Shuttle Spacewalker AK32 User manual

AK32
SocketA
AMD Athlon/Duron Processor
Based DDR/SDR Main Board
User's Manual

Shuttle®SpacewalkerTM AK32
SocketA
AMD Athlon/Duron Processor
based DDR/SDR Mainboard
Manual Version 1.0
Copyright
Copyright©2001 by Shuttle®Inc. All Rights Reserved.
No part of this publication may be reproduced, transcribed, stored in a retrieval system,
translated into any language, or transmitted in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, photocopying, manual, or otherwise, without
prior written permission from Shuttle®Inc.
Disclaimer
Shuttle®Inc. shall not be liable for any incidental or consequential damages resulting from the
performance or use of this product.
This company makes no representations or warranties regarding the contents of this manual.
Information in this manual has been carefully checked for reliability; however, no guarantee is
given as to the correctness of the contents. In the interest of continued product improvement,
this company reserves the right to revise the manual or include changes in the specifications
of the product described within it at any time without notice and without obligation to notify any
person of such revision or changes. The information contained in this manual is provided for
general use by the customers.
Trademarks
Spacewalker is a registered trademark of Shuttle Inc.
VIA is a registered trademark of VIA Corporation.
Intel, Pentium is a registered trademarks of Intel Corporation.
PS/2 is a registered trademark of IBM Corporation.
AWARD is a registered trademark of Award Software Inc.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
General Notice: Other brand and product names used herein are for identification
purposes only and may be trademarks of their respective owners.
M419

- 1 -
WHAT’S IN THE MANUAL .....................................................................5
Quick Reference................................................................................................5
About This Manual ............................................................................................5
1 INTRODUCTION .................................................................................6
1.1 TO DIFFERENT USERS ..............................................................................6
First-TimeDIYSystemBuilder ..................................................................6
ExperiencedDIYUser ..............................................................................6
SystemIntegrator .....................................................................................6
1.2 ITEM CHECKLIST........................................................................................7
2 FEATURES..........................................................................................8
2.1 SPECIFICATIONS ........................................................................................8
3 HARDWARE INSTALLATION ...........................................................12
3.1 STEP-BY-STEP INSTALLATION ...............................................................12
STEP1InstalltheCPU...........................................................................13
STEP 2 Set Jumpers..............................................................................14
STEP3InstallSDRAMSystemMemory.................................................14
STEP4InstallInternalPeripherals in System Case.................................15
STEP5MounttheMainboardontheComputerChassis ........................16
STEP6ConnectFront-panelSwitches/LEDs/Speaker/USB ..................17
STEP 7 Connect IDE & Floppy Disk Drives............................................19
STEP8ConnectOther Internal Peripherals ............................................20
STEP9ConnectPowerSupply..............................................................20
STEP10InstallAdd-onCardsinExpansionSlots ..................................21
STEP11ConnectExternalPeripheralstoBack-panel............................22
STEP 12 First Time System Boot Up......................................................24
STEP13InstallDriver&SoftwareComponents......................................25
TABLE OF CONTENTS

- 2 -
3.2 JUMPER SETTINGS ..................................................................................26
JUMPER&CONNECTORGUIDE .........................................................27
Jumpers
Clear CMOS (JP16)...............................................................................30
BIOSWriteProtection(JP3)...................................................................31
Back-Panel Connectors
PS/2 Keyboard & PS/2 Mouse Connectors ............................................32
USB1/USB2PortConnectors.................................................................32
LANConnector.......................................................................................32
COM1/2Connector ................................................................................32
ParallelPortConnector...........................................................................33
Line-Out .................................................................................................33
Line-In ....................................................................................................33
Mic-In .....................................................................................................33
MIDI/GAMEPort.....................................................................................33
Front-Panel Connectors
ATXPowerOn/OffSwitchConnector(PWRPT) .....................................34
EPMIConnector(EPMI) .........................................................................34
GreenLEDConnector(GLED)...............................................................35
HDD LED Connector (HLED).................................................................35
PWR LED Connector (PLED) ................................................................35
HardwareResetConnector(RST) ..........................................................36
Speaker Connector (SPEAK).................................................................36
ExtendedfourUSBConnectorHeader(JP1/JP5)...................................37
Internal Peripherals Connectors
EnhancedIDEPortsandFloppyConnectors ..........................................38

- 3 -
Other Connectors
ATXPowerSupplyConnector(JP6).......................................................39
CoolingFAN Connectors for CPU FANs (FAN1), AGP (FAN2),SYSTEM
(FAN3), or North Bridge Fan (FAN4).......................................................40
SIR/CIRConnector(JP2)........................................................................41
Wake-On-LANConnector (CN1).............................................................41
AudioConnectorCD_In(CN2)(Black) ...................................................42
AudioConnectorAUX_In(CN3)(White) .................................................42
AudioConnectorTAD_In(CN4)(Green).................................................42
3.3 SYSTEM MEMORY CONFIGURATION ......................................................43
InstallMemory.........................................................................................43
UpgradeMemory ...................................................................................43
4 SOFTWARE UTILITY .......................................................................44
4.1 Mainboard CD Overview ..........................................................................44
4.2 Install VIA 4 in 1 Driver .............................................................................45
4.3 Install Audio Device Software..................................................................46
4.4 Install LAN Software.................................................................................47
InstallWIN98LANdrivers .......................................................................47
InstallWIN2000LANdrivers ...................................................................50
InstallWINNTLAN drivers .......................................................................54
4.5 View the User's Manual............................................................................56

- 4 -
5 BIOS SETUP.....................................................................................57
5.1 ENTER THE BIOS......................................................................................57
5.2 THE MAIN MENU .......................................................................................58
STANDARD CMOS FEATURES ................................................................60
ADVANCED BIOS FEATURES..................................................................64
ADVANCED CHIPSET FEATURES...........................................................68
INTEGRATEDPERIPHERALS...................................................................72
POWERMANAGEMENTSETUP ..............................................................76
PNP/PCICONFIGURATION .......................................................................80
PC HEALTH STATUS.................................................................................82
FREQUENCY/VOLTAGECONTROL..........................................................84
LOAD FAIL-SAFE DEFAULTS...................................................................85
LOADOPTIMIZEDDEFAULTS ..................................................................85
SET SUPERVISOR PASSWORD ..............................................................86
SET USER PASSWORD ...........................................................................86
SAVE & EXIT SETUP.................................................................................87
EXITWITHOUTSAVING.............................................................................87

- 5 -
Quick Reference
Hardware Installation >> Step-by-Step ................................................ Page 12
Jumper Settings >> A Closer Look ...................................................... Page 26
Software Utility >> How to Install ......................................................... Page 44
BIOS Setup >> How to Configure ........................................................ Page 57
About This Manual
For First-Time DIY System Builder......................................................... Page 6
For Experienced DIY User ...................................................................... Page 6
For System Integrator ............................................................................. Page 6
WHAT’S IN THE MANUAL

- 6 -
1INTRODUCTION
1.1 To Different Users
First-Time DIY System Builder
Welcome to the DIY world! Building your own computer system is not as
difficult as you may think. To make your first computer DIY experience
successful, right from the start, we have designed the Chapter 3 Hardware
Installation section in a step-by-step fashion for all the first-time DIY system
builders. Prior to installation, we also suggest you to read the whole manual
carefully to gain a complete understanding of your new Shuttle AK32
mainboard.
Experienced DIY User
Congratulate on your purchase of the Shuttle AK32 mainboard. You will find
thatinstallingyournewShuttleAK32mainboardisjusteasy. Bundledwithan
array of onboard functions, the highly-integrated AK32 mainboard provides
you with a total solution to build the most stable and reliable system. Refer to
sections3.2 Jumper Settings and Chapter 4 Software Utility to find outhowto
get the best out of your new mainboard. Chapter 5 BIOS Setup also contains
therelevantinformationonhowtotuneupyoursystemto achieve higher per-
formance.
System Integrator
YouhavewiselychosenShuttleAK32toconstructyoursystem. ShuttleAK32
incorporates all the state-of-the-art technology of the KT266 chipset from VIA.
It integrates the most advanced functions you can find to date in a compact
ATX board. Refer to sections 3.2 Jumper Settings and Chapter 4 Software
Utility foranin-depthviewofsystemconstruction.

- 7 -
1.2 Item Checklist
Check all items with your AK32 mainboard to make sure nothing is missing.
The complete package should include:
!One piece of Shuttle AK32 Mainboard
!One piece of ATA100/66/33 Ribbon Cable
!One piece of Floppy Ribbon Cable
!One piece of twin ports USB Cable(optional)
!AK32 User’s Manual
!One piece of Bundled CD-ROM with containing:
"AK32 user’s manual on PDF format
"VIA4-IN-1driver
"VIA Audio driver
"VIALANdriver(optional)
"AwardFlashingUtility
KB1
USB1 L AN1
CON1
AGP_FAN
SYSTEM_FAN
AUDIO1
IDE2
CPU_FAN
NB_ FAN
IDE1
FDD
WOL
PCI1 PCI2 PCI3 PCI4 PCI5 PCI6
IR
USB3 USB2
Panasonic
CR 2032
3V
JAPAN1
CN2 CN3
CN4
TAD/IO
CD-IN
AUX
AGP1
CNR1 JP71RST
PLED + - SPEAK
1
1
1
10 10 1
1
11
1
1
1
1
1
JP16
JP2
JP5 JP4
JP3
FAN3
FAN2
FAN1 FAN4
FDD1
IDE 2
IDE 1
GLED + -+ - EPMI P WRPT
1 1 1
A
W
AR
D
P
C
I
/
PNP
686
169332966
1998C
C
N1
1
in
bo
n
d
L
80
22
5/
B
T0030 W
JC
2
9080
KOREA
DIMM1DIM1
JP6 DIMM2DIM2
SO C KE T 462

- 8 -
AK32 mainboard is carefully designed for the demanding PC user who wants high perfor-
mance and maximum intelligent features in a compact package.
2.1 Specifications
!!
!!
!CPU Support
Support Socket462 package CPU with 200/266 MHz FSB.
AMD Athlon Processor: 600 ~ 1.33+GHz.
AMD Duron Processor 600 ~ 850+ MHz.
!!
!!
!Chipset
Features VIA KT266, VT8366/VT8233 Chipset.
VT8366, Integrated high performance SDRAM and DDR DRAM controller.
!!
!!
!Jumperless CPU Configuration
Soft-configurationFSB(TheFSB speed is software configurable from 100MHz
to 166MHz by 1MHz step in the Frequency/Voltage Control of BIOS setup
program.)
!!
!!
!10/100 Mb Fast Ethernet (optional)
VT8233 integrated fast Ethernet controller. Support 10/100 Mb full and half
duplexoperation.
!!
!!
!AC'97 Link for Audio and Telephony CODEC
AC'97 2.1 compliant
Spread independent PCI functions for Audio and Modem
!!
!!
!Versatile Memory Support
Two 184-pin DIMM slots to support up to 2GB of PC1600 or PC2100
compliantDDR SDRAMmodule.
or two 168-pin DIMM slots to support up to 2GB of PC100 or PC133
compliantSDR SDRAMmodule.
!!
!!
!PCI Expansion Slots
Providessix32-bitPCIslots.
!!
!!
!AGP Expansion Slot
Provides one 32-bit AGP slot which supports up to 4X AGP device.
2FEATURES

- 9 -
!!
!!
!CNR Expansion Slot
ProvidesoneCNR(Communication/NetworkRiser)slot.
The CNR Slot supports the audio, modem, Lan, Home PNA of VIA VT8233
chipset.
Note: The CNR Card is optional at the time of purchase.
!!
!!
!I/O Interface
ProvidesavarietyofI/Ointerfaces:
"1 × Floppy interface for 3.5-inch FDD with 720KB, 1.44MB, or 2.88MB
formatorfor5.25-inch FDD with 360K or 1.2MB format.
"1 × PS/2 mouse connector.
"1 × PS/2 Keyboard connector.
"1 × RJ45 LAN connector.
"2 × DB9 Serial connectors 16550 UART compatible.
"1 × Infrared communication port .
(Serial port COM2 can also be redirected to an external IrDA Adapter
forwirelessconnection.)
"1 × DB25 Parallel port supporting Standard Parallel Port (SPP),
Enhanced Parallel Port (EPP), and Extended Capabilities Port (ECP)
datatransmissionschemes.
"1×Line-Outport.
"1×Line-Inport.
"1×Mic-Inport.
"1×MIDI/GAMEport.
!!
!!
!6 USB Supported Onboard
"2 × USB connectors on back-panel and two 10-pin header for optional
USB cable to extend another 4 USB ports .
!!
!!
!PCI Bus Master IDE Controller Onboard
TwoUltraDMA 100/66/33 BusMasterDual-channelIDE portsprovidesupport
to a maximum of four IDE devices (one Master and one Slave per channel).
The IDE Bus implements the data transfer speed up to 100/66/33MB/sec and
also supports Enhanced PIO Modes 0~4.
80-pin Cable Backward Compatible Legacy ATAPI Devices, ATAPI IDE CD-
ROM, CD-R, CD-RW, and LS-120 Supports.

- 10 -
!!
!!
!ATX Power Supply Connector
ATX power supply unit can be connect to the onboard 20-pin ATX power
connector,supportingSuspend and Soft-On/Off by dual-function power
button.
!!
!!
!Advanced Configuration and Power Interface
Features four power saving modes: Snoop, Suspend to RAM, Suspend to
Disk,andSoft-Off.ACPIprovidesmoreefficientEnergySavingsFeatures
controlled by your operating system that supports OS Direct Power Manage-
ment(OSPM)functionality.
!!
!!
!System BIOS
Provides licensed Award BIOS V6.0 PG on 2Mb Flash EEPROM and
supportsGreenPC,DesktopManagementInterface(DMI).
!!
!!
!ATX Form Factor
System board conforms to the ATX specification.
Board dimension: 305mm × 245mm.
!!
!!
!Advanced Features
"Dual Function Power Button - The system can be in one of two states;
one is Suspend mode and the other is Soft-Off mode. Pushing the power
button for less than 4 seconds places the system into Suspend mode.
When the power button is pressed for longer than 4 seconds, the system
enterstheSoft-Offmode.
"Wake-on-LAN (WOL) - The onboard WOL connector can be attached to
a network card that supports this function to wake up the system via LAN.
"Modem Ring Power-On - The system can be powered on automatically
by the activation of modem ring.
"CPU Clock Setting-Thisitemallows userstoadjustCPUHostClockinBIOS.
"CPU Ratio Setting- ThisitemallowsuserstoadjustCPURatioinBIOS.
"CPU Vcore Setting- This item allows users to adjust CPU Vcore in BIOS.
!!
!!
!Intelligent Features
"Voltage Monitoring - Monitorsvarious voltages of key elements, such as
theCPU, and other critical systemvoltage levels to ensure stable current
passingthroughmainboard components. Systemvoltagesinclude+3.3VIN,
+5V, +12V, -12V, -5V on system etc.

- 11 -
"Fan Status Monitoring - To prevent CPU from overheating, the CPU fan is
monitored for RPM and failure. (CPU Cooling FAN with RPM sensor is
required.)
"Temperature Monitoring-Thisitemallowsuserstomakesurewhether
the CPU or system runs in a suitable temperature.

- 12 -
3HARDWAREINSTALLATION
Before removing or installing any of these devices including CPU, DIMMs, Add-On
Cards, Cables, please make sure to unplug the onboard power connector.
This section outlines how to install and configure your AK32 mainboard. Refer to the
followingmainboardlayouttohelpyouidentifyvariousjumpers, connectors, slots, and
ports. Then follow these steps to guide you through a quick and correct installation of
yoursystem.
3.1 Step-by-Step Installation
Accessories Of AK32
KB1
USB1 LAN1
CON1
AGP_FAN
SYSTEM_FAN
AUDIO1
IDE2
CPU_FAN
NB_FAN
IDE1
FDD
WOL
PC I1
PC I2
PC I3
PC I4
PC I5
PC I6
IR
USB3 USB2
Panasonic
CR2032
3V
JAPAN1
CN2
CN3
CN4
TAD/I O
CD-IN
AUX
AG P1
C NR1
JP7
1RST
P LED
+ - SPE AK
1
1
1
10 10
1
1
11
1
1
1
1
1
JP16
JP2
JP5
JP4
JP3
FAN3
FAN2
FAN1
FAN4
FDD 1
IDE 2 IDE 1
GLED
+ -+ - EPMI PWR PT
1
1
1
AWARD
PCI/PNP686
169332 966
1998
C
CN1
1
in
bo
n
d
L8022 5/B
T 00 30
WJC29080
KOREA
DIMM1DIM1
JP6 DIMM2DIM2
SOCKET462
PS/2 Keyboard/Mouse
Connectors
ATX Power Connector
Parallel Connector
Serial Port
Connector (COM2)
Serial Port
Connector (COM1)
Line-In/Line-Out/Mic-In
Game/MIDI Connectors
Floppy Connector
BIOS Write Protection - JP3
Front Panel Connector - JP7
Two E-IDE Connectors
FAN3
FAN1
FAN4
FAN2
Socket462
Six PCI Slots
One CNR Slot
One 4 X AGP Slot
VIA VT8366 Chipset
VIA VT8233 Chipset
USB/LAN Connectors
IRConnector-
JP2
Clear CMOS- J
P16
I/O Controller
Onboard MII interface
compliant PHY
CD Audio Connectors
Onboard CODEC
Wake-On-LAN Connector -
CN1
Programmable 2Mb Flash EEPROM
Extended four USB Connectors
header - JP4/JP5
Two 184-pin DDR DIMMSlots
Two 168-pin SDR DIMM Slots

- 13 -
Step 1
Install the CPU:
1. Locate the CPU ZIF (Zero Insertion Force) socket on the upper-right
sector of your mainboard (between the back-panel connectors and the
DIMMmemoryslots).
2. Pull the CPU ZIF socket lever slightly sideways away from the socket
to unlock the lever, and then bring it to an upwardly vertical position.
3. PlaceyourAMD462Athlon/Duronprocessor in thesocketA. Notethatthe
CPU’s edges have been purposely designed non-symmetrically to prevent
from insertingtheprocessorinthewrongdirection. Thefollowing diagram
demonstrates the correct placement of the CPU in the ZIF socket. You can
seethat the two blunt-edged corners should face towards the socket-lever.
4. SlightlypushtheAMD462Athlon/Duronprocessorinto the socket without
applying excessive force while making sure there is no gap between CPU
and socket. Then lower the socket-lever all the way down to its horizontal
position and lock it to secure the CPU in place.
5. The AMD 462 Athlon/Duron processor requires a set of heatsink/fan to
ensure proper cooling of the processor. If heatsink/fan have not been
already mounted on your CPU, you must purchase the heatsink/fan sepa-
rately and have it installed. Plug the cable through the heatsink/fan in the
CPUfanpowerconnectorlocatednearby. Notethat there areseveraltypes
of CPU fan connectors. Normally, if your mainboard supports the hard
ware monitoring function, a 3-pin fan power connector should allow your
system to detect the CPU fan’s speed . The CPU fan can also run with a 2-
pin fan power connector, however, detection of CPU fan’s speed is not sup
ported. Another type of CPU fan may feature a large 4-pin fan power con-
nector, which does not support CPU fan's speed detection and must be di-
rectly connected to the system’s power supply unit. Please refer to the fol-
lowing diagram.
Notch
AMD CPU
SO C K E T4
ASSEMBLED IN MA LAY SIA
Lever Blank
Blank
SOCKET462

- 14 -
Step 2.
Set Jumpers
This mainboard is jumperless! The default jumper settings have been set for
the common usage standard of this mainboard. Therefore, you do not need
to reset the jumpers unless you require special adjustments as in any of the
followingcases:
1. Over-clock your CPU
2. Clear CMOS
Forfirst-time DIY system builders, we recommend thatyou do not change the
defaultjumpersettingsifyouarenottotallyfamiliarwithmainboardconfigu-
rationprocedures. Thefactory-setdefaultsettingsaretunedforoptimum
system performance. For the advanced users who wish to customize their
system,section3.2 Jumper Settings willprovidedetailedinformationonhow
to configure your mainboard manually.
Step 3.
Install DDR or SDR SDRAM System Memory
To insert memory module(s) in any one or two DIMM slot(s). Please note
thatmodules are directional and will not go in the DIMM slots unless prop-
erlyoriented. AfterthemoduleisfullyinsertedintotheDIMMslots, lift the
clips of both sides of the DIMM slot to lock the module in place.
SDR SDRAM DDR SDRAM

- 15 -
Step 4
Install Internal Peripherals in System Case
Before you install and connect the mainboard into your system case, we
recommendthatyoufirstassemblealltheinternal peripheral devices into the
computerhousing, including but not limited to thehard disk drive (IDE
/HDD),floppydiskdrive(FDD),CD-ROMdrive,andATXpowersupplyunit.
Thiswill greatly facilitate in making the connections tothe mainboard de-
scribedbelow.
ToinstallIDE&FDDdrives,followthisprocedure:
1. Set the required jumpers on board each device according to the
instructionsprovidedbythemanufacturer.(IDEdevices,HDD,and
CD-ROM have to set jumpers on Master or Slave mode depending
on your willing to install more than one device for each kind.)
2. Connect IDE cable and FDD cable on the back-panel of the internal
peripheral devices to the corresponding headers on board. Note that the
cable should be oriented with its colored stripe (usually in red or magenta)
connected to pin#1 both on the mainboard IDE or FDD connector and on
thedeviceaswell.
3. Connect an available power cable through your system power supply unit
to the back-panel of each peripheral device. Note that the power cable
isdirectionalandcannotfit in if it is not properly positioned.

- 16 -
Step 5
Mount the Mainboard on the Computer Chassis
1. You may find that there are a lot of different mounting hole positions
both on your computer chassis and on the mainboard. To choose a
correct mounting hole, the key point is to keep the back-panel of the
mainboard in a close fit with your system case, as shown below.
2. After deciding on the proper mounting holes, position the studs between
the frame of chassis and the mainboard. The studs are used to fix the
mainboard and to keep a certain distance between the system chassis
and the mainboard, in order to avoid any electrical shortage between the
board and the metal frame of chassis. (If your computer case is already
equippedwith mounting studs, you will need to tighten screws to attach
themainboard.)
Note: In most computer housings, you will be able to find 4 or more
attachmentpointsto install mounting studs and fix the mainboard.
If there aren’t enough matching holes, then make sure to install at
least 4 mounting studs to ensure proper attachment of the
mainboard.

- 17 -
Step 6
Connect Front-Panel Switches/LEDs/Speaker/USB connectors
You can find there are several different cables already existing in the system
caseandoriginatingfromthecomputer’sfront-paneldevices(HDDLED,
Power LED, Reset Switch, PC Speaker, or USB devices etc.) These cables
serve to connect the front-panel switches, LEDs, USB connectors to the
mainboard’s front-panel connectors group (JP7, JP4 and JP5), as shown
below.
1. ATX Soft Power On/Off (PWR PT)
2. EPMI
(HardwareSystemManagement
Interface)
JP7
1RST
P LED
+ - SPEAK
GLED
+ -+ - EPMI PWR PTHLED
JP7
1RST
P LED
+ - SPEAK
GLED
+ -+ - EPMI PWR PTHLED
USB3
1
10
USB2
10
1
JP4
JP5 JP7
1RST
P LED
+ - SPEAK
GLED
+ -+ - EPMI PWRPTHLED

- 18 -
3. Green_LED(GLED)
4. HDD_LED(HLED)
5. Power-LED(PLED)
6. HardwareResetSwitch(RST)
7. PC Speaker (SPEAK)
JP7
1RST
P LED
+ - SPEAK
GLED
+ -+ - EPMI PWR PTHLED
JP7
1RST
P LED
+ - SPEAK
GLED
+ -+ - EPMI PWR PTHLED
JP7
1RST
P LED
+ - SPEAK
GLED
+ -+ - EPMI PWR PTHLED
JP7
1RST
P LED
+ - SPEAK
GLED
+ -+ - EPMI PWR PTHLED
JP7
1RST
P LED
+ - SPEAK
GLED
+ -+ - EPMI PWR PTHLED
