CODE : 00Z
SERVICE MANUAL
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified
ones for maintaining the safety and performance of the set.
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
FOP820THSE
FACSIMILE
MODEL
UX-P880TH
UX-P850TH
FO-P820TH
NX-P870TH
DIFFERENCE BETWEEN UX-P850TH AND UX-P410TH
UX-P850TH UX-P410TH
PG No. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION PARTS CODE
-TLABP424LXHZZ AD N D CONSUMER LABEL -
5-11 TINST4395XHTC AN N D OPERATION MANUAL TINST4395XHTZ
5-17 SPAKC982HXHTZ AN N D PACKING CASE CPAKC346FXH01
5-6 QCNWG430CXHZZ AH C TELEPHONE LINE CORD QCNWG208BXHZZ
1-62 HPNLH2420XHRB AL N D DECORATION PANEL HPNLH2420XHSQ
5-2 QCNWG377DXHBG AG C HANDSET CORD QCNWG209BXHAG
5-1 DUNTK497CXHTA AW N E HANDSET DUNTK497CXHAG
1-57 PCOVP2131XHYB AE N C PANEL CABLE COVER PCOVP2131XHVB
1-46 GCOVA2447XHYB AE N D FRONT COVER GCOVA2447XHVB
1-35 GCABB2393XHRB AZ N D LOWER CABINET GCABB2393XHSQ
1-24 LFRM-2225XHSL AK N C SCANNER FRAME LFRM-2225XHVB
3-901 DCEKP480CXH61 BK N E OPERATION PANEL UNIT DCEKP480CXH36
3-19 JBTN-2361XHSL AH N C FUNCTION 2 KEY JBTN-2361XHSE
3-18 JBTN-2360XHSL AH N C SPEED KEY JBTN-2360XHSE
3-3 JBTN-2359XHSB AH C START KEY JBTN-2359XHSG
3-4 JBTN-2358XHSH AK N C FUNCTION KEY JBTN-2358XHSD
3-2 JBTN-2357XHSL AM N C 12 KEY JBTN-2357XHSE
3-1 GCASP2173XHTB AT N D PANEL CASE GCASP2173XHZK
2-17 PGIDM2621XHSL AG N C RELEASE LEVER PGIDM2621XHSF
2-5 PGIDM2620XHYB AE N C HOPPER GUIDE, RIGHT PGIDM2620XHVC
2-4 PGIDM2619XHYB AE N C HOPPER GUIDE, LEFT PGIDM2619XHVC
2-1 GCOVA2448XHYB AN N C TOP COVER GCOVA2448XHVB
This Service Manual is for UX-P880TH, UX-P850TH, FO-P820TH and NX-P870TH, which is
a minor-modification model of the UX-P410TH, UX-P610TH and NX-P160TH. This manual,
therefore, describes only the changed points from the Parts Guide. Please refer to the
UX-P410TH Service Manual (00ZUP410THSME) together with this manual.
<UX-P850TH>

UX-P880TH/UX-P850TH/FO-P820TH/NX-P870TH
–
2 –
DIFFERENCE BETWEEN FO-P820TH AND FO-P610TH
DIFFERENCE BETWEEN NX-P870TH AND NX-P160TH
FO-P820TH FO-P610TH
PG No. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION PARTS CODE
-TLABP423LXHZZ AD N D CONSUMER LABEL -
5-11 TINST4395XHTC AN N D OPERATION MANUAL TINST4395XHTZ
5-17 SPAKC981HXHTZ AM N D PACKING CASE CPAKC347FXH01
5-6 QCNWG430CXHZZ AH C TELEPHONE LINE CORD QCNWG208BXHZZ
1-62 HPNLH2420XHRA AL N D DECORATION PANEL HPNLH2420XHZK
5-2 QCNWG377DXHBW AH C HANDSET CORD QCNWG209BXHBW
5-1 DUNTK468BXHW1 AW N E HANDSET DUNTK497CXHBW
1-57 PCOVP2131XHYA AE N C PANEL CABLE COVER PCOVP2131XHVF
1-46 GCOVA2447XHYA AE N D FRONT COVER GCOVA2447XHSM
1-35 GCABB2393XHRA AZ N D LOWER CABINET GCABB2393XHSY
1-24 LFRM-2225XHSK AK N C SCANNER FRAME LFRM-2225XHSI
3-901 DCEKP480CXH60 BG N E OPERATION PANEL UNIT DCEKP480CXH34
3-19 JBTN-2361XHSE AM C FUNCTION 2 KEY JBTN-2361XHSD
3-18 JBTN-2360XHSE AL C SPEED KEY JBTN-2360XHSC
3-3 JBTN-2359XHSG AQ C START KEY JBTN-2359XHSD
3-4 JBTN-2358XHSD AP C FUNCTION KEY JBTN-2358XHSC
3-2 JBTN-2357XHSE AM C 12 KEY JBTN-2357XHSB
3-1 GCASP2173XHTA AU N D PANEL CASE GCASP2173XHZL
3-16 PGIDM2614XHSH AL N C DOCUMENT GUIDE UPPER PGIDM2614XHSD
2-17 PGIDM2621XHSK AG N C RELEASE LEVER PGIDM2621XHSD
2-5 PGIDM2620XHYA AE N C HOPPER GUIDE, RIGHT PGIDM2620XHSJ
2-4 PGIDM2619XHYA AE N C HOPPER GUIDE, LEFT PGIDM2619XHSJ
2-1 GCOVA2448XHYA AN N C TOP COVER GCOVA2448XHRI
NX-P870TH NX-P160TH
PG No. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION PARTS CODE
-TLABP425LXHZZ AD N D CONSUMER LABEL -
5-11 TINST4395XHTC AN N D OPERATION MANUAL TINST4395XHTZ
5-17 SPAKC983HXHTZ AN N D PACKING CASE CPAKC345FXH01
5-6 QCNWG430CXHZZ AH C TELEPHONE LINE CORD QCNWG208BXHZZ
1-62 HPNLH2420XHRC AL N D DECORATION PANEL HPNLH2420XHZY
5-2 QCNWG377DXHBP AH N C HANDSET CORD QCNWG209XHOW
5-1 DUNTK497CXHTB AW N E HANDSET DUNTK497CXHFW
1-57 PCOVP2131XHYA AE N C PANEL CABLE COVER PCOVP2131XHVA
1-46 GCOVA2447XHYA AE N D FRONT COVER GCOVA2447XHVA
1-35 GCABB2393XHRA AZ N D LOWER CABINET GCABB2393XHSD
1-24 LFRM-2225XHSK AK N C SCANNER FRAME LFRM-2225XHVA
3-901 DCEKP480CXH62 BG N E OPERATION PANEL UNIT DCEKP480CXH35
3-19 JBTN-2361XHSM AE N C FUNCTION 2 KEY JBTN-2361XHSD
3-18 JBTN-2360XHSM AE N C SPEED KEY JBTN-2360XHSC
3-3 JBTN-2359XHSM AE N C START KEY JBTN-2359XHSD
3-4 JBTN-2358XHSJ AE N C FUNCTION KEY JBTN-2358XHSC
3-2 JBTN-2357XHSM AK N C 12 KEY JBTN-2357XHSB
3-1 GCASP2173XHTC AV N D PANEL CASE GCASP2173XHSV
3-16 PGIDM2614XHSH AL N C DOCUMENT GUIDE UPPER PGIDM2614XHSA
2-17 PGIDM2621XHSK AG N C RELEASE LEVER PGIDM2621XHSA
2-5 PGIDM2620XHYC AE N C HOPPER GUIDE, RIGHT PGIDM2620XHVA
2-4 PGIDM2619XHYC AE N C HOPPER GUIDE, LEFT PGIDM2619XHVA
2-1 GCOVA2448XHYA AN N C TOP COVER GCOVA2448XHVA

UX-P880TH/UX-P850TH/FO-P820TH/NX-P870TH
–
3 –
DIFFERENCE BETWEEN UX-P880TH AND UX-P410TH
UX-P880TH UX-P410TH
PG No. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION PARTS CODE
5-17 SPAKC011JXHTZ AN N D PACKING CASE CPAKC346FXH01
2-1 GCOVA2448XHYB AN C TOP COVER GCOVA2448XHVB
2-4 PGIDM2619XHYB AE C HOPPER GUIDE, LEFT PGIDM2619XHVC
2-5 PGIDM2620XHYB AE C HOPPER GUIDE, RIGHT PGIDM2620XHVC
2-17 PGIDM2621XHSL AG C RELEASE LEVER PGIDM2621XHSF
3-901 DCEKP480CXH63 BH N E OPERATION PANEL UNIT DCEKP480CXH36
3-1 GCASP2173XHTD AV N D PANEL CASE GCASP2173XHZK
3-4 JBTN-2358XHSH AK C FUNCTION KEY JBTN-2358XHSD
1-24 LFRM-2225XHSL AK C SCANNER FRAME LFRM-2225XHVB
1-35 GCABB2393XHRB AZ D LOWER CABINET GCABB2393XHSQ
1-46 GCOVA2447XHYB AE D FRONT COVER GCOVA2447XHVB
1-57 PCOVP2131XHYB AE C PANEL CABLE COVER PCOVP2131XHVB
5-1 DUNTK497CXHTC AW N E HANDSET DUNTK497CXHAG
5-2 QCNWG377DXHBG AG C HANDSET CORD QCNWG209BXHAG
1-62 HPNLH2420XHRD AL N D DECORATION PANEL HPNLH2420XHSQ
5-6 QCNWG430CXHZZ AH C TELEPHONE LINE CORD QCNWG208BXHZZ
- TLABP460LXHZZ AD N D CONSUMER LABEL TLABP374JXHZA
5-11 TINST4395XHTD AP D OPERATION MANUAL TINST4395XHTZ
