0.00
V1280
Rotary Cutter
Schulte Industries Ltd.
PO Box 70
Englefeld Saskatchewan
Canada S0K 1N0
Tel. [phone]
Fax. [phone]
Parts Fax. [phone]
Web: www.schulte.ca

In order to reduce accidents and enhance the safe operation of mowers, Schulte, in cooperation with other industry
manufacturers has developed the AEM/FEMA Industrial and Agricultural Mower Safety Practices video and guide
book.
The video will familiarize and instruct mower-tractor operators in safe practices when using industrial and
agricultural mowing equipment. It is important that Every Mower Operator be educated in the operation of their
mowing equipment and be able to recognize the potential hazards that can occur while operating a mower. This
video, along with the mower operator’s manual and the warning messages on the mower, will significantly assist in
this important education.
Your Authorized Schulte Dealer may have shown this video and presented you a DVD Video when you purchased
your mower. If you or any mower operator have not seen this video, Watch the Video, Read this Operator’s
Manual, and Complete the Video Guidebook before operating your new mower. If you do not understand any of
the instructions included in the video or operator’s manual or if you have any questions concerning safety of
operation, contact your supervisor, dealer or Schulte.
If you would like a VHS video tape of the video, please e-mail [e-mail] or Fax AEM VHS
Video at [phone] or mail in a completed copy of the form on the back of this page to AEM VHS Video 1502
E Walnut Street, Seguin, TX 78155. and request the VHS video version. Please include your name, mailing
address, mower model and serial number.
Every operator should be trained for each price of equipment (Tractor and Mower), Understand the intended use,
and the potential hazards before operating the equipment.
The information and material listed above along with this Operator’s Manual can assist you in meeting the OSHA
requirement for Operator annual training.
OSHA TRAINING REQUIREMENTS
The following training requirements have been taken from Title 29, Code of Federal Regulations Part
1928.57 (a)(6). www.osha.gov
Operator Instructions. At the time of initial assignment and at least annually thereafter, the employer shall instruct
every employee who operates an agricultural tractor or implement in the safe operating practices and servicing of
equipment with which they are or will be involved, and of any other practices dictated by the work environment.

Schulte Industries LTD. is willing to provide
one (1) AEM Mower Safety Practices Video
Please Send Me: VHS Format – AEM/FEMA Mower Operator Safety Video
DVD Format – AEM/FEMA Mower Operator Safety Video
Mower Operator’s Manual
AEM Mower Operator’s Safety Manual
Requester Name:_____________________________________Phone:_____________________________
Requester Address:______________________________________
City:____________________________________
State:___________________________________
Zip Code: _______________________________
Mower Model:____________________________Serial Number:____________________________
Date Purchased:___________________________Dealer Salesperson:_________________________
Dealership Name:_________________________ Dealership Location:________________________
Mail to:
AEM Video Services
1502 E. Walnut Street
Seguin, TX 78155
Or Fax to:
[phone]
Or E-mail to:
AEMV[email protected]

To the Owner/Operator/Dealer
This Operator's Manual is an integral part of the safe operation of this machine and must be maintained with the
implement at all times. A Manual canister is provided on the implement where this manual can be properly stored.
If you lose or damage this manual a free replacement manual can be obtained from an authorized Schulte dealer or
by down loading the manual from the Schulte website www.schulte.ca
BEFORE YOU START! READ, UNDERSTAND, and FOLLOW the information provided in this manual, the AEM
Mower Safety manual and the tractor operator's manual carefully to learn how to operate and service your machine
properly. Failure to do so could result in personal injury to you and bystanders. All implements with moving parts
are potentially hazardous. Every effort has been made to ensure that the machine is safe but operators must avoid
engaging in unsafe practices and follow the written instructions provided. The manufacturer has designed this
implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
SAFETY FIRST. Completely read and understand the safety section of this manual before operating this
equipment. Do not allow anyone to operate this equipment who has not fully read and understood this manual.
Contact your Dealer to explain any instructions that you do not fully understand.
The care you give your Schulte Implement will greatly determine your satisfaction with its performance and its
service life. Carefully read and follow the instructions in this manual to provide you with a thorough understanding
of your new implement and its intended use and service requirements.
All references made in this manual to right, left, front, rear, top or bottom are as viewed facing the direction of
forward travel with the implement properly attached to the tractor.
Replacement Parts information is located in a separate Parts Manual. Schulte mowers use balanced and matched
system components for blade carriers, blades, cuttershafts, knives, knife hangers, rollers, drivetrain components,
and bearings. These parts are made and tested to Schulte specifications. Non-genuine “will fit” parts do not
consistently meet these specifications. The use of “will fit” parts may reduce mower performance, void warranties,
and present a safety hazard. Use genuine Schulte mower parts for economy and safety.
For future reference, record your Schulte product model number and serial number.
Dealer Telephone Model Number
Owner Purchase Date: Serial Number

DEALER to CUSTOMER Pre-Delivery/ Operation Instructions
Dealer should inform the Purchaser of this product of Warranty terms, provisions, and procedures that are
applicable. Dealer should inform Purchaser to review the contents of the Operator’s Manual including safety
equipment, safe operation and maintenance, to review the Safety Signs on the implement (and tractor if possible)
and of Purchaser’s responsibility to train his/her operators’s of safe operation procedures.
•IMPLEMENTS: I have explained that Deflectors, Chain Guards, or Solid Skirts must be installed and
maintained in good repair.
•DRIVELINES: I have made certain that all driveline, gearbox, and other shields are in good repair and
fastened securely in place to prevent injuries from entanglement or thrown objects.
•HYDRAULIC MACHINES: I have explained the necessity of using clean hydraulic oil, changing filters as
instructed, stopping leaks, damage caused by operating with over-heated oil, caring for hoses, using hoses of
proper rating, maintaining the specified operating pressure and the potential hazard of oils penetrating the
skin.
•FOLDING-TYPE IMPLEMENTS: I have explained that it is not possible to guard against thrown objects when
the head is lifted off ground and that operator is responsible to watch out for persons in the area. I have
explained that the lifted mower head or boom can contact overhead obstructions with damage to cables and
telephone lines and possible injury. I have explained that the extended head or boom or retracted boom can
contact power lines resulting in electrocution, injury or death and that operator is responsible for keeping clear
of such hazards.
PRE-DELIVERY SERVICE
CHECK AND ADJUST OR LUBRICATE AS REQUIRED
See Operator’s Manual for Details
Inspection Performed - Warranty and Safety Procedures Explained - Installation Complete
LUBRICATION & HYDRAULICS
Gearbox (Oil Levels)
Hydraulic Oil Level (External Tank)
Tractor Hydraulic Oil Level
Hydraulic Hoses (Not Kinked Tighten Connections)
Front Pump Drive (Assembly Is Tight And Shaft Properly
Aligned)
MOWER
Spindle And Motor Bolts Properly Torqued
Spindle Oil Level
Blade Carrier Bolts Properly Torqued/Retaining Pin In
Place
Mower Cutting Height And Level Adjusted
Cutting Shaft Bearings Lubricated
All Hardware Properly Torqued
Tire and Air Pressure/Lug Nuts (Correct Torque)
Wheel Bearings (Check, Grease, and Preload)
ATTACHMENTS & INSTALLATION
Deflectors Front And Rear
Shredding Attachments
Correct Blade Rotation Direction
Axle Arms And Beams
Tongue And Control Rods (Installed And Adjusted)
All Bolts - Pins And Nuts (Proper Torque)
MOWER TO TRACTOR CONNECTIONS
Draw Bar Length (Check And Set)
A-Frame Pivot & Links
Control Rods (Adjusted Equal)
Axle Height (Adjusted)
Cutting Height (Adjust)
Mount Kit-Pre-Operation Check Complete
Mower Wing (Adjust Level With The Center)
Mower Wing (Check For Proper Raising Operation)
C.V. Drivelines (Check Max Turn Radius)
Pull Type Hitch (Height Adjustment)
Mounting Hardware Properly Torqued
SAFETY ITEMS
Protective Shields (Operation And Installation)
Driveline Clutch (Torque Limiter) (Adjust And Run In)
Safety Decals (Installed)
Operator’s Manual (Supplied)
Tractor PTO Shield (Installed)
S.M.V. Emblem (Installed If Needed)
Tongue Jack (Installation and Operation)
Safety Tow Chain (Installed)
ADMA Driveline Safety Manual Supplied
AEM Mower Safety Manual (Supplied in Canister)
AEM Mower Safety Video has been shown to Purchaser

Table of Contents
SAFETY SECTION .............................................................................................................. 1-1
GENERAL SAFETY INSTRUCTIONS AND PRACTICES .................................................................................1-2
OPERATOR SAFETY ........................................................................................................................................1-3
CRUSHING HAZARDS ...................................................................................................................................... 1-4
CONNECTING OR DISCONNECTING IMPLEMENT SAFETY ........................................................................1-5
THROWN OBJECTS HAZARDS .......................................................................................................................1-6
THROWN OBJECTS HAZARD (CONTINUED) .................................................................................................1-7
RUN OVER HAZARDS ......................................................................................................................................1-8
PTO ENTANGLEMENT HAZARDS ...................................................................................................................1-9
MOWER BLADE CONTACT HAZARDS .......................................................................................................... 1-10
HIGH PRESSURE OIL LEAK HAZARD ........................................................................................................... 1-11
ELECTRICAL & FIRE HAZARDS ....................................................................................................................1-12
TRANSPORTING HAZARDS .......................................................................................................................... 1-13
HAZARDS WITH MAINTENANCE OF IMPLEMENT ....................................................................................... 1-14
PARTS INFORMATION ................................................................................................................................... 1-15
Decal Location ................................................................................................................................................. 1-16
Decal Description ............................................................................................................................................. 1-18
Federal Laws and Regulations ........................................................................................................................1-27
INTRODUCTION SECTION ................................................................................................. 2-1
EQUIPMENT SPECIFICATIONS .......................................................................................................................2-3
KEY OPERATION POINTS ...............................................................................................................................2-4
Operating Noise Level/Sound Pressure .............................................................................................................2-4
ASSEMBLY SECTION ........................................................................................................ 3-1
General Assembly ..............................................................................................................................................3-2
Connection to Tractor ........................................................................................................................................ 3-2
Driveline Attachment .......................................................................................................................................... 3-2
Lowering Wings ................................................................................................................................................. 3-3
Driveline Shield Chains ...................................................................................................................................... 3-3
Laminated Tires ................................................................................................................................................. 3-4
Blade Rotations ..................................................................................................................................................3-4
OPERATION SECTION ....................................................................................................... 4-1
OPERATOR REQUIREMENTS ......................................................................................................................... 4-3
TRACTOR REQUIREMENTS ............................................................................................................................ 4-4
ROPS and Seat Belt .......................................................................................................................................... 4-4
Tractor Safety Devices ....................................................................................................................................... 4-4
Tractor Horsepower ........................................................................................................................................... 4-5
Drawbar ............................................................................................................................................................. 4-5
Tractor Hydraulics .............................................................................................................................................. 4-5
Front End Weight ............................................................................................................................................... 4-5
Power Take Off (PTO) ....................................................................................................................................... 4-5
Tire Spacing ....................................................................................................................................................... 4-6
GETTING ON AND OFF THE TRACTOR .........................................................................................................4-6
Boarding the Tractor .......................................................................................................................................... 4-7
Dismounting the Tractor ..................................................................................................................................... 4-7
STARTING THE TRACTOR ..............................................................................................................................4-8
CONNECTING THE MOWER TO THE TRACTOR ........................................................................................... 4-8
Connecting the Mower Tongue to the Tractor ................................................................................................... 4-9
Safety Tow Chain ............................................................................................................................................... 4-9
SETTING THE MOWER ..................................................................................................................................4-10
Setting Deck Height ......................................................................................................................................... 4-11

Setting Deck Pitch ............................................................................................................................................ 4-12
DRIVELINE ATTACHMENT ............................................................................................................................4-13
Constant Velocity (CV) Driveline ...................................................................................................................... 4-14
PRE-OPERATION INSPECTION AND SERVICE ...........................................................................................4-15
Tractor Pre-Operation Inspection/Service ........................................................................................................ 4-16
Mower Pre-Operation Inspection/Service ........................................................................................................ 4-16
Cutting Component Inspection ......................................................................................................................... 4-20
Blade Bolt Inspection ....................................................................................................................................... 4-22
DRIVING THE TRACTOR AND IMPLEMENT .................................................................................................4-25
Starting the Tractor .......................................................................................................................................... 4-26
Brake and Differential Lock Setting .................................................................................................................. 4-26
Operating the Cutter Wings ............................................................................................................................. 4-26
Driving the Tractor and Mower ......................................................................................................................... 4-28
OPERATING THE TRACTOR AND IMPLEMENT ...........................................................................................4-30
Foreign Debris Hazards ................................................................................................................................... 4-31
Bystanders/Passersby Precautions ................................................................................................................. 4-31
Engaging the Power Take Off (PTO) ............................................................................................................... 4-32
PTO RPM and Ground Speed ......................................................................................................................... 4-33
Operating the Mower ....................................................................................................................................... 4-33
Right of Way (Highway) Mowing ...................................................................................................................... 4-36
Shutting Down the Implement .......................................................................................................................... 4-37
DISCONNECTING THE MOWER FROM THE TRACTOR ............................................................................. 4-37
MOWER STORAGE ........................................................................................................................................ 4-39
TRANSPORTING THE TRACTOR AND IMPLEMENT ................................................................................... 4-39
Tire and Wheels ............................................................................................................................................... 4-41
Transporting on Public Roadways ................................................................................................................... 4-42
Hauling the Tractor and Implement .................................................................................................................. 4-44
TROUBLESHOOTING GUIDE ........................................................................................................................ 4-45
MAINTENANCE SECTION .................................................................................................. 5-1
HAZARDS WITH MAINTENANCE OF IMPLEMENT .........................................................................................5-2
Lubrication .........................................................................................................................................................5-3
CENTER & WING GEARBOX ...........................................................................................................................5-5
Center Gearbox ................................................................................................................................................. 5-5
GREASE SCHEDULE ....................................................................................................................................... 5-6
DRIVELINES ......................................................................................................................................................5-6
DRIVELINE CLAMP CONE YOKE OPERATING INSTRUCTIONS ..................................................................5-7
Drivelines ........................................................................................................................................................... 5-7
Tractor Shaft, Constant Velocity ........................................................................................................................ 5-8
BLADE SERVICING ........................................................................................................................................... 5-9
BLADE SHARPENING ..................................................................................................................................... 5-10
BLADE REMOVAL ........................................................................................................................................... 5-10
Blade Bolt Inspection ....................................................................................................................................... 5-11
Blade Removal ................................................................................................................................................. 5-11
Blade Carrier Removal ..................................................................................................................................... 5-12
Blade Carrier Hub Installation .......................................................................................................................... 5-12
SKID SHOES ................................................................................................................................................... 5-12
SLIP CLUTCHES AND SHEAR BOLTS ..........................................................................................................5-12
Mower Frame ................................................................................................................................................... 5-13
HUBS AND SPINDLES .................................................................................................................................... 5-13
Greasing and Installation ................................................................................................................................. 5-13
Tightening Instructions for 517 & 511 Hubs ..................................................................................................... 5-14
SUSPENSION .................................................................................................................................................5-15
TIRES AND WHEELS ...................................................................................................................................... 5-15
HIGH PRESSURE OIL LEAK HAZARD............................................................................................................ 5-16
HYDRAULIC HOSES .......................................................................................................................................5-16

MAXIMUM ALLOWABLE OPERATING OIL TEMPERATURE ........................................................................ 5-16
Flex Wing Hydraulic Cylinder Replacement Instructions .................................................................................. 5-17
SKID SHOES .................................................................................................................................................... 5-18
STORAGE .......................................................................................................................................................5-18
PROPER TORQUE FOR FASTENERS ..........................................................................................................5-18
NUTS & BOLTS ...............................................................................................................................................5-19
