SIMATIC
S7-1500R/H
CPU 1515R-2 PN
(6ES7515-2RM00-0AB0)
Manual
10/2018
A5E42009914
-AA
Preface
Documentation guide
1
Product overview
2
Connecting
3
Interrupts, diagnostics, error
messages and system
events
4
Technical specifications
5
Dimension drawing
A

Siemens AG
Division Digital Factory
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E42009914-AA
Ⓟ
09/2018 Subject to change
Copyright © Siemens AG 2018.
All righ
ts reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
Manual, 10/2018, A5E42009914-AA 3
Preface
Purpose of the documentation
This manual supplements the system manual of the S7-1500R/H redundant system and the
function manuals. This manual contains a description of the module-specific information. The
system-related functions are described in the system manual. All system-spanning functions
are described in the function manuals.
The information provided in this manual and the system manual enables you to commission
the CPU 1515R-2 PN.
Conventions
STEP 7: In this documentation, "STEP 7" is used as a synonym for all versions of the
configuration and programming software "STEP 7 (TIA Portal)".
Please also observe notes marked as follows:
Note
A note contains important information on the product described in the documentation, on the
handling of the product or on the section of the documentation to which particular attention
should
be paid.
Recycling and disposal
For environmentally friendly recycling and disposal of your old equipment, contact a certified
electronic waste disposal company and dispose of the equipment according to the applicable
regulations in your country.

Preface
CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
4Manual, 10/2018, A5E42009914-AA
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens' products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be
connected to an enterprise network or the internet if and to the extent such a connection is
necessary and only when appropriate security measures (e.g. firewalls and/or network
segmentation) are in place.
For additional information on industrial security measures that may be implemented, please
visit (https://www.siemens.com/industrialsecurity).
Siemens' products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customers' exposure
to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under (https://www.siemens.com/industrialsecurity).
Siemens Industry Online Support
You can find current information on the following topics quickly and easily here:
●
Product support
All the information and extensive know-how on your product, technical specifications,
FAQs, certificates, downloads, and manuals.
●
Application examples
Tools and examples to solve your automation tasks – as well as function blocks,
performance information and videos.
●
Services
Information about Industry Services, Field Services, Technical Support, spare parts and
training offers.
●
Forums
For answers and solutions concerning automation technology.
●
mySupport
Your personal working area in Industry Online Support for messages, support queries,
and configurable documents.
This information is provided by the Siemens Industry Online Support in the Internet
(https://support.industry.siemens.com).

Preface
CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
Manual, 10/2018, A5E42009914-AA 5
Industry Mall
The Industry Mall is the catalog and order system of Siemens AG for automation and drive
solutions on the basis of Totally Integrated Automation (TIA) and Totally Integrated Power
(TIP).
You can find catalogs for all automation and drive products on the Internet
(https://mall.industry.siemens.com).

CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
6Manual, 10/2018, A5E42009914-AA
Table of contents
Preface ................................................................................................................................................... 3
1 Documentation guide .............................................................................................................................. 7
2 Product overview .................................................................................................................................. 10
2.1 Configuration and operating principle .................................................................................... 10
2.2 Hardware properties .............................................................................................................. 12
2.3 Firmware functions................................................................................................................. 15
2.4 Operator controls and display elements ................................................................................ 17
2.4.1 Front view of the module with front panel .............................................................................. 17
2.4.2 Front view of the module without front panel ......................................................................... 19
2.4.3 Rear view of the module ........................................................................................................ 20
2.5 Mode selector......................................................................................................................... 21
3 Connecting ........................................................................................................................................... 22
3.1 Terminal assignment.............................................................................................................. 22
4 Interrupts, diagnostics, error messages and system events................................................................... 26
4.1 Status and error display of the CPU ...................................................................................... 26
5 Technical specifications ........................................................................................................................ 31
A Dimension drawing ............................................................................................................................... 40
A.1 Dimension drawing ................................................................................................................ 40

CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
Manual, 10/2018, A5E42009914-AA 7
Documentation guide
1
The documentation for the redundant S7-1500R/H system is divided into three areas.
This division enables you to access the specific content you require.
Figure 1-1 S7-1500R/H guide
Basic information
The System Manual and Getting Started describe in detail the configuration, installation,
wiring and commissioning of the redundant S7-1500R/H system. The STEP 7 online help
supports you in the configuration and programming.
Device information
Product manuals contain a compact description of the module-specific information, such as
properties, wiring diagrams, characteristics and technical specifications.
General information
The function manuals contain detailed descriptions on general topics regarding the
redundant S7-1500R/H system, e.g. diagnostics, communication.
You can download the documentation free of charge from the Internet
(https://support.industry.siemens.com/cs/ww/en/view/109742691).
Changes and supplements to the manuals are documented in a Product Information.
You can download the product information free of charge from the Internet
(https://support.industry.siemens.com/cs/ww/en/view/109742691).

Documentation guide
CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
8Manual, 10/2018, A5E42009914-AA
S7-1500/ET 200MP Manual Collection
The S7-1500/ET 200MP Manual Collection contains the complete documentation on the
redundant S7-1500R/H system gathered together in one file.
You can find the Manual Collection on the Internet
(https://support.industry.siemens.com/cs/ww/en/view/86140384).
SIMATIC S7-1500 comparison list for programming languages
The comparison list contains an overview of which instructions and functions you can use for
which controller families.
You can find the comparison list on the Internet
(https://support.industry.siemens.com/cs/ww/en/view/86630375).
"mySupport"
With "mySupport", your personal workspace, you make the best out of your Industry Online
Support.
In "mySupport", you can save filters, favorites and tags, request CAx data and compile your
personal library in the Documentation area. In addition, your data is already filled out in
support requests and you can get an overview of your current requests at any time.
You must register once to use the full functionality of "mySupport".
You can find "mySupport" on the Internet (https://support.industry.siemens.com/My/ww/en/).
"mySupport" - Documentation
In the Documentation area in "mySupport" you can combine entire manuals or only parts of
these to your own manual.
You can export the manual as PDF file or in a format that can be edited later.
You can find "mySupport" - Documentation on the Internet
(https://support.industry.siemens.com/My/ww/en/documentation).
"mySupport" - CAx data
In the CAx data area in "mySupport", you can access the current product data for your CAx
or CAe system.
You configure your own download package with a few clicks.
In doing so you can select:
●Product images, 2D dimension drawings, 3D models, internal circuit diagrams, EPLAN
macro files
●Manuals, characteristics, operating manuals, certificates
●Product master data
You can find "mySupport" - CAx data on the Internet
(https://support.industry.siemens.com/my/ww/en/CAxOnline).

Documentation guide
CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
Manual, 10/2018, A5E42009914-AA 9
Application examples
The application examples support you with various tools and examples for solving your
automation tasks. Solutions are shown in interplay with multiple components in the system -
separated from the focus on individual products.
You will find the application examples on the Internet
(https://support.industry.siemens.com/sc/ww/en/sc/2054).
PRONETA
With SIEMENS PRONETA (PROFINET network analysis), you analyze the PROFINET
network during commissioning. PRONETA features two core functions:
●The topology overview independently scans PROFINET network and all connected
components.
●The IO check is a fast test of the wiring and the module configuration of a system.
You can find SIEMENS PRONETA on the Internet
(https://support.industry.siemens.com/cs/ww/en/view/67460624).
SINETPLAN
SINETPLAN, the Siemens Network Planner, supports you in planning automation systems
and networks based on PROFINET. The tool facilitates professional and predictive
dimensioning of your PROFINET installation as early as in the planning stage. In addition,
SINETPLAN supports you during network optimization and helps you to exploit network
resources optimally and to plan reserves. This helps to prevent problems in commissioning
or failures during productive operation even in advance of a planned operation. This
increases the availability of the production plant and helps improve operational safety.
The advantages at a glance
●Network optimization thanks to port-specific calculation of the network load
●Increased production availability thanks to online scan and verification of existing systems
●Transparency before commissioning through importing and simulation of existing STEP 7
projects
●Efficiency through securing existing investments in the long term and optimal exploitation
of resources
You can find SINETPLAN on the Internet (https://www.siemens.com/sinetplan).

CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
10 Manual, 10/2018, A5E42009914-AA
Product overview
2
2.1
Configuration and operating principle
Structure
The S7-1500R redundant system consists of the following components:
●Two CPUs of the type CPU 1515R-2 PN
●Two SIMATIC memory cards
●PROFINET cable (PROFINET ring)
●IO devices
●Load power supply (optional)
●System power supply (optional)
You mount the CPUs on a common mounting rail or spatially separated on two separate
mounting rails. You connect the two CPUs and the IO devices in a PROFINET ring via the
PROFINET cable.
①
Optional load current supply
②
First CPU
③
Mounting rail with integrated DIN rail profile
④
Second CPU
⑤
PROFINET cable (PROFINET ring)
Figure 2-1 Configuration example for S7-1500R

Product overview
2.1 Configuration and operating principle
CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
Manual, 10/2018, A5E42009914-AA 11
Principle of operation
One of the two CPUs in the redundant system takes on the role of CPU for process control
(primary CPU). The other CPU takes on the role of the following CPU (backup CPU). The
assigned role of the CPUs can change during operation. Synchronization of all relevant data
between primary CPU and backup CPU ensures fast switching between CPUs in the event
of a primary CPU failure. If the primary CPU fails, the backup CPU retains control of the
process as the new primary CPU at the point of interruption.
The redundancy connections are the PROFINET ring with MRP. The CPUs are
synchronized via a PROFINET ring.
Reference
You can find a detailed description of the operation and design of the CPUs in the system
manual Redundant System S7-1500R/H
(https://support.industry.siemens.com/cs/ww/en/view/109754833).

Product overview
2.2 Hardware properties
CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
12 Manual, 10/2018, A5E42009914-AA
2.2
Hardware properties
Article number
6ES7515-2RM00-0AB0
View of the module
The figure below shows the CPU 1515R-2 PN.
Figure 2-2 CPU 1515R-2 PN
Note
Protective film
Note that there is a removable protective foil on the display when the CPUs are delivered.

Product overview
2.2 Hardware properties
CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
Manual, 10/2018, A5E42009914-AA 13
Properties
CPU 1515R-2 PN has the following technical properties:
Property
Description
Additional information
CPU display
All CPUs of the redundant system S7 1500R/H have a
display with plain text information. The display provides
you with diagnostic messages as well as information
about the article number, the firmware version and the
serial number of the CPU.
You can also view and assign the IP addresses, the
PROFINET device name and the redundancy ID of the
CPU. The system IP address can be viewed via
STEP 7 but not in the display.
In addition to the functions listed here, a large number
of other functions are available on the display. These
additional functions are described in the SIMATIC S7
1500 Display Simulator.
•Redundant System S7-1500R/H
(https://support.industry.siemens.
com/cs/ww/en/view/109754833)
System Manual
•SIMATIC S7-1500 Display Simu-
lator
(http://www.automation.siemens.
com/salesmaterial-as/interactive-
manuals/getting-started_simatic-
s7-1500/disp_tool/start_de.html)
Supply voltage
The 24 V DC supply voltage is fed via a 4-pin plug
located on the front of the CPU.
•Section Connecting (Page 22)
•Redundant System S7-1500R/H
(https://support.industry.siemens.
com/cs/ww/en/view/109754833)
System Manual

Product overview
2.2 Hardware properties
CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
14 Manual, 10/2018, A5E42009914-AA
Property
Description
Additional information
PROFINET IO
PROFINET IO interface
(X1 P1 R and X1 P2 R)
The CPU has an X1 interface with two ports (X1 P1 R
and X1 P2 R).
•The PROFINET IO interface X1 (default P1 R) is
used to set up the PROFINET ring with the two
CPUs and the IO devices.
•The PROFINET IO interface X1 (default P2 R) is
used to make the connection between the two R-
CPUs in the PROFINET ring.
In the PROFINET ring, the synchronization frames
between the CPUs are transmitted via the following
connections:
–The direct connection (X1 P2 R)
–The indirect connection (X1 P1 R) via the IO de-
vices
•The interface supports PROFINET IO RT (Real-
Time) and PROFINET basic functionality.
Basic PROFINET functionality comprises:
–HMI communication
–Communication with the configuration system
–Communication with a higher-level network
(backbone, router, Internet)
–Communication with another machine or auto-
mation cell
•Redundant System S7-1500R/H
(https://support.industry.siemens.
com/cs/ww/en/view/109754833)
System Manual
•Function manual PROFINET
(https://support.industry.siemens.
com/cs/ww/en/view/49948856)
PROFINET interface
(X2 P1)
The CPU has an X2 interface with one port (X2 P1).
The interface supports PROFINET basic functionality.
Operation of the CPUs as
IO controllers
IO controller:
As IO controllers the CPUs address the following con-
figured IO devices:
•IO devices within the PROFINET ring
•IO devices that are decoupled from the PROFINET
ring via a switch
Accessories
You can find information on the topic of "Accessories/spare parts" in the system manual for
Redundant System S7-1500R/H
(https://support.industry.siemens.com/cs/ww/en/view/109754833).

Product overview
2.3 Firmware functions
CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
Manual, 10/2018, A5E42009914-AA 15
2.3
Firmware functions
Functions
CPU 1515R-2 PN supports the following firmware functions:
Function
Description
Additional information
CPU redundancy
There are two duplicate CPUs that synchronize their
data via redundancy connections within a PROFINET
ring. If one of the CPUs fails, the other CPU retains
control of the process.
Redundant System S7-1500R/H
(https://support.industry.siemens.co
m/cs/ww/en/view/109754833) Sys-
tem Manual
Integrated system diag-
nostics
The system automatically generates the messages for
the system diagnostics and outputs these messages
via a programming device/PC, HMI device or the inte-
grated display. System diagnostics information is also
available when the CPUs are in operating state STOP.
Function manual Diagnostics
(http://support.automation.siemens.c
om/WW/view/en/59192926)
Integrated trace function-
ality
Trace functionality supports you in troubleshooting
and/or optimizing the user program.
You record device tags and evaluate the recordings
with the trace and logic analyzer function. Tags are, for
example, drive parameters or system and user tags of
a CPU.
Trace and logic analyzer functions are suitable for
monitoring highly dynamic processes.
Note: Note that the S7-1500R/H redundant system
supports recording of measurements. However, saving
the measurements to the SIMATIC memory card is not
supported.
Function manual Using the trace and
logic analyzer function
(http://support.automation.siemens.c
om/WW/view/en/64897128)
PROFINET IO
System redundancy S2 All IO devices are connected redundantly in the redun-
dant S7 1500R/H system. All IO devices assigned to
the system must therefore support system redundancy
S2.
If the role of the CPUs changes, the new primary CPU
takes over the PROFINET IO communication.
•Redundant System S7-1500R/H
(https://support.industry.siemens.
com/cs/ww/en/view/109754833)
System Manual
•Function manual PROFINET
(http://support.automation.sieme
ns.com/WW/view/en/49948856)
RT (real time) RT prioritizes PROFINET IO frames over standard
frames. This ensures the required determinism in the
automation technology. In this process the data is
transferred via prioritized Ethernet frames.
Function manual PROFINET
(http://support.automation.siemens.c
om/WW/view/en/49948856)
MRP (Media Redundancy
Protocol)
The Media Redundancy Protocol enables the configu-
ration of redundant networks. Redundant transmission
links (ring topology) ensure that an alternative commu-
nication path is made available if a transmission link
fails.
Within the PROFINET ring, the R-CPUs assume the
role of the MRP Manager following appropriate project
configuration and all other devices in the ring assume
the role of the MRP clients.

Product overview
2.3 Firmware functions
CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
16 Manual, 10/2018, A5E42009914-AA
Function
Description
Additional information
PROFIenergy PROFIenergy is a PROFINET-based data interface for
switching off consumers centrally and with full coordi-
nation during pause times regardless of the manufac-
turer or device type. Through this, the process should
only be provided with the energy that is absolutely
required. Most of the energy is saved by the process.
The PROFINET device itself only contributes a few
watts to the savings potential.
Integrated technology
Integrated closed-loop
control functionality
The CPUs support PID basic functions.
No controller support:
•PID_Compact
•PID _3Step
•PID_Temp
Function manual PID Control
(https://support.industry.siemens.co
m/cs/ww/en/view/108210036)
Security Integrated
Know-how protection The know-how protection protects user blocks against
unauthorized access and modifications.
Redundant System S7-1500R/H
(https://support.industry.siemens.co
m/cs/ww/en/view/109754833) Sys-
tem Manual
Access protection You can use authorization levels to assign separate
rights to different user groups.
Integrity protection The CPUs dispose of integrity protection by default.
Integrity protection identifies possible manipulations of
engineering data on the SIMATIC memory card or
during data transfer between STEP 7 and the CPUs.
Integrity protection also checks the communication
from a SIMATIC HMI system to the CPUs for possible
manipulations of engineering data.
If integrity protection identifies the manipulation of en-
gineering data, the user receives a corresponding mes-
sage.
Password provider As an alternative to manual password entry, you can
link a password provider to STEP 7. A password pro-
vider offers the following advantages:
•Convenient handling of passwords. STEP 7 auto-
matically imports the password for the blocks. This
saves you time.
•Optimum block protection because the users do not
know the password itself.

Product overview
2.4 Operator controls and display elements
CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
Manual, 10/2018, A5E42009914-AA 17
2.4
Operator controls and display elements
2.4.1
Front view of the module with front panel
The figure below shows the front view of the CPU 1515R-2 PN.
①
LEDs for the current operating state and diagnostic status of the CPU
②
Display
③
Control keys
Figure 2-3 View of the CPU 1515R-2 PN (with front panel) - front
Note
Temperature range for display
To increase its
service life, the display switches off at a temperature below the permitted
operating temperature of the device. When the display cools down, it automatically switches
itself on again. When the display is switched off, the LEDs continue to show the status of the
CPUs.
You can find additional information on the temperatures at which the display switches itself
on and off in the
Technical specifications (Page 31).

Product overview
2.4 Operator controls and display elements
CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
18 Manual, 10/2018, A5E42009914-AA
Pulling and plugging the front panel with display
You can pull and plug the front panel with display during operation.
WARNING
Personal injury and damage to property may occur
If you remove or attach the front panel of a redundant system S7-1500R/H during
operation, personal injury or damage to property can occur in hazardous area zone 2.
Before you remove or fit the front panel, always switch off the power supply to the
S7-1500R/H redundant system in hazardous area zone 2.
Locking the front panel
You can lock the front panel to protect the SIMATIC memory card and the mode selector of
the CPU against unauthorized access.
You can attach a security seal or a padlock with a hoop diameter of 3 mm to the front panel.
Figure 2-4 Locking latch on the CPU
In addition to the mechanical lock, you can also block access to a password-protected CPU
on the display (local lock) and assign a password for the display. You can find additional
information on the display, the configurable protection levels and the local lock in the system
manual for Redundant System S7-1500R/H
(https://support.industry.siemens.com/cs/ww/en/view/109754833).
Reference
You can find detailed information on the individual display options, a training course and a
simulation of the available menu commands in the SIMATIC S7-1500 Display Simulator
(http://www.automation.siemens.com/salesmaterial-as/interactive-manuals/getting-
started_simatic-s7-1500/disp_tool/start_en.html).

Product overview
2.4 Operator controls and display elements
CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
Manual, 10/2018, A5E42009914-AA 19
2.4.2
Front view of the module without front panel
The figure below shows the operator controls and connection elements of the
CPU 1515R-2 PN.
①
LEDs for the current operating state and diagnostic status of the CPUs
②
Display connector
③
Slot for the SIMATIC memory card
④
Mode selector
⑤
LED displays for the 3 ports of the PROFINET interfaces X1 and X2
⑥
MAC addresses of the interfaces
⑦
PROFINET IO interface X2 with 1 port
⑧
PROFINET IO interface X1 with 2 ports
⑨
Connector for power supply
⑩
Fixing screws
Figure 2-5 View of the CPU 1515R-2 PN (without front panel) - front
