OWNER’S MANUAL
Portable Refrigerated Air Conditioner
CP18CW1
(ENGLISH) (CP18CW1)

CP18CW1
i |
Waste electrical products must not be disposed of with household waste.
This product should be taken to your local recycling centre for safe treatment.
CONTENTS
INTRODUCTION 1
SAFETY 2
COMPONENT LOCATION 3
INSTALLATION 4
CONTROL AND DISPLAY 5
REMOTE CONTROL 6
OPERATION 7
MAINTENANCE 9
TROUBLESHOOTING 10
SPECIFICATION 11
WIRING DIAGRAM 11
WARRANTY 12

OWNER’S MANUAL
|1
THANK YOU for choosing a Convair air
conditioner. This appliance has been
carefully engineered to bring you trouble-
free personal air conditioning. Please
read this manual carefully so that you can
take full advantage of the many benets
your Convair provides.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have supervision or been
given instruction in using the appliance by
a person responsible for their safety.
Children should be supervised to ensure
that they do not play with the appliance.
Do not place anything through the
ventilating slots.
Be sure the appliance has been securely
and correctly installed according to the
installation instructions contained within
this manual.
Personal Cooling
Your Convair refrigerated air conditioner
is a portable unit that supplies cool air to
a personal area within a room. It is not
intended to function as a house or room
air conditioner.
Energy Saving Tips
• Do not locate the air conditioner where
furniture or other objects can obstruct
the air ow.
• Keep curtains and blinds closed during
the hottest part of the day.
• Keep the lters clean.
• Set the air conditioner to maximum
cooling and high fan speed initially, then
adjust to a comfortable setting.
• Do not wait until the room is excessively
hot before using the air conditioner.
Servicing
For service issues relating to this product,
please call:
1300 526 410
Warranty
Convair air conditioners are warranted
against faulty manufacture for 2 years
after purchase. Refer to the warranty
terms near the back of the manual.
INTRODUCTION

CP18CW1
2 |
General Safety
This air conditioner is for indoor use only.
Transport the air conditioner in an upright
position only, or leave it in an upright
position for at least 2 hours before use.
Use only in the upright position on a at
level surface and at least 50 cm from any
objects.
Do not place objects on the air
conditioner, or through the ventilating
slots or restrict the air inlets & outlets.
Closely supervise any children and pets
when the air conditioner is in use.
Do not store or operate the appliance
near any ammable substances.
During operation, water will collect in the
bottom tank of the air conditioner. Be
careful when moving the unit to prevent
water from spilling.
Electrical Safety
Ensure the appliance has been installed
in accordance with national wiring
regulations.
Electrical Safety (cont.)
Caution! Before connecting the electrical
power cord to a power outlet, check that
the air conditioner voltage as shown on
the rating label on the air conditioner is
the same as your power supply. Ensure
the power supply is correctly earthed and
rated.
Plug the air conditioner directly into a
properly installed power outlet. Never
use an extension cord, double adaptor
or multi-power outlet board to run this air
conditioner.
Do not pull the air conditioner along by
the power cord or place the power cord
near a source of heat. Always unroll the
power cord completely before use.
If the power supply cord is damaged it
must be replaced by the manufacturer,
a service agent or similarly qualied
persons in order to avoid a hazard.
Switch off and unplug when not in use.
Do not use in humid environments such
as bathrooms, laundries or other steamy
or wet areas.
Do not touch or operate the air
conditioner with wet or damp hands or
when standing barefoot.
SAFETY
1
2

OWNER’S MANUAL
|3
COMPONENT LOCATION
3
4
Control panel
Air deection louvres Handles
Air outlet
Upper air intake
and air lter
Lower air intake
Exhaust outlet
Castors
POWER
TEMP -
TIMER
MODE
TEMP+
SPEED
Remote Exhaust hose Hose end connectors Window kit

CP18CW1
4 |
Air conditioner location
Place the air conditioner on a rm, at
surface. The minimum distance between
the air conditioner and any walls or
objects is 50 cm.
Installing the Exhaust Hose
Step 1: Fit both Hose end connectors to
the Exhaust hose.
INSTALLATION
Note! Do not use extension pieces for
the Exhaust hose as this will reduce
performance and possibly result in
damage to the air conditioner.
Step 2: Fit the Exhaust hose to the
Exhaust outlet at the rear of the air
conditioner.
Step 3: Open a window and t the
Window kit. Extend the attachments as
required and lock them in place with the
screw provided. The Window kit can be
installed horizontally or vertically, to suit
your window type.
Important! Ensure the outlet is not
obstructed.
5
6
7
Step 4: Fit the Exhaust hose to the
Window kit.
Note! Keep the Exhaust hose as short
and straight as possible to maximise the
cooling potential.
Important! Hot moist air will be emitted
outside through the Exhaust hose. It is
critical to the performance of the unit that
all of the exhaust air is removed from the
space being cooled.
Air deector
The Air deection louvres can be set to
a desired position manually. Keep the
vanes fully open during operation.

OWNER’S MANUAL
|5
ON/OFF
MODE
SPEED
TIMER
WATER FULL
AUTO
c
°
POWER
TEMP -
TIMER
MODE
TEMP+
SPEED
CONTROL AND DISPLAY
Control Panel
1. ON/OFF button
2. UP button
3. DOWN button
4. MODE select button
5. Fan SPEED button
6. TIMER button
7. COOL mode indicator
8. AUTO mode indicator
9. FAN speed indicator
10. DRY mode indicator
11. Thermostat display
12. Water full indicator
13. TIMER indicator
Remote Control
1. ON/OFF button
2. TIMER button
3. MODE select button
4. FAN speed button
5. UP & DOWN buttons
8
11
9
12
10
13
41
52
63
7
8
3
2
1
5
4
9

CP18CW1
6 |
REMOTE CONTROL
Preparation Before Operation
Remove the battery cover and insert new
batteries (2x AAA), making sure the +and
-match the compartment markings.
During Operation
If the remote control will not operate the
air conditioner, the batteries may need to
be replaced.
Remove the batteries and replace with
new ones. If this does not solve the
problem contact your nearest service
centre for advice.
Note! The air conditioner must be
plugged in and switched on for the remote
control to operate the air conditioner. To
use, point at the front panel and press
the remote button. The air conditioner will
“beep” when signal has been received.
If there is no beep, press the remote
button again, ensuring it is within range (6
metres) of the air conditioner.
Note! If there are two of the same air
conditioners installed, they cannot be
controlled separately. When you use a
remote, it will operate all air conditioners
within signal range
Care of your Remote Control
Don’t let the remote control drop onto
hard surfaces or be subjected to sudden
shocks of any form. The warranty does
not cover misuse or accidental damage.
Don’t place the remote control in direct
sunlight, or near extremes of temperature.
Don’t allow the remote control to get wet.
Don’t place near strong electromagnetic
waves.
Don’t mix old and new batteries!
If the remote control will not be used for a
long time, remove the batteries to avoid
corrosion.
10

OWNER’S MANUAL
|7
Starting the air conditioner
Step 1: Plug into the mains power outlet
and switch on.
Step 2: Press the ON/OFF button on the
control panel or remote control.
Mode selection
Step 3: Press the MODE button on the
control panel or the remote control to
select the operating mode.
Cool mode - refrigerated cooling
Dry mode - Dehumidication, for
extracting moisture from the air.
Auto mode - automatically selects the
operating mode based on ambient
conditions.
Cool mode
Step 4: In Cool mode press the UP and
DOWN buttons to set the thermostat
room temperature in 1°C increments.
The thermostat can be set between 16°C
- 31°C. Cooling will only occur if the set
temperature is less than the ambient
room temperature.
Note! Do not set the cooling temperature
too low as this will consume more
power. 24°C is the recommended set
temperature.
Note! In Cool mode the fan will continue
to operate even if the compressor has
turned off.
Step 5: Press the SPEED button to
adjust the fan speeds between low,
medium and high.
Auto mode
In Auto mode, the air conditioner will
automatically select the operating mode
based on the ambient temperature at the
instance when Auto mode is selected.
The operating mode is selected based on
the following conditions.
Ambient Temperature Mode
T < 23°C Fan
23°C ≤ T < 26°C Dry
T ≥ 26°C Cool
Note! The air conditioner will not change
between operating modes. All mode
changes must be made by the user.
Important! During Cool and Dry modes,
water will collect in the air conditioner’s
tank. This water is re-circulated, with
some being exhausted out with the hot
air, but will slowly ll up the tank. This
occurs more quickly in humid conditions.
If the tank should ll, the air conditioner
will shut down and display the water full
error code (see Troubleshooting). The
air conditioner cannot be restarted until
the water tank is drained. Refer to the
Maintenance section for draining the tank
should this occur.
OPERATION

CP18CW1
8 |
OPERATION CONT.
Timer Function
The air conditioner features a timer that
allows the automatic start-up or shut-
down of the air conditioner.
Timed start-up can be set when the air
conditioner is in stand by mode.
Note! The air conditioner will startup at
the setting last used.
Timed shutdown can be set when the air
conditioner is on.
Step 1: Press the TIMER button. The
timer setting will ash on the control
panel.
Step 2: Press the UP and DOWN buttons
to change the timer setting in 1 hour
increments. Timer range is 1 - 24 hours.
Step 3: Press the TIMER button again
to conrm the timer setting. The TIMER
symbol will become lit.
To cancel the timer, press the TIMER
button until the timer indicator on the
control panel has turned off.
