1.1. ELECTRICAL SAFETY

WARNING! It is the responsibility of the owner and the operator to read, understand and comply with the following:

You must check all electrical products, before use, to ensure that they are safe. You must inspect power cables, plugs, sockets and any

other connectors for wear or damage. You must ensure that the risk of electric shock is minimised by the installation of appropriate safety

devices. A Residual Current Circuit Breaker (RCCB) should be incorporated in the main distribution board. We also recommend that a

Residual Current Device (RCD) is used. It is particularly important to use an RCD with portable products that are plugged into a supply

which is not protected by an RCCB. If in any doubt consult a qualified electrician. You may obtain a Residual Current Device by

contacting your Sealey dealer.

You must also read and understand the following instructions concerning electrical safety.

1.1.1. The Electricity at Work Act 1989 requires that all portable electrical appliances, if used on business premises, are tested by a qualified

electrician, using a Portable Appliance Tester (PAT), at least once a year.

1.1.2. The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of those appliances

and the safety of the appliance operators. If in any doubt about electrical safety, contact a qualified electrician.

1.1.3. Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply. See 1.1.1 and 1.1.2

and use a Portable Appliance Tester.

1.1.4. Ensure that cables are always protected against short circuit and overload.

1.1.5. Regularly inspect power supply cables and plugs for wear or damage and check all connections to

ensure that none are loose.

1.1.6. Important: Ensure that the voltage marked on the appliance matches the power supply to be used and

that the plug is fitted with the correct fuse - see fuse rating at right.

1.1.7. DO NOT pull or carry the appliance by the power cable.

1.1.8. DO NOT pull the plug from the socket by the cable.

1.1.9. DO NOT use worn or damaged cables, plugs or connectors. Immediately have any faulty item repaired

or replaced by a qualified electrician. When a BS 1363/A UK 3 pin plug is damaged, cut the cable just

above the plug and dispose of the plug safely.

Fit a new plug according to the following instructions (UK only).

a) Connect the GREEN/YELLOW earth wire to the earth terminal ‘E’.

b) Connect the BROWN live wire to the live terminal ‘L’.

c) Connect the BLUE neutral wire to the neutral terminal ‘N’.

d) After wiring, check that there are no bare wires, that all wires have been correctly connected,

that the cable outer insulation extends beyond the cable restraint and that the restraint is tight.

Double insulated products, which are always marked with this symbol , are fitted with live (brown) and neutral (blue) wires only.

To rewire, connect the wires as indicated above - DO NOT connect either wire to the earth terminal.

1.1.10. Products which require more than 13 amps are supplied without a plug. In this case you must contact a qualified electrician to ensure

that a suitably rated supply is available. We recommend that you discuss the installation of an industrial round pin plug and socket with

your electrician.

1.1.11. Use of an extension cord is not recommended. If an extension reel must be used it should be fully unwound before connection. A reel with

an RCD fitted is preferred since any appliance plugged into it will be protected. The cable core section is important and should be at least

2.5mm².

1.2. GENERAL SAFETY INSTRUCTIONS

Familiarise yourself with the applications and limitations of the heater.

Ensure the heater is in good order and condition before use. If in any doubt do

not use the unit and contact an electrician or your Sealey dealer.

Only use recommended attachments and parts. Using unauthorised parts may

be dangerous and will invalidate your warranty.

Check that element guards are in place, undamaged and firmly attached.

Keep tools and other items away from the heater when it is in use.

Keep the work area clean and clear of unnecessary items.

Keep children and unauthorised persons away from the heater, as it gets very hot.

  Disconnect from mains and allow to cool before moving or attempting any cleaning or maintenance.

  DO NOT get the heater wet or use in damp or wet locations or areas where there is condensation.

  DO NOT locate the heater below the power outlet.

  DO NOT move the heater whilst in operation or even when still warm.

  DO NOT touch the heater elements, even when cold.

DO NOT dismantle the heater for any reason. The heater must be checked by qualified personnel only.

DO NOT use this product to perform a task for which it has not been designed.

  WARNING! If a fuse blows, ensure it is replaced with an identical fuse type and rating.

When not in use, store the heater carefully in a safe, dry, childproof location.

WARNING! Never touch the element glass directly with fingers. Use a soft cloth, otherwise the tube may get damaged.

WARNING! Ensure the heater is at least 900mm from any object.

 IMPORTANT! This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental

capabilities or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the

appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance

1. SAFETY INSTRUCTIONS

INSTRUCTIONS FOR:

INFRARED QUARTZ HEATER WALL MOUNTING

WITH REMOTE CONTROL

MODEL No: IWMH2003RC.V2

Original Language Version

RECOMMENDED FUSE

RATING 13AMP

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE

PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IWMH2003RC.V2 Issue:2(L) - 11/06/14

3. MOUNTING INSTALLATION

3.1. WALL MOUNTING (fig.1).

 IMPORTANT! The following points should be noted: The heater

should always have a minimum clearance of 450mm from a

ceiling and at least 900mm from any object. Ensure that

mounting surface is capable of supporting the weight of the

heater.

3.2. Use the bracket (fig.1C) as a template, fix the metal bracket to

the wall by means of the four holes and appropriate fixings

(not supplied).

3.3. Secure the neck (fig.1B) to the heater head (fig.1A) using a

single bolt.

3.4. Next with the help of a second person holding the heater, bolt

the neck (fig1.B) to the wall bracket (fig.1C) using a nut, bolt and

two washers.

3.5. Adjust the angle of heater to direct heat where required.

2. INTRODUCTION & SPECIFICATION

A totally dry heat, no condensation, no gas, no fumes and no smell. Reaches maximum heat output within seconds of being turned on. Highly polished

aluminium reflector for maximum heat efficiency. Adjusts horizontally through 25° while mounted. Three settings, controlled by push on/off switch or

remote control, allowing unit to be on full, half or low power. Ideal for industrial or domestic applications. Suitable for indoor and outdoor use, if weather

protected.

4. OPERATION

Note: The infrared lamp is fragile and therefore it is important that it is

not subjected to any unnecessary shocks or vibration and is not

moved when it is on or still warm. Only move once completely

cooled down.

 WARNING! Ensure you read, understand and apply the

safety instructions in Section 1 before using the heater.

4.1. Ensure the heater is at least 900mm from any object. The heater

can be tilted from 0° to 25°, set it to the required angle before

switching the heater on.

4.2. Plug in the heater and switch it on using either the control on the

base of the heater or by using the remote.

4.3. The heater will start on the low setting, each press of the on/

power button will cycle the heater onto the medium setting, high

setting and then back to the low setting.

4.4. When the heater is no longer required, switch off, using the off

button on the unit or the off button on the remote and unplug the

unit.

4.5. Make sure the heater plug is disconnected from the mains supply

before any cleaning is attempted. Also allow the heater to cool

completely. DO NOT use water or other liquids, or harsh abrasive

cleaners to clean the heater. DO NOT touch the glass elements

with fingers as this may damage the tube(s).

4.6. Clean the exterior with a soft damp cloth with some mild

detergent.

4.7. To replace any of the lamps, contact your authorised Sealey

dealer.

4.8. To change the remote batteries, press down and push back the

battery cover (fig.2), remove old batteries and replace with two

new AAA batteries.

 WARNING! DO NOT mix old and new batteries and dispose

of old batteries in accordance with local authority

regulations.

4.9. IWMH2003RC.V2 is fitted with an tilt safety mechanism so

that if for any reason the heater would be tilt beyond 25° the

heater will cut-out. Position the heater upright to turn the

heater back on.

fig.1

fig.2

Power: ...................2000W

Input supply: ...............230V 50Hz 13A

Dimensions (W x H x D): .....485 x 250 x 170mm

IWMH2003RC.V2 Issue:2(L) - 11/06/14

Environmental Protection.

Recycle unwanted materials instead of disposing of them as

waste.

All tools, accessories and packaging should be sorted, taken

to a recycle centre and disposed of in a manner which is

compatible with the environment.

When the product is no longer required, it must be disposed

of in an environmentally protective way. Contact your local

solid waste authority for recycling information.

Battery Removal.

• To remove batteries, see 4.8.

• Ensure correct polarity.

Dispose of batteries according to local authority

guidelines.

Under the Waste Batteries and Accumulators Regulations 2009, Jack

Sealey Ltd are required to inform potential purchasers of products

containing batteries (as defined within these regulations), that they are

registered with Valpak’s registered compliance scheme.

Jack Sealey Ltd’s Batteries Producer Registration Number (BPRN) is

BPRN00705

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
