SERVICE MANUAL
XL-S10H
No. S2406XLS10H//
MICRO COMPONENT SYSTEM
XL-S10H
MODEL
SHARP CORPORATION
CONTENTS
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
CHAPTER 1. GENERAL DESCRIPTION
[1] SAFETY PRECAUTION FOR SERVICE
MANUAL .......................................................1-1
[2] IMPORTANTSERVICENOTES(FORU.K.
ONLY)............................................................1-1
[3] SPECIFICATIONS.........................................1-2
[4] NAMES OF PARTS.......................................1-3
CHAPTER 2. ADJUSTMENTS
[1] ADJUSTMENT ..............................................2-1
[2] TEST MODE .................................................2-2
[3] When the CD does not function ....................2-3
CHAPTER 3. MECHANICAL DESCRIPTION
[1] DISASSEMBLY .............................................3-1
CHAPTER 4. DIAGRAMS
[1] BLOCK DIAGRAM.........................................4-1
CHAPTER 5. CIRCUIT DESCRIPTION
[1] VOLTAGE......................................................5-1
CHAPTER 6. CIRCUIT SCHEMATICS AND PARTS
LAYOUT
[1] NOTES ON SCHEMATIC DIAGRAM ............ 6-1
[2] IC701 SERIAL No. TABLE............................. 6-1
[3] TYPES OF TRANSISTOR AND LED ............ 6-1
[4] WIRING SIDE OF P.W.BOARD/SCHE-
MATIC DIAGRAM .......................................... 6-2
CHAPTER 7. OTHERS
[1] FUNCTION TABLE OF IC.............................. 7-1
[2] LCD DISPLAY................................................ 7-3
[3] WIRING OF PRIMARILY SUPPLY LEADS
(FOR U.K. ONLY) .......................................... 7-4
Parts Guide
XL-S10H Micro Component System consisting of XL-
S10H (main unit) and CP-S10H (speaker system).
•
In the interests of user-safety the set should be restored to its origi- nal condition and only parts identical to those specified be used.
•
Note for users in U.K. Recordingand playbackofany materialmayrequireconsentwhich
SHARP is unable to give. Please refer particularly to the provisions
of Copyright Act 1956, the Dramatic and Musical Performers Pro-
tection Act 1956, the Performers Protection Acts 1963 and 1972
and to any subsequent statutory enactments and orders.
(Except for U.K.)

XL-S10H
2 – 1
AudioXL-S10HService ManualXS10HMarketE
CHAPTER 2. ADJUSTMENTS
[1] ADJUSTMENT
1. MECHANISM SECTION
•Driving Force Check
•Torque Check
•Tape Speed
2. TUNER SECTION
fL: Low-range frequency
fH: High-range frequency
•AM IF/RF
Signal generator: 400 Hz, 30%, AM modulated
•Check FM VT
Signal generator: 1 kHz, 40 kHz dev., FM modulated
•FM Mute Level
Signal generator: 1 kHz, 40 kHz dev., FM modulated
•FM Detection
Signal generator: 10.7 MHz FM sweep generator
•FM RF
Signal generator: 1 kHz, 75 kHz dev., FM modulated
3. CD SECTION
•Adjustment
Since this CD system incorporates the following automatic adjust-
ment functions, readjustment is not needed when replacing the
pickup. Therefore, different PWBs and pickups can be combined
freely.
Each time a disc is changed, these adjustments are performed
automatically. Therefore, playback of each disc can be performed
under optimum conditions.
Torque Meter Specified Value
Play: TW-2111 Over 80 g
Torque Meter Specified Value
Play: TW-2111 30 to 80 g.cm
Fast forward: TW-2231 70 to 180 g.cm
Rewind: TW-2231 70 to 180 g.cm
Test Tape Adjusting
Point Specified Value Instrument Connection
MTT-111 Variable
Resistor in
motor.
3,000 ± 30 Hz Speaker Ter-
minal (Load
resistance: 6
ohms)
Figure 1
Test Stage Frequency Frequency
Display Setting/ Adjusting
Parts
Instrument
Connection
IF 450 kHz 1,602 kHz L305 *1
AM Band
Coverage — 522 kHz (fL): L306 1.1 ± 0.1 V *2
AM Tracking 990 kHz 990 kHz L302 *3
*1. Input: IC301 1Pin Output: IC301 23Pin
*2. Input: Input is not connected Output: TP-VT(IC301 28Pin)
*3. Input: Antenna Output:IC301 23Pin
Frequency Display Check
Point Instrument Connection
87.5 MHz 87.5 MHz 1.5V ± 1.0V TP-VT
108 MHz 108 MHz 5.0V ± 1.0V TP-VT
TAPE MECHANISM
VARIABLE RESISTOR
IN MOTOR
Frequency Display Adjusting
Parts Instrument Connection
98.00 MHz
(30 dBµV) 98.00 MHz Input: Antenna Output: Speaker Terminal
Test
Stage Frequency Frequency Display Setting/ Adjusting
Parts
Instrument
Connection
FM IF 10.7 MHz 98.00 MHz Input: Pin36of
IC301
Output: Pin 23
of IC301
Test
Stage Frequency Frequency Display Setting/ Adjusting
Parts
Instrument
Connection
FM Band
Coverage — 87.50 MHz (fL): L307 1.5 ± 0.1 V *1
FM RF 98.00 MHz
(10 ~ 20dB) 98.00 MHz L304 *1
*1. Input: Antenna Output: 23 Pin of IC301
Figure 2 ADJUSTMENT POINTS
CNP301
L306
IC301
L304
FM RF
L302
L307
L305
MAIN PWB-A1
AM IF
AM ANT.
FM OSC.
FM BAND
COVERAGE fL
AM BAND
COVERAGE fL
TP-VT=28Pin
AM
Tracking

XL-S10H
2 – 2
[2] TEST MODE
Test Mode Key Operation
All test modes can be terminated by turning off the power with POWER key.
•Preset clear test
All tuner preset stations are cleared.
•Preset set test
Stations are set according to destination.
•Display test
When test mode is activated, the entire display lights up. As the “PLAY” button is pressed, half of the display lights up alternately.
•CD test
In step 5, hold down the AUX button on the remote control. The tracking servo is switched on/off.
From step 3, the pick up can be moved with the FF/REW button.
•Soft reset test
All data in RAM is cleared.
•VOLUME test
Starting from level 23 (default), check all the levels (0 - 23 - MAX).
•TIMER test
Start the timer at 1:00. When it reaches 1:05, turn on the power with the AUX function and turn off the power after about 30 seconds.
(In the test mode, fade-in and fade-out are not required.)
•ALL KEY test
In the test mode, hold down all the buttons on the main unit and then press the “POWER” button. “OK” appears.
If only the “POWER” key is pressed, “ERROR” appears.
KEY1 KEY2 KEY3 TEST CONTENTS INDICATION
Memory Preset Down Power Preset clear Tu CL
Memory Stop Power Preset set FM P-01
Memory Play Power Display
Memory Preset up Power CD T-1
Memory Clear Power Soft reset CL
Bass/treble Preset down Power Volume T-3
Bass/treble Play Power Timer test T-4
Bass/treble Clear Power all key T-6
September 12 Days Indication Change
CH BAND FREQUENCY
1 FM STEREO FM 87.50 MHz
2 FM 108.00 MHz
3 FM 98.00 MHz
4 FM 90.00 MHz
5 FM 106.00 MHz
6 AM AM 522 kHz
7 AM 1620 kHz
8 AM 990 kHz
9 AM 603 kHz
10 AM AM 1404 kHz
11 ——————
·
·
35
36 FM MONO FM 106.00 MHz
37 FM 90.00 MHz
38 FM 98.00 MHz
39 FM 108.00 MHz
40 FM 87.50 MHz
CH BAND FREQUENCY
[cd step 1] Enter test mode. ←———————
↓Hold down the “memory” button
[cd step 2] After some steps, the laser turns on.
↓Hold down the “memory” button
[cd step 3] After some steps, focus search is performed.
↓Hold down the “memory” button
[cd step 4] After some steps, CLV rotation is performed.
↓Hold down the “memory” button
[cd step 5] CD playback starts.
↓Hold down the “stop” button to return to [cd step 1] ––––––––––

XL-S10H
2 – 3
[3] When the CD does not function
The CD section may not operate when the objective lens of the optical pickup is dirty. Clean the objective lens, and check the playback operation.
When this section does not operate even after the above step is taken, check the following items.
Turn the power off.
Gently clean the lens with a lens cleaning tissue and a small amount of isopropyl alcohol.
Do not touch the lens with the bare hand.
Parts code
1. CD optical pickup Lens cleaner disc UDSKA0004AFZZ
HOW TO USE
1. Using the brush in the cleaner cap, apply 1 or 2 drops of the cleaning fluid to the brush on the CD cleaner disc which has
the mark next to it.
2. Place the CD cleaner disc onto the CD disc tray with the brush side down, then press the play button.
3. You will hear music for about 20 seconds and the CD player will automatically stop. If it continues to turn, press the stop
button.
CAUTION
The CD lens cleaner should be effective for 30~50 operations, however if the brushes become worn out earller then please
replace the cleaner disc.
If the CD cleaner brushes become very wet then wipe off any excess fluid with a soft cloth.
Do not drink the cleaner fluid or allow it to come in contact with the eyes. In the event of this happening then drink and /
or rinse with clean water and seek medical advice.
The CD cleaner disc must not be used on car CD players or on computer CD ROM drives.
All rights reserved. Unauthorized duplicating, broadcasting and renting this product is prohibited by law.
Cleaner Liquid Cleaning Disc
PARTS CODE: UDSKA0004AFZZ

XL-S10H
3 – 1
AudioXL-S10HService ManualXS10HMarketE
CHAPTER 3. MECHANICAL DESCRIPTION
[1] DISASSEMBLY
Note 1:
After removing the connector for the optical pickup from the connector,
wrap the conductive aluminium foil around the front end of the connec-
tor so as to protect the optical pickup from electrostatic damage.
Caution on Disassembly
Follow the below-mentioned notes when disassembling the unit and
reassembling it, to keep it safe and ensure excellent performance:
1) Take cassette tape and compact disc out of the unit.
2) Be sure to remove the power supply plug from the wall outlet
before starting to disassemble the unit.
3) Take off nylon bands or wire holders where they need to be
removed when disassembling the unit. After servicing the unit,
be sure to rearrange the leads where they were before disas-
sembling.
4) Take sufficient care on static electricity of integrated circuits and
other circuits when servicing.
STEP REMOVAL PROCEDURE FIGURE
1 Top Cabinet 1. Screw...........................(A1) x 5
2. Socket.........................(A2) x 2
3. Flat Cable....................(A3) x 1
1
2 Side Panel 1. Screw...........................(B1) x 4 1
3 Rear Panel 1. Screw..........................(C1) x 2
2. Screw..........................(C2) x 2 1 2
4 Main PWB 1. Screw..........................(D1) x 2
2. Socket.........................(D2) x 2
3. Socket.........................(D3) x 1
2
5 Front Panel 1. Screw...........................(E1) x 2 3
6 Power PWB 1. Screw...........................(F1) x 2
2. Screw...........................(F2) x 1 3
7 Display PWB 1. Knob............................(G1) x 1
2. Screw..........................(G2) x 8 4
8 Tape Mechanism 1. Screw..........................(H1) x 1
2. Screw..........................(H2) x 4 4
9 Open/Close
Switch PWB 1. Screw...........................(J1) x 1 2. Hook............................(J2) x 2 5
10 CD Mechanism 1. Screw...........................(K1) x 4 5
Figure 1
Figure 2
Figure 3
(A3)x1
(A2)x2
Top Cabinet Open/Close
Switch PWB
CD Mechanism
Side Panel
(Right)
Rear Panel
(C1)x2
ø3x10mm
Side Panel
(Lift)
(A1)x1
ø3x10mm
(A1)x2
ø3x10mm
(A1)x1
ø3x10mm
(A1)x1
ø3x10mm
(B1)x2
ø3x10mm
(B1)x2
ø3x10mm
Top Cabinet
(D1)x2
ø3x10mm
(D2)x1
(C2)x2
ø3x10mm
Top Cabinet
(D2)x1
(D3)x1
Main PWB
Power PWB
(E1)x2
ø3x10mm
(F1)x2
ø3x10mm
(F2)x1
ø3x10mm
Power
PWB
PWB
AC cord
Front Panel

XL-S10H
3 – 2
Figure 4
Figure 5
Open
Cassette
Holder
(G2)x8
ø2.6x10mm
(H2)x4
ø3x10mm
(H1)x1
ø2.6x10mm
(G1)x1
Front Panel
Display PWB
PWB
Spring
Lever
Tape
Mechanism
(J1)x1
ø2.6x10mm
(J2)x2
(K1)x4
ø2.6x10mm
Open/Close
Switch PWB
Top Cabinet
CD Mechanism

XL-S10H
4 – 1
AudioXL-S10HService ManualXS10HMarketE
CHAPTER 4. DIAGRAMS
[1] BLOCK DIAGRAM
1
2
3
AM ANT.
BAND PASS
FILTER
FM IF
AM IF
75KHz
AM IF
FM IF
FM IF
+B
1
2
3
3
2
16
5
4
321
456
LA6548D
19202136 35 34
123 1817164 5 6 7 8 9 10 11 12 13 14 15
LV23002M
33 32 31
3
2
16
5
4
222324252627282930
VP
VTCC
FM:1.5V-5.0V
AM:1V-8V
1-SLD
G-SLD
0+SLD
0-SLD
TCAP
RESET REG-TR
0-SPD
0+SPD
G-SPD
REF-IN
1-SPD
G-TRK
REG-OUT
0+TRK
0-TRK
0-FCS
I-TRK
G-FCS
1-FCS
GND
GND
GND
0+FCS
GND
GND
GND
MUTE
VCCVCC
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16 15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
FMRF-IN
FMRF-OUT
VCC2
FM-OSC
AM-OSC
B02 B01
LP-OUT
LP-IN
PD
AGC
AMLOWOUT
DET-OUT
MPX-IN
VDD
XOUT
XIN
D0 CL DI R-OUT L-OUT FM-IET P-CCMP P-DET CE VSS P-DET FMRF-IN VCC1 AM-MIX GND1 FM-MIX REG AMRF-IN
AM LOOP
ANTENNA
M
ANTENNA
FOCUS/TRACKING/
SPIN/SLED DRIVER
AM OSC
FM RF
FM OSC
FM FRONT END
1
3
2
4
1
2
3
123457612 10 9 81113
LA4631++
POWER AMP.
+
–
–
+AMP_A1_ON
(R)
(L)
CD_A1_VCC
CD_A1_VCC
P-ON
TP-VM
MA-VCC
123
POWER
TRANSFORMER
T315mA L 250V
AC POWER
SUPPLY CORD
AC 230 V, 50 Hz
HEADPHOMES
SPEAKER
TERMINAL
L-CH
R-CH
TP-VT
CNP301
L302
D307
D306
L304
L307
D305 L306
D308
X301
D309
Q301
CF303
CF304
CF301
L305
Q371
CF302
IC301
IC802
D802
Q801
Q802
CF306
Q302
IC101
J101
J103
F653
CNP101
CNW101
CNS101
D104
D101
D103
D102
Q101
Q103
D106
Q102
Q502
PT1
PLL(TUNER)
FM IF DET./FM MPX./AM IF
CONSTANT
VOLTAGE
CONSTANT
VOLTAGE
CONS
T
VOLT
A
CONSTANT
VOLTAGE
AM BAND
COVERAGE fL
AM
Tracking
Figure 4-1 BLOCK DIAGRAM (1/3)

XL-S10H
4 – 2
CNS701
M
10
18
13
14
12
11
15
17
16
1
2
3
4
5
6
7
8
9
16.9344MHz
12320 19 18
21
22
32
38
39
40
414243585960
61
62
63
80
79
78
LA6548D
13141516 12 11 10 123456789
1234567
123456
LC78646E
4567891011121314151617
24
25
62
27
28
9
2
30
31
32
33
34
5
3
36
7
3
44456
44748490
551525354556
557
64
65
66
67
68
69
70
71
72
73
74
75
76
77
FE
RFMON
1-SLD
G-SLD
0+SLD
0-SLD
TCAP
RESET REG-TR
0-SPD
0+SPD
G-SPD
REF-IN
1-SPD
G-TRK
REG-OUT
0+TRK
0-TRK
0-FCS
I-TRK
G-FCS
1-FCS
GND
GND
GND
0+FCS
GND
GND
GND
MUTE
VCCVCC
VWRQ
VRES
DRF
CE
CL
DI
DO
CONT3
CONT2
PD01
PD02
VVSS
PCKIST
VVDD
VDD5
VSS
LDD
FR
LDS
DATA DATACK
REF1
TDO
ADAVSS
ADAVDD
JITTC
RFMON
TE
TEC
FE
RSVSS
RFVDD
RF
VREF
TIN2F
TIN1E FIN2B FIN1A
LCHO LVSS RVSS RCHO RVDD XVDD
EFMIN
SLCIST
SLCO
XOUT XIN FSX/16MIN XVSS C2F EFLG IGMOUT ASRACK ASDFIN LRSY
TEST
DOUT
VDD
VSS
MON15
MON14
MON13
ASDACK
MON12
DEFECT
SBCK/FG
CONT5
CONT4
GPDAC
SLDO
SPDO
MON11
FSEQ
V/1P
FDO
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16 15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
F B A E
+ + + + + - -
-
- -
FO+
TR+ TR- FO-
ACTUATOR
TR+
FO+
FO-
C
F
B A E
1/2V
+5V
TR-
1/2VCC
C
- +
D
VCC
VC
LD
VR
MD
D
GND
GND
LD
VR
MD(PD)
CD PICKUP UNIT
+
+
–
–
SP+ SP– SL+ SL– PU-IN
GND
PICKUP IN
SLED
MOTOR
SPINDLE
MOTOR
MM
514623
16151413121110987654321
CD SERVO
FOCUS/TRACKING/
SPIN/SLED DRIVER
FROM DISPLAY PWB
LVDD
TP8
1
2
3
1
TAPE
MOTOR
PLAY
2
3
4
1
2
3
4
1
2
3
3
2
1
P.B.
C
B
A
D
REC.
+B
+B
8
7
6
5
4
156
17
18
1190
224
32
22
2128
27
62
25
43 2 1
BD3881FV
RECORD/PLAYBACK AMP.
13 12 11 10 9 8 7 6 514
CD_A1_VCC
TP-VM
GND
SD
VCC
TRE2 TRE1
VCC2
VOL2 VOL1
SEL-OUT1 SEL-OUT2
PB2P
PB2N
PB1P
PB1N
REC10 REC1N REC2N REC20 C2 C1 B2 B1 A2 A1 OUT1 BB1 OUT2 BB2
R-CH
L-CH
RECORD/PLAYBACK
HEAD
ERASE HERD
TAPE MECHANISM ASS'Y
VP
D-GND
0-POWER
1-TP-STATE
0-EVRCLK
0-EVR-SD0
0-AMP-ON
0-TU-CE
0-TU-SDO
0-TU-SCK
1-TU-SDI
0-CD-CE
I-CD-WRQ
0-CD-CLK
O-CD-CMD
1-CD-DATA
0-CD-/RESET
I-CD-DRF
IC802
CNW802
CNS802
CNS801
CFW801
Q803
D801
X801
CNP503
IC801
D802
Q801
Q802
Q502
IC201 S501
CNA501
CNP501
CNA502
M501
SW501
CNP502
L501
Q503
LASER
DRIVER
CONSTANT
VOLTAGE
CONSTANT
VOLTAGE
CONSTANT
VOLTAGE
Figure 4-2 BLOCK DIAGRAM (2/3)

XL-S10H
4 – 3
CNP503
1
2
1
2
3
VOLUME
21
60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41
+B
+B
REMOTE
SENSOR
321
181716151413121110
987654321
242322212019181716151413121110987654321
1
CD LID
2
61
62
63
64
65
66
73
72
71
70
69
68
67
80
79
78
77
76
75
74
2019181716151413121110987654321
21
22
23
24
25
26
27
28
29
30
31
32
33
34
40
39
38
37
36
35
IXA007SJ
: IXA007SJ
IXA019SJ
IXA006SJ
OUT VCC GND
VP
D-GND
O-POWER
I-TP-STATE
O-EVR-SCK
O-EVR-SDO
O-AMP-ON
O-CD-CE
O-CD-CLK
O-CD-CMD
I-CD-DATA
I-CD-WRQ
O-CD-/RESET
1-CD-DRF
O-TU-CE
O-TU-SDO
O-TU-SCK
I-TU-SDI
VSS2
VDD2
S14
S13
S12
S11
S10
S9
S8
S7/PA7
S6/PA6
S5/PA5
S4/PA4
S3/PA3
S2/PA2
S1/PA1
S0/PA0
P73/INT3/TOIN
P72/INT2
P71/AN9
P70/AN8 P87/AN7 P86/AN6 P85/AN5 CF2 P84/AN4 P83/AN3 P82/AN2 P81/AN1 P80/AN0 VDD1 CF1 VSS1 XT2/AN11 XT1/AN10 RESET P17 P16 P15/SC1 P14/SI1
S19 S18 S17 S16 S15 S14 S13 S12 S11 S10 S9 S8 S7 S6 S5 S4 S3 S2 S1 S0 C3 C2 C1 C0
V1/PL4 V2/PL5 V3/PL6
S39 S38 S37 S36 S35 S34 S33 S32 S31 S30 S29 S28 S27 S26 S25 S24 S15
P13/S01
P12/SC0
P11/S10
P10/S00
P07
P06
P05
P04
P03
P02
P01
P00
PWM3
VDD3
VSS3
PWM2
COM3
COM2
COM1
COM0
TO MAIN PWB
SYSTEM
MICROCOMPUTER
FL DISPLAY
NOTE:
Serial No.table (See 6-1)
AT24C16
1
2
3
4
5
6
7
8
L702
CNS701
Q706
Q705
Q701
Q704Q702
L701
X702
32.768KHz
Q703
RX701
SW700
SW702~705
SW707~711
CNW702 CNS702
SW701
CNP702
IC701
IC701
LCD701
LED701~704
IC7A1
RESET
Figure 4-3 BLOCK DIAGRAM (3/3)

XL-S10H
5 – 1
AudioXL-S10HService ManualXS10HMarketE
CHAPTER 5. CIRCUIT DESCRIPTION
[1] VOLTAGE
1.6 V
1.0 V
1.6 V
1.67 V
3.2 V
0V
1.6 V
1.6 V
1.6 V
1.6 V
1.6 V
1.6 V
1.6 V
1.7 V
1.58 V
1.6 V
1.57 V
3.2 V
0V
1.6 V
1.6 V
1.6 V
1.6 V
1.6 V
1.6 V
1.5 V
0V
1.5 V
0V
0V
1.0 V
0V
0V
0V
1.5 V
1.5 V
0V
3.2 V
3.2 V
0V
3.5 V
1.7 V
0V
0V
1.75 V
3.8 V
3.1 V
1.4 V
1.6 V
1.5 V
0V
0V
1.25 V
1.25 V
1.52 V
1.52 V
1.58 V
1.58 V
1.0 V
0V
0.18 V
3.0 V
1.9 V
3.0 V
3.9 V
3.3 V
0V
3.2 V
0V
0V
0V
3.1 V
0.54 V
1.35 V
0V
1.0 V
3.26 V
2.5 V
0V
3.2 V
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
PIN
NO. VOLTAGE
IC801
4.45 V
0V
0V
0V
4.42 V
2.126 V
2.710 V
0V
2.305 V
2.637 V
5.19 V
5.26 V
1.324 V
0.115 V
3.205 V
2.021 V
5.56 V
5.19 V
5.13 V
0V
0V
4.97 V
5.11 V
0V
0V
0V
0V
0V
5.10 V
0V
0V
0V
0V
0V
0V
0V
0V
0V
0V
5.11 V
2.33 V
2.324 V
2.03 V
2.26 V
2.38 V
2.50 V
2.50 V
2.50 V
2.50 V
2.50 V
2.50 V
2.50 V
2.50 V
2.44 V
2.37 V
2.44 V
2.32 V
2.38 V
0V
0V
2.48 V
2.48 V
2.47 V
2.48 V
1.63 V
0V
1.0 V
2.13 V
5.0 V
0V
0V
0V
4.96 V
5.0 V
0.7 V
0V
1.12 V
3.4 V
0.7 V
0V
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
PIN
NO. VOLTAGE
IC701
2.25 V
2.28 V
2.59 V
0V
5.08 V
2.23 V
2.25 V
4.0 V
3.9 V
2.9 V
2.43 V
2.43 V
0V
0V
0V
0V
0V
0V
1.82 V
1.67 V
3.9 V
2.24 V
0.69 V
2.57 V
2.1 V
2.5 V
2.0V
3.1 V
2.7 V
2.1 V
4.9 V
5.1 V
4.9 V
5.1 V
0V
0.97 V
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
PIN
NO. VOLTAGE
IC301
8.8 V
1.5 V
0V
1.5 V
-1.3 V
11.5 V
17.7 V
0V
0V
0V
0V
8.4 V
0V
1
2
3
4
5
6
7
8
9
10
11
12
13
PIN
NO. VOLTAGE
IC101
17.5 V
8.6 V
17.3 V
E
C
B
PIN
NO. VOLTAGE
Q101
0.19 V
17.0 V
0.77 V
E
C
B
PIN
NO. VOLTAGE
Q102
10.7 V
17.3 V
10.8 V
E
C
B
PIN
NO. VOLTAGE
Q301
1.0 V
2.8 V
1.77 V
E
C
B
PIN
NO. VOLTAGE
Q302
0V
3.5 V
0.8 V
E
C
B
PIN
NO. VOLTAGE
Q371
7.1 V
7.6V
7.8 V
E
C
B
PIN
NO. VOLTAGE
Q502
0.17 V
0.17 V
0V
E
C
B
PIN
NO. VOLTAGE
Q503
5.84 V
14.10V
6.50 V
E
C
B
PIN
NO. VOLTAGE
Q702
0V
0V
0.64 V
E
C
B
PIN
NO. VOLTAGE
Q701
4.3 V
8.4 V
5.0 V
E
C
B
PIN
NO. VOLTAGE
Q703
0V
6.55 V
0.63 V
E
C
B
PIN
NO. VOLTAGE
Q704
0V
5.2 V
0V
E
C
B
PIN
NO. VOLTAGE
Q705
0V
4.9 V
0V
E
C
B
PIN
NO. VOLTAGE
Q706
3.3 V
7.17 V
4.18 V
E
C
B
PIN
NO. VOLTAGE
Q801
3.22 V
6.15 V
3.9 V
E
C
B
PIN
NO. VOLTAGE
Q802
2.77 V
1.83 V
2.0 V
E
C
B
PIN
NO. VOLTAGE
Q803
0V
0.8 V
0.6 V
E
C
B
PIN
NO. VOLTAGE
Q103
8.46 V
3.19 V
1.60 V
1.61 V
3.87 V
2.75 V
0V
0V
0V
3.72 V
3.70 V
1.60 V
1.60 V
3.22 V
7.39 V
3.21 V
3.83 V
1.60 V
1.60 V
3.91 V
3.80 V
0V
0V
0V
3.53 V
4.11 V
1.61 V
1.60 V
1.61 V
8.44 V
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
PIN
NO. VOLTAGE
IC802
3.66 V
3.68 V
3.65 V
3.65 V
3.65 V
3.65 V
3.65 V
3.65 V
3.65 V
3.65 V
3.65 V
7.55 V
3.65 V
0V
3.65 V
3.65 V
3.65 V
3.65 V
3.65 V
3.65 V
3.65 V
3.65 V
3.65 V
3.65 V
3.65 V
3.65 V
3.65 V
3.65 V
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
PIN
NO. VOLTAGE
IC201

XL-S10H
6 – 2
[4] WIRING SIDE OF P.W.BOARD/SCHEMATIC DIAGRAM
Figure 6-2 SCHEMATIC DIAGRAM (1/8)
A
B
C
D
E
F
G
H
123456
6-4,6-5 2~11 -
A
SVC201
SVC201
4.7/50
75kHz
100K
10P(CH)
0.1
47K
1K
390
10µH
47µH
1/50
1/50
0.01
1
2
3
1µH
1/50
AM ANT.
BAND PASS
FILTER
10
0.001
10P
0.1
33
100
330
2.2K
680
2SC5477++
1SS133
1SS133
0
0
234567
1
0
22/50
1/50
0.001
5P(CH)
0.1
0.001
100P
FM IF
FM IF
FM IF
AM IF
AM IF
33P
33P
(UJ)
(UJ)
(UJ)
5P
0.01
0.01
0.001
100K
2SC5477++
220
100K
2.2K
1K
4.7K
22/50
0.1
1K
0.01
0.1
330
0.022
22/50
4.7K
0.01
0.1
+B +B +B
+B
+B +B
+B +B
+B
+B +B
+B
+B
+B
+B
+B
+B
0.1
0.47/50
0
47
10K
22/50
10K
MTZJ3.6B
1K
1K
47K
1K
100K
MTZJ120B
10P(CH)
2SC3052F+
0.33/50
100P(CH)
100K
100K
20P
(CH)
0.01
1
2
3
100P
100P
3.3K
1/50
10µH 10
0.1
0.1
3
2
16
5
4
321
456
100K
SVC347S
19202136 35 34
123 1817164 5 6 7 8 9 10 11 12 13 14 15
LV23002M
33 32 31
560P
27P
(CH)
3
2
16
5
4
0.022
222324252627282930
VP
VTCC
FM:1.5V-5.0V
AM:1V-8V
TP-VT
FMRF-IN
FMRF-OUT
VCC2
FM-OSC
AM-OSC
B02 B01
LP-OUT
LP-IN
PD
AGC
AMLOWOUT
DET-OUT
MPX-IN
VDD
XOUT
XIN
D0 CL DI R-OUT L-OUT FM-IET P-CCMP P-DET CE VSS P-DET FMRF-IN VCC1 AM-MIX GND1 FM-MIX REG AMRF-IN
AM LOOP
ANTENNA
FM ANTENNA
TO MAIN PWB
AMP./TAPE SE
C
MAIN PWB-A1(1/2)
FM RF
FM OSC.
FM BAND COVERAGE fL
FM FRONT END
NOTES ON SCHEMATIC DIAGRAM can be found on page 6-1
CNP301
C301
D302
D303
JR304
L302
D307
D306
C309
C307
L304
JR302
C317
C316
C318
C314
L307
R328
R307 R305
C306
C308
R303
C305 R304
D305 C311
C310
C345
R310
L306
R311
C332
C329
C335
C321
R327
C344
R314
C343
C333
R316
C312
R308
R329
C320
R313
D308
C325
X301
R319
C341
C342
C351
R315
C326
C330
C338
R326
R324
R322
D309
Q301
L308
C340
R325
R318
R317
C328
C324
C327
C322
C331
C323
CF303
L305
C372
R371
R374
R375
R376
Q371
CF304
JR303
R372
C315 C313
R312
C319
R309
CF302
C334
C337
C336
R321
R320
C339
R323
L303 R302
C302
C303
L301
IC301
C801
R306
L801
CF301
CF306
Q302
PLL(TUNER)
FM IF DET./FM MPX./AM IF
AM BAND
COVERAGE fL
AM
Tracking

XL-S10H
6 – 3
Figure 6-3 SCHEMATIC DIAGRAM (2/8)
78 9 10 11 12
IC701: IXA007SJ 6-6 2 - D
IC701: IXA006SJ/IXA019SJ 6-8 2 - D
CNS701
6-4,6-5 2~11 - A
33K
33K 0
µH
100K
89 10 11 12 13 14 15 16 17
MTZJ3.9B
6.8K 6.8K
MTZJ5.1B
6.8K
6.8K
6.8K
10
18
13
14
12
11
15
17
16
1
2
3
4
5
6
7
8
9
6.8K
6.8K
6.8K
6.8K
0.1
100P
47K
15K
B
B
+B
+B +B
+B
+B +B +B
+B
+B +B
+B
+B
+B
+B
1/50
1/50
18
+B 18
18
0.1
100
100
0.1
0.1
15K
10K
1K
12
12
2SC3052F+
2SC5395F+
100
12K
10K
6.8K
1K
0.1
100/10
330
100
470
1K
0.1
12P(CH)
12P(CH)
16.9344MHz
10K
100P(CH)
100P(CH)
0.1
33/16
33K 100K 33K
0.1
100/6.3
100/6.3
100/6.3
0.1
470
10
2SA1235F+
12K
0.1
0.047
1/50
100K
0.047
0.1 100P
330
0.0022
10K
10/16
47P
0.0022
10/16
47
100/6.3
0.1
0.1
0.1
680
680
1.2K
27K
220
12320 19 18
21
22
32
38
39
40
414243585960
61
62
63
80
79
78
LA6548D
13141516 12 11 10 123456789
1234567
123456
LC78646E
4567891011121314151617
24
25
62
27
28
9
2
30
31
32
33
34
5
3
36
7
3
44456
44748490
551525354556
557
64
65
66
67
68
69
70
71
72
73
74
75
76
77
VP
D-GND
0-POWER
1-TP-STATE
0-EVRCLK
0-EVR-SD0
0-AMP-ON
0-TU-CE
0-TU-SDO
0-TU-SCK
1-TU-SDI
0-CD-CE
I-CD-WRQ
0-CD-CLK
O-CD-CMD
1-CD-DATA
0-CD-/RESET
I-CD-DRF
FE
RFMON
TP7
TP6
TP5
1-SLD
G-SLD
0+SLD
0-SLD
TCAP
RESET REG-TR
0-SPD
0+SPD
G-SPD
REF-IN
1-SPD
G-TRK
REG-OUT
0+TRK
0-TRK
0-FCS
I-TRK
G-FCS
1-FCS
GND
GND
GND
0+FCS
GND
GND
GND
MUTE
VCCVCC
VWRQ
VRES
DRF
CE
CL
DI
DO
CONT3
CONT2
PD01
PD02
VVSS
PCKIST
VVDD
VDD5
VSS
LDD
FR
LDS
DATA
DATACK
REF1
TDO
ADAVSS
ADAVDD
JITTC
RFMON
TE
TEC
FE
RSVSS
RFVDD
RF
VREF
TIN2F
TIN1E FIN2B FIN1A
LCHO
LVSS RVSS RCHO RVDD XVDD
EFMIN
SLCIST
SLCO
XOUT XIN FSX/16MIN XVSS C2F EFLG IGMOUT ASRACK ASDFIN LRSY
TEST
DOUT
VDD
VSS
MON15
MON14
MON13
ASDACK
MON12
DEFECT
SBCK/FG
CONT5
CONT4
GPDAC
SLDO
SPDO
MON11
FSEQ
V/1P
FDO
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16 15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
F B A E
+ + + + + - -
-
- -
FO+
TR+ TR- FO-
ACTUATOR
TR+
FO+
FO-
C
F
B A E
1/2V
+5V
TR-
1/2VCC
C
- +
D
VCC
VC
LD
VR
MD
D
GND
GND
LD
VR
MD(PD)
CD PICKUP UNIT
CD MECHANISM UNIT (227)
MECHANISM PWB
+
+
–
–
SP+ SP– SL+ SL– PU-IN
GND
PICKUP IN
SLED
MOTOR
SPINDLE
MOTOR
MM
514623 16151413121110987654321
CD SERVO
FOCUS/TRACKING/
SPIN/SLED DRIVER
FROM DISPLAY PWB
TO MAIN PWB (2/2)
AMP./TAPE SECTION
LVDD
TP8
IC802
C803
R812
C802
C801
CNW802
CNS802 CNS801
CFW801
R814
R816
R813
R815
R821
Q803
C814
C815
R826
R824
R822
R830 JR801 R832 R829 R827 R828
C820
R831
D801
C826
C825
C829
C824
C827
R833
C832
C831 C830
R836
C828
C817
C813
R834
C823
C816
C811
C819
C808
C807
R817
R818
C818
C821
R823
C810
C809
C812
R825
X801
R551
R559 R558
R552
R553
R555
R556
R557
R554
C833
C834
R841
CNP503
R546
R545
R544
C838
R842
C837
C836
C835
R839
R840
R838
IC801
C806
R809
R811
R810
R808
D802
C804
R806
R803
R801
R804
R802
Q801
Q802
8
01
R837
FM SIGNAL
AM SIGNAL
CD SIGNAL

XL-S10H
6 – 4
Figure 6-4 SCHEMATIC DIAGRAM (3/8)
A
B
C
D
E
F
G
H
123456
6-2,6-3 2~11 - H
3.3K
0.0022 6.8K
1/50
6.8K
1
3
2
4
1
2
3
0.0022
100
2SB1370E+ 2.2K
47/25
1K
1K
10
10
220/6.3
0.1
1K
8.2K
8.2K
1/50
4.7K
4.7K
NOT USED
0.1
1.5K
100/16
0.0022
33K
3.3K
3.3K
22/50
220
220
0.1
10
10
0.1
0.1 0.1
0.1
10
0.1
0.1
0.1
1000/16
1/50
22/50
4.7/50
330K
0.1
0.1
22K
0.047
1µH
0.1
0.1/50
6.8K
1/50
4.7K
680
220/16
0.01
2SC3052F+
1SS133
6800/25
0.1
0.1
1N4004A
1N4004A
1N4004A
2SC3052F+
0.0022
MTZJ6.8B
0.1
1N4004A
100
33K
1000/16
47/25 +B
+B
+B
+B
+B
+B
+B +B
+B
+B
+B
+B
+B
+B
+B
+B
+B
+B
+B
+B
+B +B
2SC5395F+
330K
22K
10P
123457612 10 9 81113
15
6
1
(CH)
1
3
14
LA4631++
POWER AMP.
+
–
–
+
10
AMP_A1_ON
(R)
(L)
CD_A1_P_A1_GND
CD_A1_VCC
EMC-GND
EMC-GND
TP-GND
D-GND
A-GND
SP-GND
P-ON
TP-VM
MA-VCC
GND
SD
OUT2
BB2
123
POWER
TRANSFORMER
T315mA L 250V
POWER PWB-A3
When Servicing,
Pay attention as the area enclosed
by this line ( ) is directly
connected with AC main voltage.
AC POWER
SUPPLY CORD
AC230V,50Hz
HEADPHOMES
SPEAKER
TERMINAL
L-CH
R-CH
234567
1
TO MAIN PWB (1/2)
TUNER/CD SECTION
MAIN PWB-A1(2/2)
S101
NOT USED
2
1
L
R
J102
J104
NOTES ON SCHEMATIC DIAGRAM can be found on page 6-1
C112
C130
R119
R120
R121
C111
R105
R108
C110
IC101
C116
C120
C115
C122
C123
C121
C125
R131
C133
C119
R117
R116
R112
C127
R113
C126
C117
C134 R132
L103
C105
R106
R103
C109
C104 C108
L102
C102 R104
C106
C107
C103
R107
J101
R102
R101
J103 L101
C101
F653
CNP101
CNW101
CNS101
D104
C113
C114
D101
D103
D102 Q101
R118
R110
R111
C129
C124
Q103
D106
C118
Q102
D105
C128
R109
R114
R502
C505
R549
R550
R503
R501
C502
C501
Q502
C506
R507
C504
C503
R505
R504
R508
C507
R509
C508
PT1
R115

XL-S10H
6 – 5
Figure 6-5 SCHEMATIC DIAGRAM (4/8)
78 9 10 11 12
M
6-2,6-3 2~11 - H
100
47/25
100K
100K
1
2
3
1
TAPE
MOTOR
PLAY
2
3
4
0.1
1
2
3
4
390
10K
2.2K
22K
1
2
3
5.6K
K
2.2K
33K
6.8K
33K
6.8K
1K
1K
390K
0.015
0.1/50
0.1/50
6.8K
0.1/50
6.8K
0.1/50
12K
0.22/50 68 100/35
0.015
390K
12K
0.22/50
68
100/35
0.0012
15K
0.0012
15K
220/16
1SS133
0.0056
0.01
0.0027
0.0027
18K
8.2
2SC3052F+
3
2
1
820P
P.B.
C
B
A
D
REC.
820P
0.01
0.01
47K
100
100
47K
47K
+B
+B
+B
+B
+B
+B
+B
0.0033
0.0033
10P
470P 470P 47K
3.3K
3.3K
3.3K 3.3K 47K 3.3K 3.3K 47K
6.8K 6.8K
8
7
6
5
4
156
17
18
1190
224
32
22
2128
27
62
25
43 2 1
BD3881FV
RECORD/PLAYBACK AMP.
47P 47P (CH)
(CH)
(CH)
13 12 11 10 9 8 7 6 514
GND
SD
VCC
TRE2 TRE1
VCC2
VOL2 VOL1
SEL-OUT1 SEL-OUT2
PB2P
PB2N
PB1P
PB1N
REC10 REC1N REC2N REC20 C2 C1 B2 B1 A2 A1 OUT1 BB1 OUT2 BB2
R-CH
L-CH
RECORD/PLAYBACK HEAD
ERASE HERD
TAPE MECHANISM ASS'Y(226-1)
89 10 11 12 13 14 15 16 17
TO MAIN PWB (1/2)
TUNER/CD SECTION
5
50
C506
C507
C513
C511
R506
C516
C515
C521
C524
C535
R561
R563
R562
R564
C510
R509
C509
R510
C508
R524 C520 C519 R522
R520
R518
R519 R516 R515 R514 R513 R511 R523 R521
R526
R525
R530
R528
C525
C526
C528
C527
R532
R543
IC201
R548
R547
R535
C532
R536
R541 C534
C531
R533
R534
R542
C533
R537
S501
C529
C530
R529
R527
R538
CNA501
CNP501
CNA502
M501
SW501
CNP502
C522
R539
R540
R531
D501
C517
L501
C518
C514
R560
C512 R512
R517
Q503
C523
FM SIGNAL
CD SIGNAL
PLAYBACK SIGNAL
RECORD SIGNAL

XL-S10H
6 – 6
Figure 6-6 SCHEMATIC DIAGRAM (5/8)
A
B
C
D
E
F
G
H
123456
6-3 12 - G
CNP503
12
12
3
VOLUME
2
1
0
3.9K
22K
1K
1K
330K
1K
0.01
4.7K
0.001
0.001
0.1
47K
22K
22K
10K
10K
150K
330K
0.001
0.01 100K
100K
2SC3052F+
3.3K
3.3K
10K
100K
+B
+B
+B +B
+B +B
+B +B +B
+B
+B
+B
+B
+B
10K
0.1
15P
22µH
330
22K
2SC3052F+
2SC3052F+
1SS133
MTZJ5.1B 1SS133
1.2K
1.2K
0.1
0.1
2SC3052F+
2SC5395F+
1K
1K
1K
3.3K
3.3K
3.3K
1K
3.3K
3.3K
3.3K
3.3K
3.3K
3.3K
3.3K
220/10 0.047
10P
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
3.3K
3.3K
1
CD LID
2
15P(CH)
(CH)
(CH)
VP
D-GND
O-POWER
I-TP-STATE
O-EVR-SCK
O-EVR-SDO
O-AMP-ON
O-CD-CE
O-CD-CLK
O-CD-CMD
I-CD-DATA
I-CD-WRQ
O-CD-/RESET
1-CD-DRF
O-TU-CE
O-TU-SDO
O-TU-SCK
I-TU-SDI
TO MAIN PWB
DISPLAY PWB-A2
SWITCH PWB-A5
ON/
STAND-
B
TUNIN
G
UP
32.768
K
NOTES ON SCHEMATIC DIAGRAM can be found on page 6-1
R714
R716
R711
R712
R713
R710
R701
R703
R705
R706
R709
R707
R708
R715
R702
R704
CNS701
R764
R721
C723
R717
R718
R723 R725
R771
Q705
Q701
R720
R719
C717
Q704
Q702
C718
D701
D703
D704
R733
Q706
R729
C720 R732
C702
C701
JR701
C708
L701
C706
X702
C709
R765
R731
C710
SW700
SW70
2
R728
R730
R734
R736
SW707
R726
R727
R760
C714
C715
C705 C703
R739
R740
R724
R763
CNW702
CNS702
SW701
CNP702

XL-S10H
6 – 7
Figure 6-7 SCHEMATIC DIAGRAM (6/8)
78 9 10 11 12
0.1
100K
100K
100K
100K 0
0.001
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
41
123456
47K
22K
470
100P
0.001
10
33/16
6.8K
3.9K 12K
120
3.9K
6.8K
12K
100K
47K
0.001
+B +B +B
+B
+B
+B
+B
+B
+B
+B
1K
150P
15P
22µH
1K
100P
100P
2SC5395F+
220
220
220
220
GP1U281X
REMOTE
SENSOR
3
2
1
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
MPG3372X MPG3372X
47
MPG3372X
MPG3372X
47
61
6263
64
65
66
73 72 71 70 69 68 67
80 79 78 77 76 75 74
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
100K
15P(CH)
(
CH)
(
CH) (CH)
10P(CH)
21 22 23 24 25 26 27 28 29 30 31 32 33 34 403938373635
IXA007SJ
AT24C16
PATCH CPU
EEP-VDDD
EEP-CLK
EEP-DATA
EEP-GND
OUT
VCC
GND
ENA DATA CLK RESET GND VDD
VSS2 VDD2 S14 S13 S12 S11 S10 S9 S8 S7/PA7 S6/PA6 S5/PA5 S4/PA4 S3/PA3 S2/PA2 S1/PA1 S0/PA0 P73/INT3/TOIN P72/INT2 P71/AN9
P70/AN8
P87/AN7
P86/AN6
P85/AN5
CF2
P84/AN4
P83/AN3
P82/AN2
P81/AN1
P80/AN0
VDD1
CF1
VSS1
XT2/AN11
XT1/AN10
RESET
P17
P16
P15/SC1
P14/SI1
S19
S18
S17
S16
S15
S14
S13
S12
S11
S10
S9
S8
S7
S6
S5
S4
S3
S2
S1
S0
C3
C2
C1
C0
V1/PL4
V2/PL5
V3/PL6
S39
S38
S37
S36
S35
S34
S33
S32
S31
S30
S29
S28
S27
S26
S25
S24
S15
P13/S01
P12/SC0
P11/S10 P10/S00
P07 P06 P05 P04 P03 P02 P01 P00
PWM3
VDD3
VSS3
PWM2
COM3 COM2 COM1 COM0
1
2
3
4
5
6
7
8
LED PWB-A4
SYSTEM
MICROCOMPUTER
CN799
NOT USED
LCD DISPLAY
ON/
STAND-BY
TUNING
UP
TUNING
DOWN
PRESET
UP
PRESET
DOWN
CLEAR
FUNCTION BASS/
TREBLE
MEMOLY/
SET
NOTE:
Serial No.table (See 6-1)
32.768KHz
R735
C716
C
708
L701
C
706
X702
R737
C709
C707
0
R799 JR702
R7A1
R7A2 IC7A1
R7A3
C7A1
R749
R750
R751
R752
R759
R753
Q703
RX701
C704
R755
R756
SW703 SW704
SW702
SW705
R743 R745 R747
R762
R744
R742 R746
SW711
SW709
SW707 SW710
SW708
R761
C715
C703
R740
IC701
LCD701
CFW701
LED703 LED704
R758
LED702
LED701
R757
C711
CFA701 CFA702
C724
R741
C722
C721

XL-S10H
6 – 8
Figure 6-8 SCHEMATIC DIAGRAM (7/8)
A
B
C
D
E
F
G
H
123456
6-3 12 - D
CNP503
12
12
3
VOLUME
2
1
0
3.9K
22K
1K
1K
330K
1K
0.01
4.7K
0.001
0.001
0.1
47K
22K
22K
10K
10K
150K
330K
0.001
0.01 100K
100K
2SC3052F+
3.3K
3.3K
10K
100K
+B
+B
+B +B
+B +B
+B +B +B
+B
+B
+B
+B
+B
10K
0.1
15P
22µH
330
22K
2SC3052F+
2SC3052F+
1SS133
MTZJ5.1B 1SS133
1.2K
1.2K
0.1
0.1
2SC3052F+
2SC5395F+
1K
1K
1K
3.3K
3.3K
3.3K
1K
3.3K
3.3K
3.3K
3.3K
3.3K
3.3K
3.3K
220/10 0.047
10P
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
3.3K
3.3K
1
CD LID
2
15P
32.768
K
(CH)
(CH)
(CH)
VP
D-GND
O-POWER
I-TP-STATE
O-EVR-SCK
O-EVR-SDO
O-AMP-ON
O-CD-CE
O-CD-CLK
O-CD-CMD
I-CD-DATA
I-CD-WRQ
O-CD-/RESET
1-CD-DRF
O-TU-CE
O-TU-SDO
O-TU-SCK
I-TU-SDI
TO MAIN PWB (1/2)
DISPLAY PWB-A2
SWITCH PWB-A5
ON/
STAND-
B
TUNIN
G
UP
NOTES ON SCHEMATIC DIAGRAM can be found on page 6-1
R714
R716
R711
R712
R713
R710
R701
R703
R705
R706
R709
R707
R708
R715
R702
R704
CNS701
R764
R721
C723
R717
R718
R723 R725
R771
Q705
Q701
R720
R719
C717
Q704
Q702
C718
D701
D703
D704
R733
Q706
R729
C720 R732
C702
C701
JR701
C708
L701
C706
X702
C709
R765
R731
C710
SW700
SW70
2
R728
R730
R734
R736
SW707
R726
R727
R760
C714
C715
C705 C703
R739
R740
R724
R763
CNW702
CNS702
SW701
CNP702

XL-S10H
6 – 9
Figure 6-9 SCHEMATIC DIAGRAM (8/8)
78 9 10 11 12
100K 0
0.001
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
41
123456
47K
22K
470
100P
0.001
10
33/16
6.8K
3.9K 12K
120
3.9K
6.8K
12K
100K
47K
0.001
+B +B +B
+B
+B
+B
+B
+B
+B
+B
1K
150P
1
5P
22µH
1K
100P
100P
2SC5395F+
220
220
220
220
GP1U281X
REMOTE
SENSOR
3
2
1
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
MPG3372X MPG3372X
47
MPG3372X
MPG3372X
47
61
6263
64
65
66
73 72 71 70 69 68 67
80 79 78 77 76 75 74
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
100K
15P
32.768KHz
(CH)
CH)
C
H) (CH)
10P(CH)
21 22 23 24 25 26 27 28 29 30 31 32 33 34 403938373635
IXA006SJ
IXA019SJ
OUT
VCC
GND
ENA DATA CLK RESET GND VDD
VSS2 VDD2 S14 S13 S12 S11 S10 S9 S8 S7/PA7 S6/PA6 S5/PA5 S4/PA4 S3/PA3 S2/PA2 S1/PA1 S0/PA0 P73/INT3/TOIN P72/INT2 P71/AN9
P70/AN8
P87/AN7
P86/AN6
P85/AN5
CF2
P84/AN4
P83/AN3
P82/AN2
P81/AN1
P80/AN0
VDD1
CF1
VSS1
XT2/AN11
XT1/AN10
RESET
P17
P16
P15/SC1
P14/SI1
S19
S18
S17
S16
S15
S14
S13
S12
S11
S10
S9
S8
S7
S6
S5
S4
S3
S2
S1
S0
C3
C2
C1
C0
V1/PL4
V2/PL5
V3/PL6
S39
S38
S37
S36
S35
S34
S33
S32
S31
S30
S29
S28
S27
S26
S25
S24
S15
P13/S01
P12/SC0
P11/S10 P10/S00
P07 P06 P05 P04 P03 P02 P01 P00
PWM3
VDD3
VSS3
PWM2
COM3 COM2 COM1 COM0
LED PWB-A4
SYSTEM
MICROCOMPUTER
NOTE:
Serial No.table (See 6-1)
CN799
NOT USED
LCD DISPLAY
ON/
STAND-BY
TUNING
UP
TUNING
DOWN
PRESET
UP
PRESET
DOWN
CLEAR
FUNCTION BASS/
TREBLE
MEMOLY/
SET
R735
C716
7
08
L701
C
706
X702
R737
C709
C707
0
R799 JR702
R749
R750
R751
R752
R759
R753
Q703
RX701
C704
R755
R756
SW703 SW704
SW702
SW705
R743 R745 R747
R762
R744
R742 R746
SW711
SW709
SW707 SW710
SW708
R761
C715
C703
R740
IC701
LCD701
CFW701
LED703 LED704
R758
LED702
LED701
R757
C711
C724
R741
C722
C721

XL-S10H
PARTS GUIDE
NOTE:
Parts marked with “ ” are important for maintaining the safety of the set.
Besuretoreplacepartswithspecifiedonesformaintainingthesafetyandperformanceoftheset.
“HOW TO ORDER REPLACEMENT PARTS”
To have your order filled promptly and correctly, please furnish the
following information.
1. MODEL NUMBER 2. REF. No.
3. PART NO. 4. DESCRIPTION
MARK: SPARE PARTS-DELIVERY SECTION
For U.S.A. only
Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor,
Please call Toll-Free;
1-800-BE-SHARP
Explanation of capacitors/resistors parts codes
Capacitors
VCC ....................... Ceramic type
VCK........................ Ceramic type
VCT........................ Semiconductor type
VC • • MF ............... Cylindrical type (without lead wire)
VC • • MN............... Cylindrical type (without lead wire)
VC • • TV................ Square type (without lead wire)
VC • • TQ ............... Square type (without lead wire)
VC • • CY ............... Square type (without lead wire)
VC • • CZ ............... Square type (without lead wire)
VC • • • • • • • • • J .. The 13th character represents capacity difference.
("J" ±5%, "K" ±10%, "M" ±20%, "N" ±30%,
"C" ±0.25 pF, "D" ±0.5 pF, "Z" +80-20%.)
If there are no indications for the electrolytic capacitors, error is ±20%.
Resistors
VRD ....................... Carbon-film type
VRS........................ Carbon-film type
VRN ....................... Metal-film type
VR • • MF ............... Cylindrical type (without lead wire)
VR • • MN............... Cylindrical type (without lead wire)
VR • • TV................ Square type (without lead wire)
VR • • TQ ............... Square type (without lead wire)
VR • • CY ............... Square type (without lead wire)
VR • • CZ ............... Square type (without lead wire)
VR • • • • • • • • • J .. The 13th character represents error.
("J" ±5%, "F" ±1%, "D" ±0.5%.)
If there are no indications for other parts, the resistors are ±5%
carbon-film type.
MICRO COMPONENT SYSTEM
XL-S10H
XL-S10HMicroComponentSystemconsistingofXL-S10H(main
unit) and CP-S10H (speaker system).
MODEL

PRICE
RANK
DESCRIPTION
NO. PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-S10H
– 1 –
INTEGRATED CIRCUITS
IC7A1 RH-IXA014SJ01 J Patch Cpu,AT24C16
IC101 VHILA4631++-1 J AM Power Amp.,LA4631++
IC201 VHIBD3881FV-1 J AP Record/Playback Amp.,
BD3881FV
IC301 VHILV23002M-1 J AS FM FRONT END/PLL (Tuner)/
FM IF Det./FM Mpx./AM IF,
LV23002M
IC701 RH-IXA006SJZZ J BG System Microcomputer,
IXA006SJ
IC701 RH-IXA007SJZZ J System Microcomputer,
IXA007SJ
IC701 RH-IXA019SJZZ J AW System Microcomputer,
IXA019SJ
IC801 VHILC78646E-1 J AY Servo/Signal,LC78646E
IC802 VHILA6548D/-1 J AN Focus/Tracking/Spin/Sled Driver,
LA6548D
TRANSISTORS
Q101 VS2SB1370E+-1 J AG Silicon,PNP,2SB1370 E+
Q102,103 VS2SC3052F+-1 J AD Silicon,NPN,2SC3052 F+
Q301 VS2SC3052F+-1 J AD Silicon,NPN,2SC3052 F+
Q302 VS2SC5477++-1 J AD Silicon,NPN,2SC5477++
Q371 VS2SC5477++-1 J AD Silicon,NPN,2SC5477++
Q502 VS2SC5395F+-1 J AD Silicon,NPN,2SC5395 F+
Q503 VS2SC3052F+-1 J AD Silicon,NPN,2SC3052 F+
Q701 VS2SC3052F+-1 J AD Silicon,NPN,2SC3052 F+
Q702,703 VS2SC5395F+-1 J AD Silicon,NPN,2SC5395 F+
Q704~706 VS2SC3052F+-1 J AD Silicon,NPN,2SC3052 F+
Q801 VS2SC3052F+-1 J AD Silicon,NPN,2SC3052 F+
Q802 VS2SC5395F+-1 J AD Silicon,NPN,2SC5395 F+
Q803 VS2SA1235F+-1 J AD Silicon,PNP,2SA1235 F+
DIODES
1D101~104 VHD1N4004A/-1 J AB Silicon,1N4004A
D105 VHD1SS133//-1 J AA Silicon,1SS133
D106 VHEMTZJ6R8B-1 J AC Zener,6.8V,MTZJ6.8B
D302,303 VHD1SS133//-1 J AA Silicon,1SS133
D305 VHCSVC347S/-1 J AG Variable Capacitance,SVC347S
D306,307 VHCSVC201//-1 J AE Variable Capacitance,SVC201
D308 VHEMTZJ3R6B-1 J AC Zener,3.6V,MTZJ3.6B
D309 VHEMTZJ120B-1 J AC Zener,12V,MTZJ120B
D501 VHD1SS133//-1 J AA Silicon,1SS133
D701 VHEMTZJ5R1B-1 J AC Zener,5.1V,MTZJ5.1B
D703,704 VHD1SS133//-1 J AA Silicon,1SS133
D801 VHEMTZJ5R1B-1 J AC Zener,5.1V,MTZJ5.1B
D802 VHEMTZJ3R9B-1 J AC Zener,3.9V,MTZJ3.9B
LED701~704 VHPMPG3372X-V J AD LED,Green,MPG3372X
FILTERS
CF301 RFILFA001SJZZ J AE FM IF
CF302 RFILF0003AWZZ J AK FM IF
CF303 RFILA0003SJZZ J AF AM IF
CF304 RFILFA001SJZZ J AE FM IF
CF306 RFILR0008AWZZ J AE Band Pass Filter
TRANSFORMERS
1PT1 RTRNPA003SJZZ J AX Power
COILS
L101 VP-DH1R0K0000 J AC 1 µH
L102,103 RCILZA001SJZZ J AC Line Filter
L301 VP-DH1R0K0000 J AC 1 µH
L302 RCILA0007SJZZ J AG AM Antenna
L303 VP-DH100K0000 J AB 10 µH,Choke
L304 RCILRA001SJZZ J AA FM RF
L305 RCILIA001SJZZ J AC AM Antenna
L306 RCILB0009SJZZ J AG AM OSC.
L307 RCILBA003SJZZ J AA AM OSC.
L308 VP-DH470K0000 J AB 47 µH,Choke
L501 RCILBA001SJZZ J AE BIAS OSC.
L701 VP-DH220K0000 J AB 22 µH,Choke
L801 VP-DH100K0000 J AB 10 µH,Choke
VIBRATORS
X301 RCRSPA001SJZZ J AE Crystal,75 kHz
X702 RCRSP0007SJZZ J AE Crystal,32.768 kHz
X801 RCRSP0011SJZZ J AE Crystal,16.9344 MHz
CAPACITORS
C7A1 VCKYCY1HF104Z J AB 0.1 µF,50V
C101 VCKYCY1EF473Z J AB 0.047 µF,25V
C102~110 VCKYCY1EF104Z J AA 0.1 µF,25V
C111,112 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
1C113,114 VCKYCY1EF104Z J AA 0.1 µF,25V
C115,116 RC-GZV108AF1C J AD 1000 µF,16V,Electrolytic
C117 RC-GZA226AF1H J AB 22 µF,50V,Electrolytic
C118 RC-GZW688AF1E J AH 6800 µF,25V,Electrolytic
C119 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C120 VCKYCY1EF104Z J AA 0.1 µF,25V
C121 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C122 RC-GZA226AF1H J AB 22 µF,50V,Electrolytic
C123 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C124 VCKYCY1HB103K J AA 0.01 µF,50V
C125 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C126,127 VCKYCY1HB222K J AA 0.0022 µF,50V
C128 VCKYCY1EF104Z J AA 0.1 µF,25V
C129 RC-GZA227AF1C J AB 220 µF,16V,Electrolytic
C130 VCKYCY1EF104Z J AA 0.1 µF,25V
C133,134 VCKYCY1HB222K J AA 0.0022 µF,50V
C301 VCKYCY1HB102K J AA 0.001 µF,50V
C302 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C303 VCKYCY1EF104Z J AA 0.1 µF,25V
C305 VCCCPA1HH200J J AA 20 pF (CH),50V
C306 VCKYCY1HB103K J AA 0.01 µF,50V
C307 VCCUPA1HJ100D J AA 10 pF (UJ),50V
C308 VCKYCY1EB103K J AA 0.01 µF,25V
C309 VCKYPA1HB102J J AA 0.001 µF,50V
C310 VCCCPA1HH270J J AA 27 pF (CH),50V
C311 VCCSPA1HL561J J AA 560 pF,50V
C312,313 VCKYCY1EF104Z J AA 0.1 µF,25V
C314 VCKYCY1HB103K J AA 0.01 µF,50V
C315 RC-GZA226AF1H J AB 22 µF,50V,Electrolytic
C316 VCCUPA1HJ330D J AA 33 pF (UJ),50V
C317 VCKYPA1HB102J J AA 0.001 µF,50V
C318 VCKYCY1HB103K J AA 0.01 µF,50V
C319 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C320 VCCCCY1HH101J J AA 100 pF (CH),50V
C321 RC-GZA334AF1H J AA 0.33 µF,50V,Electrolytic
C322 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C323 RC-GZA474AF1H J AA 0.47 µF,50V,Electrolytic
C324 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C325 RC-GZA226AF1H J AB 22 µF,50V,Electrolytic
C326 VCKYCY1EF104Z J AA 0.1 µF,25V
C327 VCKYCY1HB103K J AA 0.01 µF,50V
C328 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C329 VCKYCY1HB223K J AA 0.022 µF,50V
C330 RC-GZA226AF1H J AB 22 µF,50V,Electrolytic
C331 VCKYCY1HB103K J AA 0.01 µF,50V
C332 VCKYCY1HB102K J AA 0.001 µF,50V
C333 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C334 VCKYCY1HB101K J AB 100 pF,50V
C335 RC-GZA226AF1H J AB 22 µF,50V,Electrolytic
C336,337 VCKYCY1HB101K J AB 100 pF,50V
C338~340 VCKYCY1EF104Z J AA 0.1 µF,25V
C341,342 VCCCCY1HH100J J AA 10 pF (CH),50V
C343 VCCCCY1HH5R0C J AA 5 pF (CH),50V
C344 VCCUPA1HJ330D J AA 33 pF (UJ),50V
C345 VCKYPA1HB5R0J J AA 5 pF,50V
C351 VCKYCY1HB223K J AA 0.022 µF,50V
C372 VCKYCY1EF104Z J AA 0.1 µF,25V
C501 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C502 RC-GZA227AF0J J AB 220 µF,6.3V,Electrolytic
C503,504 VCKYCY1EB104K J AD 0.1 µF,25V
C505 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C506 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C507 VCCCCY1HH100J J AA 10 pF (CH),50V
C508~510 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C511 VCKYCY1HB332K J AA 0.0033 µF,50V
C512 VCKYCY1HB272K J AA 0.0027 µF,50V
C513 VCKYCY1HB332K J AA 0.0033 µF,50V
