Scosche FT4276B User manual

Installation Complete
INSTALLATION GUIDE Kit Assembly
4
Step9
Carefully apply the housing /
panel.
First locate the
top clips and
then the lower section.
IN-DASH INSTALLATION KIT FOR
2012-UP FIAT 500 VEHICLES
**Dash I Vent Modification Required**
Tools Required:
PRT (Panel Removal Tool)
Screwdriver
Rotary Cutting Tool
INTRODUCTION/PRELIMlNARY
FT4276B
FT4276WB
This premium installation kit is for 2012-UP Fiat 500 vehicles with base model radio (dash modification required).
Included are all
the parts you need to mount your car stereo or CD player into your vehicle's dash. Refer to individual
instruction in this manual
to remove your vehicles factory radio and assemble the kit.
CAUTION: DISCONNECT YOUR VEHICLE NEGATIVE BATTERY TERMINAL BEFORE THE
INSTALLATION TO HELP PREVENT ELECTRICAL DAMAGE. WE RECOMMEND THE USE OF A VOLT/
OHM
METER OVER A TEST LIGHT TO CHECK WIRING. A TEST LIGHT OR GROUNDED WIRE PROBE
CAN CAUSE DAMAGE TO THE VEHICLE'S COMPUTER AND/OR DIAGNOSTIC SYSTEMS. AVOID ALL
FACTORY AIRBAG WIRING - AIRBAGS CAN ACCIDENTALLY DEPLOY CAUSING SERIOUS INJURY
OR DEATH.
NOTES--------------------------
• See your vehicle'sinstructions for any special tools your installation might require.
•
Read all instructionsaccompanying your car stereo for proper wiring and mounting instructions.
IMPORTANT!
DO NOT RETURN PRODUCT TO THE RETAILER
LIABILITY DISCLAIMER
This instruction booklet is based on carefully documented data and research of automobiledisassembly, wire harness /codes
and information pertaining tothe installation of this kit. Scosche Industries, Inc. cannot be held responsible for discrepancies/
inconsistencies that
may occur due tothe automobile manufacturing changes oroptions, ordamage that may occur in the
automobileduring the installation of components while using this booklet.

(1 3/8”)(1 3/8”)
INSTALLATION GUIDE Disassembly
Step 1
Remove the original radio and
air-vent cover.
Step2
Remove the original air venti-
lation shafts.
Step3
Without removing it, cut the front
~
,. Before - - .
·r~ ~1-: , ,
of the airvent duct as shown. It is
recomended
to place the sleeve to fmlHa•
~ I ,
- .,..._ ~
the opening to check the placement
before the final cut.
Step4
Insert the paddles (A) into the
cut ducts, using the
"U" section
to guide the correct possition.
Remove backing paper and the
stick the foam block (B) in the
center position as shown.
2 FT4276B/FT4276WB 01/16
INSTALLATION GUIDE Kit Disassembly/Assembly
Step5
Locate the sleeve (C) in position,
ensuring correct alignment to the
~oam block and screw, as shown.
Step 7
Mount and adjust brackets to allow
Double DIN radio to sit Flush
in kit
opening
Sample Images Only
3
Step 7
Insert the DOUBLE DIN
radio into the sleeve until the
springs click and engage fully.
Step8
Using a screwdriver, or similar,
push the paddles against the
sides
of the Double DIN radio
unit
to ensure correct airflow
from ventilation system
FT 4276B/FT4276WB 01 /16
