OWNER’S GUIDE
SC630NZ

1CUSTOMER CARE - NZ: 0800 002 999
WHEN USING YOUR SHARK®PORTABLE
STEAM POCKET®, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS BE
FOLLOWED, INCLUDING THE FOLLOWING:
READ ALL INSTRUCTIONS BEFORE
USING YOUR SHARK® PORTABLE STEAM
POCKET®.
DANGER OF SCALDING.
Please use caution when using the steam
bottle directly or with the hose and tool
attachments and cleaning pockets. The steam
emitted is very hot.
IMPORTANT:
This appliance is not intended for use by
persons with reduced physical, sensory or
mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of
the appliance by a person responsible for
their safety.
Children shall not use or play with this
appliance. Close supervision is necessary to
keep appliance out of reach of children during
use and cooling.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR INJURY:
1. Use the system only for its intended use.
2. DO NOT use outdoors.
3. DO NOT leave the appliance unattended when
plugged in. Always unplug the power cord from the
electrical outlet when not in use and before servicing.
4. DO NOT allow the appliance to be used by children.
Close attention is necessary when used near
children, pets or plants.
5. Use only as described in this manual.
6 . Use only manufacturer’s recommended accessories.
7. DO NOT use with damaged cord or plug. Contact
Customer Services or Service Center for the repair or
replacement of the line cord.
8. DO NOT USE if the appliance is not working, has
been dropped, dropped into water, damaged or left
outdoors.
9. NO SERVICEABLE PARTS. Incorrect re-assembly
or repair can cause a risk of electrical shock or injury
to persons when the appliance is used. Contact
Customer Service or Service Center for the repair or
replacement under the warranty agreement.
10. To protect against a risk of electric shock, DO NOT
immerse the portable Steam Pocket®into water or
any other liquids.
11. DO NOT handle plug or portable Steam Pocket®with
wet hands or operate appliance without shoes.
12. DO NOT pull or carry by power cord, use power cord
as handle, close a door on the power cord, or pull
the power cord around sharp edges or corners. Keep
power cord away from heated surfaces.
13. DO NOT unplug by pulling on power cord. To unplug,
grasp the plug not the power cord. Do not use
extension cords or outlets with inadequate current
carrying capacity.
IMPORTANT SAFETY INSTRUCTIONS
For Household Use Only

2
CUSTOMER CARE - AU: 1800 890 840
26. If an extension cord is absolutely necessary, an
extension cord rated a minimum of 15 ampere,
2.08mm2 (14 AWG) cord should be used. Cords
rated for less amperage may overheat. Care should
be taken to arrange cord so that it cannot be pulled
or tripped over.
27. DO NOT leave unattended when the system is
connected to a power supply or electrical outlet.
Turn off all controls before unplugging the unit.
28. DO NOT store unit with damp or wet cleaning
pocket attached. Never leave the portable Steam
Pocket®in one spot on any surface for any period
of time with a damp or wet cleaning pocket
attached as this will damage your surface.
29. Always unplug and allow the portable Steam
Pocket®to cool before removing cleaning fabric or
changing cleaning tools and hose.
30. Make sure that the water tank door is closed when
using the appliance.
WARNING: Your portable Steam
Pocket®is designed to clean surfaces that will
withstand high heat. Do not use on unsealed
wood or unglazed ceramic surfaces. On surfaces
that have been treated with wax or some no wax
surfaces, the sheen may be removed by the heat
and steam action. It is always recommended to
test an isolated area of the surface to be cleaned
before proceeding. We also recommend that you
check the use and care instructions from the
surface manufacturer.
SAVE THESE
INSTRUCTIONS
14. DO NOT put any objects into openings. Do not use
with any opening that is blocked.
15. DO NOT put hands or feet under the portable Steam
Pocket®. Unit gets very hot.
16. DO NOT use on leather, wax polished furniture or
floors, synthetic fabrics, velvet or other delicate,
steam sensitive materials.
17. Liquid or steam must not be directed towards
equipment containing electrical components, such as
the interior of ovens.
18. DO NOT add cleaning solutions, scented perfumes,
oils or any other chemicals to the water used in this
appliance as this may damage the unit or make it
unsafe for use. If you live in a hard water area, we
recommend using distilled water in your portable
Steam Pocket®.
19. When in use, NEVER turn the appliance over or
on its side. NEVER DIRECT STEAM TOWARDS
PEOPLE, ANIMALS OR PLANTS.
20. Carefully remove the cleaning pocket immediately
after you have unplugged and allowed the portable
Steam Pocket®to cool.
21. When cleaning the portable Steam Pocket®, unplug
the power cord from the electrical outlet and clean
with a dry or damp cloth. Do not pour water or use
alcohol, benzene or paint thinner on the unit.
22. Never use portable Steam Pocket®without the
cleaning pocket attached.
23. Keep your work area well lit.
24. Let the system cool completely before putting away.
Wrap cord loosely around system when storing, using
the cord clip to secure.
25. To avoid circuit overload, do not operate another
appliance on the same socket (circuit) as the steam
cleaner.

3CUSTOMER CARE - NZ: 0800 002 999
THIS MANUAL COVERS MODEL NUMBER:
SC630NZ 11
TECHNICAL SPECIFICATIONS
Voltage: 220-240V~, 50/60Hz
Power: 1550 Watts
Water Capacity: 450 ml (15 fl. oz.)
GMA-102233-009
IPX4

4
CUSTOMER CARE - AU: 1800 890 840
Contents
Getting Started ..................................................................................................... 5
Using Your Portable Steam Pocket®........................................................................ 7
Care of Your Portable Steam Pocket®................................................................... 12
Suggested Uses.................................................................................................. 13
Troubleshooting Guide......................................................................................... 15
Warranty ............................................................................................................ 18
Thank you for
purchasing the
Shark®Portable
Steam Pocket®
Cleaning
System.

5CUSTOMER CARE - NZ: 0800 002 999
Getting Started
FIRST THINGS FIRST, YOU NEED TO KNOW
WHAT’S IN THE BOX YOU JUST OPENED:
a Steam Bottle
bExtension Hose
cWedge Cleaning Tool
dCylinder Cleaning Tool
eDetail Cleaning Handle
f 2 Detail Brush Accessories
gGarment Steamer Kit
hGarment Steamer Bonnet
i Shower Door Squeegee Attachment
j Filling Flask
kDirect Steam Nozzle
l 2 All-Purpose Wedge Cleaning Pockets
m2 All-Purpose Cylinder Cleaning Pockets
nSteam Duster Cylinder Cleaning Pocket
oScrubbing Wedge Pocket
pSqueegee Wedge Pocket
qNozzle Cleaner
a
c d
f g
i k
Your portable Steam Pocket®is designed to clean
surfaces that will withstand high heat and moisture.
Do not use on unsealed wood surfaces (especially
wooden antique furniture), unglazed ceramic tile, painted
surfaces or surfaces that have been treated with wax,
oils, varnishes, or shellac. The sheen may be removed
by the heat, steam, and friction of the cleaning tools.
Lacquer and polyurethane coatings provide a hard
durable protective finish that withstands moisture but
it is always recommended to test an isolated area of
the surface to be cleaned before proceeding. We also
recommend you check the use and care instructions
from the surface manufacturer.
When cleaning finished wood surfaces, use broad,
continuous cleaning strokes. To prevent surface damage,
avoid focusing steam or allowing the cleaning tools to sit
in one spot for any amount of time.
When assembling your portable Steam Pocket®, there
may be a little water in the water tank. This is because
we test all our portable Steam Pocket®cleaning systems
100% before you buy them, so you get a quality Shark®
steam product.
j
he
b

6
CUSTOMER CARE - AU: 1800 890 840
ASSEMBLY & USE INSTRUCTIONS
1Safely remove contents of the portable Steam
Pocket®cleaning system and lay them out on a flat
surface to see that you have all the components to
complete the assembly.
2READ ALL INSTRUCTIONS BEFORE USING YOUR
PORTABLE STEAM POCKET®.
IMPORTANT: Always make sure the steam
bottle is UNPLUGGED from the electrical outlet
when not in use. Never fill the water reservoir
when the unit is plugged in.
3Only use water. To extend the life of your portable
Steam Pocket®, we recommend using distilled
water. If you live in an area with hard tap water, we
recommend using distilled water.
4Do not add cleaning solutions, scented perfumes,
oils, or any other chemicals to the water used in this
appliance as this may damage the unit or make it
unsafe for use. Use of any substances other than
manufacturer’s recommended accessories will
automatically void your warranty.
FILLING AND REFILLING THE WATER TANK
1Never fill the steam bottle while plugged into an
electrical outlet.
2Disconnect the power cord before filling the water
tank.
3Turn the water tank cap anticlockwise and remove to
fill, using the filling flask provided. Be careful not to
overfill. Replace the cap by turning clockwise.
3
m
n
l
o
p
q

7CUSTOMER CARE - NZ: 0800 002 999
Using Your Portable Steam Pocket®
DIRECT SPRAY STEAM BOTTLE USE
Cleaning Tip: Direct steam spray for cleaning hard to
reach nooks & crannies and stubborn sticky messes
where focused steam power may be needed. Direct
steam spray can loosen and dislodge compact dirt
often found in corners and tight places where traditional
methods and cleaning tools tend to push dirt into,
making it difficult to reach and clean. Spray direct steam
and wipe clean with a cleaning cloth.
CAUTION: Direct steam spray temperature is
extremely hot closest to the nozzle and can
damage surfaces if held directly focusing in
one spot too long. Be sure to constantly move
and adjust the steam spray to avoid causing
damage.
1 Attach the Steam Bottle Nozzle. Aligning the arrow
located on the Steam Bottle Nozzle with the Un-Lock
symbol located on the Nozzle Connector. Press in
and turn clockwise to secure into place. The arrow
on the nozzle will align with the Lock symbol.
2 To remove the Steam Bottle Nozzle, turn
anticlockwise to unlock and remove.
1 Attach the hose connector. Aligning the arrow located
on the hose connector with the un-lock symbol
located on the nozzle connector. Press in and turn
clockwise to secure into place. The arrow on the hose
connector will align with the lock symbol.
2To remove the hose, press in and turn the hose
connector anticlockwise to unlock and remove.
3Select the desired cleaning tool for use. Follow
the cleaning tool sub assembly instructions for the
selected tool.
4Attach the cleaning tool by inserting the hose stem
into the handle of the cleaning tool. Press in and
turn clockwise at the same time to secure and
press in and turn anticlockwise to release.
Check for proper connection by turning the handle
anticlockwise a few turns. The handle should remain
connected. (Note for reference: This connection
method is the same design used with most over
the counter prescription bottles). The design of this
connection is to prevent the hose from twisting and
kinking during use.
1
3
4
1

8
CUSTOMER CARE - AU: 1800 890 840
5
6
WEDGE CLEANING TOOL ASSEMBLY
5Slide the wedge shaped cleaning pocket over the
wedge cleaning tool frame until it is completely on.
6Secure the cleaning pocket onto the frame. Close the
cinch by pulling on the elastic band and sliding the
locking bean to tighten.
Cleaning Tip: The wedge cleaning pocket was designed
for cleaning a variety of surfaces and is exceptional on
those that are large and flat, both horizontal and vertical.
Broad cleaning sides and super absorbent microfibre
fabrics loosen, lift, and lock in dirt and grime while
sanitising at the same time.
Cleaning Tip: The wedge tip and squared edges reach
into tight areas often missed or difficult to reach with
traditional cleaning methods. The wedge sides concave
to wrap around sink and faucet fixtures, door knobs,
and other small curved surfaces leaving them clean all
around. Multiple sides provide more surface cleaning
area and allow one to clean with one side and finish
with the other for a “NOW YOU KNOW THAT’S CLEAN”
performance. Surface examples for use are countertops,
tabletops, cabinets, walls, floor spot cleaning, bathroom
fixtures and more.
CAUTION: It is recommended that you allow the
cleaning pockets to cool off before removing
them from the wedge or cylinder tools to avoid
possible scalding injury.

9CUSTOMER CARE - NZ: 0800 002 999
CYLINDER CLEANING TOOL ASSEMBLY
1Squeeze “chopsticks” together and slide the cylinder
shaped cleaning pocket over the cylinder cleaning
tool frame until it is completely on.
2Secure the cleaning pocket onto the frame. Close the
cinch by pulling on the elastic band and sliding the
locking bean to tighten.
Using Your Portable Steam Pocket®- cont’d
Cleaning Tip: The thin cylinder shape provides
controlled cleaning and reaches into narrow areas,
around curved and contoured surfaces for steam
dusting and fine cleaning activities. Specialised dusting
cleaning pockets provide gentle cleaning of surfaces,
objects, and furniture while reaching into crevices and
corners. It is a great cleaning tool for in and around
window sills, door jams and frames, exhaust and intake
vents, banisters, railings, spindles, furniture, seating,
patio furniture, and more.
1
2
1
SHOWER DOOR SQUEEGEE
Cleaning Tip: The shower door squeegee provides
a streak free clean. Start at the top and gently glide
downward, wiping excess moisture and dirt away.
1 Press fit the shower door squeegee attachment onto
the detail cleaning handle.
HOSE & CLEANING TOOL ATTACHMENT USE
Cleaning Tip: Versatile cleaning tools provide multi-
purpose and task specific cleaning solutions for quick
and easy clean-up. Effortlessly interchange the tools
for on the go whole house cleaning in areas missed and
forgotten with the power of super heated steam.
CAUTION: Always avoid any sudden changes in
temperature to prevent breakage or cracks.

10
CUSTOMER CARE - AU: 1800 890 840
DETAIL SCRUBBING BRUSH ATTACHMENT
1 Press fit the detail scrubbing brush onto the detail
cleaning handle.
GARMENT STEAMER ATTACHMENT
CAUTION: Always determine colour fastness
of any fabric, especially with reds or blues.
Taking a clean, moist, warm towel and gently
rubbing a small area on the fabric that is out of
sight and out of the way as possible. If colour
bleeds onto the towel, you may need to have
the piece professionally cleaned.
1 Press fit the garment steamer onto the bottle nozzle.
2 For garment steaming, stretch the garment steamer
bonnet over the garment steamer diffuser.
3 For garment brush, attach directly onto the
garment steamer diffuser by aligning the bottom
of the diffuser with the back of the garment brush
attachment. Gently push the top of the garment
brush up into place over the bonnet until the
attachment snaps into place.
Note: It is recommended that the bonnet be used
at all times to assure a dry steam and prevent
condensation.
3
Cleaning Tip: The scrubbing brush attachment is
great for hard to reach areas and for breaking up
heavily soiled and dried on messes. Allow plenty of time
for steam heat and moisture to penetrate the surface
as it dislodges the mess for wiping. It can be especially
useful in the bathroom and shower area loosening
scum build-up on tile and grout. Select either of the
cleaning pocket tools to clean, sanitise, and wipe up
excess moisture and residue.
NOTE: The detail scrubbing brush is most effective when
applying light pressure. Let the super heated steam and
the bristle tips do the work for you. The sides of the
bristles are not effective for scrubbing. If you apply too
much force, you will bend and deform the bristles.
Tip: For freshening upholstery and removing wrinkles
from clothing, fabrics, and drapes.
1

11 CUSTOMER CARE - NZ: 0800 002 999
Using Your Portable Steam Pocket®- cont’d
GENERATING STEAM
CAUTION: Steam is hot and can cause burns,
so please use with caution.
1Plug the unit in and wait about 30 to 45 seconds
then press and hold the steam trigger to activate the
pump. You will immediately hear steam generating
and begin to see visible results either from the nozzle
or the attached cleaning tool. It is recommended
that you wait at least 30 seconds before pulling the
trigger as this will minimise water spitting.
2Once you release the steam trigger, the pump will
stop delivering water to the boiler and the steam will
reduce to a stop when the boiler becomes empty.
3For wedge and cylinder cleaning pockets, allow the
bottle to generate enough steam to activate the
cleaning fabric. Once you see visible steam emitting
through the fabric, your cleaning pocket is ready to
use. Some messes, particularly those that are sticky
may require more moisture, so allow more steam
to generate and exhaust from the cleaning pocket
before cleaning.
WARNING: Your portable Steam Pocket®is
designed to clean surfaces that will withstand
high heat and moisture. Do not use on
unsealed wood surfaces (especially wooden
antique furniture), unglazed ceramic tile, or
surfaces that have been treated with wax,
oils, varnishes, or shellac. The sheen may be
removed by the heat, steam, and friction of
the cleaning tools. Lacquer and polyurethane
coatings provide a hard durable protective
finish that withstands moisture but it is
always recommended to test an isolated
area of the surface to be cleaned before
proceeding. We also recommend you check
the use and care instructions from the surface
manufacturer.
IMPORTANT: Once plugged in, the Blue LED
will illuminate, and your portable Steam
Pocket®cleaning system will be ready to use
within 30 seconds.
NOTE: Make sure surfaces are free of crumbs and
debris before using the portable steam pocket.
Large objects may not be picked up by the Steam
Pocket®and will only be pushed around.

12
CUSTOMER CARE - AU: 1800 890 840
Care of Your Portable Steam Pocket®
CLEANING THE NOZZLES
1 Your portable Steam Pocket®should not normally
require cleaning, however, should you notice a
decrease in the steam output, it may be necessary to
remove mineral deposits built up around the nozzles.
2Unplug the cleaner from the electrical outlet
3Use the provided nozzle cleaner or a small diameter
stiff metal wire, such as a straightened metal
paperclip, and carefully insert the end of the wire
into the nozzle orifice. See illustrations above.
4Move the wire back and forth several times to
remove any deposits.
5Plug in the appliance to the power outlet and test to
note steam output.
STORAGE
1Let the appliance cool down before cleaning or
storing.
2Empty the water tank after each use.
3Store in a cool dry location.
CLEANING THE STEAM BOTTLE
1A periodic rinse of your steam cleaner will help free
it from normal water deposits. This is recommended
every 10-15 fillings to free up any scale deposit. Fill
the reservoir with water and secure the cap. Shake
vigorously for approximately 10-15 times and remove
the cap to empty the reservoir.
Cleaning tip: To prevent clogging, it is recommended
that you periodically clean the Direct Steam Nozzle and
the extension hose stem with the cleaning tool provided
or a paper clip.
WARNING: The hose stem becomes very hot during
operation and can cause burns. Do not operate
the portable Steam Pocket
®
without the proper
cleaning tools attached securely as instructed.
CAUTION: This appliance must be unplugged
from electrical outlet and allowed to cool
down before storage or cleaning.
DECALCIFYING YOUR STEAM BOTTLE
Calcium and mineral deposits can build up and impact
the performance of your steam bottle over time. To
extend the life of your product we recommend that you
use distilled water.
Cleaning tip: To prevent clogging, it is recommended
that you periodically clean the Concentrator Nozzle and
the Accessory Hose stem with the cleaning tool provided
or a paper clip.
CARE OF YOUR CLEANING POCKETS
AND/OR PADS
IMPORTANT: The pocket or pad may be
very hot from the steam. Use caution when
removing. Let the unit cool for 2-3 minutes.
1We recommend washing your pocket or pad
separately from other fabrics to
avoid picking up lint. Only use liquid
detergent (no powder detergent).
Do not use any fabric softeners or
bleach. Line dry. Do not tumble dry.
2If there are loose threads on the cleaning pad
carefully cut the thread with scissors. Do not pull on
them or cut at the base.
40°

13 CUSTOMER CARE - NZ: 0800 002 999
Suggested Uses
KITCHEN CLEANING
Clean and sanitise daily messes in your sinks, microwaves, refrigerators, cookers, food prep areas like
countertops and cutting boards.

14
CUSTOMER CARE - AU: 1800 890 840
BATHROOM CLEANING
Your portable Steam Pocket®can reduce common household bacteria and odours from all corners and areas of
your bathroom, from toilets, sinks, bathtubs, showers, and floors. Wiping grime out of those impossible to reach
spots without harsh chemicals or perfumy residue. Clean all surfaces including glass, mirrors and ceramic tiles.

15 CUSTOMER CARE - NZ: 0800 002 999
Troubleshooting
PROBLEM POSSIBLE REASONS SOLUTIONS
There is no
steam
The Steam Bottle is not plugged in.
There is not enough water in the unit.
Verify that the Blue light is on and the product is
plugged in correctly into a working outlet.
Fill the steam bottle tank.
There is not
enough steam
Mineral build-up may be clogging
thenozzle.
Water level may be low.
Using the nozzle cleaner, carefully clean the nozzle
to remove debris.
Fill the steam bottle tank.
The cleaning
pockets are
streaking or
leaving dirt
behind
The microfibre fabrics may be dirty and
need to be replaced or washed.
The microfibre fabric may be worn.
Use the other sides, if clean.
Replace with a clean cleaning pocket.
Replace as needed.
The cleaning tool
handles keep
falling
off the hose
The connection may not be secure. Check the connection, making sure you are
pressing in and turning at the same time.

16
CUSTOMER CARE - AU: 1800 890 840
Notes

17 CUSTOMER CARE - NZ: 0800 002 999
Notes

18
CUSTOMER CARE - AU: 1800 890 840
ONE (1) YEAR
LIMITED REPLACEMENT WARRANTY STATEMENT
If your product becomes defective due to faulty material or workmanship within a period of 1 year from the date of
purchase, we warrant to do the following:
 • For New Zealand Consumers: We will replace the product with a new product, free of charge, or repair the
product at our cost, at our discretion.
 • For Australian Consumers: Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any
other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not amount to a major failure.
Your warranty is subject to the following conditions:
 • DO NOT operate the appliance with a damaged plug or cord, or if the unit has been dropped, damaged or
dropped in water. To avoid the risk of electric shock, do not disassemble or attempt to repair the appliance on
your own. If the supply cord is damaged, it must be replaced by a qualified electrician in order to avoid
a hazard. Incorrect re-assembly or repair can cause a risk of electrical shock or injury to persons when the
appliance is used.
 • Theproducthasnotbeenmisused,abused,neglected,altered,modiedorrepairedbyanyone.
 • Theproducthasbeensubjectedtofairwearandtear.
 • Theproducthasnotbeenusedfortrade,professionalorhirepurposes.
 • Theproducthasnotsustaineddamagethroughforeignobjects,substancesoraccident.
Your warranty does not cover:
 • Componentsthataresubjecttonaturalwearandtearcausedbynormaluseinaccordancewithoperating
instructions.
 • Unauthorised/impropermaintenance/handlingoroverloadisexcludedfromthiswarranty.
 • Forguaranteeclaimsyouwillneedtosubmitaproofofpurchaseintheformofavalidreceiptthatdisplaysdate
and place of purchase.
This warranty does not replace but is in addition to your statutory rights.
This warranty does not apply to accessories supplied with the product.
This warranty applies only to the original purchaser and may not be transferred.
Replacement products will be covered by the limited warranty for the balance of the warranty period from the date of the
original purchase.
Please note:
Only defective product or parts returned to place of purchase will be replaced under this warranty.
New Zealand Contact: Australia Contact
Brand Developers Limited Brand Developers Aust Pty Ltd
Unit H, 686 Rosebank Road, 461 Plummer Street,
Avondale, 1026 Auckland, New Zealand PORT MELBOURNE, VIC 3207
FAX: [phone] FAX: [phone]
NZ Customer Care 0800 002 999 AUST Customer Care: 1800 890 840

Technical Details
Model number: SC630NZ 11
Main unit voltage: 220-240V~, 50/60Hz
Watts: 1550W
Copyright © Euro-Pro Operating LLC 2015
Euro-Pro, Steam Pocket, and Shark are registered
trademarks of Euro-Pro Operating LLC.
Illustrations may differ from actual product. We
are constantly striving to improve our products,
therefore the specifications contained herein are
subject to change without notice.
SC630NZ_11_1550W_IB_150324_1
GMA-102233-009
IPX4
