Sealey Cp20vwdv User manual

20V SV20 SERIES 10L WET & DRY VACUUM

CLEANER

MODEL NO: CP20VWDV

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

▲DANGER! DO NOT vacuum hot or glowing ash, cigarette ends, inflammable, explosive, corrosive or other dangerous substances.

burning matches, smoldering ash and cigarette butts, combustible, caustic, inflammable or explosive substances, vapor or liquids Be sure

to wear the appropriate P.P.E for the material being worked with.

8DO NOT operate the unit without a filter in place. Using the cleaner without a filter may cause damage to the vacuum cleaner and

will invalidate your warranty.

8DO NOT allow children or untrained persons to operate the cleaner.

8DO NOT place attachments close to your face (especially eyes, ears, etc).

8DO NOT point the hose end at other persons or animals.

8DO NOT leave machine running unattended. Turn power OFF and DO NOT leave the vicinity until motor has come to a complete stop.

8DO NOT operate the cleaner while under the influence of drugs, alcohol or impairing medication, or if you are tired.

8DO NOT use the cleaner in the rain or in very damp conditions.

8DO NOT use the cleaner for a task it is not designed to perform.

8This appliance is not suitable for vacuuming dust which can be harmful to health.

8Never use the appliance if it is damaged.

9Always switch the unit off and remove battery pack before changing attachments, filters and emptying the tank.Always check that the

filter is clear and not blocked. Keep all openings clear of any blockages.

9Only allow the appliance to be serviced by an authorized after sales service outlet.

9The appliance is only to be used with the battery intended.

9Remove battery when not in use and before servicing and cleaning.

9To avoid electric shock, do not expose to rain.

9Never modify the cleaner in any way - this is dangerous and will invalidate the warranty.

9When lifting the unit, always lift it with the handle.

9Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected to damage or stress.

9Remove the battery pack from the cleaner before servicing, changing accessories, or performing any maintenance.

9Use only genuine parts and accessories. Unauthorised parts and accessories may be dangerous and will invalidate your warranty.

9Maintain the cleaner in good condition. Keep machine clean, but DO NOT use solvents.

9For dry vacuuming ensure the filter is firmly in place before operating the cleaner.

9When not in use, store the cleaner in a safe, dry, childproof location.

9This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities

or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way

and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by

children without supervision.

2. INTRODUCTION

 10LHandheldVacuumcapableofpickingupnedust,plasterboard,sawdust,debris,liquidsandmore.Lightweight,portableand

cordless making it very convenient for use in the home, workshop or car, especially where mains power is not accessible. Lightweight

tank features quick release clips for ease of emptying. Other features include on board accessory storage; separate battery housing

and built-in blow function, which can be used for many applications. Supplied with brush head attachments (x2), 2m extendible hose,

 hosestorageclips(x4),HEPAlter,dustandfoamlters.Requirescompatible20Vbatteryandmainscharger,soldseparately.

3. SPECIFICATION

Model No: ...........................................................CP20VWDV

Airow: ....................................................................37.8m³/hr

Battery: ..................20V 2Ah - 6Ah Lithium-ion (not included)

Alternative Batteries:

............. CP20VBP2 - 2Ah Battery, CP20VBP4 - 4Ah Battery,

.......................................................CP20VBP6 - 6Ah Battery.

Drum Size:.......................................................................10L

Filter Type:....................................................................HEPA

Maximum Vacuum Pressure: .......................................10kPa

Refer to

instruction

manual

CP20VWDV Issue 2 15/11/22

Original Language Version

Motor Power:.................................................................150W

Supply:.............................................................................20V

Vacuum Accessories Diameter:....................................32mm

4. CONTENTS CARTON CO

4.1.  Contents(g.2)areinsidecleanerbody(exceptitem10).

4.2. Locate the two side locking hooks (Fig.2.6) which hold the top section in place.

4.3.  Undothelockinghooks,removethetopsectionandtakeouttheitemsinthecontainer(g.1).

4.4. Check and identify each component as shown. If anything is missing or damaged please contact your supplier immediately.

4.5.  ASSEMBLY(g.2).

WARNING: Remove Battery

4.5.1. Undo head locking hooks and lift off head assembly (fig.2).

4.5.2. Fitting the appliance head (Fig.2.3).

4.5.3. The appliance head (Fig.2.3) is fastened to the tank (7) by the locking hook (6). To remove the appliance head (Fig.2.3), open the locking

hook (6) and remove the appliance head (3). When fitting the appliance head (3), make sure that the locking hook (6) locks into place

correctly.

4.6. FITTING THE FILTER

NOTE: Never use the wet and dry vacuum cleaner without a filter! Always ensure that the filters are perfectly secure!

4.7. FITTING THE FOAM FILTER (fig.3) for wet vaccuuming.

4.7.1. For wet-vacuuming, slip the supplied foam filter (Fig.3.15) over the filter basket.

Original Language Version

Item no Description Item no Description

1 Handle 12 2-in-1 crevice/brush nozzle

2 On/O󰀨switch 13 Cartridgelter

3 Alliance head 14 Clothlter

4 Filter basket (Fig.7.4) 15 Foamlter

5 Safetyoatvalve(Fig7.5) 16 Battery cover

6 Locking hook 17 Battery charger (not shown or supplied).

7 Tank 18 Battery(showning.9butnotsupplied).

8 Suction hose connector 19 PushButtonlock(showning.9)

9Blowconnector(Fig.7.9) 20 Suction hose holder

10 Flexible hose 21 Slots for nozzle storage

11 Universal brush

fig.1fig.2

fig.3

CP20VWDV Issue 2 15/11/22

4.8.  FITTINGTHECARTRIDGEFILTER(fig.4) for dry Hepa vaccuming.

4.8.1. For dry vacuuming, slip the cartridge filter (Fig 4.13) over the filter cage. The cartridge filter (Fig 4.13) is suitable for dry-vacuuming only.

FITTING THE CLOTH FILTER (fig.5)

For dry-vacuuming, slip the cloth filter (Fig 5.14) over the filter cage, this is suitable for dry-vacuuming only.

4.8.2. ASSEMBLE 4 PCS SUNCTION HOSE HOLDERS (Fig 6.20) by pushing the holders through the slots on the appliance

head (fig.2.3),and put on the suction hose for storage.(Fig.6.21 is for the nozzle storage.

4.9. FITTING THE SUCTION HOSE(Fig.7.9,Fig.8.8)

Connect the suction hose (Fig.1.10) to the corresponding connector on the head assembly, depending on the application required.

4.10. INSTALLING THE BATTERY(fig.9)

4.10.1. Openthebatterycover(Fig9.16),Dothisbyswingingupthecoverasshowninfig.9.Theninsertthebatterypack(18)intothemount

and push it forward until you hear the battery engage. Battery not supplied see specifications not supplied with product.

 Toremovethebatterypack,pressthesidepushlockbutton(Fig9.19)ofthebatterypack,pullthebatterypackawayfromthemount.

5. OPERATION

WARNING! Ensure you read, understand and apply Section 1 ‘Safety Instructions’. Reminder: DO NOT vacuum hazardous substances.

Use of an incorrect filter will invalidate your warranty.

WARNING! Remove battery before assembly or making adjustments.

5.1. VACUUMING

5.1.1. Connect the suction hose (Fig.8.8) to the suction hose connector (fig.10 & fig.11)

Original Language Version

fig.4fig.5

fig.7

fig.8fig.9

fig.10 fig.11

fig.6

CP20VWDV Issue 2 15/11/22

5.2. BLOWER OPERATION

5.2.1. Ensurethebatteryisremovedfromtheunit(fig.9.).

5.2.2. Connectthesuctionhosetotheblowconnector(Fig.7.9).

5.2.3. Insert the battery, turn unit on and commence blowing.

5.2.4. Aim hose assembly at area to be cleared.

5.2.5. DRYVACUUMING(fig.5)

WARNING! Ensure the battery is removed from the unit.

5.2.6. Loosen clips (Fig.2.6) and remove the top section and filter assembly

5.2.7. Slide the bag filter or cartridge filter over the inlet hole to the hose connector. Manipulate to ensure a good seal (Fig.4.13 & Fig.5.14).

5.2.8. Connect hose to body.

5.2.9. Assemble required tube and hose arrangement. (fig.8, fig.10, fig.11).

5.2.10. Insert the battery, turn unit on.

5.2.11. On/Off switch (Fig.2.2)

5.2.12. Switch position 0: Off

5.2.13. Switch position I: On

5.2.14. When you have completed vacuuming, press the switch to ‘Off’.

5.3. EMPTYING DUST BAG

WARNING! Turnoffcleanerandremovebattery(fig.9).

5.3.1. Release side clips (Fig.2.6) and lift off top assembly.

5.3.2. Carefully remove bag filter and empty contents into suitable receptacle.

5.3.3. Reassemble filter and replace into cleaner body.

5.4. WET VACUMMING

WARNING! Ensure the battery is removed from the unit.

5.4.1. Loosen locking hooks (Fig.2.6) and remove the top section and filter assembly (Fig.2.3).

5.4.2. Slide foam filter over inlet (Fig.3.15) see point.5.2.

5.4.3. NOTE: Check that the filter is securely fitted at all times.

5.4.4. Check that filter components are assembled correctly.

5.4.5. Install top assembly and lock in place (Fig.2.6).

5.4.6. When wet vacuuming, the floating safety switch (Fig.7.5) closes when the maximum tank level is reached. In doing so, the suction noise

of the equipment will change and become louder. Switch off the equipment and empty the tank.

5.4.7. Insert the battery, turn unit on and commence cleaning.

5.4.8. When you have completed vacuuming remove battery, unlatch top assembly and carefully empty contents of cleaner body into suitable

receptacle. DO NOT store with liquid in cleaner body.

5.5. Handle the filters carefully when cleaning or installing.

6. MAINTENANCE

WARNING! Ensurethebatteryisremovedfromtheunitbeforepreforminganymaintenance(fig.9).

6.1. Disconnect the hose from the container(Fig.8.8).

6.2. Undo the locking hooks and remove motor head from the container.

6.3. Clear out any dirt or debris from the container and hose.

6.4. Check the battery docking to make sure it has not received any damage.

6.5. The filter assembly contains two washable partsandacartridgelter,whichcanbecleanedwithanebrushorhandbrush.

6.6.  Theclothlter(Fig.5.14)andthefoamlter(Fig.3.15)canbewashedwithcoldorlukewarmwater.DO NOT use detergent.

allow elements to air dry. DO NOT use heating equipment.

6.7. Check all elements for damage and replace if necessary.

7. TROUBLESHOOTING

If the vacuum vibrates abnormally, stop motor immediately. Abnormal vibration usually indicates a mechanical problem, continued

operation could lead to injury or damage.

NOTE: The distributor will not be responsible for any damage or injuries caused by the repair of the vacuum by an unauthorized

person or by mishandling of the vacuum. If motor sound becomes higher pitched always check for the following: Blocked hose or

 accessory.-Blockedlter.-Fullcontainer.

Original Language Version

ENVIRONMENT PROTECTION

Recycle unwanted materials instead of disposing of them as waste.All tools, accessories and packaging should be sorted,

taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product

becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and

dispose of the product and fluids according to local regulations.

PURCHASE HERE

WEEE REGULATIONS

Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment

(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid

waste authority for recycling information.

Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior

notice.

Important: No Liability is accepted for incorrect use of this product.
