CODE: 00ZARF152/A1E
DIGITAL COPIER
AR-151
AR-156
MODEL AR-F152
[ 1 ] GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
[ 2 ] SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . 2 - 1
[ 3 ] CONSUMABLE PARTS . . . . . . . . . . . . . . . . . . . 3 - 1
[ 4 ] EXTERNAL VIEWS AND INTERNAL STRUCTURES . . . 4 - 1
[ 5 ] UNPACKING AND INSTALLATION . . . . . . . . . . . . . 5 - 1
[ 6 ] OPERATIONAL DESCRIPTIONS . . . . . . . . . . . . . . 6 - 1
[ 7 ] DISASSEMBLY AND ASSEMBLY . . . . . . . . . . . . . . 7 - 1
[ 8 ] ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . 8 - 1
[ 9 ] SIMULATION, FAX SOFTWARE SWITCH,
TROUBLE CODES . . . . . . . . . . . . . . . . . . . . . . 9 - 1
[10] USER PROGRAM . . . . . . . . . . . . . . . . . . . . . . 10 - 1
[11] MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . 11 - 1
[12] ELECTRICAL SECTION . . . . . . . . . . . . . . . . . . . 12 - 1
[13] CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . . . . 13 - 1
CONTENTS
Parts marked with “ ” are important for maintaining the safety of the set. Be sure to replace these parts with specified
ones for maintaining the safety and performance of the set.
SHARP CORPORATION This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
(AR-F152)
AR-F152

CAUTION
This product is a class 1 laser product that complies with 21CFR 1040.10 and 1040.11 of the CDRH stand-
ard and IEC825. This means that this machine does not produce hazardous laser radiation. The use of
controls, adjustments or performance of procedures other than those specified herein may result in haz-
ardous radiation exposure.
This laser radiation is not a danger to the skin, but when an exact focusing of the laser beam is achieved
on the eye’s retina, there is the danger of spot damage to the retina.
The following cautions must be observed to avoid exposure of the laser beam to your eyes at the time
of servicing.
1) When a problem in the laser optical unit has occurred, the whole optical unit must be exchanged as
a unit, not as individual parts.
2) Do not look into the machine with the main switch turned on after removing the developer unit, toner
cartridge, and drum cartridge.
3) Do not look into the laser beam exposure slit of the laser optical unit with the connector connected
when removing and installing the optical system.
4) The middle frame contains the safety interlock switch.
Do not defeat the safety interlock by inserting wedges or other items into the switch slot.
LASER WAVE – LENGTH : 780 ∼795
Pulse times : 0.481 ms/6 mm
Out put power : 0.20 ±0.03 mW
CAUTION
INVISIBLE LASER RADIATION,
WHEN OPEN AND INTERLOCKS DEFEATED.
AVOID EXPOSURE TO BEAM.
VORSICHT
UNSICHTBARE LASERSTRAHLUNG,
WENN ABDECKUNG GEÖFFNET UND
SICHERHEITSVERRIEGELUNG ÜBERBRÜCKT.
NICHT DEM STRAHL AUSSETZEN.
VARO !
AVATTAESSA JA SUOJALUKITUS
OHITETTAESSA OLET ALTTIINA
NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE ÄLÄ
KATSO SÄTEESEEN.
ADVARSEL
USYNLIG LASERSTRÅLNING VED ÅBNING, NÅR
SIKKERHEDSBRYDERE ER UDE AF
FUNKTION. UNDGÅ UDSAETTELSE FOR
STRÅLNING.
VARNING !
OSYNLIG LASERSTRÅLNING NÄR DENNA DEL
ÄR ÖPPNAD OCH SPÄRREN ÄR URKOPPLAD.
BETRAKTA EJ STRÅLEN. – STRÅLEN ÄR FARLIG.
AR-F152

At the production line, the output power
of the scanner unit is adjusted to 0.57
MILLI-WATT PLUS 20 PCTS and is
maintained constant by the operation of
the Automatic Power Control (APC).
Even if the APC circuit fails in operation
for some reason, the maximum output
power will only be 15 MILLI-WATT 0.1
MICRO-SEC. Giving an accessible
emission level of 42 MICRO-WATT
which is still-less than the limit of
CLASS-1 laser product.
The foregoing is applicable only to the 220V
model
,
230V model and 240V model.
VAROITUS! LAITTEEN KÄYTTÄMINEN MUULLA
KUIN TÄSSÄ KÄYTTÖOHJEESSA MAINITULLA
TAVALLA SAATTAA ALTISTAA KÄYTTÄJÄN
TURVALLISUUSLUOKAN 1 YLITTÄVÄLLE
NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE.
VARNING - OM APPARATEN ANVÄNDS PÅ ANNAT
SÄTT ÄN I DENNA BRUKSANVISNING
SPECIFICERATS, KAN ANVÄNDAREN UTSÄTTAS
FÖR OSYNLIG LASERSTRÅLNING, SOM
ÖVERSKRIDER GRÄNSEN FÖR LASERKLASS 1.
Caution
This product contains a low power laser
device. To ensure continued safety do not
remove any cover or attempt to gain access
to the inside of the product. Refer all
servicing to qualified personnel.
LUOKAN 1 LASERLAITE
KLASS 1 LASER APPARAT
AR-F152

[1] GENERAL
1. AR-151/156/F152 major functions
Item CPM SB/MB 2 tray SPF R-SPF FAX GDI with
USB
GDI
without
USB SOPM Duplex
Model
AR-151 15CPM MB Opt ∗1 Opt ∗1 Opt Opt
AR-156 15CPM MB Opt Opt
AR-F152 15CPM MB ∗2Opt
Descriptions of items
CPM: Copy speed (Copies Per Minute)
SB/MB: SB = Manual feed single bypass, MB = Manual feed multi bypass
2 tray: Second cassette unit. The 1 tray unit (AR-DE9) is optionally available.
SPF: Original feed unit
R-SPF: Duplex original feed unit
FAX: FAX function. The AR-FX3 (FAX-SPF and FAX board) is optionally available.)
GDI with USB: GDI printer function with USB. The AR-PG1 (GDI + USB kit) is optionally available.
GDI without USB: GDI printer function without USB. The said model has no option of it.
SOPM: Scan One Print Many function (Many copies are made by one scan.)
Duplex: Auto duplex copy function
Descriptions of table
:Standard provision
:No function or no option available
∗1: Incompatible between SPF and FAX function
∗2: 1 tray option for Europe
2. System Configuration
(Options)
(AR-151) (AR-F152) (AR-156)
AR-SP3
AR-FX3
AR-DE9
AR-PG1
AR-F152
1 – 1

[2] SPECIFICATIONS
1. Basic specifications of copier
A. Basic specifications
Item Spec.
Type Desktop
Copy system Dry, electrostatic
Segment (class) Digital personal copier
External dimensions (W ×D ×H) (mm) AR-151: 518mm ×482.6mm ×292.6mm AR-156: 518mm ×482.6mm ×379mm
AR-F152: 518mm ×482.6mm ×465.3mm
Weight AR-151: Approx. 19Kg, (drum cartridges included) AR-156: Approx. 22Kg, (drum cartridges included)
AR-F152: Approx. 25Kg, (drum cartridges included)
B. Operation specification
Section Item Details Spec.
Paper
feed
section
Paper feed
system
AR-151/AR-156: 1 tray (250 sheets) + multi bypass (50 sheets)
AR-F152: 2 tray (250 sheets) + multi bypass (50 sheets)
(1 tray for Europe)
AB system
Tray paper feed
section
Paper size A4, B5, A5 (Landscape)
Paper weight 56 – 80g/m2
Paper feed capacity 250 sheets
Kinds Standard paper, specified paper, recycled paper
Remark User adjustment of paper guide available
Multi bypass paper
feed section
Paper size A4, B5, A5, B6, A6 (Landscape)
Paper weight 52 – 128g/m2
Paper feed capacity 50 sheets
Kinds ∗1Standard paper, specified paper, recycled paper, OHP, Label,
Postal card
Remark User adjustment of paper guide available
Inch system
Tray paper feed
section
Paper size 8-1/2″×14″, 8-1/2 ×11″, 8-1/2″×5-1/2″(Landscape)
Paper weight 15 – 21 lbs.
Paper feed capacity 250 sheets
Kinds Standard paper, specified paper, recycled paper
Remark User adjustment of paper guide available
Multi bypass paper
feed section
Paper size 8-1/2″×14″, 8-1/2 ×11″, 8-1/2″×5-1/2″, 3-1/2″×5-1/2″
(Landscape)
Paper weight 14 – 34.5 lbs.
Paper feed capacity 50 sheets
Kinds ∗1Standard paper, specified paper, recycled paper, OHP, Label,
Postal card
Remark User adjustment of paper guide available
Paper for
Duplex
(AR-156
only)
AB system
Paper size A4, B5, A5 (Landscape)
Paper weight 56 – 80 g/m2
Kinds Standard paper, Specified paper,
Recycled paper
Inch system
Paper size 8-1/2″×14″, 8-1/2″×11″, 8-1/2″×5-1/2″(Landscape)
Paper weight 15-21 lbs
Kinds Standard paper, Specified paper,
Recycled paper
∗1: OHP, Label, Postal card: each 1 pc.
AR-F152
2 – 1

Section Item Details Spec.
Paper exit section Exit way Face down
Capacity of output
tray 100 sheets
Originals
Original set Center Registration (left edge)
Max. original size B4 (10″×14″)
Original kinds sheet
Original size
detection None
Optical
section
Scanning
section
Scanning system CCD sensor scanning by lighting lamp scanner
CCD sensor Resolution 400 dpi
Lighting lamp Type Xenon lamp
Voltage 1.5kV
Power consumption 11 ±3W
Gradation 256 gradations/8bit
Writing
section Writing system Writing to OPC drum by the semiconductor laser
Laser unit Resolution 600 dpi
Image forming
Photoconductor Type OPC (30φ)
Life 18k
Charger Charging system Saw -tooth charging with a grid, / (–) scorotron discharge
Transfer system (+) DC corotron system
Separation system (–) DC corotron system
Developing Developing system Dry, 2-component magnetic brush development system
Cleaning Cleaning system Counter blade system (Counter to rotation)
Fusing section
Fusing system Heat roller system
Upper heat roller Type Teflon roller
Lower heat roller Type Silicon rubber roller
Heater lamp Type Halogen lamp
Voltage 100V
Power consumption 800W
Electrical section
Power source Voltage Local AC voltage
Frequency Common use for 50 and 60Hz
Power consumption
Max. AR-151/AR-156: 1000W, AR-F152: 1000W
Average (during copying) *1) AR-151/AR-156: 310Wh/H, AR-F152: 310Wh/H
Average (stand-by) *1) AR-151/AR-156: 70Wh/H, AR-F152: 90Wh/H
Pre-heat mode *1) AR-151/AR-156: 40Wh/H, AR-F152: 51Wh/H
Auto power shut-off mode *1) AR-151/AR-156: 18Wh/H, AR-F152: 23Wh/H
*1) May fluctuate due to environmental conditions and the input voltage.
C. Copy performance
Section Item Details Spec.
Copy magnification Fixed magnification ratios 3R + 2E (AB system: 50, 70, 81, 100, 141, 200%)
(Inch system: 50, 64, 78, 100, 129, 200%)
Zooming magnification ratios 50 ∼200% (151 steps in 1% increments)
Manual steps (manual,
photo) 5 steps
AR-F152
2 – 2

Section Item Details Spec.
Copy speed First copy time Tray paper feed 9.6 sec. or below (A4), 9.4 sec. or below (8-1/2" ×
14") (Pre-heat mode: 16 sec. or below / Auto power-
shut-off mode: 23 sec. or below)
Manual paper feed 10.0 sec (Pre-heat mode: 16 sec. or below / Auto
power-shut-off mode: 23 sec. or below)
AB system: A4
(Landscape) Copy speed (CPM) Same size 15
Enlargement 15
Reduction 15
B5 (Landscape) Copy speed (CPM) Same size 15
Enlargement 15
Reduction 15
Inch system 8-1/2″
×14″(Landscape) Copy speed (CPM) Same size 12
Enlargement 12
Reduction 12
8-1/2″×11″
(Landscape) Copy speed (CPM) Same size 15
Enlargement 15
Reduction 15
Max. continuous copy
quantity 99
Void
Void area
Leading edge 1 ∼4mm
Trailing edge 4mm or less, 6mm or less
(Duplex copying/both images)
Side edge void area
4.0mm or less (per side), 4.5mm or less
(Duplex copying/both images: per side)
machine with side edge void 0.5mm ∼4mm (Total of
both edge voids)
Image loss OC mode Leading edge Same size: 3.0mm or less / Enlarge (200%): 2.0mm
or less / Reduction (50%): 6.0mm or less
SPF/R-SPF/
Duplex Leading edge Same size: 4.0mm or less / Enlarge (200%): 3.0mm or less / Reduction (50%): 8.0mm or less
Warm-up time 0 sec.
Power save mode reset time 0 sec.
Paper jam recovery time 0 sec.
2. Basic specifications of facsimile (AR-F152 only)
Large Item Middle Item Small Item Sub Item Spec.
Communi-
cation system Transmission method
Transmission time Approx. 6 sec. (G3 ECM/14,400bps)
Transmission Method V17, V29, V27TER, V33 (Only Receiving)
Compression method MH, MR, MMR
Modem speed 14,400bps →2,400bps automatic fall back
Mutual transmission G3
Line used Public Switched Telephone Network (PSTN), Private
Branch exchange (PBX),
Number of lines used 1 line (cannot be added)
ECM YES
Scanning
system Document size
Max. document width OC: B4 SPF: B4 (Multi)/ 257 ×500 (Single)
Unscannable region Leading edge 1 to 4 mm, trailing edge: 4mm max., left
end + right end: either 4mm max.
Transmitted document size SPF: Max. 10.1" ×19.7" SPF: Min. 8.5" ×5.5"(Inch System)
SPF: 210 ×148mm (AB system)
Document size designation B4, 8-1/2, A4, B5, A5, 5/2
Two-sided document
designation NO
AR-F152
2 – 3

Large Item Middle Item Small Item Sub Item Spec.
Scanning
system Document size Long document 500 mm (Single Feed with hand hold)
Scanning
system
Automatic
document
detection
SPF YES (Over or Under B4 size)
OC NO
Transmission
mode SPF/OC transmission changeover NO
Document
loading capacity,
scanning cycle
(SPF
performance)
Continuous, automatic feed
compatibility NO
Document loading capacity SPF: 30 sheets
Document scanning cycle 13 sheets/min. (Standard mode, A4R memory
transmission)
processing
system
Half tone
reproduction Half tone (photo mode)
Equivalent to 256 scales
Following functions are not possible in half-Tone mode
in B4 size.
●Timer sending
●Memory sending
●Broadcast
●To store the original for memory polling.
Resolution 8 dot /mm ×7.7 line / mm (Fixed)
Contrast
adjustment Contrast selection Manual in 3 stages (AE)
Resolution
selection
Standard 8 dot / mm ×3.85 line / mm
Fine 8 dot / mm ×7.7 line / mm
Super fine 8 dot / mm ×15.4 line / mm
Finest NO
Printer section
resolution 600dpi
Print system
Printing size Max. printing width 215.9 mm
Print paper size detection YES (Only width): A4/Letter or small size
Printing size A4/Letter/Legal
Print paper
Cassette capacity 250 ×2 (1 tray option for Europe)
Print paper absence
detection By failing paper pick up
Exit Paper Tray Full sensor NO
Feed Paper cassette
Trans-
mission
function
system
Easy dialing
function
Rapid key dialing 20 other parties
Speed dialing 100 other parties
Group dialing 20 groups (including the other parties registered to rapid
key dialing)
Phonebook transmission By using the SEARCH key: Any other parties registered to speed dialing and rapid key dialing can be searched
for using the first letter.
Chain dialing YES
Redialing The last number dialed is saved
Program NO
Mode recall NO
Time
designation
function
Time specified
transmission/polling Time of day specified for transmission or polling. Max.3
AR-F152
2 – 4

Large Item Middle Item Small Item Sub Item Spec.
Trans-
mission
function
system
Recall mode
Automatic recall mode
when other party is busy Intervals 1 to 15 minutes
Count 1 to 14 times/0: no re-transmission
Recall mode when
communication error occurs
Intervals 1 to 15 minutes
Count 1 to 14 times/0: no re-transmission
Transmitted
Pages Beginning with the page where error occurred
Number of transmissions
counted in recall mode
simultaneously Max. 20 transmissions
Subsequent transmission
reservation override in
recall mode YES
Memory Trans-
mission/direct
transmission
Memory transmission
Memory
Transmission YES
Number of
transmission
Reservations
that can be
made
Max. 20
Processing
when memory is
full
Transmission is cancelled when using Timer, Group or
Broadcast function. Only scanned’ data is transmitted.
∗The number of pages to be actually sent does not
always correspond to the one passing through the
SPF in case of communication error.
∗The transmission is cancelled when communication
error occurs.
Setting change
After
Transmission
Setting
NO
Direct transmission YES
Default setting By Memory All Clear
Line sound
monitoring
function
Dialing confirmation
monitoring YES (Service Man diagnostic.)
Broadcast
function
Broadcast transmission
Number of
destinations 50 destinations (Including the Group Dial)
Transmission
method Broadcast key, group key
Usable numbers Rapid or Speed keys
Group dialing Transmitted to group registered to rapid keys or speed
dial.
Boadcast
function Relay transmission
Instructing
Station NO
Relay station NO
Multiple relay NO
Number of relay
groups NO
Number of
Receiving
stations that
may be
Specified per
Group
NO
Confidential
function Confidential transmission Other party’s Station NO
Batch
transmission
function Batch transmission NO
AR-F152
2 – 5

Large Item Middle Item Small Item Sub Item Spec.
Trans-
mission
function
system
Priority function
Transmission reservation
interrupt NO
Broadcast interrupt NO
Recall mode interrupt NO
Multiple
message
transmission
function
Multiple message
transmission NO
Rotational
Transmission Rotational transmission Paper size NO
Book document
transmission Book document transmission
Transmission
method YES (From OC mode)
Consecutive
page
transmission
(page splitting)
NO
OK stamp OK stamp NO
Remote
transmission
(polling
transmission
function)
Remote transmission
(Memory Polling) Remote Transmission YES (From Memory)
Protective function
Check by other
Party’s number NO
Check by
Matching of
System number
(user’s own
machine) and
ID number
(other party’s
Machine)
(between Sharp
machines only)
NO
Receiving
function
system
Receiving mode
Default setting Automatic receiving (can be switched to A.M mode or
manual receiving in key operator program)
Automatic receiving
Number of calls
0 to 9 times (factory-set to twice: can be changed in
key operator program)
- The external telephone rings once if set the number
of calls for automatic receiving to 0 times.
Automatic
phone/fax
switching NO
Manual receiving Manual
receiving setting YES
Receiving mode
Manual receiving
Number of
Switching calls
to automatic
Receiving in
manual
receiving mode
OFF/1 to 9 times
Telephone message
receiver connection
Answering
Machine mode YES
Automatically
switch to
automatic receive ON / OFF
Quiet detect time OFF/ 1 to 9 sec.
Receiving mode
timer switching NO
AR-F152
2 – 6

Large Item Middle Item Small Item Sub Item Spec.
Receiving
function
system
Variable scale
factor receiving Reduction
Reduction made
within Regular
size YES (ON/OFF in key operator program)
By received
data print size
Designation YES
Enlargement NO
Memory
receiving function Substitute receiving into memory
Substitute
Receiving into
Memory Only when data cannot be output
Forced memory
receiving NO
Received data
override Output NO
Transfer Transfer at occurrence of
trouble YES
Number
specified
receiving
Receiving of only specified
number enabled NO
Anti junk fax mode YES (ON/OFF) 10 group, 20 letters
Confidential
function Confidential receiving
Sender NO
Mailbox NO
Mailbox name NO
Confidential ID
code NO
Rotational
receiving NO
Split receiving Split size YES
Split receiving setting YES (according to paper selection condition in key
operator program)
Two-sided
document
receiving NO
2-in-1 receiving NO
Transmission
request (polling
receiving
function)
Transmission request
Transmission
Request YES
Resolution at
transmission
Request Depends on the Sending Machine.
Turnaround
transmission NO
Registration
system Number registration
Speed dialing
Number of other
parties 100 other parties
Number of other
party’s Number
digits 20 digits
Registered name 20 letters (may be omitted)
Speed dialing
Searched letters Up to 1 letter
User tag
Classification NO
International
communication
mode setting NO
Transmission
method Speed dialing key + (00 to 99) + start key
AR-F152
2 – 7

Large Item Middle Item Small Item Sub Item Spec.
Registration
system
Number
registration
Rapid key dialing
Number of other
parties 20 other parties
Number of other
party’s Number
digits 20 digits
Registered name 20 letters (may be omitted)
Searched letters Up to 1 letter
User tag
Classification NO
International
communication
mode setting NO
Transmission
method Rapid key dialing
Group dialing
Registration keys Rapid keys
Max. number of
registered other
parties per group 50 other parties
Registrable
Number Numbers registered to speed dialing and rapid key dialing.
Registered name 20 letters (may be omitted)
Searched letters NO
User tag
Classification NO
Transmission
method Group dialing
Program
Number of
programs NO
Registerable item NO
Registered name NO
Calling method NO
Setting change
After calling NO
Batch
Registration key NO
Number of other
parties NO
Registration
method NO
Sender
Registration Sender registration Sender’s name 24 letters, registered in key operator program
Sender’s number 20 digits, registered in key operator program
Transmission
request/remote
transmission
enable number
registration
Transmission request
enable number
Transmission
Request source
Number
Registration
NO
System number System number
Registration NO
ID number ID number
Registration NO
Letter input Input method Key input YES
Letters that may be input Characters Alphanumeric characters, symbols
Registered data
read-out, read-in NO
Date & time
adjustment Registered in key operator program Support terms is from 1990 to 2089.
Date indication
change NO
Backup Registered data backup at
power failure SRAM used, built-in battery-backed
AR-F152
2 – 8

Large Item Middle Item Small Item Sub Item Spec.
Telephone
Function
System
Handset NO
On-hook YES
Hold NO
Pause YES (2 second fixed)
Phone
transmission at
power failure NO
Ringer volume Adjusted in key operator program
Speaker volume Adjusted by pressing arrow keys on the fax control panel
Tone pulse
switching Switched between 10 pps and TONE in key operator program (North America)
External
telephone
connection
YES
Remote receiving switching YES (switching number in 1 digit +**) 0 to 9
Automatic
telephone/fax
switching
NO
Audio response NO
Response voice recording NO
Fax Memory
Memory capacity Standard 2MB (Approx. 120 pages/A4)
Option NO
Memory Back up
Yes
Job memory back up: Approx. 1 hour (after min. 6
minutes charge)
Configuration Memory back up to 5 years.
Memory
Contents
(transmission
reservation)
confirmation
LCD indication NO
Print out YES
Memory remain
indication YES (Memory available percent display 3 digits in % on LCD
Additional
information
printing
function for
transmission
Page counter NO
Date printing YES (Year: month: day/ year in 4 digits)
LCD: 2 digits / Print: 4 digits
Date indication change NO
Cover function Cover item
Other party’s
name YES
Other party’s
number YES
Sender’s name YES
Sender’s number YES
Transmission
message YES
Transmission
message Regular message NO MESSAGE/URGENT/
IMPORTANT/CONFIDENTIAL/PLS.DISTRIBUTE/PLS.
CALL BACK
User message NO
Sender printing
function Sender’s number 20 digits
Sender’s name 24 letters
Additional
printing
function for
receiving
Index printing YES
AR-F152
2 – 9

Large Item Middle Item Small Item Sub Item Spec.
Record table
system
Communication
record function
Communication record table
size A4, LETTER, Legal (not output if size setting is not A4, LETTER, legal or larger)
Communication record
memory capacity 50 communications for transmission/receiving respectively
Communication record table
Number of
communications 50 communications for transmission/receiving respectively
Time-specified
output
YES 5 kinds, Every day, Each 2 day, Each 4 day, Once
a week, OFF
The print time is fixed at 00:00.
When recording
Memory is full NO
Printing
sequence LAST IN LAST OUT
Department-by-
department
output NO
Time-specified
communication table Common to transmission record table
Confidential receiving
confirmation table NO
Communication
result report
function
Communication result table
(transmission) YES (ALWAYS PRINT, ERROR/ TIMER, SEND ONLY, NEVER PRINT, ERROR ONLY)
Broadcast transmission
report NO
Communication result table
(receiving) YES
Document image printing
when memory transmission
is not yet made NO
Other report/list
Rapid key dialing list YES (output as telephone number list)
Speed dialing list YES (output as telephone number list)
Group dialing list YES
Transmission activity list YES
ID/sender list NO
Batch transmission
confirmation list NO
Confidential ID list NO
Option setting list YES
Telephone list YES
Timer list YES
Anti junk fax number list YES
Receptions activity List YES
Memory image erasure list NO
Others
Other party
confirmation
function
Other party confirmation
display NO
CSI function CSI YES
Department
management
Department-by-department
user restriction NO
Number of set departments NO
Department-by-department
charge management function NO
Operation panel
display LCD 20 letters by 2 lines
AR-F152
2 – 10

Large Item Middle Item Small Item Sub Item Spec.
Others
Auto startup
mode NO
Distinctive Ring
(Only North
America and
Australia)
YES
Power
consumption Energy star compatibility YES
Automatic
Summer Set
(Only Europe) YES
PBX setting
(Only Europe) YES
AR-F152
2 – 11

[3] CONSUMABLE PARTS
1. Supply system table
A. SEC governments
No. Name Content Life Product name Package Remark
1 Toner CA(Black) with IC Toner
(Toner :Net Weight 210g)
Polyethylene bag
×10
×10
65K AR-152MT-J 1 ∗Life setup is based
on A4 6%.
MT=NT∗10
B. SEC/SECL/LAG
No. Name Content Life Product name Package Remark
1 Toner CA(Black) with IC Toner
(Toner :Net Weight 210g)
Polyethylene bag
×10
×10
65K AR-152MT 1 ∗Life setup is based
on A4 6%.
MT=NT∗10
2 Developer Developer
(Developer: Net Weight 170g) ×10 250K AR-152MD 1 MD=ND∗10
3 Drum kit Drum
Drum fixing plate ×1 ×1 25K AR-152DR 10
Note: Printing of the master/individual cartons is made in 2 languages, English/French.
Packed together with the machine: DR 25K/Developer UN/Process UN
C. Europe subsidiaries/East Europe/SCA/SCNZ
No. Name Content Life Product name Package Remark
1 Toner CA(Black) with IC Toner
(Toner :Net Weight 210g)
Polyethylene bag
×10
×10
65K AR-152LT 1 LT=T∗10
2 Developer Developer
(Developer :Net Weight 170g) ×10 250K AR-152LD 1 LD=DV∗10
3 Drum kit Drum
Drum fixing plate ×1 ×1 25K AR-152DM 10
Note: Printing of the master/individual cartons is made in 4 languages, English/French/German/Spanish.
Packed together with the machine: DR 25K/Developer UN/Process UN
D. SMEF (Middle East, Africa) Israel/Russia/CIS/Taiwan/Philippines
No. Name Content Life Product name Package Remark
1 Toner CA(Black) with IC Toner
(Toner :Net Weight 210g)
Polyethylene bag
×10
×10
65K AR-152ET 1 ∗Life setup is based
on A4 6%.
ET=FT∗10
2 Developer Developer
(Developer :Net Weight 170g) ×10 250K AR-152CD 1 CD=SD∗10
3 Drum kit Drum
Drum fixing plate ×1 ×1 25K AR-152DR 10
Note: Printing of the master/individual cartons is made in 4 languages, English/French/German/Spanish.
Packed together with the machine: DR 25K/Developer UN/Process UN
E. Asia (Subsidiary)
No. Name Content Life Product name Package Remark
1 Toner CA(Black) with IC Toner
(Toner :Net Weight 210g)
Polyethylene bag
×10
×10
65K AR-152CT 1 ∗Life setup is based
on A4 6%.
CT=ST∗10
2 Developer Developer
(Developer :Net Weight 170g) ×10 250K AR-152CD 1 CD=SD∗10
3 Drum kit Drum
Drum fixing plate ×1 ×1 25K AR-152DR 10
Note: Printing of the master/individual cartons is made in 4 languages, English/French/German/Spanish.
Packed together with the machine: DR 25K/Developer UN/Process UN
AR-F152
3 – 1

F. SRH/SOCC Chinese language version
No. Name Content Life Product name Package Remark
1 Toner CA(Black) with IC Toner
(Toner :Net Weight 210g)
Polyethylene bag
×10
×10
65K AR-152CT-C 1 ∗Life setup is based
on A4 6%.
CTC=STC∗10
2 Developer Developer
(Developer :Net Weight 170g) ×10 250K AR-152CD-C 1 CDC=SDC∗10
3 Drum kit Drum
Drum fixing plate ×1 ×1 25K AR-152DR-C 10
Note: Printing of the master/individual cartons is made in 2 languages, English/Chinese.
Packed together with the machine: DR 25K/Developer UN/Process UN
2. Environmental
The environmental conditions for assuring the copy quality and the
machine operations are as follows:
(1) Normal operating condition
Temperature:20˚C~25
Humidity:65 ±5%RH
(2) Acceptable operating condition
(3) Optical condition
(4) Supply storage condition
3. Production control number(lot No.)
identification
〈Developing cartridge〉
∗:Destination
Division No.
EX Destination A same pack G
B same pack H
Option Destination AP
BQ
〈Drum cartridge〉
The label on the drum cartridge shows the date of production.
(SOCC production)
〈JAPAN production〉
Humidity (RH)
85%
60%
20%
10˚C 30˚C 35˚C
Humidity (RH)
90%
60%
15%
–25˚C 30˚C 40˚C
Humidity (RH)
90%
20%
–5˚C 45˚C
Production month
Production day
Destination code
(Dealer, distributor, OEM, etc.)
Production place
(SOCC: Fixed to B.)
End digit of year
Version No.
Production month
Production day
Destination code
(Dealer, distributor, OEM, etc.)
Production place
(SOCC: Fixed to B.)
End digit of year
Version No.
X000119Ver.A 1
Production month
(1-9=Jan. - Sep. 0 = Oct. X = Nov. Y = Dec.)
Serial number of month
Fixed to 1.
Pack division
(See table below)
End digit of year
Version No.
AR-F152
3 – 2

Division No.
Ex production 1
Option 2
Same pack 3
∗1 The production control label is not attached to the cartridge of a
China product.
4. TD cartridge replacement
1) Open the front and side cabinets of the copier.
2) Keep holding Toner lover, and
3) Carefully pull out Toner unit from the copier.
4) Put Toner unit in a collection bag immediately after removing it from
the copier
Note: Never carry exposed Toner unit. Be sure to put it in the col-
lection bag.
Production control
label attachment position
Production control
label attachment position(*1)
1
3
2
AR-F152
3 – 3

[4] EXTERNAL VIEWS AND INTERNAL STRUCTURES
1. Appearance
1 Operation panel 2 Original table 3 SPF exit area ∗1
4 Original guides ∗1 5 Document feeder tray ∗1 6 FAX operation panel ∗1
7 Original cover 8 Side cover 9 Bypass tray
10 Bypass tray guides 11 Side cover open button 12 Front cover
13 Paper tray 14 R-SPF exit area ∗2 15 Middle tray ∗2
16 Original guides ∗2 17 Document feeder tray ∗2 18 Feeding roller cover ∗2
19 Handle 20 Cover for optional printer interface ∗21 Paper output tray
22 Paper output tray extension 23 Power switch 24 Power cord socket
∗A GDI expansion kit is optional. ∗1 AR-F152 only ∗2 AR-156 only
2. Internal
1 Toner cartridge lock release lever 2 Toner cartridge 3 Photoconductive drum
4 Transfer charger 5 Charger cleaner 6 Fusing unit release lever
34
6
5
2
1
13
12
7
8
10
9
11
AR-F152 only
24
23
19
20
21
22
19
14 15 16
17
18
AR-156 only
1
2
3
4
5
6
AR-F152
4 – 1

3. Operation panel
1
Exposure mode selector key and indicators
Use to sequentially select the exposure modes: AUTO,
MANUAL or PHOTO. Selected mode is shown by a lit
indicator.
2
Light and dark keys and exposure indicators
Use to adjust the MANUAL or PHOTO exposure level.
Selected exposure level is shown by a lit indicator.
Use to start and terminate user program setting.
3
Alarm indicators
:Developer replacement required indicator
:Misfeed indicator
:TD cartridge replacement required indicator
:Maintenance indicator
4SPF indicator
(AR-156, AR-F152 only)
5SPF misfeed indicator
(AR-156, AR-F152 only) 6
Copy ratio selector key and copy ratio indicators
Use to sequentially select preset reduction/enlargement
copy ratios.
Selected copy ratio is shown by a lit indicator.
7Zoom indicator 8Copy ratio display (%) key
9Display Displays the specified copy quantity, zoom copy ratio,
user program code, and error code. 10
ON LINE indicator / ON LINE KEY
Lights up when the machine is used as a printer.
To use as a printer, an optional printer expansion kit is
needed.
(AR-151, AR-156 only)
11
ON LINE KEY
Changes between the on-line and off-line modes when
the PCL expansion kit has been installed and a PCL
printer is used.
Changes modes from the off-line to on-line when the
GDI expansion kit has been installed and a GDI printer
is used.
(AR-151, AR-156 only)
12
DATA indicator
Indicates that the printer is receiving or processing print
data. To use the copier as a printer, an optional PCL
expansion kit is needed.
(AR-151, AR-156 only)
13 Power save indicator
Lights up when the copier is in a power save mode. 14 Tray select key
Use to select a paper feed station (paper tray or
bypass tray).
15 Paper feed location indicators
Light up to show the selected paper feed station. 16 Zoom keys
Use to select any reduction or enlargement copy ratio
from 50% to 200% in 1% increments.
17 Copy quantity keys • Use to select the desired copy quantity (1 to 99).
• Use to make user program entries. 18
Clear key
• Press to clear the display, or press during a copy run
to terminate copying.
• Press and hold down during standby to display the
total number of copies made to date.
19 Print key and ready indicator • Copying is possible when the indicator is on.
• Use to set a user program. 20 Duplex Mode select key and indicator
(AR-156 only)
1 2 3 4 5 6 7 8 9 10 11 12 13
191817161514
20
AR-F152
4 – 2
