Sealey SJ50.V2 User manual

BOTTLE JACK 50 TONNE
MODEL NO: SJ50.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9Regularly inspect and lubricate the jack to ensure it is in good working order and condition. DO NOT use the jack if damaged or a fault
is suspected - check Section 6 Troubleshooting. If necessary, immediately repair or replace damaged parts.
9Use recommended parts only, the use of unauthorised parts may be dangerous and will invalidate your warranty.
9Ensure the work area is clean, tidy and free from unrelated materials and has adequate lighting.
9Use jack on level and solid ground, preferably concrete. Avoid tarmacadam since jack may sink in.
9Park the vehicle and apply hand brake (if automatic, place in “Park” mode). Switch off the engine and place chocks under the wheels.
9Ensure a minimum distance of 0.5m between vehicle and static objects such as doors, walls, etc. to allow for tilting during jacking.
9Ensure all persons are out of the vehicle before jacking. DO NOT enter vehicle whilst it is supported on the jack or axle stands.
9Check vehicle weight and recommended lifting points by referring to the vehicle owner’s manual. Ensure the lifting point is not corroded.
9Check lifting point is centred and stable on jack saddle (off centre loads can slip). Position jack so as to avoid operating it from under vehicle.
9Keep all unauthorised persons away from the jack when lifting and lowering.
▲DANGER! Use the jack for lifting only, NOT for supporting the lifted load. ALWAYS USE ADEQUATELY RATED AXLE STANDS.
9Keep hands etc. clear of moving parts during raising and lowering of the vehicle.
▲DANGER! Roadside wheel changing is hazardous. Be extra vigilant, you may not be able to avoid jacking on tarmacadam. Get everyone
out of vehicle. NEVER go under vehicle. Traffic may cause vehicle to rock. Use hazard warning lights. If in doubt call professional help.
9When changing a wheel, slightly loosen wheel nuts/bolts prior to jacking vehicle. Screw wheel nuts/bolts back before lowering vehicle.
9Finally tighten when vehicle is fully lowered.
9Use a qualified person to lubricate and maintain the jack. Confirm that only recommended hydraulic jack oil is used during
maintenance.
WARNING! DO NOT allow the vehicle to move, or try to start the engine, when the vehicle is jacked up.
8DO NOT jack a vehicle if it may result in the spillage of fuel, battery acid, or other dangerous substances.
8DO NOT place any part of your body under vehicle whilst it is supported by the jack. Wait until adequately rated axle stands
have been correctly positioned.
8DO NOT use jack to support extensions or cradles. DO NOT modify jack in any way. DO NOT use the jack for any other purpose.
8DO NOT top up jack with brake fluid. Use Sealey hydraulic oil only (Part No: HJO500MLS or HJO5LS).
8DO NOT allow untrained persons to operate the jack.
8DO NOT remove any labels from the jack. If labels are damaged or unclear, replace them.
8DO NOT operate the jack when you are tired, under the influence of alcohol, drugs or intoxicating medication.
9Ensure there are no persons or obstructions beneath the vehicle before lowering.
9Clean and securely stow the jack with the ram in the down position. DO NOT leave the ram extended.
9When not in use, store the jack in a safe, dry, childproof area.
WARNING! Remember, it is very dangerous to go under a vehicle supported by a jack even if additional supports are used.
8DO NOT go under a vehicle unless it is supported by adequately rated axle stands.
NOTE: Seek advice before jacking caravans or trailers.
2. INTRODUCTION
Base and reservoir machine welded for increased strength and reduced chance of leakage.
Fitted with overload valve. Supplied with 2pc handle. Fitted with carrying handle.
3. SPECIFICATION
Model No:...............................................SJ50.V2
Capacity (tonne):..................................... 50tonne
Minimum Height: ...................................... 280mm
Maximum Height: ..................................... 450mm
Hydraulic Lift: ........................................... 170mm
4. OPERATION
WARNING! Before lifting ensure Section 1 Safety Instructions are strictly followed.
4.1. Before using the jack, purge the hydraulic system, in order to eliminate any air that may have
accumulated during transit, referring to (fig.1) as follows:
a) Fit jack handle over release valve (1) and turn anti-clockwise to open valve.
b) Insert jack handle into the handle sleeve (2) and pump several times to ensure full internal
lubrication and to bleed air from the system.
c) Fit jack handle back over the release valve (1) and turn clockwise to close.
SJ50.V2 | Issue 2 (F,2,3) 25/06/19
Original Language Version
© Jack Sealey Limited
Refer to
Instructions
Wear Protective
Gloves
Wear Safety
Footwear
Wear Protective
Clothing
g.1

4.2. LIFTING
WARNING! Ensure you prepare vehicle and use jack according to Section 1 Safety Instructions.
4.2.1. Check that the ground upon which the jack will stand is level and solid.
4.2.2. Position the jack saddle (3) under the vehicle manufacturer’s recommended lifting point.
4.2.3. Position jack so as to avoid having to operate it from under the vehicle and so that the handle can be moved up and down without hitting
any part of the vehicle.
4.2.4. Using the screw extension as necessary, raise the saddle to the lifting point. Ensure that the saddle is correctly centred beneath the lifting
point.
4.2.5. Pump the handle up and down using the full stroke until the required lift is achieved.
4.2.6. Should the jack become overloaded, a safety overload valve will open, and stop the vehicle from lifting.
4.2.7. Lower the vehicle onto suitable axle stands before attempting any work.
4.3. LOWERING
4.3.1. Ensure that the axle stands are removed and that there are no persons or obstacles beneath the vehicle, or in the path of its descent.
4.3.2. The lowering speed is controlled by the amount the release valve (1) is opened. Turn valve anti-clockwise and lower slowly and carefully.
5. MAINTENANCE
IMPORTANT: Only fully qualified personnel should attempt maintenance or repair.
NOTE: Use Sealey quality hydraulic jack oil, Model No.s HJO500MLS / HJO5LS to top up or replace the hydraulic uid.
5.1. When the jack is not in use, the ram and piston must be in their lowest positions to minimise corrosion. Remove the handle to inactivate jack.
5.2. Keep the jack clean and lubricate all moving parts with acid free oil on a regular basis.
5.3. To check oil level, fully lower the jack. Remove filler plug. The correct oil level is to the bottom of the filler opening.
5.4. After a year of extensive use, the oil should be replaced in order to extend the life of the jack. Drain the oil through the filler plug opening.
Make sure that no dirt is allowed to enter the jack or the fresh oil.
5.5. To replace the oil, fill as required. Pump (unloaded jack) 5 or 6 times to expel air. Pump jack to full height and pour off excess oil before
refitting plug.
NOTE: Ensure waste oil is disposed of in accordance with local authority regulations.
Before each use check for broken, cracked, bent, or loose parts. Also check for any visible damage to welds, ram, pump, body and base.
If any suspect item is found, remove jack from service and take the necessary action to remedy the problem.
8DO NOT use the jack if believed to have been subjected to abnormal load or shock. Inspect and take appropriate action.
5.6. Periodically check the pump piston and piston rod for signs of corrosion. Clean exposed areas with a clean oiled cloth.
IMPORTANT: NO RESPONSIBILITY IS ACCEPTED FOR INCORRECT USE OF THE MACHINE
Hydraulic products are only repaired by authorised service agents. We have service/repair agents in all parts of the UK.
8DO NOT RETURN JACKS TO US. Please telephone [phone] to obtain address and phone number of your local authorised agent.
If jack is under guarantee please contact your dealer.
DE-COMMISSIONING: Draw off the oil into an approved container and dispose of the jack and the oil according to local regulations.
6. TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE REMEDY
Jack will not lift
the load
1) Overloaded
2) Oil level low
3) Release valve not correctly closed
4) Air in system
5) Packing worn or defective
1) Be sure to use jack with adequate capacity
2) Top up oil level
3) Check and close release valve
4) Open release valve and air vent (if tted) and pump the handle a few times. Close
valve and re-try
5) Return jack to authorised service agent
Jack does not lift
high enough or
feels “spongy”
1) Oil level low
2) Worn seals
3) Air in system
4) Release valve not closed
1) Top up oil level
2) Return jack to authorised service agent
3) Open release valve and air vent (if tted) and pump the handle a few times. Close
valve and re-try
4) Check and close release valve
Jack lifts but will
not hold load
1) Release valve partially open
2) Dirt on valve seats
3) Air in system
4) Faulty seals
1) Check and close release valve
2) Lower jack, close release valve. Pull up lifting arm to full height by hand. Open the
release valve to lower arm
3) Open release valve and air vent (if tted) and pump the handle a few times. Close
valve and re-try
4) Return jack to authorised service agent
Jack will not lower
completely
1) Ram damaged
2) Air in system
3) Release valve partially open
1) Contact authorised service agent
2) Open release valve and air vent (if tted) and pump the handle a few times. Close
valve and re-try
3) Check and fully open release valve
SJ50.V2 | Issue 2 (F,2,3) 25/06/19
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on [e-mail] or 01284 757505. Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
