Shown with options.

623 mm

1,206 mm

583 mm

MX-2010U

Digital Full Colour Multifunctional System

(tentative)

SPECIFICATIONS

Digital Full Colour Multifunctional System

MX-2010U

Copy Fax

OPTION

Network Print Network Scan Sharpdesk

Be Colour Forward—Make the Switch

to a Compact, Full-Colour Solution

Desktop

Max. 20 cpm/ppm (A4, 8

" x 11", long-edge feeding)

Max. A3 wide (12" x 18"), min. A5R (5

" x 8

"R)

Standard: 600 sheets

(500-sheet tray and 100-sheet multi-bypass tray)

Maximum: 2,100 sheets

Tray: 60 g/m

to 209 g/m

(16 lbs bond to 110 lbs index)

Multi-bypass tray: 55 g/m

to 256 g/m

(13 lbs bond to 140 lbs index)

45 sec.

[Standard] Copy/print (shared): 1GB

[Option] Print: 1.5GB 160GB HDD*

Rated local AC voltage ±10%, 50/60 Hz

1.84 kW (220 to 240V), 1.44 kW (100 to 127V)

583 x 623 x 717 mm (22

" x 24

" x 28

65 kg (143.3 lbs)

Original paper size

First copy time*

Continuous copy

Resolution

Gradation

Zoom range

Preset copy ratios

Max. A3 (11" x 17")

Full colour: 10.2 sec. B/W: 8.8 sec.

Max. 999 copies

Scan (colour): 600 x 600 dpi

Scan (B/W): 600 x 600 dpi, 600 x 400 dpi, 600 x 300 dpi

Print: 9,600 (equivalent) x 600 dpi (depending on print mode),

600 x 600 dpi

Equivalent to 256 levels

25 to 400% (25 to 200% using RSPF) in 1% increments

Metric: 10 ratios (5R/5E), inch: 8 ratios (4R/4E)

B/W Facsimile (optional MX-FX11 required)

Compression method

Communication protocol

Transmission time

Modem speed

Transmission resolution

Recording width

Memory

Grey scale levels

MH/MR/MMR/JBIG

Super G3/G3

Less than 3 seconds*

33,600 bps to 2,400 bps with automatic fallback

From Standard (203.2 x 97.8 dpi) to Ultra Fine (406.4 x 391 dpi)

A3 to A5 (11" x 17" to 5

" x 8

512MB, max. 1GB*

Equivalent to 256 levels

Type

Engine speed

(colour & B/W)

Paper size

Paper capacity

(80 g/m

)

Paper weight

Warm-up time*

Memory

Power requirements

Power consumption

(max.)

Dimensions (W x D x H)*

Weight (approx.)*

General

Copier

Network Printer

Network Scanner

Scan method

Resolution

File formats

Scanner utility

Scan destinations

Push scan (via control panel),

pull scan (TWAIN-compliant application)

Push scan: 100, 200, 300, 400, 600 dpi

Pull scan: 75, 100, 150, 200, 300, 400, 600 dpi

50 to 9,600 dpi via user setting*

TIFF, PDF, encrypted PDF, JPEG (colour only), XPS

Sharpdesk

Scan to e-mail/desktop/FTP server/network folder (SMB)/

USB memory

Resolution

Interface

Supported OS*

Network protocols*

Printing protocols

PDL (emulation)

Available fonts

9,600 (equivalent) x 600 dpi, 600 x 600 dpi

USB 2.0, 10Base-T/100Base-TX/1000Base-T

Windows Server

2003, Windows Server

2008, Windows Server

2012, Windows

2000, Windows

XP, Windows Vista

Windows

7, Windows

8, Mac OS 9.0 to 9.2, Mac OS X 10.2,

10.3, 10.4, 10.5, 10.6, 10.7, 10.8, 10.9

TCP/IP (IPv4, IPv6), IPX/SPX (NetWare), NetBEUI,

EtherTalk (AppleTalk)

LPR, Raw TCP (port 9100), POP3 (e-mail printing), HTTP,

Novell Printserver application with NDS and Bindery,

FTP for downloading print files, EtherTalk printing, IPP

Standard: Sharp Advanced Printing Language-c

Option*

: PCL 6 emulation, PostScript

™

emulation, XPS

80 fonts for PCL, 136 fonts for PostScript 3 emulation

* 1 : At rated voltage, 23°C (73.4°F). May vary depending on operating conditions and environment.

* 2 : HDD capacity depends on procurement and sourcing status.

* 3 : Including document cover.

* 4 : Long-edge feeding of A4 (8 1/2" x 11") sheets from 1st paper tray, using document glass, without Auto

Colour Selection and Auto Colour mode, MFP in fully ready condition. May vary depending on operating

conditions and environment.

* 5 : Resolutions higher than 600 dpi are interpolated.

* 6 : Storage capacity will vary depending on the type of document and the scan settings.

* 7 : Some features require option(s).

* 8 : Optional MX-PK11 required for Mac OS and EtherTalk.

* 9 :

PCL requires optional MX-HD10 and MX-PB14. PostScript 3 requires optional MX-HD10, MX-PK11, and

MX-PB14. XPS requires optional MX-HD10, MX-PUX1, MX-PB14, and MX-SM10 (1GB).

*10: Based on Sharp’s standard chart with approx. 700 characters (A4 or 8 1/2" x 11" long-edge feeding) at

standard resolution in Super G3 mode, 33,600 bps, JBIG compression.

*11: Optional MX-HD10 required.

Document Filing (optional MX-HD10 required)

Document filing

capacity*

Stored jobs*

Storage folders

Confidential storage

Main and custom folders: 20,000 pages or 3,000 files

Quick file folder: 10,000 pages or 1,000 files

Copy, print, scan, fax transmission

Quick file folder, main folder, custom folder (max. 1,000 folders)

Password protection

• Design and specifications are subject to change without prior notice.

• PCL is a registered trademark of Hewlett-Packard Company. PostScript 3 is either a registered trademark or trademark

of Adobe Systems Incorporated in the US and/or other countries. Windows, Windows Server, Windows Vista, Excel, and

PowerPoint are registered trademarks of Microsoft Corporation in the US and/or other countries. Macintosh, Mac OS,

EtherTalk, and AppleTalk are trademarks of Apple Inc., registered in the US and other countries. All other brand names

and product names may be trademarks or registered trademarks of their respective owners.

Distributed by:

Get the Colour-Capable Advantage

There’s no easier way to add impact to business

communications than with the high-quality colour of the

MX-2010U. This compact, energy-efficient A3 MFP

provides all the essential copy, print, and network scan

functions—in full colour—as well as a convenient fax

option.

The productivity-boosting MX-2010U delivers fast

20-page-per-minute output in both colour and B/W and

offers superb print quality via the upgraded

second-generation Mycrostoner-HG. The optional

100-sheet RSPF (reversing single pass feeder) enhances

the effectiveness of the MX-2010U’s built-in stackless

duplex module. And the HDD option brings greater

efficiency by enabling such advanced functions as

integrated document management for enhanced

workflow, third-party creation of customised

applications via the Sharp OSA (Open Systems

Architecture) option, and reliable data protection via the

Data Security Kit option.

In the way of energy-saving performance, the

MX-2010U offers such eco advantages as a short

warm-up time and low power consumption in standby

mode. And for added convenience, the MX-2010U boasts

a lightweight, space-saving frame.

The MX-2010U is an attractive, user-friendly addition to

any workplace. Designed for easy navigation, the control

panel features a 7.0-inch W-VGA touch-screen colour

LCD that offers a choice of six screen colours and

provides both thumbnail display and data file previews.

Style, Function, and Ease of Use

Get the Colour-Capable Advantage

There’s no easier way to add impact to business

communications than with the high-quality colour of the

MX-2010U. This compact, energy-efficient A3 MFP

provides all the essential copy, print, and network scan

functions—in full colour—as well as a convenient fax

option.

The productivity-boosting MX-2010U delivers fast

20-page-per-minute output in both colour and B/W and

offers superb print quality via the upgraded

second-generation Mycrostoner-HG. The optional

100-sheet RSPF (reversing single pass feeder) enhances

the effectiveness of the MX-2010U’s built-in stackless

duplex module. And the HDD option brings greater

efficiency by enabling such advanced functions as

integrated document management for enhanced

workflow, third-party creation of customised

applications via the Sharp OSA (Open Systems

Architecture) option, and reliable data protection via the

Data Security Kit option.

In the way of energy-saving performance, the

MX-2010U offers such eco advantages as a short

warm-up time and low power consumption in standby

mode. And for added convenience, the MX-2010U boasts

a lightweight, space-saving frame.

The MX-2010U is an attractive, user-friendly addition to

any workplace. Designed for easy navigation, the control

panel features a 7.0-inch W-VGA touch-screen colour

LCD that offers a choice of six screen colours and

provides both thumbnail display and data file previews.

Style, Function, and Ease of Use

Job Finishing Options

Stapling Hole punching

Copy

CPM

PPM

CPM

PPM

Auto Colour Mode

Windmills of the Netherlands

For centuries, the Dutch used windmills

to mill corn into flour, drain water from

the land, cut timber into boards, and

carry out various other industrial tasks.

At one time, over 9,000 windmills dotted

the Dutch countryside. And, although

that number has dwindled down to just

over a thousand, many people still

associate the Netherlands with its

majestic windmills.

To harness the power of the wind, the

Dutch built a variety of windmills, with the name of each type determined by the

construction, appearance, or function of the mill. These mills sported a somewhat primitive

design that used canvas sails and that, unlike their more automated British counterparts,

had to be turned by hand to face the wind.

Auto recognition

Windmills of the Netherlands

For centuries, the Dutch used windmills

to mill corn into flour, drain water from

the land, cut timber into boards, and

carry out various other industrial tasks.

At one time, over 9,000 windmills dotted

the Dutch countryside. And, although

that number has dwindled down to just

over a thousand, many people still

associate the Netherlands with its

majestic windmills.

To harness the power of the wind, the

Dutch built a variety of windmills, with the name of each type determined by the

construction, appearance, or function of the mill. These mills sported a somewhat primitive

design that used canvas sails and that, unlike their more automated British counterparts,

had to be turned by hand to face the wind.

TEXT PHOTO

Text comes out

crisp and clear

MX-2010

stored in memory

in proper page order...

...and stacked offsetMulti-page original is scanned...

(or print data sent from PC)

MX-2010

Macintosh

Ethernet

(10Base-T/100Base-TX/1000Base-T)

Windows®

Windows Server®

2-in-1 copying (preview)

COPYING & NETWORK PRIN

TING

PRODUCTIVE

SUPERB PRINT QUALITY

VERSATILE

Super-Efficient Colour and B/W Output

The tandem printing engine with four in-line drums helps the

MX-2010U deliver a fast output of 20 cpm/ppm* in full colour

and in B/W. And the first copy comes out in just 10.2 seconds in

full colour and 8.8 seconds in B/W. What’s more, its short, straight

paper path minimises misfeeds to save you

paper and toner costs.

* A4 (8 1/2" x 11"), long-edge feeding

Productive Collated Output from Memory

The MX-2010U’s Scan Once/Print Many function only requires a

single scan of a multi-page original for copying, and the RIP

Once/Print Many function only needs to download print data once

from the PC for printing. The machine then automatically saves

the data into memory and outputs collated sets of copies or

printouts in the proper page order (electronic sorting), with each

set offset stacked for easier retrieval.

Built-In Stackless Duplex Module

The MX-2010U can make two-sided copies and printouts using

its built-in stackless duplex module, effectively reducing paper

costs as well as saving filing space. Duplex copying is even more

effective when the duplex module is used together with the

optional 100-sheet RSPF (reversing single pass feeder), which

efficiently feeds in either one- or two-sided originals.

Job Build for Large-Volume Scanning

The MX-2010U easily handles large-volume copy jobs exceeding

the RSPF’s 100-sheet*1capacity. For example, a 270-sheet original

can be scanned as batches of 100 + 100 + 70 sheets and

automatically stored on the MX-2010U’s hard disk*2. Users can

then print the entire document in a single run.

*1: A4 (8 1/2" x 11"), 80 g/m2

*2: Requires optional MX-HD10. The number of pages that can be stored

for the Job Build function depends on the machine’s HDD capacity and

other conditions.

Supports Most Office Environments

• The MX-2010U works as a network printer with the latest and most

commonly used operating systems and network protocols, including

IPv6, and even in mixed OS environments. You get fast, powerful

network printing via the 1000Base-T Gigabit Ethernet standard.

• The MX-2010U supports the PCL 6 printer language.* For

compatibility with PostScript®3™, the MX-PK11 PS3 Expansion Kit

is available.*

* Requires optional MX-HD10 and MX-PB14.

Automated Finishing

The MX-2010U automates time-consuming finishing tasks and

makes it easy to create professional-looking booklets. For a

consistent, polished look, the chapter divide* function prints

documents so that all chapters begin on odd-numbered pages or

all begin on even-numbered pages. A space-efficient Finisher is

available for jobs that require sorting and stapling. And, an

optional Punch Module allows you to punch holes in documents

for easy filing.

* Requires optional MX-HD10 and MX-PB14.

Large Paper Capacity

For high-volume work, the MX-2010U can accommodate an

optional stand with 3 x 500-sheet paper drawers for a total

capacity of 2,100 sheets. When a tray

runs out of paper, the Auto Tray

Switching function automatically

switches to another paper tray filled

with the same size paper, allowing

you to do extra-large volume jobs

without worry.

Network Tandem Function*

When two MX-2010Us are connected to the same office network,

you can use both simultaneously to double copying/printing

output to up to 40 cpm/ppm. Large-volume jobs can be

completed with ease, enabling you to meet tight deadlines.

* Requires optional MX-HD10 and MX-PB14.

Convenient Copy Previews*

To prevent errors in copying, the

MX-2010U shows previews of copy

jobs on its LCD before actually

executing them. And with previews,

it’s easy to confirm finishing options,

scan settings, and other such items.

* Requires optional MX-HD10.

NETWORK-READY

USB Memory Direct Print*

One of the two USB ports on the MX-2010U is located at the front

of the MFP beneath the control panel. It comes in handy when

printing data directly from USB memory

devices—an indispensable function for

users who are in a hurry or who want

quick machine access without a PC.

* Requires optional MX-HD10 and MX-PB14.

Versatile Paper Handling

The MX-2010U accommodates a wide range of paper sizes, from

A5R (5 1/2" x 8 1/2"R) to A3 wide (12" x 18"). When using an

optional finisher or exit tray, you can do A3 (11" x 17") full-bleed

printing onto A3-wide (12" x 18") paper, without loss of image

area. And the MX-2010U can handle heavy paper stock up to 256

g/m2, overhead transparencies, and other types of paper, further

expanding the range of printing applications.

Image Editing Functions

The MX-2010U includes colourful editing functions made possible

by digital technology.

• Multi-Page Enlargement divides an image onto separate

sheets for making posters up to A0 x 2 (44" x 68") in size.

• Photo Repeat places multiple copies of an image onto a single

sheet.

• Mirror Image makes a reverse image of the original.

• XY Zoom adjusts the horizontal and vertical ratios independently.

• B/W Reverse reverses the black and white of an image.

Please see specifications for a list of available convenient functions.

Various Copy/Print Applications

Copy & Print

• Watermark*1prints a user-selected watermark, such as

“Urgent,” on each page to indicate the status of the document.

• Tab Copy / Tab Print*2can copy or print directly onto tabs on

document separators and insert them into assigned positions.

• Multi-Shot copying and N-up printing

• Pamphlet Style copying/printing

• Cover/transparency insertion

*1: Requires optional MX-HD10. *2: Tab print requires optional MX-HD10 and MX-PB14.

• Direct Print*1allows PDF*2, TIFF, JPEG, or XPS*3files to be

printed without using the printer driver or opening applications.

• Carbon Copy Print mode automatically outputs multiple

printouts of the same data on plain and/or coloured paper;

convenient for invoices and purchase orders.

• Form Overlay can store office document formatting such as

letterheads and overlay contents in colour, eliminating the need

for pre-printed paper.

• Barcode font compatibility*4

Note: The above functions require optional MX-HD10 and MX-PB14.

*1: Direct printing may not support all PDF, TIFF, JPEG, and XPS formats. *2: Direct

PDF printing requires optional MX-PK11. *3: Direct XPS printing requires optional

MX-PUX1 and MX-SM10. *4: Requires optional MX-PF10.

Copy

• Book Copy is convenient for compiling copies of a book or

bound originals into pamphlet format.

• Card Shot enables one-touch copying of both sides of a card

(credit cards, ID cards, etc.) onto a single page.

• Colour Stamp labels your copies with page numbers, the date

or text such as “Urgent” in up to four different colours.

• Mixed Size Original Copy mode automatically distinguishes

documents of mixed sizes* (such as A3/B4, B4/A4, etc.) fed

through the RSPF and chooses the appropriate paper.

* Some restrictions apply when combining paper sizes of different format series.

Improved Imaging System

Sharp thoroughly revamped its imaging process for the

MX-2010U; now a high-performance processor, a new developer,

and the second-generation Mycrostoner-HG (High Grade)

combine to provide breathtaking image quality. The new toner

expands the colour reproducibility range for a more natural

rendering of clear blue skies, emerald green oceans, and other

colour images. And the smaller particle size of the toner and the

developer allows for reduced graininess and clear reproduction of

fine lines, fine text, and halftone colours.

Crisp, Clear Text and Images

Employing digital smoothing technology enhances the print

resolution to the equivalent of 9,600 x 600 dpi for incredibly

smooth reproduction of fine lines. Fine-grained photographs,

detailed illustrations and graphs, and small text come out crisp and

clear.

High-Quality Page Description Language

To ensure high-quality image processing, the MX-2010U uses Sharp’s

original Sharp Advanced Printing Language-c, a new page description

language (PDL) that delivers superb performance and print quality. The

MX-2010U is also compatible with PCL 6 and PostScript 3 (option).

Easy, High-Quality Copying

Auto Colour Selection automatically determines whether a page is

colour or B/W and selects the appropriate copy mode for that page.

Auto Colour Mode analyses the contents of each page,

distinguishing between different components, such as photos and

text. These are what allow the MX-2010U to print out maps with

crisp, clear text and to automatically remove the background colour

on newspaper and magazine copies for clearer output.

Job Finishing Options

Stapling Hole punching

Copy

CPM

PPM

CPM

PPM

Auto Colour Mode

Windmills of the Netherlands

For centuries, the Dutch used windmills

to mill corn into flour, drain water from

the land, cut timber into boards, and

carry out various other industrial tasks.

At one time, over 9,000 windmills dotted

the Dutch countryside. And, although

that number has dwindled down to just

over a thousand, many people still

associate the Netherlands with its

majestic windmills.

To harness the power of the wind, the

Dutch built a variety of windmills, with the name of each type determined by the

construction, appearance, or function of the mill. These mills sported a somewhat primitive

design that used canvas sails and that, unlike their more automated British counterparts,

had to be turned by hand to face the wind.

Auto recognition

Windmills of the Netherlands

For centuries, the Dutch used windmills

to mill corn into flour, drain water from

the land, cut timber into boards, and

carry out various other industrial tasks.

At one time, over 9,000 windmills dotted

the Dutch countryside. And, although

that number has dwindled down to just

over a thousand, many people still

associate the Netherlands with its

majestic windmills.

To harness the power of the wind, the

Dutch built a variety of windmills, with the name of each type determined by the

construction, appearance, or function of the mill. These mills sported a somewhat primitive

design that used canvas sails and that, unlike their more automated British counterparts,

had to be turned by hand to face the wind.

TEXT PHOTO

Text comes out

crisp and clear

MX-2010

stored in memory

in proper page order...

...and stacked offsetMulti-page original is scanned...

(or print data sent from PC)

MX-2010

Macintosh

Ethernet

(10Base-T/100Base-TX/1000Base-T)

Windows®

Windows Server®

2-in-1 copying (preview)

COPYING & NETWORK PRIN

TING

PRODUCTIVE

SUPERB PRINT QUALITY

VERSATILE

Super-Efficient Colour and B/W Output

The tandem printing engine with four in-line drums helps the

MX-2010U deliver a fast output of 20 cpm/ppm* in full colour

and in B/W. And the first copy comes out in just 10.2 seconds in

full colour and 8.8 seconds in B/W. What’s more, its short, straight

paper path minimises misfeeds to save you

paper and toner costs.

* A4 (8 1/2" x 11"), long-edge feeding

Productive Collated Output from Memory

The MX-2010U’s Scan Once/Print Many function only requires a

single scan of a multi-page original for copying, and the RIP

Once/Print Many function only needs to download print data once

from the PC for printing. The machine then automatically saves

the data into memory and outputs collated sets of copies or

printouts in the proper page order (electronic sorting), with each

set offset stacked for easier retrieval.

Built-In Stackless Duplex Module

The MX-2010U can make two-sided copies and printouts using

its built-in stackless duplex module, effectively reducing paper

costs as well as saving filing space. Duplex copying is even more

effective when the duplex module is used together with the

optional 100-sheet RSPF (reversing single pass feeder), which

efficiently feeds in either one- or two-sided originals.

Job Build for Large-Volume Scanning

The MX-2010U easily handles large-volume copy jobs exceeding

the RSPF’s 100-sheet*1capacity. For example, a 270-sheet original

can be scanned as batches of 100 + 100 + 70 sheets and

automatically stored on the MX-2010U’s hard disk*2. Users can

then print the entire document in a single run.

*1: A4 (8 1/2" x 11"), 80 g/m2

*2: Requires optional MX-HD10. The number of pages that can be stored

for the Job Build function depends on the machine’s HDD capacity and

other conditions.

Supports Most Office Environments

• The MX-2010U works as a network printer with the latest and most

commonly used operating systems and network protocols, including

IPv6, and even in mixed OS environments. You get fast, powerful

network printing via the 1000Base-T Gigabit Ethernet standard.

• The MX-2010U supports the PCL 6 printer language.* For

compatibility with PostScript®3™, the MX-PK11 PS3 Expansion Kit

is available.*

* Requires optional MX-HD10 and MX-PB14.

Automated Finishing

The MX-2010U automates time-consuming finishing tasks and

makes it easy to create professional-looking booklets. For a

consistent, polished look, the chapter divide* function prints

documents so that all chapters begin on odd-numbered pages or

all begin on even-numbered pages. A space-efficient Finisher is

available for jobs that require sorting and stapling. And, an

optional Punch Module allows you to punch holes in documents

for easy filing.

* Requires optional MX-HD10 and MX-PB14.

Large Paper Capacity

For high-volume work, the MX-2010U can accommodate an

optional stand with 3 x 500-sheet paper drawers for a total

capacity of 2,100 sheets. When a tray

runs out of paper, the Auto Tray

Switching function automatically

switches to another paper tray filled

with the same size paper, allowing

you to do extra-large volume jobs

without worry.

Network Tandem Function*

When two MX-2010Us are connected to the same office network,

you can use both simultaneously to double copying/printing

output to up to 40 cpm/ppm. Large-volume jobs can be

completed with ease, enabling you to meet tight deadlines.

* Requires optional MX-HD10 and MX-PB14.

Convenient Copy Previews*

To prevent errors in copying, the

MX-2010U shows previews of copy

jobs on its LCD before actually

executing them. And with previews,

it’s easy to confirm finishing options,

scan settings, and other such items.

* Requires optional MX-HD10.

NETWORK-READY

USB Memory Direct Print*

One of the two USB ports on the MX-2010U is located at the front

of the MFP beneath the control panel. It comes in handy when

printing data directly from USB memory

devices—an indispensable function for

users who are in a hurry or who want

quick machine access without a PC.

* Requires optional MX-HD10 and MX-PB14.

Versatile Paper Handling

The MX-2010U accommodates a wide range of paper sizes, from

A5R (5 1/2" x 8 1/2"R) to A3 wide (12" x 18"). When using an

optional finisher or exit tray, you can do A3 (11" x 17") full-bleed

printing onto A3-wide (12" x 18") paper, without loss of image

area. And the MX-2010U can handle heavy paper stock up to 256

g/m2, overhead transparencies, and other types of paper, further

expanding the range of printing applications.

Image Editing Functions

The MX-2010U includes colourful editing functions made possible

by digital technology.

• Multi-Page Enlargement divides an image onto separate

sheets for making posters up to A0 x 2 (44" x 68") in size.

• Photo Repeat places multiple copies of an image onto a single

sheet.

• Mirror Image makes a reverse image of the original.

• XY Zoom adjusts the horizontal and vertical ratios independently.

• B/W Reverse reverses the black and white of an image.

Please see specifications for a list of available convenient functions.

Various Copy/Print Applications

Copy & Print

• Watermark*1prints a user-selected watermark, such as

“Urgent,” on each page to indicate the status of the document.

• Tab Copy / Tab Print*2can copy or print directly onto tabs on

document separators and insert them into assigned positions.

• Multi-Shot copying and N-up printing

• Pamphlet Style copying/printing

• Cover/transparency insertion

*1: Requires optional MX-HD10. *2: Tab print requires optional MX-HD10 and MX-PB14.

• Direct Print*1allows PDF*2, TIFF, JPEG, or XPS*3files to be

printed without using the printer driver or opening applications.

• Carbon Copy Print mode automatically outputs multiple

printouts of the same data on plain and/or coloured paper;

convenient for invoices and purchase orders.

• Form Overlay can store office document formatting such as

letterheads and overlay contents in colour, eliminating the need

for pre-printed paper.

• Barcode font compatibility*4

Note: The above functions require optional MX-HD10 and MX-PB14.

*1: Direct printing may not support all PDF, TIFF, JPEG, and XPS formats. *2: Direct

PDF printing requires optional MX-PK11. *3: Direct XPS printing requires optional

MX-PUX1 and MX-SM10. *4: Requires optional MX-PF10.

Copy

• Book Copy is convenient for compiling copies of a book or

bound originals into pamphlet format.

• Card Shot enables one-touch copying of both sides of a card

(credit cards, ID cards, etc.) onto a single page.

• Colour Stamp labels your copies with page numbers, the date

or text such as “Urgent” in up to four different colours.

• Mixed Size Original Copy mode automatically distinguishes

documents of mixed sizes* (such as A3/B4, B4/A4, etc.) fed

through the RSPF and chooses the appropriate paper.

* Some restrictions apply when combining paper sizes of different format series.

Improved Imaging System

Sharp thoroughly revamped its imaging process for the

MX-2010U; now a high-performance processor, a new developer,

and the second-generation Mycrostoner-HG (High Grade)

combine to provide breathtaking image quality. The new toner

expands the colour reproducibility range for a more natural

rendering of clear blue skies, emerald green oceans, and other

colour images. And the smaller particle size of the toner and the

developer allows for reduced graininess and clear reproduction of

fine lines, fine text, and halftone colours.

Crisp, Clear Text and Images

Employing digital smoothing technology enhances the print

resolution to the equivalent of 9,600 x 600 dpi for incredibly

smooth reproduction of fine lines. Fine-grained photographs,

detailed illustrations and graphs, and small text come out crisp and

clear.

High-Quality Page Description Language

To ensure high-quality image processing, the MX-2010U uses Sharp’s

original Sharp Advanced Printing Language-c, a new page description

language (PDL) that delivers superb performance and print quality. The

MX-2010U is also compatible with PCL 6 and PostScript 3 (option).

Easy, High-Quality Copying

Auto Colour Selection automatically determines whether a page is

colour or B/W and selects the appropriate copy mode for that page.

Auto Colour Mode analyses the contents of each page,

distinguishing between different components, such as photos and

text. These are what allow the MX-2010U to print out maps with

crisp, clear text and to automatically remove the background colour

on newspaper and magazine copies for clearer output.

Scan

Fa x

Scan

Fa x

Scan

Fa x

Scan

Fa x

Output settings for received faxes

A A AB

Prevents data leak

Data Security SystemIP/MAC Address Filtering

Unknown IP or MAC

addresses will be

denied access

NO!

OK Copy DataPrint Data

Scan Data Fax Data

TOP SECRET

Data Encryption Data Erase

d0bN%

=5!”//?

hj5&4

mk9#¥

The data generated

for each job is

automatically erased

once that job is

finished

DesktopSuper G3 fax

Client PCs

Internet

Network folderUSB memory

E-mail

Internet fax

FTP server

Scan to

Scan

Document

Confidential document

with copy prevention data

Unauthorised attempt

to make a copy

Results in a blank page

ABC

Example: Unauthorised copying

User authentication

IMAGE SENDING

A3 Colour Network Scanning

The MX-2010U works as a full-colour network scanner. Converting

any type of paper-based document, up to A3 (11" x 17") in size, into

an editable digital file is as easy as making a copy. The MX-2010U

supports TIFF, PDF, encrypted PDF, XPS, and JPEG file formats.

Enhanced scan performance improves the legibility of extremely fine

text and allows vivid colour reproduction in scanned documents. And

Auto Colour Selection chooses the right mode for scanning

originals containing both colour and B/W pages (see page 4).

Quick Scanning

For both colour*1and B/W documents, the MX-2010U carries out

scanning at the impressive speed of 50 opm*2(originals per minute)

and can complete large scan jobs with ease and efficiency.

*1: Faxing is available in B/W only. *2: Single-side scanning

Multiple Distribution of Scanned Files

With the touch of a few on-screen buttons, you can choose different

ways to distribute your scanned documents. Scan to E-mail sends

documents as an e-mail attachment. Scan to FTP Server scans

documents directly to an FTP server for storage. Scan to Desktop

sends scanned documents directly to your PC desktop. Scan to

Network Folder (SMB) sends files to a shared folder on a

networked Windows PC. Scan to USB Memory scans documents

directly to USB memory devices. And Scan to Fax enables

conventional faxing or Internet faxing.

LDAP Support

Built-in LDAP (lightweight directory access protocol) support

eliminates the need to enter or register full addresses. By entering

the first few letters of the recipient’s

name, the MX-2010U displays a list of

possible matches from your company’s

LDAP server. Selected addresses can be

stored to the MX-2010U’s address book.

High-Speed Faxing

The optional MX-FX11 Fax Expansion Kit turns the MX-2010U into a

33.6 Kbps Super G3 fax machine. Using JBIG compression

technology, the MX-2010U can send an A4 (8 1/2" x 11") size page

in under 3 seconds*. Use the 100-sheet RSPF to further boost faxing

efficiency. And, because Quick On-Line Transmission can start

dialling and transmitting as soon as the first page is scanned into

memory, you can send documents in much less time.

* Based on Sharp’s standard chart with approximately 700 characters (A4 or 8

1/2" x 11" long-edge feeding) at standard resolution.

Automated Fax Finishing

The MX-2010U eliminates the need to copy and staple received

faxes by hand. Simply use the Fax Output setting on the LCD

control panel to designate the number of copies. With finishing

options installed, the

MX-2010U will even

automatically staple these

documents for you.

PC-Fax/PC-Internet Fax

Directly send a document created on your PC to a recipient’s fax

machine via a phone line or the Internet without printing to paper.

Save time and paper costs while retaining original document quality.

Note: PC-Internet Fax requires optional MX-HD10 and MX-FWX1; PC-Fax

requires MX-FX11.

Internet Fax

Economically send and receive faxes to and from other ITU-T

T-37-compliant Internet fax machines via the Internet. The

MX-2010U supports Direct SMTP; outgoing Internet faxes do not

go through your mail server, making transmission faster and

cheaper.

Note: Requires optional MX-HD10 and MX-FWX1.

Paperless Faxing with Inbound Routing

Paperless faxing with inbound routing lets you check incoming

faxes via e-mail before printing. It can also forward incoming faxes

to another fax/Internet fax machine, an FTP server, a network folder

(SMB), or a PC desktop. Files can be saved in either PDF or TIFF

(single/multi).

Note: Requires optional MX-HD10 and MX-FX11 or MX-FWX1.

Skip Blank Page Function

When scanning and sending a multi-page document, the

MX-2010U automatically recognises and skips over any pages

without content, reducing both data size and transmission time.

Other Key Features

Scan & Fax

• One-touch auto dial keys register up to 1,000 numbers for

frequently used destinations

• Broadcast transmission to up to 500 destinations

• Program keys (up to 48 keys) are available to set up

frequently used transmissions for instant recall

• Easy text entry* lets you enter addresses, file names, subject

titles or messages from the LCD control panel

* Only addresses can be entered for faxing.

• Mixed size original scanning automatically distinguishes

documents of mixed sizes fed through the RSPF

Fax

• Duplex transmission/reception sends and prints out

two-sided documents

• SD memory card backup ensures documents remain safely

backed up in memory, even in the event of a power failure

• Rotation transmission/reception rotates incoming and

outgoing faxes to match the direction of the printing paper

• Fax destination confirmation allows users to reconfirm fax

numbers before sending to prevent transmission errors

SECURITY

Industry-Leading Multi-Layered Security

With multiple levels of network and data security to cover a wide range of security needs, Sharp’s industry-leading

security solutions protect your business assets and bring peace of mind. The MX-2010U safeguards sensitive data with

powerful, enhanced security functions that eliminate the worry of unauthorised use and guarantee greater protection for

your confidential information.

Data Security Kit

Digital copier/printers or MFPs can retain hundreds of pages of

confidential information from previous jobs on their hard disks or

internal memory. To safeguard this information from unauthorised

access, the optional Data

Security Kit

automatically encrypts

and erases the data after

each job is complete as

well as data stored both

on the hard disk and in

the address book.

Note: Requires optional

MX-HD10.

Encrypted PDF with Password Protection

To prevent unauthorised viewing of confidential image data, the

MX-2010U enables users to password protect and encrypt PDF

data. By setting a password when scanning, users can transmit a

PDF over the network in encrypted format. Then, after

transmission, viewers will only gain access to the encrypted PDF

after successfully re-entering the chosen password.

Note: Direct printing of encrypted PDF files requires optional MX-HD10,

MX-PB14, and MX-PK11.

Document Control Function

Document Control prevents unauthorised copying, scanning,

faxing, and filing of confidential documents. This is how it works:

the MX-2010U embeds copy prevention data onto a document

when it is first copied or printed. It will then detect this data the

next time someone tries to make a copy of the document. Any

unauthorised attempts to copy a Document Controlled-document

will simply be cancelled or result in the output of a blank page.

Note: Requires optional MX-HD10 and Data Security Kit. May not work for

certain types of documents or paper.

Data Initialisation

The MX-2010U’s initialisation function allows confidential

information to be erased at the administrator’s discretion via the

MFP’s system setting. Initialising an MFP when it’s taken out of

service prevents important resources, such as customer

information and intellectual property, from leaking out and

provides considerable peace of mind.

Secure Network Access

The MX-2010U’s IP/MAC address filtering function provides

highly secure operation by restricting access to the MX-2010U on

your office network. Only PCs that have either their IP address or

MAC (media access control) address

registered are allowed to use the

MX-2010U. Attempted access from

an unknown IP or MAC address will

be denied, preventing unauthorised

use. The MX-2010U also supports

the IEEE 802.1X standard for

port-based network access control,

which blocks all access from

unauthorised devices.

Secure Sockets Layer

SSL (secure sockets layer) enables the encryption of data

communications to prevent data leakage through the network

when printing via IPP, browsing secure Web pages (HTTPS), or

communicating via e-mail (SMTP and POP3) or FTP (FTPS).

User Authentication

The MX-2010U prevents unauthorised use by requiring

passwords for machine access. This safeguarded solution can

User, or Guest and can designate to which function user

authentication applies. The MX-2010U can, for example, be set to

allow B/W copying by all users while

restricting colour copying to

designated users. And the

MX-2010U works with an external

Active Directory server to extend

user authentication to multiple MFPs

and a greater number of users.

IPv6 and IPsec Support

The MX-2010U supports the IPv6 Internet protocol. An obligatory

part of IPv6 is IPsec (IP Security), a set of protocols for securing

Internet protocol (IP) communications. IPsec encrypts and

authenticates traffic between specified parties, giving

IPsec-compatible products an extremely high level of network

security.

Scan to Me Function

Scan to Me lets a logged-in authorised user send scanned data to

his/her own e-mail address simply by pressing the start button. This

eliminates the need to manually enter or select the address, thereby

preventing documents from being sent to the wrong address.

Scan

Fa x

Scan

Fa x

Scan

Fa x

Scan

Fa x

Output settings for received faxes

AAAB

Prevents data leak

Data Security SystemIP/MAC Address Filtering

Unknown IP or MAC

addresses will be

denied access

NO!

OK Copy DataPrint Data

Scan Data Fax Data

TOP SECRET

Data Encryption Data Erase

d0bN%

=5!”//?

hj5&4

mk9#¥

The data generated

for each job is

automatically erased

once that job is

finished

DesktopSuper G3 fax

Client PCs

Internet

Network folderUSB memory

E-mail

Internet fax

FTP server

Scan to

Scan

Document

Confidential document

with copy prevention data

Unauthorised attempt

to make a copy

Results in a blank page

ABC

Example: Unauthorised copying

User authentication

IMAGE SENDING

A3 Colour Network Scanning

The MX-2010U works as a full-colour network scanner. Converting

any type of paper-based document, up to A3 (11" x 17") in size, into

an editable digital file is as easy as making a copy. The MX-2010U

supports TIFF, PDF, encrypted PDF, XPS, and JPEG file formats.

Enhanced scan performance improves the legibility of extremely fine

text and allows vivid colour reproduction in scanned documents. And

Auto Colour Selection chooses the right mode for scanning

originals containing both colour and B/W pages (see page 4).

Quick Scanning

For both colour*1and B/W documents, the MX-2010U carries out

scanning at the impressive speed of 50 opm*2(originals per minute)

and can complete large scan jobs with ease and efficiency.

*1: Faxing is available in B/W only. *2: Single-side scanning

Multiple Distribution of Scanned Files

With the touch of a few on-screen buttons, you can choose different

ways to distribute your scanned documents. Scan to E-mail sends

documents as an e-mail attachment. Scan to FTP Server scans

documents directly to an FTP server for storage. Scan to Desktop

sends scanned documents directly to your PC desktop. Scan to

Network Folder (SMB) sends files to a shared folder on a

networked Windows PC. Scan to USB Memory scans documents

directly to USB memory devices. And Scan to Fax enables

conventional faxing or Internet faxing.

LDAP Support

Built-in LDAP (lightweight directory access protocol) support

eliminates the need to enter or register full addresses. By entering

the first few letters of the recipient’s

name, the MX-2010U displays a list of

possible matches from your company’s

LDAP server. Selected addresses can be

stored to the MX-2010U’s address book.

High-Speed Faxing

The optional MX-FX11 Fax Expansion Kit turns the MX-2010U into a

33.6 Kbps Super G3 fax machine. Using JBIG compression

technology, the MX-2010U can send an A4 (8 1/2" x 11") size page

in under 3 seconds*. Use the 100-sheet RSPF to further boost faxing

efficiency. And, because Quick On-Line Transmission can start

dialling and transmitting as soon as the first page is scanned into

memory, you can send documents in much less time.

* Based on Sharp’s standard chart with approximately 700 characters (A4 or 8

1/2" x 11" long-edge feeding) at standard resolution.

Automated Fax Finishing

The MX-2010U eliminates the need to copy and staple received

faxes by hand. Simply use the Fax Output setting on the LCD

control panel to designate the number of copies. With finishing

options installed, the

MX-2010U will even

automatically staple these

documents for you.

PC-Fax/PC-Internet Fax

Directly send a document created on your PC to a recipient’s fax

machine via a phone line or the Internet without printing to paper.

Save time and paper costs while retaining original document quality.

Note: PC-Internet Fax requires optional MX-HD10 and MX-FWX1; PC-Fax

requires MX-FX11.

Internet Fax

Economically send and receive faxes to and from other ITU-T

T-37-compliant Internet fax machines via the Internet. The

MX-2010U supports Direct SMTP; outgoing Internet faxes do not

go through your mail server, making transmission faster and

cheaper.

Note: Requires optional MX-HD10 and MX-FWX1.

Paperless Faxing with Inbound Routing

Paperless faxing with inbound routing lets you check incoming

faxes via e-mail before printing. It can also forward incoming faxes

to another fax/Internet fax machine, an FTP server, a network folder

(SMB), or a PC desktop. Files can be saved in either PDF or TIFF

(single/multi).

Note: Requires optional MX-HD10 and MX-FX11 or MX-FWX1.

Skip Blank Page Function

When scanning and sending a multi-page document, the

MX-2010U automatically recognises and skips over any pages

without content, reducing both data size and transmission time.

Other Key Features

Scan & Fax

• One-touch auto dial keys register up to 1,000 numbers for

frequently used destinations

• Broadcast transmission to up to 500 destinations

• Program keys (up to 48 keys) are available to set up

frequently used transmissions for instant recall

• Easy text entry* lets you enter addresses, file names, subject

titles or messages from the LCD control panel

* Only addresses can be entered for faxing.

• Mixed size original scanning automatically distinguishes

documents of mixed sizes fed through the RSPF

Fax

• Duplex transmission/reception sends and prints out

two-sided documents

• SD memory card backup ensures documents remain safely

backed up in memory, even in the event of a power failure

• Rotation transmission/reception rotates incoming and

outgoing faxes to match the direction of the printing paper

• Fax destination confirmation allows users to reconfirm fax

numbers before sending to prevent transmission errors

SECURITY

Industry-Leading Multi-Layered Security

With multiple levels of network and data security to cover a wide range of security needs, Sharp’s industry-leading

security solutions protect your business assets and bring peace of mind. The MX-2010U safeguards sensitive data with

powerful, enhanced security functions that eliminate the worry of unauthorised use and guarantee greater protection for

your confidential information.

Data Security Kit

Digital copier/printers or MFPs can retain hundreds of pages of

confidential information from previous jobs on their hard disks or

internal memory. To safeguard this information from unauthorised

access, the optional Data

Security Kit

automatically encrypts

and erases the data after

each job is complete as

well as data stored both

on the hard disk and in

the address book.

Note: Requires optional

MX-HD10.

Encrypted PDF with Password Protection

To prevent unauthorised viewing of confidential image data, the

MX-2010U enables users to password protect and encrypt PDF

data. By setting a password when scanning, users can transmit a

PDF over the network in encrypted format. Then, after

transmission, viewers will only gain access to the encrypted PDF

after successfully re-entering the chosen password.

Note: Direct printing of encrypted PDF files requires optional MX-HD10,

MX-PB14, and MX-PK11.

Document Control Function

Document Control prevents unauthorised copying, scanning,

faxing, and filing of confidential documents. This is how it works:

the MX-2010U embeds copy prevention data onto a document

when it is first copied or printed. It will then detect this data the

next time someone tries to make a copy of the document. Any

unauthorised attempts to copy a Document Controlled-document

will simply be cancelled or result in the output of a blank page.

Note: Requires optional MX-HD10 and Data Security Kit. May not work for

certain types of documents or paper.

Data Initialisation

The MX-2010U’s initialisation function allows confidential

information to be erased at the administrator’s discretion via the

MFP’s system setting. Initialising an MFP when it’s taken out of

service prevents important resources, such as customer

information and intellectual property, from leaking out and

provides considerable peace of mind.

Secure Network Access

The MX-2010U’s IP/MAC address filtering function provides

highly secure operation by restricting access to the MX-2010U on

your office network. Only PCs that have either their IP address or

MAC (media access control) address

registered are allowed to use the

MX-2010U. Attempted access from

an unknown IP or MAC address will

be denied, preventing unauthorised

use. The MX-2010U also supports

the IEEE 802.1X standard for

port-based network access control,

which blocks all access from

unauthorised devices.

Secure Sockets Layer

SSL (secure sockets layer) enables the encryption of data

communications to prevent data leakage through the network

when printing via IPP, browsing secure Web pages (HTTPS), or

communicating via e-mail (SMTP and POP3) or FTP (FTPS).

User Authentication

The MX-2010U prevents unauthorised use by requiring

passwords for machine access. This safeguarded solution can

User, or Guest and can designate to which function user

authentication applies. The MX-2010U can, for example, be set to

allow B/W copying by all users while

restricting colour copying to

designated users. And the

MX-2010U works with an external

Active Directory server to extend

user authentication to multiple MFPs

and a greater number of users.

IPv6 and IPsec Support

The MX-2010U supports the IPv6 Internet protocol. An obligatory

part of IPv6 is IPsec (IP Security), a set of protocols for securing

Internet protocol (IP) communications. IPsec encrypts and

authenticates traffic between specified parties, giving

IPsec-compatible products an extremely high level of network

security.

Scan to Me Function

Scan to Me lets a logged-in authorised user send scanned data to

his/her own e-mail address simply by pressing the start button. This

eliminates the need to manually enter or select the address, thereby

preventing documents from being sent to the wrong address.

SCAN data

COPY data

PRINT data

FAX data

Quick File

Folder

Main

Folder

SCAN data

COPY data

PRINT data

FAX data

Private

Custom

Folder

SCAN data

COPY data

PRINT data

FAX data

Web-based device management

Printer Status Monitor

Web-based SRDM

* Image Compression Tool for converting images into compact PDF files

Word

Excel®

PDF

PowerPoint®

Scanned


etc.

Search screen

Compose

Store

View

Search Edit

Output zone

Print PC-Fax E-mail OCR ICT*

LAN

Read data from PC and

clone settings (import)

Store data to

PC (export)

Master machine PC Client machine 1 Client machine 2

Web-based device cloning

XML

FILE

Search results

Web access screen

DEVICE MANAGEMENT

DOCUMENT MANAGEMENT

Sharpdesk for Total Document Management

Document Management on the Hard Disk

You can save processed job data in designated folders on the

MX-2010U’s hard disk*, making it easy to instantly recall saved

documents or jobs for printing and sending at a later time. This

contributes greatly to efficient sharing and distribution of

information in your business operations.

* Requires optional MX-HD10.

Up to 10,000 pages or 3,000

files*1that have been copied,

printed, scanned, or faxed*2

can be stored by job on the

hard disk in a Quick File Folder.

You can easily reuse saved data

without having to reload or

rescan the original.

Quick Filing

Up to 20,000 pages or 3,000 files*1that have been copied, printed, scanned, or faxed*2can be stored by job

on the hard disk in up to 1,000 folders with customised names and locations. Enhanced security features require

users to enter a 5- to 8-digit password to access secure folders, protecting your sensitive data. Storage options

include:

• Main Folder – You can store processed files by

user name in the main public folder and share

them across the workgroup. Any file name and

a PIN code can be assigned to each saved job.

• Custom Folder - Up to 1,000 private folders (named as

desired) can be created within the Custom Folder. When

saving a file in a private folder, any file name can be

assigned. A PIN code can be applied to both private folders

and files.

Advanced Filing Function

Sharpdesk is an original Sharp application that provides integrated desktop

management of documents in over 200 file formats, including scanned

paper-based documents and those created with popular applications such as

Word. It allows you to organise, edit, search, and distribute your documents,

all with simple drag-and-drop operation.

• Intuitive desktop display features thumbnail viewing

• Sharpdesk Imaging provides annotation tools for paper-free proofreading

• Sharpdesk Composer combines different types of files into a single

document

• Optical character recognition converts documents into editable text files

• Output zone distributes files to e-mail, printers, and other applications

• File search allows searching by file name, keyword, or thumbnail

Easy Access to Stored Files

Documents stored on the hard disk can be quickly and easily

searched and accessed from the control panel’s LCD via thumbnail

displays and file previews or through a Web browser.

*1: Storage capacity will vary depending on the type of document and the scan settings.

*2: For fax and Internet fax jobs, only transmitted data (not received faxes) can be saved in the Document Filing function.

Send

To e-mail or FTP

Fax or Internet Fax*

Print Out

Paper documents

Electronic files created on a PC * These functions require their respective option(s).

See page 5 for details.

** Print data cannot be retransmitted.

Copy

Print**

PC-Internet Fa x

Fa x/Internet Fa x

PC-Fax*

Scan

Reuse

Integrated Device Management

The MX-2010U allows for easy programming of complex settings and makes it possible for a system administrator to

manage multiple devices from a single location. The result is minimum time and effort and maximum work efficiency.

Web-Based System Settings

Administrators can configure

system settings such as address

book control, document filing

management, and user control

(accounting) from either over

the network or from the control

panel of the MX-2010U.

User Control

The MX-2010U has capabilities to restrict machine access and

usage. Easily manage overall running costs by setting access rules

through a Web browser to limit or restrict functions, such as the

printing out or copying of large-volume colour documents.

• Authority Groups – Use of each function can be restricted

individually.

• User control and account – Up to 1,000 password-protected user

accounts can be created for customised access. Accounts can be

set up for individuals, groups or departments, in conjunction

with the authority group setting. Maximum limits for printing or

copying pages can be set for each account.

Remote Diagnosis

The MX-2010U can be monitored remotely through a Web

browser. In the event of a problem, such as a low amount of toner,

an alert is displayed on the Web page. And, the E-Mail Status and

Alert function generates e-mail messages to notify the

administrator when action or maintenance is required.

Network Utility Software

• Sharp Remote Device Manager

(SRDM) makes printer networks

easier to manage by allowing

administrators to customise

monitored items and view settings

such as the IP address directly from

their PC through a standard Web

browser.

• If the MX-2010U is low on paper or

toner, the Printer Status Monitor

will alert you in the form of

easy-to-understand graphics,

allowing you to avoid problems

before they arise.

Device Cloning

Machine settings can be copied conveniently to another

MX-2010U via a Web browser in XML format, making it easy to

clone machines in a networked environment. With Device Cloning,

the administrator no longer needs to set up individual machines

one by one, thereby making his/her job a lot easier.

Remote Operation

With the MX-2010U’s Remote Operation function, the same

control panel screen found on the MFP can be displayed on the

screen of a remote, office-networked PC, allowing the MFP to be

operated via that PC.* This function can, for example, enable the

administrator to guide an MFP user in need of help through

necessary procedures. It also allows users, such as the physically

challenged, who might have difficulty accessing the MFP control

panel, to operate the MFP remotely, via the PC.

* Requires VNC application.

Quick File Folder

Main Folder

Custom Folder

SCAN data

COPY data

PRINT data

FAX data

Quick File

Folder

Main

Folder

SCAN data

COPY data

PRINT data

FAX data

Private

Custom

Folder

SCAN data

COPY data

PRINT data

FAX data

Web-based device management

Printer Status Monitor

Web-based SRDM

* Image Compression Tool for converting images into compact PDF files

Word

Excel®

PDF

PowerPoint®

Scanned


etc.

Search screen

Compose

Store

View

Search Edit

Output zone

Print PC-Fax E-mail OCR ICT*

LAN

Read data from PC and

clone settings (import)

Store data to

PC (export)

Master machine PC Client machine 1 Client machine 2

Web-based device cloning

XML

FILE

Search results

Web access screen

DEVICE MANAGEMENT

DOCUMENT MANAGEMENT

Sharpdesk for Total Document Management

Document Management on the Hard Disk

You can save processed job data in designated folders on the

MX-2010U’s hard disk*, making it easy to instantly recall saved

documents or jobs for printing and sending at a later time. This

contributes greatly to efficient sharing and distribution of

information in your business operations.

* Requires optional MX-HD10.

Up to 10,000 pages or 3,000

files*1that have been copied,

printed, scanned, or faxed*2

can be stored by job on the

hard disk in a Quick File Folder.

You can easily reuse saved data

without having to reload or

rescan the original.

Quick Filing

Up to 20,000 pages or 3,000 files*1that have been copied, printed, scanned, or faxed*2can be stored by job

on the hard disk in up to 1,000 folders with customised names and locations. Enhanced security features require

users to enter a 5- to 8-digit password to access secure folders, protecting your sensitive data. Storage options

include:

• Main Folder – You can store processed files by

user name in the main public folder and share

them across the workgroup. Any file name and

a PIN code can be assigned to each saved job.

• Custom Folder - Up to 1,000 private folders (named as

desired) can be created within the Custom Folder. When

saving a file in a private folder, any file name can be

assigned. A PIN code can be applied to both private folders

and files.

Advanced Filing Function

Sharpdesk is an original Sharp application that provides integrated desktop

management of documents in over 200 file formats, including scanned

paper-based documents and those created with popular applications such as

Word. It allows you to organise, edit, search, and distribute your documents,

all with simple drag-and-drop operation.

• Intuitive desktop display features thumbnail viewing

• Sharpdesk Imaging provides annotation tools for paper-free proofreading

• Sharpdesk Composer combines different types of files into a single

document

• Optical character recognition converts documents into editable text files

• Output zone distributes files to e-mail, printers, and other applications

• File search allows searching by file name, keyword, or thumbnail

Easy Access to Stored Files

Documents stored on the hard disk can be quickly and easily

searched and accessed from the control panel’s LCD via thumbnail

displays and file previews or through a Web browser.

*1: Storage capacity will vary depending on the type of document and the scan settings.

*2: For fax and Internet fax jobs, only transmitted data (not received faxes) can be saved in the Document Filing function.

Send

To e-mail or FTP

Fax or Internet Fax*

Print Out

Paper documents

Electronic files created on a PC * These functions require their respective option(s).

See page 5 for details.

** Print data cannot be retransmitted.

Copy

Print**

PC-Internet Fa x

Fa x/Internet Fa x

PC-Fax*

Scan

Reuse

Integrated Device Management

The MX-2010U allows for easy programming of complex settings and makes it possible for a system administrator to

manage multiple devices from a single location. The result is minimum time and effort and maximum work efficiency.

Web-Based System Settings

Administrators can configure

system settings such as address

book control, document filing

management, and user control

(accounting) from either over

the network or from the control

panel of the MX-2010U.

User Control

The MX-2010U has capabilities to restrict machine access and

usage. Easily manage overall running costs by setting access rules

through a Web browser to limit or restrict functions, such as the

printing out or copying of large-volume colour documents.

• Authority Groups – Use of each function can be restricted

individually.

• User control and account – Up to 1,000 password-protected user

accounts can be created for customised access. Accounts can be

set up for individuals, groups or departments, in conjunction

with the authority group setting. Maximum limits for printing or

copying pages can be set for each account.

Remote Diagnosis

The MX-2010U can be monitored remotely through a Web

browser. In the event of a problem, such as a low amount of toner,

an alert is displayed on the Web page. And, the E-Mail Status and

Alert function generates e-mail messages to notify the

administrator when action or maintenance is required.

Network Utility Software

• Sharp Remote Device Manager

(SRDM) makes printer networks

easier to manage by allowing

administrators to customise

monitored items and view settings

such as the IP address directly from

their PC through a standard Web

browser.

• If the MX-2010U is low on paper or

toner, the Printer Status Monitor

will alert you in the form of

easy-to-understand graphics,

allowing you to avoid problems

before they arise.

Device Cloning

Machine settings can be copied conveniently to another

MX-2010U via a Web browser in XML format, making it easy to

clone machines in a networked environment. With Device Cloning,

the administrator no longer needs to set up individual machines

one by one, thereby making his/her job a lot easier.

Remote Operation

With the MX-2010U’s Remote Operation function, the same

control panel screen found on the MFP can be displayed on the

screen of a remote, office-networked PC, allowing the MFP to be

operated via that PC.* This function can, for example, enable the

administrator to guide an MFP user in need of help through

necessary procedures. It also allows users, such as the physically

challenged, who might have difficulty accessing the MFP control

panel, to operate the MFP remotely, via the PC.

* Requires VNC application.

Quick File Folder

Main Folder

Custom Folder

Power save key

Thumbnails Preview

Job status

ENVIRONMENT- &

USER-FRIENDLY

OPTIONS

ENVIRONMENTALLY ADVANCED

• The MX-2010U has two levels of

energy-saving modes to reduce or shut off

electricity after a period of inactivity. And

pressing the power save key after a job is

finished immediately puts the MX-2010U into

auto power shut-off mode for further cutbacks

on running costs.

• In support of the RoHS directive, which

restricts the use of hazardous substances, Sharp

has fully eliminated harmful lead and

chromium in all MX-2010U parts and materials.

Eco-Friendly Supplies

Integrating Sharp’s environmentally advanced supplies, the

MX-2010U takes ecological performance to a whole new level.

Second-generation Mycrostoner-HG offers a significantly lower

consumption rate than conventional toner, while the longer-life

photoconductor delivers higher performance than previous models.

Environmentally Conscious Design

• A short warm-up time of 45 seconds contributes to reduced

overall energy consumption.

• Based on prior usage patterns, the MX-2010U automatically

determines the optimal length of time to let elapse before going

into auto power shut-off mode, helping reduce overall power

consumption.

Certain options may not be available in some areas.

or or

Specifications for Options

MX-FN17 Finisher

Paper size Non offset A3W to A5R (12" x 18" to 5 1/2" x 8 1/2"R)

Offset/staple A3 to B5 (11" x 17" to 8 1/2" x 11"R)

Paper capacity (max.) 250 sheets (A3, 11" x 17"),

500 sheets (A4, 8 1/2" x 11)

Stapling capacity

50 sheets (A4 or smaller), 30 sheets (B4 or larger)

Staple position 3 locations (front, rear or both)

MX-DE12 Stand with 500-Sheet Paper Drawer

Paper size A3 to A5R (11" x 17" to 5 1/2" x 8 1/2"R)

Paper capacity 500 sheets (80 g/m2)

MX-DE13 Stand with 2 x 500-Sheet Paper Drawer

Paper size (upper and lower tray) A3 to A5R (11" x 17" to 5 1/2" x 8 1/2"R)

Paper capacity (upper and lower tray) 500 sheets each (80 g/m2)

MX-DE14 Stand with 3 x 500-Sheet Paper Drawer

Paper size (upper/middle/lower tray) A3 to A5R (11" x 17" to 5 1/2" x 8 1/2"R)

Paper capacity (upper/middle/lower tray) 500 sheets each (80 g/m2)

MX-FX11 Fax Expansion Kit

Compression method MH/MR/MMR/JBIG

Communication protocol Super G3/G3

Modem speed 33,600 bps to 2,400 bps

Punch Modules

Model name

Number of holes

Paper weight

For the MX-FN17

MX-PN11A MX-PN11B MX-PN11C MX-PN11D

2 3 4 4 (wide)

55 to 256 g/m2 *

System Configuration

MX-FN17

Finisher

MX-PN11A/B/C/D

Punch Module MX-FX11

Fax Expansion Kit

MX-TR12

Exit Tray Unit

* Guaranteed punchable weight is 55 to 128 g/m2.

7.0-Inch Touch-Screen LCD

The MX-2010U features a logically designed control panel with a

wide, clear, WVGA-resolution touch-screen LCD. Easy-to-follow

guidance puts step-by-step instructions on the LCD to guide you

through all the necessary procedures for staple/sort finishing,

pamphlet making, and other functions. Pushing the Home button,

even in the middle of an operation, takes you back to the Start

screen. Programming the most frequently used functions and

settings into My Menu gives you quick and easy access to them.

And using the included stylus pen provides controlled, accurate

touch-screen operation.

Sharp OSA (Open Systems Architecture)

The MX-2010U supports the Sharp

OSA* development platform. This

innovative technology allows users to

interact with critical business and

network applications and/or external account software right from

the LCD control panel, offering a new realm of control and

convenience. And since Sharp OSA utilises industry-standard

network protocols, such as XML and SOAP, the MX-2010U can

easily integrate with document management systems, enterprise

resource planning software, workflow applications, and more.

* Requires optional MX-HD10 and MX-AMX2 and/or MX-AMX3.

Easy-Grip Handles

Easy-grip handles on the

MX-2010U reflect a universal

design that allows the paper

drawers to be grasped from

the top as well as the bottom

for easy opening and closing.

EASY OPERATION

Thumbnail Display and Previews*

Making the search for files easier and more convenient than ever,

thumbnails and up-close previews of Document Filing data files, as

well as conventional file names, can be displayed on the

MX-2010U’s LCD control panel. And to help users decide which

documents to print out or forward to others, the LCD can also

display thumbnails and previews of incoming faxes and Internet

faxes. The MX-2010U even prevents errors in copying, scanning,

or saving documents to its hard disk by showing previews of those

jobs on the LCD before actually executing them, making it easy to

confirm finishing options, scan settings, and other such items.

* Requires optional MX-HD10.

Job Status Screen

Whether printing or copying, the control panel displays a list of all

jobs, showing you at a glance the jobs in progress and the position

of your job in the queue. And, with a few quick touches of the

LCD screen, the Priority Printing function lets you easily change

the job queue order or delete jobs

that are no longer needed.

Sharpdesk System Requirements

Supported OS Windows®XP (SP2) Professional/Home Edition, Windows Vista®, Windows®7

Hard disk Minimum requirement of operating system used plus at least 500MB to store Sharpdesk and Network Scanner Tool programs

CPU Pentium®or equivalent processor (Windows XP: 800 MHz 32-bit/64-bit processor; Windows Vista and Windows 7: 1 GHz 32-bit/64-bit processor)

Memory Windows XP: 512MB RAM; Windows Vista and Windows 7: 1GB RAM/2GB RAM (Windows 7 64-bit)

Monitor Windows XP: SVGA display; Windows Vista and Windows 7: Direct X9 support with 128MB video RAM

MX-DE13

Stand with

2 x 500-Sheet

Paper Drawer

MX-DE14

Stand with

3 x 500-Sheet

Paper Drawer

MX-DE12

Stand with

500-Sheet

Paper Drawer

MX-HD10

HDD Expansion Kit

MX-PB14

Printer Expansion Kit

MX-PK11

PS3 Expansion Kit

MX-PUX1

XPS Expansion Kit

MX-PF10

Barcode Font Kit

AR-SU1

Stamp Unit

MX-FWX1

Internet Fax Expansion Kit

MX-USX1/X5

Sharpdesk 1/5-License Kit

MX-US10/50/A0

Sharpdesk 10/50/100-License Kit

MX-AMX1

Application Integration Module

MX-AMX2

Application

Communication Module

MX-AMX3

External Account

Module

MX-SM10

Expansion Memory

Board

BASE UNIT

MX-RP12

Reversing Single

Pass Feeder

MX-VR11

Document Cover

MX-RP12 Reversing Single Pass Feeder

Scan speed (copy) Colour 36 opm (one-sided), 17 opm (two-sided)

(A4, 8 1/2" x 11) B/W 50 opm (one-sided), 20 opm (two-sided)

Paper size A3 to A5 (11" x 17" to 5 1/2" x 8 1/2")

Paper capacity 100 sheets (80 g/m2)

MX-FR25U

Data Security Kit

MX-UN01A/05A

Sharp OSA Network Scanner Tool 1/5-License Kit

MX-UN10A/50A

Sharp OSA Network Scanner Tool 10/50-License Kit

MX-UN1HA

Sharp OSA Network Scanner Tool 100-License Kit

Note: When using Sharpdesk, Sharp OSA Network Scanner Tool, and Sharp OSA, please ask your Sharp representative about PC system requirements.

Power save key

Thumbnails Preview

Job status

ENVIRONMENT- &

USER-FRIENDLY

OPTIONS

ENVIRONMENTALLY ADVANCED

• The MX-2010U has two levels of

energy-saving modes to reduce or shut off

electricity after a period of inactivity. And

pressing the power save key after a job is

finished immediately puts the MX-2010U into

auto power shut-off mode for further cutbacks

on running costs.

• In support of the RoHS directive, which

restricts the use of hazardous substances, Sharp

has fully eliminated harmful lead and

chromium in all MX-2010U parts and materials.

Eco-Friendly Supplies

Integrating Sharp’s environmentally advanced supplies, the

MX-2010U takes ecological performance to a whole new level.

Second-generation Mycrostoner-HG offers a significantly lower

consumption rate than conventional toner, while the longer-life

photoconductor delivers higher performance than previous models.

Environmentally Conscious Design

• A short warm-up time of 45 seconds contributes to reduced

overall energy consumption.

• Based on prior usage patterns, the MX-2010U automatically

determines the optimal length of time to let elapse before going

into auto power shut-off mode, helping reduce overall power

consumption.

Certain options may not be available in some areas.

or or

Specifications for Options

MX-FN17 Finisher

Paper size Non offset A3W to A5R (12" x 18" to 5 1/2" x 8 1/2"R)

Offset/staple A3 to B5 (11" x 17" to 8 1/2" x 11"R)

Paper capacity (max.) 250 sheets (A3, 11" x 17"),

500 sheets (A4, 8 1/2" x 11)

Stapling capacity

50 sheets (A4 or smaller), 30 sheets (B4 or larger)

Staple position 3 locations (front, rear or both)

MX-DE12 Stand with 500-Sheet Paper Drawer

Paper size A3 to A5R (11" x 17" to 5 1/2" x 8 1/2"R)

Paper capacity 500 sheets (80 g/m2)

MX-DE13 Stand with 2 x 500-Sheet Paper Drawer

Paper size (upper and lower tray) A3 to A5R (11" x 17" to 5 1/2" x 8 1/2"R)

Paper capacity (upper and lower tray) 500 sheets each (80 g/m2)

MX-DE14 Stand with 3 x 500-Sheet Paper Drawer

Paper size (upper/middle/lower tray) A3 to A5R (11" x 17" to 5 1/2" x 8 1/2"R)

Paper capacity (upper/middle/lower tray) 500 sheets each (80 g/m2)

MX-FX11 Fax Expansion Kit

Compression method MH/MR/MMR/JBIG

Communication protocol Super G3/G3

Modem speed 33,600 bps to 2,400 bps

Punch Modules

Model name

Number of holes

Paper weight

For the MX-FN17

MX-PN11A MX-PN11B MX-PN11C MX-PN11D

2 3 4 4 (wide)

55 to 256 g/m2 *

System Configuration

MX-FN17

Finisher

MX-PN11A/B/C/D

Punch Module MX-FX11

Fax Expansion Kit

MX-TR12

Exit Tray Unit

* Guaranteed punchable weight is 55 to 128 g/m2.

7.0-Inch Touch-Screen LCD

The MX-2010U features a logically designed control panel with a

wide, clear, WVGA-resolution touch-screen LCD. Easy-to-follow

guidance puts step-by-step instructions on the LCD to guide you

through all the necessary procedures for staple/sort finishing,

pamphlet making, and other functions. Pushing the Home button,

even in the middle of an operation, takes you back to the Start

screen. Programming the most frequently used functions and

settings into My Menu gives you quick and easy access to them.

And using the included stylus pen provides controlled, accurate

touch-screen operation.

Sharp OSA (Open Systems Architecture)

The MX-2010U supports the Sharp

OSA* development platform. This

innovative technology allows users to

interact with critical business and

network applications and/or external account software right from

the LCD control panel, offering a new realm of control and

convenience. And since Sharp OSA utilises industry-standard

network protocols, such as XML and SOAP, the MX-2010U can

easily integrate with document management systems, enterprise

resource planning software, workflow applications, and more.

* Requires optional MX-HD10 and MX-AMX2 and/or MX-AMX3.

Easy-Grip Handles

Easy-grip handles on the

MX-2010U reflect a universal

design that allows the paper

drawers to be grasped from

the top as well as the bottom

for easy opening and closing.

EASY OPERATION

Thumbnail Display and Previews*

Making the search for files easier and more convenient than ever,

thumbnails and up-close previews of Document Filing data files, as

well as conventional file names, can be displayed on the

MX-2010U’s LCD control panel. And to help users decide which

documents to print out or forward to others, the LCD can also

display thumbnails and previews of incoming faxes and Internet

faxes. The MX-2010U even prevents errors in copying, scanning,

or saving documents to its hard disk by showing previews of those

jobs on the LCD before actually executing them, making it easy to

confirm finishing options, scan settings, and other such items.

* Requires optional MX-HD10.

Job Status Screen

Whether printing or copying, the control panel displays a list of all

jobs, showing you at a glance the jobs in progress and the position

of your job in the queue. And, with a few quick touches of the

LCD screen, the Priority Printing function lets you easily change

the job queue order or delete jobs

that are no longer needed.

Sharpdesk System Requirements

Supported OS Windows®XP (SP2) Professional/Home Edition, Windows Vista®, Windows®7

Hard disk Minimum requirement of operating system used plus at least 500MB to store Sharpdesk and Network Scanner Tool programs

CPU Pentium®or equivalent processor (Windows XP: 800 MHz 32-bit/64-bit processor; Windows Vista and Windows 7: 1 GHz 32-bit/64-bit processor)

Memory Windows XP: 512MB RAM; Windows Vista and Windows 7: 1GB RAM/2GB RAM (Windows 7 64-bit)

Monitor Windows XP: SVGA display; Windows Vista and Windows 7: Direct X9 support with 128MB video RAM

MX-DE13

Stand with

2 x 500-Sheet

Paper Drawer

MX-DE14

Stand with

3 x 500-Sheet

Paper Drawer

MX-DE12

Stand with

500-Sheet

Paper Drawer

MX-HD10

HDD Expansion Kit

MX-PB14

Printer Expansion Kit

MX-PK11

PS3 Expansion Kit

MX-PUX1

XPS Expansion Kit

MX-PF10

Barcode Font Kit

AR-SU1

Stamp Unit

MX-FWX1

Internet Fax Expansion Kit

MX-USX1/X5

Sharpdesk 1/5-License Kit

MX-US10/50/A0

Sharpdesk 10/50/100-License Kit

MX-AMX1

Application Integration Module

MX-AMX2

Application

Communication Module

MX-AMX3

External Account

Module

MX-SM10

Expansion Memory

Board

BASE UNIT

MX-RP12

Reversing Single

Pass Feeder

MX-VR11

Document Cover

MX-RP12 Reversing Single Pass Feeder

Scan speed (copy) Colour 36 opm (one-sided), 17 opm (two-sided)

(A4, 8 1/2" x 11) B/W 50 opm (one-sided), 20 opm (two-sided)

Paper size A3 to A5 (11" x 17" to 5 1/2" x 8 1/2")

Paper capacity 100 sheets (80 g/m2)

MX-FR25U

Data Security Kit

MX-UN01A/05A

Sharp OSA Network Scanner Tool 1/5-License Kit

MX-UN10A/50A

Sharp OSA Network Scanner Tool 10/50-License Kit

MX-UN1HA

Sharp OSA Network Scanner Tool 100-License Kit

Note: When using Sharpdesk, Sharp OSA Network Scanner Tool, and Sharp OSA, please ask your Sharp representative about PC system requirements.

Shown with options.

623 mm

1,206 mm

583 mm

MX-2010U

Digital Full Colour Multifunctional System

(tentative)

SPECIFICATIONS

Digital Full Colour Multifunctional System

MX-2010U

Copy Fax

OPTION

Network Print Network Scan Sharpdesk

Be Colour Forward—Make the Switch

to a Compact, Full-Colour Solution

Desktop

Max. 20 cpm/ppm (A4, 8

" x 11", long-edge feeding)

Max. A3 wide (12" x 18"), min. A5R (5

" x 8

"R)

Standard: 600 sheets

(500-sheet tray and 100-sheet multi-bypass tray)

Maximum: 2,100 sheets

Tray: 60 g/m

to 209 g/m

(16 lbs bond to 110 lbs index)

Multi-bypass tray: 55 g/m

to 256 g/m

(13 lbs bond to 140 lbs index)

45 sec.

[Standard] Copy/print (shared): 1GB

[Option] Print: 1.5GB 160GB HDD*

Rated local AC voltage ±10%, 50/60 Hz

1.84 kW (220 to 240V), 1.44 kW (100 to 127V)

583 x 623 x 717 mm (22

" x 24

" x 28

65 kg (143.3 lbs)

Original paper size

First copy time*

Continuous copy

Resolution

Gradation

Zoom range

Preset copy ratios

Max. A3 (11" x 17")

Full colour: 10.2 sec. B/W: 8.8 sec.

Max. 999 copies

Scan (colour): 600 x 600 dpi

Scan (B/W): 600 x 600 dpi, 600 x 400 dpi, 600 x 300 dpi

Print: 9,600 (equivalent) x 600 dpi (depending on print mode),

600 x 600 dpi

Equivalent to 256 levels

25 to 400% (25 to 200% using RSPF) in 1% increments

Metric: 10 ratios (5R/5E), inch: 8 ratios (4R/4E)

B/W Facsimile (optional MX-FX11 required)

Compression method

Communication protocol

Transmission time

Modem speed

Transmission resolution

Recording width

Memory

Grey scale levels

MH/MR/MMR/JBIG

Super G3/G3

Less than 3 seconds*

33,600 bps to 2,400 bps with automatic fallback

From Standard (203.2 x 97.8 dpi) to Ultra Fine (406.4 x 391 dpi)

A3 to A5 (11" x 17" to 5

" x 8

512MB, max. 1GB*

Equivalent to 256 levels

Type

Engine speed

(colour & B/W)

Paper size

Paper capacity

(80 g/m

)

Paper weight

Warm-up time*

Memory

Power requirements

Power consumption

(max.)

Dimensions (W x D x H)*

Weight (approx.)*

General

Copier

Network Printer

Network Scanner

Scan method

Resolution

File formats

Scanner utility

Scan destinations

Push scan (via control panel),

pull scan (TWAIN-compliant application)

Push scan: 100, 200, 300, 400, 600 dpi

Pull scan: 75, 100, 150, 200, 300, 400, 600 dpi

50 to 9,600 dpi via user setting*

TIFF, PDF, encrypted PDF, JPEG (colour only), XPS

Sharpdesk

Scan to e-mail/desktop/FTP server/network folder (SMB)/

USB memory

Resolution

Interface

Supported OS*

Network protocols*

Printing protocols

PDL (emulation)

Available fonts

9,600 (equivalent) x 600 dpi, 600 x 600 dpi

USB 2.0, 10Base-T/100Base-TX/1000Base-T

Windows Server

2003, Windows Server

2008, Windows Server

2012, Windows

2000, Windows

XP, Windows Vista

Windows

7, Windows

8, Mac OS 9.0 to 9.2, Mac OS X 10.2,

10.3, 10.4, 10.5, 10.6, 10.7, 10.8, 10.9

TCP/IP (IPv4, IPv6), IPX/SPX (NetWare), NetBEUI,

EtherTalk (AppleTalk)

LPR, Raw TCP (port 9100), POP3 (e-mail printing), HTTP,

Novell Printserver application with NDS and Bindery,

FTP for downloading print files, EtherTalk printing, IPP

Standard: Sharp Advanced Printing Language-c

Option*

: PCL 6 emulation, PostScript

™

emulation, XPS

80 fonts for PCL, 136 fonts for PostScript 3 emulation

* 1 : At rated voltage, 23°C (73.4°F). May vary depending on operating conditions and environment.

* 2 : HDD capacity depends on procurement and sourcing status.

* 3 : Including document cover.

* 4 : Long-edge feeding of A4 (8 1/2" x 11") sheets from 1st paper tray, using document glass, without Auto

Colour Selection and Auto Colour mode, MFP in fully ready condition. May vary depending on operating

conditions and environment.

* 5 : Resolutions higher than 600 dpi are interpolated.

* 6 : Storage capacity will vary depending on the type of document and the scan settings.

* 7 : Some features require option(s).

* 8 : Optional MX-PK11 required for Mac OS and EtherTalk.

* 9 :

PCL requires optional MX-HD10 and MX-PB14. PostScript 3 requires optional MX-HD10, MX-PK11, and

MX-PB14. XPS requires optional MX-HD10, MX-PUX1, MX-PB14, and MX-SM10 (1GB).

*10: Based on Sharp’s standard chart with approx. 700 characters (A4 or 8 1/2" x 11" long-edge feeding) at

standard resolution in Super G3 mode, 33,600 bps, JBIG compression.

*11: Optional MX-HD10 required.

Document Filing (optional MX-HD10 required)

Document filing

capacity*

Stored jobs*

Storage folders

Confidential storage

Main and custom folders: 20,000 pages or 3,000 files

Quick file folder: 10,000 pages or 1,000 files

Copy, print, scan, fax transmission

Quick file folder, main folder, custom folder (max. 1,000 folders)

Password protection

• Design and specifications are subject to change without prior notice.

• PCL is a registered trademark of Hewlett-Packard Company. PostScript 3 is either a registered trademark or trademark

of Adobe Systems Incorporated in the US and/or other countries. Windows, Windows Server, Windows Vista, Excel, and

PowerPoint are registered trademarks of Microsoft Corporation in the US and/or other countries. Macintosh, Mac OS,

EtherTalk, and AppleTalk are trademarks of Apple Inc., registered in the US and other countries. All other brand names

and product names may be trademarks or registered trademarks of their respective owners.

Distributed by:

Other manuals for MX-2010U

Table of contents

Popular All In One Printer manuals by other brands

Canon

Canon iR2000 Series Installation procedures

Ricoh

Ricoh C280 manual

Epson

Epson Stylus NX410 Series Start here

Fuji Xerox

Fuji Xerox ApeosPort-V 3065 Administrator's guide

Epson

Epson EcoTank M2140 Start here

Dell

Dell H815dw user guide

Samsung

Samsung CLX3175FN - COL LASERPR MLTFUNC 4/17PPM... Manual Del Usuario

Dell

Dell S3845cdn user guide

Qls

Qls 2000 Series Operation & setup guide

Xerox

Xerox Phaser 6180MFP Features setup guide

Lexmark

Lexmark 90P4000 Brochure & specs

Toshiba

Toshiba GA-1211 Easy setup guide

Ricoh

Ricoh Pro C5210s operating instructions

Canon

Canon PIXMA MG5420 Network installation guide

Xerox

Xerox WorkCentre 3215 Quick use guide

Canon

Canon PIXMA MP500 user guide

Xerox

Xerox WorkCentre 3025 installation guide

Epson

Epson SL-D3000 Operation guide

Sharp MX-2010U User manual

Popular All In One Printer manuals by other brands
