Rostock Max v3 RTP User Guide
Give a short summary.
Written By: JJ Johnson
Rostock Max v3 RTP User Guide
© 2017 seemecnc.dozuki.com Page 1 of 11

INTRODUCTION
Congrats on your new Factory Assembled Rostock Max v3! This guide will help you in getting started
with your new machine.
Your machine was fully assembled, calibrated and printed successfully before it left our factory.
Please make sure there are no damages to your new Rostock Max v3. Inspect it carefully for any
broken parts. If you find any damages please STOP and contact the company that you purchased it
from immediately. Please include your order number when contacting them as it helps to speed up
the process.
Your machine was fully assembled, calibrated and printed successfully before it left our factory. We
have done some things to make sure the machine does not get damaged while shipping the printer.
Please complete the following steps:
Rostock Max v3 RTP User Guide
© 2017 seemecnc.dozuki.com Page 2 of 11

Step 1 — READ ME FIRST!
Please thoroughly read the Introduction - Read Me First
Want to download this guide as a PDF? Click on the PDF link just above the image and save as
PDF.

Rostock Max v3 RTP User Guide
© 2017 seemecnc.dozuki.com Page 3 of 11

Step 2 — Remove the Shrink Wrap
Remove the printer from the
shipping container if you have not
done so already. You can do this by
lifting the printer straight up out of
the container. The best place the
grab the machine is by the vertical
rails (silver aluminum rails).

Carefully remove all shrink wrap
from the frame of the printer. Be
careful not to cut the machine (or
yourself) if you are using a knife.

Don't worry about removing the
shrink wrap from the bed. We will
get to that in future steps.

Step 3 — Inverting the Arms
The arms have been inverted to prevent the hot end nozzle from striking the glass print surface
during shipping. To invert the arms from shipping position to printing position

Place your hand on ONE of the carriages and slowly move this carriage upward toward the top
of the printer.

Next select one of the two remaining carriages and repeat.
Do the same operation with the final carriage.
Rostock Max v3 RTP User Guide
© 2017 seemecnc.dozuki.com Page 4 of 11

Step 4 — Remove the Glass Build Plate
Rotate the [BLUE] bed clamps to
remove the glass build plate and
accessories from the printer.

Remove the glass plate from the
printer.

Step 5 — Remove Accessories from Glass Plate
Carefully remove all shrink wrap from the glass build plate. Be careful not to cut the accessories
(or yourself) if you are using a knife.

Replace the glass build plate back on the printer.
Rotate the [BLUE] bed clamps to clamp the glass build plate down.
Rostock Max v3 RTP User Guide
© 2017 seemecnc.dozuki.com Page 5 of 11

Step 6 — Identify the Accessories
Attached to the glass plate was a
bag of accessroies. They are shown
here. Each printer comes with a
power cable, USB cable, glue stick
(for prepping glass plate) and SD
card.

Step 7 — Assemble the Spool Holder
Assemble the spool holder as shown in the attached images.
Rostock Max v3 RTP User Guide
© 2017 seemecnc.dozuki.com Page 6 of 11

Step 8 — Installing the Spool Holder
Position the spool holder on the top plate of the machine in the four rectangular cutouts.
Slide the spool holder assembly towards the outer edge of the printer, locking it in place.
Step 9 — Install the Power Cable
The power supply in the printer is
shipped in the 110 (115) position.

Install the power cable on the right
side of the machine.

Rostock Max v3 RTP User Guide
© 2017 seemecnc.dozuki.com Page 7 of 11

Step 10 — USB Connection (Advanced)
The Rostock Max v3 is equipped with a USB connection and cable. This is intended to be used as
a connection for updating firmware and manually control the machine when diagnosing issues is
required.

Printing via the provided SD card is considered to be a significantly more stable than printing via
the USB connection. We highly encourage the use of printing via the SD card.

Rostock Max v3 RTP User Guide
© 2017 seemecnc.dozuki.com Page 8 of 11

Step 11 — Loading Filament
The spool of filament should be installed on the printer so the filament is coming off of the top side
and down to the extruder as shown.

The extruder on a 3D printer, is the device that feeds the filament to the hot end. On the RMAX
v3, the extruder is called the EZR Struder. It is the component on the side of the top assembly
that has a clear cover, black base and red release lever.

Press the red release trigger and push filament down through the filament path on the side of the
EZR Struder until you see it in the clear PTFE tube (connected to the EZR Struder)

This clear tube is often referred to as a BOWDEN TUBE. The material of the tube is PTFE

Either rotate the blue knob on the EZR Struder or press the red release lever and feed filament to
the hot end until you see the filament just above the top (as shown in picture 3)

Rostock Max v3 RTP User Guide
© 2017 seemecnc.dozuki.com Page 9 of 11

Step 12 — Software and Setup
To operate your Rostock Max v3
software is required to prepare
printing files. We recommend and
support using MatterControl.

Download and install MatterControl
per your operating system

Windows
MAC
Step 13 — Configure and Setup MatterControl
MatterControl Setup and Calibration
Rostock Max v3 RTP User Guide
© 2017 seemecnc.dozuki.com Page 10 of 11

This document was last generated on 2017-06-16 02:52:32 PM.
Step 14 — Using MatterControl / First Print
Your next step is to download and
check out the MatterControl User
Manual It will guide you through
setting up MatterControl and running
your first print!

You can also check out: Setup and
User Guides to find other helpful
resources such as changing
filament, exporting GCODE to the
SD card, and more. It would be a
good idea to bookmark that page.

