Sealey SC03 User manual

INSTRUCTIONS FOR:
FLOOR CABINET 2 SHELF
MODEL No: SC03
1. SAFETY INSTRUCTIONS
2. INTRODUCTION
1.1 GENERAL SAFETY
 WARNING! Ensure Health & Safety, local authority, and
general workshop practice regulations are adhered to when
using this cabinet.
 WARNING! Use caution when handling and assembling
the metal components. The metal may have sharp edges
or corners, the use of protective gloves is recommended.
Locate cabinet in a suitable working area and secure to a
wall with suitable fasteners.
 Keep the work area clean and uncluttered.
Keep the cabinet clean and tidy in accordance with good
workshop practice.
Keep children and unauthorised persons away from the
working area.
 DO NOT climb, step or stand on the cabinet shelves.
 DO NOT use the cabinet for any purpose other than that
for which it is designed.
 DO NOT use in damp work areas.
 WARNING! The warnings, cautions and instructions
referred to in this instruction manual cannot cover all
possible conditions and situations that may occur. It must
be understood that common sense and caution are factors
which cannot be built into this product, but must be applied
by the operator.
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and properly
maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE
AND/OR PERSONAL INJURY, AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
3. CONTENTS
Original Language Version SC03 Issue:1 - 15/07/10
Use as an individual storage unit. Featuring two large
doors, two full shelves and base storage. Added security
provided by cylinder lock, supplied with two keys. All steel
construction, stabilised by an inner cross member. Supplied
flat packed to save freight cost, simple assembly required.
Size (W x D x H): 916 x 458 x 1060mm
3.1 CONTENTS INSPECTION
Unpack all the parts and layout on the packing material.
Visually inspect all panels to check for transportation
damage.
A1 .....Back (left hand side) ............................................1 off
A2 .....Back (right hand side) ..........................................1 off
B1 .....Side (left hand side) .............................................1 off
B2 .....Side (right hand side)...........................................1 off
C.......Cross member......................................................1 off
D.......Base .....................................................................1 off
E.......Base outer fascia .................................................1 off
F........Top........................................................................1 off
G.......Shelf .....................................................................4 off
H1 .....Door (left hand side) ............................................1 off
H2 .....Door (right hand side) ..........................................1 off
I.........Bolt and butterfly nut ............................................4 off
J........Top panel retainer moulding.................................2 off
K.......Hinge pivot moulding............................................4 off
L........Locking rod recess moulding ...............................2 off
P.......Hinge pin ..............................................................4 off
Q.......Door stop moulding ..............................................4 off
S.......Shelf stop .............................................................8 off

4. ASSEMBLY
4.5 TOP ASSEMBLY (Step 5)
4.5.1 Take the two top panel retainer mouldings (J) and fully
insert one into each hole at the top front edge of each
side panel in the orientation shown in Step 5.
4.5.2 Take the top panel (F) and hook it's front edge over the
two retainer mouldings, then swing the panel downwards
until the top edges of the back and side panels begin to
enter the receiving channels within the top panel. Tap the
top panel down into position using a rubber hammer until
the four indents in the back panels clip into the matching
holes in the back receiving channels.
4.4 BASE ASSEMBLY (Step 4)
4.4.1 Place the base (D) into position as shown above and
slide it down to the bottom until its edges make contact
with the receiving channels on the back and side panels.
Using a rubber hammer, tap the base down until it is fully
engaged in the channels.
4.3 CROSS MEMBER ASSEMBLY (Step 3)
4.3.1 Tie the side panels together at the bottom front edge by
attaching the cross member (C) using four bolts (I) and
 fourbutterynutsasshownintheinsetdiagramabove.
4.2 SIDE ASSEMBLY (Step 2)
4.2.1 Holdthesidepanels(B1&B2)ataslightangleandt 
the tabs on the back panels into the slots of the side
panels and slide up to engage.
Original Language Version
4.1 BACK ASSEMBLY (Step 1)
4.1.1 Place the back panels (A1& A2) on a suitably protected
 atsurfacetopreventscratching.
4.1.2 Interlock the tabs into the slots on the back panels and
slide together until the two panels are fully engaged and
aligned.
SC03 Issue:1 - 15/07/10

4.7 SHELF ASSEMBLY (Step 7)
4.7.1 Insert shelf stops (S) at the desired height for each shelf
and lay the shelves onto the stops.
4.8 DOORS ASSEMBLY (Step 8)
4.8.1 Mount each door in turn by placing it between the upper
and lower hinge pivot mouldings. Align the upper hole in
the door edge with the hole in the upper pivot moulding
and insert a hinge pin upwards through the door and into
the moulding. Rotate the short arm of the pin around onto
the inner face of the door as shown above and bend over
the metal tab to retain it. Mount the lower hinge pin in the
same way. Repeat the process to mount the other door.
4.8.2 Fit the rubber door stops (Q) as shown in Step 8 to the
corners of each door
4.9 Using a mild solution of detergent and water and wipe
the unit down with a soft cloth.
4.6 BASE OUTER FASCIA ASSEMBLY (Step 6)
4.6.1 Fit the base outer fascia (E) over the cross member (C)
with the hinge pivot holes facing upwards. Tap the base
outer fascia down with a rubber hammer until the indents
in the sides of the fascia clip into the matching holes on
the cross member (C).
4.6.2 Insert a hinge pivot moulding (K) at each end of the
upper face of the base outer fascia (E). Insert the other
two hinge pivot mouldings at each end of the downward
facing edge of the cabinet top.
4.6.3 Insert a locking rod recess moulding (L) into the centrally
placed holes in the same faces used for mounting the
hinge pivot mouldings at both the top and the bottom.
