INSTRUCTIONS FOR: VACUUM CLEANERS AND
FRONT MOUNTED SQUEEGEES
MODEL: PC455, PC477, PC455AK1, PC477AK1
1. SAFETY INSTRUCTIONS
1.1. ELECTRICAL SAFETY
WARNING! It is the responsibility of the owner and the operator to read, understand and comply with the following:
You must check all electrical products, before use, to ensure that they are safe. You must inspect power cables, plugs, sockets and
any other connectors for wear or damage. You must ensure that the risk of electric shock is minimised by the installation of appropriate
safety devices. A Residual Current Circuit Breaker (RCCB) should be incorporated in the main distribution board. We also recommend
that a Residual Current Device (RCD) is used. It is particularly important to use an RCD with portable products that are plugged into a
supply which is not protected by an RCCB. If in any doubt consult a qualified electrician. You may obtain a Residual Current Device by
contacting your Sealey dealer. You must also read and understand the following instructions concerning electrical safety.
1.1.1. The Electricity at Work Act 1989 requires all portable electrical appliances, if used on business premises, to be tested by a qualified
electrician, using a Portable Appliance Tester (PAT), at least once a year.
1.1.2. The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of those appliances
and the safety of the appliance operators. If in any doubt about electrical safety, contact a qualified electrician.
1.1.3. Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply. See 1.1.1. and 1.1.2.
and use a Portable Appliance Tester.
1.1.4. Ensure that cables are always protected against short circuit and overload.
1.1.5. Regularly inspect power supply cables and plugs for wear or damage and check all
connections to ensure that none is loose.
1.1.6. Important: Ensure that the voltage marked on the appliance matches the power supply
to be used and that the plug is fitted with the correct fuse - see fuse rating at right.
1.1.7. DO NOT pull or carry the appliance by the power cable.
1.1.8. DO NOT pull the plug from the socket by the cable.
1.1.9. DO NOT use worn or damaged cables, plugs or connectors. Immediately have any faulty
item repaired or replaced by a qualified electrician. When an ASTA/BS approved UK
3 pin plug is damaged, cut the cable just above the plug and dispose of the plug safely.
Fit a new plug according to the following instructions (UK only).
a) Connect the GREEN/YELLOW earth wire to the earth terminal ‘E’.
b) Connect the BROWN live wire to the live terminal ‘L’.
c) Connect the BLUE neutral wire to the neutral terminal ‘N’.
d) After wiring, check that there are no bare wires, that all wires have been correctly connected, that the cable outer
insulation extends beyond the cable restraint and that the restraint is tight.
Double insulated products, which are always marked with this symbol , are fitted with live (brown) and neutral (blue) wires only.
To rewire, connect the wires as indicated above - DO NOT connect either wire to the earth terminal.
1.1.10. Products which require more than 13 amps are supplied without a plug. In this case you must contact a qualified electrician to
ensure that a suitably rated supply is available. We recommend that you discuss the installation of an industrial round pin plug
and socket with your electrician.
1.1.11. If an extension reel is used it should be fully unwound before connection. A reel with an RCD fitted is preferred since any appliance
plugged into it will be protected. The cable core section is important and should be at least 1.5mm², but to be absolutely sure that the
capacity of the reel is suitable for this product and for others which may be used in the other output sockets, we recommend the use
of 2.5mm² section cable. If extension reel is to be used outdoors, ensure it is marked for outdoor use.
1.2 GENERAL SAFETY
Disconnect the cleaner from the power supply before servicing, changing accessories, or
performing any maintenance.
Use only genuine parts and accessories. Unauthorised parts and accessories may be
dangerous and will invalidate your warranty.
Maintain the cleaner in good condition. Use an authorised agent for servicing. Keep
machine clean, but DO NOT use solvents.
DO NOT operate the unit without a filter in place as this will cause machine faults and will
invalidate your warranty.
Use only the paper cartridge filter specified for dry vacuuming.
Use only the cloth filter specified for wet vacuuming.
Wear protective clothing and gloves.
DO NOT allow children or untrained persons to operate the cleaner.
DO NOT place attachments close to your face (especially eyes, ears).
DO NOT point the hose end at other persons or animals.
DANGER! DO NOT vacuum very fine powders,hot or glowing ash, inflammable,
explosive, corrosive or other dangerous substances.
DO NOT leave the machine running unattended, turn power supply OFF.
DO NOT leave the vicinity until motor has come to a complete stop.
DO NOT operate the cleaner when you are tired or under the influence of alcohol, drugs or
intoxicating medication.
DO NOT use the cleaner in the rain or in very damp conditions.
DO NOT use the cleaner for a task it is not designed to perform.
DO NOT tilt or drop the cleaner.
DO NOT place the cleaner close to a heat source.
When not in use, store the cleaner in a safe, dry, childproof location.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS AND
CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY
CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and
properly maintained, give you years of trouble free performance.
FUSE RATING 13 AMP
Blue
Neutral
Wire
Yellow & Green
Earth Wire
Cable
Restraint
Brown
Live
Wire
Original Language Version PC455, PC477, PC455AK1, PC477AK1 Issue: 3 - 17/11/10

2.1 Introduction
High powered, lightweight industrial units. Stainless steel drum with dual
filtration system for superior performance. Features safety shut-off for
wet operation. Trolleys with swivel bin and two rear locking wheels for
easy emptying plus front swivel castors for added manoeuvrability. Foot
operation for squeegee adjustment. Supplied with Ø38mm accessory kit,
3.2mtr cable with 3 pin plug, cloth and cartridge filters. PC477 is fitted
with twin motors offering superior vacuuming power to collect any type of
solid from dust to rubble and is particularly suitable for industrial and
commercial applications where extra capacity and power are required to
clean large areas or large volumes of waste. PC455 features blower
facility. Optional front mounting squeegee available, as illustrated in fig.9.
2.2 Specifications
Model No ................................................ PC455...........................PC477
Motor Power ...........................................1200W.......................... 2400W
Supply........................................................230V............................. 230V
Air Flow................................................132m³/hr ....................... 174m³/hr
Drum Size ................................................... 55ltr ...............................77ltr
Weight........................................................ 28kg .............................. 39kg
Vacuum Accessories Ø............................ 38mm............................38mm
Filter Type ...................................... Paper, Cloth.................. Paper, Cloth
Replacement Paper Filter..................PC455.PF ..................... PC477.PF
Replacement Cloth Filter Basket ...... PC455.CF..................... PC477.CF
Optional Squeegee ........................PC455AK1 ....................PC477AK1
Overall Squeegee Length...................... 670mm .........................670mm
2. INTRODUCTION AND SPECIFICATIONS
4. OPERATION
3.1 Hose Installation. Fig. 1.
3.1.1 Fully insert the hose into the suction coupler on the main drum. It will
automatically snap into place.
3.1.2 To release the hose, slide the release knob in the direction of the arrow
and pull the hose out of the suction coupler.
3.2 Filter Removal. Fig. 2a/2b
3.2.1 To access the filter, unclip and remove the upper part of the cleaner from
the metal tank.
3.2.2 To change the paper cartridge filter push the retaining clip in the
direction of the arrow (fig.2b) and remove the filter from the motor unit.
3.2.3 For wet vacuuming remove the paper cartridge filter and install the fabric
filter over the filter basket. The filter basket (fig.2a) sits in the top of the
drum and is held in place when the upper part of the vacuum cleaner is
clipped onto the tank.
3.3 Blower Function. Fig. 3. (PC455 only)
3.3.1 Connect the hose to the air vent on top of the vacuum cleaner.
3.3.2 Turn the power supply switch to ON.
3.4 Locking and Unlocking the Tank. Fig. 4.
3.4.1 Lock the tank to the frame support by pushing the knobs DOWN.
3.4.2 Unlock the tank from the frame support by pushing the knobs UP.
3.4.3 When the tank is unlocked it can be lifted from the frame.
3.4.4 The tank must only be tipped for emptying in the locked position. See fig.13.
Fig. 1
Fig. 2b
Fig. 2a
Fig. 3
Fig. 4
3. ASSEMBLY
4.1 Nozzles
4.1.1 The brush nozzle is used on large, dry areas such as a floor or a bed.
Refer to Fig. 5.
4.1.2 The squeegee nozzle is used on water, cement or other non-volatile
substances. Refer to Fig. 6.
4.1.3 The round brush is used on small areas such as a sofa, window or the
corner of a floor. Refer to Fig. 7.
4.1.4 The crevice tool is used on narrow grooves or windows. Refer to Fig. 8.
4.2 Optional Squeegee. Figs. 9, 10 and 11.
4.2.1 The optional squeegee should be attached to the underside of the
vacuum cleaner as shown in Fig. 11.
4.2.2 Depress the operating pedal. The squeegee will drop on to the surface
to be cleaned. Refer to Fig. 10.
4.2.3 If necessary, adjust the height of the squeegee using the butterfly nut at
the front of the cleaner. This sets the height of the front guide wheel.
Refer to Fig. 9.
4.2.4 With the squeegee in contact with the surface to be cleaned, lock the
guide in position.
4.2.5 Operate the squeegee by pushing the vacuum cleaner across the area
to be cleaned.
4.2.6 When cleaning is completed, raise and lock the squeegee by depressing
the rest and lock pedal.
Fig. 5
Fig. 6
Fig. 8
Fig. 7
Original Language Version PC455, PC477, PC455AK1, PC477AK1 Issue: 3 - 17/11/10

Cleaner will not operate.
Dust comes from the motor cover.
Reduced efficiency and increased
motor speed/vibration.
No power supply.
Faulty power cable, switch or motor.
Container full of liquid.
Filter missing or damaged.
Filter clogged.
Nozzle, hose or bin inlet blocked.
Check supply.
Check and repair or replace faulty item.
Empty container.
Fit or replace.
Replace or clean filter.
Check nozzle, hose and bin inlet for blockage.
6. TROUBLESHOOTING
5.1 Cleaning
NOTE: If the suction is weak, remove the paper or
fabric filter and remove the dust by hand-
patting the filter.
5.1.1 Remove the vacuum cleaner head to
access the filter. Refer to Fig. 12.
5.1.2 Remove all dust on the filter. Clean and if
necessary air-dry the filter for further use.
5.2 Emptying the Tank
5.2.1 Position the cleaner next to a suitable
container or drain. Lock tank onto frame as
shown in fig.4. Put the rear wheel locks
on. Hold the frame handle with one hand
and lift the tank to the emptying position
using the tank handle. Refer to Fig. 13.
5. CLEANING AND MAINTENANCE
Fig.10
Fig.9 Fig.11
Fig.12 Fig.13
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
Original Language Version PC455, PC477, PC455AK1, PC477AK1 Issue: 3 - 17/11/10
