Shuttle Spacewalker AB30 User manual

AB30/AB30R
Pentium 4 Processor
Based MAIN BOARD
User's Manual

Shuttle®SpacewalkerTM AB30/AB30R
Pentium 4 , 478-pin processor based AGPset Mainboard
Manual Version 1.0
Copyright
Copyright©2001 by Shuttle®Inc. All Rights Reserved.
No part of this publication may be reproduced, transcribed, stored in a retrieval system,
translated into any language, or transmitted in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, photocopying, manual, or otherwise, without
prior written permission from Shuttle®Inc.
Disclaimer
Shuttle®Inc. shall not be liable for any incidental or consequential damages resulting from the
performance or use of this product.
This company makes no representations or warranties regarding the contents of this manual.
Information in this manual has been carefully checked for reliability; however, no guarantee is
given as to the correctness of the contents. In the interest of continued product improvement,
this company reserves the right to revise the manual or include changes in the specifications
of the product described within it at any time without notice and without obligation to notify any
person of such revision or changes. The information contained in this manual is provided for
general use by the customers.
Trademarks
Spacewalker is a registered trademark of Shuttle Inc.
Intel, Pentium is a registered trademarks of Intel Corporation.
PS/2 is a registered trademark of IBM Corporation.
AWARD is a registered trademark of Award Software Inc.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
General Notice: Other brand and product names used herein are for identification
purposes only and may be trademarks of their respective owners.
M474

- 1 -
WHAT’S IN THE MANUAL .....................................................................5
Quick Reference................................................................................................5
About This Manual ............................................................................................5
1 INTRODUCTION .................................................................................6
1.1 TO DIFFERENT USERS ..............................................................................6
FIRST-TIMEDIYSYSTEMBUILDER ............................................................6
EXPERIENCEDDIY USER .........................................................................6
SYSTEMINTEGRATOR ...............................................................................6
1.2 ITEM CHECKLIST:.......................................................................................7
2 FEATURES..........................................................................................8
2.1 SPECIFICATIONS ........................................................................................8
3 HARDWARE INSTALLATION ...........................................................11
3.1 STEP BY STEP INSTALLATION................................................................ 11
Accessories of AB30/AB30R ................................................................ 11
STEP1 InstalltheCPU...........................................................................12
STEP 2 Set Jumpers..............................................................................14
STEP3 InstallSDRAMSystemMemory .................................................14
STEP4 InstallPeripherals in SystemCase.............................................15
STEP5 Mountthe Mainboardonthe ComputerChassis ........................16
STEP6 ConnectFrontPanel Switches/LEDs/Speaker/USB ..................17
STEP7 Connect IDE, IDERAID, and FloppyDisk Drives .......................19
STEP8Connect OtherInternalPeripherals ............................................20
STEP9 Connectthe PowerSupply ........................................................21
STEP10 InstallAdd-on Cardsin Expansion Slots ..................................21
STEP11Connect External Peripheralsto Back Panel...........................22
STEP 12 First Time System Boot Up......................................................24
TABLE OF CONTENTS

- 2 -
STEP13 InstallDrivers &Software Components....................................25
3.2 JUMPER SETTINGS ..................................................................................26
JUMPERS& CONNECTORSGUIDE ....................................................27
Jumpers
Clear CMOS Setting (JP1) ....................................................................30
Onboard RAIDEnable/Disable Setting (JP17)(AB30R only) .................31
FSB Speed Contiguration Setting (JP2).................................................32
Back-Panel Connectors
PS/2 Keyboard & PS/2 Mouse Connectors ............................................33
USB1/USB2Port Connectors.................................................................33
COM1/2Port Connectors .......................................................................33
ParallelPort Connector...........................................................................33
Line-Out(Front-Out)PortConnector .......................................................34
Line-In(Rear-Out)PortConnector...........................................................34
Mic-In PortConnector .............................................................................34
MIDI/GAMEPortConnector....................................................................34
Front-Panel Connectors
ATXPower On/OffSwitchConnector (PWON)........................................35
SystemManagement InterfaceConnector (EPMI) ...................................35
GreenLED Connector (GLED)...............................................................36
HDD LED Connector (HLED).................................................................36
Power LED Connector (PLED)...............................................................36
HardwareResetConnector(RST) ..........................................................37
KeylockConnector (KEYLOCK) .............................................................37
Speaker Connector (SPEAKER)............................................................37
ExtendedUSB Header (JP4)..................................................................38

- 3 -
Internal Peripherals Connectors
EnhancedIDE, IDERAID,and FloppyConnector ...................................39
Other Connectors
ATXPower Supply Connector(CN7, JP12,and JP13) ...........................40
CoolingFan Connectors forCPU (FAN1),AGP (FAN2),chipset (FAN3),
System (FAN4) .......................................................................................41
IRHeader (JP16) ...................................................................................41
AudioCD-IN Connector(CN5) (Black)....................................................42
Audio Auxiliary-INConnector (CN4)(White) ............................................42
AudioBass/Center-Out Header(JP18)...................................................42
Wake-on LanConnector (JP3)................................................................43
Smart Card Header (JP15) ....................................................................43
3.3 SYSTEM MEMORY CONFIGURATION ......................................................44
1.INSTALL MEMORY.............................................................................44
2.UPGRADE MEMORY.........................................................................44
4 SOFTWARE UTILITY .......................................................................45
4.1 Mainboard CD Overview ..........................................................................45
4.2 Install Mainboard Software ......................................................................46
4.2.A InstallChipset SystemDriver ............................................................47
4.2.B InstallIDEDriver ...............................................................................48
4.2.C InstallAudio Driver............................................................................49
4.2.D InstallIDERAIDDriver(AB30R only) ................................................50
4.3 View the User's Manual............................................................................51

- 4 -
5 BIOS SETUP.....................................................................................52
5.1 ENTER BIOS ..............................................................................................52
5.2 THE MAIN MENU .......................................................................................53
STANDARD CMOS FEATURES ................................................................55
ADVANCED BIOS FEATURES..................................................................59
ADVANCED CHIPSET FEATURES...........................................................63
INTEGRATEDPERIPHERALS...................................................................66
POWERMANAGEMENT SETUP ..............................................................70
PNP/PCICONFIGURATION .......................................................................74
PC HEALTH STATUS.................................................................................76
FREQUENCY/VOLTAGECONTROL..........................................................78
LOAD FAIL-SAFE DEFAULTS...................................................................79
LOADOPTIMIZED DEFAULTS ..................................................................79
SET SUPERVISOR PASSWORD ..............................................................80
SET USER PASSWORD ...........................................................................80
SAVE & EXIT SETUP.................................................................................82
EXITWITHOUTSAVING.............................................................................82

- 5 -
Quick Reference
Hardware Installation >> Step-by-Step ................................................ Page 11
Jumper Settings >> A Closer Look ...................................................... Page 26
Drivers/Software Utilities >> How to Install ......................................... Page 45
BIOS Setup >> How to Configure ........................................................ Page 52
About This Manual
For First-Time DIY System Builder......................................................... Page 6
For Experienced DIY User ...................................................................... Page 6
For System Integrator ............................................................................. Page 6
WHAT’S IN THE MANUAL

- 6 -
1.1 To Different Users
First-Time DIY System Builder
Welcome to the DIY world! Building your own computer system is not as
difficult as you may think. To make your first computer DIY experience
successful, right from the start, we ha e designed the 3.1 Hardware Installation
section in a step-by-step fashion for all the first-time DIY system builders. Prior
to installation, we also suggest you to read the whole manual carefully to gain a
complete understanding of your new Shuttle AB30/AB30R mainboard.
Experienced DIY User
Congratulate on your purchase of the Shuttle AB30/AB30R mainboard. You
will find that installing your new Shuttle AB30/AB30R mainboard is just easy.
Bundled with an array of onboard functions, the highly-integrated AB30/AB30R
mainboard pro ides you with a total solution to build the most stable and reli-
able system. Refer to sections 3.2 Jumper Settings and Chapter 4 Drivers/
Software tilities to find out how to get the best out of your new mainboard.
Chapter 5 BIOS Setup also contains the rele ant information on how to tune
up your system to achie e higher performance.
System Integrator
You ha e wisely chosen Shuttle AB30/AB30R to construct your system.
Shuttle AB30/AB30R incorporates all the state-of-the-art technology of the
Brookdale chipset from Intel. It integrates the most ad anced functions you
can find to date in a compact ATX board.
1INTRODUCTION
This manual adopted in AB30 and AB30R mainboards at the same time.
The difference between AB30 and AB30R is that AB30R equips with
onboard IDE RAID Controller. In the manual, if there are some standards,
characters, equipment or software only appeared or adopted by AB30R; it
will be mentioned (AB30R only)

- 7 -
1.2 Item Checklist:
Check all items with you AB30/AB30R mainboard to make sure nothing is
missing. The complete package should include:
One piece of Shuttle AB30/AB30R Mainboard
One piece of Audio Cable (Central/Bass Channel)
One piece of ATA 100/66/33 Ribbon Cable
One piece of Floppy Ribbon Cable
One piece of twin ports USB Cable (optional)
AB30/AB30R Users Manual
One piece of Bundled CD-ROM with containing:
Ø AB30/AB30R users manual sa ed in PDF format
Ø IDE RAID users manual sa ed in PDF format (AB30R only)
Ø Intel Chipset System Dri er
Ø Onboard Audio controller dri er
Ø IDE dri er
Ø IDE RAID dri er (AB30R only)
Ø Award Flashing Utility
