TORQUE MULTIPLIER SET 7PC 1/2”- 3/4” SQ
DRIVE
MODEL NO: AK6290
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered to when using tools.
WARNING! DO NOT use the tool if damaged or thought to be faulty (Contact Service Agent).
9Ensure the work area is clean and tidy and free from unrelated materials and there is adequate lighting.
8DO NOT exceed the rated capacity of the torque multiplier.
8DO NOT use the torque multiplier for any purpose other than for which it is designed.
8DO NOT operate the torque multiplier when you are tired or under the inluence of alcohol, drugs or intoxicating medication.
9Maintain correct balance and footing, ensure the floor is not slippery and wear non-slip shoes.
9Keep children and unauthorised persons away from the working area.
8DO NOT drop or throw the torque multiplier.
8DO NOT use the torque multiplier unless you have been instructed in its use by a qualified person.
8DO NOT use the torque multiplier with air or electric impact guns.
9After use clean and store in a safe, dry, childproof location.
WARNING! Failure to heed safety and warning instructions may result in damage and/or personal injury and will invalidate the
warranty.
WARNING! The warnings, cautions and instructions referred to in this manual cannot cover all possible conditions and situations that
may occur. It must be understood that common sense and caution are factors which cannot be built into this product, but must be
applied by the operator.
2. INTRODUCTION
Robust construction with 1/2”Sq drive female input and 3/4”Sq drive male output. Accurately delivered torque multiplication factor
of 1:6.5. Compatible with a wide range of drive tools including torque and ratchet wrenches. Includes straight and 90° reaction bars,
reaction base, two breakaway adaptors* and L-type hex key. Supplied in carry-case.
*Note: Breakaway adaptors are not covered by the lifetime guarantee and are treated as consumable items.
3. SPECIFICATION
Model No............................................................ AK6290
Input Drive.............................................. 1/2”Sq(Female)
Output Drive............................................... 3/4”Sq(Male)
Maximum Rated Input ............................231Nm(170lb.ft)
Maximum Rated Output .....................1500Nm(1100lb.ft)
Gear Ratio.................................................................. 1.9
Torque Ratio............................................................ 1:6.5
4. OPERATION
Please refer to the makers instructions for correct use and setting of the torque wrench.
4.1.  TheAK6290isusedincombinationwithasuitabledrivetool,suchasaratchetwrenchortorquewrenchttedintothefemaleinput
 socketandasuitablesizesocketttedontothemale3/4”drivesquare(g.1).
4.2.  Ifusingatorquewrenchcalculatetherequiredinputgureforthetorquewrenchbydividingthetorquesettingforthexingbyafactor
of 6.5.
4.3. The torque multiplier can either be used with the long or the 90° reaction bar. The 90° Reaction bar can be adjusted to use with
 anormaloradeepsocket(seeg.1).
4.4.  Thisassembly(g.1)isnowplacedonthenutorbolttobetightenedwiththeReactionbarifpossiblerestrainedagainstsome 
substantial part of the equipment being serviced. Any force applied to the input drive is multiplied by a factor of 6.5 at the output drive of
the multiplier.
Note: Because the multiplier uses a system of gears, the output drive turns substantially slower than the input drive. When the preset
torque setting is reached, the torque wrench mechanism will “click.” Stop applying force immediately to avoid overtightening the
nut/bolt.
4.5. This torque multiplier is designed to have a maximum input of 231Nm and the 1/2”Sq female input will break away if more force is
applied. If this happens, wind the broken portion out, by turning the socket set screw in its middle, clockwise. Replace with the spare
supplied.
Note: Breakaway adaptors are not covered by the lifetime guarantee and are treated as consumable items.
AK6290 | Issue 2 (H4F) 09/03/18
Original Language Version
© Jack Sealey Limited
Refer to
instructions

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Parts support is available for this product. Contact
email [e-mail] or telephone [phone]
