Sennheiser CC 513 User manual

2
The CC 513 headset
The CC 513 is a monaural headset with neckband.
Via a telephone-specific adapter cable, you can connect the
headset to most standard telephones or Call Center
systems.
The headset is extremely comfortable to wear due to:
• ultra-lightweight design
•softearpad
•flexibleneckband
The specially developed “Active Acoustic Shock” system
protects your ears from excessive volume. The micro-
phone’s “Ultra Noise Cancelling” technology effectively
filters out ambient noise.
If the headset is connected to a Sennheiser Communi-
cations Universal Interface (accessory), you can switch
between the handset and the headset and make use of the
many additional options offered.
CC_513.book Seite 2 Freitag, 9. September 2005 12:15 12

3
Contents of the packing unit
A– Headset with earcup , microphone boom ,
neckband , headset cable with one half of the
“Easy Disconnect” facility 
– Cable clip
–Popshield
–Storagebag
– Replacement ear pad
You additionally require a telephone-specific adapter cable
(accessory) that is available from your specialist dealer.
Safety instructions
• Keep children away from the clip-headset. When
playing, children can be strangled by the cables.
• Do not use the headset in a damp or dusty
environment.
Volume up? – No!
Avoid using headphones with the volume turned up for
an extended period of time. Doing so can damage your
hearing. It is avisable to keep the volume at a moderate
level at all times.
CC_513.book Seite 3 Freitag, 9. September 2005 12:15 12

4
Putting the headset into operation
Connection options
The headset is not directly connected to the telephone but
via a telephone-specific adapter cable (accessory).
Connection of the headset to the adapter cable is via the
“Easy Disconnect” facility.
There are three connection options:
• The adapter cable is connected to the telephone instead
of the handset.
• The adapter cable is connected to the telephone in
addition to the handset.
• The adapter cable is connected to a Universal Interface
(accessory).
Connecting the adapter cable to the telephone’s handset
socket
Pull the Western plug of the handset cable out of the
telephone.
Connect the Western plug of the adapter cable to the
handset socket on the telephone until it locks into place
with an audible “click”.
CC_513.book Seite 4 Freitag, 9. September 2005 12:15 12

5
Directly connecting the adapter cable to the telephone
Some telephones feature an additional socket to which you
can connect a second handset or a headset. Connect the
Western plug of the adapter cable to this socket until it
locks into place. An audible “click” should be heard.
Connecting the headset to a Universal Interface
For connecting the headset to a Universal Interface, please
refer to the operating instructions of the Universal Interface.
The “Easy disconnect” facility
The headset is connected to the adapter cable via an “Easy
Disconnect” facility. During a converation, you can leave
your telephone while holding the call by simply
disconnecting the headset from the “Easy Disconnect”
facility. This allows you to move around freely without
having to put off the headset. As soon as you re-connect
the two halves of the “Easy Disconnect” facility, you can
continue your call.
BTo connect the headset to the “Easy Disconnect”
facility, plug in one half of the “Easy Disconnect” facility
into the other half until it locks into place with an
audible “click” should be heard.
CTo disconnect the headset from the “Easy Disconnect”
facility, press one of the two release buttons . The
two halves of the “Easy Disconnect” facility
automatically disconnect.
CC_513.book Seite 5 Freitag, 9. September 2005 12:15 12

6
Wearing the headset
DPut the headset on.
EThe headset features a flexible microphone boom .
Bend the microphone boom so that the micro-phone 
is placed at the corner of the mouth. Maintain a
distance of approx. 1 cm between microphone and
mouth.
The cable clip
FAffix the headset cable to the clothing by means of the
supplied cable clip. Attach the cable clip so that you can
freely move your head.
The popshield
The popshield effectively reduces pop noise.
GSlide the popshield over the microphone. The popshield
must totally enclose the microphone.
When is the headset ready for operation?
The headset is ready for operation as soon as it is
connected – via an adapter cable – to your telephone or a
Universal Interface. If you disconnect the headset from the
telephone or Universal Interface, it is out of operation.
Replacing the ear pad
HGrasp behind the ear pad and pull it up and away from
the earcup. Slide the new ear pad onto the earcup.
CC_513.book Seite 6 Freitag, 9. September 2005 12:15 12

7
Cleaning the headset
For cleaning the headset, only use a dry or slightly damp
soft cloth. Do not use any solvents or cleansing agents as
these can damage the varnish of the headset. If necessary,
the ear pad can be cleaned with soapy water (use a mild
cleanser such as washing-up liquid).
Transportation and storage
To prevent the headset from being damaged, always use
the supplied storage bag for transportion and storage.
If problems occur...
If the problem persists, please contact your local
Sennheiser Communications agent for assistance. Never
repair or attempt to repair the units as this will invalidate
the warranty.
Problem What to do
The other party cannot hear you Make sure that the cables
are connected correctly.
You cannot hear the other party
CC_513.book Seite 7 Freitag, 9. September 2005 12:15 12

8
Accessories and replacement parts
The following accessories and replacement parts are
available from your specialist dealer:
Accessory /
Replacement part
Cat. No.
Adapter cable available from your
specialist dealer
Leatherette ear pad 091530
Foam ear pad 091527
Popshield 091540
Cable clip 091552
UI 710 Universal Interface 009882
UI 720 Universal Interface 009883
UI 730 Universal Interface 009884
UI 740 Universal Interface 009885
UI 750 Universal Interface 009886
CC_513.book Seite 8 Freitag, 9. September 2005 12:15 12

9
Specifications
System
Temperature range: –10 up to +50°C / 95% RH
Headphones
Frequency response: 200 Hz–4.5 kHz
Impedance: 250 Ω
Sound pressure level
(at 1 kHz, 1 Vrms): 112 dB
Cable length: 1.0 m
Microphone
Frequency response: 100 Hz–4.5 kHz
Pick-up pattern: Ultra Noise Cancelling (UNC)
Sensitivity
(at 1 V/Pa, 1 kHz): –38 dB
Impedance: ∼2kΩ
CC_513.book Seite 9 Freitag, 9. September 2005 12:15 12

10
Das Headset CC 513
Das CC 513 ist ein einseitiges Headset mit Nackenbügel.
Sie können das Headset über ein telefonspezifisches
Adapterkabel an alle handelsüblichen Telefone und Call
Center-Systeme anschließen.
Der hohe Tragekomfort des Headsets beruht auf:
• dem ultraleichten Design
• dem bequemen Ohrpolster
• dem flexiblen Nackenbügel
Das speziell entwickelte „Active Acoustic Shock“-System
schützt Ihr Gehör vor zu hohen Lautstärken. Die „Ultra
Noise Cancelling“-Technik des Mikrofons blendet Störschall
wirkungsvoll aus.
Wenn Sie das Headset an ein Sennheiser Communications
Universal Interface (Zubehör) anschließen, können Sie
nicht nur zwischen dem Telefonhörer und dem Headset
umschalten, sondern viele zusätzliche Möglichkeiten
nutzen.
CC_513.book Seite 10 Freitag, 9. September 2005 12:15 12

11
Inhalt der Packung
A – Headset mit Hörermuschel  , Mikrofonarm ,
Nackenbügel  , Headsetkabel mit einer Hälfte der
Schnelltrennkupplung

– Kleiderclip
– Poppschutz
– Aufbewahrungsbeutel
– 1 Ersatzohrpolster
Sie benötigen zusätzlich ein telefonspezifisches Adapter-
kabel, das Sie als Zubehör bei Ihrem Fachhändler erhalten.
Einige Worte zu Ihrer Sicherheit
• Das Headset gehört nicht in Kinderhände. Beim Spielen
können sich Kinder mit dem Kabel strangulieren.
• Benutzen Sie das Headset nicht in feuchter oder
staubiger Umgebung.
Laut hören? – Nein!
Um Hörschäden zu vermeiden, sollten Sie nicht längere
Zeit mit hoher Lautstärke hören.
