Sealey CD2005TT.V2 User manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the user’s responsibility to check the following:
Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs and all
electrical connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with all electrical
products. You may obtain an RCD by contacting your local Sealey stockist.
If the heater is used in the course of business duties, it must be maintained in a safe condition and routinely PAT (Portable Appliance
Test) tested.
1.2. ELECTRICAL SAFETY INFORMATION It is important that the following information is read and understood.
1.2.1. Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
1.2.2. Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
1.2.3. IMPORTANT: Ensure that the voltage rating on the appliance suits the power supply to be used and that
 theplugisttedwiththecorrectfuse-seefuseratingintheseinstructions.
8DO NOT pull or carry the appliance by the power cable.
8DO NOT pull the plug from the socket by the cable.
8DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or
 replacedimmediatelybyaqualiedelectrician.
1.2.4. ThisproductisttedwithaBS1363/A13Amp3pinplug.
9If the cable or plug is damaged during use, switch the electricity supply and remove from use.
9 Ensurethatrepairsarecarriedoutbyaqualiedelectrician.
9 ReplaceadamagedplugwithaBS1363/A13Amp3pinplug.Ifindoubtcontactaqualiedelectrician.
 a)ConnecttheGREEN/YELLOWearthwiretotheearthterminal‘E’.
 b)ConnecttheBROWNlivewiretotheliveterminal‘L’.
 c)ConnecttheBLUEneutralwiretotheneutralterminal‘N’.
9Ensure that the cable outer sheath extends inside the cable restraint and that the restraint is tight.
9 Sealeyrecommendthatrepairsarecarriedoutbyaqualiedelectrician.
1.3. GENERAL SAFETY
 WARNING!Disconnect the heater from the mains power supply before carrying out any servicing or maintenance.
9 Disconnect the heater from the power supply before handling or cleaning.
9 Maintain the heater in good order and clean condition for best and safest performance.
9 Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9Ensure there is adequate lighting and keep the immediate area in front of the outlet grille clear.
9 Onlyusetheheaterstandingonitsfeetintheuprightposition.
8 DO NOT allow any untrained persons to use the heater. Ensure they are familiar with the controls and hazards of the heater.
8 DO NOT let power lead hang over an edge (i.e. table), or touch a hot surface, lie in heater hot air flow, or run under a carpet.
8 DO NOT touch the outlet grille (top) of the heater during and immediately after use as it will be hot.
8 DO NOT place the heater near items that may be damaged by heat.
8 DO NOT place heater too close to yourself or any object, allow the air to circulate freely.
8 DO NOT use the heater for any purpose other than for which it is designed.
8 DO NOT use heater on very deep pile carpets.
8 DO NOT use the heater outdoors. These heaters are designed for indoor use only.
8 DO NOT use heater if the power cord, plug or the heater is damaged, or if the heater has become wet.
8 DO NOT use in bathroom, shower room, or in any wet or damp environments or where there is high condensation.
8 DO NOT operate the heater when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8 DO NOT allow the heater to get wet as this may result in an electric shock and personal injury.
8 DO NOT insert or allow objects to enter any openings of heater as this may cause an electric shock,a fire or damage to heater.
8 DO NOT use the heater where there are flammable liquids, solids or gases such as petrol, solvents, aerosols etc, or where heat sensitive
materials may be stored.
8DO NOT place the heater immediately below any electrical outlet.
8 DO NOT cover heater when in use, and do not obstruct the air inlet and outlet grille (i.e. clothing, curtain, furniture, bedding etc).
9Allowtheunittocoolbeforestorage.Whennotinuse,disconnectfromthemainspowersupplyandstoreinasafe,cool,dry,childproofarea.
CD2005TT.V2Issue:2(2)-13/02/2019
Original Language Version
©JackSealeyLimited
Recommended fuse rating
13 Amp
CONVECTOR HEATER 2000W/230V
WITH TURBO & TIMER
MODELNO:CD2005TT.V2
This product is only suitable for well insulated areas or occasional use.
Refer to
instruction
manual
Do not cover

NOTE: Children of less than 3 years should be kept away unless continuously supervised.
 Childrenagedfrom3yearsandlessthan8yearsshallonlyswitchon/offtheapplianceprovidedthatithasbeenplacedorinstalled
in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the
appliance or perform user maintenance.
2. INTRODUCTION
Electricconvectorheaterswiththreeheatsettingsof750/1250/2000Wforgradualcontrolofheatingelements.Rotarycontrolledroom
thermostatmaintainsambienttemperatureatpresetlevel.ModelNo’sCD2005TandCD2005TTfeaturebuilt-inturbofanforacceleratedheating.
Model No. CD2005TT also features a 24 hour timer allowing the user to programme the time and duration the heater is operated. Slimline sturdy
constructionandhighqualitynishmaketheseunitssuitableforhome,lightindustrialandofceenvironments.Suppliedwith13Ampnon-
rewirable ASTA approved plug.
3. SPECIFICATIONS
Model No: .........................CD2005TT.V2
Power Settings: ...................750/1250/2000W
Supply: ...................................230V
Size(WxDxH): ..................595x200x420mm
Weight:...................................2.9kg
4. ASSEMBLY
4.1. MOUNTING THE FEET (fig.1.)
4.1.1. Turn the heater upside down and support it securely. Take one of the feet and place it
onto the underside of the heater in the position indicated in (fig.1).
4.1.2. Whenthefootispositionedcorrectly2holesinthefootwilllineupwiththeholesinthe
underside of the heater.
4.1.3. Fasten each foot down with the self tapping screws provided.
5. OPERATION
5.1. OPERATING THE HEATER (See fig.2)
5.1.1. Place the heater in a suitable position in the area you require to heat.
5.1.2. Allow a minimum of 500mm between the heater and adjacent objects such as furniture etc.
5.1.3. Plug the heater into the mains supply.
5.1.4. Turn the thermostat knob (fig.2.C) to a high setting.
5.2. SELECTING THE HEAT OUTPUT
5.2.1. Choose the required heat output by selecting the appropriate switch which will light up
when pressed.
 Lowsetting (750W)  Selectswitch‘A’
 Mediumsetting (1250W) Selectswitch‘B’
 Highsetting (2000W) Selectbothswitches.
5.3. USING THE THERMOSTAT (fig.2.C)
5.3.1. Oncetherequiredroomtemperaturehasbeenachieved,turnthethermostatdownslowly
in the direction of the Min. setting until the heat output switch light (part of each switch)
goes out. The heater will then keep the surrounding air at the set temperature by switching
on and off at intervals. You may reset the thermostat at any time.
5.4. TURBO FAN FEATURE
5.4.1. Toboosttheoutputofairatanytemperaturesettingselectswitch‘D’whichhasafan
symbol beside it. The fan can also be used to circulate cool air only by switching off the
two heat setting switches.
5.5. TIMER FUNCTION
5.5.1. To activate timer function, turn the outer ring (fig.2.E) to the correct time. This will need to
be repeated every time that the heater is reconnected to the power supply.
5.5.2. The function selector switch (fig.2.F) has three positions:
 Left............Heateronpermanently
Centre........Heatertimed.
Right.........Heateroff.-The heater will not operate at all with the switch set in this position.
5.5.3. To select the time during which the heater is active, move the timer pins (fig.2.G.)
outwards for the period required. Each pin is equal to 15minutes.
5.5.4. To switch the unit off, turn the heat selecting switches off and unplug from the mains.
5.5.5. Allow the unit to cool before handling or storage.
WARNING! DO NOT touch the top of the heater when in use as it becomes hot.
5.6. SAFETY CUT OUT FEATURE
5.6.1. The heater is fitted with a thermostatic safety cut out which will turn the heater off automatically should the airflow become blocked or if
the heater has a technical malfunction.
5.6.2. Should this happen, switch the heater off and unplug it from the mains power supply.
 WARNING! In such a case the heater will be very hot.
8DO NOT connect the heater to the power supply again until the reason the safety cut out activated has been identified.
5.6.3. Allow the heater to cool completely before handling and then check the air inlet and outlet for obstructions before attempting to switch the
unit back on.
5.6.4. If the cause is not obvious return the heater to your local Sealey stockist for servicing.
CD2005TT.V2Issue:2(2)-13/02/2019
Original Language Version
©JackSealeyLimited
g.1
g.2

CD2005TT.V2Issue:2(2)-13/02/2019
Original Language Version
©JackSealeyLimited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
DisposeofthisproductattheendofitsworkinglifeincompliancewiththeEUDirectiveonWasteElectricalandElectronicEquipment
(WEEE).Whentheproductisnolongerrequired,itmustbedisposedofinanenvironmentallyprotectiveway.Contactyourlocalsolid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
Important:NoLiabilityisacceptedforincorrectuseofthisproduct.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
6. MAINTENANCE B
6.1. Before attempting any maintenance ensure the unit is unplugged from the mains power supply and that it is cool.
6.2. Clean the unit with a soft dry cloth. DO NOT use abrasives or solvents.
6.3. Periodically check the air inlet and outlet to ensure the air way is clear.
