Siemens A80485-1 User manual

PRINTED IN U.S.A.
QUICK START GUIDE
SIEMENS A80485-1 GCP DISPLAY MODULE
CONFIGURATION AND OPERATION
DECEMBER 2017
DOCUMENT NO. SIG-QG-17-05
VERSION A
Siemens Industry, Inc. Rail Automation
700 East Waterfront Drive
Munhall, PA 15120, USA
1-800-793-SAFE
Copyright © 2017 Siemens Industry, Inc.
All rights reserved

ii
SIG-QG-17-05 DECEMBER 2017
Version No.: A
PROPRIETARY INFORMATION
Siemens Industry, Inc. has a proprietary interest in the information contained herein and, in some
instances, has patent rights in the systems and components described. It is requested that you
distribute this information only to those responsible people within your organization who have an
official interest.
This document or the information disclosed herein, shall not be reproduced or transferred to other
documents or used or disclosed for manufacturing or for any other purpose except as specifically
authorized in writing by Siemens Industry, Inc.
TRANSLATIONS
The manuals and product information of Siemens Industry, Inc. are intended to be produced and
read in English. Any translation of the manuals and product information are unofficial and can be
imprecise and inaccurate in whole or in part. Siemens Industry, Inc. does not warrant the
accuracy, reliability, or timeliness of any information contained in any translation of manual or
product information from its original official released version in English and shall not be liable for
any losses caused by such reliance on the accuracy, reliability, or timeliness of such information.
Any person or entity that relies on translated information does so at his or her own risk.
WARRANTY INFORMATION
Siemens Industry, Inc. warranty policy is as stated in the current Terms and Conditions of Sale
document. Warranty adjustments will not be allowed for products or components which have
been subjected to abuse, alteration, improper handling or installation, or which have not been
operated in accordance with Seller's instructions. Alteration or removal of any serial number or
identification mark voids the warranty.
SALES AND SERVICE LOCATIONS
Technical assistance and sales information on Siemens Industry, Inc. products may be obtained
at the following locations:
SIEMENS INDUSTRY, INC. RAIL AUTOMATION
SIEMENS INDUSTRY, INC.RAIL AUTOMATION
2400 NELSON MILLER PARKWAY
939 S. MAIN STREET
LOUISVILLE, KENTUCKY 40223
MARION, KENTUCKY 42064
TELEPHONE:
[phone]
TELEPHONE:
[phone]
FAX:
[phone]
CUSTOMER SERVICE:
[phone]
SALES & SERVICE:
[phone]
TECHNICAL SUPPORT:
[phone]
WEB SITE:
USA Rail Automation Site
FAX:
[phone]
FCC RULES COMPLIANCE
The equipment covered in this manual has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the
interference at his/her own expense.

iii
SIG-QG-17-05 DECEMBER 2017
Version No.: A
DOCUMENT HISTORY
Version
Release
Date
Sections
Changed
Details of Change
A
DEC 2017
----
Initial Release

iv
SIG-QG-17-05 DECEMBER 2017
Version No.: A
Table of Contents
Section Title Page
PROPRIETARY INFORMATION.................................................................................................................. ii
TRANSLATIONS........................................................................................................................................... ii
WARRANTY INFORMATION ....................................................................................................................... ii
SALES AND SERVICE LOCATIONS ........................................................................................................... ii
FCC RULES COMPLIANCE......................................................................................................................... ii
DOCUMENT HISTORY ................................................................................................................................iii
NOTES, CAUTIONS, AND WARNINGS...................................................................................................... vi
ELECTROSTATIC DISCHARGE (ESD) PRECAUTIONS...........................................................................vii
GLOSSARY ................................................................................................................................................viii
SECTION 1 - INTRODUCTION .................................................................................................................1-1
1.0 INTRODUCTION.............................................................................................................................1-1
1.1 GCP DISPLAY MODULE ............................................................................................................1-1
1.1.1 GCP Display Module Controls, Indicators, Connectors, and Display..........................1-2
1.2 RESOURCE DOCUMENTS........................................................................................................1-4
SECTION 2 - CONFIGURATION...............................................................................................................1-1
2.0 CONFIGURATION..........................................................................................................................2-1
2.1 DISPLAY MODULE MAIN SCREENS ........................................................................................2-1
2.2 KEYPAD/NAVIGATION CLUSTER.............................................................................................2-2
2.2.1 Keypad and Navigation Cluster Operation..................................................................2-2
2.3 SERIAL PORT.............................................................................................................................2-3
2.3.1 Configuring the Serial Port...........................................................................................2-3
2.4 ETHERNET PORTS....................................................................................................................2-4
2.4.1 Ethernet Port Configuration.........................................................................................2-4
2.4.1.1 Server Mode ................................................................................................................2-5
2.4.1.2 Client Mode..................................................................................................................2-5
2.4.1.3 Disabled Mode.............................................................................................................2-5
2.4.1.4 Laptop Ethernet Port Setup.........................................................................................2-5
2.4.1.5 Ethernet Ports 1 and 2 Setup ......................................................................................2-7
2.4.1.6 DNS (Domain Name System) Setup ...........................................................................2-8
2.4.1.7 Ethernet Port Status ....................................................................................................2-8
2.4.2 Display Options Settings..............................................................................................2-8
SECTION 3 - OPERATION........................................................................................................................2-1
3.0 OPERATION...................................................................................................................................3-1
3.1 DISPLAY MODULE LAPTOP INTERFACE................................................................................3-1
3.1.1 Display Module to Laptop Connection.........................................................................3-1

v
SIG-QG-17-05 DECEMBER 2017
Version No.: A
3.2 USB OPERATION.......................................................................................................................3-2
3.2.1 USB Drive File Structure..............................................................................................3-2
3.2.2 USB Menu ...................................................................................................................3-3
3.2.3 USB Detection.............................................................................................................3-3
3.2.4 USB Menu ...................................................................................................................3-4
3.3 MODULE SOFTWARE UPDATES..............................................................................................3-5
3.4 DISPLAY MODULE POWERED ETHERNET PORT..................................................................3-5
3.4.1 Display Module to Ethernet 1 Port Power-Over-Ethernet (POE) Device Connection 3-6
3.5 ETHERNET NETWORK CONNECTION ....................................................................................3-7
List of Figures
Section Title Page
Figure 1-1 A80485 Siemens Display Module...........................................................................................1-1
Figure 1-2 A80485 GCP Display Module Controls, Indicators, and Display............................................1-2
Figure 2-1 GCP4000 and GCP5000 Main Screens.................................................................................2-1
Figure 2-2 GCP3000+ Main Screens.......................................................................................................2-1
Figure 2-3 Keypad, and Navigation Cluster Keys....................................................................................2-2
Figure 2-4 Keypad Operation...................................................................................................................2-2
Figure 2-5 Navigation Key Cluster...........................................................................................................2-2
Figure 3-1 Display Module to Laptop Connection....................................................................................3-1
Figure 3-2 Inserting a USB Drive.............................................................................................................3-3
Figure 3-3 USB Detected Screen ............................................................................................................3-3
Figure 3-4 USB Menu Screens GCP4000 and GCP5000.......................................................................3-4
Figure 3-5 USB Menu Screens GCP3000+.............................................................................................3-4
Figure 3-6 Display Module to GCP Module Serial Cable Connection .....................................................3-5
Figure 3-7 Display Module to Ethernet Power-Over-Ethernet Device Connection..................................3-6
Figure 3-8 Display Module to Ethernet Network Connection...................................................................3-7
List of Tables
Section Title Page
Table 1-1 Display Module Controls, Indicators, Connectors, and Display Descriptions..........................1-3
Table 1-2 Resource Documents..............................................................................................................1-4

vi
SIG-QG-17-05 DECEMBER 2017
Version No.: A
NOTES, CAUTIONS, AND WARNINGS
Throughout this manual, notes, cautions, and warnings are frequently used to direct the reader’s
attention to specific information. Use of the three terms is defined as follows:
WARNING
INDICATES A POTENTIALLY HAZARDOUS SITUATION WHICH,
IF NOT AVOIDED, COULD RESULT IN DEATH OR SERIOUS
INJURY. WARNINGS ALWAYS TAKE PRECE
DENCE OVER
NOTES, CAUTIONS, AND ALL OTHER INFORMATION.
CAUTION
REFERS TO PROPER PROCEDURES OR PRACTICES WHICH IF
NOT STRICTLY OBSERVED, COULD RESULT IN A POTENTIALLY
HAZARDOUS SITUATION AND/OR POSSIBLE DAMAGE TO
EQUIPMENT. CAUTIONS TAKE PRECEDENCE OVER NOTES
AND ALL OTHER INFORMATION, EXCEPT WARNINGS.
NOTE
Generally used to highlight certain information relating to the topic
under discussion.
If there are any questions, contact Siemens Industry, Inc. Application Engineering.

vii
SIG-QG-17-05 DECEMBER 2017
Version No.: A
ELECTROSTATIC DISCHARGE (ESD) PRECAUTIONS
Static electricity can damage electronic circuitry, particularly low voltage components such as the
integrated circuits commonly used throughout the electronics industry. Therefore, procedures
have been adopted industry-wide which make it possible to avoid the sometimes invisible
damage caused by electrostatic discharge (ESD) during the handling, shipping, and storage of
electronic modules and components. Siemens Industry, Inc. has instituted these practices at its
manufacturing facility and encourages its customers to adopt them as well to lessen the likelihood
of equipment damage in the field due to ESD. Some of the basic protective practices include the
following:
•Ground yourself before touching card cages, assemblies, modules, or components.
•Remove power from card cages and assemblies before removing or installing modules.
•Remove circuit boards (modules) from card cages by the ejector lever only. If an ejector lever is not
provided, grasp the edge of the circuit board but avoid touching circuit traces or components.
•Handle circuit boards by the edges only.
•Never physically touch circuit board or connector contact fingers or allow these fingers to come in
contact with an insulator (e.g., plastic, rubber, etc.).
•When not in use, place circuit boards in approved static-shielding bags, contact fingers first. Remove
circuit boards from static-shielding bags by grasping the ejector lever or the edge of the board
only. Each bag should include a caution label on the outside indicating static-sensitive contents.
•Cover workbench surfaces used for repair of electronic equipment with static dissipative workbench
matting.
•Use integrated circuit extractor/inserter tools designed to remove and install electrostatic-sensitive
integrated circuit devices such as PROM’s (OK Industries, Inc., Model EX-2 Extractor and Model
MOS-40 Inserter (or equivalent) are highly recommended).
•Utilize only anti-static cushioning material in equipment shipping and storage containers.
For information concerning ESD material applications, please contact the Technical Support Staff
at 1-800-793-7233. ESD Awareness Classes and additional ESD product information are also
available through the Technical Support Staff.

viii
SIG-QG-17-05 DECEMBER 2017
Version No.: A
GLOSSARY
TERM
DESCRIPTION
AAR:
Association of American Railroads – An organization that establishes
uniformity and standardization among different railroad systems.
AREMA:
American Railway Engineering and Maintenance-of-way Association
DIAG.:
Diagnostic
DNS:
Domain Name Server
GCP: Grade Crossing Predictor – A train detection device used as part of a
highway-railroad grade crossing warning system to provide a relatively
uniform warning time.
GPS: Global Positioning System.
IP: Internet Protocol - ISO Model Layer 3 (network) protocol that performs
proper routing of packets.
LAN: Local Area Network – A limited network where the data transfer medium
is generally wires or cable.
LED: Light-Emitting-Diode - A solid-state indicator.
Module: Physical package including PCBs and input/output terminals for
connecting to external devices and equipment.
RJ-45: Industry standard Ethernet port
RS232: Industry standard serial port.
RX: Receive
RXD: Receive Data
TX: Transmit
TXD: Transmit Data
USB Port: Universal Serial Bus Port
USB Drive: Types of memory devices that plug into a USB port. These devices are
commonly called flash drives or memory sticks.

INTRODUCTION
_________________________________________________________________________________________________________
1-1
SIG-QG-17-05 DECEMBER 2017
Version No.: A
SECTION 1 - INTRODUCTION
1.0 INTRODUCTION
The purpose of this quick start guide is to introduce GCP Users to the Siemens Next-Generation
Display module, A80485-1, used on the GCP3000+, GCP4000, and GCP5000. The scope of
this guide encompasses the location and operation of the display controls, indicators, and
connectors as well as addressing the initial user-configurable port parameters to enable
connection to external devices, such as a laptop, external network, or Ethernet powered
devices.
1.1 GCP DISPLAY MODULE
The Siemens A80485-1 Display Module is the next generation display module replacing the
A80407 Display Module, offering enhanced features and improved speed and responsiveness.
A restructured menu reduces programming and maintenance time in the field. The addition of
two Ethernet ports offers connectivity to a network or Ethernet devices. A powered Ethernet port
is available for devices deriving their power from an Ethernet connection. The Laptop port
enables the user to connect a laptop computer to the display to configure parameters, update
software, and download logs. The display screen and keypad provide a local user interface,
allowing operation without the need of a computer.
Figure 1-1 A80485 Siemens Display Module

INTRODUCTION
_________________________________________________________________________________________________________
1-2
SIG-QG-17-05 DECEMBER 2017
Version No.: A
1.1.1 GCP Display Module Controls, Indicators, Connectors, and Display
The GCP Display module controls, indicators, connectors, and display are shown in Figure 1-2
and described in Table 1-1.
Figure 1-2 A80485 GCP Display Module Controls, Indicators, and Display
(M9)
1
Symbol
2
ABC
3
DEF
4
GHI
5
JKL
6
MNO
7
PQRS
8
TUV
9
WXYZ
HELP
0
Space BACK
ENTER
USB LAPTOP
DIAG
CPU SEAR
TX RX POWER TX RX
DISPLAY
Module
A80485-2
COM
TX RX
ECHELON
ETHERNET 2ETHERNET 1
ETH
PWR
ESSR
Powered
Ethernet Port
Keypad
Navigation
Keys
USB Port
Ethernet Port
(Unpowered)
Laptop
Ethernet Port
Display
Echelon®
TX RX LEDS
SEAR
TX RX
LEDS
COM
TX RX LEDS
CPU
TX RX
LEDS
Power LED
Diagnostic
(Diag) Port

INTRODUCTION
_________________________________________________________________________________________________________
1-3
SIG-QG-17-05 DECEMBER 2017
Version No.: A
Table 1-1 Display Module Controls, Indicators, Connectors, and Display Descriptions
ITEM
DESCRIPTION
DISPLAY
2 ½ x 4 inch OLED Color Display
CONTROLS
Keypad
12-key membrane keypad
Navigation
5-key membrane navigational cluster
INDICATORS
Power
LED (Green)
CPU TX/RX
CPU data stream indicators
TX LED (Green) RX LED (Yellow)
COM TX/RX
Communications data stream indicators
TX LED (Green) RX LED (Yellow)
SEAR TX/RX
SEAR data stream indicators
TX LED (Green) RX LED (Yellow)
Echelon®LAN
Echelon®LAN data indicators
TX LED (Green) RX LED (Yellow)
Ethernet 1 (powered)1
Ethernet Power indicator LED (Green)
Ethernet 1 data indicators (embedded in connector)
Data:TX LED (Green) RX LED (Yellow)
Ethernet 21
Ethernet 2 data indicators (embedded in connector)
TX LED (Green) RX LED (Yellow)
CONNECTORS
Ethernet 11
RJ-45 powered connector (See note)
Ethernet 21
RJ-45 connector
Diag (Diagnostics)
DB-9, Female Serial connector, RS-232
USB
USB 2.0 Type A connector
Laptop
RJ-45 connector
1 Ethernet 1 and Ethernet 2 ports are not available on the GCP4000, therefore these ports on
the Display module are not useable.
NOTE
The Ethernet 1 powered connector is designed specifically for
Siemens Ethernet Spread Spectrum Radios and may not power other
Power-Over-Ethernet (POE) devices.

INTRODUCTION
_________________________________________________________________________________________________________
1-4
SIG-QG-17-05 DECEMBER 2017
Version No.: A
1.2 RESOURCE DOCUMENTS
The GCP manuals and guidelines listed in Table 1-2 will provide complete and detailed
information for the configuration and operation of your GCP unit. This quick start guide is a
supplemental document to be used in concert with the product manuals listed in Table 1-2.
Table 1-2 Resource Documents
DOCUMENT NUMBER
TITLE
SIG-00-17-03
GCP 3000+ Installation & Instruction
SIG-00-17-04
GCP 3000+ Application Guidelines
SIG-00-08-06
GCP 4000 Application Guidelines
SIG-00-08-10
GCP 4000 Field Manual
SIG-00-10-05
GCE 4000 Application Guidelines
SIG-00-12-68
GCP 4000 Plus Field Manual
SIG-00-13-03
GCP 5000 Field Manual
SIG-00-13-04
GCP 5000 Application Guidelines
SIG-00-15-05
CPU III for GCP

CONFIGURATION
_________________________________________________________________________________________________________
2-1
SIG-QG-17-05 DECEMBER 2017
Version No.: A
SECTION 2 - CONFIGURATION
2.0 CONFIGURATION
The GCP Display module default settings will normally suffice for the majority of GCP
installations. This section will show some of the initial display programming options to enable
the user to customize the display serial and Ethernet ports.
2.1 DISPLAY MODULE MAIN SCREENS
The display module main screens serve as the starting point for setup and operation of the GCP
system. The main screens for the GCP4000 and GCP5000 are shown in Figure 2-1 and the
main screens for the GCP3000+ are shown in Figure 2-2.
Figure 2-1 GCP4000 and GCP5000 Main Screens
Figure 2-2 GCP3000+ Main Screens

CONFIGURATION
_________________________________________________________________________________________________________
2-2
SIG-QG-17-05 DECEMBER 2017
Version No.: A
2.2 KEYPAD/NAVIGATION CLUSTER
The Keypad and Navigation Cluster shown in Figure 2-3 is the local user interface to enter data
and navigate through the display menu structure. The BACK key returns to one of the main
screens. The HELP key will bring up Help screens to assist the user with hints and additional
information when available.
Figure 2-3 Keypad, and Navigation Cluster Keys
2.2.1 Keypad and Navigation Cluster Operation
The Display module keypad allows the user to select menus or enter data. Press the desired
key multiple times to select a letter, number, or symbol. Figure 2-4 lists the alpha-numeric
sequence of each key. The HELP key brings up a dialog box with instructions or information in
some of the menus. The BACK key returns to one of the four main screens.
Figure 2-4 Keypad Operation
The Navigation Key Cluster shown in Figure 2-5 is used to navigate through menus and text.
The ENTER key completes the transaction.
Figure 2-5 Navigation Key Cluster
1
Symbol
2
ABC
3
DEF
4
GHI
5
JKL
6
MNO
7
PQRS
8
TUV
9
WXYZ
HELP
0
Space BACK
1
Symbol
2
ABC
3
DEF
4
GHI
5
JKL
6
MNO
7
PQRS
8
TUV
9
WXYZ
HELP
0
Space BACK
ENTER
ECHELON
Navigation Keys
Keypad
Enter Key
Back Key
Help Key

CONFIGURATION
_________________________________________________________________________________________________________
2-3
SIG-QG-17-05 DECEMBER 2017
Version No.: A
NOTE
Display screens vary between GCP models and unit configuration.
The following screen examples in this quick start guide are shown for
general reference purposes. Refer to the applicable manual listed in
Section 1.2 for the screens used by your GCP model.
2.3 SERIAL PORT
The GCP Display has a serial port (Diag) used for diagnostic functions and transferring software
updates to other modules in the GCP case. The serial port default settings are used for
transferring software and therefore no serial port configuration is necessary.
2.3.1 Configuring the Serial Port
Should the user desire to change serial port settings, use the following procedure:
1. Navigate to the Program View screen using the left/right navigation keys.
2. Select Display Programming (press the 4 key or use the navigation keys to select Display
Programming and then press the ENTER key).
3. From the Display screen, select Serial Port (press the 1 key or use the navigation keys and
select Serial Port and then press the ENTER key).
2
3
1

CONFIGURATION
_________________________________________________________________________________________________________
2-4
SIG-QG-17-05 DECEMBER 2017
Version No.: A
4. From the Serial Port screen, press the ENTER key to bring up the serial port parameters
screen.
5. Set the serial port parameters as required using the keypad and navigation keys.
2.4 ETHERNET PORTS
The GCP Display has three Ethernet ports: Laptop port, Ethernet 1 (powered), and Ethernet 2
(unpowered). The setting options for these ports are:
Laptop Port
Server*
Client
Disabled
Ethernet 1 and 2 Ports
Disabled*
Client
* Denotes default setting
NOTE
The Ethernet 1 powered connector is designed specifically for
Siemens Ethernet Spread Spectrum Radios and may not power other
Power-Over-Ethernet (POE) devices.
2.4.1 Ethernet Port Configuration
The Laptop Ethernet port has three modes: Server, Client, and Disabled. The Ethernet 1 and
Ethernet 2 ports have two modes: Disabled and Client. Ethernet ports 1 and 2 also have
additional parameters for Path Type and Protocol, which are used in conjunction with PTC and
ATCS Back Office communications. Consult the GCP manual for details and information on
these settings.
4
5

CONFIGURATION
_________________________________________________________________________________________________________
2-5
SIG-QG-17-05 DECEMBER 2017
Version No.: A
2.4.1.1 Server Mode
The Server mode is only available on the Laptop port. When connecting a laptop to the display
module, set the laptop’s Ethernet DHCP as a client. The display module, acting as a DHCP
server, will assign an IP address to the laptop and establish communications.
WARNING
DO NOT CONNECT A NETWORK TO THE LAPTOP ETHERNET
PORT IF THE PORT HA
S BEEN CONFIGURED AS A SERVER
(NOTE THIS IS THE DEFAULT SETTING), THIS WILL CAUSE
DISRUPTION TO THE NETWORK. IF A NETWORK IS TO BE
CONNECTED TO THE LAPTOP PORT, CONFIGURE THE
LAPTOP PORT DHCP AS A CLIENT.
2.4.1.2 Client Mode
The Client mode is available on all three Ethernet ports. In the Client mode, the Display
Ethernet port will be assigned an IP address from the external network server.
2.4.1.3 Disabled Mode
The Disabled mode shuts off the Ethernet port. Ethernet ports 1 and 2 default setting is the
disabled mode, these ports may be configured as clients for use on a network and/or external
Ethernet devices.
2.4.1.4 Laptop Ethernet Port Setup
If the user desires to change the DHCP setup of the Laptop port, use the following procedure:
1. From the Display screen (see section 2.3.1 on how to navigate to the Display screen), select
Ethernet Ports (press 2 on the keypad or use the navigation keys and select Ethernet Ports
then press the ENTER key).
2. Select Laptop (press 1 on the keypad or use the navigation keys and select Laptop and press
the ENTER key).
NOTE
On the GCP4000, Ethernet Ports 1 & 2 are disabled and will not be
visible on the screen.
1
2

CONFIGURATION
_________________________________________________________________________________________________________
2-6
SIG-QG-17-05 DECEMBER 2017
Version No.: A
3. The Laptop DHCP Configuration default setting is Server. To Configure the port to either a
client mode or to disable the port, press the ENTER key.
4. From the DHCP Configuration screen, select the desired mode using the navigation keys and
press the ENTER key.
NOTE
For Laptop operation it is recommended to use the Server mode and
setting the laptop DHCP to Client.
5. In the Server mode the IP Address and Network Mask are pre-assigned from the factory and
cannot be changed.
Server
3
4
OR
Server *
5

CONFIGURATION
_________________________________________________________________________________________________________
2-7
SIG-QG-17-05 DECEMBER 2017
Version No.: A
2.4.1.5 Ethernet Ports 1 and 2 Setup (GCP3000+ and GCP5000 only)
Ethernet ports 1 and 2 have two modes available, Disabled and Client. The default setting is
disabled. To reconfigure the Ethernet 1 or 2 ports, use the following procedure:
1. From the Program View main screen, select Display Programming (press 4 on the keypad or
use the navigation keys and select Display Programming, then press the ENTER key).
2. From the Display screen, select Ethernet Ports (press 2 on the keypad or use the navigation
keys and select Ethernet Ports and press the ENTER key).
3. From the Ethernet Ports screen, select either Port 1 or Port 2 (press 2 or 3 on the keypad or
use the navigation keys and select Port 1 or Port 2, then press the ENTER key).
4. Highlight the DHCP Configuration text and press the ENTER key.
5. Select the desired mode, Disabled or Client, (highlight using the navigation keys and press
the ENTER key).
6. The port is now set; refer to the GCP manual for further configuration of Path Type or
Protocol.
4
5
3
6
2
1

CONFIGURATION
_________________________________________________________________________________________________________
2-8
SIG-QG-17-05 DECEMBER 2017
Version No.: A
2.4.1.6 DNS (Domain Name System) Setup
The Display DNS setup has three default server addresses. The user can reconfigure up to
three of these addresses to match their network operations. Refer to the GCP manual for further
instructions on setting DNS servers.
2.4.1.7 Ethernet Port Status
The status of the Display module Ethernet ports can be viewed by selecting the Status tab on
the Laptop, Ethernet 1 or Ethernet 2 screen. The status of all three ports can be viewed
regardless of which Ethernet port screen is selected.
2.4.2 Display Options Settings
The Display Options not covered in this quick guide are detailed in the product manual for your
specific GCP model. See Table 1-2.
Server
