Sealey WB951LED.V2 User manual

12V/24V LED WARNING BEACON-
VARIOUS FITTINGS
MODEL NO: WB951LED.V2, WB952LED.V2,
WB954LED.V2, WB955LED.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Familiariseyourselfwiththisproduct’sapplicationandlimitations,aswellasanyspecicpotentialhazardspeculiartothebeacon.
9 Replaceorrepairdamagedparts.Use recommended parts only. Non authorised parts may be dangerous and will invalidate the
warranty.
8DO NOTusethebeaconforanypurposeotherthanforwhichitisdesigned.
8DO NOTallowchildrentooperatethebeacon.
8DO NOToperatethebeaconifanypartsaremissingordamagedasthismaycausefailureorpossiblepersonalinjury.
9 Whennotinuseswitchthebeaconoffandwhereappropriateremoveplugfrompowersupply.
2. INTRODUCTION
3-FunctioncontrolallowsfordifferentLEDashcongurations.Heavy-dutyABSbase.Quickrelease,UVstabiliseddomewillnot
 fadeifexposedtoprolongedsunlight.
WB951LED.V2 - Singlepointmountingbeaconsuitablefordirectmountingtovehicleroofusing12mmbolt.
WB952LED.V2-Directmountingbeaconpre-drilledwith3x6.5mmholes.
WB954LED.V2-Fittedwithsixpowerfulmagnets,strongenoughtocopewithnormalroadspeeds.Suppliedwith3mcoiledexand
  universalvehicleaccessorysocketplug.
WB955LED.V2 - FlexibleDINelementsuitableforagriculturalvehicleswherestandardbeaconsmaybebroken.
3. SPECIFICATION
MODEL No’s: WB951LED.V2,WB952LED.V2,WB954LED.V2,WB955LED.V2
Voltage:............................................................12V/24V(DC)
LightSource................................................SMD2835,45pcs
Max.Current....................................................... 1.6A@12V
Max.Current........................................................ 0.8A@24V
WorkingTemperature...........................................-30/+50o C
EMC........................................................... E910R0516099
R65...............................................................TA1E9006105
Waterproof......................................................................IP56
4. FIXING INSTRUCTIONS
4.1. WB951LED.V2: 12mmSingleBoltFixing
4.1.1. Drilla13mmmountingholeinasuitablepointonthevehicle.
4.1.2. Connecttocablesofatleast2mm²sectionandusean8Afuse;checkpolarities.
4.1.3. Fixthebeaconbyusingnutsandwashersaccordingtothetypeandshapeofthemountingsurface
WB951LED.V2,WB952LED.V2,WB954LED.V2,WB955LED.V2Issue114/12/20
Original Language Version
©JackSealeyLimited
Refer to
instructions
WB951LED.V2 WB952LED.V2 WB954LED.V2 WB955LED.V2

4.2. WB952LED.V2:ThreeBoltFixingBase
4.2.1. Drillmountingholesusingthebeaconbaseasatemplate.Alsomakeprovisiontoroutecablesintothevehicle.
4.2.2. Connecttocablesofatleast2mm²sectionandusean8Afuse;checkpolarities.
4.2.3. Fixthebeaconwith3xM6screws.
4.3. WB954LED.V2:MagneticBase
4.3.1. Fittedwithhighpowermagnetstrongenoughtocopewithnormalroadspeeds.
4.3.2. Suppliedwith3mcoiledexanduniversalauxiliarypoweroutletplug.
4.3.3. Thebeaconmustbeplacedonasurfaceparalleltotheground.
4.3.4. Thesurfaceshouldbeatandcleantoensuregoodadherence.
4.4. WB955LED.V2:FlexibleBasewithDINSpigotMounting.
4.4.1. Fitasuitableadaptersocketontothevehicle.Makesureitisperfectlyvertical.
4.4.2. Usecablesofatleast2mm²sectionandusean8Afuse;checkpolarities.
4.4.3. Pushthebeaconspigotdownfullyontotheadaptersocketandsecurebytighteningthewingnut.
4.4.4. Whenthebeaconisremoved,alwaysclosetheadaptersocketoutletusingtherubbercap.
5. FLASH PATTERN SELECTION
5.1.  Threeashpatternsareavailableforselectionusingbuttononthetopoftheunitasing.2.Thebuttonisaccessedbyremoving
 thedomeasing.1.
5.2.  Pattern1:Rotatingash;ashrotatesmimickingarotarybeacon.
 Pattern2:Rapidashes.
 Pattern3:Threerapidashesfollowedbyabreak.
NOTE:Whenswitchedontheunitwilldisplayasthelastpatternsetting.
6. VOLTAGE SELECTION
6.1. Thebeaconswillswitchbetween12Vand24Vautomatically.
Original Language Version
©JackSealeyLimited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento
arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely
unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids
accordingtolocalregulations.
WEEE REGULATIONS
DisposeofthisproductattheendofitsworkinglifeincompliancewiththeEUDirectiveonWasteElectricalandElectronicEquipment
(WEEE).Whentheproductisnolongerrequired,itmustbedisposedofinanenvironmentallyprotectiveway.Contactyourlocalsolid
wasteauthorityforrecyclinginformation.
Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior
notice.Pleasenotethatotherversionsofthisproductareavailable.Ifyourequiredocumentationforalternativeversions,pleaseemailorcall
ourtechnicalteamon[e-mail]or01284757505.
Important:NoLiabilityisacceptedforincorrectuseofthisproduct.
Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.
