Sharp DV-SV92S(L) User manual

MODEL
DV-SV92S(L)
DVD Video Player
OPERATION MANUAL
The region number for this
DVD Video Player is 2.
Please read this Operation Manual carefully before using
your DVD Video Player.
2
DV-SV92S(B)_East_europian_english .indd 1 12/14/2005 5:54:02 PM

DV-SV92S(B)_East_europian_english .indd 1 12/14/2005 5:54:04 PM

- 1 - EN
SAFETY INFORMATION
Note:
This player can be used only where the power supply is
AC 220-240 V, 50 Hz. It cannot be used elsewhere.
CAUTION:
USE OF CONTROLS OR ADJUSTMENTS OR PER-
FORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN HAZ-
ARDOUS RADIATION EXPOSURE.
AS THE LASER BEAM USED IN THIS PLAYER IS
HARMFUL TO THE EYES, DO NOT ATTEMPT TO
DISASSEMBLE THE CABINET. REFER SERVICING
TO QUALIFIED PERSONNEL ONLY.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS EQUIPMENT TO
RAIN OR MOISTURE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, AND ANNOYING INTERFERENCE, USE THE
RECOMMENDED ACCESSORIES ONLY.
Laser Diode Properties
Material: GaAs
Wavelength: DVD: 650 nm
CD: 790 nm
Emission duration: Continuous
Laser output: Max. 0.5 mW
Power Cord Protection
To avoid any malfunctions of the player, and to protect against
electric shock, fire or personal injury, please observe the fol-
lowing.
• Hold the plug firmly when connecting or disconnecting the
AC power cord
• Keep the AC power cord away from heating appliances.
• Never put any heavy object on the AC power cord.
• Do not attempt to repair or reconstruct the AC power cord in
any way.
• This player is classified as a CLASS 1 LASER product.
• The CLASS 1 LASER PRODUCT label is located on the rear
cover.
• This product contains a low power laser device. To ensure
continued safety do not remove any cover or attempt to gain
access to the inside of the product. Refer all servicing to
qualified personnel.
DV-SV92S(B)_East_europian_english .indd 1 12/14/2005 5:54:07 PM

- 2 - EN
Location and Handling
• Do not cover or place the player in enclosed spaces to
prevent excessive temperature build-up.
• Do not place the player in direct sunlight, or near heat
sources.
• Keep the player away from strong magnetic objects.
• Do not place any object containing water or other liquids
on the player. In the event that liquid should enter the
cabinet, unplug the player immediately and contact the
retailer or service centre approved by SHARP immedi-
ately.
• Do not remove the player cabinet. Touching parts inside
the cabinet could result in electric shock and/ or dam-
age to the player. For service and adjustment inside the
cabinet, call a qualified dealer or service centre approved
by SHARP.
Non-use Periods
When the player is not being used, switch the player to
the Standby mode.
When left unused for a long period of time, the player should
be unplugged from the household AC outlet.
No Fingers or Other Objects Inside
Do not put any foreign object on the disc tray.
Stacking
Place the player in a horizontal position, and do not place
anything heavy on it.
Condensation
Moisture may form on the pickup lens in the following
conditions:
• immediately after a heater has been turned on.
• in a steamy or very humid room.
• when the player is suddenly moved from a cold environ-
ment to a warm one.
If moisture forms inside this player, it may not operate
properly. In this case, turn on the power and wait about
one hour for the moisture to evaporate.
Cleaning
Unplug your player before cleaning. Use a damp cloth
for cleaning. Do not use cleaning fluids or aerosols which
could enter the player and cause damage, fire, or electri-
cal shock.
These substances may also deteriorate the finish of your
player.
If There Is Noise Interference on the TV While a Broad-
cast Is Being Received
Depending on the reception condition of the TV, interfer-
ence may appear on the TV monitor while you watch a TV
broadcast and the player is left on. This is not a malfunc-
tion of the player or the TV. To watch a TV broadcast, turn
off the player.
Service
Do not attempt to service this player yourself. Please
refer any service to the nearest service centre approved
by SHARP.
Copyright
Audio-visual material may consist of copyrighted works
which must not be recorded without the authority of the
owner of the copyright. Please refer to relevant laws in
your country.
Copy Protection
This player supports Macrovision copy protection. On DVDs
that include a copy protection code, if the contents of the
DVD are copied using a VCR, the copy protection code
prevents the videotape copy from playing normally.
U.S.Patent Nos. 4,631,603; 4,819,098; 4,907,093;
5,315,448; and 6,516,132
This product incorporates copyright protection technol-
ogy that is protected by U.S. patents and other intel-
lectual property rights. Use of this copyright protection
technology must be authorised by Macrovision, and is
intended for home and other limited viewing uses only
unless otherwise authorised by Macrovision. Reverse
engineering or disassembly is prohibited.
• When attempting to record copy protected material on a
VCR or other recording device, the copy protection will
activate and the protected material will not be recorded
correctly. In addition, attempting to display copy protected
material on a monitor connected via a VCR, whether for
the purpose of viewing or not, will cause an inferior quality
picture to be displayed. This is not a fault of the equipment.
Please view copy protected material by connecting the
product directly to the monitor.
Recommended Measures for Optimum Picture Excel-
lence
The player is a precision device that is constructed using
extremely accurate technology.
Soiling or friction affecting the pickup lens or disc drive can
impair the image quality. At the worst, neither video nor
audio will be played back. Contact your authorised SHARP
supplier for details.
Do not attempt to clean the pickup lens yourself.
SAFETY INFORMATION
DV-SV92S(B)_East_europian_english .indd 2 12/14/2005 5:54:08 PM

- 3 - EN
TABLE OF CONTENTS
SAFETY INFORMATION ............................................................................1
TABLE OF CONTENTS .............................................................................3
ABOUT THIS MANUAL ..............................................................................4
GENERAL PROPERTIES .......................................................................... 4
SUPPLIED ACCESSORIES .......................................................................4
DISC TYPES COMPATIBLE WITH THE PLAYER ..................................... 5
SAFETY PRECAUTIONS .......................................................................... 7
FRONT PANEL FUNCTIONS .....................................................................8
FRONT PANEL DISPLAY (VFD) ................................................................8
CONNECTORS ON THE REAR PANEL ....................................................9
CONNECTION OF THE PLAYER WITH TV ............................................ 10
CONNECTION OF THE PLAYER WITH AV AMPLIFIER ......................... 12
REMOTE CONTROL ................................................................................14
REMOTE CONTROL FUNCTIONS ..........................................................15
DVD PLAYBACK .....................................................................................16
Direct Selection of Scenes .......................................................................17
Repeat Play ..............................................................................................18
Convenient Functions ...............................................................................19
VIDEO CD PLAYBACK ...........................................................................21
Direct Selection of Scenes .......................................................................22
Repeat Play .............................................................................................23
Convenient Functions ...............................................................................23
AUDIO CD PLAYBACK ...........................................................................24
Direct Selection of Tracks ......................................................................... 25
Repeat Play ..............................................................................................25
Convenient Functions ...............................................................................26
SMART NAVI ...........................................................................................27
USING SETUP MENU ............................................................................. 29
VIDEO SETUP .........................................................................................30
AUDIO SETUP .........................................................................................31
LANGUAGE SETUP ............................................................................... 31
PARENTAL SETUP ..................................................................................31
PREFERENCES ...................................................................................... 32
DivX(R) REGISTRATION .........................................................................32
TROUBLESHOOTING .............................................................................33
SPECIFICATIONS .................................................................................... 34
DEFINITION OF TERMS .........................................................................35
DV-SV92S(B)_East_europian_english .indd 3 12/14/2005 5:54:09 PM

- 4 - EN
Instructions in this manual describe the controls on the player. You can also use the controls on the remote if they have
the same or similar names as those on the player.
Dear Customers
We would like to thank you for purchasing this DVD/DVD-RW/DVD-R/DVD+RW/DVD+R/VCD/S-VCD/AUDIO CD/CD-
RW/CD-R/MP3/JPEG/MPEG-4/ DivX® player.
We strongly recommend that you carefully study the operating instructions before attempting to operate the player and
that you note the listed safety precautions.
GENERAL PROPERTIES
1) DVD/DVD-RW/DVD-R/DVD+RW/DVD+R/VCD/S-VCD/AUDIO CD/CD-RW/CD-R/MP3/JPEG/MPEG-4/ DivX® play-
back
2) Official DivX® Certified product
Plays all versions of DivX® video (including DivX®6 ) with standard playback of DivX® media files
3) PAL/NTSC playback (according to disc content)
4) User-friendly multi-language OSD menu control
5) Vacuum Fluorescent Display (VFD)
6) DTS, Dolby Digital, LPCM audio, MPEG audio via coaxial and optical digital audio outputs
7) Multiple Aspect Ratio support (16:9 Wide screen, 4:3 Letterbox, 4:3 PAN & SCAN)
8) Multi-Audio (up to 8) support
9) Multi-Subtitle (up to 32) support
10) Multi-Angle (up to 9) support
11) 8 level parental control
12) Fast forward and reverse at different speeds
13) Smooth and seamless playback at 2x speed for DVD
14) Slow motion playback at different speeds
15) Frame-by-frame forward and backward playback
16) Time Search
17) Repeat (disc, title, chapter, A-B)
18) Different play modes for Audio CD, MP3 and JPEG
19) Programme function for Audio CD, MP3 and JPEG
20) Scart connector
21) Progressive Scan Component Video output
22) Composite Video output
• Manufactured under licence from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Labo-
ratories.
• is a trademark of DVD Format/Logo Licensing Corporation.
• “DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.
• DivX, DivX Certified, and associated logos are trademarks of DivX, Inc. and are used under licence.
SUPPLIED ACCESSORIES
In the packaging material you will find the following:
(1) Remote control (2) Two R03 (AAA) batteries for the remote control (3) Operation manual
ABOUT THIS MANUAL
DV-SV92S(B)_East_europian_english .indd 4 12/14/2005 5:54:09 PM

- 5 - EN
The player can play the following discs.
Disc Types
(Logos)
Recording
Types Disc Size
Max.
Playing
Time
Characteristics
DVD
Audio
+
Video
12 cm
Single - sided;
240 min.
Double - sided;
480 min.
• DVD contains excellent sound and
video due to Dolby Digital and MPEG-
2 System.
• Various screen and audio functions
can be easily selected through the
on-screen menu.
8 cm
Single - sided;
80 min.
Double - sided;
160 min.
VIDEO-CD
Audio
+
Video
12 cm 74 min.
• Video with CD sound, VHS quality and
MPEG-1 compression technology.
8 cm 20 min.
AUDIO-CD
Audio
12 cm 74 min. • An LP is recorded as an analogue
signal with more distortion. CD is
recorded as a digital signal with better
audio quality, less distortion and less
deterioration of audio quality over
time.
8 cm 20 min.
MP3-CD Audio
(xxxx.mp3)
12 cm It depends
on MP3
quality.
• MP3 is recorded as a digital signal
with better audio quality, less distor-
tion and less deterioration of audio
quality over time.
8 cm
PICTURE-CD Video
(still picture)
12 cm It depends
on JPEG
quality.
• JPEG is recorded as a digital signal
with better picture quality over time.
8 cm
DivX®
Audio
+
Video
12 cm It depends
on DivX®
quality.
• DivX® media files contain highly com-
pressed video with high visual quality
that maintains a relatively small file
size.
8 cm
 NOTE:
For DVD-RW/-R, DVD+RW/+R, only discs recorded in Video mode can be played back.
• Some DVD-RW/-R, DVD+RW/+R or CD-RW/-R discs made on personal computers, or on DVD recorders
may not be played back properly due to the factors such as scratches, dirt or special properties of the disc.
• Discs made on personal computers may not be played back properly due to the different environment or
the settings of the application you use. We recommend always to use the standardised, correctly formatted
discs.
DISC TYPES COMPATIBLE WITH THE PLAYER
DV-SV92S(B)_East_europian_english .indd 5 12/14/2005 5:54:11 PM

- 6 - EN
The following discs cannot be played back on the player:
• DVD with region codes other than 2 or ALL.
• DVD-ROM
• DVD-RAM (Never play back, otherwise malfunction may result.)
• CDV (Only plays back the audio part.)
• CD-ROM
• CD-G (Only plays back the sound.)
• CD-I (Never play back, otherwise malfunction may result.)
• Super Audio CD (Only the sound recorded on the normal CD layer can be delivered. The sound recorded on the
high density Super Audio CD layer cannot be delivered.)
• Photo CD (Never play back, otherwise malfunction may result.)
Any other discs without compatibility indications.
 NOTE:
When an incompatible disc is inserted, a message appears in the VFD and the on-screen display indicating that
the disc is not playable.
RECORD
SPRAY
THINNER
BENZENE
Notes on discs:
On handling discs
• To keep the disc clean, handle the disc by its edge. Do not touch the surface.
• Do not stick paper or tape on the disc.
• If the disc is contaminated with any substance such as glue, remove it before using the
disc.
• Do not expose the disc to direct sunlight or heat sources such as hot air ducts, or leave
it in a car parked in direct sunlight as the temperature can rise quickly and damage the
disc.
• After playing, store the disc in its case.
On cleaning
• Before playing, clean the disc with a cleaning cloth. Wipe the disc from the centre
out.
• Do not use solvents such as benzene, thinner, commercially available cleaners or anti-
static spray intended for vinyl LPs.
Discs that should not be used
Only the discs including the marks shown on page 5 can be played.
 NOTE:
• Discs with special shapes (heart-shaped discs, hexagonal discs, etc.) cannot be played.
Do not attempt to play such discs, as they may damage the player.
• Do not use record or anti-static spray. Also do not use volatile chemicals such as ben-
zene or thinner.
DV-SV92S(B)_East_europian_english .indd 6 12/14/2005 5:55:01 PM

- 7 - EN
Power Source
The player should be operated only from a 220-240 V, 50 Hz outlet. Please do not open the cover by yourself. There is
high voltage in the player, which will endanger your life. Please contact a local service agent for help and advice. Repairs
are to be carried out by a qualified technician only.
• The player is not disconnected from the AC power source (mains) as long as it is connected to the wall outlet, even if
the player itself has been turned off.
• If you are not going to use the player for a long time, be sure to disconnect the player from the wall outlet.
Power Cord
Do not place the player, a piece of furniture, etc., on the power cord (mains lead), or pinch the cord. Handle the power
cord by the plug. Do not pull out the plug by tugging the cord and never touch the power cord when your hands are wet
as this could cause a short circuit or electric shock. Never make a knot in the cord or tie it with other cords. The power
cord should be routed in such a way that it is not likely to be stepped on. A damaged power cord can cause fire or give
you an electrical shock. Check the power cord once in a while. When you find it damaged, ask your closest service agent
for help. When the AC power cord needs to be changed, it should be done at a qualified service shop only.
Choice of Location
• Please do not place the player in a place subject to direct sunlight, excessive dust or mechanical shock or in a location
near heat sources.
• The player should be placed on a solid and safe base. Do not place the player on a soft surface such as a rug that might
block the ventilation holes on the bottom.
• Do not place the player in a room subject to high humidity, such as a kitchen, as condensation may cause malfunction
or damage the player.
• Heating or other thermal radiation under the player also may cause malfunction or damage the player.
• The hot air, which arises during the operation, should be ventilated with sufficient air circulation. Please do not put the
set into closed areas and do not cover it.
• Do not allow the player to come in contact with water or humidity. Do not use the player near a bath or swimming
pool.
• Take care to provide good air circulation. Place the player in a location with adequate ventilation to prevent heat build-up
in the player.
• Should any solid object or liquid fall into the cabinet, unplug the player and have it checked by qualified personnel before
operating it any further.
SAFETY PRECAUTIONS
DV-SV92S(B)_East_europian_english .indd 7 12/14/2005 5:55:03 PM

- 8 - EN
FRONT PANEL FUNCTIONS
1 21 43 56 7
1. Disc tray
Place a disc on the tray.
2. OPEN/CLOSE button
Opens or closes the disc tray.
3. PLAY/PAUSE button
Plays/pauses the disc. For any DVD title that has a root menu with still picture, this button functions as SELECT (selects
highlighted item) in the root menu. Otherwise the disc will prohibit this function on the root menu, and “ ” will be displayed
on the screen.
4. STOP button
Stops playing the disc.
5. SKIP buttons
Press to go back to the preceding chapter/track or to go to the next chapter/track.
6. Front panel display (VFD)
Indicates the playing time, title, chapter/track, etc.
7. OPERATE button
Turns the player to Operate or Standby mode.
FRONT PANEL DISPLAY (VFD)
5
6
7
8
9
1
2
3
4
1. Play/Pause
2. Disc loaded
3. Time or Title / Chapter / Track number
4. Dolby Digital / DTS
5. Zoom
6. Title number
7. Angle
8. Chapter / Track number
9. Repeat
DV-SV92S(B)_East_europian_english .indd 8 12/14/2005 5:56:39 PM

- 9 - EN
CONNECTORS ON THE REAR PANEL
1. DIGITAL AUDIO OUT connectors
OPTICAL :
Connects to an audio component using the optical digital connection cable.
COAXIAL :
Connects to an audio component using the coaxial digital connection cable.
2. AUDIO OUT connectors
Connects to the AV amplifier or audio input connector on the TV by using two cables (Left, Right).
3. VIDEO OUT connector
Connects to the TV using a video cable.
4. SCART connector
Connects to the TV using the SCART cable.
5. COMPONENT OUT connectors
Connects to the TV using a component video cable.
DV-SV92S(B)_East_europian_english .indd 9 12/14/2005 5:56:41 PM

- 10 - EN
CONNECTION OF THE PLAYER WITH TV
Be sure to turn off the power of each component before making the connections.
Use one video connection for best picture performance
When the player is connected to multiple video output connectors, the picture performance may be affected by unde-
sired video signals from the connectors that are not selected.
For best picture performance, it is recommended that you select the appropriate item from the SETUP menu and use
only one video connection method.
SCART Connector:
If the player is not connected to a hi-fi set or AV amplifier to hear better sound, SCART is enough for both audio & video
connections.
Video & Audio Output Connectors:
Video (yellow) and audio (red: right, white: left) output connectors can be used to connect the player to your TV set via cables.
To make this connection, your TV set must have video and audio input connectors. This type of connection is alternative
to scart connection. Picture quality is not as good as SCART RGB connection but audio performance is the same.
TV
Audio/Video cable (commercially available)
AUDIO OUT
(L-R)
VIDEO OUT
TV
Scart cable (commercially available)
SCART SCART
DV-SV92S(B)_East_europian_english .indd 10 12/14/2005 5:56:42 PM

- 11 - EN
Compatibility of the progressive scan TVs
Some progressive scan TVs are not fully compatible with the player, which may cause image distortion. In this case,
switch Video output mode from “PROGRESSIVE” to “VIDEO”, “Y/PB/PR” or “RGB”.
Component Video & Audio Output Connectors
• If you have a high-definition or “digital ready” TV, you may take advantage of the player’s Progressive Scan and YPBPR
(YUV) output for the highest video resolution possible.
• If your TV does not accept the Progressive Scan or YPBPR (YUV) format, the picture will appear scrambled when you
try Progressive Scan or YPBPR (YUV) output on the player.
1. Connect the COMPONENT OUT connectors on the player to the corresponding input connectors on the TV, using a
component video cable.
2. Connect the L-R AUDIO OUT connectors of the player to the audio Left - Right input connectors on the TV using the
audio cable.
Y Pb Pr
COMPONENT VIDEO INPUT
LEFT RIGHT
AUDIO INPUT
Audio cable
(commercially available) Component video cable
(commercially available)
TV
DV-SV92S(B)_East_europian_english .indd 11 12/14/2005 5:57:30 PM

- 12 - EN
CONNECTION OF THE PLAYER WITH AV AMPLIFIER
Be sure to turn off the power of each component before making the connections.
Analogue Audio Output Connectors:
To achieve better sound quality, the player can be connected to an amplifier via AUDIO OUT connectors.
TV
Audio cable
(commercially available)
AUDIO OUT
(L-R)
VIDEO
OUT
Video cable
(commercially available)
Amplifier
DV-SV92S(B)_East_europian_english .indd 12 12/14/2005 5:57:31 PM

- 13 - EN
Digital Audio Output Connectors:
For the best sound, the player can be connected via optical or coaxial digital audio outputs to an AV amplifier with a built-in
Dolby Digital or DTS decoder. With the use of six speakers, you can enjoy 5.1-channel surround sound.
IN
IN
 NOTE:
• When the player is connected to a separate decoder box or amplifier through the DIGITAL AUDIO OUT connector, you
may sometimes hear a short noise when selecting the sound system in the DVD menu. This is not a malfunction.
AmplifierDVD player
OR Dust protection cap
DVD player
Coaxial or optical cable
(commercially available)
to coaxial or optical
digital audio input connector Amplifier
Front speaker
(Left)
Front speaker
(Right)
Centre speaker
Rear speaker
(Left)
Rear speaker
(Right)
Subwoofer
DV-SV92S(B)_East_europian_english .indd 13 12/14/2005 5:58:22 PM

- 14 - EN
REMOTE CONTROL
When using the remote control, point it towards the front
of the player. If the remote control does not work or the
chosen function cannot be selected, the batteries are most
probably exhausted and they should be replaced as soon
as possible.
Inserting the Batteries
The batteries (two R-03 batteries (“AAA” size, UM/SUM-4,
HP-16 or similar)) are included in the package.
1 Pull down the tab on the cover and remove the cover
towards the direction of the arrow.
2 Insert the included batteries.
• Insert the batteries making sure the polarities correctly
match the and marks inside the battery compart-
ment.
3 Insert the lower tab of the cover into the opening, and lower
the cover until it clicks in place.
Incorrect use of the batteries may cause them to leak or explode. Please follow the precautions below.
Caution
• Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
• Insert the batteries making sure the polarities correctly match and marks inside the battery compartment.
• Batteries of different types have different properties, therefore do not mix batteries of different types.
• Do not mix new and old batteries.
This may shorten the life of new batteries or may cause old batteries to leak.
• Remove the batteries from the remote control once they have run out, as leaving them can cause them to leak.
Battery fluid from leaked batteries is harmful to your skin, therefore ensure that you first wipe them and then remove
them using a cloth.
• The batteries included with the player may exhaust over a short period, depending on how they are kept.
Be sure to replace them as soon as possible with new batteries.
• Remove the batteries from the remote control if you do not use the remote control for a long time.
• Comply with the rules (ordinance) of each local government when disposing of worn-out batteries.
1
2
3
4
5
6
7
9
10
11
12
13
14
16
17
18
19
20
21
22
23
15
24
8
DV-SV92S(B)_East_europian_english .indd 14 12/14/2005 5:59:12 PM

- 15 - EN
1. OPERATE button
Turns the player on or switches the player to Standby mode.
2. PROGRAM button
Enters the programme menu in Stop mode for Audio CD, MP3 CD and JPEG CD.
3. TIME button
Changes Playing time display mode of the disc, title, track, on the OSD and front panel display.
4. ZOOM button
Zooms the picture.
5. PLAY/PAUSE button
Plays/pauses the disc. For any DVD title that has a root menu with still picture, this button functions as SELECT
(selects highlighted item) in the root menu. Otherwise the disc will prohibit this function on the root menu, and “ ”
will be displayed on the screen.
6. MENU button
Displays the DVD root menu on the screen. During VCD playback, shows the VCD menu if it exists.
7. TITLE button
Displays the title menu on the TV screen.
8. /// buttons
Move to the items or settings.
9. SEARCH MODE button
Puts the player in Search mode (title, chapter, track, time, index).
10. SUBTITLE button
Changes the language of the subtitle while playing a DVD and switches selected subtitle on/off for DivX®.
11. Number buttons
Press to directly enter track/chapter/title/time numbers.
12. +10 button
Enters numbers greater than 9.
13. OPEN/CLOSE ( ) button
Opens or closes the disc tray.
14. REPEAT button
Executes disc/title/chapter repeat.
15. A - B button
Executes the A - B repeat play.
16. SLOW/SEARCH buttons
Press to adjust the forward and reverse playback at different speed during playback (fast forward/reverse) or dur-
ing Pause mode (slow motion).
17. SKIP/FRAME buttons
Go to the previous/next chapter or track during playback, or go to next/previous frame during pause.
18. STOP button
Stops playing disc.
19. DISPLAY button
Displays the current playing status or SETUP menu on the TV screen.
20. RETURN button
Returns to the preceding selection screen.
21. SELECT button
Executes the items or settings.
22. ANGLE button
Changes the angle when playing a DVD.
23. AUDIO button
Changes the language of the sound while playing a DVD.
24. C button
Deletes incorrect entries or cancel some functions.
REMOTE CONTROL FUNCTIONS
DV-SV92S(B)_East_europian_english .indd 15 12/14/2005 5:59:13 PM

- 16 - EN
DVD PLAYBACK
Preparations
If the player has been connected to an audio system, turn
it on and then turn on your TV.
Basic Play
1. Press OPERATE.
2. Press OPEN/CLOSE ( ) to open the disc tray.
3. Place a disc onto the tray.
Hold the disc without touching either of its surfaces, posi-
tion it with the printed title side facing up, align it with the
guides, and place it in its proper position.
4. Press OPEN/CLOSE ( ).
A menu may be displayed on the TV screen after a few
moments or the film may start immediately after the intro-
duction of the Film Company. This behaviour depends on
the disc content and may change.
 NOTE:
• Steps 5 and 6 are available only when a menu is recorded
on the disc.
5. Press /// or the number buttons to select the
preferred title.
6. Press SELECT.
Play of the selected items now starts. The played item
may be a motion picture, a still picture or another submenu
depending on the disc.
 NOTE:
• The disc controls the behaviour of the player during menu
operation.
To stop play and return to the menu screen (when a menu
is available on the disc), press MENU or TITLE depending
on the disc. Play is suspended, and the disc menu screen
is displayed.
After operation
When the player is not in use, remove the disc and press
OPERATE to turn off the player.
 NOTE:
• The disc continues to rotate while the menu is displayed
even after the player has finished playing a particular item.
When no further selections are to be played, be sure to
press STOP () to clear the menu display.
• If the disc is placed in upside down (and it is a single sided
disc), the VFD on the player will indicate “NO DISC”.
For your reference:
If an action corresponding to a button is prohibited, “ ” is
displayed on the screen.
Stopping Play
Press STOP () twice.
When play is stopped, the player records the point where
STOP () was pressed once (Resume function). Press
PLAY/PAUSE again, and play will resume from this point.
When the tray is opened or the STOP () is pressed again,
the Resume function will be cleared.
To stop play permanently, press STOP () twice. When
STOP () is pressed for the first time, the message
“PRESS PLAY TO CONTINUE” is displayed on the screen
to prompt you whether to continue play. To stop play
press STOP () again or you can press PLAY/PAUSE
to continue.
Fast Forward / Reverse
Press SLOW/SEARCH (Fast reverse or  Fast forward)
on the remote control during playback.
Normal play is resumed when PLAY/PAUSE or SELECT
on the remote control is pressed.
The speed of fast forward or fast reverse changes each
time  or  is pressed.
Skip Forward / Backward
Press SKIP/FRAME ( or ) during playback.
The chapter is skipped forward or backward each time the
button is pressed.
Pause
Press PLAY/PAUSE once during playback.
Play pauses.
To return to normal play:
Press PLAY/PAUSE or SELECT.
Step Forward / Backward
Press PLAY/PAUSE once during playback.
Play pauses.
Press SKIP/FRAME ( or ).
The next or previous frame of the movie is displayed.
DV-SV92S(B)_East_europian_english .indd 16 12/14/2005 5:59:13 PM

- 17 - EN
Direct Selection of Scenes
Selecting Scenes by Chapter Number
Press SEARCH MODE on the remote control once during
playback.
The chapter/title search box is displayed on the screen. You
can see the total number of chapters as “-/xx”.
Enter the number of the chapter using number buttons.
The selected chapter is played just after you enter the
chapter number.
If the chapter number entered is between 0 and 9, the player
will automatically jump to the related chapter. To enter a
chapter number with more than one digit, press +10 and
then enter the chapter number.
If you enter a wrong number, press C to clear the field.
You can press RETURN to cancel chapter search.
 NOTE:
• If you attempt to enter a number greater than the total
number of chapters on the current title, the search box
disappears.
• If you wait 10 seconds without pressing any button to
select scenes by chapter number, this operation is can-
celled.
Selecting Scenes by Title Number
Press SEARCH MODE on the remote control once during
playback.
The chapter/title search box is displayed on the screen.
Press  on the remote control to select the title field in the
search box to change the title.
You can see the currently playing title and total number of
titles as “-/xx”.
Enter the number of the title using number buttons.
The selected title is played just after you enter the title
number.
If the title number entered is between 0 and 9, the player
will automatically jump to the related title. To enter a title
number with more than one digit, press +10 and then enter
the title number.
If you enter a wrong number, press C to clear the field.
You can press RETURN to cancel title search.
Slow Motion Play Forward / Backward
Press PLAY/PAUSE once during playback.
Play pauses.
Press SLOW/SEARCH ( Slow backward or  Slow
forward) to increase or decrease the speed of the slow
motion play.
The speed of slow motion play is displayed on the screen
each time you change it.
To return to normal play:
Press PLAY/PAUSE or SELECT.
DV-SV92S(B)_East_europian_english .indd 17 12/14/2005 5:59:14 PM

- 18 - EN
 NOTE:
• If you attempt to enter a number greater than the total
number of titles, the search box disappears.
• If you wait 10 seconds without pressing any button to se-
lect scenes by title number, this operation is cancelled.
Selecting Scenes by Time
You can view the DVD starting from any desired time
point.
Press SEARCH MODE on the remote control twice during
playback.
The time search box is displayed on the screen. You can
see the total runtime of the title as “--:--:--”.
Enter the time using number buttons.
The title is played beginning from the desired time just after
you enter the time, if not prohibited by the DVD.
If you enter a wrong number, press C to clear the field.
You can press RETURN to cancel time search.
 NOTE:
• If you attempt to enter a number greater than the total
time of the current title, the search box disappears.
• If you wait 10 seconds without pressing any button to
enter the time, this operation is cancelled.
Repeat Play
Repeat Viewing
Press REPEAT during playback.
Each time this button is pressed, a different repeat box is
displayed on the screen.
If “CHAPTER REPEAT ON” is displayed, the current chap-
ter will be played again.
If “TITLE REPEAT ON” is displayed, the current title will
be played again.
If “REPEAT OFF” is displayed, Repeat mode is disabled.
 NOTE:
• Repeat play may be prohibited by some DVD titles.
Repeating Sections between Two Specific Points
(A – B Repeat)
Press A-B during playback at the point where Repeat play
is to start (A).
“A TO B SET A” is displayed on the screen.
Press A-B again at the point where Repeat play is to end
(B).
“A TO B SET B” is displayed and Repeat play of the se-
lection between points A and B starts, if not prohibited by
the DVD.
To return to normal play:
Press A-B again. “A TO B CANCELLED” is displayed and
the A-B Repeat is disabled.
DV-SV92S(B)_East_europian_english .indd 18 12/14/2005 5:59:14 PM
