Sharp QT-V5H User manual

QT-V5H_SEEG_FRONT.fm04/6/14 9HX80432100007
DVD/CD-SYSTEM
SYSTÈME DVD/CD
REPRODUCTOR DE DVD/CD
DVD/CD SYSTEM
SYSTEMA DVD/CD
DVD/CD-SYSTEEM
SYSTEMA DVD/CD
DVD/CD SYSTEM
MODELL
MODÈLE
MODELO
MODELL
QT-V5H
BEDIENUNGSANLEITUNG
MODE D’EMPLOI
MANUAL DE MANEJO
BRUKSANVISNING
DEUTSCH
ITALIANO
NEDERLANDS
ENGLISH
FRANÇAIS
ESPAÑOL
SVENSKA
PORTUGUÊS
Siehe Seiten i
bis vi und D-1 bis
D-36.
Se reporter aux
pages i àvi et F-1
à F-36.
Consulte las
páginas i a vi y
S-1 a S-36.
Hänvisa till
sidorna i till vi
och V-1 till V-36.
Leggere le
pagine i a vi e I-1
a I-36.
Raadpleeg de
bladzijden i t/m
vi en N-1 t/m N-36.
Favor consultar
as páginas i a vi
e P-1 a P-36.
Please refer to
pages i to vi and
E-1 to E-36.
MODELLO
MODEL
MODELO
MODEL
MANUALE DI ISTRUZIONI
GEBRUIKSAANWIJZING
MANUAL DE OPERAÇÃO
OPERATION MANUAL

i
04/6/14 QT-V5H_SEEG_COMMON.fm 9HX80432100007
QT-V5H
0406
BESONDERE ANMERKUNGEN
REMARQUES SPÉCIALES
NOTAS ESPECIALES
SÄRSKILDA ANMÄRKNINGAR
NOTE PARTICOLARI
BIJZONDERE OPMERKINGEN
NOTAS ESPECIAIS
SPECIAL NOTES
Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/
EWG und 73/23/EWG mit Änderung 93/68/EWG.
Ce matériel répond aux exigences contenues dans les directives 89/336/
CEE et 73/23/CEE modifiées par la directive 93/68/CEE.
Este aparato satisface las exigencias de las Directivas 89/336/CEE y
73/23/CEE, modificadas por medio de la 93/68/CEE.
Denna utrustning uppfyller kraven enligt riktlinjerna 89/336/EEC och 73/23/
EEC så som kompletteras av 93/68/EEC.
Quest’apparecchio è conforme ai requisiti delle direttive 89/336/EEC e 73/
23/EEC, come emendata dalla direttiva 93/68/EEC.
Dichiarazione di conformità
La società SHARP ELECTRONICS EUROPE GmbH dichiara che il prodotto
SHARP QT-V5H SYSTEMA DVD/CD è costruito in conformità alle prescrizioni
del D.M.n˚548 del 28/8/95, pubblicato sulla G.U.n˚301 del 28/12/95 ed in
particolare è conforme a quanto indicato nell’art. 2, comma 1 dello stesso
decreto.
Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/EEG en 73/23/
EEG, gewijzigd door 93/68/EEG.
Este equipamento obedece às exigências das directivas 89/336/CEE e
73/23/CEE, na sua versão corrigida pela directiva 93/68/CEE.
This equipment complies with the requirements of Directives 89/336/
EEC and 73/23/EEC as amended by 93/68/EEC.
Dette udstyr overholder kravene i direktiv nr. 89/336/EEC og 73/23/EEC
med tillaeg nr. 93/68/EEC.
Este equipamento obedece às exigências das directivas 89/336/CEE e 73/
23/CEE, na sua versão corrigida pela directiva 93/68/CEE.
Dette produktet oppfyller betingelsene i direktivene 89/336/EEC og 73/23/
EEC i endringen 93/68/EEC.
Tämä laite täyttää direktiivien 89/336/EEC ja 73/23/EEC vaatimukset, joita
on muutettu direktiivillä 93/68/EEC.
Bei Einstellung des ON/STAND-BY-Schalters auf ist die Netzspannung
immer noch im Gerät vorhanden.
Wenn die ON/STAND-BY-Schalter auf ON eingestellt wird, kann das Gerät
unter Verwendung der Fernbedienung in Betrieb gesetzt werden.
Warnung:
In diesem Gerät sind keine vom Benutzer wartbaren Teile vorhanden.
Niemals Abdeckungen entfernen, außer wenn Sie dafür qualifiziert sind. In
diesem Gerät sind gefährliche Spannungen vorhanden. Vor Ausführung
von irgendwelchen Kundendienstarbeiten oder bei längerer Nicht-
verwendung des Gerätes stets den Netzstecker aus der Netzsteckdose
ziehen.
Lorsque le commutateur ON/STAND-BY est mise en , l’appareil est
toujours sous tension.
Lorsque le commutateur ON/STAND-BY se trouve sur la position ON,
l’appareil est prêt à fonctionner par la télécommande.
Avertissement:
Cet appareil contient des pièces non réparables par l’utilisateur. Personne
non qualifiée n’enlèvera jamais les couvercles. L’appareil contenant des
organes portés à haute tension, débrancher l’appareil avant toute réparation
ou en période de non-utilisation.
Cuando el interruptor ON/STAND-BY está puesto en la posición ,
todavía hay tensión dentro del aparato.
Cuando el interruptor ON/STAND-BY está puesto en la posición ON, el
aparato puede ponerse en funcionamiento utilizando el controlador remoto.
Advertencia:
Tenga en cuenta que dentro de este aparato no hay piezas que pueda reparar.
No quite nunca las tapas a menos que se esté cualificado para hacerlo. Este
aparato tiene en su interior tensiones peligrosas. Desenchufe siempre la
clavija de la red del tomacorriente antes de realizar cualquier servicio de
mantenimiento y cuando no se use el aparato durante un largo período de
tiempo.
När ON/STAND-BY knappen är i läge , finns nätspänning i apparaten.
Med ON/STAND-BY knappen i läge ON kan apparaten startas med
fjärrkontrollen.
Varning:
Apparaten innehåller inga delar som kan åtgärdas av kunden. Höljet får
endast öppnas av kvalificerad personal. Apparaten innehåller farliga
spänningar.
Stickkontakten ska därför dras ut från nätuttaget före reparationsarbeten
och bör dras ut om apparaten inte ska användas på mycket länge.

ii
04/6/14 QT-V5H_SEEG_COMMON.fm 9HX80432100007
QT-V5H
0305
Når ON/STAND-BY-knappen er sat i positionen, er der stadig netspaend-
ing til stede i apparatet.
Når ON/STAND-BY-knappen er sat i ON position, kan apparatet startes
v.hj.a. fjernbetjeningen.
Advarsel:
Apparatet indeholder ingen dele, der kan repareres af brugeren selv. Fjern
aldrig kabinettet med mindre De er kvalificeret hertil. Apparatet indeholder
farlig strømspaending. Traek altid stikket ud af stikkontakten før der
foretages reparationer, eller hvis apparatet ikke er i brug i laengere tid.
DENNA APPARAT ÄR ANSLUTEN TILL 230 V VÄXELSTRÖM NÄR
STICKPROPPEN ÄR INSKJUTEN I VÄGGUTTAGET. FÖR ATT
FULLSTÄNDIGT KOPPLA IFRÅN APPARATEN, V.G. DRAG UT
STICKPROPPEN.
Quando l’interruttore ON/STAND-BY si trova in posizione , all’interno
dell’apparecchio c’è ancora la corrente.
Se l’interruttore ON/STAND-BY si trova nella posizione ON, l’unitàpuò
essere accesa con il telecomando.
Avvertenza:
L’apparecchio non contiene parti riparabili dall’utente.
Non togliere mai i coperchi, a meno di non essere qualificati per farlo.
All’interno dell’apparecchio ci sono tensioni pericolose, per cui si deve
sempre staccare la spina del cavo d’alimentazione dalla presa di corrente
prima di qualsiasi intervento di manutenzione e quando non si usa
l’apparecchio per un lungo periodo di tempo.
Wanneer de ON/STAND-BY schakel in de stand staat, loopt er nog
steeds stroom (netspanning) in het toestel.
Wanneer de ON/STAND-BY schakel in de ON stand staat, kan het toestel
ingeschakeld worden via de afstandsbediening.
Waarschuwing:
Dit toestel bevat geen door de gebruiker te repareren onderdelen. Verwijder
de behuizing nooit tenzij u deskundig bent op dit gebied. In het toestel
loopt een gevaarlijke spanning; haal de stekker altijd uit het stopcontact
alvorens onderhoud uit te voeren of wanneer het toestel voor langere tijd
niet gebruikt wordt.
Quando o comutador ON/STAND-BY estána posição , a tensão da rede
principal ainda estápresente dentro da unidade.
Quando o comutador ON/STAND-BY estána posição ON, a unidade pode
ser colocada em operação através do controle remoto.
Advertência:
Neste aparelho não hápartes que podem ser consertadas pelo usuário. Nunca
retire a tampa, a menos que vocêtenha qualificação para tal. Este aparelho
contém voltagens perigosas. Remova sempre o cabo de alimentação da
tomada antes de efetuar qualquer conserto ou quando deixar o aparelho muito
tempo fora de uso.
When the ON/STAND-BY switch is set at position, mains voltage is still
present inside the unit.
When the ON/STAND-BY switch is set at ON position, the unit may be
brought into operation by the remote control.
Warning:
This unit contains no user serviceable parts. Never remove covers unless
qualified to do so.This unit contains dangerous voltages, always remove
mains plug from the socket before any service operation and when not
in use for a long period.
1
SHARP 9HX80432100007

iii
04/6/14 QT-V5H_SEEG_COMMON.fm 9HX80432100007
QT-V5H
Advarsel:
Til at forbygge ild og stød risiko, lad vaere med at undsaette denne indretning
for drypning eller overstaenkning. Der måikke anbringes nogen genstande
fyldt med vand, som for eksempel vaser, pådette apparat.
Advarsel:
For åunngåbrann eller kortslutning, utsett ikke produktet for vann eller
fuktighet. Gjenstander som inneholder vaeske, feks. en blomstervase, må
ikke plasseres oppåapparatet.
Varoitus:
Älävie laitetta sateeseen tai kosteisiin tiloihin. Jos laite on kostunut,
anna sen kuivua ennen kuin käytät sitäverkkovirralla. Nestettäsisältäviä
astioita kuten esim. kukkamaljakoita ei saa asettaa laitteen päälle.
Vorsicht:
Das Gerät weder Tropf- noch Spritzwasser aussetzen. Ansonsten besteht
die Gefahr eines Brandes oder elektrischen Schlages. Es sollten keine mit
Flüssigkeiten gefüllten Gegenstände wie Vasen auf dem Gerät abgestellt
werden.
Attention:
Pour éviter un incendie ou une secousse électrique, mettre l’appareil àl’abri de
l’eau (éclaboussure, goutte). Ne pas poser sur l’appareil un récipient contenant
du liquide.
Advertencia:
Para evitar incendios y descargas eléctricas, no exponga el aparato a goteo
o salpicadura de líquidos. No deberán ponerse encima del aparato objetos
que estén llenos de líquido, como por ejemplo un florero.
Varning:
Utsätt inte enheten för dropp eller stänk för att förhindra brand eller
elektriska stötar. Inga vätskefyllda föremål såsom vaser bör placeras
påenheten.
Attenzione:
Per prevenire incendi o scosse elettriche, non fare gocciolare nessun liquido
sull’apparecchio e non bagnarlo. Non collocarvi sopra nessun oggetto
riempito d’acqua, come per esempio vasi.
Waarschuwing:
Stel het toestel niet bloot aan druipend of spattend water om brand en
elektrische schokken te voorkomen. Met vloeistoffen gevulde voorwerpen,
zoals vazen, mogen niet op het toestel geplaatst worden.
Cuidado:
Para evitar incêndio ou choque elétrico, não exponha este aparelho a
gotejamento ou salpicamento de água. Não coloque objetos com água como,
por exemplo, um vaso de flores, em cima do aparelho.
Warning:
To prevent fire or shock hazard, do not expose this appliance to dripping or
splashing. No objects filled with liquids, such as vases, should be placed
on the apparatus.
0110

iv
04/6/14 QT-V5H_SEEG_COMMON.fm 9HX80432100007
QT-V5H
0110
Dette produktet er klassifisert som et KLASSE 1 LASERPRODUKT.
Dette produkt er klassificeret som et KLASSE 1 LASERPRODUKT.
Tämälaite on luokiteltu LUOKAN 1 LASERLAITTEEKSI.
Denna produkt klassificeras som KLASS 1 LASERAPPARAT.
Dieses Produkt ist ein Laserprodukt der Klasse 1.
Ce produit est classifiécomme étant un LASER DE CLASSE 1.
Este producto estáclasificado como un PRODUCTO LÁSER DE CLASE 1.
Denna produkt klassificeras som KLASS 1 LASERPRODUKT.
Questo prodotto èclassificato come CLASS 1 LASER PRODUCT.
Dit product is geclassificeerd als een KLASSE 1 LASER PRODUCT.
Este produto éclassificado como PRODUTO LASER DE CLASSE 1.
This product is classified as a CLASS 1 LASER PRODUCT.
CAUTION
Use of controls, adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
As the laser beam used in this compact disc player is harmful to the eyes, do
not attempt to disassemble the cabinet. Refer servicing to qualified personnel
only.
VORSICHT
Verwendung von Regelungen oder Einstellungen bzw. Durchführung von
anderen Verfahren als die hierin angegebenen kann zum Aussetzen
gefährlicher Strahlung führen.
Da der in diesem Compact Disc Player verwendete Laserstrahl für die Augen
schädlich ist, ist das Gehäuse unter keinen Umständen zu zerlegen.
Wenden Sie sich für Wartungsarbeiten nur an berechtigten Fachhändler.
ATTENTION
Respecter les indications données relatives àla manipulation, au réglage et
au fonctionnement. En cas de non-respect, on s’exposera àune radiation
dangereuse.
Éviter absolument de démonter l’appareil, qui utilise un rayon laser nuisible
aux yeux. Pour toute réparation, s’adresser àune personne qualifiée.
PRECAUCIÓN
El uso de los controles, ajustes o ejecución de procedimientos distintos de los
especificados podría causar la exposición a radiación peligrosa.
No intente desmontar la caja ya que el haz de láser usado en este reproductor
de discos compactos es perjudicial para los ojos. Para el servicio de reparación,
consulte a una persona cualificada.
OBSERVERA
Användning av reglage eller justeringar eller handhavande påannat sätt än
som anges kan leda till farlig bestrålning.
Försök inte ta isär höljet eftersom CD-spelarens laserstråle är skadlig för
ögonen. Överlåt service endast till kvalificerad personal.
ATTENZIONE
L’uso dei comandi e l’effettuazione di regolazioni e procedimenti diversi da
quelli specificati nel manuale possono provocare una pericolosa esposizione
alle radiazioni.
Poichéil raggio laser usato in questo giradischi puòdanneggiare gli occhi,
non smontare l’apparecchio. Per le riparazioni rivolgersi a personale
specializzato.
LET OP
Gebruik van regelaars, het maken van instellingen, gebruik of handelingen
anders dan in deze gebruiksaanwijzing vermeld, kan gevaarlijke straling
blootleggen.
De laserstraal in deze CD-speler kan de ogen beschadigen, Probeer derhalve
de ombouw niet te verwijderen. Laat reparaties alleen over aan erkend
onderhoudspersoneel.
CUIDADO
O uso de controles, ajustes ou a execução de procedimentos além daqueles
especificados aqui pode resultar em perigosa exposição àradiação.
Como os raios laser usados neste player de CD são perigosos para os olhos,
não tente desmontar o aparelho. Solicite o conserto somente para pessoas
especializadas.

v
04/6/14 QT-V5H_SEEG_COMMON.fm 9HX80432100007
QT-V5H
Eigenschaften der Laserdiode
Material: AIGaAs/AIGaInP
Wellenlänge: 785 nm/650 nm
Emissionsdauer: kontinuierlich
Laser-Ausgang: max. 0,6 mW
Caractéristiques de la diode laser
Matière: AIGaAs/AIGaInP
Longueur d’onde: 785 nm/650 nm
Durée d’émission: ininterrompue
Puissance de sortie
laser maximale: 0,6 mW
Características del diodo láser
Material: AIGaAs/AIGaInP
Longitud de onda: 785 nm/650 nm
Duración de emisión: continua
Salida de láser: máx. 0,6 mW
Laserdiodens egenskaper
Material: AIGaAs/AIGaInP
Våglängd: 785 nm/650 nm
Utstrålningsvaraktighet: kontinuerlig
Lasereffekt: max. 0,6 mW
Proprietàdel diodo laser
Materiale: AIGaAs/AIGaInP
Lunghezza d’onda: 785 nm/650 nm
Durata di emissione: continua
Uscita massima del laser: 0,6 mW
Laser diode specificaties
Materiaal: AIGaAs/AIGaInP
Golflengte: 785 nm/650 nm
Stralingsduur: doorlopend
Laseruitgang: max. 0,6 mW
Propriedades do diodo de laser
Material: AlGaAs/AlGaInP
Comprimento de onda: 785 nm/650 nm
Duração da emissão: contínua
Saída de laser: máx. 0,6 mW
Laser Diode Properties
Material: AIGaAs/AIGaInP
Wavelength: 785 nm/650 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW 0405
ADVERSEL-SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING. SE IKKE IND I
STRÅLEN-HELLER IKKE MED OPTISKE INSTRUMENTER.
VARO! AVATTAESSA OLET ALTTIINA NÄKYVÄLLE JA NÄKYMÄTTÖMÄLLE
LASERSÄTEILYLLE ÄLÄTUIJOTA SÄTEESEEN ÄLÄKÄKATSO SITÄOPTISEN
LAITTEEN LÄPI.
VARNING-SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR
ÖPPNAD. STIRRA EJ IN I STRÅLEN OCH BETRAKTA EJ STRÅLEN GENOM
OPTISKT INSTRUMENT.
0110
VAROITUS! LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ
KÄYTTÖOHJEESSA MAINITULLA TAVALLA SAATTAA ALTISTAA
KÄYTTÄJÄN TURVALLISUUSLUOKAN 1 YLITTÄVÄLLE NÄKYVÄLLE JA
NÄKYMÄTTÖMÄLLE
LASERSÄTEILYLLE.
VARNING - OM APPARATEN ANVÄNDS PÅANNAT SÄTT ÄN I DENNA
BRUKSANVISNING SPECIFICERAS. KAN ANVÄNDAREN UTSÄTTAS FÖR
SYNLIG OCH OSYNLIG LASERSTRÅLNING, SOM ÖVERSKRIDER GRÄNSEN
FÖR LASERKLASS 1.

vi
04/6/16 QT-V5H_SEEG_COMMON.fm 9HX80432100007
QT-V5H
0304
In Lizenz von Dolby Laboratories hergestellt. “Dolby” und das Doppel-D-Sym-
bol sind Warenzeichen der Dolby Laboratories.
Fabriqué sous licence de Dolby Laboratories. «Dolby» et le symbole double
D sont des marques de commerce de Dolby Laboratories.
Fabricado bajo licencia de Dolby Laboratories. “Dolby” y el simbolo con una
doble D son marcas registradas de Dolby Laboratories.
Tillverkad på Dolby Laboratories licens. “Dolby” och dubbel-D-symbol är reg-
istrerade varumärken som tillhör Dolby Laboratories.
Prodotto sotto licenza dalla Dolby Laboratories. “Dolby” ed il simbolo doppia
D sono marchi registrati della Dolby Laboratories.
Vervaardigd in licentie van Dolby Laboratories. “Dolby” en het dubbel D-sym-
bool zijn handelsmerken van Dolby Laboratories.
Fabricado sob licença de Dolby Laboratories. Dolby e o simbolo com duplo D
são marcas comerciais de Dolby Laboratories.
Manufactured under license from Dolby Laboratories. “Dolby” and the double-
D symbol are trademarks of Dolby Laboratories.

E-1
04/6/14 QT-V5H_SEEG_E1.fm
ENGLISH
9HX80432100007
QT-V5H
ENGLISH
General Information
- Introduction / Accessories / Types of playable discs -
Introduction
Thank you for purchasing this SHARP product. To obtain the best performance from
this product, please read this manual carefully. It will guide you in operating your
SHARP product.
Accessories
Please confirm that the following accessories are included.
Note:
Only the above accessories are included.
Types of playable discs
The unit can play back discs bearing any of the following marks:
Remote control 1 AC power lead 1
"AAA" size battery (UM-4, R03, HP-16
or similar) 2 "AA" size battery (UM/SUM-3, R6, HP-7 or similar) 2
Video cable 1 Audio cable 1
Yellow
Disc type Disc contents Disc size
DVD-Video Disc Audio and video
(movies) 12 cm
Or DVD-R/DVD-RW re-
corded in video mode
(*1)
8 cm
Super Video CD Audio and video
(movies) 12 cm
8 cm
Video CD Audio and video
(movies) 12 cm
8 cm
Audio CD Audio 12 cm
Or CDV (*2) 8 cm
CD-R/CD-RW (*3) Audio and picture 12 cm
Or CD-R/CD-RW record-
ed in MP3 format (*4),
JPEG format (*5)
8 cm
(*1): All discs including DVD-R/DVD-RW may not be played back due to properties
and scratches on the disc, dirty optical pickup lens, etc.
(*2): Only the audio on the CDV can be played.
(*3): The CD-R/CD-RW may not be played back properly depending on the recording
equipment or the disc.
(*4): If the sampling frequency is 44.1 or 48.1 kHz and the fixed bit rate is 128 kbps or
higher,MPEG 1Audio Layer3 (MP3)filescan beplayed. However,some ofthem
may not be played depending on their conditions or formats.
(*5): JPEG or JPG picture discs also play on this unit. However, pictures may not be
clear (depends on resolution and recording method).
!For unplayable discs, see page 6.

E-2
QT-V5H_SEEG_E1.fm04/6/14
ENGLISH
9HX80432100007
F
S
V
I
N
P
E
D
QT-V5H
General Information
- Contents -
Contents
Page
"General Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4, 5
Description of discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6, 7
"Preparation for Use
System connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Power source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Battery installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Turning the power on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
General control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
"DVD Operation
DVD playback
Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 14
Resume play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
DVD mode operation indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Basic operation
To locate the beginning of a chapter/track (skip) . . . . . . . . . . . . . . . . . . . . . . . 15
Fast forward/Fast reverse (search) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
To start playback from the desired point (direct play) . . . . . . . . . . . . . . . . . . . 16
Useful operation
Still picture/Frame advance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Slow-motion play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
To change the angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
To zoom images (zoom) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
To play repeatedly (repeat play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
To play the contents between the specified points repeatedly (A-B repeat) . 18
To select a title from the top menu of the disc . . . . . . . . . . . . . . . . . . . . . . . . . 18
To select a subtitle or audio language from the disc menu . . . . . . . . . . . . . . . 18
Various settings
To change the subtitle language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
To change the audio language (audio output) . . . . . . . . . . . . . . . . . . . . . . . . . 19
To change the TV system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
To change the display on TV screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Page
"Video CD and Super Video CD Operation
Video CD and Super Video CD playback
Video CD with P.B.C. (playback control) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
To start playback from the desired point (direct play) . . . . . . . . . . . . . . . . . . . 22
"CD, CD-R and CD-RW Operation
CD operation
To play in the desired order (programmed play) . . . . . . . . . . . . . . . . . . . . . . . . 22
To play in random order (random play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
MP3 and JPEG disc operation
MP3 and JPEG disc playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Zoom function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Rotating a picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
"Radio Operation
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25, 26
"Advanced Features
Changing the setup menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 - 30
Timer and sleep operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31, 32
Connecting other equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
"References
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34, 35
Error indicators and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Icons used in this operation manual
Some functions may not be available depending on discs.The following icons
indicate the discs that can be used in the section.
Some operations may not be performed depending on discs even if they
are described in this manual.
During operation, " " may be displayed on the screen.
This means that the operations described in this manual are not possible
at this time.
...Indicates DVDs.
...Indicates super video CDs.
...Indicates video CDs.
...Indicates audio CDs.
...Indicates CD-R/RW with MP3 recording.
...Indicates CD-R/RW with JPEG recording.

E-3
QT-V5H_SEEG_E1.fm04/6/14
ENGLISH
9HX80432100007
QT-V5H
General Information
- Precautions -
Precautions
"General !No naked flame sources, such as lighted candles, should be placed on the apparatus.
!Attention should be drawn to the environmental aspects of battery disposal.
!The apparatus is designed for use in moderate climate.
!This unit should only be used within the range of 5°C - 35°C (41°F - 95°F).
Warning:
The voltage used must be the same as that specified by this unit. Using this product with a
higher voltage other than that specified is dangerous and may result in a fire or other types
of accident, causing damage. SHARP will not beheld responsible for any damage resulting
from the use of this unit with a voltage other than that specified.
"Volume control
It is advisable to avoid exposure to high volume levels, which occurs whilst turning the unit
on with the volume control setting up high, or whilst continually listening at high volumes.
Copy Protection:
This unit supports Macrovision copy protection.
On DVD discs that include a copy protection code, if the contents of the DVD disc are cop-
ied using a VCR, the copy protection code prevents the videotape copy from playing nor-
mally.
!Please ensure that the equipment is positioned in a well ventilated area and that
there is at least 10 cm of free space along the sides and back. There must also be
a minimum of 20 cm of free space on the top of the unit.
!Use the unit on a firm, level surface free from vibra-
tion.
!Keep the unit away from direct sunlight, strong mag-
netic fields, excessive dust, humidity and electronic/
electrical equipment (home computers, facsimiles,
etc.) which generate electrical noise.
!Do not place anything on the unit.
!Do not expose the unit to moisture, to temperatures higher than 60°C (140°F) or to
extremely low temperatures.
!If the unit does not work properly, unplug and plug it in again. Then turn on the unit.
!In case of an electrical storm, unplug the unit for safe-
ty.
!Hold the AC power plug by the head when removing it
from the wall socket, as pulling the lead can damage
internal wires.
!Do not remove the outer cover, as this may result
in electric shock. Refer internal service to your lo-
cal SHARP service facility.
!The ventilation openings should not be impeded by
covering them with items, such as newspapers, table-
cloths, curtains, etc.
10 cm 10 cm 10 cm
20 cm
Copyright Information:
!Unauthorised copying, broadcast, public display, transmission, public performance
and rental (regardless of whether or not such activities are for profit) of disc contents
are prohibited by law.
!This system is equipped with copy protection technology that causes substantial deg-
radation of images when the contents of a disc are copied to a videotape.
"DTS" and "DTS Digital Out" are trademarks of Digital Theater Systems, Inc.
Apparatus Claims of U.S. Patent Nos. 4,631,603, 4,577,216, 4,819,098 and
4,907,093 licensed for limited viewing uses only.
This product incorporates copyright protection technology that is protected by
method claims of certain U.S. patents and other intellectual property rights owned
by Macrovision Corporation and other rights owners. Use of this copyright
protection technology must be authorized by Macrovision Corporation, and is
intended for home and other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse engineering or disassembly is
prohibited.
0403

E-4
QT-V5H_SEEG_E1.fm04/6/14
ENGLISH
9HX80432100007
F
S
V
I
N
P
E
D
QT-V5H
General Information
- Controls and indicators -
Controls and indicators
"Main unit Reference page
1.On/Stand-by Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 14
4.Play/Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 14
5.Chapter (track) Skip Down or Tuning Down Button . . . . . . . . 15, 25
6.Chapter (track) Skip Up or Tuning Up Button . . . . . . . . . . . . . 15, 25
7.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
8.Disc Tray Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
9.Remote Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
10.Disc Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
11.Timer Set Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
12.Extra Bass Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
13.Random Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
14.Repeat Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
15.Memory Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
16.Track Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
17.Surround Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
18.Stereo Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
19.Sleep Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
20.Timer Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
21.Preset Equaliser Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
22.CD Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
23.MP3 Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
24.FM Telescopic Rod Aerial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
25.SCART Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
26.S-video Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
27.Video Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
28.Audio Output Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
29.Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
30.Optical Digital Audio Output Socket . . . . . . . . . . . . . . . . . . . . . . . 33
31.Battery Compartment cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
32.AC Power Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
12 13 14 15 16 17 18 19 20
24
31 32
25 26 27 2928 30
21 22 23
9 10 11
1 2 3 4 5 6 7 8
<The bottom of the unit>
MODEL NO. QT-V5H
DVD / CD SYSTEM
230-240V 50Hz 23W
12 V ..., (UM / SUM-1 or R20) 8
3 V ..., (UM / SUM-3 or R6) 2 (FOR MEMORY)
FREQUENCY RANGE :
FM 87.5 - 108 MHz
AM 522 - 1620 kHz
SERIAL NO.
SHARP CORPORATION MADE IN CHINA

E-5
QT-V5H_SEEG_E1.fm04/6/14
ENGLISH
9HX80432100007
QT-V5H
General Information
- Controls and indicators -
Controls and indicators (continued)
"Remote control Reference page
1.Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.On-Screen Display Select Button . . . . . . . . . . . . . . . . . . . . . . . 11, 20
3.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.Subtitle Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.Audio Language Select or Audio Output Select Button . . . . . . . . 19
6.Angle Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17, 24
7.Top Menu Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
8.Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
9.Return Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
10.Cursor Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
11.1/ALL Repeat Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17, 23
12.A - B Repeat Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
13.PBC On/Off Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
14.Slow-motion Play Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
15.Fast Reverse/Tuner Preset Down and Fast Forward/
Tuner Preset Up Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 24, 26
16.Programme Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22, 26
17.Clock Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
18.Shift Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17, 20, 24
19.Timer/Sleep Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31, 32
20.Sound Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
21.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
22.Dimmer Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12, 20
23.Disc Tray Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
24.Direct Number Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16, 22
25.Menu Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18, 27
26.Enter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
27.GOTO Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16, 22
28.Random Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
29.Still/Frame Advance Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
30.Chapter (Track) Skip Up and Down Buttons . . . . . . . . . . . 15, 21, 25
31.Play/Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 14, 21
32.Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 14, 21
33.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1
32
22
23
24
25
26
27
28
33
31
29
30
9
7
6
5
4
3
2
10
11
12
13
14
18
15
16
17
19
20
21
8
This button works as the ZOOM button when pressed with the SHIFT button.
This button works as the NTSC/PAL select button when pressed with the SHIFT
button.

E-6
QT-V5H_SEEG_E1.fm04/6/14
ENGLISH
9HX80432100007
F
S
V
I
N
P
E
D
QT-V5H
General Information
- Description of discs -
Description of discs
"Discs that cannot be played
!The discs above cannot be played at all, or no sound is heard although images
appear on the screen or vice versa.
!Incorrect operation may damage the speakers and can have an negative effect on
your hearing when played at high volume settings.
!You cannot play illegally produced discs.
Notes:
!A disc with scratches or fingerprints may not play properly. Refer to "Care of discs
(page 36)" and clean the disc.
!Do not play the discs of special shapes (heart or octagon shaped) as they can be
ejected whilst rotating and cause injury.
"Title, chapter and track
DVDs are divided into "titles" and "chapters". If the disc has more than one movie on
it, each movie is a separate "title". "Chapters" are subdivisions of titles.
Video CD and audio CD are composed of "tracks". Tracks are equivalent to songs on
a CD.
Note:
Title, chapter, or track numbers may not be recorded on some discs.
MP3, JPEG discs consist of "folders" and "tracks".
"Icons used on DVD discs
Check the icons on the DVD case before playing your discs.
!DVDswithout theregionnumber"2"or
"ALL". !DVD-Audio
!CDG
!DVDs with SECAM system !Photo CD
!DVDs with MPEG sound !CD-ROM
!DVD-ROM !SACD
!DVD-RAM !Discs recorded in special formats, etc.
Title 1 Title 2
Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 2
Track 3Track 2Track 1 Track 5Track 4
Folder 1 Folder 2
Track 1 Track 2 Track 3 Track 1 Track 2
MP3
disc JPEG disc
Display Description
Region number (playable area
number) DVD discs are programmed with region num-
bersindicatingcountries in whichtheycanbe
played. This system can play discs with re-
gion number "2" or "ALL".
Format recorded on the DVD To adapt the video format to the connected
TVs ("wide-screen TV" or "4:3 size TV").
Recorded in 4:3.
You can enjoy wide images on a wide-screen TV and letterbox size im-
ages on the 4:3 size TV.
You can enjoy wide images on a wide-screen TV and 4:3 images with
the side edges cut on the 4:3 size TV.
Type of subtitles recorded Recorded subtitle languages.
Example: Language can be selected with the SUBTI-
TLE button.
1: English
2: French
Number of camera angles Number of angles recorded on the DVD.
Angles can be selected with the ANGLE but-
ton.
Number of audio tracks and
audio recording systems The number of audio tracks and audio re-
cording systems are indicated.
Example:
1: Original <English>
(Dolby Digital 5.1 Sur-
round)
!The audio recorded on the DVD can be
switched by using the AUDIO button.
2: English (Dolby Digital
2 Surround) !The number of audio tracks and recording systems vary depending on the DVD.
Check them in the DVD's manual.
2
ALL
2
2

E-7
QT-V5H_SEEG_E1.fm04/6/14
ENGLISH
9HX80432100007
QT-V5H
General Information
- Description of discs -
Description of discs (continued)
The list below shows the countries covered by region number 2.
* represents area name.
Common names Names of nations and areas
Albania Republic of Albania
Andorra Principality of Andorra
Austria Republic of Austria
Bahrain State of Bahrain
Belgium Kingdom of Belgium
Bosnia and Herzegovina Bosnia and Herzegovina
Bulgaria Republic of Bulgaria
Channel Islands *Channel Islands
Croatia Republic of Croatia
Cyprus Republic of Cyprus
Czech The Czech Republic
Denmark Kingdom of Denmark
Egypt Arab Republic of Egypt
Faeroe Islands *Faeroe Islands
Finland Republic of Finland
France French Republic
Germany Federal Republic of Germany
Gibraltar *Gibraltar
Greece Hellenic Republic
Greenland *Greenland
Hungary Republic of Hungary
Iceland Republic of Iceland
Iran Islamic Republic of Iran
Iraq Republic of Iraq
Ireland Ireland
Isle of Man *Isle of Man
Israel State of Israel
Italy Italian Republic
Japan Japan
Jordan Hashemite Kingdom of Jordan
Kuwait State of Kuwait
Common names Names of nations and areas
Lebanon Republic of Lebanon
Lesotho Kingdom of Lesotho
Liechtenstein Principality of Liechtenstein
Luxembourg Grand Duchy of Luxembourg
Macedonia Republic of Macedonia
Malta Republic of Malta
Monaco Principality of Monaco
Netherlands Kingdom of the Netherlands
Norway Kingdom of Norway
Oman Sultanate of Oman
Poland Republic of Poland
Portugal Portuguese Republic
Qatar State of Qatar
Romania Romania
San Marino Republic of San Marino
Saudi Arabia Kingdom of Saudi Arabia
Slovakia The Slovak Republic
Slovenia Republic of Slovenia
South Africa Republic of South Africa
Spain Kingdom of Spain
Svalbard and Jan Mayen Islands *Svalbard and Jan Mayen Islands
Swaziland Kingdom of Swaziland
Sweden Kingdom of Sweden
Switzerland Swiss Confederation
Syrian Arab Republic Syrian Arab Republic
Turkey Republic of Turkey
United Arab Emirates United Arab Emirates
United Kingdom United Kingdom of Great Britain and North-
ern Ireland
Vatican City State State of the City of Vatican
Yemen Republic of Yemen
Yugoslavia Federal Republic of Yugoslavia

E-8
QT-V5H_SEEG_E2.fm04/6/14
ENGLISH
9HX80432100007
F
S
V
I
N
P
E
D
QT-V5H
Preparation for Use
- System connections -
System connections
"Connecting to a TV with a video input
socket
You can enjoy DVD images by connecting your TV and this unit with a video cable.
Use an audio cable for the connection to enjoy DVD sound through the TV speakers.
"Connecting to a TV with an S-video or
SCART input socket
If your TV is equipped with an S-video input socket, you can enjoy higher quality
images by connecting it with an S-video cable (not supplied).
You can enjoy DVD images by connecting your TV and this unit with the SCART
cable.
Notes:
!Change the TV input in accordance with the connected socket.
!Do not connect other equipment (VCR, etc.) between the TV and this unit. Pic-
tures may be distorted.
!Refer to the operation manual of the equipment to be connected.
!Insert the plugs fully to avoid fuzzy pictures or noise.
!When playing a disc in DTS mode, no sound will be heard from the speakers. To
listen to the sound, select another audio output in the "To change the audio lan-
guage (audio output)" on page 19.
"Magnetically shielded speakers
The speakers are magnetically shielded.
Therefore, they do not affect the display even you use them near the TV. However,
some colour variation may occur, depending on the type of TV used.
If discolouration occurs...
Turn off the TV (from the power switch).
After 15 - 30 minutes, turn the TV on again.
If the discolouration is still present...
Move the unit further away from the TV.
If any kind of magnet or an electromagnet is placed too close to the TV and the sys-
tem, irregular colours may appear on the TV screen.
Unplug all equipment before making any connections.
To video
input socket
Video cable (supplied)
Video signal
TV
Audio signal
To audio
input
sockets
Audio cable
(supplied)
To SCART
input socket
SCART cable
(commercially available)
S-Video cable
(commercially available)
Video signal
TV
Audio signal
To audio
input
sockets
Audio cable
(supplied)
To S-video
input socket

E-9
QT-V5H_SEEG_E2.fm04/6/14
ENGLISH
9HX80432100007
QT-V5H
Preparation for Use
- Power source -
Power source
"Inserting memory batteries
Memory batteries maintain the clock setting and preset stations for the tuner.
Notes:
!If memory batteries are not inserted or low, preset stations and the clock setting
will be lost.
!Replace memory batteries approximately once a year.
Caution:
Do not use rechargeable batteries (nickel-cadmium battery, etc.).
Precautions for battery use:
!Insert the batteries according to the direction indicated in the rear panel.
!Remove the batteries if weak or if the unit is not in use for long periods to prevent
potential damage due to battery leakage.
!Replace all batteries with new ones at the same time.
!Do not mix old and new batteries.
"Using with the main batteries
Playing a disc consumes more battery power than listening to the radio. It is recommended
to use the AC power.
Battery replacement:
Replace the batteries when they become weak and playback is impaired. This may occur
even though radio broadcasts are audible.
"Using with the AC power lead
After checking all the connections, connect the AC power lead to the AC power input
socket, then to the wall socket.
Notes:
!Unplug the AC power lead from the wall socket if the unit will not be used for a pro-
longed period of time.
!Connecting the AC power lead to the unit disconnects the batteries.
!Use only the supplied AC power lead. Using other AC power leads may cause an elec-
tric shock or fire.
1Open the battery compartment.
2Insert the 2 supplied "AA" size batteries (UM/SUM-3, R6, HP-7 or
similar) into the battery compartment.
Insertion and removal:
Push the battery toward to insert or remove.
3Close the battery compartment.
1 2
1Disconnect the AC power lead, and open the battery compartment.
2Insert 8 "D" size batteries (UM/SUM-1, R20, HP-2 or similar) into the
battery compartment.
!"D" size batteries (UM/SUM-1, R20, HP-2 or similar) are not included.
!It is recommended to use alkaline batteries.
Insertion and removal:
!Push the batteries and toward to insert or remove.
!Placing the batteries incorrectly can cause the unit to malfunction.
3Close the battery compartment.
1243
5 7 6
8
Wall socket
(AC 230-240 V,
50 Hz)

E-10
QT-V5H_SEEG_E2.fm04/6/14
ENGLISH
9HX80432100007
F
S
V
I
N
P
E
D
QT-V5H
Preparation for Use
- Battery installation / Turning the power on -
Battery installation
Precautions for battery use:
!Replace all old batteries with new ones at the same time.
!Do not mix old and new batteries.
!Remove the batteries if the unit is not to be used for long periods of time. This will
prevent potential damage due to battery leakage.
Caution:
!Do not use rechargeable batteries (nickel-cadmium battery, etc.).
!Incorrect installation may cause the unit to malfunction.
Notes concerning use:
!Replace the batteries if the operating distance is reduced or if the operation
becomes erratic. Purchase 2 "AAA" size batteries (UM-4, R03, HP-16 or similar).
!Periodically clean the transmitter on the remote control and the sensor on the unit
with a soft cloth.
!Exposing the sensor on the unit to strong light may interfere with operation.
Change the lighting or the direction of the unit.
!Keep the remote control away from moisture, heat, shock, and vibrations.
Turning the power on
"To turn the power on
1Set the ON/STAND-BY switch on the main unit to ON.
2When the ON/STAND-BY switch on the main unit is set to ON, you can
also turn the power on or put the unit in the stand-by mode using the
ON/STAND-BY button on the remote control.
"Test of the remote control
The remote control can be used within the range shown below:
Press the ON/STAND-BY button. Does the power turn on? Now, you can enjoy music.
1Remove the battery cover.
2Insert the 2 supplied "AAA" size batteries (UM-4, R03, HP-16 or sim-
ilar) according to the direction indicated in the battery compart-
ment.
When inserting or removing the batteries, push them towards the battery termi-
nals.
3Replace the cover.
After use:
When not using this unit, set the ON/STAND-BY switch on the main unit to .
1
2
Remote sensor
0.2 m - 6 m

E-11
QT-V5H_SEEG_E2.fm04/6/14
ENGLISH
9HX80432100007
QT-V5H
Preparation for Use
- Setting the clock -
Setting the clock
The clock can only be set using the buttons on the remote control.
In this example, the clock is set for the 12-hour (AM 12:00) display.
To confirm the time display:
Press the CLOCK button for less than 0.5 seconds whilst the main unit turns the
power on.
The time display will appear for about 5 seconds.
To readjust the clock:
Perform "Setting the clock" from step 1.
To change the 12-hour or 24-hour display:
Note:
Insert memory batteries to keep the clock setting even after unplugging the unit.
1Press the ON/STAND-BY switch on the main unit to turn the power
on.
2Press the CLOCK button.
3Within 5 seconds, press the button to se-
lect the hour.
4Within 5 seconds, press the or button
to adjust the hour.
Press the or button once to advance the time by
1 hour. Hold it down to advance continuously.
5Within 5 seconds, press the button to se-
lect the minute.
6Within 5 seconds, press the or button
to adjust the minute.
Press the or button once to advance the time by 1 minute. Hold it down to
advance continuously.
7Within 5 seconds, press the ENTER button.
When the time is displayed, press the DISPLAY button for 0.5 seconds or more to se-
lect the 12-hour or 24-hour display.
"AM 12:00" The 12-hour display will appear.
(AM 12:00 - PM 11:59)
"0:00" The 24-hour display will appear.
(0:00 - 23:59)

E-12
QT-V5H_SEEG_E2.fm04/6/14
ENGLISH
9HX80432100007
F
S
V
I
N
P
E
D
QT-V5H
Preparation for Use
- General control -
General control
Some of these functions are only available on the remote control.
"To change the display brightness (3 levels)
You can switch the display brightness by pressing the DIMMER button.
Each time the button is pressed, the display brightness changes in the following order.
"Adjusting the volume
"Emphasising the bass
"Setting surround effects
"Changing the sound quality
Press the VOLUME + button to increase the volume and the
VOLUME - button to decrease the volume.
You can also use the VOLUME + or VOLUME -button on the
main unit.
1Press the SOUND MODE button repeatedly to select "XBS OFF".
2Within 5 seconds, press the or button to select "XBS ON".
Increase Unchanged
To cancel, select "XBS OFF".
Brightened OFF Dimmed
00 01 31 32
1Press the SOUND MODE button repeatedly to select "SUR OFF".
2Within 5 seconds, press the or button to select "SUR ON".
To cancel the surround, select "SUR OFF".
1Press the SOUND MODE button repeatedly to select "FLAT".
2Within 5 seconds, press the or button to select the desired
sound quality "FLAT", "CUSTOM", "ROCK", "POP", "JAZZ" or
"CLASSIC".
When "CUSTOM" is selected in step 2, you can adjust the bass and
treble.
1 Press the or button to select "TREB", or "BASS".
2 Within 5 seconds, press the or button to adjust the treble or the bass.
FLAT CUSTOM ROCK POP JAZZ CLASSIC
FLAT : The sound is not modified.
CUSTOM : Customise the bass and treble levels.
-7 7-7 7

E-13
QT-V5H_SEEG_E3.fm04/6/14
ENGLISH
9HX80432100007
QT-V5H
DVD Operation
- DVD playback -
DVD playback
Turn on the TV, and switch the input to the "VIDEO 1", "VIDEO 2", etc.
accordingly. "Playback
1Press the ON/STAND-BY switch on the
main unit to turn the power on.
!The startup screen appears.
!When the disc input mode is not selected, press
the STOP button to display the startup screen.
!If the startup screen does not appear, make sure
the correct video input is selected on the TV .
!If the initial setting screen is blurred, press the NTSC/PAL button repeatedly
whilst holding down the SHIFT button to change the TV type (see page 20).
2Press the OPEN/CLOSE button to open the disc tray.
3Place the disc on the disc tray, label side up.
Be sure to place 8 cm discs in the middle of the tray.
4Press the OPEN/CLOSE button to close the disc tray.
Discs supporting auto start will start to play once you close the disc tray even if
you do not press the PLAY/PAUSE / button.
5If playback does not start, press the PLAY/PAUSE / button.
DVD
VideoCD
CD
Audio Visual
Entertainment
NO DISC
Disc tray
Label side
