Shuttle MK35V User manual

MK35V&MK35VN
AMD AthlonXP/Athlon/Duron
462-pinProcessor
with 200/266 MHz FSB
Based DDR MAINBOARD
User's Manual

Thermalissueishighlyessentialforprocessorswithaspeedof600MHzandabove.
Hence,werecommendyoutousetheCPUfanqualifiedbyAMDor motherboard
manufacturer.Meanwhile,pleasemakesure CPUandfan aresecurelyfastened well.
Otherwise,improper faninstallationnot onlygetssystem unstablebutalso could
damageboth CPU and motherboard because insufficient thermaldissipation.
Ifyou would like to know more about thermaltopicpleaseseeAMD website for
detailedthermal requirementthroughthe address:
http://www.amd.com
WARNING

M808
Shuttle®MK35V & MK35VN
AMDAthlonXP/Athlon/Duron
462-pin Processor
with 200/266 MHz FSB
Based DDR Mainboard
Manual Version 1.1
Copyright
Copyright©2003 by Shuttle®Inc. All Rights Reserved.
This publication, including all photos, illustrations, and software, is protected under interna-
tional copyright laws, with all rights reserved. Reproducing any of the material contained
herein is prohibited without the consent of the publisher.
Disclaimer
Shuttle®Inc. shall not be liable for any incidental or consequential damages resulting from the
performance or use of this product.
This company makes no representations or warranties regarding the contents of this manual.
Information in this manual has been carefully checked for reliability; however, no guarantee is
given as to the correctness of the contents. In the interest of continued product improvement,
this company reserves the right to revise the manual or include changes in the specifications
of the product described within it at any time without notice and without obligation to notify any
person of such revision or changes. The information contained in this manual is provided for
general use by the customers.
Trademarks
Shuttle is a registered trademark of Shuttle Inc.
AMD,Athlon,andDuronare registered trademarks ofAMD Corporation.
PS/2 is a registered trademark of IBM Corporation.
AWARD is a registered trademark ofAward Software Inc.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
General Notice: Other product names used in this manual are ascribed to their respective
owners and acknowledged.

Statement of Shuttle Mainboard via the EMI Test
Shuttle mainboards have been via the EMI test in terms of series of regulations: EN55022/
CISPR22/AS/NZS3548Class B, EN55024 (1998/AS/NZS), EN4252.1 (1994), EN61000,ANSI
C63.4 (1992), CFR47 Part 15 Subpart B, and CNS13438 (1997). The items tested are illus-
trated as follows:
(A)Voltage:AC110V/60HZ &AC230V/50HZ
(B) Tested Product Information:
Product Name: PC Mainboard
Status: Sample
ModelName:MK35VN/MK35V
S/N:N/A
CPU:
External Frequency: 133 MHz
AMDAthlonXP1500+/1600+/1700+/1800+/1900+/2000+/2100+/2400+/2600+
AMDAthlon1.00/1.13/1.20/1.33/1.40GHz
External Frequency: 100 MHz
AMDAthlon750/800/850/900/950 MHz,1.00/1.10/1.20/1.30/1.40GHz
AMDDuron750/800/850/900/950MHz, 1.00/1.10/1.20/1.30 GHz
Mouse Port: one port with 6 pins
Keyboard Port: one port with 6 pins
Parallel Port: one port with 25 pins
Serial Port: one port with 9 pins
VGA Port: one port with 15 pins
USB Port: four ports with 4 pins respectively
LANPort: one port with8pins (10Mbps/100Mbps)(MK35VN only)
Line-In & Line-Out & Mic-In Ports: one port for each
DIMM Memory (optional): DDR 266 256 MB*2
Power Cable: Detachable and Shielded (with a GND pin)
Monitor: CRT+DVI
Maximum Resolution: 1280 X 1024 V:60Hz
All CPUs have completely been tested, and values offered by the worst EMI combination of
CPU external frequency are listed as follows:
Test Mode
1
2
3
4
5
6
7
8
External Frequency
133 MHz
133 MHz
133 MHz
133 MHz
100 MHz
100 MHz
100 MHz
100 MHz
CPU
AthlonXP2600+
AthlonXP2600+
Athlon 1.4 GHz
Athlon 1.4 GHz
Athlon 1.4 GHz
Athlon 1.4 GHz
Duron 1.2 GHz
Duron 1.2 GHz
Case Open/Closed
Closed
Open
Closed
Open
Closed
Open
Closed
Open

(C) Remedy for the Tested Product & Its EMI Interference:
Remedy:N/A
EMIInterference:
Crystal:14.318 MHz(X1)/32.768 KHz(X3)/24.576MHz(X2)/25.000 MHz(X4)
Clock Generator: GEN1
(D)Difference between MK35VN andMK35V:
To discriminate MK35VN from MK35V lies in the extent that chips in MK35VN support LAN,
and the combination for testing is based on MK35VN.
(E) Supported Host Peripherals:
(F) Notices for Assembling Computers:
1. Cases should be made of iron or other metal that has good electric conductivity.
2. Cylinders in a case should be made of metal, and as having a mainboard mounted
in a case, make sure screws are all utilized and fastened on a mainboard.
3. An I/O shielding should be contacted with I/O metallic parts of a mainboard.
4. Cables should appropriately be arranged and fixed in a case. Follow instructions:
Ø Leave IDE cables not crossed upon CPU and SDRAM;
Ø Leave power cables minimum in length, and not crossed upon a mainboard;
Ø Leave CPU fan cables minimum in length, and not near CPU;
Ø Leave cables on panels and other spare cables tied in a computer case.
5. Make sure an EMI shielding attached to a case has properly been installed.
6. Make sure a 5.25" or 3.5" FDD and screws are fastened to an EMI shielding.
7. Make sure a case is closely in contact with EMI connected points.
8. Make sure there is no cleft in a case which is not deformed.
9. Make sure a PCI orAGP door is bound to a case.
10. Make sure cables of other devices (fans or some others) are fixed in a case.
Host Peripheral Product Name Model Name S/N FCC ID
#1 Case AK32V
#2 Seventeam Power
Supply (switchable) ST-250HK
#3 IBM HDD (82.3GB) IC35L080AVVA07-0 A4DEENPG 3902I082
#4 MITSUMI FDD D353M3
#5 SONY CD-ROM Player CDU4811 3892A291
#6 Shuttle AGP Card CV22 (registered no.: D33032)
