SeaView MODTOPPTM1 User manual

INSTALLATION
INSTRUCTIONS
For Seaview Modular Pole Top:
MODTOPPTM1
WWW.SEAVIEWGLOBAL.COM
Refer to website for most up to
date instructions and videos.

3/8” = 9.52mm 7/16” = 11.11mm
7/16” = 11.11mm
PARTS INCLUDED
¼ - 20 x 1”
x2x2 x2 x1 x1
x1x1x1
TOOLS NEEDED
x2 x2
1
Sudbury Elastomeric
Marine Sealant is
recommended. To
purchase call 800-655-7922
or visit
www.seaviewglobal.com
Before beginning please make sure
that the Seaview Top Plate will face
forward.

If you are not using a light
bar then insert the plastic
plug into the back of the
modular top. Make sure that
the plug snaps in place from
the light bar pin.
If you are using a light bar,
do not use the black light
bar pin.
1
2
Apply marine adhesive
sealant to the inside of the
modular top where the pole
will slide into. Be sure to get
around the bolt holes.
2
TIP:
Dry t the modular pole top
over the pole. Some will feel a
bit loose (approx 1/16”of space).
This occasionally happens with
the combination of tolerances
between the pole and the pole
top. You can use a clear silicone
and spread a thin layer around
the inside of the pole top and
let it dry. This should help ll in
the gap and tighten better.

Slide the modular top
assembly onto the top of the
pole making sure that the
bolt holes line up.
3
3
Secure the modular top by
threading the two ⁄-20
x 1” bolts into the plastic
shoulder washers into the
nut.
Inside pole top.
Outside pole top.
4
Place the rubber gasket into
the groove on the top of
the modular top and then
place the Seaview Top Plate
ontop.
Make sure that the eight
bolt holes line up with the
eight bolt holes on the
modular top.
5

Insert the rubber cable
grommet into the top of the
Seaview Top Plate.
6
Secure the Seaview Top
Plate to the modular
top using the eight bolts
included in your Seaview
Top Plate kit.
7
4
Apply marine adhesive
sealant around the base of
the modular top.
8

5
