Seneca MyAlarm3 Cloud User manual

MI00535-4-EN My3 Cloud
INSTALLATION MANUAL
MyAlarm3 Cloud

MI00535-4-EN My3 Cloud

MI00535-4-EN My3 Cloud
CONTENTS
1-WARNINGS SAFETY REGULATIONS 4
2-PRODUCT DESCRIPTION 5
3-PACKET CONTENT 8
4-CONTROL UNIT OPERATION 9
5-CONTROL UNIT INSTALLATION 10
6-ELECTRICAL CONNECTIONS 12
7-DISPLAY FUNCTIONS AND USE 13
8-CLOUD SERVICE ACTIVATION AND MANAGEMENT 14
9-GPS ANTENNA INSTALLATION 24
10-EXTERNAL NTC PROBE INSTALLATION 25
11-TROUBLESHOOTING 26

4MI00535-4-EN My3 Cloud
• Do not apply different voltages or higher voltages than indicated between
terminals, or between any terminal and earth (voltages greater than 50Vdc).
• Do not use the MyAlarm3 Cloud control unit if damaged, or if signs of possible
damage are visible on it.
• Do not remove the internal battery.
• Do not use the MyAlarm3 Cloud control unit if it runs abnormally.
• Do not touch the control unit terminals during use.
• For a correct use, use the cables supplied.
• Make sure the internal battery is charged if you intend to use the MyAlarm3
Cloud control unit without power.
• Use the MyAlarm3 Cloud control unit as described in this manual.
• Before each use, refer to the electrical connections shown in the manual.
REFERENCE STANDARDS: ETSI EN 301-489-7
EN 301 511
EN 301 489-1
IEC / EN 60950
CAUTION
WARNING
1-WARNINGS SAFETY REGULATIONS
Electrical and electronic waste disposal (applicable in the European Union and other countries
with recycling). The symbol on the product or its packaging shows the product must be
surrendered to a collection centre authorized to recycle electrical and electronic waste.
The full content of this manual must be read before any operation.
The device is to be exclusively used by qualied electricians.
Damaged parts must be replaced by the manufacturer, who is also responsible for repairing the
device. The product is sensitive to electrostatic discharges. Take appropriate measures during
any operation.
The warranty shall become null and void in the event of improper use or tampering with the
device or accessories supplied by the manufacturer as necessary for its correct operation, and if
the instructions contained in this manual are not followed.

5MI00535-4-EN My3 Cloud
MyAlarm3 Cloud is a monitoring system consisting of an intelligent control unit for
remote control of homes, systems, machinery and unattended instruments. The
system is based on a Cloud platform offered by Seneca s.r.l. (https://cloud.seneca.it) .
The Cloud service subscription is included with the purchase of the product.
The MyAlarm3 Cloud service is free for the rst two years from the product
activation date.
For information and service renewal costs go to:
www.seneca.it/myalarm3-cloud.
MyAlarm3 Cloud is a service offering the main functions useful to monitoring
through immediate consultation and the practical use of both web browser
and mobile APP. Using the app, available in the Apple and Android stores, you
can check the state of the control unit in real time in case of an alarm (push
notications).
2-PRODUCT DESCRIPTION
If the purchased model has GPS. For optimum reception of the GPS signal given
by satellites, it is better to place the MyAlarm3 Cloud vertically in an area not
covered by metal structures.
ASSEMBLY REGULATIONS
ON / OFF power button
Connector for charging and connecting to the power supply
Menu access button
SIM slot
SD card slot
Digital input connector
SYMBOLS ON THE ENCLOSURE

6MI00535-4-EN My3 Cloud
2-PRODUCT DESCRIPTION
TECHNICAL SPECIFICATIONS
Power supply
Voltage
Absorption
Internal batteries
6 - 15 Vdc (enter value) 500 mA Max
3.5 W Max
Lithium Ion 3.7 V -1100 mAh, rechargeable non-replaceable
Voltage output +12 Vdc 50 mA (maximum current)
Temperature sensor NTC internal (as standard), external (option) thermistor
Ambient conditions
Temperature
Humidity
Storage temperature
Protection rating
Seneca recommends use at 0 to 45°C for correct operation
With the power supply present: -20 .. +55°C
With use of the battery (when discharged): -20 .. 45°C. Charging is possible in
the range: 0 .. +45°C
30%– 90% non condensing.
from -20°C to +20°C < 1 year; from -20°C to +45°C < 3 months; from -20°C to
+60°C < 1 month
IP40
Connections
Spring clamps, 3.5 mm pitch, connector for Micro USB and SMA connector for
GSM, MMCX for GPS antennas (option)
Internal memories FLASH 1 MB + 8 MB
Slot Type/ Memory
Micro SD
Push-Push for SD card and SD HC card / max 32GB
Slot Type SIM Push-Push for mini SIM (15 x 25 mm)
Digital inputs
Type
Maximum frequency
Threshold OFF
Threshold ON
4 inputs
Reed, contact, PNP, Pulsecap
30 Hz
0 - 3 Vdc, I > 1 mA
6 - 24 Vdc, I > 3 mA
Analogue inputs 2 inputs, Voltage 0- 30 Vdc / Current 0- 20 mA, 0.1% of full scale
Display 128x32 LCD Dots with visible area of 39 mm x 8.6 mm
USB 1 micro USB for conguration and supply
CPU 120 MHz 32 bit ARM
GSM QUAD BAND (850 / 900 / 1800 / 1900 MHz)
Digital outputs 2 outlets Relay 3 A max - 250 V SPST (with shared terminal)
GPS SPECIFICATIONS (if present in the purchased model)
RECEIVER 22 channels
SENSITIVITY -165 dBm
FIX TIME 32 s usually
ACCURACY Up to 2.5 m

7MI00535-4-EN My3 Cloud
MyAlarm3 Cloud control unit
Technical characteristics:
• Display LCD 128 x 32 Dots
• Rechargeable Li-Io buffer battery,
up to 8 hours’ autonomy
• GSM/GPRS antenna
• Slot for mini SIM (15x25 mm)
• Internal GPS module with built-in
antenna (OPTION)
• ON/OFF key and display scroll key
• Status LED: device power/status,
GSM/GPRS status
• Slot for mini SIM card (for any
rmware update) and to allow the
device access to the 2G network
through the best known SIM
telephone providers
2-PRODUCT DESCRIPTION
LED STATUS LED MEANING
GSM
(YELLOW)
Off MyAlarm3 Cloud OFF
Fast ashing
(64 ms ON / 300 ms OFF)
Network search
No signal
SIM card with incorrect pin
Slow ashing
(64 ms ON / 3000 ms OFF)
GSM network registration successful, but internet
connection not active
Medium ashing
(64ms ON/ 800 ms OFF)
Successful access to the Internet
correct APN
Registration to the GPRS network successful
PWR
(GREEN)
On MyAlarm3 Cloud ON
Off MyAlarm3 Cloud OFF

8MI00535-4-EN My3 Cloud
1 - MyAlarm3 Cloud control unit
4 - Power supply unit 12 V
2 - NTC sensor for temperature measurement
(Included in the control unit)
6 - SD card
3 - Installation manual
5 - Coupling system for the control unit (wall or DIN rail)
3-PACKET CONTENT
7 - Stylus antenna
8 - V-SIM card
N.B.: The NTC sensor and the stylus antenna can be replaced with
an external sensor and an external antenna respectively.
To see the available accessories, access the "ACCESSORIES"
section on: www.seneca.it/myalarm3-cloud.

9MI00535-4-EN My3 Cloud
Internal GPS antenna
Connection to the Seneca Cloud system
4-CONTROL UNIT OPERATION
Cable for power supply on 230 V socket
Accessory supplied
NTC probe for temperature measurement probe
length 5 cm, accessory supplied
If present in the
purchased model
Stylus antenna

10 MI00535-4-EN My3 Cloud
N.B.: for optimum reception of the
GPS signal (if supported in the
purchased version), it is better
to place the MyAlarm3 Cloud
horizontally on a surface. If the
control unit has a weak or absent
signal, you can use the external
GPS antenna accessory which
can be purchased separately in
the accessories section of the web
page:
www.seneca.it/products/myalarm3-cloud
FW update procedure:
The update of the control unit
rmware is possible via the micro SD
card supplied (or via App). Follow the
procedure below:
1. Copy the le FW.BIN in the main
folder of the micro SD card;
2. Insert the micro SD card into the
MyAlarm3 Cloud control unit;
3. Power the control
4. Wait for the message conrming
the detection of the new rmware;
5. Press “OK” and wait for installation
to complete with the unit restarting.
6. When the power is turned back
on, use the “SCR” button to select
the “Cloud” menu, press and hold
the “SCR” button to enter the
menu, select “default cong.” and
conrm with the “PWR” button.The
procedure is now complete.
First startup procedure:
1. Insert the mini SIM card into the
switched-off MyAlarm3 Cloud (*);
2. Check that the SD card is
correctly inserted (see image 2);
3. Power the control unit connecting
the power supply to the Power
Supply socket or alternatively
use the cable with the forks.
To conrm the rst startup procedure
is correct, the Yellow GSM LED will
change ashing from 1 to 3 times a
second.
(*) if a SIM card other than the
one supplied with the KIT is used,
ensure you have removed the
locking PIN when you switched
on using another device (i.e. a
smartphone)
Switching on and menu keys:
MyAlarm3 Cloud is tted with an
ON/OFF PWR key positioned in the
LH top corner (Figure 3).
To switch it off, keep the PWR key
pressed for a few seconds.
The device is tted with a MENU
key, in the RH top corner.
Pressing this key displays the
parameters.
5-CONTROL UNIT INSTALLATION

11 MI00535-4-EN My3 Cloud
5-CONTROL UNIT INSTALLATION
N.B.: in order to guarantee the correct operation of the MyAlarm3 Cloud control
unit, THE CONTENT OF THE SD CARD MUST NOT BE REMOVED
Image 3
External GPS
antenna
attachment*
*For the installation of the A-GPS
accessory (external GPS antenna) follow
the instructions in chapter 9.
USB Port
Image 2Image 1
Follow the instructions below to update the rmware via the app:
1. From the “home” screen, select “settings” via the dedicated icon
2. Select “options”.
3. Select “installation
4. Select “update rmware” and wait for the installation procedure.

12 MI00535-4-EN My3 Cloud
TERMINAL BLOCK CONTACT KEY
AUX 1
Common to the two relays
AUX 2
DIN 1
DIN 2
DIN 3
DIN 4
AUX+12 Vdc
GND
AIN 1
AIN 2
GND
NTC
Supply
Supply
Input for
sensor
6-ELECTRICAL CONNECTIONS
USE OF THE PUSH-WIRE TERMINALS
Insertion of a rigid cable
Insertion of a thin cable
Extraction of a cable
Press
down Recommended
aying:
8-9 mm
A: press with a
screwdriver
B: insert the
cable
A: press with a
screwdriver
B: extract
the cable

13 MI00535-4-EN My3 Cloud
7-DISPLAY FUNCTIONS AND USE
The main MyAlarm3 Cloud display page provides the following
information:
A - GSM signal level
B - output 1 status
C - output 2 status
D - digital input 1 status
E - digital input 2 status
F - digital input 3 status
G - digital input 4 status
H - battery level
To choose the desired command use the SCR key which allows you to
scroll through the various options, to conrm the desired option press the
PWR key.
It is also possible to call up the contextual menu of a page by holding
down the SCR key for a few seconds. Through a contextual menu it is
possible to display other sub-pages and / or information. Pages with
contextual menus are identiable by a triangle in the display top right
corner.

14 MI00535-4-EN My3 Cloud
8-CLOUD SERVICE ACTIVATION AND MANAGEMENT
To use the MyAlarm3 Cloud monitoring system, it is necessary to register
a SENECA Cloud account and activate the dedicated service.
Preliminary information: in this chapter the concepts of account, service,
owner and user are explained.
ACCOUNT: is an individual registered in the Seneca Cloud and identied
with name, surname and email.
SERVICE: is the MyAlarm3 Cloud device registered in the Seneca Cloud.
OWNER: is the account that activates and manages the individual
MyAlarm3 Cloud service owned and managed by it.
USER: is the account that can use the single MyAlarm3 Cloud service
after receiving the invitation from the owner of the service.
Each activated Service (therefore each MyAlarm3 Cloud) is managed only
by the "OWNER ACCOUNT", which also has full responsibility for it, while
several "USER ACCOUNTS" can use the individual service after receiving
the invitation from the "OWNER ACCOUNT".
The "OWNER ACCOUNT" can either invite other "USER ACCOUNTS"
to use its MyAlarm3 Cloud as guest users, or be invited by other owner
accounts to use their MyAlarm3 Cloud as a guest user.
The "USER ACCOUNT" is the guest user of MyAlarm3 Cloud not owned
by him after the invitation to use by the respective "OWNER ACCOUNTS".
It is not necessary to have a MyAlarm3 Cloud to register in the Seneca
Cloud and be invited by an "OWNER ACCOUNT".
In this way, it is possible to create cross eets of MyAlarm3 Clouds with
owners of one or more devices, individual users of a device and system
maintainers with access to groups of systems consisting of multiple
MyAlarm3 Cloud devices.
Some examples are shown on the opposite page:

15 MI00535-4-EN My3 Cloud
Example 1: three “OWNER ACCOUNTS” manage just their devices:
Control unit 1 Control unit 2 Control unit 3
OWNER 1
ACCOUNT
OWNER 2
ACCOUNT
OWNER 3
ACCOUNT
Example 2: A device is managed by one “OWNER ACCOUNT” and two
“USER ACCOUNTS”:
OWNER
ACCOUNT
USER 1
ACCOUNT
USER 2
ACCOUNT
fully manages the
system in all its functions
manages only the
functions the owner
account gives access to
manages only the
functions the owner
account gives access to
8-CLOUD SERVICE ACTIVATION AND MANAGEMENT

16 MI00535-4-EN My3 Cloud
Example 3: two "OWNER ACCOUNTS" own one device, a third device is used
by the two different accounts, one as the "OWNER ACCOUNT" and one as the
"USER ACCOUNT":
Control unit 1 Control unit 2 Control unit 3
OWNER 1
ACCOUNT
OWNER 2
ACCOUNT
Control unit 1 Control unit 2 Control unit 3
OWNER 3
ACCOUNT
Example 4: groups of crossed devices
OWNER 2
ACCOUNT
OWNER 1
ACCOUNT
USER 3
ACCOUNT
USER 2
ACCOUNT
USER 1
ACCOUNT
8-CLOUD SERVICE ACTIVATION AND MANAGEMENT

17 MI00535-4-EN My3 Cloud
To use MyAlarm3 Cloud, it is necessary to register a SENECA Cloud account and
activate the dedicated service.
The MyAlarm3 Cloud KIT includes a usage fee for 12 months from rst activation.
For further information and renewal costs go to:
https://www.seneca.it/myalarm3-cloud
The activation procedure is available from both WEB browser and MyAlarm3
Cloud mobile app.
Activation from WEB browser
1. Start the control unit as per rst startup procedure (see chapter 5 of the
following manual);
2. Connect to https://cloud.seneca.it to register your own SENECA Cloud
account (if not previously done to activate services related to other MyAlarm3
Cloud devices owned or to be able to access as a guest user services related to
MyAlarm3 Cloud belonging to other accounts after their invitation).
Wait for an account activation email;
3. After receiving the account activation email, select the "ACTIVATE ACCOUNT"
key;
4. After activating the account, connect to https://cloud.seneca.it again to log in.
Select the "CLOUD SERVICES" key and select "ADD" in the top right hand corner;
5. Enter the “Activation code” of 5+10 characters found on the back of the control
unit (and inside the package) and select the “ADD” key again; (*)
6. From now on, the service is active and the control unit's owner account can
access the MyAlarm3 Cloud system from both the web browser and the MyAlarm3
Cloud mobile app of the same name, as well as invite other users to use his newly
activated MyAlarm3 Cloud. (For activation and access from a mobile app see the
next paragraph. To invite other users to use the newly activated MyAlarm3 Cloud
service, see next chapter).
(*) The operation requires less than 1 minute during which the device is
synchronized with the Seneca Cloud platform.
8-CLOUD SERVICE ACTIVATION AND MANAGEMENT

18 MI00535-4-EN My3 Cloud
Activation via MyAlarm3 Cloud app
1. Start the control unit as per rst startup procedure (see chapter 5 of the
following manual);
2. Install the MyAlarm3 Cloud app by Seneca available in the iOS and Android
stores, using the following QR codes or searching for MyAlarm3 Cloud by SENECA:
3. Open the appropriate app and register your Seneca cloud account (if not
previously done to activate services related to other MyAlarm3 Cloud devices
owned or to be able to access as a guest user services related to MyAlarm3
Clouds owned by other accounts after their Invitation). Wait for an account
activation email;
4. After receiving the account activation email, select “ACTIVATE ACCOUNT”
key;
5. After activating the account, open the app again and log in for the rst time by
entering your newly created username and password;
6. Enter the 5 + 10 character "activation code" on the back of the control unit (and
inside the package) and select the "ACTIVATE" button (if it is not the rst service
associated with the account, from the app click "change system "and then select
the" ADD "button); (*)
7. From now on, the service is active and the control unit's owner account can
access the MyAlarm3 Cloud system from both the web browser and the MyAlarm3
Cloud mobile app of the same name, as well as invite other users to use his newly
activated MyAlarm3 Cloud. (For activation and access from a web browser, see
the previous paragraph. To invite other users to use the newly activated MyAlarm3
Cloud service, see next chapter).
(*) The operation requires less than 1 minute during which the device is
synchronized with the Seneca Cloud platform.
8-CLOUD SERVICE ACTIVATION AND MANAGEMENT

19 MI00535-4-EN My3 Cloud
Entering new users invited by the owner account:
The addition of new users to the MyAlarm3 Cloud service is an operation that can
be performed both from the HTML 5 WEB browser and via the MyAlarm3 Cloud
mobile app. It is possible to dene users with different authorizations according
to the needs of the owner account: non-owner administrator (ADMIN), EDITOR,
USER:
ADMIN: displays information, sends commands, modies settings.
EDITOR: displays information, sends commands
USER: displays information
Instructions for inviting new users to the MyAlarm3 Cloud service from a WEB browser
1) Access your Cloud account via the https://cloud.seneca.it WEB browser;
2) Select “Cloud Services”;
3) Select the "MANAGEMENT" button on the MyAlarm3 Cloud service (owned by you)
that you want to make other users use;
4) Select the "ADD" button in the "Invitations" section;
5) Enter the email of the user to be invited and the role (ADMIN, EDITOR, USER) to be
assigned, then select the "ADD" button. If the user is already registered as an account
in the Seneca Cloud, go to point 9). If he is not registered, the system reports that the
user is not present in the Seneca Cloud as an account, then asks if you want to send
him an invitation (via email) to register. Click on "YES". The user will have to wait to
receive the invitation email to register on the Seneca Cloud;
6) After receiving the invitation email to register the account on the Seneca Cloud, the
user must select the "REGISTER" button, then follow what is required in the registration
procedure and once registered he must wait for the account activation email;
7) After receiving the account activation email, the user must select the “ACTIVATE
ACCOUNT” key. Once activated, he can be invited to use the MyAlarm3 Cloud service
by the owner account. Wait for the invitation;
8) Once the user to be invited has registered and activated an account on the Seneca
Cloud, it is nally possible to send him an invitation to use the MyAlarm3 Cloud service
(owned by you), then return to point 5) of the guide;
9) Upon receiving the invitation email to use the MyAlarm3 Cloud service, the user must
select the "ACCEPT INVITATION” key. Alternatively, the owner account from a web
browser (or from the MyAlarm3 Cloud app) can force acceptance of the invitation and at
any time modify the role assigned;
10) From now on, the user account can use the MyAlarm3 Cloud service for which it
received the invitation to use from the device owner account
8-CLOUD SERVICE ACTIVATION AND MANAGEMENT

20 MI00535-4-EN My3 Cloud
Instructions for inviting new users to the MyAlarm3 Cloud service from the
MyAlarm3 Cloud App:
1) Open the app and select "INVITATIONS" from the options menu (if you manage
multiple MyAlarm3 Cloud services from the app, when opening the app will
show the status of the last MyAlarm3 Cloud which was accessed then, selecting
invitations, you can invite the user account to use this MyAlarm3 Cloud. Clearly the
invitations section in the app is only available to the owner of the Myalarm3 Cloud);
2) Enter the email of the user to be invited and the role (ADMIN, EDITOR, USER)
to be assigned, then select the "INVITE" button. If the user is already registered as
an account in the Seneca Cloud, go to point 6). If he is not registered, the system
reports that the user is not present in the Seneca Cloud as an account, then asks if
you want to send him an invitation (via email) to register. Click on "YES". The user
will have to wait to receive the invitation email to register on the Seneca Cloud;
3) After receiving the invitation email to register the account on the Seneca Cloud,
the user must select the "REGISTER" button, then follow what is required in the
registration procedure and once registered he must wait for the account activation
email;
4) After receiving the account activation email, the user must select the “ACTIVATE
ACCOUNT” key. Once activated, he can be invited to use the MyAlarm3 Cloud
service by the owner account. Wait for the invitation;
5) Once the user to be invited has registered and activated an account on the
Seneca Cloud, you can send him an invitation to use the MyAlarm3 Cloud service
(owned by you), then go back to point 2) of the guide;
6) Upon receiving the invitation email to use the MyAlarm3 Cloud service, the user
must select the "ACCEPT INVITATION” key from the email or from the App main
menu select “change device” from the App. Alternatively, the owner account can
force acceptance of the invitation from the MyAlarm3 Cloud app (or from a web
browser) and at any time modify the role assigned;
7) From this moment, the user account can use the MyAlarm3 Cloud service for
which it received the invitation from the device owner account (For the insertion of
new invited users via web browser see the previous paragraph).
8-CLOUD SERVICE ACTIVATION AND MANAGEMENT
