This document describes the preconditions when testing drives. The fulfillment of these
preconditions is the basis for achieving the smoothest possible testing process and maximum
possible customer satisfaction.
The following drive tests are described:
● Routine tests
● Tests that are offered as standard
Note
If the scope of testing and inspection cannot fulfill all customer requirements, please consult
your Siemens sales advisor at head office.
SINAMICS DCM 6RN F03
Reference Manual Rev.201902141527 SINAMICS DCM 7

Introduction
SINAMICS DCM 6RN F03
8Reference Manual Rev.201902141527 SINAMICS DCM

General scope of services 2
A variable-speed drive can include the following components:
● Induction motor, synchronous motor or PEM motor with or without speed encoder
● SINAMICS drives
● Drive transformer
● Cooling unit for water-cooled drives
● Small PLCs with drive functionality.
The Nuremberg Vogelweiherstrasse factory offers test equipment adapted to these types of
systems.
Note
Contact your sales person if additional components must be taken into account for your
particular project.
Scope of services offered
Unless otherwise stated in the quotation, the scope of services includes all activities,
equipment, materials and expendables required to perform the specified tests. The deadline
and testing period stated, and the quoted cost, can be met only if all the test and inspection
procedures to be performed are clarified in detail in advance. Due to the high capacity utilization
of the associated equipment, it might not be possible to carry out individual inspections and
tests that are requested late if the planned test is already in progress.
If you have received specific requirements from your customer, please send these as soon as
possible – with the necessary key data – to the Nuremberg Vogelweiherstrasse factory.
Sequence of a customer acceptance
A customer acceptance test is generally executed in the sequence:
1. Installation and commissioning of the components before the customer arrives.
2. Kickoff with presentation of the test schedule and discussion of individual steps in the
acceptance test workflow.
3. Execution of the tests according to the test schedule
4. Discussion of the test results
5. Preparation of test documentation for the customer.
The test documentation is created before or after the customer leaves depending on the
scope of testing and the time schedule.
SINAMICS DCM 6RN F03
Reference Manual Rev.201902141527 SINAMICS DCM 9

Components provided by customer
Components provided by the customer must be available in plenty of time so that tests can be
carried out on time. The Nuremberg Vogelweiherstrasse factory has no access to components
that are not within the PD LD scope of supply. This also applies to components ordered from
other Siemens' Groups. The technical data for these components is required at the latest eight
weeks before the start of the acceptance test, e.g.:
● Dimensions
● Weights
● Energy Requirement
● Interfaces
Location of the customer acceptance
All customer acceptance tests in the test fields for drives are performed as part of the
manufacturing process.
Note
Limited number of persons in the test field
For safety reasons, the number of persons in the test field is limited. In addition to the regional
sales partner, only two persons from the customer are permitted in the test field at the same
time.
Note
Test without load motors or multipulse infeeds via transformers in the test field
Some tests are simulated or performed in test mode with limited rated data.
Note
Tests with the customer's own cooling units or excitation equipment
If the customer's own cooling units or excitation equipment are to be tested, a system test can
be ordered with option F97.
General scope of services
SINAMICS DCM 6RN F03
10 Reference Manual Rev.201902141527 SINAMICS DCM

2.1 Routine test
During production, the drive is subject to an internal routine test.
General scope of services
2.1 Routine test
SINAMICS DCM 6RN F03
Reference Manual Rev.201902141527 SINAMICS DCM 11

2.2 Visual inspection
The visual inspection is performed to ensure that the equipment complies with the order
specifications. The tests are carried out with the drive in a no-voltage condition.
The visual inspection together with the customer – or with the company accepting the
equipment – is carried out with the drive installed and labeled. Each test step is documented in
the acceptance report with the specific results of the step.
The visual inspection is part of the function test (F72, F73).
Visual inspection Order codes
Without the
customer
present
With the cus‐
tomer
present
● Rating plate
● Housing degree of protection
● Electrical cabinet components
● Cable installation
● Cable markings
● Setting values of circuit breakers, if used
● Dimensions
- F03
See also
Visual inspection (Page 16)
General scope of services
2.2 Visual inspection
SINAMICS DCM 6RN F03
12 Reference Manual Rev.201902141527 SINAMICS DCM

2.3 Function tests
The drive functions are tested according to IEC 61800-5-1. In addition, excerpts from additional
standards apply, which are listed in the relevant chapters as well as internal Siemens directives
within the scope of quality assurance.
The function tests are performed and documented in the Siemens test field by internal test field
personnel. For the function test, the drive is in the test mode with restricted monitoring functions.
The successful test is confirmed in a 3.1 certificate – or in the case that the customer has
ordered the acceptance test, in a 3.2 certificate.
See also
Function test (Page 20)
General scope of services
2.3 Function tests
SINAMICS DCM 6RN F03
Reference Manual Rev.201902141527 SINAMICS DCM 13

2.4 Insulation test
The insulation resistance is measured before and after the high-voltage test. The insulation test
can only be ordered and carried out together with the function test (F72, F73).
Insulation test Order codes
Without the
customer
present
With the cus‐
tomer
present
● High-voltage test
● Measuring the insulation resistance
F76 F77
The successful test is confirmed in a 3.1 certificate – or in the case that the customer has
ordered the acceptance test, in a 3.2 certificate.
The insulation test is performed on a separate acceptance day prior to the function test.
General scope of services
2.4 Insulation test
SINAMICS DCM 6RN F03
14 Reference Manual Rev.201902141527 SINAMICS DCM

Tests 3
The tests that have been expressly ordered for the drive with serial number K91539032021001
are listed in the following.
SINAMICS DCM 6RN F03
Reference Manual Rev.201902141527 SINAMICS DCM 15

3.1 Visual inspection
The visual inspection is performed to ensure that the drive complies with the requirements of
the order. The individual test steps are performed with the drive in a no-voltage condition.
The test together with the customer – or his representative – is carried out with the drive
installed and labeled. The results of all of the tests are documented in the acceptance report.
3.1.1 Rating plate
Fundamentals
The technical data and ordered options on the rating plate and the routine test certificate are
checked to ensure that they match up.
Test procedure
1. The data on the rating plate and the routine test certificate are visually compared.
Result
The test is passed if the data match up.
3.1.2 Housing degree of protection
Fundamentals
A check is made as to whether the housing degree of protection ordered complies with what is
described in the catalog.
Test procedure
1. The housing degree of protection is identified based on what is stamped on the rating plate.
2. Depending on the version, the following components are visually checked, e.g.:
– Canopies
– Cooling slots
– Fittings and rubber seals in the doors and between the cabinet units
– Cable entries
– Openings for water pipes, if available
– Additional components, if available
Tests
3.1 Visual inspection
SINAMICS DCM 6RN F03
16 Reference Manual Rev.201902141527 SINAMICS DCM

Result
The test is passed if the components required for the specified housing degree of protection are
available.
3.1.3 Electrical cabinet components
Fundamentals
A visual inspection is made to see whether the electrical cabinet components are installed as
defined in the layout diagram and/or circuit diagram.
Test procedure
1. The customer selects electrical cabinet components by random sampling.
2. The selected electrical cabinet components are visually checked to ensure that they are
correctly installed and marked.
Result
The test is passed if the selected electrical cabinet components are installed as specified in the
layout diagram and/or circuit diagram.
3.1.4 Cable installation
Fundamentals
Visual and mechanical checks are made to ensure that cables and conductors have been
installed correctly and are connected correctly according to the circuit diagram.
Test procedure
1. The customer selects cables or conductors by random sampling.
2. The following is inspected:
– Are the cables firmly connected?
– Have edge protectors been attached to sharp edges?
– Are the cables routed according to the circuit diagram?
Result
The inspection is passed if the cable installation does not exhibit any deficiencies and matches
the information in the circuit diagram.
Tests
3.1 Visual inspection
SINAMICS DCM 6RN F03
Reference Manual Rev.201902141527 SINAMICS DCM 17

3.1.5 Cable markings
Fundamentals
A visual inspection is made to see whether cables and conductors are marked as defined in the
circuit diagram.
Test procedure
1. The customer selects cables or conductors by random sampling.
– Are the cable end tags and conductor colors of cables and conductors marked as defined
in the circuit diagram?
Result
The test is passed if the cable and conductor markings match what is specified in the circuit
diagram.
3.1.6 Setting values of circuit breakers, if used
Fundamentals
The circuit breaker settings are visually checked against what is specified in the circuit diagram.
Test procedure
1. The customer selects circuit breakers by random sampling.
2. The circuit breaker settings are visually checked against what is specified in the circuit
diagram.
Result
The test is passed if the circuit breaker settings match what is specified in the circuit diagram.
3.1.7 Dimensions
Fundamentals
The drive dimensions are measured. The basis for the visual inspection is the order-specific
dimension drawing.
Test procedure
1. The external dimensions, length, width and height of the drive are measured.
Tests
3.1 Visual inspection
SINAMICS DCM 6RN F03
18 Reference Manual Rev.201902141527 SINAMICS DCM

Result
The test is passed if the dimensions match with what is specified in the dimension drawing.
Tests
3.1 Visual inspection
SINAMICS DCM 6RN F03
Reference Manual Rev.201902141527 SINAMICS DCM 19

3.2 Function test
3.2.1 Connecting the excitation equipment
Fundamentals
A check is made as to whether the PROFIBUS connection to the DC master of the excitation
equipment is established using the operating software at the test field computer. This is the
basis for additional tests and successful commissioning.
Test procedure
1. The excitation equipment is switched on.
2. The operating software has started and is connected to the excitation equipment.
3. The PROFIBUS connection is parameterized.
The operating software visualizes the status feedback signals.
Parameters can be entered.
Result
The test is successfully completed if the operating software indicates that the excitation
equipment is "Online".
3.2.2 Voltage test
Fundamentals
As no motor is available in the test station, the correct functioning of the excitation equipment
is demonstrated using an ohmic (resistive) load.
Test procedure
1. The supply voltage stamped on the nameplate is connected at the excitation equipment
input.
2. An ohmic (resistive) load is connected at the excitation unit output.
3. The excitation unit is switched on, started and operated at the rated voltage with reduced
current.
The actual electrical values are displayed on the measuring instrument/the test station
computer.
Result
The test is successfully passed if the characteristic of the armature current and voltage
corresponds to the defined curve characteristics. The displays of calibrated measuring
instruments serve as reference.
Tests
3.2 Function test
SINAMICS DCM 6RN F03
20 Reference Manual Rev.201902141527 SINAMICS DCM
