Sealey SSG1P.V3 User manual

PRESSURE POT SYSTEM
MODEL NO: SSG1P.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGEAND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9Familiarise yourself with the application, limitations and potential hazards peculiar to the spray gun.
WARNING! Disconnect the spray gun from the air supply before changing accessories, servicing or performing any maintenance.
9Maintain the spray gun in good condition (use an authorised service agent).
9Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9Keep the spray gun clean for best and safest performance.
9Ensure that the compressed air system can supply the spray gun air consumption (7-12cfm).
9Wear approved safety respiratory protection and safety eye goggles.
9If spraying isocyanate based finisher, wear approved respirator/clean air breathing apparatus and protect skin with latex gloves and an
impervious hooded coverall.
9Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery and tie back long hair.
9Locate the spray gun in a suitable work area. Keep area clean and tidy and free from unrelated materials and ensure that there is
adequate ventilation and lighting.
9Keep children and unauthorised persons away from the work area.
9When not in use, ensure that the air supply is turned off.
9Avoid unintentional operation of spray gun.
8DO NOT point spray gun at yourself, other persons or animals.
8DO NOT direct air from the air hose at yourself, other persons or animals.
8DO NOT carry the spray gun by the hose, or pull the hose from the air supply.
8DO NOT exceed the maximum air pressure of 78psi.
8DO NOT use the spray gun for any purpose other than that for which it is designed.
8DO NOT allow untrained persons to operate the spray gun.
8DO NOT get the spray gun wet or use in damp or wet locations or in areas where there is condensation.
8DO NOT operate the spray gun if any parts are missing or damaged as this may cause failure and/or personal injury.
9When not in use, disconnect the spray gun from the air supply, clean thoroughly and store safely.
2. INTRODUCTION
Based on the SSG1 spray gun head and supplied with high capacity
pressure pot with gauge. Suitable for bulk/production spraying.
Suitable for use with water based paints. Components of this set are
also available individually. Alternative set-up available separately.
3. SPECIFICATION
Model No.........................................SSG1P.V2
Set-Up...................................................1.8mm
Available Set-Ups..................................2.0mm
Air Pressure........................................40-60psi
Air Consumption..................................7-12cfm
Pot Capacity............................................2.0ml
Original Language Version
© Jack Sealey Limited
Refer to
instructions Wear eye
protection Wear protective
gloves Wear safety
footwear Wear protective
clothing Wear a mask
g.1
SSG1P.V3 Issue 1 15/11/21

4. AIR SUPPLY
Recommended supply system see fig.2.
4.1. Ensure that the spray gun trigger is in the “off” position before
connecting to the air supply.
4.2. You will require an air pressure between 50psi, and an air
flow according to the specification.
WARNING! Ensure that the air supply is clean and does not
exceed 60psi while operating the spray gun. Too high an air pressure
and/or unclean air will shorten the product life, due to excessive
wear, and may cause damage and/or personal injury.
4.3. Drain the air tank daily. Water in the air line will damage the
spray gun and invalidate your warranty.
4.4. Clean compressor air inlet filter weekly.
4.5. Line pressure should be increased to compensate for unusually long air hoses (over 8 metres). The minimum hose diameter should be
1/4” I.D. and fittings must have the same inside dimensions.
4.6. Keep hose away from heat, oil and sharp edges.
4.7. Check hoses for wear, and make certain that all connections are secure.
5. OPERATION
5.1. For best results, handle the gun correctly. It should be held perpendicular to the surface
being sprayed and moved parallel to it. Start the stroke before squeezing the trigger and
release the trigger before finishing the stroke. This will give more accurate control of
the gun and the material fig.3.
5.2. Spray from a distance of 6 (150mm) to 10 inches (250mm), depending on the material
and the atomizing pressure. The material deposited should always be even and wet.
Each stroke must overlap the preceding stroke to obtain a uniform finish. To reduce
over spray and obtain maximum efficiency, spray with the lowest possible atomizing
air pressure.
5.3. Controlling the fluid and the fan spray:
a) As the width of the spray is altered so the fluid flow must be adjusted to maintain
the same coverage. Use the fluid control screw (‘C’ in Section 6).
b) The direction of the fan spray, either horizontal or vertical, is adjusted by turning
the air cap to the desired position and then tightening the retaining ring
6. CLEANING/MAINTENANCE
WARNING! Disconnect from the air supply before attempting any maintenance or cleaning. When reassembling after maintenance,
be sure to take care when screwing parts together. At first screw parts hand tight to avoid cross-threading. If a part cannot easily
be turned by hand, check that you have the correct part, or unscrew, realign and try again. DO NOT use excessive force when
reassembling.
6.1. Spray gun
6.1.1. Immerse the front end of the gun only in solvent until the solvent just covers the fluid connection.
6.1.2. Use a bristle brush and solvent to wash off accumulated paint.
6.1.3. DO NOT immerse the entire gun in solvent. This will cause lubricants to dissolve and packing to
dry out. Dirty solvent may also clog the narrow passages in the gun.
6.1.4. Wipe the outside of the gun with a dampened solvent rag.
6.1.5. Lubricate the gun daily with a light machine oil. Be sure to lubricate the fluid needle packing,
air valve packing, side port control packing and trigger pivot point. Do not use lubricants
containing silicone.
6.1.6. When finished spraying, flush the gun through with clean thinners.
6.2. Air nozzle, fluid nozzle & needle assembly.
6.2.1. To clean the nozzles, soak them in solvent to dissolve any dried material then blow them clean
with air.
6.2.2. Handle all nozzles carefully and do not make any alterations in the gun.
6.2.3. If you need to probe the holes in the nozzles, be sure to use a tool that is softer than brass; do not use metal instruments.
6.2.4. Adjust the fluid needle valve so that when the gun is triggered, air flow occurs before fluid flow.
Original Language Version
© Jack Sealey Limited
g.3
g.4
g.2
SSG1P.V3 Issue 1 15/11/21

SSG1P.V3 Issue 1 15/11/21
Original Language Version
© Jack Sealey Limited
Parts support is available for this product. To obtain a parts listing and/or diagram,
please log on to www.sealey.co.uk, email [e-mail] or telephone [phone].
7. TROUBLESHOOTING
A faulty spray is usually caused by improper cleaning or dried material around the uid nozzle tip or in the air nozzle. If cleaning is required,
remove these parts and soak them in solvent. This will soften the dried material which can then be removed with a brush or a cloth.
These parts are carefully machined and any damage to them will cause a faulty spray. If either the air nozzle or uid nozzle are damaged, they
must be replaced before a perfect spray can be obtained.
PROBLEM CAUSE SOLUTION
Heavy atomization, poor centre pattern. Fluid ow is too high for the air pressure and
ow.
1. Increase air pressure by adjusting
regulator (A) and increase ow adjusting
regulator (B).
2. Reduce paint ow with regulator (C).
3. Paint may be too thick. If so, dilute it.
Poor atomization/heavy centre pattern. Air pressure and ow too high for uid ow. 1. Reduce air pressure by adjusting
regulator (A).
2. Reduce air ow by adjusting regulator (B)
and increase uid ow with regulator (C).
Intermittent spray pattern. Air entering the uid supply. 1. Tighten the connection between the gun
and the pot.
2. Tighten uid nozzle with gun spanner.
3. Check if pot vent hole is blocked.
4. Check if pot is empty.
Heavy right or left side pattern. Horn hole (A) blocked. In order too check,
turn the air cap (C), if the faulty pattern is
now upside down the hole must be cleaned.
1. Place the air cap in solvent.
2. Clean hole with compressed air or with a
wooden toothpick.
3. DO NOT use a metal probe which will
damage the hole.
Top heavy or bottom heavy pattern. Possible paint build- up between uid nozzle
and air cap (A). 1. Clean the air cap and the uid nozzle, check that they match.
2. Check needle for damage.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
