1.2 Purpose and scope
This document provides information regarding the HMI-TM device, including its
functions and operations. The programming of HMI-TM is not covered in this
document, but shall be governed by the Climatix SCOPE.
The target readers of this document are technical personnel of OEM ACR
customer, who may use the information provided in this document to write user
manual for dedicated application.
1.3 Document conventions
The following symbols are used in this document to indicate warnings and notes:
This symbol draws your attention to special safety notes and warnings. Ignoring
such notes can lead to personal injury and/or major damage to property.
This symbol precedes the notes that must be observed in order to prevent
malfunctions or data loss.
Notes with this symbol provide important information requiring appropriate
attention.
Paragraphs with this symbol provide tips.
The following abbreviations are used in this document:
Abbreviation Explanation
BSP Board Support Package (operating system)
HMI Human Machine Interface (operation unit)
HMI-DM Climatix Dot Matrix HMI POL895.xx
HMI-IB Climatix In-Built on POL4xx/6xx
HMI-SG Climatix Segmented HMI POL822.xx
HMI-TP Climatix Touch Panel HMI POL8Tx
HMI-TM Climatix Text Matrix HMI POL871.xx
HVAC Heating, Ventilating, Air Conditioning
RU Room Unit (e.g. POL822.xx)
SCADA Supervisory Control and Data Acquisition
SELV Safety Extra-Low Voltage
Name Explanation
Climatix Controller family with common tools
SAPRO SAPRO programming tool
SCOPE SCOPE commissioning and service tool
Symbols used
STOP
Abbreviations
Products and T
ools

6 / 38
Siemens Climatix HMI-TM CB1P3917en_redesigned
Smart Infrastructure Introduction 2023-06-13
1.4 Human machine interface
The Climatix HMI-TM is designed for display, system configuration, set-up and
operation. It is a product of the Climatix range, supporting all Climatix range of
controllers.
The HMI-TM cannot be used to operate any 3rd-party devices.
1.5 Key features
- High screen resolution: 240 x 128 dots
- 6 keys for ease of operation
- Programmable menu with easy-to-understand structure
- Key ALARM,INFO and ESC with LED indicators
- Definable user password for every access level
- Support of multi-language and Unicode fonts
- Support of online trend, time scheduler and iconic mode function
- HMI local settings supported
- Data point access supported
- Powered by controller via local HMI connection
- Panel or magnetic mounting, hand-held operation
- Firmware can be updated via controller (SD card support required)
1.6 Reference documents
The following documents contain further information on the products described in
this document:
#
D
ocument
Document
N
o.
1 Data Sheet Climatix HMI-TM POL871.7x CB1N3917en
2 Data Sheet Climatix HMI-TM POL871.6x A6V13923796
3 Mounting Instructions Climatix HMI-TM CB1M3917en
4 CE declaration of conformity POL871.7x CB1T3917xx
5 CE declaration of conformity POL871.6x A5W00442844A
6 Environment product declaration POL871.x1 233006-T-0601_EN
7 Environment product declaration POL871.x2 233006-T-0602_EN
8 Environment product declaration POL871.6x A5W00346618A
Brief introduction

7 / 38
Siemens Climatix HMI-TM CB1P3917en_redesigned
Smart Infrastructure Connections 2023-06-13
1.7 Product variants
HMI
-
TM variant
S
p
e
c
i
f
i
c
s
POL871.x1: HMI-TM for magnetic
mounting and mobile operation
> With 4-wire twisted pair spiral cable, with one RJ45 plug
>
Total cable length 2.5 m (1 m flat, 1.5 m expandable spiral cable)
POL871.x2: HMI-TM for mounting in
control panels
> Separate 1.5 m Cat-5 Ethernet cable (8-wire twisted pair) with two RJ45 plugs
>
Two terminals
with screws (for assemblies requiring IP65)
2 Connections
The local connection is a peer-to-peer connection between one HMI-TM and one
Climatix controller.
The maximum distance between HMI-TM and controller is 50 m via shielded
standard 8-wire twisted net cable.
For detail information, refer to Mounting Instruction CB1M3917en.
In case the Climatix controller is connecting to an HMI-TM (POL871) and
downloading the HMI.BIN file, the connection will not start until the downloading
process completes.
Cable for magnetic mounting and mobile
operation POL871.x1
Cable for mounting in control panels
POL871.x2
2.5 m customized cable with 1 RJ45 plug
and 1 slim connector (4-wire twisted pair)
1.5 m Cat-5 Ethernet cable with 2 RJ45
connectors (8-wire twisted pair)
Local
c
onnection
Cable Type

8 / 38
Siemens Climatix HMI-TM CB1P3917en_redesigned
Smart Infrastructure HMI-TM overview 2023-06-13
3 HMI-TM overview
This section introduces the overview of Climatix HMI-TM.
3.1 Function keys
The function keys of HMI-TM are illustrated as follows:
* Hold the key for more than 2 seconds.
Key Name Operation Description
UP
Press To increase the input value
Press and hold* To enable the acceleration function to increase the value in a large
extent
DOWN
Press To decrease the input value
Press and hold* To enable the acceleration function to decrease the value in a large
extent
ENTER
Press - To select one item;
- To confirm the selection
Press and hold*
- If logging in with one user level, press and hold key ENTER to
activate the log in/off page;
- If not, press and hold key ENTER to redirect to the password entering
page
INFO Press
- If users have defined which page it redirects to and the current user
level has enough privileges, it will go to that page. Otherwise, it will
go to the home page (refer to Climatix SCOPE online help for detail
information about how to define the target page);
- In the password related page, the function of pressing key INFO
depends on the templates users defined (refer to
Password Management for details)
ALARM Press To activate and switch among alarm related pages (refer to
Alarm Management for details)
ESC
Press - To cancel modification;
- To exit to the upper level of menu or back to previous page
Press and hold* To redirect to the page displaying the menu of HMI settings and Local
connection

9 / 38
Siemens Climatix HMI-TM CB1P3917en_redesigned
Smart Infrastructure HMI-TM overview 2023-06-13
3.2 LED indicators
3.3 Display specification
The STN LCD with dot matrix resolution of HMI-TM is 240*128 pixels
(width*height).
The size of LCD screen is 93*58 mm (width*height). The size of visible area is
86.15*47.78 mm (width*height).
For Latin (English) characters, font sizes of 6*12 pixels and 7*14 pixels
(width*height) are supported; For Eastern Asian characters such as Chinese, font
sizes of 12*12 and 14*14 pixels (width*height) are supported.
Here are the examples:
LED Name Status Description
ALARM
Flashing in red To indicate active but unacknowledged alarm exists
Constant light in red To indicate active alarms exist and all alarms acknowledged
Green Definable
OFF To indicate no active alarm exists
The LED status can be defined by users, such as constant light in red/green/yellow, flashing in
red/green/yellow as well as OFF
INFO Definable (for detail information, refer to Climatix SCOPE online help)
ESC Definable (for detail information, refer to Climatix SCOPE online help)
LCD
Character
s
ize
Display
ing
example

10 / 38
Siemens Climatix HMI-TM CB1P3917en_redesigned
Smart Infrastructure HMI-TM overview 2023-06-13
Lab
el
Icon
Descrip
tion
①Key
INFO
②Key
ALARM
③Key
ESC
④•••
To indicate there are characters hidden in this line.
1. If the string is longer than the length of the line, “•••”
will be displayed at the end of the line. If this line is
highlighted, it will scroll automatically character by
character.
2. In a line with more than one string, if the end part of
a string is covered by the string of next position, “•••”
will be displayed at the end of the string. When this
line is highlighted, the first string with covered text
will scroll automatically character by character.
The character scrolling function assures that every
character is displayed completely each time.
⑤►To indicate a sub-menu exists
⑥Key
ENTER
⑦
▲
The icon on the right margin is to indicate key UP.
The icon on the upper margin is to indicate there are
other line(s) hidden above the current page.
+On the value-editing page, the icon “▲” becomes “+” to
indicate that the key is used for value increasing.
⑧
▼
The icon on the right margin is to indicate key DOWN.
The icon on the upper margin is to indicate there are
other line(s) hidden below the current page.
-On the value-editing page, the icon “▼” becomes “-” to
indicate that the key is used for value decreasing.
⑨
To indicate the HMI-TM does not login with any user
level
To indicate the current user level is End User
To indicate the current user level is Service
To indicate the current user level is OEM Factory
⑩1/11 To indicate the total number of lines in this page is “11”,
and the 1st line is currently being selected
⑪Title area
The title line, which will never be highlighted, supports all
tokens and has the same characteristics as the lines in
content area.
The target page can be defined by application engineer
on this line. When users press key INFO and the current
user level has the privilege to access to this target page,
it will redirect to this page. Regarding how to program a
title line, refer to Climatix SCOPE online help.
D
isplay
ing
icons
