Sebo Airbelt E User manual

OWNER’S MANUAL
For Household Use Only

Technical Details 2
How To Contact SEBO 2
Important Safety Instructions 3
AIRBELT E Product Features 4
AIRBELT E1 Kombi & E2 Turbo Features 5
AIRBELT E3 Premium Features 5
Optional Attachments, Accessories, Bags and Filters 6
Standard Features of All SEBO Vacuums 7
Identification of Parts 8
Standard Attachments 8
Brushes and Heads 8
Assembly 8
Operating Instructions 9
Starting the Machine 9
Suction Control 9
Brush Roller Switch - E3 Premium 10
Adjusting the Telescopic Tube 10
Using the Telescopic Tube, Hose & Attachments 10
Bag Full or Clog Indicator & Automatic Shut-off 10
Retracting the Cord 11
Storing the Vacuum 11
Use and Maintenance of Brushes and Heads 11
Parquet Brush 11
Premium Parquet Brush 11
TT-C Turbo Head 11
Kombi Nozzle 11
Premium Kombi Nozzle 11
Vacuum Maintenance 12
Changing the Filter Bag 12
Changing the Pre-motor Filter 12
Changing the Exhaust Microfilter 12
Changing the AIRBELT Textile 13
Clog Removal 14
Clogs in the Head or Brush 14
Clogs in the Telescopic Tube 14
Clogs in the Hose 14
Clogs in Entrance to Filter Bag 14
Trouble-shooting Guide 15
AIRBELT E1 Kombi & E2 Turbo Schematic and Part Numbers 16
AIRBELT E3 Premium Schematic and Part Numbers 17
2
Vacuum motor 1200 watts
Filter bag capacity .92 gallons
Body weight 11.4 lbs
Technical details may be subject to change.
TABLE OF CONTENTS
TECHNICAL DETAILS
To contact SEBO in the United States of America:
SEBO America, LLC
Telephone: [phone]
Fax: [phone]
Website: www.sebo.us
To contact SEBO in Canada:
SEBO Canada
Telephone: [phone]
Fax: [phone]
Website: www.sebocanada.ca
HOW TO CONTACT SEBO
For Warranty coverage information please refer to your Warranty Card included with your SEBO vacuum cleaner.
Motor protection Thermal cut-out
Cord length 25 feet
Range 37 feet

IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE
3
1. Do not leave vacuum while plugged in. Unplug from
outlet when not in use and before servicing.
2. Do not use outdoors or on wet surfaces.
3. Do not use near small children or pets. Do not allow to be
used as a toy. Use of this product by children should
always be supervised by an adult.
4. Use only as described in this manual. Use only
manufacturer-recommended attachments.
5. Do not use with a damaged cord or plug. If vacuum is not
working as it should, has been dropped, damaged, left
outdoors, or dropped into water, take it to a SEBO service
center.
6. Do not pull or carry by cord, use cord as a handle, close a
door on cord, or pull cord around sharp edges or corners.
Do not run vacuum over cord. Keep cord away from heated
surfaces.
7. Do not unplug by pulling on cord. To unplug, grasp the
plug – not the cord.
8. Do not use outlets above counters to plug in vacuum –
damage to items in the surrounding area could occur.
9. Always carry the vacuum over steps and sills.
10. Do not handle plug or vacuum handle with wet hands.
11. Do not put any object into vacuum openings. Do not use
machine with any openings blocked. Keep openings free
of lint, hair, and anything that may reduce air flow.
12. Do not re-use filter bags or wash the filters.
13. Do not remove any screws from vacuum.
14. Do not vacuum up anything that is burning or smoking,
such as cigarettes, matches, or hot ashes.
15. Do not use vacuum without filter bag and/or filters in place.
16. Turn off all machine controls before unplugging.
17. Use extra care when cleaning on stairs.
18. Do not use machine to vacuum up flammable or
combustible liquids such as gasoline or use in areas
where they may be present.
19. Machines can cause a fire when operated near flammable
vapors or materials. Do not operate this vacuum near
flammable fluids, dust or vapors.
20. Maintenance and repairs must be done by authorized
personnel.
21. Use only original SEBO replacement parts.
22. Do not use vacuum as a step.
23. If vacuum is used on plush carpet or carpet with thick
padding, do not leave machine standing in one place with
machine turned on.
24. While the vacuum is in use, the power cord should be
unwound from the cable reel at least two thirds of its length.
Hold plug when rewinding onto the cord reel. Do not allow
plug to whip while rewinding.
25. Keep hair, loose clothing, fingers, and all parts of body away
from vacuum openings and moving parts. Do not place
fingers or other body parts under vacuum unless it is
unplugged.
26. Do not place the power head over rug or carpet edges.
27. The vacuum has a manual reset thermal protector. The
protector is reset by switching off the vacuum. The thermal
protector needs some time to cool down after switching off!
Check the vacuum for air blockages or mechanical failures
before switching on.
28. Store the vacuum in a dry place at room temperature. When
the vacuum is not in use, you should rewind the cord onto
the cord reel
29. The E3 hose contains electrical wires. Do not use if
damaged, cut, or punctured. Avoid picking up sharp objects.
30. Always unplug vacuum before connecting or disconnecting
either hose or power head.
31. Use a SEBO power head only in combination with a SEBO
vacuum cleaner.
32. Do not connect power head to a malfunctioning or damaged
vacuum.
When using an electrical appliance, basic precautions must always be followed.
To reduce the risk of electric shock, this vacuum cleaner has a polarized plug; one blade is wider than
the other. This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any
way. Connect only to the outlet type specified on the serial number plate underneath the machine.
SAVE THESE INSTRUCTIONS.
WARNING: To reduce the risk of fire, electric shock, or injury:
!

SEBO AIRBELT E PRODUCT FEATURES
4
Bag Full or Clog Indicator & Auto Shut Off –
The warning indicator will show orange
when it senses a full bag, a clog in the air-
flow pathway, or an excessively dirty micro
filter. If the user ignores this warning, the
suction motor will shut off to protect itself
from damage, usually within 6-10 minutes.
The user should turn the switch off, unplug the machine and
immediately insert a new bag or remove the clog (to remove a
clog, refer to the Clog Removal section on page 13) and restart the
machine. If the airflow is still restricted, the indicator will again
show orange and the above sequence will be repeated.
Shock Absorber Provides Furniture and
Wall Protection – The patented “AIRBELT”
bumper that surrounds the E canisters
acts as a protective barrier. The soft foam
bumper with its durable textile cover pro-
tects furniture, walls and the vacuum
itself from damage during use. The
bumper also diffuses exhaust air, which contributes to its
ultra-quiet performance.
Quick-release Connections – The AIRBELT E models allow for
quick and convenient connection of telescopic tubes, power
brush heads, accessory cleaning heads and on-board tools.
Comfortable Ergonomic Handle – The AIRBELT handles are
ergonomically designed and positioned to reduce wrist and
arm fatigue. For extra comfort, an additional swivel is built into
the handle-to-hose connection.
Mid-sized Canister Vacuum – The AIR-
BELT E models are considered mid-size
canister vacuums, which means they are
smaller, more compact machines that
offer three full-size on-board tools and a
large filter bag with a capacity of .92 gal-
lons. The large capacity filter bag is eco-
nomical because fewer bag changes are
needed. An indicator window turns orange
when the filter bag needs to be replaced,
and closing its built-in hygiene cap pre-
vents dust from escaping during bag
removal and disposal.
Three Protective, Rubber-coated Wheels,
mounted on steel axles – The superb rub-
ber-coated castor-wheels glide easily and
gently over all floor types, providing
exceptional maneuverability and protec-
tion of floor surfaces.
Dusting Brush
Crevice Nozzle
Upholstery Nozzle
Flat-to-the-floor 3-1/2” Profile – A low cleaning-head profile
makes reaching under furniture and beds easy!
Long, 25-foot cord and 37-foot Operating Range - The large
cleaning radius saves time because it can clean large areas
without changing electrical outlets. Plus, the 7-foot suction
hose provides superb user maneuverability.
Push-button Cord Rewinder – The super-long power cord
rewinds by simply pressing a button.
Large-capacity Filter Bags – The .92-gallon filter bag is con-
venient and economical because fewer bag changes are need-
ed, and closing its built-in hygiene cap prevents dust from
escaping during bag removal and disposal.
Convenient Parking and Storage Aids – After the work is done,
the suction hose with telescopic tube and Parquet Brush,
Turbo Brush or Kombi Nozzle can be firmly stored on the can-
ister’s underside or backside housing.
Three Full-size On-board Tools – The vacuum comes standard
with a crevice nozzle, dusting brush and upholstery nozzle. The
dusting brush is mounted on the telescopic tube, and the
crevice and upholstery nozzles are on the canister. Many
optional accessories are also available.

5
The SEBO AIRBELT E1 Kombi and E2 Turbo are straight-suc-
tion vacuums. As a result, they differ from the AIRBELT E3
Premium in the following two ways:
Suction-control Knob on Canister Body –
Because the E1 and E2 models have hoses
and telescopic tubes without power cords,
their suction-control knobs are located on
their canister bodies, not the handles.
TT-C Turbo Head Parquet Brush
Designed for All Floor Surfaces.
AIRBELT E3 Premium:
The AIRBELT E3 has an electrified hose
and telescopic tube designed to accom-
modate the ET-1 power head. The ET-1
power head is designed to provide thor-
ough brushing for optimal cleaning of
carpets.
Both Carpet and Hard Floor Cleaning –
With a power brush to clean carpets and
a parquet brush to clean hard floors, the
AIRBELT E3 provides all the flexibility
needed to care for a variety of floor sur-
faces. The parquet brush comes stan-
dard.
High-quality Telescopic Tube and Hose –
On the E3, the power cord is built inside
the telescopic tube and suction hose.
This eliminates unsightly external wires
and enables unobstructed and conven-
ient handle height adjustment.
Suction-adjustment Slider – The vacu-
um’s suction power can be adjusted from
0 to 1,200 watts by a slider switch conve-
niently located on the handle.
Brush Roller Switch on Handle - To
switch from brushing action to straight
suction for delicate floors, press the brush
roller power switch on the handle. This will
power off the brush roller on the power
head. All indicator lights on the power
head will turn off until the brush roller but-
ton is switched on again.
AIRBELT E3 PREMIUM
Kombi Nozzle
AIRBELT E1 Kombi and E2 Turbo
Powerful Vacuum Motors Provide
Excellent Cleaning – The canister suction
motor is 1,200 watts, and the power head
motor is 175 watts (ET-1), for a total of
1,375 watts.
The SEBO ET-1 (12” wide, 10 1⁄2” cleaning width) – This power
head delivers cleaning flexibility because its brush action
aggressively cleans carpeting, but the brush roller may be
switched off on the handle, so delicate rugs and hard floors
can be cleaned with straight suction. Its amazing 180° steer-
ing ability provides maneuverability around furniture, and the
extension side of the L-shaped head makes cleaning edges
and under counters easy.
Brush Obstruction Light & Auto Shut Off –
If an obstruction becomes jammed in the
brush roller, a red brush-warning light
will quickly flash, the brush roller will
immediately stop spinning and the vacu-
um will shut off. The user should turn the
power switch off, unplug the machine, and
immediately remove the obstruction. If the user restarts the
machine without removing the obstruction, the power head will
again shut off and the red light will flash. This prevents the belt
from breaking and protects the motor and carpet from dam-
age.
Incorrect Height Setting or Brush
Deterioration Light – To ensure optimum
cleaning at all times, a red brush-warning
light will illuminate, to indicate when the
brush height is set too high for effective
cleaning or when the brush roller should
be replaced due to excessive wear.
Can Not Use a Power Brush – The AIRBELT E1 Kombi and the
AIRBELT E2 Turbo do not have an electrified telescopic tube
and hose; therefore, they do not accommodate an electrified
power brush. Instead, the AIRBELT E1 Kombi comes standard
with the Kombi Nozzle, and the AIRBELT E2 Turbo comes stan-
dard with the TT-C Turbo Head for carpet and a Parquet Brush
for hard floors. Both models clean hard floors and rugs.
Parquet Brush

OPTIONAL ATTACHMENTS, ACCESSORIES, BAGS & FILTERS
6
NOTE: The optional Premium Parquet Brush and Premium Kombi Nozzle have brush strips that are removable for cleaning and replacement. To change the
brush strip, remove the yellow cap with a screw driver and pull out the brush strip. After inserting the new brush strip, the cap has to click into place again.
SEBO AeraPure™ filter bags can be purchased in boxes of eight
and filters are sold separately. SEBO bags, filters and accessories
are reasonably priced and widely available. To create a fresh scent
while vacuuming, SEBO FRESH is available. To use, deposit a
scented stick in the filter bag.
In addition to the standard on-board tools, a variety of optional
attachments are available. The 9’ 2” extension hose (extends suc-
tion hoses) and the 22” extension wand are very popular because
they create useful tools for cleaning stairs and out-of-reach areas.
Another popular attachment is the Hand-held Turbo Brush for
removing pet hair from upholstery.

STANDARD FEATURES OF ALL SEBO VACUUMS
7
Designed and Manufactured in Germany – Legendary quality,
reliability and performance make SEBO vacuums the first
choice of cleaning professionals throughout the world.
World’s Best Pet Vacuums – Because of superior power-head
and brush-roller technology, SEBO vacuums are the world’s
best for pet hair removal!
Tightly Sealed Vacuums Ensure Effective Filtration – Dirty air,
which flows through a vacuum, can only be filtered completely
if it does not escape into the room through seams or seals in
the machine. This is why all SEBO vacuums have tight seals
throughout.
Many vacuum companies with high-filtration claims are actual-
ly quoting specifications made by the manufacturer of the filter
material, as measured in the laboratory, not the filtration effec-
tiveness of the vacuum itself while operating. Whether or not
dirty air can escape through leaks in the body of the machine is
not considered. The filtration effectiveness of SEBO vacuums is
tested while they operate.
Reliable, Commercial-grade Components – All SEBO vacuums
are constructed with thick, reinforced, ABS plastic, aluminum
and metal parts, steel axles and bearings, and high-end, quali-
ty motors. Therefore, SEBO users own reliable, long-lasting
vacuum cleaners. Competing vacuums are made with thin,
flimsy, inexpensive, plastic materials, none of which are rein-
forced, and typically have useful lifespans of one or two years.
Rubber Wheels and Soft Bumpers Protect Homes – Smooth-
gliding, rubber wheels protect hard floors and provide excep-
tional maneuverability. In addition, the bumpers that surround
the power heads and the soft AIRBELT bumpers that surround
SEBO’s canisters protect furniture, walls, and vacuum housings
from incurring scuffs and scratches during use.
Advanced, Brush-roller Technology – SEBO’s brush rollers are
uniquely designed to funnel hair and debris into the power
head’s airflow channel, which improves vacuum cleaning per-
formance on all flooring surfaces.
Changing Bags is Easy and Clean – SEBO filter bags can be
changed in just a few seconds, and a hygiene cap keeps dust
sealed inside during removal and disposal.
Save Money! SEBO Vacuums Last for Years and Extend Carpet
Life! – If properly maintained, SEBO vacuums save ordinary,
residential users hundreds of dollars, by providing excellent
performance for ten to fifteen years or more, and their deep-
cleaning, power-brush technology extends the life of carpets.
Typical vacuums perform poorly, even when new, and usually
do not last beyond two years. So six or seven “disposable vacu-
ums” must be purchased during the average life expectancy of
just one SEBO machine.
Incredible Warranty Coverage – All SEBO models include a
FREE seven-year warranty on the motor and five-years on non-
wear parts and labor charges.
SEBO’s FILTRATION SYSTEM:
Bagged vs. Bagless . . . Bags are Better! –
Top-fill, three-layer AeraPure™ Bags are
an integral part of SEBO’s filtration system
because they hold virtually all the dirt cap-
tured by the vacuum, which improves the
effectiveness and useful life of the microfil-
ters. They also ensure continuously strong
suction because dirt enters from the top,
deposits at the bottom, accumulates
upward, and air exits through the sides,
which allows unimpeded airflow as they fill
to capacity. And they can be tightly sealed
with a hygiene cap when full, so no dust can escape into the air
during bag removal and disposal.
In contrast, without bags to hold nearly all the captured dirt, the
microfilters on bagless vacuums quickly clog from excessive dirt
build-up and must be replaced often, or a loss of suction and
cleaning effectiveness will occur. In addition, dust and other
allergens become airborne when emptying bagless dirt contain-
ers. Lastly, bagless vacuum microfilters are expensive, usually
costing more than a multi-year supply of SEBO filter bags.
S-class, Pre-motor and/or Exhaust
Microfilters – S-class, Pre-motor and Ex-
haust Microfilters (S =“Schwebstoff” = air-
borne particles) are made from electrosta-
tically charged, micro-fiber material, which
attracts and captures dust particles from
the airflow of the vacuum before and after it passes over the
motor to cool it. Cooling the motor with super-clean air
increases motor life and reduces the possibility of mainte-
nance, even after many years of use. Also, the exhaust air is
cleaned to the highest level before being emitted from the
machine. The S-class Standard requires filters to absorb
greater than 99.9% of particles down to 0.3 microns in diame-
ter. For comparison, 100 microns is the diameter of a human
hair. Their advantages are a relatively open texture that allows
smoother airflow for better suction performance, a longer life
expectancy, and they cost less than HEPA filters.
HEPA, Pre-motor and/or Exhaust Microfilters (Optional) –
HEPA Microfilters (“High Efficiency Particulate Air”) remove a
minimum of 99.97% of all airborne particulate matter down to
0.3 microns in diameter. Because these filters use small, grid-
like structures to capture dust particles, dirt build-up clogs the
airflow pathway sooner than what is expected from S-class
microfilters. However, SEBO’s HEPA microfilters are sold along
with three-layer AeraPure™ bags, which provide highly effec-
tive filtration before the airflow goes through the HEPA micro-
filter, greatly increasing life expectancy and reducing the
potential of diminished air flow.

8
Push the neck (11) of the hose (8) into the suction opening of the canister (16).
E3: The three notches in the suction opening (32) will line up with the three prongs on the
neck. When the notches are lined up correctly, the neck will snap firmly into place.
E1 & E2: The slot in the suction opening (31) will line up with the raised bar on the hose neck.
When lined up correctly, the neck will snap firmly into place.
To release the hose from the suction opening, press release buttons (14) on the neck of the hose (11),
and pull the neck out.
Connect the handle (1) to the top of the telescopic tube (5). Snap in place. To release the telescopic tube
(5) from the handle, push the handle release button (3) and slide the handle out.
Attach the head or brush to the bottom of the telescopic tube (5). Insert the bottom of the telescopic tube
into the neck (33) of the head or brush until it locks into place; or line up the square hole in the telescopic
tube with the notches in the front of the neck, and snap firmly into place. To release a head or brush from
the telescopic tube (5), push the release button (6), and pull the head or brush tool off the end of the tel-
escopic tube. The release button (6) is in the same position on all of the heads, brushes and power heads.
To attach the dusting brush clip (26) - E3: Locate the two raised ridges on the upper end of the tele-
scopic tube (5) just below the handle. Push the clip onto the tube directly below the ridges then slide the
clip up until it locks onto the ridges. E1 & E2: Push the clip onto the tube and slide to desired position.
Snap the dusting brush (27) into the holder.
NOTE: To attach the ET-1 Power Head to your E3 Premium, please refer to your power head owner’s
manual for instructions.
Brushes and Heads
28. Parquet Brush - standard for the E3 Premiums and
E2 Turbo, optional for the E1 Kombi - Part #6391DA
7. Kombi Nozzle - standard for the E1 Kombi, optional
for the E3 Premiums and E2 Turbo - Part #8351GS
29. TT-C Turbo Head - standard for the E2 Turbo,
optional for the E3 Premiums and E1 Kombi -
Part #8365GS
30. ET-1 Power Head - standard for E3 Premiums
Arctic White - Part #9260AM; Red - Part #9296AM;
Graphite - Part #9988AM; Black - Part #9961AM
23. Crevice nozzle
24. Upholstery nozzle
NOTE: All illustrations shown in this manual represent the E3 model except where part numbers and instructions are different for each model.
29
ASSEMBLY
1. Handle grip
2a. Suction-control slider (E3 Premium)
2b. Brush roller switch (E3 Premium)
3. Handle release button
4. Slide button
5. Telescopic tube
6. Tool release button
7. Kombi nozzle
8. Hose
9. Push-button cord rewinder
10. On/off power knob (E3 Premium)
On/off power and suction-control
knob (E1 & E2)
11. Hose neck
12. Filter bag cover
24
27
23
26
26. Dusting brush clip
27. Dusting brush
5
633
1
5
3
E1 & E2
Standard Attachments
28
IDENTIFICATION OF PARTS
8
13
19
1
3
5
18
14
15
11
17
25
10
21
12
9
22
24
23
9
10
11
7
2a
4
6
17
16
20
2b
13. Carrying handle
14. Hose neck release buttons
15. Warning indicator
16. Suction opening
17. Filter bag cover release catch
18. Parking attachment groove
19. Exhaust filter cover
20. Exhaust filter cover release buttons
21. Power cord
22. Parking attachment groove
23. Crevice nozzle
24. Upholstery nozzle
25. AIRBELT bumper & textile cover
E3
11 11
16 16
14
14
32
31
30
7

Starting The Machine
Your AIRBELT E canister is equipped with a soft start system and variable suction controls.
To help you better understand the various power control options on your SEBO canister,
please follow the instructions below.
E3 Premium Users - Figures 1, 2, 3 & 4
Before turning on your canister, make sure that the vacuum handle is in its upright locked position.
1. With the canister main power knob (10) in the OFF position, and the suction-control slider on the
handle (#2a, figure 4) in the OFF position, pull the power cord out from the base of the canister
(figure 1). The power cord should be unwound from the cable reel at least two thirds of its length.
Note: do not over-extend the cord.
2. Plug the polarized power cord into a 120 volt wall outlet located near the floor.
3. Press the main power knob (10) on the base of the canister gently with your foot or hand.
A blue light will illuminate indicating that the power is on.
4. Slide the suction-control slider (#2a, figure 4) toward the MAX position. It will move freely between
0 suction and MAX suction. Set the slider to the suction desired.
5. When the power head is on with the handle in the upright locked position, the brush roller will not
spin. To release the ET-1 power head from the upright locked position, press down on the foot
pedal, (#34, figure 3), lower the handle into the normal operating position and push the brush
roller switch on the handle (#2b, figure 4) to engage the brush roller. The green light on the power
head will illuminate. The handle can be lowered to a horizontal position useful for vacuuming
under beds.
Note: E3 users - see the ET-1 Owner’s Manual for power head instructions.
E1 Kombi and E2 Turbo Users - Figures 1 & 2
Before turning on your canister, make sure that the vacuum handle is in its upright locked position.
1. With the canister main power knob (10) in the OFF position, pull the power cord out from the base
of the canister (figure 1). The power cord should be unwound from the cable reel at least two-thirds
of its length. Note: do not over-extend the cord.
2. Plug the polarized power cord into a 120 volt wall outlet located near the floor.
3. Press the main power knob (10) on the base of the canister gently with your foot or hand.
Suction Control
E3 Premium Users - Figure 4
You may adjust the suction with the suction-control slider (2a) as you vacuum different sur-
faces or when using the accessory tools. For optimal cleaning and brushing, operate the
machine at the maximum suction power setting and push the power head slowly over the
carpet.
When the canister’s main power knob (10) is in the ON position, you may turn the suction and
the power head off and on with the suction-control slider (2a). To turn the power off using
the suction-control slider, pull the slider to 0 suction, then continue pulling the slider up
until it “clicks” into the OFF position. The green power head light will then shut off (the blue
light on the canister will remain illuminated until the vacuum is powered off using the main
power knob).
E1 Kombi and E2 Turbo Users - Figure 5
The on/off power and suction-control knob is located on the top side of the canis-
ter (10). Rotate the knob clockwise for maximum suction. Rotate counter-clockwise
to reduce suction for vacuuming curtains or delicate fabrics.
+
9
OPERATING INSTRUCTIONS
Figure 1
9
21
Figure 2
10
Figure 5 - E1 & E2
Figure 3 - E3
34
0
max.
Figure 4 - E3
2a
2b
0 = Zero Suction
MAX = Maximum Suction
ON position - Move the slider
toward MAX.
OFF position - Pull the slider
up to 0 suction then continue
pulling the slider up until it
“clicks” into the OFF position.
10
10

10
Figure 13
15
Brush Roller Switch - E3 Premium - Figure 6
To switch from brushing action to straight suction for delicate floors, press the brush roller power
switch (2b) on the handle. This will power off the brush roller on the power head. All indicator lights
on the power head will turn off until the brush roller button is switched on again.
Adjusting the Telescopic Tube - Figure 7
Adjust the telescopic tube (5) to the correct height by pushing the slide button (4) and gently pulling
the tube out to lengthen, or pushing it in to shorten. Release the slide button (4) to lock the tube to
the adjusted height.
Using the Telescopic Tube, Hose & Attachments -
Figures 8, 9, 10, 11 & 12
ALWAYS TURN OFF THE CANISTER AND UNPLUG BEFORE CONNECTING OR DISCONNECTING THE
HOSE (8), TELESCOPIC TUBE (5) OR POWER HEAD.
The telescopic tube (5) is useful for vacuuming corners and hard-to-reach areas. You may use the
telescopic tube without a brush, power head or attachment. To remove a brush or power head,
switch off the power knob (10) and unplug the vacuum. Then, press the tool release button (6) and
pull the tube out. The crevice nozzle (23) and dusting brush (27) may be inserted onto the end of the
tube. To use the upholstery nozzle (24), fit it onto the end of the crevice nozzle (23). It is not neces-
sary to turn off the vacuum while switching the standard attachments (the crevice nozzle, upholstery
nozzle or dusting brush). After use, switch off the power, unplug the vacuum and remove attach-
ment. Re-insert the telescopic tube into the power head or brush, turning the tube if needed, until
you hear it click into place.
To use the hose without the telescopic tube, switch off the power and unplug the vacuum. Push the
handle release button (3) and pull the HANDLE out of the end of the telescopic tube. Do not try to sep-
arate the hose from the handle! Insert the crevice nozzle (23) or dusting brush (27) onto the end of the
handle. To use the upholstery nozzle (24), fit it onto the end of the crevice nozzle (23). After use,
switch off the power, unplug the vacuum and remove the attachment. Re-insert the handle into the
telescopic tube making sure it is seated correctly and snap it into place.
Figure 8
Figure 10
6
5
23
1
5
23
24
Figure 7
5
4
0
max.
Figure 6 - E3
2a
2b
Bag Full or Clog Indicator & Auto Shut-Off - Figure 13
When the “BAG FULL OR CLOG” indicator, located on top of the canister (15), illuminates, airflow is
reduced due to a full bag, a clog in the airflow pathway, or an excessively dirty filter. Turn the power off,
unplug the machine and immediately insert a new bag (see page 12) or remove the clog (see page 14).
If the user ignores the warning indicator, the motor will shut off to protect itself from damage. The user
should turn the power off, unplug the machine and immediately insert a new bag or remove the clog. If
the airflow is still restricted, the “BAG FULL OR CLOG” indicator will illuminate again and the machine
will shut off.
Vacuuming fine dust may require an earlier filter bag change even though the filter bag is not full.
Fluff may overfill the bag without the light coming on.
The bag full indicator works more efficiently at full power. Check the bag full status regularly at full
suction power.
WARNING!The quality, condition, coating, texture, age and manufacturing technique of all floor surfaces vary.
Therefore, vacuums with rotating brushes, including your SEBO, may damage some floor coverings or surfaces. Some
types of high-gloss hardwood floors, cushion vinyl, berber carpets, long shag, and delicate or hand-woven carpets are particu-
larly vulnerable to damage by rotating brushes. When possible, consult the materials supplied by your flooring manufacturer
for information on proper upkeep and cleaning. To ensure that your new SEBO vacuum cleaner is compatible with your
floor, please test the vacuum cleaner on each type of flooring surface in a small inconspicuous area to determine if any
damage occurs. If damage occurs, stop using the vacuum cleaner immediately!
!
Figure 9
Figure 12- Push button to
release upholstery nozzle.
1
5
7
30
Figure 11

11
28
Retracting the Cord - Figure 14
To retract the cord, switch the vacuum off, unplug it from the outlet, then press the push-button cord
rewinder (9) and the mechanism will automatically rewind the cord. You must hold the button down until
the cord is fully rewound. Hold plug while rewinding into the cord wheel. Do not allow the plug to whip
while rewinding. The rewind mechanism will stop automatically when you release the button. Before
rewinding the cord, always switch off and unplug the vacuum.
ALWAYS TURN THE POWER OFF ON THE CANISTER BEFORE UNPLUGGING THE UNIT.
Storing the Vacuum- Figure 15
The vacuum can be stored with the canister in a horizontal or vertical
position. The Parquet Brushes, Kombi Nozzles and the TT-C Turbo
Head have a parking tab located on the neck (35). Insert the parking
tab into the upper side of the parking groove (18 or 22) and slide down
firmly. For vertical storage, or for easy carrying, use the parking
groove on the underside (18). For horizontal storage, use the parking
groove on the end of the canister (22).
Figure 15
35 13 22
18
Figure 14
9
21
USE AND MAINTENANCE OF BRUSHES AND HEADS
Parquet Brush - Figure 16
The Parquet Brush (28) was designed specifically for vacuuming hard floors. It is lightweight with
soft bristles, so it glides gently over floors and provides easy maneuverability. Fibers and hair can
be pulled out of the bristles manually, or vacuum the bristles with the telescopic tube.
Premium Parquet Brush - Figure 17
The Premium Parquet Brush (36) is specially designed for use on hard surfaces. The brush should
be cleaned regularly. Remove the parquet brush from the telescopic tube to clean. Fibers and hair
can be pulled out of the bristles manually, or vacuum the bristles with the telescopic tube. The
brush strips are removable for cleaning and replacement.
TT-C Turbo Head - Figure 18
The TT-C Turbo Head (29) has an air-driven rotating brush for gentle brushing of carpets. The Turbo
head can be adjusted for high and low pile carpet. To adjust the head for high pile carpet, push the
slider button (37) upward. For low pile carpet, push the slider button (37) downward. The rotating
brush should be cleaned regularly. Remove the Turbo head from the telescopic tube to clean. Remove
fibers and hair from the brush manually.
Kombi Nozzle and Premium Kombi Nozzle - Figure 19
The Kombi Nozzle (7) and the Premium Kombi Nozzle (38) are adjustable for carpet or hard floors.
Use the toggle button (39) on either nozzle to raise the brush for carpet or lower the brush for hard
floors. The brush should be cleaned regularly. Remove the nozzle from the telescopic tube to clean.
Fibers and hair can be pulled out of the bristles manually, or vacuum the bristles with the telescopic
tube.
Always unplug vacuum from outlet before dismantling any part of machine! To remove a brush or power
head, switch off the power and unplug the vacuum. Then, press the tool release button (6) and pull the tube out.
NOTE! E3 Premium users with the ET-1 power head, please refer to your power head user’s manual for more detailed
instructions for operating and maintaining your power head.
!
Figure 17
36
Figure 18
39
29
38
37
Figure 16
Figure 19
39
7
NOTE: The Premium Parquet Brush and the Premium Kombi Nozzle have brush
strips that are removable for cleaning and replacement. To change the brush strip,
remove the yellow cap with a screwdriver and pull out the brush strip. After inserting the
new brush strip, the cap has to click into place again.

VACUUM MAINTENANCE
Changing the Filter Bag - Figures 20, 21 & 22
To change the filter bag (40), lift the filter bag release catch (17, figure 20) then lift open
the filter bag cover (12). Seal the used filter bag with the sealing cap (41). Tilt the green
sealing plate collar up (42, figure 21) and lift the bag out. Slide the front of the sealing plate
(42) of a new bag vertically into the bag holder (43, figure 22). Line up the sealing plate so
that the U-shaped metal spring (44) is positioned in the slot (44) of the collar and tilt it back
into place. Close the cover, making sure it snaps shut completely. The cover will not close
if the bag is inserted improperly. Do not re-use the filter bags. Note: The nature of the con-
tents of the filter bag will affect the point at which it needs changing. Fine dust may require
an earlier change even though the bag is not full. Fluff or hair allows air to pass through
easily, so the filter bag may overfill before the “bag full” indicator turns orange.
The “bag full or clog” indicator works correctly only at full power. At lower power levels, the
“bag full or clog” indicator may read incorrectly. Check the status of the filter bag regular-
ly at full power.
Changing the Pre-motor Filter - Figure 23
The pre-motor filter (46) needs to be changed when it becomes extremely dirty or clogged
with dust, or after approximately 10 to 20 filter bags have been used. To change the pre-
motor filter, lift the filter bag release catch (17, figure 20), lift open the filter bag cover (12)
and remove the filter bag. Grasp the tab at the bottom of the filter (47, figure 23) and pull
the filter out and up. When the filter is horizontal, lift it out of the holder (48). Insert the
new filter into the holder horizontally (48) then swing it downward until the tab (47) locks
into place. Replace the filter bag and the filter bag cover.
Figure 22
Figure 26
Always unplug vacuum from outlet
before dismantling any part of machine!
!
Pre-motor Filter
part of the E Filter Set
Part #8322AM
Exhaust Microfilter
part of the E Filter Set
Part #8322AM
Changing the Exhaust Microfilter - Figures 24, 25 & 26
After 10 to 20 bags have been used, change the exhaust microfilter (49). To remove the
exhaust microfilter, press the filter cover release buttons together (20, figure 24) and pull
the filter cover (19) off. Pull the material part of the filter out of the machine (49, figure
25). Press the red latches (50, figure 26) located on either side of the filter inward and pull
the filter out. Insert the opening of the new filter over the exhaust opening with the red
alignment tab at the bottom. When it is aligned, push down until the red latches (50) click
shut to hold the filter in place. Tuck the material part of the filter inside the opening.
Insert the cover by fitting the tabs on the top side of the cover into the grooves. Push the
cover closed, making sure it snaps shut completely.
Note: Never operate the vacuum with incorrectly attached filters or without filters, bag, AIRBELT textile or filter bag hous-
ing cover (26). Do not re-use filter bags. Do not wash and re-use filters.
AeraPure™ Filter Bags
Part #8300AM
Figure 23
12 17
46
48
46
19
49
20
12
CLOSE
CLOSE
40
41
42
42
40
43
43
45 44
Figure 20
Figure 21
47
48
50
49
Figure 24 Figure 25
48
50

13
Changing the AIRBELT Textile - Figures 27-33
Your E-Series vacuum cleaner is fitted with the patented AIRBELT shock absorber sys-
tem, which protects your walls and furniture and filters exhaust air. The AIRBELT shock
absorber system consists of the foam bumper (52) and the AIRBELT textile cover (25). If
damage occurs to the AIRBELT textile, it will need to be replaced.
To remove the AIRBELT system (25 & 52), remove the upholstery tool from the rear of the
machine (figure 27), and lever out the tool holder (51) using a slot-head screwdriver (fig-
ure 28). The AIRBELT system (25 & 52) can then be pried out of the recess with a screw-
driver (figure 29) and removed by carefully sliding the assembly toward the front of the
machine (figure 30). Remove the damaged textile (25) from the foam bumper (52).
Fit the new AIRBELT textile (25) over the foam bumper (52) by inserting the side rails (53,
figure 31) of the textile (25) into the grooves (54) of the foam bumper. The upper side rail
of the textile has a mark (55, figure 31). Insert the upper side rail with the mark into the
groove which is marked “TOP” (56, figure 31) Start from one end and continue fitting the
textile into the grooves around the bumper (figure 32). Fit the bumper assembly to the
front of the machine, then press in around the sides toward the rear (figure 33).
Refit the upholstery tool holder (51) under the parking groove (22) and tilt it down to lock
it into the lower side. Finally, re-insert the upholstery tool.
Figure 27
Note: Never operate the vacuum with incorrectly attached filters or without filters, bag, AIRBELT textile or filter bag housing
cover (12). Do not re-use filter bags. Do not wash and re-use filters.
Figure 28
24
22
51
Figure 29
25
AIRBELT Textile
Part # 8221AM01 - Gray Black, solid
Part # 8221AM10 - Black/Silver, stripes,
52
Figure 30
25
52
53
25
54
55
56
Figure 31 Figure 32 Figure 33
52
25

CLOG REMOVAL
14
NOTE! E3 users with ET-1 power heads, please refer to your power head user’s
manual for more detailed instructions for removing clogs in your power head.
If the “bag full or clog” warning indicator (15) remains orange after the filter bag
has been changed and the filters are in good condition, there is likely a clog in the
system.
Clogs in the Head or Brush - Figure 34
Clogs in the swivel neck (56) of a head or brush can be cleared by first pressing the
tool release button (6) and removing the brush or head. Check inside the swivel neck
channel, and clean out pathway.
Clogs in the Telescopic Tube - Figure 34
Remove head from telescopic tube (5) by pushing the tool release button (6) and
pulling the tube out. Remove the hose from the top of the telescopic tube by pushing
the handle release button (3). A stiff wire or stick can be used to push the clog out of
the tube.
Clogs in the Hose - Figures 35, 36 & 37
Check for suction at the handle end of the hose. If you feel reduced suction, the block-
age is in the hose. To clear blockages in the hose (8), remove the handle (1) from the
telescopic tube by pressing the handle release button (3). Hold the hose upright with
one hand blocking the end of the handle (figure 36) and switch on the machine at full
power. If necessary, quickly lift your hand on and off the end of the hose.
Note: Do not insert a wire or stick into the hose. Doing so may cause damage to the
hose.
Clogs in Entrance to Filter Bag - Figures 38 & 39
Remove hose (10) from vacuum cleaner. To release the hose from the suction open-
ing, press release buttons (14) on the neck of the hose (11), and pull the neck out.
Check the hose neck (11) and suction opening (16) for clogs. If the clog is in the filter
bag opening, open the filter bag cover and clean out the entrance to the bag (57).
Always unplug vacuum from outlet before removing any clogs!
!
Figure 39
5
1
3
57
Figure 36
Figure 38
Figure 35
1
Figure 37
11
16
8
Figure 34
56
6
4
3
5

15
TROUBLE-SHOOTING GUIDE
PROBLEM
Does not turn on
Bag full or clog light on
Bag full or clog light on
& machine shuts off
Does not pick up
Filter bag door won’t
fully close
REASON
1. Telescopic tube not inserted properly.
2. Not plugged into working outlet.
3. Cord worn.
4. Hose neck (11) not inserted
properly into suction opening (16).
5. E3: The suction-control slider
switch is set to “0” (“off” position).
1. Bag full.
2. Clog in hose, telescopic tube,
brush or head, or entrance to
filter bag.
3. Exhaust microfilter dirty.
4. Pre-motor filter dirty.
1. Hose/handle assembly not
correctly inserted.
2. The suction-control dial is rotated
to no suction setting
3. Filter bag cover not closed.
1. Filter bag cover not fully closed.
2. Bag not inserted properly
3. Pre-motor filter not properly
inserted.
SOLUTION
1. See page 7.
2. Use another outlet.
3. Replace cord.
4. See Assembly on page 7.
5. E3: Set slider switch to “on”
position. See page 9.
1. Replace filter bag. See page 12.
2. See Clog Removal on page 14.
E3 users with clog in power head
attachment: Refer to clog removal
in the ET-1 owner’s manual.
3. Replace exhaust microfilter.
See page 12.
4. Replace filter. See page 12.
1. Re-insert hose/handle assembly
making sure that it is lined up
properly and is snapped into
place. See page 7.
2. E1 & E2: Rotate suction-control dial
clockwise for suction. See page 9.
3. See below.
1. Re-insert bag. Lock the cover
down firmly.
2. Re-insert bag. Lock the cover
down firmly.
3. Remove the filter bag and make
sure the pre-motor filter is seated
firmly in place (see pg. 12, figure 23).
Always unplug vacuum from outlet before dismantling any part of the machine!
!

AIRBELT E1 KOMBI AND E2 TURBO SCHEMATIC AND PARTS LIST
16
53
51
50
20
21
2
18
23
19
14
16
5
31
32
30
26
25
1
4
3
19
24
19
13
12
9
10 11
19
29
27
18
18
8
6
7
17
15
19
19
33
28
22
52
34
35
36
38
37
54
Canister with Handle/Hose
52
50 51
Kombi Nozzle
included with E1 Kombi
#8351GS
TT-C Turbo Head
included with E2 Turbo
#8365GS
Parquet Brush
included with E2 Turbo
#6391DA
#91602AM E1 Kombi, #91602FC E1 Kombi
Arctic White Machine
Pos. Part # Description
1 8335WEER Bottom casing, white
2 8275GSER Castor front, gray black
3 8276GSER Castor rear, gray black
4 8249WEER Cover exhaust air filter, white
5 8230ULER Middle casing incl. pos. 6+7
6 7045ER Cover latch spring
7 8053ER Bolt 20 x 5/7
8 8212ER Engine mount gasket
9 8243ER Vac motor 120 V
10 8282ULER Wire
11 8045ER Motor support
12 8220ER Noise limiting cover
13 8289ER Motor cover
14 665633ER Cord rewind unit, AM plug
15 8256ER Potentiometer pinion
16 8338ER On/Off button E1 & E2, cpl.
17 8292ER Printed circuit board
18 01036 Screw 4 x 14
19 01017 Screw STS 4 x 20 T20
20 8322AM Microfilter box E - pre-motor
filter and exhaust microfilter
21 8300AM AeraPure™ filter bags E
22 8328WEER Top casing, white
23 8340ER Top cover E1, inner part
24 8224WEER Filter cover
25 8237ER Bumper
26 8221AM01 AIRBELT Textile, gray black, solid,
AM models
8221AM10 AIRBELT Textile, black/silver,
stripes, FC models
27 8213GSER Support
28 8066GS Crevice nozzle
29 8210GS Upholstery nozzle
30 8310 Hose cpl. incl. handle
31 8314 Hose E1 and E2, without handle
32 6300GS Handle grip, cpl., without hose
33 6303GS Retaining ring
34 6237ER Telescopic tube (incl. 6668GS
dusting brush clip adapter)
35 1736GS Fitting neck
36 1735ER Release button, cpl.
37 6238ER Locking mechanism
38 6425ER Sliding knob
50 8351GS Kombi Nozzle, gray black
53 6694GS Dusting brush clip, gray black
54 1387GS Dusting brush
#91604FC E1 Kombi - Black Machine Exceptions
1 8335SWER Bottom casing, black
4 8249SWER Cover exhaust air filter, black
22 8328SWER Top casing, black
24 8224SWER Filter cover, black
#91620AM E2 Turbo, #91620FC E2 Turbo
Dark Blue Machine Exceptions
1 8335DBER Bottom casing, dark blue
4 8249DBER Cover exhaust air filter, dark blue
22 8328DBER Top casing, dark blue
24 8224DBER Filter cover, dark blue
51 8365GS TT-C Turbo Head
52 6391DA Parquet Brush
#91621FC E2 Turbo - Red Machine Exceptions
1 8335DRER Bottom casing, red
4 8249DRER Cover exhaust air filter, red
22 8328DRER Top casing, red
24 8224DRER Filter cover, red
51 8365GS TT-C Turbo Head
52 6391DA Parquet Brush
#91602AM AIRBELT E1 Kombi - Arctic White (USA)
#91602FC AIRBELT E1 Kombi - Arctic White (Canada)
#91604FC AIRBELT E1 Kombi - Black (Canada)
#91620AM AIRBELT E2 Turbo - Dark Blue (USA)
#91620FC AIRBELT E2 Turbo - Dark Blue (Canada)
#91621FC AIRBELT E2 Turbo - Red (Canada)

17
AIRBELT E3 PREMIUM SCHEMATIC AND PARTS LIST
Canister with Handle/Hose
ET-1 Power Head
included with E3 Premium
Refer to ET-1 Manual for parts
identification
#91646AM, #91646FC E3 Premium
Arctic White Machine
Pos. Part # Description
1 8335WEER Bottom casing, white
2 8275GSER Castor front, gray black
3 8276GSER Castor rear, gray black
4 8249WEER Cover exhaust air filter, white
5 8230ULER Middle casing incl. pos. 6+7
6 7045ER Cover latch spring
7 8053ER Bolt 20 x 5/7
8 8212ER Engine mount gasket
9 8243ER Vac motor 120 V
10 8282ULER Wire
11 8045ER Motor support
12 8220ER Noise limiting cover
13 8289ER Motor cover
14 665633ER Cord rewinder
16 8339ER On/Off button E3, cpl.
17 8296ER Printed circuit board
18 01036 Screw 4 x 14
19 01017 Screw STS 4 x 20-T20
20 8322AM Filter box E - pre-motor filter
and exhaust microfilter
21 8300AM AeraPure™ filter bags E
22 8328WEER Top casing, white
23 8341ER Top cover E3, inner part
24 8224WEER Filter cover, white
25 8237ER Bumper
26 8221AM01 AIRBELT Textile, gray black, solid
27 8213GSER Support
28 8066GS Crevice nozzle
29 8210GS Upholstery nozzle
31 6391DA Parquet Brush
33 8547AM 7’ hose & handle for E3,
complete assembly only
37 60237UC Telescopic tube (incl. 60238AD
dusting brush clip adapter)
39 8320ER Cabling set
41 6694GS Dusting brush clip
42 1387GS Dusting brush
#91647AM, #91647FC E3 Premium
Red Machine Exceptions
1 8335DRER Bottom casing, red
4 8249DRER Cover exhaust air filter, red
22 8328DRER Top casing, red
24 8224DRER Filter cover, red
#91648AM, #91648FC E3 Premium
Graphite Machine Exceptions
1 8335GSER Bottom casing, gray black
4 8249GSER Cover exhaust air filter,
gray black
22 8328GSER Top casing, gray black
24 8224GSER Filter cover, graphite
26 8221AM10 AIRBELT Textile, black/silver,
stripes
#91650AM E3 Premium
Black Machine Exceptions
1 8335SWER Bottom casing, black
4 8249SWER Cover exhaust air filter, black
22 8328SWER Top casing, black
24 8224SWER Filter cover, black
26 8221AM10 AIRBELT Textile, black/silver,
stripes
CLOSE
42
20
21
2
18
23
19
14
16
5
26
25
1
4
3
19
24
22
19
13
12
9
10 11
19
29
27
39
18
18
19
8
6
7
17
28
19
19
33
31
41
37
#91646AM AIRBELT E3 Premium - Arctic White (USA)
#91646FC AIRBELT E3 Premium - Arctic White (Canada)
#91647AM AIRBELT E3 Premium - Red (USA)
#91647FC AIRBELT E3 Premium - Red (Canada)
#91648AM AIRBELT E3 Premium - Graphite (USA)
#91648FC AIRBELT E3 Premium - Graphite (Canada)
#91650AM AIRBELT E3 Premium - Black (USA)
31
Parquet Brush
included with E3 Premium
#6391DA

18
NOTES
