Siegenia AEROPAC User manual

Window systems
Door systems
Comfort systems
AERO
Wall mounted ventilator with noise absorbtion.
AEROPAC
ORIGINAL OPERATING
INSTRUCTIONS
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ

AEROPAC Original operating instructions
30 07.2019
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
Contents
1. Target group of this documentation...............................................................................................31
2. Intended use...................................................................................................................................31
3. Dimensions .....................................................................................................................................32
4. Safety notes....................................................................................................................................32
5. Scope of delivery / features ..........................................................................................................33
6. Installation ......................................................................................................................................34
7. Unit function....................................................................................................................................44
8. Operation.......................................................................................................................................44
9. Care and maintenance ..................................................................................................................47
10. Rectification of malfunctions........................................................................................................51
11. Accessories ..................................................................................................................................52
12. Technical specifications ...............................................................................................................52
13. Feedback on documentation.......................................................................................................53
14. EU Declaration of Conformity with regard to CE marking .........................................................54

Original operating instructions AEROPAC
07.2019 31
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
1. Target group of this documentation
• This documentation is intended for use by specialists and end users.
• All instructions concerning assembly, installation and repairs described in this document are to be
performed exclusively by electricians with training and practice in the installation, commissioning,
servicing and maintenance of decentralised ventilation units.
• All instructions on operation, care and maintenance as well as rectification of disturbance described
here are intended for specialists as well as end users.
• After the successful assembly and installation, the installation company is committed to handing over
the operating instructions to the end user.
2. Intended use
• Use the AEROPAC exclusively for the ventilation of closed rooms (kitchen, bathroom, living rooms
and bedrooms).
• The unit is not suitable for use in swimming pools and/or damp locations.
• Be sure to mount the supplied SIEGENIA weather grille for the protection of the unit from the outer
side.
• Do not install the unit in contaminated rooms and ensure that no hazardous substances can be
drawn in.
• If the unit is to be used in a room with a heating unit that draws air from the room, prior authorisation
must be obtained from the proper authorities, such as the officially appointed district chimney sweep.
• Observe appropriate possibilities such as adequately dimensioned overflow openings.
On request, we can send you notes regarding overflow (H45.WANS001INT).
• Only operate and/or store the AEROPAC at temperatures between -15°C and +40°C.
• Use the unit only with original accessories from SIEGENIA.
• The unit must always be installed by an experienced specialist, in accordance with the installation
and planning documents of SIEGENIA. The installation instructions in this document must be
complied with at all times.
• Observe the safety regulations for operating electrical equipment and, if necessary, for ladders,
steps and work overhead or at certain heights.
• Use the unit only when it is in a technically sound condition.
• Do not modify the unit's components in any way.
• Ensure that the device's ventilation openings are kept free and are not blocked by other equipment,
furniture or objects.
• Please do not put any objects on top of the unit.
• Please make sure that the unit is not locked via the lock for a longer period (several days) in order to
enable minimum ventilation and to prevent nesting of insects.
• At least one of the two ventilation openings must be open while the blower is switched on.

AEROPAC Original operating instructions
32 07.2019
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
• The unit must be checked by a specialist in the event of a fault.
3. Dimensions
• All the dimensions in this documentation are specified in mm.
4. Safety notes
• This unit can be used by children aged 8 and above as well as by people with physical, sensory or
mental difficulties or with a lack of experience and knowledge as long as they are supervised or
have been instructed in how to use the unit safely and understand the resulting risks. Children must
not play with the unit. Cleaning and user maintenance must not be carried out by children without
supervision.
• Electrically operated unit. Risk of fatal injury from electric shock or fire.
To prevent personal injury or damage to property, always comply with the following instructions:
- Insert the Euro mains plug of the standard connecting cable only into a suitable 230VAC mains
power supply socket.
- If the mains connection cable for the unit is damaged, it must be replaced by SIEGENIA, its
customer service department or an equally qualified person to eliminate hazards.
- Only a qualified electrician may perform any work on the 230V AC mains power supply that is
required in order to connect the unit.
- All-pole safety isolation is required if the customer is routing the mains cable.
- Current local regulations (such as those of the VDE in Germany) must be observed.
- Relevant country-specific regulations must be strictly followed for all work carried out on the
voltage supply system or house wiring system.
- Should a solid object or any liquid get inside the unit, stop operation immediately and
disconnect the unit from the mains power supply.
• Hazard due to third party attacks on SIEGENIA WLAN devices! Please observe the following notes
to protect your system against attacks by third parties:
- Every SIEGENIA WLAN device is protected by two passwords (user and administrator). It is
essential that you change these passwords after the initial setup. Do not leave in the default
setting.
- If the SIEGENIA WLAN devices are integrated in your home WLAN, this must be encrypted for
operation.
- Please choose secure passwords consisting of lower case and capital letters, numbers and
special symbols.

Original operating instructions AEROPAC
07.2019 33
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
5. Scope of delivery / features
Item Designation AEROPAC
DD SN smart
Scope of delivery
1AEROPAC wall-mounted ventilator with G3
dust filter
2Ventilation pipe Ø 80 mm, length 500 mm
3Weather grille
4Bag of screws
(2 screws, 2 dowels, 1 plug)
5Original operating instructions
6Drilling template
Unit properties
Sound absorption:
Low internal noise
Filters dust and exhaust fume odours
Adjustable airflow ( )
Blower —
Timer function —
Filter change indicator —
WLAN module for operation via SIEGE-
NIA Comfort app — —
1
3
4
5
6
2

AEROPAC Original operating instructions
34 07.2019
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
6. Installation
6.1 Installation requirements
• Suitable installation location:
- In the vicinity of a 230VAC power connection (unit's maximum cable length: 4.5m)
- When a permanent mains connection is used over a flush-mounted box
- Not in the immediate vicinity of radiator thermostats
• A smooth and even wall
• Ensure that no cables or pipes are routed inside the wall at the unit's designated position.
• Keep the unit free from dirt during installation and before start-up.
• To prevent damage to the high-quality surface of the unit, it is advisable to wear suitable gloves
during the installation.
6.2 Additional requirements for AEROPAC smart
• The AEROPAC smart should be installed to be as free from interference as possible.
The following interferences can have a negative influence on the WLAN signal:
- Water lines
- Stone and concrete walls
- Metal objects
- Air conditioning units
- Wireless devices (e. g. radio telephones, baby monitors, Bluetooth loudspeakers, etc.)
- WLAN networks on the same wireless channels (e. g. the neighbour's WLAN router)
• If energy-carrying cables are routed in parallel to data cables (ISDN, DSL, etc.), this could lead
to interference e.g. in the speed of the data transmission.

Original operating instructions AEROPAC
07.2019 35
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
6.3 Recommended unit position
min. 350 mm Max. 1000 mm
min. 300 mm

AEROPAC Original operating instructions
36 07.2019
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
6.4 Marking the holes and drilling the core
Risk of damage to property by drilling through concealed
cables or pipes!
›Before installing the unit, use a suitable cable and pipe detector at the installation location to
identify the presence of concealed cables or pipes in the wall (such as water pipes):
1. Use a water spirit level to align the drilling
template at a suitable position and attach
to the wall.
2. Mark two mounting holes and the core
mounting hole on the wall. If required,
mark an additional mounting drill hole (B)
that may be used to additionally secure
the unit. B
3. Drill core hole. Using a hammer drill at an
angle of approx. 2° to 5°, drill a hole
through to the outside wall.
Attention! If the AEROPAC is combined with
a vent duct, the corresponding assembly
instructions must be observed.
≥ Ø 82
2–5°

Original operating instructions AEROPAC
07.2019 37
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
6.5 Drilling the mounting holes and inserting the fixing screws
1. Drill the two marked mounting holes and, if
required, the additional mounting hole (B)
(all drilled holes should have a diameter of
8mm and be at least 45mm deep).
90°
B
2. Insert two dowels into the drill holes. If
necessary, insert a further dowel into the
additional mounting hole (B).
Note: Depending on the type of wall
(e.g. plasterboard), suitable dowels may
need to be provided by the customer for
inserting into the drill holes.
3. Screw two screws up to 8 mm in the
dowels.
B
8
6.6 Inserting the ventilation pipe into the core bore hole
1. Trim the pipe to wall thickness (dimension
X).
2. Slide the ventilation pipe into the core bore
hole (so that both ends are flush with the
wall).
X
X

AEROPAC Original operating instructions
38 07.2019
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
6.6.1 Recommendation for installation of the ventilation pipe
The connection joint between the ventilation pipe and the core bore hole must be properly sealed
inside the room and outside.
Please note the following:
• Ensure that the gap to be sealed is wide enough to allow for movement in the materials.
• Insulate the connection joint (heat insulation)
• Seal the connection joint on the outside so that it is resistant to driving rain
• Seal the connection joint inside the room so that it is air-tight
• The following principle applies: “Inside tighter than outside”
6.6.2 Thermal insulation
For gaps > 6 mm, it is essential that the insulation is free of voids and suitable insulating material is
used for all wall systems.
Clean the connection joints. Ensure that the holding surfaces are clean and free of grease. In
particular, remove any residues of insulating material.
Insert the insulating
material
Core drill hole
e. g. Ø 93
Gap width > 6
Ventilation
pipe Ø 80

Original operating instructions AEROPAC
07.2019 39
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
6.6.3 Sealing the ventilation pipe on the room side
To ensure that no warm and humid indoor air enters the outside wall, the connection joint inside the
room must be air-tight. We recommend the use of an acrylic sealing compound (observe the
manufacturer’s instructions).
1. Insert the separation
layer into the the gap.
2. Sealing the connection
joint:
Apply sealing com-
pound around the
connection joint of the
ventilation pipe.
Separation layer,
e.g. round cord
Sealing compound,
e.g. acrylic
6.6.4 Sealing the ventilation pipe on the outside
To prevent moisture from entering the outside wall, the exterior connection joint must be sealed all
round using a durable sealant (resistant to driving rain). We recommend the use of a silicone
sealing compound (observe the manufacturer’s instructions).

AEROPAC Original operating instructions
40 07.2019
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
6.7 Mounting the weather grille
1. Sealing the ventilation pipe on the outside.
Recommendation: To prevent three-point
adhesion from occurring, insert a
separating layer such as a round cord into
the gap.
2. Sealing the weather grille:
Apply the sealing compound (not
included in the delivery) around the
socket piece of the supplied weather
grille.
3. Insert the weather grille:
- The lamellae must point downwards
and should be horizontal.
- Push the weather grille socket piece
into the ventilation pipe.
- Press the weather grille firmly against
the wall so that the silicone is evenly
distributed and the ventilation pipe and
weather grille are properly sealed.

Original operating instructions AEROPAC
07.2019 41
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
6.8 Connecting the mains cable
6.8.1 Standard connection
• The length of the integrated mains cable is set at the factory to approx. 1.50m.
• The mains cable can be adapted to suit the local conditions (maximum cable length is approx.
4.5m).
1. Carefully lift the self-adhesive foam foil that
runs along the cable channel located on
the rear of the unit (on the left).
2. Pull the integrated mains cable out of the
guide groove and adapt to the required
dimension.
3. Afterwards, press the mains cable back
into the guide groove.
1.
2.
6.8.2 Permanent mains connection
Exposed electrical components.
Risk of fatal injury from electric shock or fire.
›Prior to installation, make sure that the power supply is disconnected.
1. Trim mains cable with a suitable tool
(e. g. a wire cutter).
2. Connect the integrated mains cable and
cable provided by the customer to one
another in a flush-mounted box (e.g. using
a lustre terminal).
Note: To ensure the mains cable is connected
properly, the unit’s cable storage compartment
should be positioned over the flush-mounted
box.
1.
2.
Integrated power
supply
Mains cable
provided by
the customer

AEROPAC Original operating instructions
42 07.2019
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
6.9 AEROPAC Fixing and connecting
1. Guide the mounting openings on the rear
of the unit over the fixing screws and push
the unit downwards.
2. Afterwards, check that the unit is secure.
3. Press the two markings on the top of the
front panel while pulling the panel towards
you. Pull out the front panel until you feel
some resistance.
4. Grip the bottom of the filter frame bar and
remove the frame from the holder.
5. Fold back the insulating mat inside.
6. Press the plug into the oblong hole until
you reach the stop.
7. Reassemble the unit in the reverse order.
8. Insert the Euro plug of the integrated mains
cable into a 230VAC socket.

Original operating instructions AEROPAC
07.2019 43
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
6.10 AEROPAC Additional securing (optional)
The AEROPAC can be secured with an additional screw (not included in the scope of delivery),
e. g. if the unit is to be turned by 180° and mounted:
• Drilling additional mounting holes with a drilling template:
Remove the unit from the wall and perform steps 6.4 + 6.5 (see pages 36 + 37).
• Drilling additional mounting holes without a drilling template:
Check that the unit is secure and perform the following steps:
1. Press the two markings on the top of the front
panel while pulling the panel towards you.
Pull out the front panel until you feel some
resistance.
2. Grip the bottom of the filter frame bar and
remove the frame from the holder.
3. Fold back the insulating mat inside.
4. Use a pointed object such as a scriber to
pierce the recess (Ø 8mm) in the rear panel
of the unit.
5. Detach the unit from the holder, drill the
additional hole for securing the unit (Ø
8mm) and insert a suitable dowel (not
included in the scope of delivery).
6. Guide the unit over the two fixing screws
again and check that the unit is secure.
7. Insert a suitable screw through the recess (in
the rear panel of the unit) into the dowel
and tighten.
8. Reassemble the unit in the reverse order.

AEROPAC Original operating instructions
44 07.2019
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
7. Unit function
The wall-mounted ventilators AEROPAC SN and AEROPAC smart uses an electrically operated
blower to quietly draw in fresh air from the outside and provide controlled and energy-efficient
filtered air inside.
When the blower is switched off, the unit equalises the pressure of the indoor and outdoor air to
allow fresh air from the outside to flow inside (pressure differential ventilation).
Various filters may be used, depending on the intended use:
G3 dust filter For coarse dust Included in scope of delivery
F5 dust filter For pollen/fine dust See accessories, page 52
Activated carbon filter E.g. exhaust fume odours See accessories, page 52
NOx-filter F7 nitrogen dioxide, fine dust,
pollen
See accessories, page 52
8. Operation
8.1 Operation by pressure
differential
When switched off, the AEROPAC functions as
a pressure differential ventilator and equalises
the pressure of the inside and outside air.
The sliders on the sides of the unit open and
close the air outlet and continuously adjust the
air flow.
Do not keep the slider closed for a longer
period (several days)
4 control buttons
with display
Slider or air
outlet
Air outlet

Original operating instructions AEROPAC
07.2019 45
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
8.2 Blower operation
In order for the blower to operate, the unit must be connected to the 230V mains power supply and
at least one of its side air openings must be open.
Switching the unit on and off
The on and off buttons are used to switch the
unit on or off respectively.
Setting the blower levels
The unit always starts with the last blower level
that was set. The blower level can be changed
at any time.
• Press button +once: Blower level increases
(the unit reacts on a delay).
• Press button -once: Blower level is reduced.
• Recommended blower level for when one
person is in the room: 30 m3/h
• Recommended blower level for when two
people are in the room: 60 m3/h
• Maximum blower level: 180 m3/h (max.
indicator flashes)
8.3 Operation via smartphone or tablet
The AEROPAC smart can be controlled by a tablet or smartphone.
Please follow the enclosed quick start instructions (H47.MOTS005EN).
Overview of the device functions
• Control of the blower performance
• Timer can be programmed
• Filter change indicator and reset of the filter change indicator (after filter has been replaced)
Blower
level

AEROPAC Original operating instructions
46 07.2019
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
8.4 Timer function
The Timer button is used to activate/deactivate the timer function. When the timer is activated, the
timer starts the unit for a preset run time (in hours). This is preset at the factory to 8 hours.
The blower automatically switches off after the running time has elapsed.
24 hours after the timer has been activated, the unit restarts automatically with the settings that were
last selected. This procedure is repeated cyclically every 24 hours.
The function ends when the timer is switched off.
Note: After a power failure, the timer must be reactivated.
Setting the timer
The timer running time may be set to a value between 1 and 18 hours and can be changed at any
time
1. Press the Timer button 1x (pressing the
button again ends the timer function).
2. Adjustment of the running time:
- To shorten the running time, press the
–button immediately.
- To extend the running time, press the +
button immediately.
Note: The display lights up briefly, the clock
symbol flashes, and the set blower level plus
the running time in hours are displayed
Note: Approx. 5 seconds after the running
time has been set, the display changes to show
the remaining run time.
• Remaining running time: 5:59 hours (set
running time: 6:00 hours)

Original operating instructions AEROPAC
07.2019 47
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
9. Care and maintenance
Electrically operated unit.
Risk of fatal injury from electric shock or fire.
To prevent personal injury or damage to property, always comply with the
following instructions:
›Pull the mains plug out of the socket prior to every cleaning process or maintenance work.
Never pull at the cable to disconnect the device from the mains power supply.
›For all devices with a fixed connection to the 230 V AC mains power supply, switch off all poles
of the feeder. The fuses may need to be removed.
9.1 Cleaning
Important: When cleaning the AEROPAC, do not allow liquids to get inside the unit.
• Never use cleaning agents that are aggressive or contain solvents, or sharp-edged objects, as these
may damage the surfaces of the casing.
• Never clean the unit with a high-pressure cleaner or steam-jet cleaner.
• Clean the AEROPAC with a cloth moistened with a mild soap solution or cleaning agent.
• Always clean the G3 dust filter manually (e.g. with a vacuum cleaner, wash out using a grease-dis-
solving cleaning agent). Do not wash the filter in a washing machine!

AEROPAC Original operating instructions
48 07.2019
DEUTSCH ENGLISH FRANÇAIS ITALIANO NEDERLANDS POLSKI РУССКИЙ
9.2 Replacing the filter
The filter must be replaced when the air
throughput starts to diminish. The L filter
change indicator appears on the display after
an operation period of six months.
Note: Filters for various uses can be found in
the chapter Accessories (page 52).
9.2.1 Filter installation and dismounting
1. Switch off the unit. Press the two markings
on the top of the front panel while pulling
the panel towards you.
2. Grip the bottom of the filter frame bar and
remove the frame from the holder.
3. Remove the filter from the frame and insert
a new filter.
Note: Insert the F5 filter so that its smooth
surface is facing the holding bar.
4. Push the filter frame back into the holder
and close the front panel until it locks into
place.
5. Press the –button for approx. 5 seconds
until the Lfilter change indicator disappe-
ars.
3. 5.
