Sealey SDL7.V2 User manual

4V RECHARGEABLE LITHIUM-ION SOLDERING
IRON
MODEL NO: SDL7.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY FOR USE OF CHARGER
USE ONLY THE SUPPLIED CHARGER PLUG AND LEAD FOR CONNECTING CHARGER TO THE IRON .
WARNING ! It is the user’s responsibility to read, understand and comply with the following electrical instructions:
You must ensure the risk of electric shock is minimised by the installation of appropriate safety devices.
An RCCB (Residual Current Circuit Breaker) should be incorporated in the main distribution board. We also recommend that an
RCD (Residual Current Device, Sealey model RCD981) is used with all electrical products, particularly portable equipment which is
plugged into an electrical supply not protected by an RCCB.
You must also read and understand the following instructions concerning electrical safety.
1.1.1. TheElectricityAtWorkAct1989requiresallportableelectricalappliances,ifusedonbusinesspremises,tobetestedbyaqualied
electrician, using a Portable Appliance Tester (PAT), at least once a year.
1.1.2. The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of the appliance and
 thesafetyoftheapplianceoperator.Ifinanydoubtaboutelectricalsafety,contactaqualiedelectrician.
1.1.3. You must ensure that you:
Inspect the charger plug, cable and connector for wear and damage to ensure items are safe before connecting to the mains power
supply. If worn or damaged DO NOT use.
1.1.4. Uncoil the cable between charger and the iron.
8DO NOT pull the charger plug from the mains socket by the lead.
WARNING ! DO NOT use any other type of charger with this product, other than the supplied one. Failure to observe this warning
 couldresultininjuryandorreandwillinvalidatethewarranty.
8DO NOT try to take the charger plug apart.
8DO NOT use the charger plug to charge or power any other electrical item.
8DO NOT get the charger plug wet, or use in wet, damp conditions (for indoor use only).
1.2. BATTERY SAFETY
WARNING ! Toreducetheriskofburnsorre:
8DO NOT attempt to open, disassemble, modify or service the battery pack.
8DO NOTcrush,puncture,shortexternalcontactsordisposeofinreorwater.
8DO NOT expose to temperatures above 60°C (140°F).
Recycle or dispose of used equipment as stipulated by local regulation.
1.3. GENERAL SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop
practise regulations are adhered to when using this equipment.
9Familiarise yourself with the application, limitations and potential hazards of the soldering station.
9Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9Locate soldering station in a suitable working area, keep area clean and tidy and free from unrelated materials.
9Keep the work area clean, uncluttered and ensure there is adequate lighting.
9Keep the soldering iron clean for best and safest performance.
9Ensure there are no flammable or combustible materials near the work area.
9Wear approved safety eye protection (standard spectacles are not adequate).
9Wear appropriate protective clothing.
9Ensure the workpiece is adequately held before operating the soldering iron. See Sealey model number SD150.
9Always replace the soldering iron in its holder when not in use.
9Remove excess solder from the soldering iron by wiping the tip on a damp, natural sponge; not by abrupt force.
8DO NOT attempt to remove excess solder from the soldering iron by shaking it. Hot solder may become airborne and land on skin
causing burns and blisters.
8DO NOT allow children or pets into the area where the soldering is taking place.
8DO NOT attempt to cool the gun with water.
NOTE: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not
be carried out by children without supervision.
SDL7.V2 Issue 1 13/11/2020
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Hot surfaces Indoor use
only
Warning Wear eye
protection

2. INTRODUCTION
Professional Lithium-ion cordless soldering iron. Ideal for multiple applications including automotive soldering in-and-around engine
 bays.Heatsuptoworkingtemperaturein25seconds.IntegralLEDworklights(x2).Autoshut-o󰀨after10mins.Unitfeaturesasturdy
base stand and is supplied with a mains charger. Maximum Temperature: 450°C.
3. SPECIFICATION
Model No:.....................................................................SDL7
Battery: ..........................................................4V 1.5Ah Li-ion
Charging time:...................................................................3hr
Maximum temperature ................................................. 450oC
Operating time ............................................................. 50min
Power rating......................................................................8W
IMPORTANT WARRANTY INFORMATION
Thebatteryttedtothisironisconsideredtobeaconsumableitemanditsabilitytoacceptachargewillreduceovertime.
We will provide warranty against mechanical and electrical defect for a period of one year - this does not cover fair wear and tear.
Ifthebatteryisnotproperlychargedbeforerstuse,orregularlyconditioned,itscapacitywilldiminish.Underthesecircumstanceswewill
not replace the battery regardless of whether it is less than one year old.
NOTE:Thelithiumbatterydoesnotsu󰀨erfrommemorye󰀨ectandoncefullychargedmaybestoredforuptosixmonthswithoutanother
charge.
4. OPERATION
4.1. Plug in charger and ensure that the soldering iron is fully
 chargedbeforerstuse.Thebatterychargeindicator(g.1)is
red when charging and green once fully charged.
4.2. To switch on, remove the soldering iron from the charging dock
 andpresstheOn/O󰀨button(g.1).Thetwoworklightswill
illuminate.
4.3. HolddowntheOn/O󰀨button,thesolderingtipwarmsupand
the battery charge / state indicator will glow red until the tip
is up to temperature. When the tip reaches the working
temperature the light will glow green.
4.4. The tip will maintain the working temperature for 10 minutes
and the green light will show in the state indicator after which
itwillturno󰀨.
4.5. To recommence soldering, after a brief period, repeat
4.2, 4.3 and 4.4.
Original Language Version
© Jack Sealey Limited
g.1
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without
prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of
products containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance
scheme. Jack Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
SDL7.V2 Issue 1 13/11/2020
