Sharp DV-SL80U User manual

POWER PLAY STOP SKIP OPEN/CLOSE
REV FWD
DVD Video Player
MODEL
DV-SL80U
OPERATION MANUAL
Please read this Operation Manual carefully
before using your DVD Video Player.
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
1

–2–EN
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO
WIDE SLOT, FULLY INSERT.
ATTENTION: POUR ÉVITAR LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA
PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET
POUSSER JUSQU’AU FOND.
CAUTION:
THIS UNIT IS A CLASS 1 LASER PRODUCT.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
AS THE LASER BEAM USED IN THIS UNIT IS HARMFUL TO THE EYES, DO NOT ATTEMPT TO DISAS-
SEMBLE THE CABINET.
REFER SERVICING TO QUALIFIED PERSONNEL ONLY.
This symbol warns the user of uninsulated
voltage within the unit that can cause danger-
ous electric shocks.
This symbol alerts the user that there are
important operating and maintenance instruc-
tions in the literature accompanying this unit.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USER SER-
VICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
For future reference, record the serial number (located on the rear of the
Unit) in the space provided.
Products that have earned ENERGY STAR
®
are designed to protect the environment through superior energy efficiency.
Model No.: DV-SL80U
Serial No.:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
INFORMATION
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guar-
antee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
“WARNING—FCC Regulations state that any unauthorized changes or modifications
to this equipment not expressly approved by the manufacturer could void the user’s
authority to operate this equipment.”
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Este aparato digital de la Clase B cumple con la norma ICES-003 de Canadá.

–3–EN
IMPORTANT SAFEGUARDS
1) Read Instructions - All the safety and operating instruc-
tions should be read before the product is operated.
2) Retain Instructions - The safety and operating instructions
should be retained for future reference.
3) Heed Warnings - All warnings on the product and in the
operating instructions should be adhered to.
4) Follow Instructions - All operating and use instructions
should be followed.
5) Cleaning - Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.
6) Attachments - Do not use attachments not recommended
by the product manufacturer as they may cause hazards.
7) Water and Moisture - Do not use this product near water -
for example, near a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement; or near a swimming pool;
and the like.
8) Accessories - Do not place this
product on an unstable cart, stand,
tripod, bracket, or table. The prod-
uct may fall, causing serious injury
to a child or adult, and serious dam-
age to the product. Use only with a
cart, stand, tripod, bracket, or table
recommended by the manufacturer,
or sold with the product. Any
mounting of the product should follow the manufacturer’s
instructions, and should use a mounting accessory recom-
mended by the manufacturer.
9) A product and cart combination should be moved with
care. Quick stops, excessive force, and uneven surfaces
may cause the product and cart combination to overturn.
10) Ventilation - Slots and openings in the cabinet are provid-
ed for ventilation and to ensure reliable operation of the
product and to protect it from overheating, and these open-
ings must not be blocked or covered. The openings should
never be blocked by placing the product on a bed, sofa,
rug, or other similar surface. This product should not be
placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacturer's
instructions have been adhered to.
11) Power Sources - This product should be operated only
from the type of power source indicated on the marking
label. If you are not sure of the type of power supply to
your home, consult your product dealer or local power
company. For products intended to operate from battery
power, or other sources, refer to the operating instructions.
12) Grounding or Polarization - This product may be equipped
with a polarized alternating-current line plug (a plug hav-
ing one blade wider than the other). This plug will fit into
the power outlet only one way. This is a safety feature. If
you are unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit, con-
tact your electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the polarized plug.
13) Power-Cord Protection - Power-supply cords should be
routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying par-
ticular attention to cords at plugs, convenience receptacles,
and the point where they exit from the product.
14) Lightning - For added protection for this product during a
lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent
damage to the product due to lightning and power-line
surges.
15) Power lines - An outside antenna system should not be
located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into
such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them
might be fatal.
16) Overloading - Do not overload wall outlets, extension
cords, or integral convenience receptacles as this can
result in a risk of fire or electric shock.
17) Object and Liquid Entry - Never push objects of any kind
into this product through openings as they may touch dan-
gerous voltage points or short-out parts that could result in
a fire or electric shock. Never spill liquid of any kind on
the product.
18) Servicing - Do not attempt to service this product yourself
as opening or removing covers may expose you to danger-
ous voltage or other hazards. Refer all servicing to quali-
fied service personnel.
19) Damage Requiring Service - Unplug this product from the
wall outlet and refer servicing to qualified service person-
nel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the
product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following
the operating instructions. Adjust only those controls
that are covered by the operating instructions as an
improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the product to its normal
operation,
e) If the product has been dropped or damaged in any way,
and
f) When the product exhibits a distinct change in perfor-
mance - this indicates a need for service.
20) Replacement Parts - When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer or have the same character-
istics as the original part. Unauthorized substitutions may
result in fire, electric shock, or other hazards.
21) Safety Check - Upon completion of any service or repairs
to this product, ask the service technician to perform safe-
ty checks to determine that the product is in proper oper-
ating condition.
22) Heat - The product should be situated away from heat
sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
PORTABLE CART WARNING
S3125A

Copy Protection
This Unit supports Macrovision copy protection.
On DVD discs that include a copy protection code, if the contents of the
DVD disc are copied using a VCR, the copy protection code prevents the
videotape copy from playing normally.
Recommended Measures for Optimum Picture Excellence
This Unit is a precision device constructed using extremely accurate technology.
• The disc cannot be played if the disc drive component is worn out or if the internal pick up lens is dirty.
• If this unit still does not perform properly although you refer to the relevant sections and to TROUBLESHOOTING GUIDE
on page 18, the laser optical pickup unit may be dirty. Consult a Sharp Authorized Service Center for inspection and clean-
ing of the laser optical pickup unit.
Notice for progressive scan outputs
Consumers should note that not all high definition television sets are fully compatible with this product and may cause arti-
facts to be displayed in the picture. In case of 525 progressive scan picture problems, it is recommended that the user switch
the connection to the ‘standard definition’ output. If there are questions regarding our TV set compatibility with this model
525p DVD player, please contact our customer service center.
Warning of Dew Formation
Dew may form on the pickup lens in the following conditions.
• When the unit is suddenly moved from a cold environment to a warm one.
• Immediately after a heater has been turned on. • In a steamy or very humid room.
If dew forms inside this unit, it may not operate properly. In this case, turn on the power and wait about one hour for the dew
to evaporate.
Others
It is the intent of Sharp that this product be used in full compliance with the copyright laws of the United States and that prior
permission be obtained from copyright owners whenever necessary.
Apparatus Claims of U.S. Patent Nos. 4,631,603,
4,577,216, 4,819,098 and 4,907,093 licensed for
limited viewing uses only.
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and
other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protec-
tion technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses
only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Manufactured under licence from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby
Laboratories.
–4–
FEATURES
¡Progressive Scan system
¡Dolby Digital sound
This player can handle Dolby Digital surround sound having
5.1 channels when connected to a Dolby Digital decoder.
¡Still/fast/slow/step playback
¡Rapid Play
Playback in slightly faster/ slower speed while keeping the
sound quality as in the normal playback.
Rapid Play is available only on discs recorded in the
Dolby Digital format.
¡Random playback for audio CD and MP3
¡Program playback for audio CD and MP3
¡DVD menus in a desired language
¡Screen saver/Auto power-off functions
The screen saver program starts when there is no input
from the player for 5 minutes in the stop mode. When the
screen saver program is activated for 30 minutes, the
power is automatically turned off.
¡Subtitles in a desired language
¡Selecting a camera angle
¡Choices for audio language and sound mode
¡Parental lock
¡Automatic detection of discs
This player automatically detects if a loaded disc is DVD,
audio CD or MP3 disc.
¡Playing an MP3 disc
¡Direct Search
¡On-screen display
Information about the current operation can be displayed
on a TV screen, allowing you to confirm the currently
active functions (such as program playback), on the TV
screen using the remote control.
¡Search
Chapter search / Title search / Track search / Time search
¡Repeat
Chapter / Title / Track / Group / All / A-B
¡Zoom
¡Marker
The part designated by user can be called back.
¡Resume Play
¡Virtual Surround
¡Component Video Out Jacks
Jacks located on the back of the DVD Player which are used to
send high-quality video to a TV via Component Video In Jacks.
¡Dimmer
¡Bit rate indication
¡DRC (Dynamic range control)
You can control the range of sound volume.
¡Black Level Setting
Service
1. Do not attempt to service this Unit yourself. Instead, unplug it and contact a qualified service technician. (See LIMITED
WARRANTY at the end of this manual.)
2. Be sure the service technician uses authorized replacement parts or their equivalents. Unauthorized parts may cause fire,
electrical shock, or other hazards.
3.
Following any service or repair, be sure the service technician performs safety checks to certify that this Unit is in safe operating order.
EN
“Licensed under one or more of U.S. Pat. 4,972,484, 5,214,678, 5,323,396, 5,530,655, 5,539,829, 5,544,247,
5,606,618, 5,610,985, 5,740,317, 5,777,992, 5,878,080, or 5,960,037.”

–5–EN
TABLE OF CONTENTS
■ IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . . . . . . 3
■ FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
■ INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Symbols Used in this Manual. . . . . . . . . . . . . . . . . . . . . 5
Supplied Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 5
■ ABOUT THE DISCS . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Playable Discs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Disc Types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
■ FUNCTIONAL OVERVIEW . . . . . . . . . . . . . . . . . . . . . . 7
FRONT PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
REAR VIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . 7
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Displays During Operation . . . . . . . . . . . . . . . . . . . . . . . 8
Loading the Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . 8
■ HOOK UPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connecting to a TV using a VIDEO OUT Jack
or a S-VIDEO OUT Jack . . . . . . . . . . . . . . . . . . . . . . . . 8
Connecting to an Amplifier Equipped with Digital Input
Jacks such as MD deck or DAT deck . . . . . . . . . . . . . . . 9
Connecting to a Dolby Digital decoder . . . . . . . . . . . . . . 9
Connecting to a TV or a Stereo TV that has
Component VIDEO In Jacks . . . . . . . . . . . . . . . . . . . . . 9
■ PLAYING A DISC . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Basic Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
General Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Pause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Disc Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Title Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Step by Step Playback. . . . . . . . . . . . . . . . . . . . . . . . . 10
Rapid Play. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Resume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Playing the disc recorded in VR mode
(Video Recording format) . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Fast Forward / Reverse . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Slow Forward / Reverse . . . . . . . . . . . . . . . . . . . . . . . 11
Zoom. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Track Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Title / Chapter Search . . . . . . . . . . . . . . . . . . . . . . . . . 12
Time Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Repeat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
A-B REPEAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Program (CD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Random Playback (CD) . . . . . . . . . . . . . . . . . . . . . . . . 12
MP3 Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Program (MP3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Random Playback (MP3) . . . . . . . . . . . . . . . . . . . . . . . 13
Stereo Sound Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Audio Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Subtitle Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Camera Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Changing the On-Screen Display. . . . . . . . . . . . . . . . . 14
Marker Setup Screen. . . . . . . . . . . . . . . . . . . . . . . . . . 14
Black Level Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Virtual Surround . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
■ DVD SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Audio Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Parental Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
PARENTAL LEVEL. . . . . . . . . . . . . . . . . . . . . . . . . . 15
IF YOU FORGET THE PASSWORD . . . . . . . . . . . . . 15
PARENTAL CONTROL LEVELS. . . . . . . . . . . . . . . . 15
Display Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Language Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Returning all selections of SETUP
(except for PARENTAL) to their default settings . . . . . . 16
■ TROUBLESHOOTING GUIDE. . . . . . . . . . . . . . . . . . . 18
■ SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
■ MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
■ SERVICE INFORMATION . . . . . . . . . . . . . . . . . . . . . . 19
Symbols Used in this Manual
INTRODUCTION
The following symbols appear below in some headings and
notes in this manual, with the following meanings!
: Description refers to playback of DVD video discs. (includ-
ing DVD-RW/R, DVD+RW/R discs (Video mode only))
: Description refers to playback of audio CDs.
: Description refers to playback of MP3 discs.
: Description refers to playback of the VR mode (Video
Recording format).
*The VR mode (Video Recording format) is a recording
mode to enjoy editing the program or “manual mode” for
recording in desired resolution and time.
(QUICK)
: Basic setup can be performed more quickly by selecting
(QUICK setup menu).
DVD-RW
MP3
CD
DVD
VR mode
■ IMPORTANTES MEDIDAS DE SEGURIDAD Y PRECAU-
CIONES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
■ CONTROLES DE OPERACIÓN Y FUNCIONES . . . . . 22
PANEL DELANTERO / PANEL TRASERA . . . . . . . . 22
MANDO ADISTANCIA . . . . . . . . . . . . . . . . . . . . . . . 22
Visualización . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Visualizaciones Durante la Operación . . . . . . . . . . . . . 23
Instalación de las Pilas . . . . . . . . . . . . . . . . . . . . . . . . 23
■ CONEXIONES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Conexión a un TV utilizando una toma
VIDEO OUT o una toma S-VIDEO OUT. . . . . . . . . . . . 23
Conexión a un Amplificador Equipado con tomas de
Entrada Digital, Platina MD o Platina DAT . . . . . . . . . . 23
Conexión a un Descodificador Dolby Digital . . . . . . . . . 23
Conexión a un Televisor o a un Televisor Estéreo Que
tenga tomas Component Video in . . . . . . . . . . . . . . . . 23
■ REPRODUCCIÓN DE UN DISCO . . . . . . . . . . . . . . . . 23
Reproducción básica . . . . . . . . . . . . . . . . . . . . . . . . . . 23
INDICE
• Remote control (9HSNA999UD)
• Two AA batteries
• Operation Manual
• Audio/Video cables
Supplied Accessories

–6– EN
Disc Types
[DVD]
Data on a DVD is divided into sections
called "titles", and then into subsections
called "chapters", each of which is given
a title or chapter number. Playback condi-
tions are preset on some DVD video
discs, and these playback conditions take
priority over user operations on this play-
er. If a function you selected do not run
as desired, refer to the manual accompa-
nying the disc.
[Audio CD]
Data on an audio CD is divided into
sections called “tracks”, each of which
is given a track number.
[MP3]
Data on an MP3 disc is divided into
sections called "groups", and then into
subsections called "tracks", each of
which is given a group or track number.
• You can play back discs which bear the marks on page 19. If you use nonstandardized discs, this unit may not play them
back. Even if they are played back, the sound or video quality will be compromised.
• This player conforms to the NTSC color system.You cannot play discs recorded in other color systems such as PAL or SECAM.
• Some discs include region codes as shown below.
• The number inside the symbol refers to a region of the world, and a disc encoded in a specific region format can only be
played back on DVD player with the same region code.
:This label indicates playback compatibility with DVD-RW discs recorded in VR mode (Video Recording Format).
NOTE: This player cannot play the DVD-RW that supports CPRM (Contents Protection for Recordable Media).
1
ABOUT THE DISCS
Playable Discs
The following discs can be played back on this DVD player.
¡DVD video ¡DVD-RW/R* ¡DVD+RW/R* ¡Audio CD ¡CD-RW/R* ¡MP3*
* Depending on the types or the writing method of the medium some discs can not be played.
For DVD+RW/R, only discs recorded in the Video mode can be played back.
• Some DVD-RW/R, DVD+RW/R, or CD-RW/R discs made on personal computers, or on DVD recorders may not be played back prop-
erly due to the factors such as scratches, dirt or special properties of the disc.
•
Discs made on personal computers may not be played back properly due to the different environment or the settings of the application you
use. We recommend always to use the standardized, correctly formatted discs. (Please contact the sales agency for more detail).
Selecting 525p (480p) Progressive Scan or 525i (480i) Interlaced Playback
• If your TV is compatible with 525p (480p) progressive scanning, connect the TV to the Component Video Output jacks of
the DVD player and set “PROGRESSIVE” to “ON” in the display setting. Next, set your TV to the progressive scan mode.
Refer to page 16 for instructions on changing the display setting.
• If your TV is not compatible with progressive scan, set “PROGRESSIVE” to “OFF”.
• Use a commercially available adaptor if the video input jacks of your TVs or monitors are the BNC type.
What is Progressive Scanning?
• Unlike conventional interlace scanning, the progressive scan system provides less flickering and images in higher resolution
than that of traditional 525i (480i) television signals.
Example
Title 1 Title 2
Chapter 1 Chapter 2 Chapter 1 Chapter 2Chapter 3 Chapter 4
Example
Track 1 Track 2 Track 3 Track 4 Track 5 Track 6
Example
Group 1 Group 2
Track 1 Track 2 Track 5 Track 6Track 3 Track 4
¡On the following discs, only the sound can be heard (picture cannot be viewed).
CDV, CD-G
¡NEVER play back the following discs. Otherwise, malfunction may result!
DVD-RAM, CD-I, Photo CD, Video CD,
DVD with region codes other than 1 or ALL,
DVD-ROM for personal computers,
DTS-CD,
CD-ROM for personal computers
¡On the following disc, the sound MAY NOT be heard.
Super Audio CD
NOTE: Only the sound recorded on the normal CD layer can be delivered.
The sound recorded on the high density Super Audio CD layer cannot be delivered.
¡Any other discs without compatibility indications are NOT PLAYABLE.
For Customer Use:
Read carefully the information located at the bottom of your DVD player and enter below the Serial No.Retain this informa-
tion for future reference.
Model No. DVD player : DV-SL80U
Serial No. __________________________

–7–EN
AUDIO OUT
DIGITAL AUDIO OUT
COAXIAL
LY
VIDEO
OUT CB/ PBS-VIDEO
OUT
CR/ PRCOMPONENT
VIDEO OUT
R
11 12 13 1514
10
REAR VIEW
243519
7
6
POWER BPLAY CSTOP HSKIP G
E REV FWD D
AOPEN/CLOSE
8
FRONT PANEL
REMOTE CONTROL
RETURN
ZOOM
MODE
MENU
SKIPPAUSEA-B
REPEAT
ANGLE
AUDI O
SUB
TITLE
CLEAR
TOP MENU
STOP
PLAY
FWDREV
SETUP
ENTER
OPEN/
CLOSE
SEARCH
MODE
DISPLAY
123
456
789
0 +10
POWER
1
2
3
4
5
6
7
8
9
10
11
14
12
13
15
18
19
17
16
21
20
22
24
25
26
23
DVD VIDEO PLAYER
1. POWER
to switch the player to ON or OFF
2. PLAY
to start or resume disc playback
3. STOP
to stop playback
4. SKIP H/ REV h
goes to previous chapter or track during playback; press
and hold for 1.5 seconds for a reverse search
5. SKIP G/ FWD g
goes to next chapter or track during playback; press and
hold for 1.5 seconds for a forward search
6. OPEN/CLOSE
to open/close the disc tray
7. Disc tray
8. Remote sensor window
9. Display
10. MAIN (AC Power Cord)
connect to a standard AC outlet
FUNCTIONAL OVERVIEW
11. COAXIAL (Digital audio out)
connect to AUDIO inputs of a digital (coaxial) audio
equipment
12. AUDIO OUT (Left/Right)
connect to AUDIO inputs of an amplifier, receiver or
stereo system
13. VIDEO OUT
connect to the Video Input of a TV
14. COMPONENT VIDEO OUT
connect to a TV with Component video in jacks
15. S-VIDEO OUT
connect to a TV with S-Video inputs
CAUTION:
• Do not touch the inner pins of the jacks on the rear
panel. Electrostatic discharge may cause perma-
nent damage to the player.
10. REV Button [page 11]
Fast reverse playback to a desired point.
11. PLAY Button [page 10]
Starts playback of the disc contents.
12. SETUP Button [page 15]
Press to enter the setup mode or to change setup items.
13. MODE Button [page 10, 12, 13, 15]
Activates program playback or random playback
mode.(CD/MP3)
Activates the Virtual Surround, Black level, or Rapid
Play.(DVD)
14. ZOOM Button [page 11]
Enlarges part of a DVD-reproduced image.
15. TOP MENU Button [page 10]
Displays the title menu.
16. ENTER Button [page 10]
Press to accept a setting.
17. RETURN Button [page 15]
Returns to the previous operation.
18. Arrow Buttons (
o / p / s / B ) [page 10]
Use when making settings while watching the display on
a TV screen.
19.
MENU Button [page 10]
Displays the DVD menus and MP3 file lists.
20. STOP Button [page 10]
Stops operation of the disc.
21. FWD Button [page 11]
Fast forwards playback to a desired point.
22. SKIP H Button [page 11]
Plays back from the beginning of the current chapter or
track.
23. SKIP G Button [page 11]
Plays back from the beginning of the next chapter or track.
24. Numerical Buttons [page 11]
25. OPEN/CLOSE Button [page 10]
Press to insert discs into or remove them from the tray.
26. SEARCH MODE Button [page 11, 14]
Press to locate a desired point or to memorize your
favorite places on a disc.
1. DISPLAY Button [page 14]
Displays the current status on the TV screen for checking purposes.
2. POWER Button [page 10]
Press to turn the power on and off.
3. AUDIO Button [page 13]
Press to select a desired audio language or sound mode.
4. SUBTITLE Button [page 14]
Press to select a desired subtitle language.
5. ANGLE Button [page 14]
Press to change the camera angle to see the sequence
being played back from a different angle.
6. REPEAT Button [page 12]
Repeats playback of the current disc, title, chapter or track.
7. A-B REPEAT Button [page 12]
Repeats playback of a selected section.
8. CLEAR Button [page 12]
Resets a setting.
9. PAUSE Button [page 10]
Pause playback temporarily/frame-by-frame playback.

–8–EN
1. Open the battery compartment cover.
2. Insert two AA batteries, with each one
oriented correctly.
3. Close the cover.
NOTES:
• Do not mix alkaline and manganese
batteries.
• Do not mix old and new batteries.
Loading the Batteries
FUNCTIONAL OVERVIEW
Display
Displays During Operation
Lights up when the inserted
disc is being played back.
Displays a type of the disc
which is inserted on the tray.
• DVD: DVD
• CD: Audio CD, MP3
Lights up when the
inserted disc comes
to a pause.
Lights up when the
A-B repeat function is on Lights up when the repeat function is on.
Lights up when playing back
in slow mode. (DVD)
Displays the elapsed time of the title
or track.The number of a new title,
chapter, or track is displayed when
a chapter or track is switched.
Lights up when the ALL
repeat function is on.
GROUP P.SCAN
DVD
CD
Lights up when the
progressive scan
system is activated.
Power on
No disc inserted or
cannot read the disc
Tray open
Tray closed
Loading the Disc
Power off
HOOK UPS
CAUTION:
• Be sure to turn off the Player and equipment to be connected before connecting.
• Read through the operation manual for the equipment to be connected.
• Be sure that the colors of the jacks and plugs match up when using Audio/Video cables.
• Be sure to keep the Player connection cables separate from the TV antenna cable when you install the Player, because
it may cause electrical interference when you are watching television programs.
Connecting to a TV using a VIDEO OUT Jack or a S-VIDEO OUT Jack
AUDIO OUT
DIGITAL AUDIO OUT
COAXIAL
LY
VIDEO
OUT CB/ PBS-VIDEO
OUT
CR/ PRCOMPONENT
VIDEO OUT
R
To Right (red)
and Left (white)
AUDIO OUT jacks
A/V-compatible or
wide screen TV
To VIDEO INPUT jack
To Right (red) and Left (white)
AUDIO INPUT jacks
To S-VIDEO OUT jackTo S-VIDEO INPUT jack
To VIDEO OUT jack
or
Stereo system
A/V-compatible
or
wide screen TV
AUDIO OUT
DIGITAL AUDIO OUT
COAXIAL
LY
VIDEO
OUT CB/ PBS-VIDEO
OUT
CR/ PRCOMPONENT
VIDEO OUT
R
or
To VIDEO INPUT jack
To Right (red) and Left (white)
ANALOG AUDIO INPUT jacks
To VIDEO OUT jack
To S-VIDEO
INPUT jack
To S-VIDEO
OUT jack
To Right (red)
and Left (white)
AUDIO OUT jacks
The S-VIDEO connection provides a better quality video signal than the VIDEO (COMPOSITE) output. Use a commercially
available S-VIDEO cable to connect from the Player to the TV.
• When the Player is connected to a TV using both a VIDEO cable and an S-VIDEO cable, only the S-VIDEO connection is
enabled (the VIDEO connection is disabled).
• You will not be able to hear all of the sound being output by the Player if you use the VIDEO/AUDIO cable (supplied) to a
monaural TV that has only one AUDIO input jack.

–9–EN
HOOK UPS
NOTES:
• Connect the DVD player directly to a TV. If the Audio/Video cables are connected to a VCR, pictures may be distorted due
to the copy protection system.
• Be sure to turn off the power to all components in the system before connecting another component.
• Refer to the Operation Manuals for your TV, stereo system and any other components to be connected to the DVD player.
• This player does not support DTS audio.
Connecting to an Amplifier Equipped with Digital Input Jacks such as MD deck or DAT deck
Use an audio coaxial digital cables (not included) for the audio connections. Connecting to an amplifier equipped with digital
input jacks such as MD Deck or Dat Deck.
Amplifier equipped with digital
input jacks, MD deck,
DAT deck, etc.
A/V-compatible
or
wide screen TV
AUDIO OUT
DIGITALAUDIO OUT
COAXIAL
LY
VIDEO
OUT CB/ PBS-VIDEO
OUT
CR/ PRCOMPONENT
VIDEO OUT
R
To COAXIAL DIGITAL
AUDIO OUT jack
To VIDEO INPUT jackTo VIDEO OUT jack
To S-VIDEO
INPUT jack
To S-VIDEO
OUT jack
To COAXIAL DIGITAL
AUDIO INPUT jack
or
NOTES:
• The audio source on a disc in a Dolby Digital 5.1 channel surround format cannot be recorded as digital sound by an
MD or DAT deck.
•
Set “DOLBY DIGITAL” to “DPCM” for audio output in the setup mode. Playing a DVD using incorrect settings may generate
noise distortion, and may also damage the speakers. (Refer to page 15 to change the audio settings.)
HOW TO CONNECT TO A TV WITHOUT AUDIO/VIDEO INPUT JACKS
If your TV does not have RCA type audio and video input jacks it is still possible to connect this DVD player to your TV’s 75-ohm coaxi-
al antenna terminal using a commercially available Stereo Audio/Video RF Modulator. Connect the audio and video outputs of the DVD
player to the audio and video inputs on the RF Modulator, and then connect the coaxial output of the RF Modulator (usually marked
“TO TV”) to the 75 ohm coaxial antenna terminal on your TV. Follow the instruction supplied with the RF Modulator for more details.
If your TV’s 75 ohm coaxial antenna terminal is already occupied by an antenna or cable box connection, remove that cable from your
TV’s antenna terminal and reconnect it to the coaxial antenna input terminal of the RF Modulator (usually marked “ANT IN”), then con-
nect the RF modulator to your TV’s antenna terminal as described above.
NOTE
• The picture quality from DVD discs will not be as good if the DVD player is connected to the TV’s antenna terminal through an RF Modulator.
Connecting to a TV or a Stereo TV that has Component VIDEO In Jacks
A/V-compatible
or
wide screen TV
Stereo system
AUDIO OUT
DIGITALAUDIO OUT
COAXIAL
LY
VIDEO
OUT CB/ PBS-VIDEO
OUT
CR/ PRCOMPONENT
VIDEO OUT
R
To Right (red) and
Left (white)
AUDIO OUT jacks
To Right (red) and Left (white)
ANALOG AUDIO INPUT jacks
To COMPONENT
VIDEO INPUT jack
To COMPONENT
VIDEO OUT jack
NOTES:
• If the output is Dolby Digital-encoded audio, connect a Dolby Digital decoder, and set “DOLBY DIGITAL” to “BITSTREAM” for
audio output in the setup mode.
• Unless connected to a Dolby Digital decoder, set “DOLBY DIGITAL” to “DPCM” for audio output in the setup mode. Playing a
DVD using incorrect settings may generate noise distortion, and may also damage the speakers.
Connecting to a Dolby Digital decoder
If using this DVD player to play back a DVD in a Dolby Digital 5.1 channel surround format, the DVD player outputs a Dolby Digital data stream from
its COAXIAL DIGITAL AUDIO OUT jack. By hooking the player up to a Dolby Digital decoder, you can enjoy a more convincing, realistic ambience
with powerful and high-quality surround sound of a professional standard as can be heard in movie theaters.
Use audio coaxial digital cables (commercially available) for the audio connections.
A/V-compatible
or
wide screen TV
Front
speaker
(left)
Center speaker
Front
speaker
(right)
Surround
speaker
(left)
Surround
speaker
(right)
Subwoofer
Dolby Digital
decoder
AUDIO OUT
DIGITALAUDIO OUT
COAXIAL
LY
VIDEO
OUT CB/ PBS-VIDEO
OUT
CR/ PRCOMPONENT
VIDEO OUT
R
To COAXIAL
DIGITAL AUDIO
OUT jack
To VIDEO INPUT jackTo VIDEO OUT jack
To S-VIDEO
INPUT jack
To S-VIDEO
OUT jack
To COAXIAL DIGITAL
AUDIO INPUT jack
or
NOTE:
• If your TV is compatible with 525p (480p) progressive scanning, connect the TV to Component Video Output jacks of the
DVD player, and make sure that “PROGRESSIVE” is “ON”. Refer to page 16 for more details.

–10 –EN
During playback, press PAUSE.
• Playback will pause and sound will be muted.
The disc goes forward by one frame each time PAUSE is
pressed.
To exit step by step playback, press PLAY.
NOTE:
• Set STILL MODE to FIELD on the Display menu if pictures
during step by step playback are blurred. (Refer to page16.)
3
2
1
DVD-RW
DVD
Step by Step Playback
During playback, press PAUSE.
• Playback will pause and sound will be muted.
To continue playback, press PLAY.
NOTE:
• Set STILL MODE to FIELD on the Display menu if pictures
in the pause mode are blurred. (Refer to page 16.)
2
1
MP3CDDVD-RWDVD
Pause
Getting started
• Turn on the power of the TV, amplifier and any other com-
ponents which are connected to the DVD player.
• Make sure the TV and audio receiver (commercially avail-
able) are set to the correct channel.
Press POWER.
• “P-ON” will appear briefly on the display panel.
Press OPEN/CLOSE to open disc
loading tray.
Place the chosen disc on the tray, with
the label facing up.
Press PLAY.
• The tray will close automatically, and
playback will then start from the first chapter or track of
the disc. If the playback does not start automatically,
press PLAY.
• When you playback the DVD which a title menu is
recorded, it may appear on the screen. In this case,
refer to “TITLE MENU”.
Press STOP to stop playback.
NOTES:
• A “prohibited icon” may appear at the top-right
on the TV screen during operation, warning
that a prohibited operation has been encoun-
tered by the DVD player or the disc.
• With DVDs that use some titles for playback program
signals, playback may start from the second title, or it
may skip these titles.
• During the playback of two layered disc, pictures may
stop for a moment. This happens when the 1st layer
switches to the 2nd layer. This is not a malfunction.
•
A DVD-RW disc recorded in the VR mode may freeze
momentarily during playback depending on how the
playlist was made and edited (deleted titles, repeated
recording).
5
4
3
2
1
MP3CDDVD-RWDVD
Press MENU.
• The DVD main menu will appear.
If the feature is not available, symbol may appear on
the TV screen.
If disc menu is available on the disc, audio language,
subtitle options, chapters for the title and other options
will appear for selection.
Press Arrow ( o / p / s / B )to select an item, and
ENTER to confirm selection.
4
3
2
1
DVD
PLAYING A DISC
Basic Playback Disc Menus
VR mode
VR mode
VR mode
Press TOP MENU.
• The title menu will appear.
If the feature is not available, symbol may appear
on the TV screen.
Press Arrow ( o / p / s / B )to select an item, and
ENTER to confirm selection.
• Playback will begin at the selected Title.
To call up a menu screen during playback
• Press MENU to call up the DVD main menu.
• Press TOP MENU to call up the title menu.
NOTE:
• Contents of menus and corresponding menu opera-
tions may vary between discs. Refer to the manual
accompanying the disc for details.
3
2
1
Title Menu
DVD
Available only on discs recorded in the Dolby Digital format,
Rapid Play plays back in slightly faster/ slower speed while
keeping the sound quality as in the normal playback.
During playback, press MODE.
• The current setting appears.
Press ENTER to switch among (x1.3), (x0.8) and OFF.
: Plays back approximately
at 0.8 times of normal playback.
: Plays back approximately at 1.3 times of normal
playback.
To return to normal playback, press PLAY.
NOTES:
• Audio (language) setting cannot be changed while
using this mode.
• Virtual Surround and Black Level settings cannot be
changed while using this mode.
•
Virtual Surround does not function while using this mode.
• This feature may not work at some point in a disc.
• When using digital audio connection (COAXIAL), the
PCM sound will be output.
3
2
1
DVD
Rapid Play
MDD
DVD may contain menus to navigate the disc and access
special features. Enter an appropriate number or use Arrow
( o / p / s / B )to highlight your selection in the DVD main
menu and press ENTER to confirm.
NOTE:
• Unless stated, all operations described are based on
remote control use. Some operations can be carried
out using the menu bar on the TV screen.
General Features

–11 –EN
During playback, press FWDgor REVhrepeatedly
to select the required forward or reverse speed.
• For DVDs, fast forward or reverse speed is different
depending on the disc. Approximate speed is 1 (x2),
2(x8), 3 (x50), and 4 (x100).
• For audio CDs, the approximate speed is x16.
• For MP3, the approximate speed is x8.
• If you are using FWDgor REVhon the front
panel, press and hold it for more than a few seconds.
When you reach the desired speed, release the button.
To return to normal playback, press PLAY.
2
1
MP3CDDVD-RWDVD
Fast Forward / Reverse
During playback, press PAUSE.
Press FWDgor REVh.
• Slow motion playback will begin and sound will be
muted.
2
1
DVD-RWDVD
Slow Forward / Reverse
There are three ways to begin playback on an audio CD,
MP3 disc at a specific Track.
Using the Numerical buttons
Press the numerical buttons to enter the desired Track
number.
• Playback will start at the selected track.
• For single digit tracks (1-9), press a single number
(eg. track 3, press 3).
• To play track 26, press +10, 2, 6 on the numerical but-
tons.
Using the SEARCH MODE.
Press SEARCH MODE.
• The track search display appears.
Within 30 seconds, select a desired track number using
the numerical buttons. For single digits press “0” first.
• Playback will start at the selected track.
Using the SKIP HG
During playback, press SKIP G to move to the next track.
Press it quickly and repeatedly to skip subsequent tracks.
Press SKIP Hto go back to the beginning of the current
track. Press it repeatedly to go to the previous tracks.
• Track number will appear briefly on the DVD display
panel.
•IfSKIP HGis pressed while the playback is
paused, the playback will be paused again after skip-
ping to the next track.
NOTE:
•SKIP HGare not available when playback is
stopped.
2
1
1
MP3CD
Track Search
PLAYING A DISC
During playback, press STOP.
• Resume message will appear on the TV screen.
Press PLAY, playback will resume from the point at
which playback was stopped.
• To cancel resume, press STOP again.
•
To stop playback, press STOP twice from playback mode.
NOTE:
• For MP3, playback will resume from the beginning of the
current track.
2
1
CD
DVD-RW
DVD
Resume
DVDs recorded in VR mode can have a PLAYLIST assigned to
alter the order or content to be played. If a PLAYLIST has been
created, you can choose the ORIGINAL or PLAYLIST option.
Press MENU in stop mode.
• The current setting screen will appear.
• Pressing MENU during playback is not valid.
Press s or Bto select ORIGINAL or PLAYLIST.
• PLAYLIST will not be displayed when it has not been made.
• Resume playback will not be possible if you change the set-
ting.
Press K or L to select a title, then press ENTER.
• Playback will start.
NOTE:
• [ORIGINAL]: A list of titles which are recorded with a DVD
recorder.
[PLAYLIST]: A list of titles which is made based on the
ORIGINAL edited list.
3
2
1
DVD-RW
Playing the disc recorded in
VR mode (Video Recording format)
ORIGINAL PLAYLIST
1 PLAYLIST1
2 PLAYLIST2
3 PLAYLIST3
4 PLAYLIST4
5 PLAYLIST5
6 PLAYLIST6
VR mode
The Zoom function allows you to enlarge the video image
and to pan through the enlarged image.
Press ZOOM during playback.
• Playback will continue.
Press ZOOM repeatedly to select the required zoom fac-
tor: x2, x4 or OFF.
Use Arrow (
o / p / s / B )to move the zoomed picture
across the screen.
To exit zoom mode, press ZOOM to OFF.
NOTES:
• Zooming function does not work while disc menu is
shown.
• x4 zoom is not available on some discs.
4
3
2
1
DVD-RWDVD
Zoom
VR mode
VR mode
VR mode
VR mode
Press FWDgor REVhrepeatedly to select the
required speed.
• Slow forward or reverse speed is different depending
on the disc. Approximate speed is 1 (1/16), 2 (1/8), and
3 (1/2).
• If you are using FWD gor REV hon the front
panel, press and hold it for more than a few seconds.
When you reach the desired speed, release the button.
To return to normal playback, press PLAY.
NOTE:
• Set STILL MODE to FIELD on the Display menu if pic-
tures in the slow playback mode are blurred. (Refer to
page 16.)
4
3

–12 –EN
You may determine the order in which tracks will play.
Press MODE (playback must
first be stopped).
• The PROGRAM screen
appears.
Press ▲or ▼to select a
track, then press ENTER.
•
Press CLEAR to erase the
most recently entered program.
Press PLAY to play the programmed tracks.
NOTES:
• Press STOP once and then PLAY again, playback will
restart from the point where STOP was pressed.
• Press STOP twice and then PLAY. Playback starts
from the first track in the original order. However, the
program can be called back when you follow the above
steps.Your programs will be stored unless either the
disc tray is opened or power is turned off.
• Up to 99 tracks can be entered.
• To erase all tracks in the program at once, select ALL
CLEAR at the bottom of the list at Step2.
• To repeat the current track in the program, press REPEAT
repeatedly until TRACK appears during playback. If
you like to repeat the entire program press REPEAT
repeatedly until ALL appears during playback.
3
2
1
Program (CD)
PLAYING A DISC
A-B REPEAT
Press A-B REPEAT at your chosen starting point.
• A- appears briefly on the TV screen.
Press A-B REPEAT again at your chosen end point.
• A-B appears briefly on the TV screen, and the repeat
sequence begins.
To exit the sequence, press A-B REPEAT.
NOTES:
• The A-B REPEAT section can only be set within the cur-
rent title (for DVDs), or current track (for audio CDs).
• A-B REPEAT is not available with some scenes in DVD.
• To cancel the A point which was set, press CLEAR.
• A-B REPEAT playback does not function during title,
chapter, track or all repeat playback.
3
2
1
CDDVD-RWDVD
NOTES:
• The REPEAT setting will be cleared when moving to
other track.
• Repeat playback does not function during A-B REPEAT
playback.
To activate the repeat function, press REPEAT during playback.
• The repeat mode changes as described below every time
you press the button.
CD
0:03:30
TRACK ALL OFF
(current track repeat) (entire disc repeat) (repeat off)
VR mode
MP3
TRACK ALL OFF
(current track repeat) (entire disc repeat)
(repeat off)
GROUP
(current group repeat)
CD
This shuffles the playing order of tracks instead of playback in
the sequence.
In stop mode, press MODE
repeatedly until the RANDOM
screen appears.
Press PLAY to start random
playback.
NOTE:
•T o repeat the current track in the random selection, press
REPEAT repeatedly until TRACK appears during play-
back. To repeat the entire random selection press REPEAT
repeatedly until ALL appears during playback.
2
1
CD
Random Playback (CD)
To activate the repeat function, press REPEAT during playback.
• The repeat mode changes as described below every time
you press the button.
DVD
NOTES:
• Repeat Title/Chapter is not available with some scenes.
• The REPEAT setting will be cleared when moving to
other title or chapter.
Repeat
The repeat function is available only during playback.
CHAPTER TITLE OFF
(current chapter repeat) (current title repeat) (repeat off)
CHAPTER TITLE
OFF
(current chapter repeat) (current title repeat) (repeat off)
ALL
(entire disc repeat)
VR mode
DVD-RW
Press SEARCH MODE repeatedly until the Time Search
screen appears.
Within 30 seconds, enter a desired disc time using the
numerical buttons.
• Playback will start at the specified time.
• When there is no need to enter a number, “0” appears auto-
matically. For example, “0:0_:_ _” appears in the Time Search
display if the total time of the disc is less than 10 minutes.
NOTE:
• Press CLEAR to erase the incorrect input.
2
1
CDDVD-RWDVD
Time Search
VR mode
Press SEARCH MODE repeat-
edly until the Chapter or Title
search screen appears.
Enter the desired chapter/title num-
ber using the numerical buttons.
NOTE:
• Depending on the disc being played, this function can
also be performed by directly entering the desired
chapter number using numerical buttons. Refer to the
manual accompanying the disc.
2
1
DVD-RWDVD
Title / Chapter Search
/2
VR mode

–13 –EN
PLAYING A DISC
When a CD with MP3 files is inserted in the DVD player and
MENU is pressed, the FILE LIST will appear on the display.
The number of tracks is also displayed on the front panel.
Press Kor Lto select the desired group (folder) or track.
• If a group (folder) is select-
ed, press B or ENTER to
go on to the track selection
screen. Press Kor Lto
choose a track, then press
PLAY or ENTER.
• If a track is selected, press
PLAY or ENTER to start
playing tracks. Starting from the one that has been cho-
sen and the subsequent tracks will be played.
• Press TOP MENU to return to the first item.
Press STOP to stop playback.
NOTES:
• Folders are known as Groups; files are known as Tracks.
• Folders are accompanied by icon.
• MP3 files are accompanied by icon.
• Maximum of 255 folders can be recognized.
• Maximum of 512 files can be recognized.
• Up to 8 hierarchies can be created.
This player recommends the use of files recorded at the below
specifications:
• Sampling frequency: 44.1kHz or 48kHz
• Constant bit rate: 112kbps ~ 320kbps.
2
1
MP3 Playback
folder name
folder name 1
folder name 2
folder name 3
folder name 4
file name 1
file name 2
file name 3
MP3
Information on MP3 files
• This DVD player can play back images and sounds from
data recorded in MP3 formats on CD-RW and CD-R
discs.
•A file with an extension of “.mp3 (MP3)” is called an “MP3
file”.
•The DVD player can run an image file conforming to the
Exif specification. Exif is a file format, Exchangeable
Image File format established by Japanese Electronic
Industry Development Association (JEIDA).
•Files whose extension is other than “.mp3 (MP3)” will not
be listed in the MP3 menu.
•If the file is not recorded in MP3 format, noise may be
produced even if the file extension is “.mp3 (MP3)”.
•The name of group and track can be displayed in up to 25
characters. Unrecognizable characters will be replaced
with asterisks. The ninth and deeper hierarchies cannot
be displayed.
•Unplayable groups or tracks may be displayed depending
on the recording conditions.
•If TOP MENU is pressed when a file list is displayed, the
first item will be highlighted.
The DVD player allows you to select a language (if more
than one languages are available) during DVD disc playback.
Press AUDIO during playback.
Press AUDIO repeatedly to select your desired language.
NOTES:
• The sound mode cannot be changed during playback of
discs not recorded in double sound.
• Audio language selection cannot be made during Rapid
Play. (Refer to page 10.)
• Pressing AUDIO may not work on some DVDs with multi-
ple audio languages (e.g. DVDs which allow audio lan-
guage setting on the disc menu).
NOTES (for VR mode only) :
• Pressing AUDIO cycles the sound mode through MAIN,
SUB, MAIN + SUB.
• DVD-RW discs recorded in double sound (two languages )
can be played back in MAIN, SUB or MAIN + SUB.
• With discs recorded in VR mode, c hanging the audio
(MAIN, SUB or MAIN+SUB) is effective only when using an
analogue connection. Although you may be able to change
the settings of the on-screen display, it will not affect the
sound when using a digital connection.
2
1
DVD-RWDVD
Audio Language
In stop mode, press MODE repeatedly until the RAN-
DOM screen appears.
Press PLAY to play the tracks in random order.
2
1
MP3
Random Playback (MP3)
VR mode
NOTES:
• To erase all tracks in the program at once, select ALL
CLEAR at the bottom of the list at Step 2.
• Press STOP once and then PLAY again, playback will
restart from the beginning of the track at which STOP
was pressed.
• Press STOP twice and then PLAY. Playback starts
from the first track in the original order. However, the
program can be called back when you follow the above
steps.Your programs will be stored unless either the
disc tray is opened or power is turned off.
MAIN
SUB
MAIN
SUB
Display on
the TV screen
Mode
MAIN
SUB
MAIN+
SUB
Main Audio
Main Audio
Sub Audio
Sub Audio
Main Audio
Sub Audio
L
R
L
R
L
R
AUDIO OUTPUT
Program (MP3)
This feature allows you to program an MP3 disc to play in a
desired sequence.
Press MODE (playback must first be stopped).
• The PROGRAM screen will appear.
Press Kor Lto select a track, then press ENTER, to
save it in a program.
• Press CLEAR to erase the incorrect input.
Press PLAY to start programmed playback.
3
2
1
MP3
Press AUDIO repeatedly during playback to select
between STEREO, L-CH or R-CH.
STEREO - both right and left channels are active (stereo)
L-CH - only left channel is active
R-CH - only right channel is active
NOTE:
• If the Virtual Surround setting is ON, the sound mode will
be fixed to STEREO, and can not be changed.
1
CD
Stereo Sound Mode

If you are playing a DVD-RW
with setting the PLAYLIST, the
following will also be displayed.
ORG: Playing the ORIGINAL.
PL: Playing the PLAYLIST.
Press DISPLAY again to remove the display.
Press DISPLAY during playback, the current Track will be
displayed on the TV screen.
• The elapsed and remaining playing time of the current
track will be displayed.
Press DISPLAY again to show current Total Track.
• The elapsed and remaining playing time of the current
total track will be displayed.
Press DISPLAY again to remove the display.
Press DISPLAY during playback of an MP3 disc.
• The name of the file currently in play will be displayed.
Press DISPLAY again to show the track number, the
elapsed time (for MP3 only), the repeat status, and the
playback status at the top of the screen.
• will be displayed when the repeat play has been
selected.
T- indicates Track repeat
G- indicates Group (folder) repeat
A- indicates All (disc) repeat
Press DISPLAY again to exit.
3
2
1
MP3
3
2
1
CD
4
–14 –EN
PLAYING A DISC
Some DVDs contain scenes which have been shot simulta-
neously from various angles.You can change the camera
angle when the ( ) icon appears on the screen. If the
ANGLE ICON setting is OFF in the Display setting, the ( )
icon will not appear. (Refer to page 16.)
Press ANGLE during playback.
• The selected angle will be displayed on the display bar
at the top of the screen.
Press ANGLE repeatedly to select your desired angle.
2
1
DVD
Camera Angle
Use markers to memorize your favorite places on a disc.
During playback, press SEARCH MODE repeatedly until
you see the Marker Setup screen. .
• The Marker Setup screen appears on the TV display.
Press sor Bto select a Marker (1 ~ 10), and ensure
that “- : - - : - -” appears in the display.
When it reaches the desired point, press ENTER.
• Selected number will turn to and the point will be
marked.
• The Title or Track and elapsed playing time will appear
in the TV screen.
To return to the Marker later during playback, press
SEARCH MODE repeatedly until you see the Marker
Setup screen. Press sor Bto choose the desired
marker (one of the mark), then press ENTER.
NOTES:
• Opening the disc tray or turning off the power or select
AC (All Clear) at step and press ENTER will erase
all Markers.
• To clear a marker using sor B, position the cursor on
to the marker number to be cleared and press CLEAR.
• You can mark up to 10 points.
Press SEARCH MODE or RETURN to exit.
5
2
4
3
2
1
CDDVD-RWDVD
Marker Setup Screen
VR mode
You can check information about the current disc by pressing
DISPLAY on the remote control.
Press DISPLAY during playback to show current Chapter.
• The elapsed and remaining
playing time of the current
chapter will be displayed.
Press DISPLAY again to show current Title.
• The elapsed and remaining playing time of the current
title will be displayed.
Press DISPLAY again.
• The BIT RATE and the current repeat setting will be
displayed.
• If you are playing a dual layered disc, the layer number
will also be displayed ( L0: Layer 0 is playing. L1: Layer
1 is playing).
3
1
1
DVD-RWDVD
Changing the On-Screen Display
9/49 0:03:21 -0:02:15
IIII ORGT
VR mode
The DVD player allows you to select a language for subtitle
(if available) during DVD disc playback.
Press SUBTITLE during playback.
Press SUBTITLE repeatedly to select your desired subti-
tle language.
• The selected language will be displayed on the display
bar at the top of the screen.
To turn off subtitles, press SUBTITLE repeatedly until
OFF appears.
NOTES:
• Some discs allow audio language setting/subtitle language
setting on the disc menu. (Operation varies between discs,
so refer to the manual accompanying the disc.)
• If the desired language is not shown after pressing SUB-
TITLE several times, the disc does not have a subtitle in
that language.
• If you choose a Language that has a 3 letter language
code, the code will be displayed every time you change
the Subtitle language setting. If you choose any other lan-
guages, ‘---’ will be displayed instead. (Refer to page 17.)
• Pressing SUBTITLE may not work on some DVDs with
multiple subtitle languages (e.g. DVDs which allow sub-
title language setting on the disc menu).
3
2
1
DVD-RWDVD
Subtitle Language
VR mode

–15 –EN
Adjust the Black Level Settings to make the black parts of
the picture as bright as you prefer.
During playback, press MODE
repeatedly until the Black Level
Setting screen appears.
Press ENTER to switch ON/OFF.
ON : Makes the dark parts brighter.
OFF : Shows the picture as recorded.
Press MODE or RETURN to exit.
NOTES:
• The setting will be saved even if the player is turned off.
• This function cannot be used during Rapid Play. (Refer
to page 10.)
3
2
1
DVD-RWDVD
Black Level Setting
You can enjoy surround-sound effect over two speakers.
Press MODE repeatedly until the Virtual Surround screen
appears.
Press ENTER to set it to 1 (Natural
effect), 2 (Emphasized effect) or OFF.
Press MODE or RETURN to exit.
NOTES:
• The setting will be saved even if the player is turned off.
• The setting will not be effective unless the sound mode
is set to STEREO (for audio CDs).
•
Turn down the level or turn it “OFF” if the sound is distorted.
• This function cannot be used during Rapid Play. (Refer
to page 10.)
3
2
1
MP3CDDVD-RWDVD
Virtual Surround
OFF
VR mode
VR mode
ON
PLAYING A DISC
DVD SETUP
Audio Setting
Choose appropriate settings for best sound reproduction depen-
dent on your externally connected equipment. These settings
only affect DVD playback.
Press SETUP in STOP mode.
Press sor Bto select (CUS-
TOM), then press ENTER.
• On screen menu will appear.
Press
sor B to select (AUDIO), then ENTER to con-
firm.
Press Kor Lto select the items below, then press
ENTER.
DRC (Dynamic Range Control) :
• Choose ON t o compress the range
of sound volume.
• The default setting is ON.
• DRC function is available only on the discs recorded in
the Dolby Digital format.
DOWN SAMPLING :
• Choose ON to set down sampling to 48kHz.
• Choose OFF when outputting in the original sound.
• The default setting is ON.
•
When playing a disc with copyright protection, the sound
will be down sampled at 48kHz even if you set it to OFF.
• DOWN SAMPLING function is available only on digital
output of a disc recorded in 96kHz, and when the unit is
connected to another source using the digital out jack.
• DOWN SAMPLING function is available only on the
discs recorded in the Dolby Digital format.
DOLBY DIGITAL :
Set to BITSTREAM when the player is connected to Dolby
Digital Decoder.
(BITSTREAM : Output by Dolby Digital)
(DPCM : Convert the Dolby Digital to PCM)
• The default setting is BITSTREAM.
• You can also adjust the setting from (QUICK) setup menu.
Press SETUP to exit.
5
4
3
2
1
AUDIO
DRC ON
DOWN SAMPLING ON
DOLBY DIGITAL BITSTREAM
QUICK SETUP
PLAYER MENU ENGLISH
TV ASPECT
4:3 LETTER BOX
DOLBY DIGITAL BITSTREAM
Parental Control
Parental Control prevents disc being viewed that exceed the
set limit, unless a password is used. This feature allows you
to prevent discs with unsuitable scenes from being played by
your children.
•ALL All parental lock is cancelled.
•Level 8 DVD software of any grade (adult/general/children) can
be played back.
•Levels 7 to 2 Only DVD software intended for general use and
children can be played back.
•Level 1 Only DVD software intended for children can be played back,
with those intended for adult and general use prohibited.
PARENTAL CONTROL LEVELS
IF YOU FORGET THE PASSWORD
Press 4,7,3,7at step in the PARENTAL LEVEL section.
• Password will be cleared and parental level will be set to ALL.
Proceed the steps - again to set parental level.
742
41
PARENTAL LEVEL
Parental Level allows you to set the rating level of your DVD
discs. Playback will stop if the disc’s ratings exceed the level
you set.
Press SETUP in STOP mode.
Press sor Bto select (CUS-
TOM), then press ENTER.
Press sor Bto select
(PARENTAL), then press ENTER.
Enter your four-digit password.
Press Kor Lto select PARENTAL LEVEL, then press
ENTER.
Press Kor Lto select the desired level (ALL to LEVEL1),
then press ENTER.
• The rating levels continue on two menu screens. Press Kor L
to move to the next or previous screen to find the rating level.
Press SETUP to exit.
NOTES:
• When doing this for the first time, enter a 4-digit number
(except for 4737), then press ENTER. This number will
be used as the password from the second time onward.
• To change the password, press Kor Lto select
CHANGE at step , then press ENTER. Enter the four-
digit password, then press ENTER.
• With some DVDs, it may be difficult to find if they are com-
patible with parental lock. Be sure to check if the parental
lock function operates in the way that you have set.
• Record the password in case you forget it.
5
7
6
5
4
3
2
1
PARENTAL
PARENTAL LEVEL ALL

–16 –EN
Language options are not available with some discs.
Press SETUP in STOP mode.
Press sor Bto select
(CUSTOM), then press ENTER.
• On screen menu will appear.
Press sor Bto select (LAN-
GUAGE), then press ENTER to
confirm.
Press Kor Lto select the below items, then press
ENTER.
AUDIO :
• Sets the audio language.
SUBTITLE :
• Sets the subtitle language.
DISC MENU :
• Sets the language for DVD Menu.
PLAYER MENU :
• Sets the language for the On-Screen display.
• You can also adjust the setting from (QUICK) setup
menu.
Press Kor Lto select a setting, then press ENTER.
• If OTHER is selected in the AUDIO, SUBTITLE or DISC
MENU screen, press four-digit number to enter the
code for the desired language. (Refer to the language
code below.)
• Only the languages supported by the disc can be
selected.
Press SETUP to exit.
NOTE:
• Language Setting for Audio and Subtitle is not available
with some discs. Then use AUDIO and SUBTITLE.
Details are on pages 13 and 14.
6
5
4
3
2
1
Language Setting
LANGUAGE
AUDIO ORIGINAL
SUBTITLE OFF
DISC MENU ENGLISH
PLAYER MENU ENGLISH
Returning all selections of SETUP (except
for PARENTAL) to their default settings
This allows you to return all selections of SETUP (except for
PARENTAL) to their default settings.
Press SETUP in STOP mode.
Press sor Bto select (INI-
TIALIZE), then press ENTER.
Select YES.
Press SETUP to exit.
NOTE:
• When you cancel to initialize at
step , select NO.
3
4
3
2
1
QUICK SETUP
PLAYER MENU ENGLISH
TV ASPECT
4:3 LETTER BOX
DOLBY DIGITAL BITSTREAM
INITIALIZE
Initialize?
NO
YES
DVD SETUP
Display Setting
You can change certain aspects of the DVD display screens,
on-screen messages and the display panel on the front of
the DVD player.
Press SETUP in STOP mode.
Press sor Bto select (CUSTOM), then press ENTER.
• On screen menu will appear.
Press sor Bto select (DISPLAY), then ENTER to
confirm.
Press Kor Lto select the below items, then
press ENTER.
TV ASPECT :
• Press Kor Lfor an item
selection, then press ENTER.
• Select 4:3 LETTER BOX for a
black bars appears on top and
bottom of the screen.
• Select 4:3 PAN & SCAN for a
full height picture with both sides trimmed.
PAN & SCAN is only available on DVDs recorded with
this option, if not LETTER BOX mode will be used.
• Select 16:9 WIDE if a wide-screen TV is connected to
the DVD player.
• The default setting is 4:3 LETTER BOX.
• You can also adjust the setting from (QUICK) setup
menu.
STILL MODE :
• Press Kor Lfor an item selection (AUTO, FIELD, or
FRAME), then press ENTER.
• This adjusts the resolution of still pictures.
• AUTO is normally selected (default).
• If you select FIELD, still pictures will be stabilized
although they will be coarse due to little amount of
data.
• If you select FRAME, still pictures will be highly defined
although they will be blurred due to output of two fields
at the same time.
ANGLE ICON :
• Press ENTER repeatedly to turn Angle icon ON or
OFF.
• The default setting is ON.
AUTO POWER OFF :
• Press ENTER repeatedly to turn Auto Power off ON or
OFF.
• The default setting is ON and it will turn the DVD player
to off automatically after 35 minutes of no use.
PROGRESSIVE :
• Press Kor Lto set PROGRESSIVE to ON or OFF,
then press ENTER.
• The setting will be effective when you exit the setup
screen by pressing SETUP.
• When PROGRESSIVE is ON, “P.SCAN” appears on
the DVD player’s display.
• The default setting is OFF.
• Refer to page 6 for more details.
PANEL DISPLAY :
• Press Kor Lfor an item selection BRIGHT, DIMMER
or AUTO, then press ENTER.
• This adjusts the brightness of the display panel with the
factory default BRIGHT.
• When AUTO is selected, the display dims only during
playback.
Press SETUP to exit.
NOTE:
• Be sure to press SETUP, or the setting will not work.
5
4
3
2
1
DISPLAY
TV ASPECT
4:3 LETTER BOX
STILL MODE AUTO
ANGLE ICON ON
AUTO POWER OFF ON
PROGRESSIVE OFF
PANEL DISPLAY BRIGHT

–17 –EN
A-B
Abkhazian 4748
Afar 4747
Afrikaans 4752
Albanian 6563
Amharic 4759
Arabic 4764
Armenian 5471
Assamese 4765
Aymara 4771
Azerbaijani 4772
Bashkir 4847
Basque 5167
Bengali;Bangla 4860
Bhutani 5072
Bihari 4854
Bislama 4855
Breton 4864
Bulgarian 4853
Burmese 5971
Byelorussian 4851
C-E
Cambodian 5759
Catalan 4947
Chinese [CHI] 7254
Corsican 4961
Croatian 5464
Czech 4965
Danish [DAN] 5047
Dutch [DUT] 6058
English [ENG] 5160
Esperanto 5161
Estonian 5166
F-H
Faroese 5261
Fiji 5256
Finnish [FIN] 5255
French [FRE] 5264
Frisian 5271
Galician 5358
Georgian 5747
German [GER] 5051
Greek [GRE] 5158
Greenlandic 5758
Guarani 5360
Gujarati 5367
Hausa 5447
Hebrew 5569
Hindi 5455
Hungarian [HUN] 5467
I-K
Icelandic [ICE] 5565
Indonesian 5560
Interlingua 5547
Interlingue 5551
Inupiak 5557
Irish [IRI] 5347
Italian [ITA] 5566
Japanese [JPN] 5647
Javanese 5669
Kannada 5760
Kashmiri 5765
Kazakh 5757
Kinyarwanda 6469
Kirghiz 5771
Kirundi 6460
Korean [KOR] 5761
Kurdish 5767
L-N
Laothian 5861
Latin 5847
Latvian;Lettish 5868
Lingala 5860
Lithuanian 5866
Macedonian 5957
Malagasy 5953
Malay 5965
Malayalam 5958
Maltese 5966
Maori 5955
Marathi 5964
Moldavian 5961
Mongolian 5960
Nauru 6047
Nepali 6051
Norwegian [NOR] 6061
O-R
Occitan 6149
Oriya 6164
Oromo(Afan) 6159
Panjabi 6247
Pashto;Pushto 6265
Persian 5247
Polish 6258
Portuguese [POR] 6266
Quechua 6367
Rhaeto-Romance 6459
Romanian [RUM] 6461
Russian [RUS] 6467
S
Samoan 6559
Sangho 6553
Sanskrit 6547
Scots Gaelic 5350
Serbian 6564
Serbo-Croatian 6554
Sesotho 6566
Setswana 6660
Shona 6560
Sindhi 6550
Singhalese 6555
Siswat 6565
Slovak 6557
Slovenian 6558
Somali 6561
Spanish [SPA] 5165
Sundanese 6567
Swahili 6569
Swedish [SWE] 6568
T
Tagalog 6658
Tajik 6653
Tamil 6647
Tatar 6666
Telugu 6651
Thai 6654
Tibetan 4861
Tigrinya 6655
Tonga 6661
Tsonga 6665
Turkish [TUR] 6664
Turkmen 6657
Twi 6669
U-Z
Ukrainian 6757
Urdu 6764
Uzbek 6772
Vietnamese 6855
Volapuk 6861
Welsh 4971
Wolof 6961
Xhosa 7054
Yiddish 5655
Yoruba 7161
Zulu 7267
Language Code Language Code Language Code Language Code
If you choose a Language that has a 3 letter language code, the code will be displayed every time you change the Audio or Subtitle lan-
guage setting on pages 13 and 14. If you choose any other languages, ‘---’ will be displayed instead. (3 letter language code is written in
bracket.)
DVD SETUP

–18 –EN
TROUBLESHOOTING GUIDE
If the DVD player does not perform properly when operated as instructed in this Operation Manual, check the player, consult-
ing the following checklist.
NOTES:
• Some functions are not available in specific modes, but this is not a malfunction. Read the description in this Operation
Manual for details on correct operations.
• Playback from a desired track and random playback are not available during program playback.
• Some functions are prohibited on some discs.
Problem Solution
No power –Check if the AC power cord is properly connected.
No picture –Check if the TV is switched on.
–Check that the VIDEO cable is connected to the correct device (See Connecting
to a TV).
Distorted picture –Sometimes a small amount of picture distortion may appear. This is not a malfunction.
–Check if the INTERLACE/PROGRESSIVE SCAN is set correctly according to your TV.
Completely distorted picture or –Connect DVD player directly to the TV.
black/white picture with DVD –Make sure the disc is compatible with the DVD player.
No sound or distorted sound –Adjust the volume.
–Check that the speakers are connected correctly.
–Check that the AUDIO cable is connected to the correct device (See Connecting
to a TV).
No audio at digital output –Check the digital connections.
–Check if the audio format of the selected audio language matches your receiver
capabilities.
No DTS audio at analogue output. –This player does not support DTS audio. This is not a malfunction.
Picture freezes momentarily –Check the disc for fingerprints/scratches and clean with a soft cloth wiping from
during playback center to edge.
Disc can’t be played –Ensure the disc label is facing up.
–Check if the disc is defective by trying another disc.
No return to start-up screen when disc is removed –Reset the player by switching the player off, then on again.
The player does not respond to –Aim the remote control directly at the sensor on the front of the player.
the remote control –Reduce the distance to the player.
–Replace the batteries in the remote control.
–Re-insert the batteries with their polarities (+/– signs) as indicated.
Buttons do not work or player stops –To completely reset the player, unplug the AC cord from the AC outlet for 5-10
responding seconds.
Player does not respond to some –Operations may not be permitted by the disc.
operating commands during playback. Refer to the instructions of the disc.
DVD player cannot read –Use a commonly available cleaning CD/DVD to clean the lens before sending the
CDs/DVDs DVD player for repair.
If you are unable to remedy a problem by following these hints, consult a Sharp Authorized Service Center.

–19 –EN
Cleaning the Cabinet
• Use a soft cloth slightly moistened with a mild detergent solution. Do not use a solution containing alcohol, spirits,
ammonia or abrasives.
Cleaning Discs
• When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the center out. Do not wipe in a circular
motion.
• Do not use solvents such as benzine, thinner, commercially available cleaners, detergent, abrasive cleaning agents or
antistatic spray intended for analogue records.
Cleaning the disc lens
• If the player still does not perform properly when it is operated while referring to the relevant sections and to “TROU-
BLESHOOTING GUIDE” in this Operation Manual, the laser optical pickup unit may be dirty. Consult your dealer or a
Sharp Authorized Service Center for inspection and cleaning of the laser optical pickup unit.
Disc Handling
• Use discs which have the following logos on them. (Optical audio digital discs.)
• Handle the discs so that fingerprints and dust do not adhere to the surfaces of the discs.
• Always store the disc in its protective case when it is not used.
MAINTENANCE
PRODUCT TYPE
DVD Player
DISCS (PLAYBACK COMPATIBILITY)
DVD Video
Audio CD
CD-RW / R
DVD-RW / R, DVD+RW / R
OUTPUT SIGNAL FORMAT
NTSC color
FREQUENCY RESPONSE
DVD (linear sound) : 20 Hz to 20 kHz (sample rate: 48 kHz)
20 Hz to 44 kHz (sample rate: 96 kHz)
CD : 20 Hz to 20 kHz
SIGNAL-TO-NOISE RATIO (S/N RATIO)
CD : 120 dB (JEITA)
DYNAMIC RANGE
DVD (linear sound) : 102 dB
CD : 99 dB (JEITA)
TOTAL DISTORTION FACTOR
DVD : 0.0025% (JEITA)
CD : 0.003% (JEITA)
WOW AND FLUTTER
Below the measurement limitation (±0.001 % W PEAK)
(JEITA)
CONNECTIONS
Video output
One RCA connector, 1 Vpp (75 Ω )
Component video output One pin jack (Y), 1 Vpp (75 Ω)
Two pin jacks (CR/PR, CB/PB),
700mVpp (75 Ω)
S-Video output Mini DIN 4-pin jack (75 Ω)
Analog audio output Two RCA connectors (one left
channel, one right channel)
2 Vrms (47 kΩ)
Coaxial digital audio output One pin jack, 500mVpp (75 Ω)
Optical digital audio output Optical connector
POWER SOURCE
120V AC +/- 10 %, 60 Hz +/- 0.5 %
POWER CONSUMPTION
10 W (standby: 0.8 W)
OPERATING TEMPERATURE
41 F° to 104 F° (5 °C to 40 °C)
DIMENSIONS
W: 17 1/8” (435 mm)
H: 2” (51 mm)
D: 8 5/16” (211 mm)
WEIGHT
Approx. 2.9 lbs. (1.3 kg)
• Designs and specifications are subject to change
without notice.
• If there is a discrepancy between languages, the
default language will be English.
SPECIFICATIONS
Make your contribution to the environment!!!
• Used up batteries do not belong in the dust bin.
• You can dispose of them at a collection point for used up batteries or special waste.
Contact your council for details.
Recordable
ReWritable
For the location of the nearest Sharp Authorized Service Center, or to obtain product literature, accessories, supplies or cus-
tomer assistance, please call 1-800-BE-SHARP (1-800-237-4277) or visit SHARP’s website (http://www.sharpusa.com).
SERVICE INFORMATION (For the U.S.)

–20 –SP
AVISO: PARA REDUCIR EL RIESGO DE INCENDIO O ELECTROCHOQUE NO
EXPONGA ESTE APARATO A LA HUMEDAD.
Este dispositivo cumple con la Parte 15 de las reglas de la FCC (Comisión Federal de Comunicaciones). La operación
se encuentra sujeta a las dos condiciones siguientes:
(1) Este dispositivo no debería producir interferencias perjudiciales, y
(2) este dispositivo debe aceptar cualquier interferencia recibida, incluyendo las que puedan producir una operación
indeseable.
INFORMACION
Este equipo se ha sometido a todo tipo de pruebas y cumple con las normas establecidas para dispositivo digital de
Clase B, de conformidad con la Parte 15 de las reglas de la FCC (Comisión Federal de Comunicaciones). Estas reglas
están diseñadas para asegurar una protección razonable contra interferencias perjudiciales en las instalaciones residen-
ciales. Este equipo genera, utiliza y puede emitir energía de radiofrecuencia y, si no se instala y utiliza debidamente, es
decir, conforme a las instrucciones, podrían producirse interferencias perjudiciales en las radiocomunicaciones. Sin
embargo, no se garantiza que estas interferencias no se produzcan en una instalación determinada. Si este equipo oca-
siona interferencias en la recepción de radio o televisión, lo cual puede comprobarse con sólo apagar y encender el
equipo, intente corregir el problema mediante una o una combinación de las siguientes medidas:
—Reoriente la antena receptora o cámbiela de lugar.
—Aumente la separación entre el equipo y el receptor.
—Enchufe el equipo a una toma de corriente situada en un circuito distinto del receptor.
—Consulte a su distribuidor o a un técnico experto en radio/televisión.
PRECAUCION:
ESTA UNIDAD HA SIDO CLASIFICADA COMO PRODUCTO CLASS 1 LASER.
EL USO DE MANDOS O AJUSTES O LA REALIZACION DE PROCEDIMIENTOS DISTINTOS DE LOS INDI-
CADOS EN LA PRESENTE IMPLICA EL RIESGO DE EXPOSICION A UNA RADIACION PELIGROSA.
COMO LOS RAYOS LASER UTILIZADOS EN ESTA UNIDAD PUEDEN RESULTAR PERJUDICIALES PARA
SUS OJOS, NO INTENTE DESARMAR EL GABINETE. SOLICITE EL SERVICIO UNICAMENTE A PERSONAL
CUALIFICADO.
“ADVERTENCIA—Las reglas de la FCC (Comisión Federal de Comunicaciones) estip-
ulan que cualquier modificación o cambio a este equipo no aprobado expresamente por
el fabricante podrá anular la autorización del usuario para operar este equipo”.
Este símbolo previene al usuario del voltaje
aislado dentro de la unidad que puede provocar
descargas eléctricas peligrosas.
Este símbolo advierte al usuario que existen
instrucciones de operación y de mantenimien-
to en la literatura incluida en esta unidad.
PRECAUCION:
TPARA REDUCIR EL RIESGO DE DESCARGA ELEC-
TRICA, NO QUITE LA CUBIERTA. EL USUARIO NO
DEBERA DAR NINGUN TIPO DE SERVICIO A NINGU-
NA PARTE INTERNA. DEBERA SER REALIZADO SOLO
POR PERSONAL DE SERVICIO CALIFICADO.
PRECAUCION
PELIGRO DE DESCARGA ELECTRICA NO
ABRIR DECLARACIÓN DE CONFORMIDAD
Para futura referencia, anote los números de modelo y de serie (indica-
dos en la parte posterior esta unidad) en el espacio provisto.
Los productos que han ganado la marca
ENERGY STAR® han sido diseñados para proteger el medio ambiente mediante
una eficiencia superior en el uso de la energía.
No. de modelo: DV-SL80U
No. de serie:
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Este aparato digital de la Clase B cumple con la norma ICES-003 de Canadá.
PRECAUCIÓN: PARA EVITAR DESCARGAS ELÉCTRICAS, HAGA QUE LA
PALETA ANCHA DEL ENCHUFE COINCIDA CON LA RANURA ANCHA E
INTRODÚZCALA HASTA EL FONDO.
