Siemens ECOFAST User manual

Part of Totally
Integrated
Automation
ecofast
02/2002
Motor Starter

DeutschEnglish
Important information,
Contents
Product overview 1
Installation of motor starters 2
Wiring and interfaces 3
Commissioning and diagnostics 4
Device functions 5
Technical data A
Dimension drawings B
Order numbers C
Edition 01
ECOFAST
Motor Starters
Manual
GWA 4NEB 950 0562-12

Safety guidelines
This manual contains notices which you should observe to ensure your own personal safety, as well as to pro-
tect the product and connected equipment. These notices are highlighted in the manual by a warning triangle
and are marked as follows according to the level of danger:
Danger
indicates that death, severe personal injury or substantial property damage will result if proper precautions
are not taken.
Warning
indicates that death, severe personal injury or substantial property damage can result if proper precautions are
not taken.
Caution
indicates that minor personal injury or property damage can result if proper precautions are not taken.
Caution
indicates that property damage can result if proper precautions are not taken.
Attention
draws your attention to particularly important information on the product, handling the product, or to a particu-
lar part of the documentation.
Qualified personnel
Only qualified personnel should be allowed to install and work on this equipment. Qualified persons are defi-
ned as persons who are authorized to commission, to ground, and to tag circuits, equipment, and systems in
accordance with established safety practices and standards.
Correct usage
Note the following:
Warning
This device and its components may only be used for the applications described in the catalogue or the techni-
cal descriptions, and only in connection with devices or components from other manufacturers which have
been approved or recommended by Siemens.
This product can only function correctly and safely if it is transported, stored, set up, and installed correctly,
and operated and maintained as recommended.
Brands
SIMATIC®, SIMATIC HMI®, ECOFAST® and SIMATIC NET® are brands of SIEMENS AG.
Han Brid‚, Han Q8‚, Han 10E‚are brands of Harting company
Some other designations used in these documents are also brands; the owner's rights may be violated if they
are used by third parties for their own purposes.
Siemens AG
Bereich Automatisierungs- und Antriebstechnik
Geschäftsgebiet Niederspannungs-Schalttechnik
D-91050 Erlangen
Siemens Aktiengesellschaft
Siemens AG 2002
Technical data subject to change without notice.
Copyright Siemens AG 2002 All rights reserved
The reproduction, transmission or use of this document or its con-
tents is not permitted without express written authority. Offenders
will be liable for damages. All rights, including rights created by
patent grant or registration of a utility model or design, are reserved.
Disclaimer of liability
We have checked this manual to ensure that its contents are correct
and applicable in relation to the hardware and software it describes.
Despite all our endeavors, however, discrepancies cannot be wholly
excluded and so we cannot guarantee complete correctness and
applicability. However, the data in this manual are reviewed regularly
and any necessary corrections included in subsequent editions. Sug-
gestions for improvement are welcomed.
Technical Assistance: Telephone: [phone] (8°° - 17°° MEZ) Fax: [phone]
E-mail: nst.technical-[email protected]
Internet: www.siemens.de/lowvoltage/technical-assistance
Technical Support: Telephone: [phone]

Contents
ECOFAST Motor Starters
GWA 4NEB 950 0562-12
i
DeutschEnglish
Contents
Figuresl . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Introduction to the Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
1 Motor Starters: Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.1 What are ECOFAST Motor Starters? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.2 Connections, fieldbus interfaces, LED indicators . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.2.1 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.2.2 Fieldbus interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.2.3 LED indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.3 Product overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
2 Installation of Motor Starters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.1 Setting the address. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2 Setup with motor plugged in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.2.1 Required components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.2.2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.3 Setup with motor nearby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.3.1 Required components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.3.2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
3 Wiring and interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.1 Power Cables Prefabricated at One End . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
3.1.1 Power Cables Prefabricated at One End with Han Q8 Pin . . . . . . . . . . . . . . . . . . . . 3-3
3.1.2 Power Cables Prefabricated at One End with Han 10E Pin . . . . . . . . . . . . . . . . 3-4
3.2 Wiring rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
3.2.1 Selecting the power leads. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
3.2.2 Unused connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
3.3 Motor terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
3.3.1 Pin assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
3.3.2 Preparing power cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
3.4 Power terminal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
3.4.1 Pin assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
3.4.2 Preparing power cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
3.5 Power tee connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
3.6 Digital inputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
3.7 AS-i interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
3.7.1 Connection techniques . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
3.7.2 Behavior in the event of a power failure . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
3.8 Addressing socket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16

Contents
ECOFAST Motor Starters
ii GWA 4NEB 950 0562-12
4 Commissioning and diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.1 Process data and process images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.2 Commissioning and starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
4.3 Diagnostics through LED indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
4.4 Diagnostics with the addressing and diagnostic unit . . . . . . . . . . . . . . . . . . . . . . 4-7
4.5 Behavior in the event of faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
5 Device functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5.1 Temperature sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
5.2 Reversing starter control function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
5.3 Mechanical braking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
5.4 Electronic/mechanical switching technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
A Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
A.1 General technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
A.2 Auxiliary power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
A.3 Digital inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
A.4 Main power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4
A.4.1 Mechanical switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-5
A.4.2 Brake output 400 V AC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-6
B Dimension drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
B.1 Motor Starter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
C Order numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
C.1 Motor Starters (Reversing starters) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2
C.2 Motor Connection Cables and Power Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3
C.3 Power & Control Modules (Infeed Modules) . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-5
C.4 Hybrid Fieldbus Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-6
C.5 AS-Interface Shaped Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-7
C.6 Hybrid Fieldbus Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-7
C.7 Connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-8
C.8 Project engineering software and Documentation . . . . . . . . . . . . . . . . . . . . . . . . C-9
C.9 Tools, Connector Sets, Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-10
Index
Correction page

Figures
ECOFAST Motor Starters
GWA 4NEB 950 0562-12
iii
DeutschEnglish
Figures
Page
Fig. 1-1: Connections on the motor starter . . . . . . . . . . . . . . . . . . . 1-2
Fig. 1-2: Fieldbus interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Fig. 1-3: LED indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Fig. 3-1: Numbers printed on the power cable cores . . . . . . . . . . . . 3-3
Fig. 3-2: Power cables prefabricated at one end with Han Q8 pin . . . . . . 3-3
Fig. 3-3: Power cables prefabricated at one end with Han 10E pin . . . . . . 3-4
Fig. 3-4: Pin assignment for motor terminal . . . . . . . . . . . . . . . . . . 3-7
Fig. 3-5: Pin assignment for power terminal . . . . . . . . . . . . . . . . . . 3-9
Fig. 3-6: Han Q8 power connector . . . . . . . . . . . . . . . . . . . . . . . 3-11
Fig. 3-7: Pin assignment for power tee connector . . . . . . . . . . . . . . . 3-12
Fig. 3-8: Pin assignment with circuit examples . . . . . . . . . . . . . . . . . 3-13
Fig. 3-9: AS-i interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Fig. 3-10: Contacting the AS-i cables . . . . . . . . . . . . . . . . . . . . . . 3-14
Fig. 3-11: Addressing socket . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
Fig. 4-1: Starting the motor starter . . . . . . . . . . . . . . . . . . . . . . . 4-5
Fig. 5-1: Typical circuit for mechanical braking . . . . . . . . . . . . . . . . . 5-4
Fig. 2-1: Motor starter dimension drawing . . . . . . . . . . . . . . . . . . . B-2

ECOFAST Motor Starters
iv GWA 4NEB 950 0562-12

Tables
ECOFAST Motor Starters
GWA 4NEB 950 0562-12
v
DeutschEnglish
Ta b l e s
Page
Table 1-1: Product overview of motor starters with PROFIBUS-DP . . . . . . . 1-4
Table 1-2: Product overview of motor starters with AS-Interface . . . . . . . . 1-5
Table 2-1: AS-i slave profile . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Table 2-2: Setting the address via the addressing socket . . . . . . . . . . . . 2-2
Table 2-3: Components required for setting up with the motor plugged in . . . 2-3
Table 2-4: Installation: motor plugged in . . . . . . . . . . . . . . . . . . . . . 2-4
Table 2-5: Components required for setting up with the motor nearby . . . . . 2-5
Table 2-6: Installation: motor nearby . . . . . . . . . . . . . . . . . . . . . . . 2-6
Table 3-1: Rules for wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Table 3-2: Preparing connecting leads with Han 10E . . . . . . . . . . . . . . 3-8
Table 3-3: Preparing connecting leads with Han Q8 . . . . . . . . . . . . . . . 3-10
Table 3-4: Assembling and wiring power connectors . . . . . . . . . . . . . . 3-11
Table 4-1: Process data and process image, AS-Interface . . . . . . . . . . . . 4-2
Table 4-2: Software requirements for commissioning . . . . . . . . . . . . . . 4-4
Table 4-3: Requirements for commissioning . . . . . . . . . . . . . . . . . . . 4-4
Table 4-4: Testing the wiring from the motor starter to the motor . . . . . . . . 4-4
Table 4-5: Diagnostics through LED indicators . . . . . . . . . . . . . . . . . . 4-6
Table 4-6: Possible faults and fault handling . . . . . . . . . . . . . . . . . . . 4-7
Table C-1: Order numbers for Motor Starters . . . . . . . . . . . . . . . . . . C-2
Table C-2: Order numbers for Motor Connection Cables and Power Cables . . . C-3
Table C-3: Order numbers for Power & Control Modules ( Infeed Modules) . . . C-5
Table C-4: Order numbers for Hybrid Fieldbus Cables . . . . . . . . . . . . . . C-6
Table C-5: AS-Interface Shaped Cable . . . . . . . . . . . . . . . . . . . . . . C-7
Table C-6: Order numbers for Hybrid Fieldbus Interfaces . . . . . . . . . . . . C-7
Table C-7: Order numbers for Connectors . . . . . . . . . . . . . . . . . . . . C-8
Table C-8: Project engineering software and Documentation . . . . . . . . . . C-9
Table C-9: Order numbers for Tools, Connector Sets, Configuration . . . . . . . C-10

ECOFAST Motor Starters
vi GWA 4NEB 950 0562-12

ECOFAST Motor Starters
GWA 4NEB 950 0562-12
vii
DeutschEnglish
Introduction to the Manual
Purpose
This manual is intended to be used for reference purposes. It shows you
how to operate "ECOFAST Motor Starters" with fieldbus AS-Interface.
These motor starters do not process data records.
"ECOFAST Motor Starters" are accompanied by
"ECOFAST Motor Starters High Feature", which process data records, such
as parameters and diagnosis/statistical data.
These motor starters are described in the "ECOFAST Motor Starter High
Feature" manual.
To p i c s
The manual consists of chapters providing instructions for use and that can
be used for reference. The following topics are covered:
• Motor starters overview
• Installation of motor starters
• Commissioning and diagnostics
• Wiring and interfaces
• Device functions
• Technical data
• Dimension drawings
• Order numbers
Notes
Notes of special importance are enclosed by two straight lines.
Specifications
This manual only describes the ECOFAST Motor Starter.
The terms "ECOFAST Motor Starter" and "Motor Starter" are interchangeable
in this manual.

ECOFAST Motor Starters High Feature
viii GWA 4NEB 950 0562-12
Correction page
At the end of this manual is a correction page. Please use this page to note
down your suggestions for improvements, additional information, or correc-
tions and send the page back to us. In this way, you will help us improve the
next edition of this manual.
Manuals
Two manuals are available:
• ECOFAST Motor Starters (this manual)
• ECOFAST Motor Starters High Feature
Other system manuals
For more information on ECOFAST, see the following
system manual:
• System ECOFAST

ECOFAST Motor Starters
GWA 4NEB 950 0562-12
1-1
DeutschEnglish
Motor Starters: Overview 1
Section Subject Page
1.1 What are ECOFAST Motor Starters ? 1-2
1.2 Connections, fieldbus interfaces, LED indicators 1-2
1.2.1 Connections 1-2
1.2.2 Fieldbus interfaces 1-3
1.2.3 LED indicators 1-3
1.3 Product overview 1-4

Motor Starters: Overview
ECOFAST Motor Starters
1-2 GWA 4NEB 950 0562-12
1.1 What are ECOFAST Motor Starters?
ECOFAST Motor Starters are part of the ECOFAST system, which unifies the
connection technology of all ECOFAST components.
ECOFAST Motor Starters are
• available as reversing starters and soft starters
• suitable for switching and protecting three-phase loads rated at 400 V AC up
to 4 kW (mechanical switching) and up to 5.5 kW (soft starter)
• optionally equipped with a 400 V AC brake contact
• available with a PROFIBUS-DP or AS-Interface (AS-i) connection
1.2 Connections, fieldbus interfaces, LED indicators
1.2.1 Connections
ECOFAST Motor Starters have the following connections:
Fig. 1-1: Connections on the motor starter
AUX PWR
AS-i
Motor connector
Motor terminal
Power terminal
Power connector
Power tee connector
Digital Inputs
Addressing socket

Motor Starters: Overview
ECOFAST Motor Starters
GWA 4NEB 950 0562-12
1-3
DeutschEnglish
1.2.2 Fieldbus interfaces
Depending on the device version, ECOFAST Motor Starters have the follo-
wing fieldbus interfaces:
Fig. 1-2: Fieldbus interfaces
1.2.3 LED indicators
ECOFAST Motor Starters have the following LED indicators:
Fig. 1-3: LED indicators
PROFIBUS-DP
PROFIBUS-DP interface
with data terminal and
data tee connector,
optionally for copper cable
or fiber-optic cable
AS-i interface using insulation
displacement technology
for yellow AS-i cable (data and
24 V non-switched) and
black AS-i cable (AUX PWR: 24 V
DC switched)
AS-Interface (AS-i)
AS-i
AUXPWR
AS-Interface Description
SF General fault
AS-i Fieldbus status
AUX PWR 24 V DC switched
STATE Circuit state
IN 1/2 Digital input 1 / 2
IN 2 Digital input 2
SF
AS-i
AUX PWR
STATE
IN.1/2
IN.2
ADDR.
DEVICE
X2
X1
X3

Motor Starters: Overview
ECOFAST Motor Starters
1-4 GWA 4NEB 950 0562-12
1.3 Product overview
High Switching Rates
Note
If you want to use the motor starter in applications with high switching
rates, use motor starters with the "Electronic switching technology" device
function.
The following table contains an overview of the individual motor starters and
their corresponding device functions:
PROFIBUS-DP
Table 1-1: Product overview of motor starters with PROFIBUS-DP
3RK1 303-2AS51-1AA0
3RK1 303-2AS51-1AA3
3RK1 303-5BS41-1AA0
3RK1 303-5BS41-1AA3
3RK1 303-5CS41-1AA0
3RK1 303-5CS41-1AA3
3RK1 303-6BS71-1AA0
3RK1 303-6BS71-1AA3
3RK1 303-6DS71-1AA0
3RK1 303-6DS71-1AA3
Shaded boxes: device function for this order number available
Light-gray fields: Description in manual
"ECOFAST Motor Starters High Feature"
Order no. 3RK1 702-3AB18-1AA0 (German)
Order no. 3RK1 702-3BB18-1AA0 (English)
Gray fields: Description in this manual
"ECOFAST Motor Starters"
Order no. 3RK1 702-2GB18-0AA0
(German/English)
Order number
Device function
Self-test Local device interface Electronic switching technolog
y
Mechanical switching technolog
Emergency start Mechanical braking Electrical braking Control function: soft starte
r
Control function: revers. st. Response to bus failure Inputs - actions Asymmetry Current limits Temperature sensor Thermal motor model

Motor Starters: Overview
ECOFAST Motor Starters
GWA 4NEB 950 0562-12
1-5
DeutschEnglish
AS-Interface
Table 1-2: Product overview of motor starters with AS-Interface
3RK1 323-2AS51-1AA0
3RK1 323-2AS51-1AA3
3RK1 323-5BS41-1AA0
3RK1 323-5BS41-1AA3
3RK1 323-5CS41-1AA0
3RK1 323-5CS41-1AA3
3RK1 323-6BS71-1AA0
3RK1 323-6BS71-1AA3
3RK1 323-6DS71-1AA0
3RK1 323-6DS71-1AA3
Shaded boxes: device function for this order number available
Light-gray fields: Description in manual
"ECOFAST Motor Starters High Feature"
Order no. 3RK1 702-3AB18-1AA0 (German)
Order no. 3RK1 702-3BB18-1AA0 (English)
Gray fields: Description in this manual
"ECOFAST Motor Starters"
Order no. 3RK1 702-2GB18-0AA0
(German/English)
Order number
Device function
Self-test Local device interface Electronic switching technolog
y
Mechanical switching technolog
Emergency start Mechanical braking Electrical braking Control function: soft starte
r
Control function: revers. st. Response to bus failure Inputs - actions Asymmetry Current limits Temperature sensor Thermal motor model

Motor Starters: Overview
ECOFAST Motor Starters
1-6 GWA 4NEB 950 0562-12

ECOFAST Motor Starters
GWA 4NEB 950 0562-12
2-1
DeutschEnglish
Installation of Motor Starters 2
Introduction
You can either set up the motor starter in the vicinity of the motor (motor
nearby with connecting cable) or plug it into the motor directly
(motor plugged in with mounting plate).
Section Subject Page
2.1 Setting the address 2-2
2.2 Setup with motor plugged in 2-3
2.2.1 Required components 2-3
2.2.2 Installation 2-4
2.3 Setup with motor nearby 2-5
2.3.1 Required components 2-5
2.3.2 Installation 2-6

Installation of Motor Starters
ECOFAST Motor Starters
2-2 GWA 4NEB 950 0562-12
2.1 Setting the address
AS-i slave profile
Table 2-1: AS-i slave profile
Requirements
To be able to set the address you need a device such as the addressing and
diagnostic unit (Order No.: 3RK1904-2AB00).
The valid addresses are 1 to 31. Use each address only once.
Note
Motor starters with product status smaller than 10 can be readdressed a
maximum of 15 times. After the 15th time, the last valid address is retained.
Table 2-2: Setting the address via the addressing socket
Motor starter
Order No.
I /O
configu-
ration
(hex)
ID Code
(hex)
ID1 Code
(hex)
ID2 Code
(hex)
of product status1)
smaller 10 from 10
3RK1 323-2AS51-1AA0 7 D F F 0
3RK1 323-2AS51-1AA3 7 D F F 0
1) The product status is printed below the addressing socket
Step Procedure
1If you intend to address the motor starter via the addressing socket,
switch off the AS-i supply voltage. This is necessary for reasons of
system safety.
2Unscrew the screw cap (Order No.: 3RK1 901-1KA00) from the
addressing socket.
3Connect the addressing and diagnostic unit to the addressing socket.
4Set the required address.
5After carrying out addressing, screw the screw cap back into the socket
in order to obtain degree of protection IP 67.
Addressing socket
Connecting lead
Screw cap
S
AUX PWR
STATE
IN.2
ADDR.
DEVICE
X1
X3
Addressing socket

Installation of Motor Starters
ECOFAST Motor Starters
GWA 4NEB 950 0562-12
2-3
DeutschEnglish
2.2 Setup with motor plugged in
2.2.1 Required components
The table below shows which components are required:
Table 2-3: Components required for setting up with the motor plugged in
Item Order data Order number
1 Motor starter 3RK1 3..
depending on version
2 Mounting plate with screws for motor starter 3RK1 911-3AA00
3 Power cable for looping through power
Han Q8 pin / power tee connector
prefabricated
or prepared by customer
3RK1 911-0..
depending on length and
cross section
Power cable, no looping through of power
Han Q8 at both ends
prefabricated
or prepared by customer
3RK1 911-0..
depending on length and
cross section
4 AS-i cable, trapezoidal-section yellow,
rubber 2 x 1.5 mm2 for fieldbus
3RX9 01.-0AA00
depending on length
5 AS-i cable, trapezoidal-section black,
rubber 2 x 1.5 mm2 for ext. 24 V auxiliary voltage
AUX PWR
3RX9 02.-0AA00
depending on length
6 Cable end covers for sealing open
cable ends (1 set = 10 covers)
3RK1 901-1MN00
