Siamp SCC 80 Quick guide

CISTERNS
Download products information from www.siamp.com
112
CISTERNS
SCC 80
DESCRIPTIOn
◗ For ground or suspended pans
◗ Masonry recessed inside wall
◗ Masonry mesh
◗ Low level installation
◗ Back or front wall fixing
◗ Mechanical double or simple flush front commands,
see choice page XX
◗ Cistern made from PEHD
◗ Cistern maximum water volume 7,2l
◗ Outer PSE insulation
◗ Adjustable double flush flush valve, 3l./6l. factory preset.
◗ Adjustable noiseless float valve , 6l. factory preset
◗ Stop cock
◗ Inner or outer water connexion
◗ 3/8th" M or 1/2" M water connexion
◗ Height adjustable insulated supply bent
◗ Supply sleeve with pan seal
Packing Packing Palette
Quantity
Nb M3Kg
SCC 80 Carton 1 -
SUPPLEmEnTS:
Command (See page 54)
I III II III
I = 100 mm min.
II = 15  45 mm min.
I = 50 mm min.
II = 100 mm min.
III = 10  40 mm min.
230 ~ 330 mm 480 mm
510 mm
90 mm
Front fixing back fixing

CONCEALEDCISTERN
INTEGRA 80
ASSEMBLY AND MAINTENANCE MANUAL
GB

2
DESCRIPTION
a
d
f
h
i
k
e
g
b
j
c
l
m

3
Toolsrequired:
• Key of 19 mm
• Metal saw
• Drill with a bit diameter 8 mm
• Leveller
• Pencil & ruler
• Measuring tape
• Hammer
• Screwdriver
Advice:
• Keep this notice for any future maintenance
 Read the instructions supplied with the bowl, the seat cover, the cistern and the pressurised
water supply system before starting installation work.
 Before tting the cistern, the supply pipe should be ushed clear.
1 / The internal Equilibrium valve was designed to be used with clear, non agressive
water supplied under a pressure from 1 bar (15 p.s.i) to 10 bars (150 p.s.i).
It is tted with a lter to prevent foreign bodies from impeding the ow.
This lter may require occasional cleaning. Proceed as described page 14.
2 / The internal stop valve should be regularly turned off and on to ensure
that it remains serviceable.
 Siamp shall not be responsible or liable for improper installation of the product or of any
cistern tting damage caused by the use of cleaners containing chlorine
Complete cistern (feat. double ush and oating valves)
Supply bend
Supply sleeve
Wall mounting bracket x 2
Stop cock M 1/2˝ - F 3/8˝
Plug x 2
Screw plug x 2
M6 washer x 2
Cistern anti-condensation lining
Supply bend anti-condensation lining
Template
Supply bend cap
Foam obturator
a
b
c
d
e
f
g
h
i
j
k
l
m

4
CISTERNDIMENSIONS

BACKFIXATIONFRONTFIXATION
5
WALLCONFIGURATIONS

BACKFIXATIONFRONTFIXATION
6
WALLCONFIGURATIONS

7
I-CISTERNASSEMBLING
➍
➍
➌
➋
➍
➍
➊
➌
➋
➊ If needed, adjust supply bend and supply bend lining to desired height. If cut, supply bend must deburred.
➋ Assemble anti-condensation lining onto supply bend.
➌ Mount supply bend onto cistern.
➍ Clip brackets onto cistern.
BACKFIXATION
FRONTFIXATION
From 0
to 100 mm

8
II-WALLPOSITIONING
III-WALLFIXING
➊ Place assembled cistern onto wall. Check horizontal and vertical levels alignments. Mark the 2 drilling points.
Drill wall at the marks using a Ø8 bit. Maximum drilling depth: 45 mm.
➊ Fix cistern into wall using (f)
plugs, (g) screw plugs and
(h) M6 washer.
➊
f
h
gg
➊
BACKFIXATION
BACKFIXATION
FRONTFIXATION
FRONTFIXATION
f
h

9
IV-WATERSUPPLYCONNECTION
➊ Remove the frame by lifting the two locks
➋ Connect stop cock (e) to oat valve placing bre seal in
between
➌ Insert foam obturator on water supply pipe
➍ Connect water supply pipe to ½’’ stop cock end (ensure
tightness using a bre seal, not supplied)
➎ Place foam obturator in between pipe and cistern hole
Frame
➋
➊
e
➌

10
V-WATERSUPPLYCONNECTIONTEST
➊ Insert the supply sleeve (c) and the drain
sleeve on the toilet bowl
➋ Connect the toilet bowl to the cistern and
to building drain system
➌ Turn on the water using stop cock (e),
wait until cistern is lled up
➍ Manually operate the mechanism by
lifting pull rod
➎ Check the tightness of
a) stop cock connections
b) toilet supply and drain connections
➏ Close stop cock (e) and drain cistern by
lifting pull rod
➐ Remove the toilet bowl
c
➊
➋
➎ b
➎ ae
➌➏
➍
➏

11
VI-CLADDINGPREPARATION VII-CLADDING
➊ Put the frame back onto cistern
➋ Attach PSE template (k) using two grey screws
provided in the control panel box
➌ Fit the cap (l) on the supply bend (b)
Cladding thickness:
- Front xation: from 15 to 45 mm
- Back xation: from 10 to 40 mm
Once the covering is nished, take off the PSE
template (k), keep the screws for xing on the control
plate, take off the cap (l).
➊
➋
➌l
b
k
Frame
k
l

12
VIII-TOILETBOWLCONNECTION
➊ Using a rule, draw a mark on supply sleeve (c)
as shown on drawing.
➋ Remove supply sleeve (c) from toilet bowl and
place it on supply bend (b). Using a rule, make
a mark as shown on drawing.
 Read the instructions for the bowl and seat cover before starting.
c
➊
➋
➋

13
VIII-TOILETBOWLCONNECTION(continued)
➌ Measure the dimension (L) in
between the two marks.
➍ Transfer L dimension increasing
it by 3 mm at the end of the
supply sleeve (wall side, e.g.
L = 50 mm, shorten supply
sleeve by 53 mm.), measure
it and make a mark
➎ Cut supply sleeve using a hack
saw.
➏ De-burr supply sleeve cut using
a le
➐ Mount supply sleeve c and
drain pipe into toilet bowl.
Place toilet bowl at its nal
location.
➌
➏
➐
➍ ➎

14
MAINTENANCEOPERATIONS
During the use of your INTEGRA 80 ushing cistern, you may be required to maintain the
equipment.
I - MAINTENANCE OF THE VALVE (lter cleaning, replacement of membrane)
➊ Remove the control plat by lifting it slightly and tilting it forward
➋ Remove the operating screws
➌ Unscrew the chassis screws and remove the chassis
➍ Remove the frame as indicated under point IV of the manual
➎ Close the stop cock
➏ Unscrew oat valve bolt
➐ Take out the oat valve
➑ Unscrew the bolts of the float valve to take out the
membrane and the lter. Change the membrane and clean
the lter.
Filter
Membrane
➊➍
➌
➋
➏➎
➐
Chassis
Bolt

15
MAINTENANCEOPERATIONS(cont’d)
II - MECHANISM MAINTENANCE (cleaning or replacement of the seal)
Proceed in the same way as for the maintenance of the float valve up to
point ➏then:
➊
➋
90°
➋ Grasp the mechanism by the tube and lift it vertically, make it turn 90° and then take it out. Plughole remains into
cistern.
➊ Take off the brace

You have just installed a “Concealed cistern” toilet from SIAMP’s
INTEGRA 80 range and we would like to thank you for putting your
trust in us.
We are specialists in bathroom technical equipment and accessories and
have taken the utmost care in the design and manufacturing of this product,
which we guarantee for 5 years, excluding rubber parts and man hours.
For any more information or requests, please contact your sales outlet.
Réf. 6097 - Imprimerie PONS s.a.
➌
➌ Unclip the washer, take out the seal and change it, then re-assemble the whole set.
 To position the mechanism properly the plughole and the mechanism are provided with a polariser.
Seal
Washer to be unclipped
