Sealey YKGS20 User manual

SAFETY GUARD FOR PRESSES
MODEL NO’S: YKGS20, 30, 50, 75
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Regularlycheckguardforworn,loose,ordamagedparts.IfyoundanyoftheseconditionsDO NOT USE THE GUARD.
 Failuretodosomaycausesevereinjury!
9Keeptheguardfreeofdirtanddebris.
8DO NOTaddtoormodifyanypartoftheguard.Doingsowillvoidyourwarranty.
8DO NOTusetheguardforpurposesotherthanthoseitwasdesignedfor.
9 Cleanguardwithwaterandmilddetergent.
9 Alwaysrefertothesafetyinstructionsprovidedinyouroorpressinstructionmanual.
WARNING! Thewarnings,cautionsandinstructionsreferredtointhismanualcannotcoverallpossibleconditionsandsituationsthat
 mayoccur.Itmustbeunderstoodthatcommonsenseandcautionarefactorswhichcannotbebuiltintothisproduct,butmustbe
 appliedbytheoperator.
2. INTRODUCTION
Lightweightaluminiumframewithtoughsteelmesh.Adjustableguardprotectstheuserand/orpasserbyfrombeinginjuredifworkpieceis
accidentlydislodgedunderload.Boltsontoeithersideofthetableandfeaturesveheightincrements,allowingtheworkpiecetobeplacedonto
tablewithnoobstruction.One-wayspringloadedlockingclipsthenallowtheguardtobepulledupquicklyandsnapstraightintopositionforfull
protection.
3. SPECIFICATION
Model No: ................................................................YKSG20
Applications: ............................................ YK209F, YK20FFP
Model No: ................................................................YKSG30
Applications: .............................YK30F, YK30FAH, YK30FFP
Model No: ................................................................YKSG50
Applications: .........................YK509F, YK509FAH, YK50FFP
Model No: ................................................................YKGS75
Applications: ..........................................YK759F, YK759FAH
4. ASSEMBLY/ OPERATION
4.1.  Choosewhichsideoftheoorpresstottheguard,xtheguardsupportbracketstothe
 tableusingthepre-drilledholesandxingsprovided.Seegs.1&2.
 Ensurethebracketsarettedwiththelocksontheoutsideandthecorrectwayupasg.1.
Refer to
instruction
manual
YKSG20,30,50,75Issue:2(H,F)07/04/22
Original Language Version
©JackSealeyLimited
Guard SupportGuard Support
BracketFixingsBracketFixings
Ensure The CorrectEnsure The Correct
OrientationOfTheOrientationOfThe
LockingMechanismLockingMechanism
RearRear
ViewOfViewOf
BracketBracket
FixingsFixings
g.1
g.2

4.2.  Taketheguardandslideitintothebracketsfromabove;theguardhasastoponeithersideatthetopoftheframe,thisshouldbe
 uppermostandfacingtowardstheoperatorg.3.
4.3.  Pullthelocksbackoneithersideandlowertheguardallthewaydown.
CAUTION! Theguardwilldropfreelyuntilitreachesthestops.
4.4.  Toraisetheguardtooneoftheveheightincrements,pulluptheguardandthespringloadedlockingclipswillsnapintopositionat
 thedesiredheight.
.
Original Language Version
©JackSealeyLimited
Guard Stops
Uppermost
fig.3
YKSG20,30,50,75Issue:2(H,F)07/04/22
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento
arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely
unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids
accordingtolocalregulations.
Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior
notice.
Important:NoLiabilityisacceptedforincorrectuseofthisproduct.
Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.
