NFG01Z Revised September 12, 2006 (Replaces 5/22/06) © 2002, 2006 by SENCO Products, Inc. Cincinnati, Ohio 45244 - U.S.A.
FinishPro
®
41 XP
SM
Questions? Comments? call SENCO’s toll-free Action-line:
1-800-543-4596 (North and South America Only)
or e-mail: [email protected]
Senco Products Inc.
8485 Broadwell Road
Cincinnati, Ohio 45244
Visit Our Website: www.senco.com
15 ga. Finish Nailer
* Schematic drawings inside
Repair Kits
YK0362
YK0361

KB0045
BB0199
BC0361*
LB0900
LB0132
AC0230
LB0018
BF0092
CA0103*
BA0146
KC0055
HF0021
KC0062
HC0183
KB4197
HF0022
HF0015
KB4198
HC0170
HF0079
FCO218
KB3519
KB3225
FC0220
FA0228
FC0067
KB0045
FC0219
HC0333
KB0045
KB0029
KB2964
KB3518
KB1500 GA0361
GF0041
GC0539
GC0545
GB0510 (US)
GB0511 (Euro)
KB0029
KB2964
GA0358
1/4" FPT
KB3320
KC0062
AC0228
KB0020
BF0224
AC0238
BF0237
AC0226
BF0238
LB0897
LB0034
EA0138
GA0414 (US)
GA0415 (Euro)
HF0017
AB0145
KB3518
KB3409
KB3391
AF0064
LB0897
LB0034
KB4190
1Z0001N Sequential Actuation
1Z2001N Sequential Actuation
1Z2002N Contact Actuation
Model
* Does Not Include O-rings
* No incluye sellos de gomas
* Ohne Dichtringe
* Joints exclus
Available Triggers
Sequential
Actuation
Contact
Actuation
HA0137
HA0136
FinishPro
®
41XP FinishPro
®
41XP
3/8"
Body
1/4"
Body
Tru-Flate 1/4" NPT
Tru-Flate 1/4" NPT
Ind. Interchange 1/4" NPT
Ind. Interchange 1/4" NPT
PC0479 4
PC0486
PC0468 4
PC0474
1/4"
Body
4 Recommended Plugs
3/8"
Body
Plugs shown smaller than actual size
Available Plugs
(Not Included with Tool)
NFG01Z Revised September 12, 2006 (Replaces 5/22/06) © 2002, 2006 by SENCO Products, Inc. Cincinnati, Ohio 45244 - U.S.A.
BC0370

KB0045
BB0199
BC0361*
LB0900
LB0132
AC0230
LB0018
BF0092
CA0103*
BA0146
KC0055
HF0021
KC0062
HC0183
KB4197
HF0022
HF0015
KB4198
HC0170
HF0079
FCO218
KB3519
KB3225
FC0220
FA0228
FC0067
KB0045
FC0219
HC0333
KB0045
KB0029
KB2964
KB3518
KB1500 GA0361
GF0041
GC0539
GC0545
GB0510 (US)
GB0511 (Euro)
KB0029
KB2964
GA0358
1/4" FPT
KB3320
KC0062
AC0228
KB0020
BF0224
AC0238
BF0237
AC0226
BF0238
LB0897
LB0034
EA0138
GA0414 (US)
GA0415 (Euro)
HF0017
AB0145
KB3518
KB3409
KB3391
AF0064
LB0897
LB0034
KB4190
1Z0001N Sequential Actuation
1Z2001N Sequential Actuation
1Z2002N Contact Actuation
Model
* Does Not Include O-rings
* No incluye sellos de gomas
* Ohne Dichtringe
* Joints exclus
Available Triggers
Sequential
Actuation
Contact
Actuation
HA0137
HA0136
FinishPro
®
41XP FinishPro
®
41XP
3/8"
Body
1/4"
Body
Tru-Flate 1/4" NPT
Tru-Flate 1/4" NPT
Ind. Interchange 1/4" NPT
Ind. Interchange 1/4" NPT
PC0479 4
PC0486
PC0468 4
PC0474
1/4"
Body
4 Recommended Plugs
3/8"
Body
Plugs shown smaller than actual size
Available Plugs
(Not Included with Tool)
NFG01Z Revised September 12, 2006 (Replaces 5/22/06) © 2002, 2006 by SENCO Products, Inc. Cincinnati, Ohio 45244 - U.S.A.
BC0370

FinishPro
®
41XP 15 ga. Finish Nailer
REPLACEMENT PARTS LIST • LISTA DE PARTES DE REPUESTO • ERSATSTEILE-LISTE • LISTE DE PIÈCES DE RECHANGE
Questions? Comments? call SENCO’s toll-free Action-line: 1-800-543-4596 (North & South America Only) or e-mail: [email protected]
PART NO. DESCRIPTION DESCRIPCIÓN BESCHREIBUNG DÉSIGNATION
AB0145................... MAIN BODY ASSEMBLY..................... ASAMBLE DE CARCASA.................................GEHÄUSE-ZUSAMMENBAU ............................... CORPS D'ASSEMBLÉE
AC0226 ................... SEAL .................................................. SELLO ............................................................ DICHTUNG ......................................................... JOINT
AC0228 ................... END CAP ............................................TAPA............................................................... KAPPE................................................................ BOUCHON
AC0230 ................... SEAL .................................................. SELLO ............................................................ DICHTUNG ......................................................... JOINT
AC0238 ................... PLATE ................................................ PLACA............................................................PLATTE............................................................... PLAQUE
AF0064.................... DEFLECTOR ....................................... DEFLECTOR.................................................... ABWEISER ......................................................... DÉFLECTEUR
BA0146................... VALVE ASSEMBLY..............................ASAMBLE DE VALVULA..................................VENTIL-ZUSAMMENBAU ................................... VALVE D'ASSEMBLÉE
BB0199 ................... STOP.................................................. TOPE .............................................................. PUFFER .............................................................. ARRÊT
BC0361 ................... CYLINDER.......................................... CILINDRO....................................................... ZYLINDER .......................................................... CYLINDRE
BC0370 ................... MUFFLER ...........................................SILENCIADOR ................................................ DÄMPFER........................................................... SILENCIEUX
BF0092.................... SEAL .................................................. SELLO ............................................................ DICHTUNG ......................................................... JOINT
BF0224.................... CAP....................................................TAPA............................................................... KAPPE................................................................ BOUCHON
BF0237.................... SEAL .................................................. SELLO ............................................................ DICHTUNG ......................................................... JOINT
BF0238.................... RETAINER .......................................... JUNTA TÓRICA............................................... SICHERUNGSRING............................................. RETENUE
CA0103................... VALVE ASSEMBLY..............................ASAMBLE DE VALVULA..................................VENTIL-ZUSAMMENBAU ................................... VALVE D'ASSEMBLÉE
EA0138 ................... PISTON ASSEMBLY ...........................ASAMBLE DE PISTON....................................KOLBEN-ZUSAMMENBAU.................................. PISTON D'ASSEMBLÉE
FA0228.................... LATCH ASSY....................................... ASAMBLE DE UÑETA......................................VERSCHLUSS-ZUSAMMENBAU......................... DOIGT DE RETENUE D'ASSEMBLÉE
FC0067.................... FINGER GRIP.....................................AGARRADERO................................................ FINGERGRIFF ..................................................... GAINE EN CAOUTCHOUC
FC0218.................... GUIDE BODY......................................PLACA DE NARIZ ...........................................NAGELFÜHRUNG ...............................................FRONT
FC0219.................... PLATE ................................................ PLACA............................................................PLATTE............................................................... PLAQUE
FC0220.................... DOOR................................................. PUERTA..........................................................ABDECKSCHIEBER............................................. PORTE
GA0358................... FEEDER SPRING ASSY....................... ENSEMBLAJE DEL ALIMENTADOR ................ ROLLFEDER ....................................................... RESSORT DE POUSSOIR
GA0361................... FEEDER SHOE ASSY. .........................ASAMBLE DE ALIMENTADOR ........................NAGELSCHIEBER-ZUSAMMENBAU ................... POUSSOIR D'ASSEMBLÉE
GA0414................... SHROUD (US)....................................PROTECTOR................................................... ABDECKUNG ...................................................... CACHE
GA0415................... SHROUD (EURO) ............................... PROTECTOR................................................... ABDECKUNG ...................................................... CACHE
GB0510................... RAIL (US)........................................... CARRIL...........................................................SCHIENE............................................................. RAIL
GB0511................... RAIL (EURO)......................................CARRIL...........................................................SCHIENE............................................................. RAIL
GC0539................... RAIL...................................................CARRIL...........................................................SCHIENE............................................................. RAIL
GC0545................... RETAINER ..........................................JUNTA TÓRICA............................................... SICHERUNGSRING............................................. RETENUE
GF0041 ................... RAIL................................................... CARRIL...........................................................SCHIENE............................................................. RAIL
HA0136................... TRIGGER ASSEMBLY (DUAL) ............ ASAMBLE DE GATILLO...................................AUSLÖSER-ZUSAMMENBAU............................. GACHETTE D'ASSEMBLÉE
HA0137................... TRIGGER ASSEMBLY (REST)............. ASAMBLE DE GATILLO...................................AUSLÖSER-ZUSAMMENBAU............................. GACHETTE D'ASSEMBLÉE
HC0170................... SAFETY ELEMENT (LOWER)..............SEGURO DE INFERIOR...................................UNTERSICHERHEITSVORRICHTUNG................. SÉCURITÉ EN DESSOUS
HC0183................... SAFETY ELEMENT (UPPER)............... SEGURO DE SUPERIOR .................................OBERSICHERHEITSVORRICHTUNG................... SÉCURITÉ EN DESSUS
HC0333................... ADAPTOR...........................................ADAPTADOR................................................... ADAPTER ........................................................... ADAPTATEUR
HF0015 ................... SPACER ............................................. SEPARADOR .................................................. DISTANZSTÜCK.................................................. ENTRETOISE
HF0021 ................... COVER ............................................... CUBIERTA.......................................................ABDECKUNG ...................................................... COUVERCLE
HF0022 ................... RETAINER .......................................... JUNTA TÓRICA...............................................SICHERUNGSRING............................................. RETENUE
HF0079 ................... CUSHION ........................................... AMORTIGUADOR ...........................................SCHUTZ.............................................................. COUSSIN
KB0020 ................... SCREW .............................................. TORNILLO...................................................... SCHRAUBE......................................................... VIS
KB0029 ................... SCREW .............................................. TORNILLO...................................................... SCHRAUBE......................................................... VIS
KB0045 ................... SCREW .............................................. TORNILLO...................................................... SCHRAUBE......................................................... VIS
KB1500 ................... NUT.................................................... TUERCA.......................................................... MUTTER............................................................. ÉCROU
KB2964 ................... WASHER............................................ARANDELA..................................................... SCHEIBE............................................................. RONDELLE
KB3225 ................... PIN..................................................... PASADOR.......................................................STIFT.................................................................. GOUPILLE
KB3320 ................... PIN..................................................... PASADOR.......................................................STIFT.................................................................. GOUPILLE
KB3391 ................... WASHER............................................ARANDELA..................................................... SCHEIBE............................................................. RONDELLE
KB3409 ................... SCREW .............................................. TORNILLO...................................................... SCHRAUBE......................................................... VIS
KB3518 ................... WASHER............................................ARANDELA..................................................... SCHEIBE............................................................. RONDELLE
KB3519 ................... PIN..................................................... PASADOR.......................................................STIFT.................................................................. GOUPILLE
KB4190 ................... SPRING.............................................. MUELLE ......................................................... FEDER ................................................................ RESSORT
KB4197 ................... SPRING.............................................. MUELLE ......................................................... FEDER ................................................................ RESSORT
KB4198 ................... SPRING.............................................. MUELLE ......................................................... FEDER ................................................................ RESSORT
KC0055 ................... PIN..................................................... PASADOR.......................................................STIFT.................................................................. GOUPILLE
KC0062 ................... RETAINER .......................................... JUNTA TÓRICA...............................................SICHERUNGSRING............................................. RETENUE
LB0018 ................... SEAL .................................................. SELLO ............................................................ DICHTUNG ......................................................... JOINT
LB0034 ................... SEAL .................................................. SELLO ............................................................ DICHTUNG ......................................................... JOINT
LB0132 ................... SEAL .................................................. SELLO ............................................................ DICHTUNG ......................................................... JOINT
LB0897 ................... SEAL .................................................. SELLO ............................................................ DICHTUNG ......................................................... JOINT
LB0900 ................... SEAL .................................................. SELLO ............................................................ DICHTUNG ......................................................... JOINT
