SIMATIC
S7-300
S7-300 Module data
Manual
This description is part of the S7-300
documentation package with the order number:
6ES7398-8FA10-8AB0
02/2013
A5E00105505-08
Preface
General technical data
1
Power supply modules
2
Digital modules
3
Principles of analog value
processing
4
Principles of analog modules
5
Analog modules
6
Other signal modules
7
Interface modules
8
Parameter sets of signal
modules
A
Diagnostics data of signal
modules
B
Dimensional drawings
C
Spare parts and accessories
for S7-300 modules
D
Directive on handling
Electrostatic-Sensitive
Devices (ESD)
E
Service & support
F
List of abbreviations
G

Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E00105505-08
Ⓟ 02/2013 Technical data subject to change
Copyright © Siemens AG 2013.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

S7-300 Module data
Manual, 02/2013, A5E00105505-08 3
Preface
Purpose of the manual
The information contained in this manual can be used as a reference to operating, to
functions, and to the technical data of the signal modules, power supply modules and
interface modules of the S7-300.
Refer to the relevant S7-300 or ET 200M manuals to find out how to assemble and wire the
modules.for system installation.
Basic knowledge required
This manual presumes general knowledge in the field of automation engineering.
Range of validity of this manual
The manual describes the components based on the data valid at the time of its release.
SIEMENS reserves the right to include product information for each new module of a later
version.
Changes compared to the previous version
Changes / enhancements compared to the previous version described in this manual:
● New digital input module SM 321 DI 16 x DC 24V/125V
6ES7321-7EH00-0AB0
● Errors in the previous version of this manual have been corrected in the present version.

Preface
S7-300 Module data
4 Manual, 02/2013, A5E00105505-08
Position in the overall documentation structure
The following documentation forms part of the S7-300 documentation package. You can also
find this, along with the associated entry ID, on the Internet
(http://support.automation.siemens.com/WW/view/en/10805159/133300).
Name of the manual Description
Manual
CPU 31xC and CPU 31x, technical data
Entry ID: 12996906
Control and display elements, communication,
memory concept, cycle and reaction times,
technical data
Operating Instructions
S7-300, CPU 31xC and CPU 31x: Installation
Entry ID: 13008499
Project design, installation, wiring, addressing,
commissioning, maintenance and test functions,
diagnostics and troubleshooting.
System Manual
PROFINET system description
Entry ID: 19292127
Basic description of PROFINET:
Network components, data exchange and
communication, PROFINET IO, Component-
based Automation, application example of
PROFINET IO and Component-based
Automation.
Programming Manual
Migration from PROFIBUS DP to PROFINET IO
Entry ID: 19289930
Guideline for migration from PROFIBUS DP to
PROFINET IO.
Manual
•CPU 31xC: Technological functions
Entry ID: 12429336
•CD containing examples
Description of the technological functions:
positioning, counting, point-to-point coupling, loop
control.
The CD contains examples of the technological
functions.
YOU ARE CURRENTLY READING the Manual
S7-300 Automation System: Module Data
Entry ID: 8859629
Description of the functions and technical data of
signal/ power supply/ interface modules.
Instructions List
•CPU 31xC, CPU 31x,
IM151-7 CPU, IM154-8 CPU, BM 147-1 CPU,
BM 147-2 CPU
Entry ID: 13206730
•CPU 312, CPU 314, CPU 315-2 DP
CPU 315-2 PN/DP, CPU 317-2 PN/DP,
CPU 319-3 PN/DP as of V3.0
Entry ID: 31977679
List of the CPU's instruction set and
corresponding execution times. List of executable
blocks (OBs, SFCs, SFBs) and their execution
times.
Getting Started
Available anthology of Getting Started manuals:
•S7-300 Getting Started
Entry ID: 15390497
•PROFINET Getting Started Collection
Entry ID: 19290251
Using concrete examples, the Getting Started
documentation provides step-by-step instructions
focused on commissioning a fully functional
application.

Preface
S7-300 Module data
Manual, 02/2013, A5E00105505-08 5
Other manuals on S7-300 and ET 200M
Name of the manual Description
Reference Manual
•CPU Data: CPU 312 IFM - 318-2 DP
•Entry ID: 8860591
Control and display elements, communication,
memory concept, cycle and reaction times,
technical data
Software Installation Manual
S7-300 Automation System: Installation:
CPU 312 IFM – 318-2 DP
Entry ID: 15390415
Project design, installation, wiring, addressing,
commissioning, maintenance and test functions,
diagnostics and troubleshooting.
Configuration Manual
ET 200M signal modules for process automation
Entry ID: 7215812
Description of integration in process automation,
parameter configuration using SIMATIC PDM,
digital input modules, digital output modules.
Manual
Distributed I/O Device ET 200M
HART analog modules
Entry ID: 22063748
Description of configuration and commissioning
of HART analog modules.
Manual
Distributed I/O Device ET 200M
Entry ID: 1142798
Description of configuration, assembly and wiring.
Manual
SM 335 - High-speed analog mixed module for
SIMATIC S7-300
Entry ID: 1398483
Description of how to use the SM 335 module in
a SIMATIC S7-300.
Overview of operations, descriptions of functions,
and technical data relating to the SM 335.
Sign posts
The manual contains various features supporting quick access to specific information:
● At the beginning of the manual, you will find a complete table of contents.
● Key terms are explained in the glossary.
● You can use the index to find the key parts of the manual.
Approvals
See section Standards and approvals (Page 15).
CE approval
See section Standards and approvals (Page 15).
Mark for Australia (C-Tick-Mark)
See section Standards and approvals (Page 15).

Preface
S7-300 Module data
6 Manual, 02/2013, A5E00105505-08
Standards
See section Standards and approvals (Page 15).
Recycling and disposal
Since the S7-300 components only contain low levels of harmful substances, they are
suitable for recycling. For ecologically compatible recycling and disposal of your old device,
contact a certificated disposal service for electronic scrap.
Note on IT security
Siemens offers IT security mechanisms for its automation and drive product portfolio in order
to support the safe operation of the plant/machine. We recommend that you inform yourself
regularly on the IT security developments regarding your products. You can find information
on this on the Internet (http://support.automation.siemens.com).
You can register for a product-specific newsletter here.
For the safe operation of a plant/machine, however, it is also necessary to integrate the
automation components into an overall IT security concept for the entire plant/machine,
which corresponds to the state-of-the-art IT technology. You can find information on this on
the Internet (http://www.siemens.com/industrialsecurity).
Products used from other manufacturers should also be taken into account here.

S7-300 Module data
Manual, 02/2013, A5E00105505-08 7
Table of contents
Preface ...................................................................................................................................................... 3
1 General technical data............................................................................................................................. 15
1.1 Standards and approvals .............................................................................................................15
1.2 Electromagnetic compatibility ......................................................................................................20
1.3 Shipping and storage conditions for modules and backup batteries ...........................................22
1.4 Mechanical and climatic environmental conditions for S7-300 operation....................................23
1.5 Specification of dielectric tests, protection class, degree of protection, and rated voltage
of S7-300......................................................................................................................................25
1.6 Rated voltages of S7-300 ............................................................................................................25
1.7 SIPLUS S7-300 Modules.............................................................................................................26
1.8 Environmental conditions for the operation of SIPLUS S7-300 modules ....................................29
2 Power supply modules............................................................................................................................. 31
2.1 Power supply module PS 307; 2 A; (6ES7307-1BA01-0AA0).....................................................32
2.2 Power supply module PS 307; 5 A; (6ES7307-1EA01-0AA0).....................................................35
2.3 Power supply module PS 307; 10 A; (6ES7307-1KA02-0AA0)...................................................38
2.4 Power supply module PS 305; 2 A; (6AG1305-1BA80-2AA0) ....................................................41
2.5 Power supply module PS 307; 5 A; (6AG1307-1EA80-2AA0) ....................................................44
3 Digital modules ........................................................................................................................................ 49
3.1 Module overview ..........................................................................................................................50
3.1.1 Digital input modules:...................................................................................................................50
3.1.2 Digital output modules .................................................................................................................53
3.1.3 Relay output modules ..................................................................................................................56
3.1.4 Digital IO modules........................................................................................................................57
3.2 Steps in selecting and commissioning the digital module ...........................................................58
3.3 Programming digital modules ......................................................................................................59
3.4 Diagnostics of digital modules .....................................................................................................60
3.5 How to protect digital modules from inductive overvoltage .........................................................62
3.6 Digital input module SM 321; DI 64 x DC 24 V, sinking/sourcing; (6ES7321-1BP00-0AA0) ......64
3.7 Digital input module SM 321; DI 32 x DC 24 V; (6ES7321-1BL00-0AA0)...................................72
3.8 Digital output module SM 321; DI 32 x AC 120 V; (6ES7321-1EL00-0AA0)...............................76
3.9 Digital input module SM 321; DI 16 x DC 24 V; (6ES7321-1BH02-0AA0) ..................................79
3.10 Digital input module SM 321; DI 16 x DC 24 V High Speed; (6ES7321-1BH10-0AA0) ..............83

Table of contents
S7-300 Module data
8 Manual, 02/2013, A5E00105505-08
3.11 Digital input module SM 321; DI 16 x 24 VDC; with hardware and diagnostic interrupts
(6ES7321-7BH01-0AB0)............................................................................................................. 85
3.11.1 Isochronous mode....................................................................................................................... 90
3.11.2 SM 321; DI 16 x DC 24 V - Parameters...................................................................................... 91
3.11.3 SM 321; DI 16 x DC 24 V - Diagnostics...................................................................................... 93
3.11.4 SM 321; DI 16 x DC 24 V - Behavior .......................................................................................... 95
3.11.5 SM 321; DI 16 x DC 24 V - Interrupts ......................................................................................... 96
3.12 Digital input module SM 321; DI 16 x DC 24/125 V; with hardware and diagnostic
interrupts (6ES7321-7EH00-0AB0)............................................................................................. 98
3.12.1 Parameters of SM 321; DI 16 x DC 24/125 V........................................................................... 102
3.12.2 Diagnostics of SM 321; DI 16 x DC 24/125 V........................................................................... 103
3.12.3 Interrupts of SM 321; DI 16 x DC 24/125 V .............................................................................. 105
3.13 Digital input module SM 321; DI 16 x DC 24 V; source input; (6ES7321-1BH50-0AA0) ......... 107
3.14 Digital input module SM 321; DI 16 x UC 24/48 V; (6ES7321-1CH00-0AA0).......................... 110
3.15 Digital input module SM 321; DI 16 x DC 48-125 V; (6ES7321-1CH20-0AA0)........................ 113
3.16 Digital input module SM 321; DI 16 x AC 120/230 V; (6ES7321-1FH00-0AA0)....................... 117
3.17 Digital input module SM 321; DI 8 x AC 120/230 V; (6ES7321-1FF01-0AA0)......................... 120
3.18 Digital input module SM 321; DI 8 x AC 120/230 V ISOL; (6ES7321-1FF10-0AA0)................ 124
3.19 Digital output module SM 322; DO 64 x DC 24 V/0.3 A sourcing; (6ES7322-1BP00-0AA0) ... 127
3.20 Digital output module SM 322; DO 64 x DC 24 V/0.3 A Sinking (6ES7322-1BP50-0AA0)...... 135
3.21 Digital output module SM 322; DO 32 x DC 24 V/ 0.5 A; (6ES7322-1BL00-0AA0) ................. 143
3.22 Digital output module SM 322; DO 32 x AC 120/230 V/1 A; (6ES7322-1FL00-0AA0)............. 147
3.23 Digital output module SM 322; DO 16 x DC 24 V/ 0.5 A; (6ES7322-1BH01-0AA0)................. 151
3.24 Digital output module SM 322; DO 16 x DC 24 V/0.5 A: (6ES7322-8BH10-0AB0).................. 155
3.24.1 Parameters of digital output modules ....................................................................................... 160
3.24.2 Diagnosis of digital output modules .......................................................................................... 161
3.24.3 Firmware update via HW Config ............................................................................................... 163
3.24.4 I&M identification data............................................................................................................... 164
3.25 Digital output module SM 322; DO 16 x DC 24 V/0.5 A High Speed;
(6ES7322-1BH10-0AA0)...........................................................................................................165
3.26 Digital output module SM 322; DO 16 x UC 24/48 V; (6ES7322-5GH00-0AB0)...................... 169
3.26.1 Parameters of digital output module SM 322 DO 16 x UC24/48 V........................................... 173
3.27 Digital output module SM 322; DO 16 x AC 120/230 V/1 A; (6ES7322-1FH00-0AA0) ............ 175
3.28 Digital output module SM 322; DO 8 x DC 24 V/2 A; (6ES7322-1BF01-0AA0) ....................... 179
3.29 Digital output module SM 322; DO 8 x DC 24 V/ 0.5 A; with diagnostics interrupt;
(6ES7322-8BF00-0AB0) ...........................................................................................................183
3.29.1 SM 322; DO 8 x DC 24 V/0.5 A - Parameters........................................................................... 188
3.29.2 SM 322; DO 8 x DC 24 V/0.5 A - Diagnostics........................................................................... 189
3.29.3 SM 322; DO 8 x DC 24 V/0.5 A - Behavior............................................................................... 191
3.29.4 SM 322; DO 8 x DC 24 V/0.5 A - Interrupts.............................................................................. 192
3.30 Digital output module SM 322; DO 8 x DC 48-125 V/1.5 A; (6ES7322-1CF00-0AA0)............. 193
3.31 Digital output module SM 322;DO 8 x AC 120/230 V/2 A; (6ES7322-1FF01-0AA0)................ 197

Table of contents
S7-300 Module data
Manual, 02/2013, A5E00105505-08 9
3.32 Digital output module SM 322; DO 8 x AC 120/230 V/2 A ISOL (6ES7322-5FF00-0AB0) .......201
3.32.1 Parameters of SM 322; DO 8 x AC 120/230 V/2 A ISOL ..........................................................205
3.32.2 SM 322; DO 8 x AC 120/230 V/2 A ISOL - Diagnostics ............................................................206
3.32.3 SM 322; DO 8 x AC 120/230 V/2 A ISOL - Interrupts................................................................207
3.33 Relay output module SM 322; DO 16 x Rel. AC 120/230 V; (6ES7322-1HH01-0AA0) ............208
3.34 Relay output module SM 322; DO 8 x Rel. AC 230 V; (6ES7322-1HF01-0AA0)......................212
3.35 Relay output module SM 322; DO 8 x Rel. 230VAC/5A; (6ES7322-5HF00-0AB0) ..................217
3.35.1 Parameters of SM 322; DO 8 x Rel. AC 230V/5A .....................................................................223
3.35.2 SM 322; DO 8 x Rel. AC 230V/5A - Diagnostics .......................................................................224
3.35.3 SM 322; DO 8 x Rel. AC 230V/5A - Interrupts...........................................................................225
3.36 Relay output module SM 322; DO 8 x Rel. AC 230 V/5 A; (6ES7322-1HF10-0AA0) ...............226
3.37 Digital IO module SM 323; DI 16/DO 16 x DC 24 V/0.5 A; (6ES7323-1BL00-0AA0)................232
3.38 Digital IO module SM 323; DI 8/DO 8 x DC 24 V/0.5 A; (6ES7323-1BH01-0AA0) ...................236
3.39 Programmable digital IO module SM 327; DI 8/DO 8 x DC 24 V/0.5 A
(6ES7327-1BH00-0AB0)............................................................................................................240
3.39.1 Parameters of SM 327; DI 8/DO 8 x 24 VDC/0.5 A...................................................................244
3.39.1.1 Structure of data record 1 of SM 327; DI 8/DO 8 x DC 24 V/0.5 A............................................245
4 Principles of analog value processing.................................................................................................... 247
4.1 Overview ....................................................................................................................................247
4.2 Wiring and connecting transducers to analog inputs.................................................................248
4.2.1 Wiring and connecting electrically isolated transducers ............................................................249
4.2.2 Wiring non-isolated transducers ................................................................................................251
4.3 Wiring and connecting voltage transducers...............................................................................253
4.4 Wiring and connecting current transducers ...............................................................................254
4.5 Wiring and connecting resistance thermometers and resistors.................................................256
4.6 Wiring and connecting thermocouples.......................................................................................258
4.6.1 Wiring and connecting thermocouples with internal compensation...........................................262
4.6.2 Wiring and connecting thermocouples with external compensation..........................................263
4.7 Wiring and connecting loads/actuators to analog outputs .........................................................267
4.7.1 Wiring and connecting loads/actuators to voltage outputs ........................................................268
4.7.2 Wiring and connecting loads/actuators to current outputs.........................................................270
5 Principles of analog modules................................................................................................................. 273
5.1 Representation of the values for analog input channels............................................................275
5.2 Representation of analog values for analog output channels....................................................292
5.3 Setting the measuring method and ranges of analog input channels........................................295
5.4 Response of the analog modules ..............................................................................................298
5.4.1 Influence of the power supply and operating state ....................................................................298
5.4.2 Influence of the range of analog values.....................................................................................300
5.4.3 Influence of operational limits and basic error limits..................................................................301
5.5 Conversion and cycle times of analog modules ........................................................................302
5.6 Settling and response times of analog output channels ............................................................306

Table of contents
S7-300 Module data
10 Manual, 02/2013, A5E00105505-08
5.7 Programming analog modules .................................................................................................. 307
5.7.1 Parameters of analog input modules ........................................................................................ 308
5.8 Diagnostics of analog modules ................................................................................................. 308
5.8.1 Diagnostics messages of analog input modules....................................................................... 309
5.8.2 Diagnostic messages of analog output modules ...................................................................... 310
5.8.3 Causes of error and troubleshooting at analog input modules ................................................. 311
5.8.4 Causes of error and troubleshooting at analog output modules............................................... 312
5.9 Interrupts of analog modules .................................................................................................... 313
6 Analog modules..................................................................................................................................... 315
6.1 Analog module selection and commissioning sequence .......................................................... 316
6.2 Module overview ....................................................................................................................... 317
6.2.1 Analog input modules................................................................................................................ 317
6.2.2 Analog output modules ............................................................................................................. 320
6.2.3 Analog I/O modules................................................................................................................... 321
6.3 Analog input module SM 331; AI 8 x 16 bit; (6ES7331-7NF00-0AB0) ..................................... 322
6.3.1 Measurement types and ranges ............................................................................................... 328
6.3.2 Programmable parameters ....................................................................................................... 329
6.3.3 Additional information on SM 331; AI 8 x 16 Bit........................................................................ 331
6.4 Analog input module SM 331; AI 8 x 16 Bit; (6ES7331-7NF10-0AB0)..................................... 333
6.4.1 Measurement types and measuring ranges.............................................................................. 339
6.4.2 Programmable parameters ....................................................................................................... 340
6.4.3 Additional information for SM 331; AI 8 x 16 Bit ....................................................................... 341
6.5 Analog input module SM 331; AI 8 x 14 Bit High Speed; isochrone;
(6ES7331-7HF0x-0AB0) ...........................................................................................................345
6.5.1 Measurement types and measuring ranges.............................................................................. 351
6.5.2 Programmable parameters ....................................................................................................... 353
6.5.3 Isochronous mode..................................................................................................................... 354
6.5.4 Additional information on SM 331; AI 8 x 14 Bit High Speed, isochrone.................................. 356
6.6 Analog input module SM 331; AI 8 x 13 Bit; (6ES7331-1KF02-0AB0) ..................................... 357
6.6.1 Measurement types and measuring ranges.............................................................................. 365
6.6.2 Programmable parameters ....................................................................................................... 366
6.6.3 Additional information on SM 331; AI 8 x 13 Bit........................................................................ 367
6.7 Analog input module SM 331; AI 8 x 12 bit;(6ES7331-7KF02-0AB0) ...................................... 370
6.7.1 Analog input module SM 331; AI 8 x 12 bit;(6ES7331-7KF02-0AB0) ...................................... 370
6.7.2 Measurement types and ranges ............................................................................................... 381
6.7.3 Programmable parameters ....................................................................................................... 384
6.7.4 Additional information on SM 331; AI 8 x 12 Bit........................................................................ 385
6.8 Analog input module SM 331; AI 2 x 12 Bit; (6ES7331-7KB02-0AB0)..................................... 386
6.8.1 Analog input module SM 331; AI 2 x 12 Bit; (6ES7331-7KB02-0AB0)..................................... 386
6.8.2 Measurement types and measuring ranges.............................................................................. 396
6.8.3 Programmable parameters ....................................................................................................... 398
6.8.4 Additional information on SM 331; AI 2 x 12 Bit........................................................................ 399
6.9 Analog input module SM 331; AI 8 x RTD; (6ES7331-7PF01-0AB0)....................................... 400
6.9.1 Measurement types and measuring ranges.............................................................................. 407
6.9.2 Programmable parameters ....................................................................................................... 410
6.9.3 Additional information on SM 331; AI 8 x RTD ......................................................................... 412

Table of contents
S7-300 Module data
Manual, 02/2013, A5E00105505-08 11
6.10 Analog input module SM 331; AI 8 x TC; (6ES7331-7PF11-0AB0) ..........................................416
6.10.1 Measurement types and measuring ranges ..............................................................................425
6.10.2 Adjustable parameters ...............................................................................................................426
6.10.3 Additional information on SM 331; AI 8 x TC.............................................................................428
6.11 Analog input module SM 331, AI 6 x TC isolated (6ES7331-7PE10-0AB0)..............................433
6.11.1 Measurement types and measuring ranges ..............................................................................444
6.11.2 Programmable parameters ........................................................................................................445
6.11.3 Additional information relating to SM 331; AI 6 x TC.................................................................446
6.11.4 Firmware update via HW Config for analog input module SM 331; AI 6 x TC ..........................453
6.11.5 I&M data for identifying the analog input module SM 331; AI 6 x TC........................................455
6.11.6 Calibration of analog input module SM 331; AI 6 x TC..............................................................456
6.12 Analog output module SM 332; AO 8 x 12 bit; (6ES7332-5HF00-0AB0) ..................................463
6.12.1 SM 332; AO 8 x 12 Bit - Output ranges .....................................................................................468
6.12.2 Programmable parameters ........................................................................................................469
6.12.3 Additional information on SM 332; AO 8 x 12 Bit.......................................................................470
6.13 Analog output module SM 332; AO 4 x 16 bit; isochrone; (6ES7332-7ND02-0AB0)................471
6.13.1 SM 332; AO 4 x 16 Bit - Output ranges .....................................................................................477
6.13.2 Programmable parameters ........................................................................................................478
6.13.3 Isochronous mode .....................................................................................................................479
6.13.4 Additional information on SM 332; AO 4 x 16 Bit.......................................................................480
6.14 Analog output module SM 332; AO 4 x 12 Bit; (6ES7332-5HD01-0AB0) .................................481
6.14.1 Output ranges of SM 332; AO 4 x 12 Bit ...................................................................................487
6.14.2 Programmable parameters ........................................................................................................488
6.14.3 Additional information on SM 332; AO 4 x 12 Bit.......................................................................489
6.15 Analog output module SM 332; AO 2 x 12 Bit; (6ES7332-5HB01-0AB0) .................................490
6.15.1 Output ranges of SM 332; AO 2 x 12 Bit ...................................................................................496
6.15.2 Programmable parameters ........................................................................................................497
6.15.3 Additional information on SM 332; AO 2 x 12 Bit.......................................................................498
6.16 Analog IO module SM 334; AI 4/AO 2 x 8/8 Bit; (6ES7334-0CE01-0AA0) ...............................499
6.16.1 SM 334; AI 4/AO 2 x 8/8 Bit - Function principle .......................................................................505
6.16.2 Measurement and output type of SM 334; AI 4/AO 2 x 8/8 bit ..................................................506
6.16.3 Measurement and output ranges of SM 334; AI 4/ AO 2 x 8/8 bit.............................................506
6.16.4 Additional information on SM 334; AI 4/AO2 x 8/8 Bit ...............................................................506
6.17 Analog IO module SM 334; AI 4/AO 2 x 12 bit; (6ES7334-0KE00-0AB0).................................507
6.17.1 Programmable parameters ........................................................................................................513
6.17.2 Measurement types and ranges ................................................................................................514
6.17.3 Additional information on SM 334; AI 4/ AO 2 x 12 bit ..............................................................515
7 Other signal modules............................................................................................................................. 517
7.1 Module overview ........................................................................................................................517
7.2 Simulator module SM 374; IN/OUT 16; (6ES7374-2XH01-0AA0).............................................518
7.3 Dummy module DM 370; (6ES7370-0AA01-0AA0)...................................................................521
7.4 Position decoder module SM 338; POS-INPUT; (6ES7338-4BC01-0AB0) ..............................523
7.4.1 Isochronous mode .....................................................................................................................525
7.4.2 Wiring and block diagrams.........................................................................................................526
7.4.3 Functions of SM 338; POS-INPUT; encoder value acquisition .................................................527
7.4.3.1 Encoder value acquisition ..........................................................................................................527

Table of contents
S7-300 Module data
12 Manual, 02/2013, A5E00105505-08
7.4.3.2 Gray code/binary code converter.............................................................................................. 527
7.4.3.3 Transferred encoder value and scaling..................................................................................... 528
7.4.3.4 Freeze function ......................................................................................................................... 530
7.4.4 Parametrization SM 338 POS-INPUT....................................................................................... 530
7.4.5 Addressing SM 338 POS-INPUT ..............................................................................................532
7.4.6 Diagnostics of SM 338; POS-INPUT ........................................................................................ 534
7.4.7 SM 338; POS INPUT - Interrupts.............................................................................................. 536
7.4.8 Technical data of SM 338; POS-INPUT.................................................................................... 537
8 Interface modules .................................................................................................................................. 541
8.1 Module overview ....................................................................................................................... 541
8.2 Interface module IM 360; (6ES7360-3AA01-0AA0).................................................................. 542
8.3 Interface module IM 361; (6ES7361-3CA01-0AA0).................................................................. 544
8.4 Interface module IM 365; (6ES7365-0BA01-0AA0).................................................................. 546
A Parameter sets of signal modules.......................................................................................................... 549
A.1 Principles of programming signal modules in the user program............................................... 549
A.2 Parameters of digital IO modules.............................................................................................. 551
A.3 Parameters of the digital input module SM 321; DI 16 x DC 24/125 V..................................... 553
A.4 Parameters of digital output modules .......................................................................................555
A.5 Settings from the digital output module SM 322; DO 16 x DC 24 V/0.5 A
(6ES7322-8BH10-0AB0)...........................................................................................................557
A.6 Parameters of analog input modules ........................................................................................ 560
A.7 Parameters of analog input module SM 331; AI 8 x RTD......................................................... 564
A.8 Parameters of SM 331; AI 8 TC................................................................................................ 574
A.9 Parameters of analog input module SM 331; AI 8 x 13 Bit....................................................... 582
A.10 Setting of the analog input module SM 331; AI 8 x 16 Bit (6ES7331-7NF10-0AB0) ................ 585
A.11 Parameters of analog input module SM 331; AI 6 x TC isolated.............................................. 592
A.12 Parameters of analog output modules ...................................................................................... 599
A.13 Parameters of analog output module SM 332; AO 8 x 12 Bit................................................... 602
A.14 Parameters of analog IO modules ............................................................................................ 605
B Diagnostics data of signal modules........................................................................................................ 609
B.1 Evaluating diagnostic data of signal modules in the user program........................................... 609
B.2 Structure and content of diagnostics data, byte 0 and up......................................................... 610
B.3 Channel-specific diagnostics data ............................................................................................ 614
B.4 Diagnosis data from the SM 322; DO 16 x DC24 V/0.5 A (6ES7322-8BH10-0AB0)................ 616
B.5 Diagnostics data of SM 331; AI 6 x TC isolated........................................................................ 619
B.6 Diagnostics data of SM 338; POS-INPUT ................................................................................ 622

Table of contents
S7-300 Module data
Manual, 02/2013, A5E00105505-08 13
C Dimensional drawings............................................................................................................................ 625
C.1 Dimensional drawings of the mounting rails ..............................................................................626
C.1.1 Bus modules ..............................................................................................................................632
C.2 Dimensional drawings of the power supply modules.................................................................633
C.3 Dimensional drawings of the interface modules ........................................................................637
C.4 Dimensional drawings of the signal modules.............................................................................639
C.5 Dimensional drawings of accessories........................................................................................641
D Spare parts and accessories for S7-300 modules ................................................................................. 643
E Directive on handling Electrostatic-Sensitive Devices (ESD)................................................................. 647
E.1 Definition of ESD........................................................................................................................647
E.2 Electrostatic charging of the body..............................................................................................648
E.3 Basic protective measures against electrostatic discharge .......................................................649
F Service & support .................................................................................................................................. 651
F.1 Service & support.......................................................................................................................651
G List of abbreviations............................................................................................................................... 653
G.1 List of abbreviations ...................................................................................................................653
Glossary ................................................................................................................................................ 655
Index...................................................................................................................................................... 665

Table of contents
S7-300 Module data
14 Manual, 02/2013, A5E00105505-08

S7-300 Module data
Manual, 02/2013, A5E00105505-08 15
General technical data 1
1.1 Standards and approvals
Introduction
Contents of general technical data:
● standards and test values satisfied by modules of the S7-300 automation system
● test criteria of S7-300 modules.
Note
Information on the nameplate
You will find the current labels and approvals on the nameplate of the respective
modules.
Safety guidelines
WARNING
Personal injury and damage to property may occur.
In potentially explosive environments, there is a risk of injury or damage if you disconnect
any connectors while the S7-300 is in operation.
Always isolate the S7-300 operated in such areas before you disconnect and connectors.
WARNING
Explosion hazard
Components may no longer qualify for Class I, Div. 2 if they are replaced.
WARNING
This S7-300 modules are only suitable for use in Class I, Div. 2, Group A, B, C, D, or in
non-hazardous areas.

General technical data
1.1 Standards and approvals
S7-300 Module data
16 Manual, 02/2013, A5E00105505-08
Test symbols and their significance
The test symbols and their meanings are described in the following section.
CE Label
The S7-300 automation system satisfies the requirements and protection goals of the
following EC directives, and conforms with the harmonized European standards (EN) for
programmable logic controllers announced in the Official Journals of the European
Community:
● 2006/95/EC "Electrical Equipment Designed for Use within Certain Voltage Limits"
(LowVoltage Directive)
● 2004/108/EC "Electromagnetic Compatibility" (EMC Directive)
● 94/9/EC "Equipment and protective systems intended for use in potentially explosive
atmospheres" (Explosion Protection Directive)
The EC declaration of conformity is held on file available to competent authorities at:
Siemens AG
Automation & Drives Group
Industry Sector I IA AS R&D DH A
P.O. Box 1963
92209 Amberg, Germany
You can also download this under the keyword "Declaration of conformity" on the Internet
(http://support.automation.siemens.com/WW/view/en/37217116/134200).
UL certification
Underwriters Laboratories Inc., complyling with
● UL 508 (Industrial Control Equipment)

General technical data
1.1 Standards and approvals
S7-300 Module data
Manual, 02/2013, A5E00105505-08 17
CSA approval
Canadian Standards Association to
● C22.2 No. 142 (Process Control Equipment)
or
cULus approval
Underwriters Laboratories Inc. complying with
● UL 508 (Industrial Control Equipment)
● CSA C22.2 No. 142 (Process Control Equipment)
or
cULus HAZ. LOC. - approval
+$=/2&
Underwriters Laboratories Inc., complying with
● UL 508 (Industrial Control Equipment)
● UL 1604 (Hazardous Location)
● CSA C22.2 No. 142 (Process Control Equipment)
● CSA C22.2 No. 213 (Hazardous Location)
APPROVED for use in
Class I, Division 2, Group A, B, C, D Tx;
Class I, Zone 2, Group IIC Tx

General technical data
1.1 Standards and approvals
S7-300 Module data
18 Manual, 02/2013, A5E00105505-08
FM approval
Factory Mutual Research (FM) in accordance with
Approval Standard Class Number 3611, 3600, 3810
APPROVED for use in
Class I, Division 2, Group A, B, C, D Tx;
Class I, Zone 2, Group IIC Tx
ATEX approval
In accordance with EN 60079-15 (Electrical Apparatus for Potentially Explosive
Atmospheres; Type of Protection "n") and EN 60079-0 (Electrical apparatus for potentially
explosive gas atmospheres - Part 0: General Requirements)
,,*([Q$,,77
Marking for Australia and New Zealand
The S7-300 automation system satisfies requirements of standards to
AS/NZS CISPR 16.
IEC 61131
The S7-300 automation system satisfies requirements and criteria to
IEC 61131-2 (Programmable Controllers, Part 2: Equipment requirements and tests).

General technical data
1.1 Standards and approvals
S7-300 Module data
Manual, 02/2013, A5E00105505-08 19
Marine approval
Classification societies:
● ABS (American Bureau of Shipping)
● BV (Bureau Veritas)
● DNV (Det Norske Veritas)
● GL (Germanischer Lloyd)
● LRS (Lloyds Register of Shipping)
● Class NK (Nippon Kaiji Kyokai)
Use in industrial environments
SIMATIC products are designed for industrial applications.
Table 1- 1 Use in industrial environments
Field of application Noise emission requirements Noise immunity requirements
Industry EN 61000-6-4: 2007 EN 61000-6-2: 2005
Use in residential areas
Note
The S7-300 is designed for use in industrial areas; using it in residential areas could disturb
radio and TV reception.
To operate an S7-300 in a residential area, it's RF emission must comply with Limit Value
Class B to EN 55011.
Suitable measures for achieving the required Class B radio interference level include, for
example:
● S7-300 installation in grounded switch cabinets / cubicles
● Use of noise filters in the supply lines

General technical data
1.2 Electromagnetic compatibility
S7-300 Module data
20 Manual, 02/2013, A5E00105505-08
1.2 Electromagnetic compatibility
Definition
Electromagnetic compatibility (EMC) is the ability of an electrical installation to function
satisfactorily in its electromagnetic environment without interfering with that environment.
The S7-300 modules also satisfy requirements of EMC legislation for the European domestic
market. Compliance of the S7-300 system with specifications and directives on electric
design is prerequisite.
Pulseshaped disturbance
The table below shows the EMC compatibility of S7 modules in areas subject to pulse-
shaped disturbance.
Pulse-shaped disturbance Test voltage corresponds with degree
of severity
Electrostatic discharge
to IEC 61000-4-2
Air discharge: ± 8 kV
Contact discharge ± 4 kV
3
2
Burst pulses (high-speed
transient disturbance)
to IEC 61000-4-4.
2 kV (power supply lines)
2 kV (signal lines > 3 m)
1 kV (signal lines < 3 m)
3
3
High-energy single pulse (surge) to IEC 61000-4-5
External protective circuit required
(refer to
S7-300 Automation System, Hardware and Installation,
Chapter "Lightning and overvoltage protection")
•asymmetric coupling 2 kV (power supply lines)
DC with protective elements
2 kV (signal/ data line only > 3 m),
with protective elements as required
•symmetric coupling 1 kV (power supply lines) DC with
protective elements
1 kV (signal/ data line only > 3 m),
with protective elements as required
3
Additional measures
When connecting an S7-300 system to the public network, always ensure compliance with
Limit Value Class B to EN 55022.
