OWNER’S
MANUAL
Model No.
200.71210
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
10/2 AMP
MANUAL
BATTERY CHARGER
CAUTION:
Read and Follow All Safety
Rules and Operating Instructions
Before Every Use of this Product.

1
Sears 210 - Sch 50911/13/95
Table Of Contents
Warranty .................................................................. 1
Important Safety Instructions ................................. 2
Parts ......................................................................... 3
Before Using Your Battery Charger ........................ 4
Plugging it in .......................................................... 4
Using an extension cord ........................................ 4
Preparing your battery to be charged ................... 5
Warranty
FULL TWO-YEAR WARRANTY
If, within two years from the date of purchase this battery charger fails due to a defect in materials or work-
manship, simply RETURN IT TO THE NEAREST SEARS STORE IN THE UNITED STATES, and Sears will
repair or replace it, free of charge.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to
state.
Sears, Roebuck and Co., Dept 817WA,
Hoffman Estates, IL 60179
Using Your Battery Charger .................................... 6
Setting the controls ................................................ 6
Charging your battery ............................................ 6
Calculating charge time ......................................... 8
Maintenance and care ........................................... 9
Troubleshooting .................................................... 10
Please read this Owner's Manual before using your Battery Charger
The Sears model 200.71210, Manual Battery Charger, offers a wide range of features to accommodate
the needs for home or light commercial use. This manual will show you how to use your charger safely and
effectively. Please read and follow these instructions and precautions carefully.

2
Sears 210 - Sch 50911/13/95
Help us help you
Remember:
•Place charger as far away from battery being
charged as the charger cables will permit.
•Do not expose charger to rain or snow.
•Never charge a frozen battery. If battery fluid
(electrolyte) becomes frozen, bring battery into a
warm area to thaw before you begin charging.
•Never allow battery acid to drip on charger when
reading specific gravity or filling battery.
•Never set a battery on top of the charger.
•Never place charger directly above battery being
charged. The gases from the battery will corrode
and damage the charger.
•Never use charger for charging dry-cell batteries
that are commonly used with home appliances.
These batteries may burst and cause personal
injury.
Personal Safety Precautions
For your own personal safety, please follow the
following precautions:
•Wear complete eye and clothing protection when
working with lead-acid batteries.
•Be sure that someone is within range of your
voice
to come to your aid if needed while you work
with or are near a lead-acid battery.
•Have plenty of fresh water and soap nearby for
use in case battery acid contacts your eyes, skin,
or cloth-ing. If this happens, wash immediately
with soap and water. Then get medical attention.
•Avoid touching your eyes while working with a
battery. Acid particles (corrosion) may get into
your eyes. If this occurs, flush eyes immediately
with running cold water for at least 10 minutes.
Then immediately get medical attention.
– SAVE THESE INSTRUCTIONS –
w
• Read all instructions and cautions printed
on the battery charger, battery, and vehicle or
equipment using battery.
• Use charger only on lead-acid type re-
chargeable batteries, such as those used in
cars, trucks, tractors, airplanes, vans, RV’s,
trolling motors, etc. This charger is not in-
tended to supply power to a low voltage
electrical system other than in an automotive
application.
•Use only attachments recommended or
sold by manufacturer. The use of attachments
not recommended by the manufacturer may
result in fire, electric shock, or injury.
•Never touch the battery clamps together when the
charger is energized.
•Never operate charger if it has received a hard blow,
been dropped, or otherwise damaged. Take it to a
qualified professional for inspection and repair.
•Be sure to position the charger power cord to
prevent it from being stepped on, tripped over, or
damaged.
•Never pull out the plug by the cord when unplug-
ging the charger. Pulling on the cord may cause
damage to the cord or the plug.
•Do not operate the charger if it has a damaged
power cord or plug. Have the cord replaced.
Important Safety Instructions
To reduce the risk of explosion, explosive gases, or injury while
using your battery charger, follow the precautions listed below:
•Do not disassemble charger. Take it to a
qualified service professional if service or
repair is required. Incorrect assembly may
result in fire or electrical shock.
• To reduce risk of electrical shock, unplug
the charger from the outlet before attempting
any maintenance or cleaning.
•Always charge battery in a well ventilated
area.
L
!WARNING
•Remove all personal metal items from your body,
such as rings, bracelets, necklaces, and watches
while working with a lead-acid battery. A battery can
produce a short circuit current high enough to weld
a ring (or the like) to metal, causing a severe burn.
•Take care not to drop any metal tool or metal object
onto the battery. This may spark or short circuit the
battery or another electrical device that may cause
an explosion.
•Always operate your battery charger in an open, well
ventilated area.
•Never smoke or allow a spark or flame in the vicinity
of the battery or engine. Batteries generate explosive
gases.
•Neutralize any acid spills thoroughly with baking
soda before attempting to clean up.

3
Sears 210 - Sch 50911/13/95
Parts
This section shows an illustration of your battery charger. Use it to become familiar with where all the parts are
located, and what they look like.
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Replacement Parts List Sears 71210
Description Part Number
Cover 3799001402
Heatsink/Diode Assembly 2299000825
Base 3799001382
AC Power Cord 90026058
Transformer 93026336
Output Cable 3899000016
Circuit Breaker (20A) 3999000045
50A Clamp (1) 2299000248
Sleeving Red (2) required 0399000007
Sleeving Black (2) required 0399000008
Meter 5399100091
Switch SPDT 0499000032
Front Panel 3799001392
Decal 0899000531
Handle 3599000240
Screw 8-18 x 3/8" (4) 5181806256
Owner's Manual and Parts List (Not Shown) 0000000509
Wiring diagram

4
Sears 210 - Sch 50911/13/95
A TEMPORARY adapter may be used to connect the
charger to a two-pole outlet if a properly grounded
outlet is not available. Use the adapter ONLY until a
properly grounded outlet can be installed by a qualified
electrician.
DANGER: Before using an adapter as illustrated, be
certain that the center screw of the outlet plate is
grounded. The green colored grounding clip of the
adapter must be attached by a screw to a properly
grounded outlet. If unsure whether outlet is properly
grounded, contact a professional electrician. If neces-
sary, replace the original outlet cover screw with a
longer one that will secure the grounding clip to the
outlet cover and make a ground connection to the
grounded outlet.
Using an extension cord
The use of an extension cord is not recommended. If
you must use an extension cord, please make sure
that you follow these guidelines:
•Make sure the pins on the plug of the extension cord
are the same number, size, and shape as those of the
plug on the charger.
•Use only 3-conductor (grounded) extension cord
when necessary.
•Check that the extension cord is properly wired and
in good electrical condition.
•Make sure that the wire size is large enough for its
length and for the AC ampere rating as specified in
the accompanying chart.
Before Using Your Battery Charger
It is important to understand your charger's requirements. This section will tell you about your charger's electrical
requirements and how to prepare a battery for charging.
Plugging it in
Electrical Shock Hazard
Be sure that power cord fits properly into outlet.
If not, have a qualified technician install a proper
outlet. Never alter the AC cord or plug provided.
Improper connection can result in electrical shock.
Your charger should be grounded to reduce the risk
of electrical shock.
Your charger is equipped with an electrical cord that
has an equipment grounding conductor and a ground-
ing plug designed to be used on a 120 volt circuit. The
plug must be plugged into an outlet that has been
properly installed and grounded in accordance with all
local codes and ordinances.
L!WARNING
MINIMUM RECOMMENDED EXTENSION CORD
Length of Cord, in Feet 25 50 100 150
AWG* Size of Cord 18 18 16 14
*AWG=American Wire Gauge
