Sea-doo Aqua Mate SD75005 User manual

English Version
CAUTION
ELECTRICALLY OPERATED PRODUCT
Not recommended for children under 8 years of age. As with all
electrical products, precautions should be observed during handling
to reduce the risk of electric shock.
User Manual
p
SDP05855
Distributors in the United States and Canada provide a standard Limited
Warranty for 6 months from the date of purchase for new products. If
you're not located in the United States or Canada, please contact your
local distributor for warranty arrangements in your territory.
Please visit
www.seadooseascooter.com for distributor/Service Centre details.
Distributors ONLY warrant the products purchased from an authorized
dealer.
Ask your local Distributor for the warranty period in your region by calling their
Service Center. Any part of the product supplied by the Distributor and found in the
reasonable judgment of the Distributor to be defective in material or workmanship
will be repaired or replaced by the Distributor without charge for parts or labor. The
product including any defective part must be sent to the Distributor within the
warranty period. The customer will pay for the expense of delivering the product to
the Distributor. The Distributor will pay for the expense of returning the product to
the customer.
ALWAYS ACTIVATE YOUR WARRANTY IMMEDIATELY ON
http://www.seadooseascooter.com/warranty.html
www.seadooseascooter.com
WARRANTY
Distributors ONLY warrant products with an active
Warranty Registration

Contents Introduction
Introduction 1
Parts diagram 2
Warnings 3
Assembling the 5
SEA-DOO®AQUA MATE
Battery use 7
Charging the battery 11
Using the SEA-DOO®AQUA MATE 15
Care & Maintenance 16
Trouble Shooting 18
Technical Specifications 21
Discarded electrical appliances are
recyclable and should not be discarded
in the domestic waste! Please actively
support us in conserving resources and
protecting the environment by returning
this appliance to the collection centers
(if available).
Experience a totally new Aqua Sport Adventure with
the SEA-DOO®AQUA MATE.
The SEA-DOO®AQUA MATE is easy to assemble and
easy to drive.
• Speed up to 2 mph (3.2 km/h)
• Run up to 1 hour with Normal use
Please take time to study this user manual before
using your SEA-DOO®AQUA MATE.
1

Parts Diagram WARNINGS
WARNING:
This is not a life saving device. Do not leave children
unattended while device is in use.
Only to be used in water in which the child is within its
depth and under supervision.
This AQUA MATE is NOT A BOAT.
The AQUA MATE is for pool use only - DO NOT use in
the open sea.
• Read the User Manual carefully before using the AQUA
MATE.
• Keep the packaging since it contains important information.
• Do not operate the AQUA MATE for long periods out of the
water to avoid damage.
• The AQUA MATE must be assembled by an adult.
• An adult must be responsible for battery safety at all times,
during use, storage and charging.
• A child under 8 years old should never operate the AQUA
MATE.
• Always wear a Approved Personal Floatation Device /
Approved Life-Preserver when using the AQUA MATE.
• The AQUA MATE is designed to hold ONE person not
exceeding 155 lb / 70 kg.
• Never stick body parts, clothing or other objects in the
vicinity of the propeller.
• DO NOT wear loose or flowing clothing that could be
drawn into the propeller.
• DO NOT use at night or in low light situation.
32
Fig.1
15
14
16 17
Back
Inflatable
Steering Unit
On/off Trigger
Master Switch
Steering Column
Steering Column
Sleeve
Nozzle
Battery Door
Battery Door Seal
Inflatable Repair Kit
and Air Release Tubes
Rechargeable Battery
Charger
Rear Grille
Inflatable Chamber A
Inflatable Chamber B
Inflatable Chamber C
Inflatable Chamber D
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

• User with long hair should tie it up or wear a swimming cap
when using the AQUA MATE.
• Particular care should be exercised when using the AQUA
MATE near anybody with long hair.
• ALWAYS inspect the area to ensure it is free of hazards or
obstacles such as swimmers before using the AQUA
MATE. NEVER ride over swimmers or other objects.
• ALWAYS ensure sufficient charges remains in the battery
to return to the poolside before using the AQUA MATE.
• Always charge battery to its maximum before using the
AQUA MATE. After charging is complete the battery will
continue to emit gas. Wait at least 30 minutes after
charging before removing the battery from the charger or
placing the battery into the battery housing. Failure to do
so could result in an explosion.
• The AQUA MATE is to be operated in water only when fully
assembled in accordance with the instructions.
• Do not use alcohol or drugs prior to using this product.
• ALWAYS keep the AQUA MATE out of direct sunlight when
not in use. HEAT KILLS BATTERIES AND IT MAY
EXPLODE OR LEAK.
• ALWAYS remove the battery from the unit when not in use.
• NEVER leave in or near the water when not in use.
• Adults should inflate the chambers in numbered sequence.
5
4
1. Use a pump (not included), to blow up the Inflatable.
Make sure that the valve for each chamber is properly
closed once inflated.
Adults should inflate the chambers in numbered
sequence. (See Fig. 1)
1Chamber C & D > 2Chamber A > 3Chamber B
DO NOT OVER INFLATE THE INFLATABLE.
2. Connect the Steering Column to the Propulsion Unit.
(See Fig.2) You will hear a "click" sound once the
Steering Column has been correctly connected.
Fig.2
Fig.3
a
b
Assembling the SEA-DOO® AQUA MATE
3a. Slide the Steering Sleeve into the hole in the Inflatable
from the top.
3b. Slide Steering Column/Propulsion Unit assembly from
the bottom of the inflatable through the Steering
Sleeve. You will hear a "click" sound once the Steering
Column has completely passed through the Steering
Sleeve. (See Fig.3)
Tip: If the Steering Column Sleeve is stuck, pour some
water to lubricate and then push it down.

67
4. Attach the Steering Unit to the Steering Column - you
will hear a "click" sound once it has been properly
attached (See Fig.4).
The SEA-DOO®AQUA MATE is now ready for battery
installation.
Battery Use
Fig.4
Fig.5
Make sure the Propulsion Unit and Steering Unit are
aligned correctly (See Fig.5).
RE-CHARGE THE BATTERY
3
3
AT LEAST
MONTHS
EVERY
MONTHS
WARNING
BATTERY SAFETY
• Must remove and store the
battery separately from the unit
when not in use!
• Must re-charge the battery after
use WITHIN 24 HOURS.
• Must re-charge the battery at
least EVERY THREE MONTHS
when not in use.
User Manual must be read and
understood before use.
Please read and follow the
Battery Safety Instruction.
Incorrect battery maintenance
may reduce the battery life and
influence its function.
www.seadooseascooter.com

CAUTION
• Your SEA-DOO®AQUA MATE is supplied with a battery
that needs to be treated carefully as it will release
potentially explosive gasses during its normal cycle of
use (off-gassing). Failure to do so can result in an
explosion occurring. Please read the entire manual
thoroughly and follow all instructions.
• Always remove the battery from your SEA-DOO®
AQUA MATE when it is not in use and store separately in
a well ventilated area where it is out of the reach of
children and away from heat and ignition sources.
• Do not attach the battery in your SEA-DOO®
AQUA MATE until prior to using it.
• Before disconnecting/connecting any cables, open the
nose cone and allow two minutes for any explosive
gases to dissipate.
• Do not use/store/charge the battery in temperatures
above 40ºC (104ºF) as excessive off gassing may occur.
Keep the battery and AQUA MATE in the shade when not
in use.
• Always ensure the unit is dried thoroughly before
opening the Nose Cone.
• Only use the charger supplied with the SEA-DOO®
AQUA MATE.
• The battery supplied with your
SEA-DOO
®
AQUA MATE
releases a potentially explosive gas during charging.
Charging should only take place in a well ventilated area,
away from children and open flames or other ignition
sources (cigarettes, sparks). Never charge the battery
while still in the SEA-DOO®AQUA MATE
• Charge the battery as soon as possible after use within
24 hours.
Battery Use
CAUTION
• Always charge the battery to the maximum before
using the SEA-DOO®AQUA MATE.
• Always remove the battery from the battery housing
before charging.
• Always connect charger jack to the battery first and then
plug charger into the electrical socket/plug.
• After charging, disconnect from the electrical socket/plug
first and then disconnect the battery from the charger.
• After charging is complete the battery will continue to
emit gas. Wait at least 30 minutes after charging before
removing the battery from the charger or placing the
battery into the battery housing. Failure to do so could
result in an explosion.
• Do not place battery into your SEA-DOO®AQUA MATE
until immediately before use.
• Remove battery from charger once fully charged.
• Never charge the battery in a sealed container.
• Never charge the battery near water.
• Never short circuit the battery or battery connectors.
• Always ensure the charger is dry before use.
• The charger gets quite warm in use – this is normal.
• If in doubt of the state of the battery, recharge it until
the indicator on the battery charger indicates a full
charge.
Battery Use
98

CAUTION
• If the battery is not to be used for an extended period,
store it in a well ventilated area away from children, heat
and ignition sources. Recharge it every three months to
maintain charge and avoid excess off-gassing. DO NOT
store the
battery inside the SEA-DOO
®
AQUA MATE.
• If the battery appears damaged or will not fully charge, the
battery must be replaced. If battery life is noticeably
reduced, the battery should be replaced.
• Exhausted batteries are to be removed from the toy.
• An adult must be responsible for battery safety at all times,
during use, storage and charging.
• ALWAYS charge battery in a well-ventilated place out of
reach of children.
• The battery supplied with your SEA-DOO®
AQUA MATE should last about 200 cycles or two years
before it should be replaced. Please contact your local
customer service center/distributors. Using a battery in
excess of these recommendations can result in
excessive off-gassing of explosive gases.
• The Rechargeable Battery will give you approximately one
hour of use - always make sure you have enough power
left to return to the poolside.
• When the SEA-DOO®AQUA MATE speed drops it is time
to recharge the battery. Do not continue to use the
SEA-DOO®AQUA MATE after the speed drops, until it
stops, otherwise the battery will be damaged.
To charge the battery follow these instructions.
1. Always ensure that the Master Switch is OFF
(See Fig.6).
2. Always ensure that the SEA-DOO®AQUA MATE is out of
the water, dry and placed in a dry area.
3.
Use a small coin to unscrew the Screw Cap
counter-clockwise. (See Fig.7).
Battery Use Charging the battery
1110
Fig.6
OFF
Fig.7
Screw Cap

Battery
Door
12mm
1312
7. Allow two minutes for any gasses to dissipate.
8. Take out the battery from the Battery Compartment
and place on a level surface.
9. Connect the battery to the Charger (See Fig.10).
10. Plug Charger into electrical socket/plug, and turn on
the supply.
11. Charging will take 6-8 hours for a fully discharged
battery. When the battery is charging the LED on the
Charger turns RED. When the battery is charged the
LED turns GREEN.
12.
Unplug the Charger from the electrical socket/plug.
13. Allow battery to stand for 30 minutes before using it.
14. Unplug the battery from the charger.
15. When ready for use, install the battery and making
sure to insert it the right way round. (See Fig.11)
16. Make sure the seal and sealing surfaces are clean and
lubricated with silicone grease EVERYTIME (you can
buy this at your local hardware store) before replacing
the Battery Door (See Fig.12).
4. Pull out the Screw Cap slightly to a maximum of 12mm
ONLY. DO NOT PULL OUT THE SCREW CAP AND
STEM COMPLETELY. (See Fig. 8)
5. Press on Screw Cap to release locking mechanism of
Battery Door. (See Fig. 9)
6. Pull out Battery Door part to access battery.
Fig.10
Fig.9
Fig.11
Seal
Sealing surfaces
Fig.12
Fig.8
Silicone
Grease

Using the SEA-DOO
®
AQUA MATE
1514
17. Replace the Battery Door and turn the Battery Door Screw
making sure it is tightened completely (See Fig.13).
Fig.13
Replacing a flat battery with a fully charged battery.
1. Follow the steps 1 to 8 above.
2. Remove the flat battery.
3. Install and connect the charged battery.
4. Follow steps 16 to 17.
Buying Rechargeable Batteries
It is a good idea to have a second battery so that when
one has run out you can swap it over with a charged one.
Contact your local customer service center/distributor to
purchase additional rechargeable batteries.
Battery & Charger Ratings
Rechargeable battery: 12V / 2.8Ah
Charger: Output-12V / 500mA
When you buy the
SEA-DOO®AQUA MATE the battery is
disconnected and needs to be charged. Follow the Battery
Instruction on pages 7 to 10 and charging instructions on
pages 11 to 14.
1. Make sure the rechargeable battery has been fully
charged.
2. Place the SEA-DOO®AQUA MATE in the water.
3. Turn the Master Switch to 'ON' position (See Fig.14).
4. Help your child to sit on the SEA-DOO®AQUA MATE - a
Approved Personal Flotation Device / Approved
Life-Preserver should always be worn by your child.
5. The rider simply has to pull the Trigger to start, turn
the steering unit to maneuver and release the Trigger
to stop.
Fig.14
ON

Care And Maintenance
16 17
Disassembling and Storing the
SEA-DOO®AQUA MATE
DO NOT leave the Aqua Mate in the water. Always take
the unit out of water when not in use.
1. Always rinse the AQUA MATE in fresh water and allow
it to dry before storage immediately after use.
2. Unclip the Steering Unit, remove the Steering Column
Sleeve, the Nozzle and Steering Column and unclip
the Steering Column.
Tip: If the Steering Column Sleeve is stuck, pour some
water over it to lubricate and then remove.
3. Open the Battery Door and remove the rechargeable
battery (see also section on Rechargeable Battery
Care for more storage information).
4. Deflate the inflatable fully. To do this insert one air
release tube (packed with the repair kit) in each valve
and press gently on the inflatable until all air has been
expelled.
5. Store the AQUA MATE in the original box in a dry place
- ambient temperature for storage should be within
- 20oC to 40oC (-4oF to 104oF).
Battery and Charger Care
1. The battery should be recharged as soon as possible
after use.
2. If the AQUA MATE is not used for extended periods,
the battery should be removed from the unit and
charged overnight, every three months.
3. Only use the charger supplied with the AQUA MATE.
4. Never place the battery in a sealed container when
charging.
5. Never short-circuit the battery or battery cable.
6. Never place/store the battery near a radiator/fire, etc.
7. To store the battery, remove it from the AQUA MATE
and keep in a place that is dry and cool with the rest of
the AQUA MATE in the original box.
8. Rechargeable batteries are to be removed from the
AQUA MATE before being charged.
9. An adult must be responsible for battery safety at all
times, during use, storage and charging.
10. The battery charger should be required examined by
an adult for potential hazard, such as damage to the
cable or cord, plug, encloser or other parts, and that, in
the event of damage, the charger must not be used
until that damage has been properly removed.
