Senco FramePro 651 User manual

SM
MEMBER
Questions? Comments? call SENCO’s toll-free Action-line:
1-800-543-4596 (North & South America only)
or e-mail: [e-mail]
Senco Products, Inc.
8485 Broadwell Rd.
Cincinnati, Ohio 45244
Visit our Website: www.senco.com
* Schematic drawings inside
NFG02G Revised November 6, 2006 (Replaces 3/13/06) © 2002, 2006 by SENCO Products, Inc. Cincinnati, Ohio 45244 - U.S.A.
FramePro
®
651
Framing Nailer
FramePro
®
651
Repair Kit
YK0360

!DANGER
3/8"
Body
1/4"
Body
Tru-Flate 3/8" NPT
Tru-Flate 3/8" NPT
Ind. Interchange 3/8" NPT
Ind. Interchange 3/8" NPT
PC0480
PC0485 4
PC0469
PC0475 4
1/4"
Body
4Recommended Plugs
3/8"
Body
Plugs shown smaller than actual size
Available Plugs
(Not Included with Tool)
KB9911
GC0902
BB0148
FramePro
®
651
HC0432
KB9837
GC1015
GC1016
GC1020
Contact Actuation
Single Sequential
Actuation
Trigger Type Part Number
A
A
Contact Actuation
Single Sequential
Contact Actuation
Single Sequential
2G0003N
2G0004N
2G2101N
2G2102N
Model Tool
KB9904
NFG02G Revised November 6, 2006 (Replaces 3/13/06) © 2002, 2006 by SENCO Products, Inc. Cincinnati, Ohio 45244 - U.S.A.
AA0143
BA0159
*O-Rings available- order YK0360
EA0164
GA0468 (Euro)
HA0170
FA0242
HA0171
A
BA0161
GA0463
KB9912
GA0464 (US)
FramePro
®
651
BC0483
LB1017*
LB1016*
LB1015*
LB1018*
KB3255
KB9752
BC0482
KB4393
LB1020*
LB1021*
BC0485*
BC0481*
BC0486
BC0484
MC5113
AA0140 LB0018*
LB0057*
LB1014*
LB1011*
LB1010*
LB0057*
CA0108
LB0057*
KB9905
KB9910
AC0302
KC0873
LB1019
HG0063 (US)
KB4394
KB9909
HC0428
KB9909
KB9837
KB9908
HC0429
KB9776
HA0167
HA0168
GC1018
HG0068 (Euro)
HC0427
AA0142
HC0430

!DANGER
3/8"
Body
1/4"
Body
Tru-Flate 3/8" NPT
Tru-Flate 3/8" NPT
Ind. Interchange 3/8" NPT
Ind. Interchange 3/8" NPT
PC0480
PC0485 4
PC0469
PC0475 4
1/4"
Body
4Recommended Plugs
3/8"
Body
Plugs shown smaller than actual size
Available Plugs
(Not Included with Tool)
KB9911
GC0902
BB0148
FramePro
®
651
HC0432
KB9837
GC1015
GC1016
GC1020
Contact Actuation
Single Sequential
Actuation
Trigger Type Part Number
A
A
Contact Actuation
Single Sequential
Contact Actuation
Single Sequential
2G0003N
2G0004N
2G2101N
2G2102N
Model Tool
KB9904
NFG02G Revised November 6, 2006 (Replaces 3/13/06) © 2002, 2006 by SENCO Products, Inc. Cincinnati, Ohio 45244 - U.S.A.
AA0143
BA0159
*O-Rings available- order YK0360
EA0164
GA0468 (Euro)
HA0170
FA0242
HA0171
A
BA0161
GA0463
KB9912
GA0464 (US)
FramePro
®
651
BC0483
LB1017*
LB1016*
LB1015*
LB1018*
KB3255
KB9752
BC0482
KB4393
LB1020*
LB1021*
BC0485*
BC0481*
BC0486
BC0484
MC5113
AA0140 LB0018*
LB0057*
LB1014*
LB1011*
LB1010*
LB0057*
CA0108
LB0057*
KB9905
KB9910
AC0302
KC0873
LB1019
HG0063 (US)
KB4394
KB9909
HC0428
KB9909
KB9837
KB9908
HC0429
KB9776
HA0167
HA0168
GC1018
HG0068 (Euro)
HC0427
AA0142
HC0430

FramePro
®
651 Framing Nailer
REPLACEMENT PARTS LIST • LISTA DE PARTES DE REPUESTO • ERSATSTEILE-LISTE • LISTE DE PIÈCES DE RECHANGE
Questions? Comments? call SENCO’s toll-free Action-line: 1-800-543-4596 (North & South America only) or e-mail: [e-mail]
PART NO. DESCRIPTION DESCRIPCIÓN BESCHREIBUNG DÉSIGNATION
AA0140....................DEFLECTOR ASSEMBLY.................... ASAMBLE DE DESVIADOR........................ABWEISER-ZUSAMMENBAU.................................... ENSEMBLE DÉFLECTEUR
AA0142....................END CAP ASSEMBLY......................... ASAMBLE DE TAPA TERMINAL.................ABSCHLUßKAPPE-ZUSAMMENBAU......................... BOUCHON D’EXTRÉMITE DE RAIL
AA0143....................CAP ASSEMBLY.................................ASAMBLE DE TAPA ...................................KAPPE-ZUSAMMENBAU .......................................... ENSEMBLE BOUCHON
AC0302....................SEAL.................................................. SELLO .......................................................DICHTUNG................................................................ JOINT
BA0159....................FIRING VALVE ASSEMBLY.................ASAMBLE DE VÁLVULA ............................VENTIL-ZUSAMMENBAU.......................................... ENSEMBLE VALVE
BA0161....................CYLINDER ASSEMBLY ......................ASAMBLE DE CILINDRO ...........................ZYLINDER-ZUSAMMENBAU..................................... ENSEMBLE CYLINDRE
BB0148....................STOP, PISTON ................................... TOPE .........................................................PUFFER .................................................................... ARRÊT
BC0481....................WASHER............................................ ARANDELA................................................SCHEIBE................................................................... RONDELLE
BC0482....................SEAL.................................................. SELLO .......................................................DICHTUNG................................................................ JOINT
BC0483 ....................RETAINER, SLEEVE ........................... RETÉN.......................................................SICHERUNGSRING................................................... RETENUE
BC0484....................SEAL.................................................. SELLO .......................................................DICHTUNG................................................................ JOINT
BC0485....................WASHER............................................ ARANDELA................................................SCHEIBE................................................................... RONDELLE
BC0486....................RETAINER..........................................RETÉN.......................................................SICHERUNGSRING................................................... RETENUE
CA0108....................CORE ASSEMBLY.............................. ASAMBLE DE VÁSTAGO............................VENTILSTIFT-ZUSAMMENBAU................................. ENSEMBLE NOYAU
EA0164 ....................PISTON ASSEMBLY...........................ASAMBLE DE PISTON...............................KOLBEN-ZUSAMMENBAU........................................ ENSEMBLE PISTON–COUTEAU
FA0242.....................GUIDE BODY ASSEMBLY ..................ASAMBLE DE PLACA DE NARIZ................NAGELFÜHRUNG-ZUSAMMENBAU.......................... ENSEMBLE FRONT
GA0463....................FEEDER SHOE ASSEMBLY ................ASAMBLE DE ALIMENTADOR ...................NAGELSCHIEBER-ZUSAMMENBAU.......................... ENSEMBLE POUSSOIR
GA0464....................MAGAZINE (US) ................................ CARGADOR...............................................MAGAZIN.................................................................. MAGASIN
GA0468....................MAGAZINE (EURO)............................ CARGADOR...............................................MAGAZIN.................................................................. MAGASIN
GC0902....................RETAINER, PIN.................................. RETÉN.......................................................SICHERUNGSRING................................................... RETENUE
GC1015....................SPRING, FEEDER............................... RESORTE...................................................FEDER ...................................................................... RESSORT
GC1016....................ROLLER, FEEDER SPRING ................ RODILLO ...................................................ROLLE ...................................................................... GALET
GC1018....................STOP .................................................TOPE .........................................................PUFFER .................................................................... ARRÊT
GC1020....................FEEDER SHOE ................................... ALIMENTADOR..........................................NAGELSCHIEBER ..................................................... POUSSOIR
HA0167....................TRIGGER ASSY, DUAL ACTION. ........ ASAMBLE DE GATILLO..............................AUSLÖSER-ZUSAMMENBAU ................................... ENSEMBLE GÂCHETTE
HA0168....................TRIGGER ASSY, RESTRICTIVE.......... ASAMBLE DE GATILLO..............................AUSLÖSER-ZUSAMMENBAU ................................... ENSEMBLE GÂCHETTE
HA0170....................NO-MAR PAD ASSEMBLY..................ASAMBLE DE AMORTIGUADOR................SCHUTZ-ZUSAMMENBAU........................................ ENSEMBLE COUSSIN
HA0171....................SAFETY ELEMENT ASSEMBLY ..........ASAMBLE DE SEGURO..............................SICHERHEITSVORRICHTUNG-ZUSAMMENBAU ...... ENSEMBLE PALPEUR DE SÉCURITÉ
HC0427....................SPRING .............................................RESORTE...................................................FEDER ...................................................................... RESSORT
HC0428....................BUSHING...........................................CASQUILLO...............................................HÜLSE...................................................................... DOUILLE
HC0429....................NO-MAR PAD .................................... AMORTIGUADOR ......................................SCHUTZ.................................................................... COUSSIN
HC0430................... .SAFETY ELEMENT............................. SEGURO.................................................... SICHERHEITSVORRICHTUNG ................................. PALPEUR DE SÉCURITÉ
HC0432....................COVER, SAFETY ................................ CUBIERTA..................................................ABDECKUNG ............................................................ COUVERCLE
HG0063....................LABEL (US) ....................................... ETIQUETA..................................................AUFKLEBER.............................................................. ÉTIQUETTE
HG0068....................LABEL (EURO)................................... ETIQUETA..................................................AUFKLEBER.............................................................. ÉTIQUETTE
KB3255....................SCREW..............................................TORNILLO.................................................SCHRAUBE............................................................... VIS
KB4393....................SPRING, FIRING VALVE..................... RESORTE...................................................FEDER ...................................................................... RESSORT
KB4394....................SPRING, SAFETY...............................RESORTE...................................................FEDER ...................................................................... RESSORT
KB9752....................WASHER............................................ ARANDELA................................................SCHEIBE................................................................... RONDELLE
KB9776....................SCREW..............................................TORNILLO.................................................SCHRAUBE............................................................... VIS
KB9837....................NUT ..................................................TUERCA.....................................................MUTTER ................................................................... ÉCROU
KB9904....................SCREW..............................................TORNILLO.................................................SCHRAUBE............................................................... VIS
KB9905....................SCREW..............................................TORNILLO.................................................SCHRAUBE............................................................... VIS
KB9908....................SCREW..............................................TORNILLO.................................................SCHRAUBE............................................................... VIS
KB9909....................WASHER............................................ ARANDELA................................................SCHEIBE................................................................... RONDELLE
KB9910....................WASHER............................................ ARANDELA................................................SCHEIBE................................................................... RONDELLE
KB9911....................WASHER............................................ ARANDELA................................................SCHEIBE................................................................... RONDELLE
KB9912....................PIN ....................................................PASADOR..................................................STIFT........................................................................ GOUPILLE
KC0873....................PIN, TRIGGER PIVOT ........................PASADOR..................................................STIFT........................................................................ GOUPILLE
LB0018 ....................SEAL.................................................. SELLO .......................................................DICHTUNG................................................................ JOINT
LB0057 ....................SEAL.................................................. SELLO .......................................................DICHTUNG................................................................ JOINT
LB1010 ....................SEAL.................................................. SELLO .......................................................DICHTUNG................................................................ JOINT
LB1011 ....................SEAL.................................................. SELLO .......................................................DICHTUNG................................................................ JOINT
LB1014 ....................SEAL.................................................. SELLO .......................................................DICHTUNG................................................................ JOINT
LB1015 ....................SEAL.................................................. SELLO .......................................................DICHTUNG................................................................ JOINT
LB1016 ....................SEAL.................................................. SELLO .......................................................DICHTUNG................................................................ JOINT
LB1017 ....................SEAL.................................................. SELLO .......................................................DICHTUNG................................................................ JOINT
LB1018 ....................SEAL.................................................. SELLO .......................................................DICHTUNG................................................................ JOINT
LB1019 ....................SEAL.................................................. SELLO .......................................................DICHTUNG................................................................ JOINT
LB1020 ....................SEAL.................................................. SELLO .......................................................DICHTUNG................................................................ JOINT
LB1021 ....................SEAL.................................................. SELLO .......................................................DICHTUNG................................................................ JOINT
MC5113 ...................GRIP.................................................. AGARRADERO...........................................GRIFF........................................................................ GAINE EN CUIR
YK0360....................SEAL KIT ........................................... ASAMBLE DE SELLO.................................DICHTUNG-ZUSAMMENBAU.................................... ENSEMBLE JOINT
