Sealey CST999.V2 User manual

300KG SACK TRUCK WITH PNEUMATIC TYRES
MODEL NO: CST999.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9Always load evenly with the centre of gravity of the load as near the centre and rear of the plate as possible.
9Obtain additional support for large or wide loads to prevent tipping.
8DO NOT overload the truck - see Specification.
8DO NOT leave unattended, especially when loaded, unless the wheels are chocked
or the truck is otherwise secured.
8DO NOT use truck on curbs or steps - use a ramp.
8DO NOT allow others to ride on the truck.
8DO NOT use the truck if any part is damaged, paying particular attention to the wheels.
9Ensure tyres are correctly inflated, refer to section 3, Specification.
Max tyre pressure: 30psi.
2. INTRODUCTION
Extra strong tubular steel frame construction. Steel centred pneumatic wheels allow transport over the roughest terrain. Features composite hand
grips for added comfort and control.
3. SPECIFICATION
Model No..................................................................... CST999
Capacity ..........................................................................300kg
Wheel size.....................................................................250mm
Wheel width.....................................................................90mm
Height..........................................................................1300mm
Overall Width.................................................................500mm
Platform Depth ..............................................................280mm
Recommended tyre pressure................................... 22-26psi
4. ASSEMBLY
4.1. WHEELS
4.1.1. Ensure each axle is clean from dust and dirt to allow free movement of the wheel.
4.1.2. Slide the wheel (fig.1.2) onto the axle (fig.1.1), followed by the washer (fig.1.3) and complete by pushing the split pin (fig.1.4) through the
hole in the end of the axle and bending over to retain.
4.1.3. Repeat for the other side.
g.1
CST999.V2 | Issue 1 24/10/19
Original Language Version
© Jack Sealey Limited
Refer to
instructions

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on [e-mail] or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Parts support is available for this product. To obtain parts, please log on to
www.sealey.co.uk, email [e-mail] or telephone [phone]
