Shuttle Spacewalker MS51 User manual

MS51/MS51N
Pentium 4 Processor
Based DDR MAIN BOARD
User's Manual

Shuttle®SpacewalkerTM MS51/MS51N
Pentium 4 , 478-pin processor based DDR Mainboard
Manual Version 1.0
Copyright
Copyright©2002 by Shuttle®Inc. All Rights Reserved.
No part of this publication may be reproduced, transcribed, stored in a retrieval system,
translated into any language, or transmitted in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, photocopying, manual, or otherwise, without
prior written permission from Shuttle®Inc.
Disclaimer
Shuttle®Inc. shall not be liable for any incidental or consequential damages resulting from the
performance or use of this product.
This company makes no representations or warranties regarding the contents of this manual.
Information in this manual has been carefully checked for reliability; however, no guarantee is
given as to the correctness of the contents. In the interest of continued product improvement,
this company reserves the right to revise the manual or include changes in the specifications
of the product described within it at any time without notice and without obligation to notify any
person of such revision or changes. The information contained in this manual is provided for
general use by the customers.
Trademarks
Spacewalker is a registered trademark of Shuttle Inc.
Intel, Pentium is a registered trademarks of Intel Corporation.
SiS is a registered trademarks of SiS Corporation.
PS/2 is a registered trademark of IBM Corporation.
AWARD is a registered trademark of Award Software Inc.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
General Notice: Other brand and product names used herein are for identification
purposes only and may be trademarks of their respective owners.
M521

- 1 -
WHAT’S IN THE MANUAL .....................................................................5
Quick Reference................................................................................................5
About This Manual ............................................................................................5
1 INTRODUCTION .................................................................................6
1.1 TO DIFFERENT USERS ..............................................................................6
FIRST-TIMEDIYSYSTEMBUILDER ............................................................6
EXPERIENCEDDIY USER .........................................................................6
SYSTEMINTEGRATOR ...............................................................................6
1.2 ITEM CHECKLIST:.......................................................................................7
2 FEATURES..........................................................................................8
2.1 SPECIFICATIONS ........................................................................................8
3 HARDWARE INSTALLATION ...........................................................11
3.1 STEP BY STEP INSTALLATION................................................................ 11
Accessories of MS51/MS51N ...............................................................11
STEP1 CPUInstallation.........................................................................12
STEP 2 Set Jumpers..............................................................................14
STEP3 InstallDDR SDRAMSystem Memory ........................................14
STEP4 Install Peripheralsin SystemCase.............................................15
STEP5 MounttheMainboard onthe ComputerChassis ........................16
STEP6 Connect FrontPanel Switches/LEDs/Speaker/USB ..................17
STEP 7 Connect IDE and Floppy Disk Drives.........................................18
STEP8Connect OtherInternalPeripherals ............................................18
STEP9 Connectthe PowerSupply ........................................................19
STEP10 InstallAdd-on Cards inExpansion Slots ..................................20
STEP11Connect External Peripheralsto Back Panel...........................21
STEP 12 First Time System Boot Up......................................................22
STEP13 InstallDrivers &Software Components ....................................23
TABLE OF CONTENTS

- 2 -
3.2 JUMPER SETTINGS ..................................................................................24
JUMPERS& CONNECTORSGUIDE ....................................................25
Jumpers
Clear CMOS Setting (JP1) ....................................................................28
BIOSWrite Protection (JP2)...................................................................29
Back-Panel Connectors
PS/2 Keyboard & PS/2 Mouse Connectors ............................................30
COM1Port Connector............................................................................30
VGAPort Connector...............................................................................30
ParallelPort Connector...........................................................................30
Line-Out PortConnector .........................................................................30
Line-InPortConnector............................................................................31
Mic-In PortConnector .............................................................................31
MIDI/GAMEPortConnector....................................................................31
LANPort Connector(MS51Nonly) .........................................................31
USB Port 1/USB Port 2 Connectors........................................................31
Front-Panel Connectors
ATXPower On/OffSwitch Connector(PWR SW)....................................32
Green LED / Power LED Connector (ACPI LED)....................................32
HDD LED Connector (HDD LED)...........................................................33
HardwareReset Connector(RST SW) ...................................................33
Speaker Connector (SPEAKER)............................................................33
ExtendedUSB Headers (LUSB1/LUSB2) ..............................................34
Internal Peripherals Connectors
EnhancedIDE andFloppyConnector ....................................................35
Other Connectors
ATXPower SupplyConnector (ATX1/ATX2) ...........................................36

- 3 -
Cooling Fan Connectors for CPU (CPUFAN1), Case (CHSFAN1/
BAKFAN1) .............................................................................................37
Wake-on-LAN Connector(WOL1) ..........................................................37
Wake-on-Modem Connector(WOM1).....................................................37
IRHeader(LSIR1) ..................................................................................38
ModemIn Header(LMDN1)....................................................................38
COM2Connector (COM2)......................................................................39
AudioCD-INConnector(CDIN1/CDIN2).................................................39
Front-PanelAudioHeader (LAUDIO1).....................................................40
Memory module LED (LED1) .................................................................40
3.3 SYSTEM MEMORY CONFIGURATION ......................................................41
1.INSTALL MEMORY.............................................................................41
2.UPGRADE MEMORY.........................................................................41
4 SOFTWARE UTILITY .......................................................................42
4.1 Mainboard CD Overview ..........................................................................42
4.2 Install Mainboard Software ......................................................................43
4.2.A InstallSIS ChipsetDriver ..............................................................44
4.2.B InstallAudio Driver........................................................................45
InstallWINNTAudio driver ...........................................................46
4.2.C InstallSIS VGADriver ..................................................................48
InstallWINNTVGAdriver..............................................................49
4.2.D InstallLAN Driver(MS51Nonly)....................................................51
InstallWIN98 LANdriver ...............................................................52
InstallWINNTLANdriver...............................................................55
4.3 View the User's Manual............................................................................57

- 4 -
5 BIOS SETUP.....................................................................................58
5.1 ENTER BIOS ..............................................................................................58
5.2 THE MAIN MENU .......................................................................................59
STANDARD CMOS FEATURES ................................................................61
ADVANCED BIOS FEATURES..................................................................64
ADVANCED CHIPSET FEATURES...........................................................67
INTEGRATEDPERIPHERALS...................................................................69
POWERMANAGEMENT SETUP ..............................................................74
PNP/PCICONFIGURATION .......................................................................77
PC HEALTH STATUS.................................................................................79
FREQUENCY/VOLTAGECONTROL..........................................................80
LOAD FAIL-SAFE DEFAULTS...................................................................81
LOADOPTIMIZED DEFAULTS ..................................................................81
SET PASSWORD ......................................................................................82
SAVE & EXIT SETUP.................................................................................83
EXITWITHOUTSAVING.............................................................................83

- 5 -
Quick Reference
Hardware Installation >> Step-by-Step ................................................ Page 11
Jumper Settings >> A Closer Look ...................................................... Page 24
Drivers/Software Utilities >> How to Install ......................................... Page 42
BIOS Setup >> How to Configure ........................................................ Page 58
About This Manual
For First-Time DIY System Builder......................................................... Page 6
For Experienced DIY User ...................................................................... Page 6
For System Integrator ............................................................................. Page 6
WHAT’S IN THE MANUAL

- 6 -
1.1 To Different Users
First-Time DIY System Builder
Welcome to the DIY world! Building your own computer system is not as
difficult as you may think. To make your first computer DIY experience
successful, right from the start, we ha e designed the 3.1 Hardware Installation
section in a step-by-step fashion for all the first-time DIY system builders. Prior
to installation, we also suggest you to read the whole manual carefully to gain a
complete understanding of your new Shuttle MS51/MS51N mainboard.
Experienced DIY User
Congratulate on your purchase of the Shuttle MS51/MS51N mainboard. You
will find that installing your new Shuttle MS51/MS51N mainboard is just easy.
Bundled with an array of onboard functions, the highly-integrated MS51/MS51N
mainboard pro ides you with a total solution to build the most stable and reli-
able system. Refer to sections 3.2 Jumper Settings and Chapter 4 Drivers/
Software tilities to find out how to get the best out of your new mainboard.
Chapter 5 BIOS Setup also contains the rele ant information on how to tune
up your system to achie e higher performance.
System Integrator
You ha e wisely chosen Shuttle MS51/MS51N to construct your system.
Shuttle MS51/MS51N incorporates all the state-of-the-art technology of the
SiS 650 chipset from SiS. It integrates the most ad anced functions you can
find to date in a compact Micro ATX board.
1INTRODUCTION
This manual adopted in MS51 and MS51N mainboards at the same time.
The difference between MS51 and MS51N is that MS51N equips with
onboard LAN Controller. In the manual, if there are some standards,
characters, equipment or software only appeared or adopted by MS51N; it
will be mentioned (MS51N only)

- 7 -
1.2 Item Checklist:
Check all items with you MS51/MS51N mainboard to make sure nothing is
missing. The complete package should include:
One piece of Shuttle MS51/MS51N Mainboard
One piece of ATA100/66/33 Ribbon Cable
One piece of Floppy Ribbon Cable
One piece of 9-pin Ribbon Cable
One piece of twin ports USB Cable (optional)
I/O Shielding
MS51/MS51N Users Manual
One piece of Bundled CD-ROM with containing:
Ø MS51/MS51N users manual sa ed in PDF format
Ø SiS Chipset dri er
Ø SiS VGA dri er
Ø AC'97 Audio dri er
Ø LAN dri er (for MS51N)
Ø Award Flashing Utility
PSKBM1
COM 1
VGA1
VG A PRT
1
1
1
1
1
1
1
1 1
IT8712F-A 9944-DXS MA4500
CHSFAN1
SmartI/Ointe rface
BAKFAN1
CPUFAN1
1
1
J2
1
11
PWR
SW
LPANEL1
RST
SWSPEAKER
ACP
LED
HDD LED
1
1
1
1
11
1
CDIN1 COM2
CDIN2 LMDN1
JP2
1
DI MM2
DI MM1
ID E1
ID E2
ATX2
ATX1
USB 3&4USB 5&6
JP1
J3
J1
LED1
WOM1 WOL1
LSIR1SPEAKER1
USBLAN1
LUSB1LUSB2
PCI 1
AGP1
PCI 2
PCI 3
CNR1
RTL8100B
18034T3
009BT AIWAN
4MC
+
961
SIS'00
ELD2691
0138EA
5E5
+
650
SI S'01
PLD 48 92
0145EA
5E5
FLOPPY1

- 8 -
MS51/MS51N mainboard is carefully designed for the demanding PC user who wants
high performance and maximum intelligent features in a compact package.
2.1 Specifications
CPU Support
Intel Pentium 4, 478-pin processors with 400 MHz FSB.
Chipset
Features SiS 650 N.B. and SiS 961 S.B..
Onboard Lan (MS51N only)
Realtek 8100, support 10Mb/s and 100Mb/s operation.
Jumperless CPU Configuration
Soft-configuration FSB (The FSB speed is software configurable from 100MHz
to 133MHz in the Frequency/Voltage Control of BIOS setup program.)
AC'97 Link for Audio and Telephony CODEC
AC'97 2.2 compliant.
Spread independent PCI functions for Audio and Modem.
Versatile Memory Support
Two 184-pin DIMM slots to support up to 2GB of PC1600, PC2100, and
PC2700 compliant DDR SDRAM module.
PCI Expansion Slots
Pro ides three 32-bit PCI slots.
AGP Expansion Slot
Pro ides one 32-bit AGP slot which supports 4X AGP de ices.
CNR Expansion Slot
Pro ides one Communication and Network Riser (CNR) slot.
6 USB Interface Onboard
Ø2 × USB connectors on back-panel and two sets of dual USB ports header
on mid-board.
2 FEATURES

- 9 -
I/O Interface
Pro ides a ariety of I/O interfaces:
Ø1 × Floppy interface for 3.5-inch FDD with 720KB, 1.44MB, or 2.88MB
format or for 5.25-inch FDD with 360K or 1.2MB format.
Ø1 × PS/2 mouse connector.
Ø1 × PS/2 Keyboard connector.
Ø1 × DB15 VGA connector.
Ø1 × DB9 Serial connector 16550 UART compatible.
Ø1 × Infrared communication port.
(Serial port COM2 can also be redirected to an external IrDA Adapter
for wireless connection.)
Ø1 × DB25 Parallel port supports Standard Parallel Port and Bi-directional
(SPP), Enhanced Parallel Port (EPP), and Extended Capabilities Port (ECP)
data transmission schemes.
Ø1 × Line-Out port.
Ø1 × Line-In port.
Ø1 × Mic-In port.
Ø1 × MIDI/GAME port.
Ø1 ×RJ45 LAN connector. (MS51N only)
PCI Bus Master IDE Controller Onboard
Two Ultra DMA 100/66/33 Bus Master Dual-channel IDE ports pro ide sup-
port to a maximum of four IDE de ices (one Master and one Sla e per channel).
The IDE Bus implements data transfer speeds of up to 100/66/33 MB/sec and
also supports Enhanced PIO Modes.
80-pin Cable Backward Compatible Legacy ATAPI De ices, ATAPI IDE CD-
ROM, CD-R, CD-RW, and LS-120 Supports.
ATX Power Supply Connector
ATX power supply unit can connected to the onboard 20-pin Pentium 4
standard ATX power connectors, supporting Suspend and Soft-On/Off by
dual-function power button.
The Pentium 4 ATX power include other 4-pin +12V ATX power connectors.

- 10 -
Advanced Configuration and Power Interface
Features four power sa ing modes: S1 (Snoop), S3 (Suspend to RAM), S4
(Suspend to DISK), and S5 (Soft-Off). ACPI pro ides more efficient Energy
Sa ing Features controlled by your operating system that supports OS Direct
Power Management (OSPM) functionality.
System BIOS
Pro ides licensed Award BIOS V6.0 PG on Intel Firmware Hub 2Mb Flash
core and supports Green PC, Desktop Management Interface (DMI).
ATX Form Factor
System board conforms to Micro ATX specification.
Board dimension: 244mm × 220mm.
Advanced Features
ØLow EMI - Built in spread spectrum and automatic clock shut-off of
unused PCI/SDRAMS slots to reduce EMI.
ØDual Function Power Button - The system can be in one of two states,
one is Suspend mode and the other is Soft-Off mode. Pushing the power
button for less than 4 seconds places the system into Suspend mode.
When the power button is pressed for longer than 4 seconds, the system
enters Soft-Off mode.
ØModem Ring Power-On - The system can be powered on automatically by
the acti ation of modem ringing.
ØCP Host/DRAM/PCI Clock Setting - This item allows users to adjust
CPU Host Clock, DRAM, and PCI Clock in BIOS.
ØCP Multiplier Setting - This item allows users to adjust CPU Multiplier in
BIOS.
Intelligent Features
ØVoltage Monitoring - Monitors arious oltages of key elements, such as
the CPU, and other critical system oltage le els to ensure stable current
passing through mainboard components.
ØFan Status Monitoring - To pre ent CPU from o erheating, the CPU fan is
monitored for RPM (CPU Cooling FAN with RPM sensor is required.)
ØTemperature Monitoring - This item allows users to make sure whether the
CPU or system runs in a suitable temperature.

- 11 -
Before removing or installing any of these devices including CP , DIMMs, Add-On
Cards, Cables, please make sure to unplug the onboard power connector.
This section outlines how to install and configure your mainboard. Refer to the following
mainboard layout to help you to identify arious jumpers, connectors, slots, and ports.
Then follow these steps designed to guide you through a quick and correct installation of
your system.
3.1 Step-by-Step Installation
3HARDWAREINSTALLATION
Accessories Of MS51/MS51N
PSKBM1
COM1
VGA1
VGA PRT
1
1
1
1
1
1
1
IT8712F -A
9944-D XS
M A450 0
CHSFAN1
BAKFAN1
CPUFAN1
1
1
1
1
PWR
SW LPANEL1
RST
SWSPEAKER
ACPI
LED
HDD
LED
1
1
1
1
1
1
1
CDIN1
COM2
CDIN2
LMDN1
JP2
1
DIMM2 DIMM1
ID E 1
ID E 2
AT X2
AT X1
USB 3& 4USB 5& 6
JP1
J1
LED1
WOM1
WOL1
LSIR1
US BL AN1
LUSB1LUSB2
PCI1
AG P1
PCI2
PCI3
CNR1
RT L8100B
1 8034 T3
009B TAIWAN
4MC
+
961
S IS '0 0
ELD2691
0138E A
5E5
+
650
SIS'01
PLD4892
0145EA
5E5
FLOPPY1
Three P CI Slots
One AGP 4x Slot
One CNR Slot
SOCKET 478
BAKFAN1
CHSFAN1
USB & AN
Connectors
(MS51N only)
Extended USB 1.1 Headers -
LUSB1/ LUSB2
Front-Panel - LPANEL1Header
Parallel Connector
Serial Port
Connector (COM1)
COM2 Connector
Front Audio Connector
- LAUDIO1
VGA Port Connector
RT 8100 AN Controller
(MS51N onl y)
Onboard Audio CODEC
ine-Out/ ine-In/Mic-In/
Game/MIDI Connectors
Onboard Audio
Connectors -
CDIN1/CDIN2
PS/2 Keyboard and
PS/2 Mouse Connectors
I/O Controller
Two 184-pin DIMM Slots
Memory module ED
- LED1
CPUFAN1
ATX Power Connector
- ATX2
P4 ATX
12V Power Connector
- ATX1
IR Connector -
LSIR1
BIOS Write Protection
- JP2
Modem in Connector
- LMDN1
Clear CMOS -
JP1
Wake On AN -
WOL1
Battery
Wake On Modem -
WOM1
Clock Generator
Programmable Flash EEPROM (FWH)
SiS 961 Chipset
Floppy Connector
Two E-IDE Connectors
SiS 650 Chipset

- 12 -
Step 1
CPU Installation:
This mainboard supports Intel ® Pentium ® 4 , Socket 478 series CPU. Please
follow the step as below to finish CPU installation.
Be careful of CPU orientation when you plug it into CPU socket.
1. Pull up the CPU socket le er and up to 90-degree angle.
2. Locate Pin 1 in the socket and look for a black dot or cut edge on the CPU
upper interface. Match Pin 1 and cut edge, then insert the CPU into the
socket. CPU pin 1 and cut edge
CPU socket lever up to
90 degree

- 13 -
3. Press down the CPU socket le er and finish CPU installation.
Note: If you do not match the CPU socket Pin 1 and CPU cut
edge well, it may damage the CPU.

- 14 -
Step 2.
Set Jumpers
This mainboard is jumperless! The default jumper settings ha e been set for
the common usage standard of this mainboard. Therefore, you do not need
to reset the jumpers unless you require special adjustments as any of the
following cases:
1. Clear CMOS
2. BIOS Write Protection
For first-time DIY system builders, we recommend that you do not change the
default jumper settings if you are not totally familiar with the mainboard
configuration procedures. The factory-set default settings are tuned for opti-
mum system performance. For the ad anced users who wish to customize
their system, section 3.2 Jumper Settings will pro ide detailed information on
how to configure your mainboard manually.
Step 3
Install DDR SDRAM System Memory
To install memory, insert DDR SDRAM memory module(s) in DIMM slot(s).
Note that DDR SDRAM modules are directional and will not go in the DIMM
slots unless properly oriented. After the module is fully inserted into the
DIMM slots, lift the clips of both sides of the DIMM slot to lock the module in
place.
DDR SDRAM

- 15 -
Step 4
Install Internal Peripherals in System Case
Before you install and connect the mainboard into your system case, we
recommend that you first assemble all the internal peripheral de ices into the
computer housing, including but not limited to the hard disk dri e (IDE/
HDD), floppy disk dri e (FDD), CD-ROM dri e, and ATX power supply unit.
This will greatly facilitate in making the connections to the mainboard de-
scribed below.
To install IDE & FDD dri es, follow this procedure:
1. Set the required jumpers on each de ice according to the instructions
pro ided by the manufacturer. (IDE de ices, HDD, and CD-ROM, ha e to
set jumpers to Master or Sla e mode depending on whether you install
more than one de ice of each kind.)
2. Connect IDE cable and FDD cable on the back-panel of the internal
peripheral de ices to the corresponding headers on board. Note that the
cable should be oriented with its colored stripe (usually red or magenta)
connected to pin#1 both on the mainboard IDE or FDD connector and on
the de ice as well.
3. Connect an a ailable power cable from your system power supply unit
to the back-panel of each peripheral de ice. Note that the power cable is
directional and cannot fit in if not properly positioned.
4. Connect serial port cable to on board COM2 header. And install the other
side of CMOS cable to back-panel with a screw.

- 16 -
Step 5
Mount the Mainboard on the Computer Chassis
1. You may find that there are a lot of different mounting hole positions
both on your computer chassis and on the mainboard. To choose
correct mounting holes, the key point is to keep the back-panel of the
mainboard in a close fit with your system case, as shown below.
2. After deciding on the proper mounting holes, position the studs between
the frame of the chassis and the mainboard. The studs are used to fix the
mainboard and to keep a certain distance between the system chassis
and the mainboard, in order to a oid any electrical shorts between the
board and the metal frame of the chassis. (If your computer case is
already equipped with mounting studs, you will need to tighten screws to
attach the mainboard.)
Note: In most computer housings, you will be able to find 4 or more
attachment points to install mounting studs and then fix the
mainboard. If there arent enough matching holes, then make sure to
install at least 4 mounting studs to ensure proper attachment of the
mainboard.

- 17 -
Step 6
Connect Front Panel Switches/LEDs/Speaker/USB
You can find there are se eral different cables already existing in the system
case and originating from the computers front-panel de ices (HDD LED,
Power LED, Reset Switch, PC Speaker, or USB de ices etc.) These cables
ser e to connect the front-panel switches, LEDs, and USB connectors to the
mainboards front-panel connectors group ( LUSB1/LUSB2 and LPANEL1), as
shown below.
1. ATX Soft Power On/Off (PWR SW)
2. Green-LED and Power-LED (ACP LED)
3. HDD-LED (HDD LED)
4. Hardware Reset Switch Button (RST SW)
5. PC Speaker (SPEAKER)
6. Extended USB Headers
GROUND KEY +DATA1 -DATA1 USBPWR1
USBPWR0
-DATA0
+DATA0
GROUND GROUND
1
USB port 4/6
USB port 3/5
6
1
1
USB 3 & 4USB 5 & 6
LUSB1LUSB2
1
PWR
SW LPANEL1
RST
SWSPEAKER
ACPI
LED
HDD
LED
1
SPEAKER RST
SW
HDD
LED
ACPI
LED PWR
SW
1
2
5
4
3
+
+
+

- 18 -
Step 7
Connect IDE and Floppy Disk Drives
1. IDE cable connector
2. Floppy cable connector
Step 8
Connect Other Internal Peripherals
1. CD-IN and Front Audio connectors
11
IDE1
IDE2
FLOPPY1
11
CDIN1 CDIN2
1
LAUDIO1
