Siegenia AERO AEROVITAL ambience User manual

ORIGINAL OPERATING
INSTRUCTIONS
AERO
Wall-mounted venlator with sound absorpon.
AEROVITAL ambience
Window systems
Door systems
Comfort systems

09.20232/20 H47.WANS007EN-03
Contents
1 TARGET GROUP OF THIS
DOCUMENTATION.....................................3
2 INTENDED USE ..........................................3
3 SAFETY NOTES...........................................4
4 GENERAL NOTES........................................4
5 SCOPE OF DELIVERY AND EQUIPMENT ....5
6 UNIT DESCRIPTION ...................................6
6.1 Unit funcon ................................................. 6
6.2 Designaon of parts ...................................... 7
7 LED INDICATOR..........................................8
7.1 Operang status ............................................ 8
7.2 Special funcon ............................................. 8
7.3 Malfuncons ................................................. 8
8 COMMISSIONING......................................9
8.1 Notes on calibraon
(AEROVITAL ambience smart only) ............... 9
8.2 Performing the calibraon ............................ 9
9 OPERATION................................................9
9.1 Buons on the unit ....................................... 9
9.2 Acvang and deacvang
the keyboard lock (child-proof lock) ............. 9
10 OPERATION VIA SMARTPHONE
OR TABLET
...10
10.1 Teaching devices ......................................... 10
10.2 Unit funcons in the app ............................ 10
11 MAINTENANCE........................................11
11.1 Cleaning ...................................................... 11
11.2 Replacing the lter ...................................... 11
12 ACCESSORIES..........................................14
13 RECTIFICATION OF MALFUNCTIONS.......15
13.1 SIEGENIA Comfort app ................................ 16
14 TECHNICAL SPECIFICATIONS...................17
15 DIMENSIONS ...........................................17
16 PRODUCT DATA SHEET

 ...................18
17 EU DECLARATION OF CONFORMITY
 .............19
AERO

AEROVITAL ambience

H47.WANS007EN-03 09.2023 3/20

AEROVITAL ambience AERO
1 
• This documentaon is intended for use by specialists
and end users.
• All notes on operaon and maintenance as well as
the reccaon of malfuncons described here are
intended for specialists and end users.
• Aer the successful assembly and installaon, the
installaon company is commied to handing over
the operang instrucons to the end user.
2 
• Use the AEROVITAL ambience exclusively for the
venlaon of closed rooms (kitchen, bathroom,
living rooms and bedrooms).
• Do not use the AEROVITAL ambience in
environments with corrosive or explosive
atmospheres (dust, vapour or gas).
• The AEROVITAL ambience is not suitable for
dehumidicaon (e.g. for the drying of new
buildings).
• Be sure to mount the supplied SIEGENIA weather
grille for the protecon of the unit from the outer
side.
• Do not install the unit in contaminated rooms and
ensure that no hazardous substances can be drawn
in.
• The unit is not suitable for use in swimming baths
and / or damp locaons.
• Only operate and/or store the AEROVITAL ambience
at temperatures between -15 °C and +40 °C.
• Use the unit only with original accessories from
SIEGENIA.
• Comply with the safety regulaons for operang
electrical equipment and, if necessary, for ladders,
steps and work overhead or at certain heights.
• Use the unit only when it is in a technically sound
condion.
• Do not modify the unit's components in any way.
• Please do not put any objects on top of the unit.
• Do not use the device as a seat.
• Make sure that air can ow in and out at the two
outer sides without impedance. Do not hang any
texles or paper or similar items over the air inlet
and outlet ports and do not place any objects
directly in front of or next to the unit. Do not insert
any objects into the openings of the unit.
• Do not remove any covers or unit components that
are not dened in the "Maintenance" chapter. Do
not remove the cover of the connecng clamps
inside the unit.
• Please make sure that the unit is not switched o
for a longer period (several days) in order to enable
minimum venlaon and to prevent nesng of
insects.
• The unit must be checked by a specialist in the event
of a fault.

09.20234/20 H47.WANS007EN-03
AERO

AEROVITAL ambience
3 
• This unit can be used by children aged 8 and above
as well as by people with physical, sensory or
mental dicules or with a lack of experience and
knowledge as long as they are supervised or have
been instructed in how to use the unit safely and
understand the resulng risks. Children must not
play with the unit. Cleaning and user maintenance
may not be carried out by unsupervised children.
• Electrically operated unit. Risk of fatal injury from
electric shock or re.
• To prevent personal injury or damage to property,
always comply with the following instrucons
– insert the Euro mains plug of the standard
connecng cable only into a suitable 230 V AC
mains power supply socket.
– If the mains connecon cable for the unit is
damaged, it must be replaced by SIEGENIA, the
company's customer service department, or
similarly qualied personnel in order to prevent
the development of hazards.
– If any work is required for the connecon of the
device to the 230 V AC mains power supply, this
may only be carried out by an electrician.
– All-pole safety isolaon is required if the
customer is roung the mains cable.
– The current VDE direcves must be observed.
– Relevant country-specic regulaons with regard
to installaon, funconal tesng, repair and
maintenance of electrical products must be
strictly followed for all work carried out on the
voltage supply system or house wiring system.
– Should a solid object or any liquid get inside the
unit, stop operaon immediately and disconnect
the device from the electricity grid.
• 
A vacuum can be created when this venlaon unit
is operated simultaneously with a heat-producing
appliance (such as a stove or gas heater). The
vacuum could cause exhaust fumes to enter the
room, leading to the danger of poisoning.
– Have the venlaon compound in your home
checked by an accredited chimney sweep.
– For venlaon units that permanently run in
exhaust air operaon, install a safety device in
consultaon with the accredited chimney sweep.
• 
Insects could nest in the unit if the venlaon slots
are closed. The insects could y out and sng you
when you open the unit for maintenance purposes.
– To prevent insects from nesng in the unit, do
not leave the venlaon slots closed for several
days in succession.
– Wear protecve clothing to open the device if
the venlaon slots have been closed for several
days in succession.
•  on SIEGENIA
WIFI devices! Please observe the following notes to
protect your system against aacks by third pares:
– every SIEGENIA WIFI device is protected by
two passwords (user and administrator). It is
essenal that you change these passwords aer
the inial setup. Do not leave in the default
seng.
– If the SIEGENIA WIFI devices are integrated in
your home WIFI, this must be encrypted for
operaon.
– Please choose secure passwords consisng of
lower case and capital leers, numbers and
special symbols.
•  – In order to prevent personal injury,
it is essenal to ensure that condensate does not
ow onto pavements and freeze when outdoor
temperatures are below 0 °C.
• in the case of damage to the
venlaon slots. Switch o the unit and contact the
customer service.
4 General notes
All the dimensions in this documentaon are specied
in millimetres (mm).

H47.WANS007EN-03 09.2023 5/20

AEROVITAL ambience AERO
5 
Item Name AEROVITAL ambience AEROVITAL ambience
smart

1 Heat accumulator stone (2x)
2 Weather grille (2x)
3 Pipe (2x)
4Insect screen (2x)
5 Bag of screws (5 screws and 5 dowels)
6Assembly instrucons
7Drilling template
8AEROVITAL ambience
9Original operang instrucons
10 Quick start instrucons ―

Heat recovery:
Keyboard lock (child-proof lock)
Temperature and humidity sensor
Air quality sensor with CO2 and TVOC
regulaon ―
Operaon via SIEGENIA Comfort app ―
 Unit set
13
2
4
5
6
7
8
9
10

09.20236/20 H47.WANS007EN-03
AERO

AEROVITAL ambience
6 
6.1 
6.1.1 

1
3
2
4
• The outside air (1) is drawn in and enters the room
as ltered supply air (2).
• The exhaust air (3) is drawn in and is released into
the atmosphere as exhaust air (4).
• Both streams of air ow are drawn through the
two heat accumulator stones (heat exchanger)
alternately. The outside air is pre-heated here,
before entering the room as supply air (especially
during cold mes of the year).
6.1.2 
• The blower levels 1 to 5 are controlled in automac
mode. The necessary blower level is dependent
on the temperature and air humidity as well as
oponally on the CO2 value and on the TWOC value.
The least favourable value is the signicant value.
• The blowers are not switched o, but connue to
run at a minimum level.
• The temperature and humidity sensor measures the
inside and outside temperature as well as the inside
and outside humidity.
• The air quality sensor with CO2 and TVOC regulaon
determines a derived CO2 value based on human
aspiraon (hydrogen H2). The ethanol content in the
air is also taken into account for the determinaon
of the TVOC value.
• TVOC (Total Volale Organic Compounds) are volale
organic compounds in gaseous form (e. g. ethanol,
carbon monoxide, methane, butane and cigaree
smoke).
6.1.3 
• The condensate and frost protecon control serves
the device protecon and secures the funconing
of the device even in case of lower outside
temperatures.
• The humidity and temperature sensors connuously
record the environmental condions. If the
environmental condions are extreme, the unit
is switched o. These condions could be lower
outside temperatures or a parcularly high room
humidity, for example.

H47.WANS007EN-03 09.2023 7/20

AEROVITAL ambience AERO
6.2 
5
6
7
5
6
1 2 3 4
1. On/O (and brightness sensor1))
2. Blower levels 1 to 5
3. Automac mode (AUTO)
4. Heat recovery (WRG)
5. Supply air venlaon slots
6. Exhaust air venlaon slots
7. Mains cable with Euro plug (alternave xed
connecon)
1) Depending on the light intensity in the room, the brightness sensor
automacally regulates the brightness of the LED indicator. The darker the
light in the room, the darker the LED indicator.

09.20238/20 H47.WANS007EN-03
AERO

AEROVITAL ambience
7 
7.1 
LED 
»AUTO« ashes Warm-up phase during the calibraon
(see calibraon, page 9)
»Blower level«
lights up Selected blower level is acve
»AUTO« lights up Automac mode is acve*
»WRG« lights up Heat recovery is acve
* In automac mode, the blowers are not switched o, but connue to run
at a minimum level
7.2 
LED 
All LEDS light up
briey
Conrmaon of a special funcon
(e. g. keyboard lock, reset)
7.3 
• Malfuncons are displayed in addion to the
current operang status.
• For fault messages, see "Reccaon of
malfuncons", see page 15.

H47.WANS007EN-03 09.2023 9/20

AEROVITAL ambience AERO
8 Commissioning
8.1 

• For units with air quality sensors, a one-o
calibraon of the sensor is performed during
the commissioning. The sensor adapts to the
environment.
• The room temperature must be between 5 °C and
40 °C.
• The calibraon lasts 24 hours.
• The automac mode already funcons during the
warm-up phase.
• The air quality is already displayed during the
calibraon in the SIEGENIA Comfort app.
• The accuracy of the sensor rises with the connuing
duraon of the calibraon.
8.2 
• Air the room thoroughly for 10 min.
• Connect the AEROVITAL ambience to the mains
electricity grid.
• The exhaust air sensors automacally start a warm-
up phase (duraon approx. 5 min.):
• The calibraon starts automacally.
9 
9.1 
Step  
Switch on unit Unit On/O
Adjust the
blower level
required or
automac
mode
Reduce the blower level
(lowest blower level = 1)
Increase the blower level
(highest blower level = 5)
Automac mode On/O
Acvate heat
recovery Heat recovery On/O
Note: following a restart, the device switches into the
mode last used (blower level, automac mode, heat
recovery)
9.2 

• You can lock the buons on the unit to protect
the venlaon unit against third-party aacks or
to prevent the unintenonal acvaon of device
funcons.
• Aer the keyboard lock has been acvated,
the venlaon unit can only be controlled via
SIEGENIA Comfort app
(AEROVITAL ambience smart only).
– Select the following key combinaon to acvate
and deacvate:
– All LEDS ash for 1-2 seconds following
successful acvaon/deacvaon

09.202310/20 H47.WANS007EN-03
AERO

AEROVITAL ambience
10 AEROVITAL ambience
The AEROVITAL ambience smart can be controlled by
a tablet or smartphone and oers addional device
funcons via the SIEGENIA Comfort app.
10.1 
See enclosed quick start instrucons
(H47.MOTS005EN)
10.2 
10.2.1
The blower performance can be set manually.
• On applicaon of the automac mode silent mode
or mer, the manually adjusted blower performance is
overridden.
10.2.2
The "mode of operaon" funcon enables dierent
venlaon scenarios.
Supply air
Exhaust air
Supply and exhaust air
Air supply and exhaust air with heat
recovery
10.2.3
For informaon on the automac mode, see page 6.
10.2.4
The silent mode restricts the blower performance,
thus overriding all blower levels that are programmed
in other funcons (e. g. mer). The silent mode can
therefore guarantee silent venlaon.
10.2.5 Timer
The mer funcon enables the adjustment of up to 5
dierent me programs. The starng and running me
as well as weekdays, mode of operaon and blower
performance can be freely dened according to the
programmed mer.
10.2.6
As soon as a lter replacement is required, this will be
indicated as a warning.
10.2.7
• The room temperature is indicated in degrees
Celsius (°C).
• The air humidity is indicated in percent (%).
• The air quality is indicated in the form of a trac
light:
– red = bad air quality
– yellow = mediocre air quality
– green = good air quality

H47.WANS007EN-03 09.2023 11/20

AEROVITAL ambience AERO
11 Maintenance
DANGER
Electrically operated unit

• Switch o the unit and pull the mains plug out of the
socket prior to every cleaning process or maintenance
work. Never pull at the cable to disconnect the device
from the electricity grid.
• for all devices with a xed connecon to the 230 V AC
mains power supply, switch o all poles of the feeder.
The safety devices must be removed if necessary.
11.1 Cleaning
• Important: when cleaning the AEROVITAL ambience,
do not allow any liquids to get inside the device.
• Never use cleaning agents that are aggressive or
contain solvents, or sharp-edged objects, as these
may damage the surfaces of the casing.
• Never clean the unit with a high-pressure cleaner or
steam-jet cleaner.
• Clean the AEROVITAL ambience with a cloth
moistened with a mild soap soluon or cleaning
agent.
11.2 
• Replace both exhaust air lters and the supply air
lter as soon as the lter change LED ashes.
• The lters should be replaced every 12 months, at
the latest.
• Only use the original lters from SIEGENIA. You can
purchase replacement lters from SIEGENIA or from
specialist retailers (see accessories page 14).
1
Remove the casing cover

09.202312/20 H47.WANS007EN-03
AERO

AEROVITAL ambience
2 7
Release and remove the top cover plate Insert the new air supply lter
3 8
Remove the muer Posion the muer in the centre
4 9
Remove the polluted supply air lter Posion the top cover plate
5 10
Remove and clean the soiled insect screen Fix the top cover plate
6

If you are not careful, your ngers or hand could be
caught between two plates. This could lead to crushing
and bruises.
• Proceed with cauon.
Insert the cleaned insect screen

H47.WANS007EN-03 09.2023 13/20

AEROVITAL ambience AERO
11 15
Release and remove the boom cover plate Posion the exhaust air lter and lter bracket in the
centre
12 16
2
1
Remove the exhaust air lter and lter bracket (le and
right)
Posion and x the boom cover plate
13 

If you are not careful, your ngers or hand could be
caught between two plates. This could lead to crushing
and bruises.
• Proceed with cauon.
Remove the polluted exhaust air lter
14
Insert a new exhaust air lter

09.202314/20 H47.WANS007EN-03
AERO

AEROVITAL ambience
17
2
3
1
Close the casing cover
18
The lter change display must be reset aer
changing the lter. This is done either using the
SIEGENIA Comfort app or by pressing the Minus
and Plus buons alternately 
12 Accessories
  Contents
Filter set AEROVITAL ambience L3130160-093010 1x supply air lter ePM10 50%
2x exhaust air lter ePM10 50%
Filter set NOx ePM10 (for pollen / ne
dust / nitrogen dioxide) L3130150-093010 1x supply air lter NOx ePM10
2x exhaust air lter ePM10 50%

H47.WANS007EN-03 09.2023 15/20

AEROVITAL ambience AERO
13 
In case of a malfuncon, do not open the unit or try to repair it under any circumstances. If the problem is not
listed in the table below, please contact your installaon rm or SIEGENIA directly: tel. [phone]
Problem  
AEROVITAL ambience shows
no reacon when buon is
pressed
Keyboard lock acve Deacvate keyboard lock (see page 9)
No power supply Check power supply
Wiring wrong/defecve or cable
defecve Have the wiring checked by a qualied electrician
Power supply defecve Have the supply voltage checked by a qualied
electrician
AEROVITAL ambience smart
does not react to
smartphones / tablets
no WIFI connecon to the router
of the home network restart WIFI router of the home network
no WIFI connecon to the
smartphone/tablet restart smartphone/tablet
No WIFI connecon to the
AEROVITAL ambience smart
Reset AEROVITAL ambience smart:
1. Press the On-O buon and Minus buon
alternately
2. All LEDS light up briey
3. The AEROVITAL ambience smart switches to
blower level 1 and has been reset to the factory
sengs.
The outside temperature
displayed on the
SIEGENIA Comfort App
deviates from the actual
outside temperature
The temperature sensor is located
in the unit interior. Depending
on the exterior inuences, the
displayed temperature can deviate
from the actual temperature (e.g.
direct sunlight on the facade)
Not necessary

09.202316/20 H47.WANS007EN-03
AERO

AEROVITAL ambience
Problem  
LED "Blower level 1" ashes
Filter soiled Replace lter
(see lter replacement, page 11)
LED "Blower level 2" ashes
Frost protecon control acve
(Outside temperature below
−15 °C)
Once the outside temperature increases above
–13 °C again, the unit switches to the last blower
level used.
LED "Blower level 3" ashes
Condensate protecon control
acve
When the environmental condions improve, the
unit switches to the last blower level used.
“Blower level 4” LED ashes
periodically 4 mes
Fault with supply air fan:
• The venlaon unit switches o
• Disconnect device from power supply
• Switch the power supply back on
• Contact the Service department if this fault
persists
Fault with exhaust air fan:
• Blower funcon limited
“Blower level 4” LED ashes
periodically 3 mes
Fault with heat recovery system:
• Heat recovery is deacvated
“Blower level 4” LED ashes
periodically 2 mes
Fault with the sensors in the
supply air stream:
• Automac mode limited
• Condensate and frost protecon
control limited
“Blower level 4” LED ashes
periodically 1 me
Fault with the sensors in the
exhaust air stream:
• Automac mode limited
• Condensate and frost protecon
control limited
13.1 
You will nd detailed informaon on operaon and on how to recfy malfuncons using the
SIEGENIA Comfort app on the SIEGENIA Smarthome Internet page.
hps://smarthome.siegenia.com

H47.WANS007EN-03 09.2023 17/20

AEROVITAL ambience AERO
14 
AEROVITAL ambience AEROVITAL ambience smart
Inherent noise
(measured according to DIN EN ISO 3741 with room insulaon
of 8 dB)
Level 1 LPA = 20 dB (A)
Level 2 LPA = 22 dB (A)
Level 3 LPA = 25 dB (A)
Level 4 LPA = 30 dB (A)
Level 5 LPA = 31 dB (A)
Level 1 LPA = 20 dB (A)
Level 2 LPA = 22 dB (A)
Level 3 LPA = 25 dB (A)
Level 4 LPA = 30 dB (A)
Level 5 LPA = 31 dB (A)
Air throughput
Level 1 25 m³/h
Level 2 30 m³/h
Level 3 42 m³/h
Level 4 55 m³/h
Level 5 60 m³/h
Level 1 25 m³/h
Level 2 30 m³/h
Level 3 42 m³/h
Level 4 55 m³/h
Level 5 60 m³/h
Power consumpon
(normal operang mode)
Level 1 6 W
Level 2 7 W
Level 3 8 W
Level 4 11 W
Level 5 12 W
Level 1 6 W
Level 2 6 W
Level 3 8 W
Level 4 11 W
Level 5 12 W
Heat recovery eciency (in accordance with DiBT) up to 85 % up to 85 %
Sound absorpon (in accordance with DIN EN 10140-2) Dn,e,w = 54 dB Dn,e,w = 54 dB
Sound absorpon thanks to sound absorpon pipe
(measured in accordance with DIN EN 10140-2) Dn,e,w = 58 dB Dn,e,w = 58 dB
Electrical connecon 230 V AC / 0.06 A 230 V AC / 0.06 A
Protecon class II II
Weight 24 kg 24 kg
Fresh air lters (supply air and exhaust air lters) Filter grade ePM10 50% Filter grade ePM10 50%
Admissible ulisaon temperature ‒15 °C to +40 °C ‒15 °C to +40 °C
Technical approval Z-51.3-403 Z-51.3-403
15 Dimensions
618 185
690
528
600

09.202318/20 H47.WANS007EN-03
AERO

AEROVITAL ambience
16 
aProducer SIEGENIA SIEGENIA
bModel idener AEROVITAL ambience AEROVITAL ambience smart
c
Energy consumpon (SEC);
Energy eciency class (SEC class)
(according to climac zone warm / average
/ cold)
‒ 16.82 kWh/(m² . a); E
― 41.52 kWh/(m² · a); A
‒ 84.64 kWh/(m² . a); A+
‒ 17.72 kWh/(m² . a); E
‒ 42.42 kWh/(m² . a); A+
‒ 85.53 kWh/(m² . a); A+
dType WLA / ZLA WLA / ZLA
eType of drive Mul-stage control Rotaonal speed control
fHeat recovery system regenerave regenerave
gThermal eciency 83 % 83 %
hMaximum ow rate 60 m³/h 60 m³/h
iElectrical input power 12.0 W 11.8 W
jNoise level 33 dB (A) 33 dB (A)
kRelave air ow rate 42 m³/h 42 m³/h
lRelave pressure dierenal ― ―
mSpecic input power 0.20 W/(m³/h) 0.20 W/(m³/h)
nControl factor / control typology 1.21 / 0.65 1.21 / 0.65
o
Highest degree of inner and outer leakage
rate
(inner / outer leakage)
0.0 % / 3.6 % 0.0 % / 3.6 %
pMix rate (inner area / outer area) 0.0 % / 0.0 % 0.0 % / 0.0 %
qInstrucons for replacing lter Replace lter see page 11 Replace lter see page 11
r
Instrucons for the mounng of outside air
/ exhaust air grilles
(for one-direconal venlaon units)
― ―
sInstrucons for dismantling ― ―
t
Pressure uctuaon sensivity of the air
ow
(at +20 Pa and –20 Pa)
20 % / 23 % 20 % / 23 %
uAir ghtness between inside and outside 2.6 m³/h / 2.6 m³/h 2.6 m³/h / 2.6 m³/h
vAnnual power consumpon 1.427 kWh/a 1.067 kWh/a
w
Annual saving of heang energy
(according to climac zone warm / average
/ cold)
20.39 kWh/a
45.09 kWh/a
88.20 kWh/a
20.39 kWh/a
45.09 kWh/a
88.20 kWh/a

H47.WANS007EN-03 09.2023 19/20

AEROVITAL ambience AERO
17 
For our product AEROVITAL ambience, we conrm that the general safety of the dened product, in accordance
with Direcve 2001/95/EC, is compliant with the relevant protecon requirements which are laid down in the
Council Direcves about electrical and electronic products.
The following listed test standards, which are harmonised in the relevant direcves, have been employed for the
evaluaon:
 
EN 55014-1:2006+A1:2009+A2:2011
EN 55014-2:1997+A1:2001+A2:2008
EN 61000-3-2:2014
EN 61000-3-3:2013
 
EN 60335-1:2012+A11:2014
EN 62233:2008
 
c1) Electromagnec compability:
EN 301489-1, V.1.9.2
EN 301 489-17, V.2.2.1
EN 61000-3-2:2014
EN 61000-3-3:2013
c2) Electrical safety - Establishment of informaon technology
EN 60950-1:2006+A11:2009+A12:2011+A1:2010+A2:2013
c3) Safety of persons in electromagnec elds (10 MHz to 300 GHz)
EN 62479:2010
c4) Radio spectrum maers - data transmission devices in the 2.4 GHz ISM band
EN 300 328 V1.9.1
 
EN 12100:2010 Risk assessment
 2011/65/EU RoHs
EN 50581:2012 Technical documentaon on the evaluaon of electrical and electronic devices with
reference to the restricon of hazardous substances
This declaraon is responsible for the producers / importers based in the European Union submied by:
SIEGENIA-AUBI KG
Hardware and venlaon technology
Duisburger Straße 8
57234 Wilnsdorf, Germany
Siegen, 2017-03-30

H47.WANS007EN-03

