SIMATIC
PCS 7 process control system
CPU 410 Process Automation/CPU
410 SMART
System Manual
05/2017
A5E31622160
-AC
Preface
1
Introduction to the CPU 410
2
Configuration of the CPU
410
3
PROFIBUS DP
4
PROFINET IO
5
I/O configuration variants
6
System and operating states
of the CPU 410
7
Link-up and update
8
Special functions of the CPU
410
9
Time synchronization and
time stamping
10
Plant changes in RUN - CiR
11
Plant changes during
redundant operation - H-CiR
12
Replacement of failed
components during
redundant operation
13
Synchronization modules
14
System expansion card
15
Technical data
16
Properties and technical
specifications of CPU 410
SMART
17
Supplementary information
18
Characteristic values of
redundant automation
systems
A
Function and communication
modules that can be used in
a redundant configuration
B
Connection examples for
redundant I/Os
C

Siemens AG
Division Process Industries
and Drives
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E31622160-AC
Ⓟ
06/2017 Subject to change
Copyright © Siemens AG 2017.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

CPU 410 Process Automation/CPU 410 SMART
System Manual, 05/2017, A5E31622160-AC 3
