S6069 Apollo
Infrared Portable
Outdoor Heater
Instructions &
Operation Manual

Safety Information:
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
When using any electrical appliance, safety precautions should always
be observed. Read these instructions carefully, and retain for future
reference.
When used by, or near, young children or infirm persons, supervision is
necessary. Young children should be supervised to ensure that they do not
play with the appliance.
Use this appliance only with the voltage specified on rating label.
Do NOT use this appliance other than for its intended use.
Do NOT touch hot surfaces or moving parts.
Do NOT cover the grilles or place any object or material up against
the unit, as this may block entry or exhaust of air.
Do NOT probe any opening.
To ensure trouble free performance it is recommended that on a regular basis the
unit be isolated from the power supply and a vacuum cleaner used to remove dust
from the inlet and outlet grilles.
Caution:
When the heater is operated ensure the heater is not obstructed in
any way. Ensure the heater can operate safely, should the heater switch on when the
ambient temperature drops, or a timer activates the heater.
Do NOT allow the supply cord to come into contact with heated
surfaces during operation.
Regulations require that electrical work be carried out by authorised
persons. For your own safety and that of others, ensure this is done.
If the supply cord becomes damaged, it must be replaced by a
qualified person, in order to avoid a hazard.

Apollo Portable Patio Heater -1.2kW
Our Apollo heavy duty portable patio heater has been exclusively designed by our
engineers to provide a solid and sturdy patio heater that can be placed almost
anywhere in complete safety.
The strong aluminium frame encases our powerful 1.2kW glass fronted infrared heater
S6068 with a large, highly polished reflector to give you a maximum heat output with
the minimum of fuss.
Rubber elbow and base protectors make the Apollo Portable
Patio Heater completely non-slip and able to be placed on a wide range of surfaces
from tiled, paved or wooden floors to desks or cabinets.
Specifications
Specification
Model
S2069
Voltage (V)
220
-240
Power consumption (W)
1200
Dimensions
L x H x D (mm)
400X190X306mm
-
Heater
560X360X335mm
- Cage
Weight (kg)
3.7 Light
–4.00 Cage
IP protection
IP
54

•6•7•7
For additional protection the installation of a residual current device
(RCD) is strongly recommended. ( Refer to local electrical regulations)
Remove all packaging e. material ( and check the appliance, supply cord and the plug
for signs of damage
Pay attention to the surface on which Apollo is going to be placed. Ensure that it is
suitable, flat, stable and strong enough to hold the appliance.
Before using ensure that the minimum safe distances from walls and solid objects are
strictly followed.
45mm 45mm
45mm
0.2m
0.5m
1.8mm
Installation
There must be a distance of at least 1.5 M at each side between the appliance and
walls or the like.
Assemble the appliance into the cage using mounting bracket located on the back of
the heater
Connect to a power source using the 4.5 meter ruberised cordset provided.
Observe whether during the first 10-15 minutes that the appliance is functioning
properly.

Installing the heater into the Portable Cage
1. Remove the attached bracket from the back of the heater. (4 bolts to unscrew)
2. Using the same 4 bolts attach the heater unit to the matching bracket on the cage
and tighten the screws on the cage and tighten the bolts.
3. The heater is then securely held in position with the front face of the heater at an
angle of approximately 185 degrees to a flat floor surface face pointing slightly
upwards.
4. The cage is designed to ‘flex’ in order that the lamp is not broken if the unit is
roughly used.
5 .Before use ensure that the rubberised joints of the cage are tight by using the
Allan key provided to tighten the screws located in the joints if necessary.

Cleaning and Maintenance
This appliance is constructed of a robust and maintenance-free materials with a
heater cover of toughened glass. There are no user serviceable parts inside.
Before cleaning remove the plug from the power outlet (if fitted) and wait until the
appliance is sufficiently cool.
Wipe the appliance only with clean and lint-free cloth or a soft brush.
Caution! Before the next use the unit must be dry.
Never use abrasive cleaners, scrubbing brushes and chemical cleaners for cleaning!
Never use flammable cleaners such as benzine or spirits.
To protect against electrical shock do not immerse cord, plug, or any part of the
appliance in water or other liquid.
For heating element replacement please contact Serene Industries Limited or a
properly qualified service person.
Recomended Disposal
In accordance with the European Directive 2011/65/EU (not yet mandated in AU and
NZ) concerning used electrical and electronic appliances please return any electrical
equipment that you will no longer use to suitable waste collection points provided
for their disposal.
This symbol indicates that the appliance should not be treated as normal domestic
waste.
